Sinetek's Driver for Realtek "RTSX" SDHC Card Readers

[micha3]

I tried with a 5209 on 10.12.3 with no luck. In the konsole the card attach and detache is recognized, but enabling is not possible. Can someone help? Thanks in advance.

Standard 18:19:42.379869 +0100 kernel rtsx: attach card
Standard 18:19:42.535450 +0100 symptomsd rssi (-70) or transmitRate (351.000000) changed on interface en1 for BSSID:
Standard 18:19:43.632614 +0100 kernel rtsx: cmd 52 arg=0x80000c08 data=0x0 dlen=0 flags=0x1c01 proc="" (error 60)
Standard 18:19:44.386407 +0100 opendirectoryd Client: , UID: 501, EUID: 501, GID: 20, EGID: 20
Standard 18:19:44.633748 +0100 kernel rtsx: cmd 5 arg=0 data=0x0 dlen=0 flags=0x1031 proc="" (error 60)
Standard 18:19:44.634799 +0100 kernel rtsx: cmd 0 arg=0 data=0x0 dlen=0 flags=0x21 proc="" (error 0)
Standard 18:19:45.049994 +0100 opendirectoryd Client: , UID: 0, EUID: 0, GID: 0, EGID: 0
Standard 18:19:45.050463 +0100 opendirectoryd Client: , UID: 0, EUID: 0, GID: 20, EGID: 20
Standard 18:19:45.050977 +0100 opendirectoryd Client: , UID: 501, EUID: 501, GID: 20, EGID: 20
Standard 18:19:45.061231 +0100 opendirectoryd Client: , UID: 501, EUID: 501, GID: 20, EGID: 20
Standard 18:19:45.635587 +0100 kernel rtsx: cmd 55 arg=0 data=0x0 dlen=0 flags=0x1c01 proc="" (error 60)
Standard 18:19:46.636794 +0100 kernel rtsx: cmd 1 arg=0x40000000 data=0x0 dlen=0 flags=0x1031 proc="" (error 60)
Standard 18:19:46.636819 +0100 kernel rtsx: can't read memory OCR
Standard 18:19:46.638328 +0100 kernel rtsx: can't enable card
Standard 18:19:46.638339 +0100 kernel rtsx: detach card

[jaymonkey]

I tried with a 5209 on 10.12.3 with no luck. In the konsole the card attach and detache is recognized, but enabling is not possible. Can someone help? Thanks in advance.



It might be worth trying it with another brand or type of smart card ....

your system with 5209 reader got much further than mine with 525A reader ...



Good Luck

Jay

[kikiwora]

So, the new version does not work at all for all of us, except for new device entry in IOReg...

[xXConcasXx]

On 11/2/2017 at 11:51 PM, Sinetek said:

macOS kext_rtsx



Hi, making a new thread. This driver is for Realtek SDHC card readers on a pci/pcie bus, most commonly found in laptops.

I would like to get testers. The driver is not yet finalized, but I'm making the tread now anyway since there was interest. expect this post to change in the future.



[read below for current status]





-- sinetek





things to fix eventually



- get more pci id's in plist

- async task in its own thread instead of blocking the os

- prealloc DMA buffer?

- cards with sector_size != 512, haven't been tested at all.

- clean up src. git push.

- power management? what happens when you sleep the machine?

- the eject button in finder is broken, do not use for now.

- spams the syslog with debug messages. release config?

- basic namespace pollution a bit out of hand



Update 1:



Power management support on the way: see post #43.

Does it works for:

PCI\VEN_10EC&DEV_5287&SUBSYS_202F1043&REV_01


Realtek PCIE CardReader

[mnfesq]

On 3/23/2018 at 1:33 PM, xXConcasXx said:

Does it works for:

PCI\VEN_10EC&DEV_5287&SUBSYS_202F1043&REV_01


Realtek PCIE CardReader

Yours is 0x528710EC.  According to this post, it is supported:

https://www.insanelymac.com/forum/forums/topic/321080-sineteks-driver-for-realtek-rtsx-sdhc-card-readers/?do=findComment&comment=2376387

Edited March 26, 2018 by mnfesq

[Dec_Bra1n]

On 02/03/2017 at 6:11 PM, Sinetek said:

Hi folks!



little update:



I'm working on the power management support, so that you call can put your laptops in suspend/resume.
Nothing is crashing but the driver is not calling my save/resume state routine, and I'm not sure why yet.



if someone wants to help with testing, here's the latest (debug) build of this thing.



let me know if you see the text "rtsx_softc::setPowerState" in the dmesg log output.



For the record my machine is a X240 thinkpad.

List of supported ID's:  0x520910EC 0x522710EC 0x522910EC 0x522A10EC 0x524910EC 0x528610EC 0x528710EC 0x528910EC

If yours is different try adding it manually to plist and then report.



thanks!



Sinetek-rtsx.kext.zip

not working man i have 10EC, 5209, 103C, 3388, Realtek Semiconductor Co., Ltd., RTS5209 PCI Express Card Reader this is my log

0:100  0:100  MemLog inited, TSC freq: 1995466252
0:100  0:000  CPU was calibrated with ACPI PM Timer
0:100  0:000  LegacyRegion2: Chipset/proc: 0x01048086
0:100  0:000   Next Generation Core processors (PAM 0x80-0x86)
0:100  0:000   Test PAM1=(0x41=90, 0x5a=00, 0x81=11, 0x91=00) at chipset 01048086
0:100  0:000  , Install = Success
0:113  0:013  BiosVideoDriverBindingStart!
0:113  0:000  BiosVideoCheckForVbe
0:113  0:000  EdidOverride not found
0:125  0:012   Edid1+
0:125  0:000   found Detail Timing 1366x768
0:125  0:000  timing string after 0xFE:SAMSUNG

0:125  0:000  timing string after 0xFE:156AT05-H07

0:137  0:012   Edid0+
0:137  0:000   found Detail Timing 1366x768
0:137  0:000  ... already present
0:137  0:000  timing string after 0xFE:SAMSUNG

0:137  0:000  timing string after 0xFE:156AT05-H07

0:138  0:000     0 1024x768 attr=9B - ok, edid-, 1024x768, working, highest, pref=0
0:138  0:000     1 640x480 attr=9B - ok, edid-, 640x480, working
0:138  0:000     2 800x600 attr=9B - ok, edid-, 800x600, working
0:139  0:000  BV new mode: 0 1024x768
0:267  0:128   SetMode pref 0 (0) = Success
1:496  1:229
1:496  0:000  Now is 11.4.2018,  18:28:30 (GMT)
1:496  0:000  Starting Clover revision: 4411 on CLOVER EFI
1:496  0:000  Build with: [Args: -D NO_GRUB_DRIVERS_EMBEDDED -t XCODE8 | -D NO_GRUB_DRIVERS_EMBEDDED -D USE_LOW_EBDA -a X64 -b RELEASE -t XCODE8 -n 5 | OS: 10.12.6 | XCODE: 9.2]
1:496  0:000  SelfDevicePath=PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(1,GPT,D47655B6-67B7-43E7-9B5A-3468812E2D09,0x28,0x64000) @AC037A18
1:496  0:000  SelfDirPath = \EFI\CLOVER
1:497  0:000  === [ Get Smbios ] ========================================
1:497  0:000  Type 16 Index = 0
1:497  0:000  Total Memory Slots Count = 2
1:497  0:000  Type 17 Index = 0
1:497  0:000  Table has error information, checking
1:497  0:000  Found memory information in table 18/0, type=0x3, operation=0x2 syndrome=0x0
1:497  0:000  ...memory OK
1:497  0:000  SmbiosTable.Type17->Speed = 1333MHz
1:497  0:000  SmbiosTable.Type17->Size = 4096MB
1:497  0:000  SmbiosTable.Type17->Bank/Device = BANK 0 Bottom - Slot 1 (top)
1:497  0:000  SmbiosTable.Type17->Vendor =
1:497  0:000  SmbiosTable.Type17->SerialNumber = 03000000
1:497  0:000  SmbiosTable.Type17->PartNumber = CMSO4GX3M1A1333C9
1:497  0:000  Type 17 Index = 1
1:497  0:000  Table has error information, checking
1:497  0:000  Found memory information in table 18/1, type=0x3, operation=0x2 syndrome=0x0
1:497  0:000  ...memory OK
1:497  0:000  SmbiosTable.Type17->Speed = 1333MHz
1:497  0:000  SmbiosTable.Type17->Size = 4096MB
1:497  0:000  SmbiosTable.Type17->Bank/Device = BANK 2 Bottom - Slot 2 (under)
1:497  0:000  SmbiosTable.Type17->Vendor = Hynix
1:497  0:000  SmbiosTable.Type17->SerialNumber = 10239B68
1:497  0:000  SmbiosTable.Type17->PartNumber = HMT351S6BFR8C-H9
1:497  0:000  Boot status=0
1:497  0:000  Running on: 'HP Pavilion dv6 Notebook PC' with board '3388'
1:497  0:000  === [ GetCPUProperties ] ==================================
1:497  0:000  CPU Vendor = 756E6547 Model=206A7
1:497  0:000   The CPU supported SSE4.1
1:497  0:000  BrandString = Intel(R) Core(TM) i7-2630QM CPU @ 2.00GHz
1:497  0:000   The CPU supported turbo
1:497  0:000  MSR 0x35               40008
1:497  0:000  MSR 0xE2 before patch 1E000404
1:497  0:000  MSR 0xCE              00000800_60011400
1:497  0:000  MSR 0x1B0             00000000
1:497  0:000  FSBFrequency = 100 MHz, DMI FSBFrequency = 1333 MHz, Corrected FSBFrequency = 100 MHz
1:497  0:000  MaxDiv/MinDiv: 20.0/8
1:497  0:000  Turbo: 26/26/28/29
1:497  0:000  Features: 0xBFEBFBFF
1:497  0:000  Threads: 8
1:497  0:000  Cores: 4
1:497  0:000  FSB: 100 MHz
1:497  0:000  CPU: 2000 MHz
1:497  0:000  TSC: 2000 MHz
1:497  0:000  PIS: 400 MHz
1:497  0:000  ExternalClock: 100 MHz
1:497  0:000  === [ GetDevices ] ========================================
1:497  0:000  PCI (00|00:00.00) : 8086 0104 class=060000
1:497  0:000  PCI (00|00:02.00) : 8086 0116 class=030000
1:497  0:000   - GFX: Model=Intel HD Graphics 3000 (Intel)
1:497  0:000  PCI (00|00:16.00) : 8086 1C3A class=078000
1:497  0:000  PCI (00|00:1A.00) : 8086 1C2D class=0C0320
1:497  0:000  PCI (00|00:1B.00) : 8086 1C20 class=040300
1:497  0:000  PCI (00|00:1C.00) : 8086 1C10 class=060400
1:497  0:000  PCI (00|01:00.00) : 10EC 8168 class=020000
1:497  0:000   - LAN: 0 Vendor=Realtek
1:497  0:000  PCI (00|00:1C.01) : 8086 1C12 class=060400
1:497  0:000  PCI (00|07:00.00) : 168C 002B class=028000
1:497  0:000   - WIFI: Vendor=Atheros
1:497  0:000  PCI (00|00:1C.02) : 8086 1C14 class=060400
1:497  0:000  PCI (00|0D:00.00) : 10EC 5209 class=FF0000
1:497  0:000  PCI (00|00:1C.03) : 8086 1C16 class=060400
1:497  0:000  PCI (00|13:00.00) : 1033 0194 class=0C0330
1:497  0:000  PCI (00|00:1D.00) : 8086 1C26 class=0C0320
1:497  0:000  PCI (00|00:1F.00) : 8086 1C49 class=060100
1:497  0:000  PCI (00|00:1F.02) : 8086 1C03 class=010601
1:497  0:000  PCI (00|00:1F.03) : 8086 1C22 class=0C0500
1:497  0:000  === [ GetDefaultSettings ] ================================
1:497  0:000  Clover load options size = 0 bytes
1:501  0:003  EFI\CLOVER\config.plist loaded: Success
1:501  0:000  === [ GetListOfThemes ] ===================================
1:503  0:002  - [00]: BGM
1:506  0:003  - [01]: embedded
1:507  0:000  - [01]: metal
1:510  0:003  - [02]: random
1:510  0:000  - [02]: HighSierra
1:512  0:001  - [03]: HP
1:512  0:000  - [04]: Nightwish
1:512  0:000  - [05]: One
1:513  0:000  - [06]: black color
1:515  0:001  - [07]: Neon
1:516  0:001  === [ Found config plists ] ===============================
1:516  0:000  - config.plist
1:518  0:002  === [ GetEarlyUserSettings ] ==============================
1:518  0:000  timeout set to -1
1:518  0:000  Custom boot CUSTOM_BOOT_DISABLED (0x0)
1:518  0:000  KextsToPatch: 3 requested
1:518  0:000   - [00]: com.apple.iokit.IOAHCIBlockStorage (Enable TRIM for SSD) :: BinPatch :: data len: 11
1:518  0:000   - [01]: com.apple.iokit.IOGraphicsFamily (Boot graphics glitch, 10.10.x/10.11.x (credit lisai9093, cecekpawon)) :: BinPatch :: data len: 5
1:518  0:000   - [02]: com.apple.driver.AppleBacklight (AppleBacklightInjector.kext) :: BinPatch :: data len: 9
1:519  0:000  Default theme: Nightwish
1:519  0:000  === [ LoadDrivers ] =======================================
1:521  0:002  Loading AppleImageCodec-64.efi  status=Success
1:522  0:000  Loading AppleKeyAggregator-64.efi  status=Success
1:522  0:000  Loading AppleUITheme-64.efi  status=Success
1:523  0:000  Loading FirmwareVolume-64.efi  status=Success
1:523  0:000  Loading FSInject-64.efi  status=Success
1:524  0:001  Loading SMCHelper-64.efi  status=Success
1:524  0:000  Loading XhciDxe-64.efi  status=Success
1:525  0:000   - driver needs connecting
1:525  0:000  Loading apfs.efi  status=Success
1:529  0:004   - driver needs connecting
1:529  0:000  Video bios patch requested or CustomEDID - forcing video reconnect
1:529  0:000  3 drivers needs connecting ...
1:529  0:000  PlatformDriverOverrideProtocol->GetDriver overriden
1:529  0:000  EdidActive: size=128 found
1:529  0:000  APFS driver loaded
1:529  0:000  Video driver loaded: disconnect Success
1:641  0:111  VideoBiosPatchNativeFromEdid:
1:641  0:000   Bios: VideoBiosPatchInit(LegacyRegion = Not Found, LegacyRegion2 = Success) = Success
1:641  0:000   VideoBiosUnlock:  unlocked
1:641  0:000   Patching: Patch BT_INTEL:  Parse Edid: descriptor block 0 is timing descriptor (h_active: 1366, v_active: 768, h_sync_offset: 48, h_sync_width: 32, h_blanking: 114, v_blanking: 12, pixel_clock: 6930, v_sync_offset: 2, v_sync_width: 5)
1:641  0:000   patched 2 time(s)
1:641  0:000   VideoBiosLock: Success
1:653  0:012  BiosVideoDriverBindingStart!
1:653  0:000  BiosVideoCheckForVbe
1:653  0:000  EdidOverride not found
1:666  0:012   Edid1+
1:666  0:000   found Detail Timing 1366x768
1:666  0:000  timing string after 0xFE:SAMSUNG

1:666  0:000  timing string after 0xFE:156AT05-H07

1:678  0:012   Edid0+
1:678  0:000   found Detail Timing 1366x768
1:678  0:000  ... already present
1:678  0:000  timing string after 0xFE:SAMSUNG

1:678  0:000  timing string after 0xFE:156AT05-H07

1:679  0:000     0 1366x768 attr=9B - ok, edid+, working, highest, pref=0
1:679  0:000     1 640x480 attr=9B - ok, edid-, 640x480, working
1:679  0:000     2 800x600 attr=9B - ok, edid-, 800x600, working
1:679  0:000  BV new mode: 0 1366x768
1:827  0:148   SetMode pref 0 (0) = Success
2:156  0:329  === [ InitScreen ] ========================================
2:156  0:000  SetScreenResolution: 1366x786 - not found!
2:156  0:000  Console modes reported: 4, available modes:
2:156  0:000   - [01]: 80x25
2:156  0:000   - [03]: 100x31
2:156  0:000   - [04]: 170x40 (current mode)
2:156  0:000  SetScreenResolution: 1366x768 - already set
2:156  0:000  reinit: self device path=PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(1,GPT,D47655B6-67B7-43E7-9B5A-3468812E2D09,0x28,0x64000)
2:156  0:000  === [ GetMacAddress ] =====================================
2:156  0:000  === [ ScanSPD ] ===========================================
2:157  0:000  SMBus device : 8086 1C22 class=0C0500 status=Success
2:157  0:000  SMBus CmdReg: 0x3
2:157  0:000  Scanning SMBus [8086:1C22], mmio: 0xC6506004, ioport: 0x5040, hostc: 0x1
2:157  0:000  Slots to scan [8]...
2:157  0:000  SPD[0]: Type 11 @0x50
2:176  0:018  Not using XMP because it is not present
2:176  0:000  DDR speed 1333MHz
2:176  0:000  Slot: 0 Type 24 4096MB 1333MHz Vendor=Corsair PartNo=CMSO4GX3M1A1333C9 SerialNo=0003000000000000
2:176  0:000  SPD[2]: Type 11 @0x52
2:195  0:019  Not using XMP because it is not present
2:195  0:000  DDR speed 1333MHz
2:195  0:000  Slot: 2 Type 24 4096MB 1333MHz Vendor=SK Hynix PartNo=HMT351S6BFR8C-H9N0 SerialNo=01000203090B0608
2:196  0:000  === [ GetAcpiTablesList ] =================================
2:196  0:000  Get Acpi Tables List from RSDT:
2:196  0:000   - [00]: FACP  SLIC-MPC len=244
2:196  0:000   - [01]: ASF!  INSYDE   len=165
2:196  0:000   - [02]: HPET  INSYDE   len=56
2:196  0:000   - [03]: APIC  INSYDE   len=140
2:196  0:000   - [04]: MCFG  INSYDE   len=60
2:196  0:000   - [05]: SLIC  SLIC-MPC len=374
2:196  0:000   - [06]: SSDT  INSYDE   len=1311
2:196  0:000   - [07]: BOOT  INSYDE   len=40
2:196  0:000   - [08]: ASPT  INSYDE   len=52
2:196  0:000   - [09]: SSDT  INSYDE   len=2316
2:196  0:000   - [10]: SSDT  INSYDE   len=2454
2:196  0:000   - [11]: SSDT  INSYDE   len=730
2:196  0:000   - [12]: SSDT  INSYDE   len=861
2:196  0:000  Calibrated TSC Frequency = 1995466252 = 1995MHz
2:196  0:000  === [ GetUserSettings ] ===================================
2:196  0:000  USB FixOwnership: yes
2:196  0:000   - final DSDT Fix mask=11400000
2:196  0:000  smartUPS: present
2:196  0:000  Using ProductName from config: MacBookPro8,2
2:196  0:000  Using latest BiosVersion from config
2:196  0:000  BiosVersion: MBP81.88Z.004E.B00.1801250923
2:196  0:000  BiosReleaseDate: 01/25/18
2:196  0:000  Using FirmwareFeatures from config: 0xC00DE137
2:196  0:000  Using FirmwareFeaturesMask from config: 0xFF1FFF3F
2:196  0:000  Board-ID set from config as Mac-94245A3940C91C80
2:196  0:000  BoardType: 0xA
2:196  0:000  ChassisType: 0xA
2:196  0:000  Converted CustomUUID 9D34717B-6B12-BBEC-525D-2C27D7B48515
4:123  1:926  === [ ScanVolumes ] =======================================
4:123  0:000  Found 14 volumes with blockIO
4:123  0:000  - [00]: Volume: PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)
4:125  0:001          Result of bootcode detection: bootable unknown (legacy)
4:125  0:000  - [01]: Volume: PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)
4:513  0:387  - [02]: Volume: PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(1,GPT,D47655B6-67B7-43E7-9B5A-3468812E2D09,0x28,0x64000)
4:515  0:002          Result of bootcode detection: bootable unknown (legacy)
4:515  0:000          This is SelfVolume !!
4:515  0:000  - [03]: Volume: PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(2,GPT,2B29288D-D40C-44D5-98FB-226382368AFB,0x64028,0x7746680)
4:516  0:000  - [04]: Volume: PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(3,GPT,83FAF4E7-CC92-44E5-BC88-6FC7E0AC20E8,0x77AA6A8,0x135F20)
4:516  0:000  - [05]: Volume: PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(4,GPT,8043B5F3-DE53-40E9-A322-89F6D1479DB6,0x78E0800,0x8000)
4:516  0:000  - [06]: Volume: PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(5,GPT,8AE95078-42CF-4AC6-A2F9-88D06F325E28,0x78E8800,0x7593800)
4:517  0:000          Result of bootcode detection: bootable Windows (vista,win)
4:517  0:000  - [07]: Volume: PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(1,GPT,361E9389-C5E6-474F-8293-034E29FC0008,0x28,0x64000)
4:517  0:000          Result of bootcode detection: bootable unknown (legacy)
4:520  0:003  - [08]: Volume: PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(2,GPT,77FCA1C2-1044-47EE-8AF9-7B378EC91007,0x64028,0xAE928B8)
4:527  0:006  - [09]: Volume: PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(3,GPT,5A2F962D-27D1-487D-B649-07EC1FA4BB50,0xAEF68E0,0x135F20)
4:540  0:012  - [10]: Volume: PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(4,GPT,1B6D2338-2341-4AAC-A50A-8777D7F4CF3B,0xB02C800,0x1E848000)
4:547  0:007          Result of bootcode detection: bootable Windows (vista,win)
4:547  0:000  - [11]: Volume: PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(5,GPT,CF511414-A1AF-4C72-AE62-65066FA9CBD3,0x29874800,0x1E848000)
4:563  0:015          Result of bootcode detection: bootable Windows (vista,win)
4:563  0:000  - [12]: Volume: PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(6,GPT,E0F12A90-F51C-4F6C-BB5A-1EFFE6373937,0x480BC800,0x29428000)
4:584  0:020          Result of bootcode detection: bootable Windows (vista,win)
4:584  0:000  - [13]: Volume: PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(7,GPT,9DD2DAB3-0529-4191-972A-2F748B86952F,0x714E4800,0x322258F)
4:694  0:110  Loading nvram.plist from Vol 'EFI' - loaded, size=2244
4:703  0:008  === [ PutNvramPlistToRtVars ] =============================
4:703  0:000   Adding Key: EFILoginHiDPI: Size = 4, Data: 00 00 00 00
4:703  0:000   Adding Key: LocationServicesEnabled: Size = 1, Data: 01
4:703  0:000   Adding Key: SystemAudioVolume: Size = 1, Data: 80
4:703  0:000   Adding Key: SystemAudioVolumeDB: Size = 1, Data: 00
4:703  0:000   Adding Key: backlight-level: Size = 2, Data: FB 00
4:703  0:000   Adding Key: bootercfg: Size = 2, Data: 27 00
4:703  0:000   Adding Key: csr-active-config: Size = 4, Data: 67 00 00 00
4:703  0:000   Adding Key: fakesmc-key-#KEY-ui32: Size = 4, Data: 00 00 00 11
4:703  0:000   Adding Key: fakesmc-key-$Adr-ui32: Size = 4, Data: 00 00 03 00
4:703  0:000   Adding Key: fakesmc-key-$Num-ui8: Size = 1, Data: 01
4:703  0:000   Adding Key: fakesmc-key-BATP-flag: Size = 1, Data: 00
4:703  0:000   Adding Key: fakesmc-key-BBIN-ui8: Size = 1, Data: 01
4:703  0:000   Adding Key: fakesmc-key-BEMB-flag: Size = 1, Data: 01
4:703  0:000   Adding Key: fakesmc-key-BNum-ui8: Size = 1, Data: 01
4:703  0:000   Adding Key: fakesmc-key-EPCI-ui32: Size = 4, Data: 05 B0 07 00
4:703  0:000   Adding Key: fakesmc-key-MSAc-ui16: Size = 2, Data: 00 00
4:703  0:000   Adding Key: fakesmc-key-MSFW-ui8: Size = 2, Data: 01 00
4:703  0:000   Adding Key: fakesmc-key-MSPS-ui16: Size = 2, Data: 00 03
4:703  0:000   Adding Key: fakesmc-key-MSTc-ui8: Size = 1, Data: 00
4:703  0:000   Adding Key: fakesmc-key-MSWr-ui8: Size = 1, Data: 00
4:703  0:000   Adding Key: fakesmc-key-RBr -ch8*: Size = 8, Data: 74 72 75 6E 6B 00 00 00
4:703  0:000   Adding Key: fakesmc-key-REV -ch8*: Size = 6, Data: 01 69 0F 00 00 04
4:703  0:000   Adding Key: fakesmc-key-RMde-char: Size = 1, Data: 41
4:703  0:000   Adding Key: fakesmc-key-RPlt-ch8*: Size = 8, Data: 6B 39 31 66 00 00 00 00
4:703  0:000   Adding Key: flagstate: Size = 32, Data: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
4:703  0:000   Adding Key: fmm-computer-name: Size = 11, Data: 4D 61 63 42 6F 6F 6B 20 50 72 6F
4:703  0:000   Adding Key: install-product-url: Size = 73, Data: 78 2D 6F 73 70 72 6F 64 75 63 74 3A 2F 2F 33 32 36 31 43 41 36 41 2D 34 44 33 45 2D 33 34 35 41 2D 42 41 36 32 2D 43 32 37 38 34 44 36 45 42 33 33 32 2F 6D 61 63 4F 53 25 32 30 49 6E 73 74 61 6C 6C 25 32 30 44 61 74 61
4:703  0:000   Adding Key: prev-lang:kbd: Size = 9, Data: 65 6E 2D 49 4E 3A 32 35 32
4:703  0:000   Adding Key: previous-system-uuid: Size = 36, Data: 42 33 43 38 45 43 39 34 2D 35 37 41 41 2D 33 41 44 33 2D 39 30 35 30 2D 32 37 30 41 41 44 44 38 34 41 43 38
4:703  0:000   Adding Key: rc_imgsrc_info: Size = 99, Data: 62 70 6C 69 73 74 30 30 A1 01 D1 02 03 5F 10 24 37 42 46 38 30 41 30 45 2D 38 36 33 42 2D 33 36 34 30 2D 38 38 44 31 2D 44 31 35 42 37 37 43 33 33 37 34 37 5A 45 6C 20 43 61 70 69 74 61 6E 08 0A 0D 34 00 00 00 00 00 00 01 01 00 00 00 00 00 00 00 04 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 3F
4:703  0:000   Adding Key: security-mode: String: Size = 4, Val = 'none'
4:703  0:000  === [ InitTheme ] =========================================
4:709  0:005  Using theme 'Nightwish' (EFI\CLOVER\themes\Nightwish)
4:709  0:000  OS main and drive as badge
4:711  0:002  Loading font from ThemeDir: Success
4:711  0:000  Choosing theme Nightwish
4:711  0:000  after NVRAM boot-args=
4:711  0:000  === [ Dump SMC keys from NVRAM ] ==========================
4:711  0:000  found AppleSMC protocol
4:712  0:000  Registered 17 SMC keys
4:712  0:000  === [ AddCustomEntries ] ==================================
4:712  0:000  Custom entry 0 FullTitle:"macOS Sierra" Path:"\System\Library\CoreServices\boot.efi" Options:"kext-dev-mode=1 slide=0 " Type:1 Flags:0x12 matching Volume:"2B29288D-D40C-44D5-98FB-226382368AFB"
4:712  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(1,GPT,D47655B6-67B7-43E7-9B5A-3468812E2D09,0x28,0x64000)) ... skipped
4:712  0:000      Checking volume "macOS Sierra" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(2,GPT,2B29288D-D40C-44D5-98FB-226382368AFB,0x64028,0x7746680)) ... match!
4:718  0:006      Check if volume Is Hibernated:
4:718  0:000      Check sleep image 'by signature':
4:725  0:006      read prefs \Library\Preferences\com.apple.PowerManagement.plist status=Success
4:725  0:000      using default sleep image name = \private\var\vm\sleepimage
4:727  0:002      no valid sleep image offset was found
4:727  0:000       sleepimage offset could not be acquired
4:727  0:000      hibernated: no - sign
4:730  0:002  Custom settings: <null string>.plist will  be applied
4:730  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(3,GPT,83FAF4E7-CC92-44E5-BC88-6FC7E0AC20E8,0x77AA6A8,0x135F20)) ... skipped
4:730  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(1,GPT,361E9389-C5E6-474F-8293-034E29FC0008,0x28,0x64000)) ... skipped
4:730  0:000      Checking volume "High Sierra" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(2,GPT,77FCA1C2-1044-47EE-8AF9-7B378EC91007,0x64028,0xAE928B8)) ... skipped
4:730  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(3,GPT,5A2F962D-27D1-487D-B649-07EC1FA4BB50,0xAEF68E0,0x135F20)) ... skipped
4:730  0:000      Checking volume "Installer" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(7,GPT,9DD2DAB3-0529-4191-972A-2F748B86952F,0x714E4800,0x322258F)) ... skipped
4:731  0:000  Custom entry 1 FullTitle:"BOOTCAMP" Path:"\EFI\Microsoft\Boot\bootmgfw.efi" Options:"-s -h" Type:7 Flags:0x0 matching Volume:"D47655B6-67B7-43E7-9B5A-3468812E2D09"
4:731  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(1,GPT,D47655B6-67B7-43E7-9B5A-3468812E2D09,0x28,0x64000)) ... match!
4:732  0:001  Custom settings: <null string>.plist will  be applied
4:732  0:000      Checking volume "macOS Sierra" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(2,GPT,2B29288D-D40C-44D5-98FB-226382368AFB,0x64028,0x7746680)) ... skipped
4:732  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(3,GPT,83FAF4E7-CC92-44E5-BC88-6FC7E0AC20E8,0x77AA6A8,0x135F20)) ... skipped
4:732  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(1,GPT,361E9389-C5E6-474F-8293-034E29FC0008,0x28,0x64000)) ... skipped
4:732  0:000      Checking volume "High Sierra" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(2,GPT,77FCA1C2-1044-47EE-8AF9-7B378EC91007,0x64028,0xAE928B8)) ... skipped
4:732  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(3,GPT,5A2F962D-27D1-487D-B649-07EC1FA4BB50,0xAEF68E0,0x135F20)) ... skipped
4:732  0:000      Checking volume "Installer" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(7,GPT,9DD2DAB3-0529-4191-972A-2F748B86952F,0x714E4800,0x322258F)) ... skipped
4:732  0:000  Custom entry 2 FullTitle:"High Sierra" Path:"\System\Library\CoreServices\boot.efi" Options:"kext-dev-mode=1 slide=0 " Type:1 Flags:0x12 matching Volume:"77FCA1C2-1044-47EE-8AF9-7B378EC91007"
4:732  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(1,GPT,D47655B6-67B7-43E7-9B5A-3468812E2D09,0x28,0x64000)) ... skipped
4:732  0:000      Checking volume "macOS Sierra" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(2,GPT,2B29288D-D40C-44D5-98FB-226382368AFB,0x64028,0x7746680)) ... skipped
4:732  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(3,GPT,83FAF4E7-CC92-44E5-BC88-6FC7E0AC20E8,0x77AA6A8,0x135F20)) ... skipped
4:732  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(1,GPT,361E9389-C5E6-474F-8293-034E29FC0008,0x28,0x64000)) ... skipped
4:732  0:000      Checking volume "High Sierra" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(2,GPT,77FCA1C2-1044-47EE-8AF9-7B378EC91007,0x64028,0xAE928B8)) ... match!
4:802  0:070      Check if volume Is Hibernated:
4:802  0:000      Check sleep image 'by signature':
4:842  0:040      read prefs \Library\Preferences\com.apple.PowerManagement.plist status=Success
4:842  0:000      using default sleep image name = \private\var\vm\sleepimage
4:871  0:028      sleepimage not found -> Not Found
4:871  0:000      hibernated: no - sign
4:871  0:000  Custom settings: <null string>.plist will  be applied
4:874  0:002      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(3,GPT,5A2F962D-27D1-487D-B649-07EC1FA4BB50,0xAEF68E0,0x135F20)) ... skipped
4:874  0:000      Checking volume "Installer" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(7,GPT,9DD2DAB3-0529-4191-972A-2F748B86952F,0x714E4800,0x322258F)) ... skipped
4:874  0:000  Custom entry 3 skipped because it is hidden.
4:874  0:000  Entry scan disabled
4:874  0:000  === [ AddCustomLegacy ] ===================================
4:874  0:000  Custom legacy 0 matching "macOS Sierra SSD" ...
4:874  0:000     Checking volume "Whole Disc Boot" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)) ... skipped because volume is not legacy bootable
4:874  0:000     Checking volume "Whole Disc Boot" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)) ... skipped because volume is not legacy bootable
4:874  0:000     Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(1,GPT,D47655B6-67B7-43E7-9B5A-3468812E2D09,0x28,0x64000)) ... skipped because volume is not legacy bootable
4:874  0:000     Checking volume "macOS Sierra" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(2,GPT,2B29288D-D40C-44D5-98FB-226382368AFB,0x64028,0x7746680)) ... skipped because volume is not legacy bootable
4:874  0:000     Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(3,GPT,83FAF4E7-CC92-44E5-BC88-6FC7E0AC20E8,0x77AA6A8,0x135F20)) ... skipped because volume is not legacy bootable
4:874  0:000     Checking volume "Legacy HD4" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(4,GPT,8043B5F3-DE53-40E9-A322-89F6D1479DB6,0x78E0800,0x8000)) ... skipped because volume is not legacy bootable
4:874  0:000     Checking volume "Legacy HD5" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(5,GPT,8AE95078-42CF-4AC6-A2F9-88D06F325E28,0x78E8800,0x7593800)) ... skipped
4:874  0:000     Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(1,GPT,361E9389-C5E6-474F-8293-034E29FC0008,0x28,0x64000)) ... skipped because volume is not legacy bootable
4:874  0:000     Checking volume "High Sierra" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(2,GPT,77FCA1C2-1044-47EE-8AF9-7B378EC91007,0x64028,0xAE928B8)) ... skipped because volume is not legacy bootable
4:874  0:000     Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(3,GPT,5A2F962D-27D1-487D-B649-07EC1FA4BB50,0xAEF68E0,0x135F20)) ... skipped because volume is not legacy bootable
4:874  0:000     Checking volume "Legacy HD4" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(4,GPT,1B6D2338-2341-4AAC-A50A-8777D7F4CF3B,0xB02C800,0x1E848000)) ... skipped
4:874  0:000     Checking volume "Legacy HD5" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(5,GPT,CF511414-A1AF-4C72-AE62-65066FA9CBD3,0x29874800,0x1E848000)) ... skipped
4:874  0:000     Checking volume "Legacy HD6" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(6,GPT,E0F12A90-F51C-4F6C-BB5A-1EFFE6373937,0x480BC800,0x29428000)) ... skipped
4:874  0:000     Checking volume "Installer" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x5,0x0,0x0)\HD(7,GPT,9DD2DAB3-0529-4191-972A-2F748B86952F,0x714E4800,0x322258F)) ... skipped because volume is not legacy bootable
4:874  0:000  === [ AddCustomTool ] =====================================
4:875  0:000  found tool \EFI\CLOVER\tools\Shell64U.efi
4:875  0:000  Checking EFI partition Volume 2 for Clover
4:875  0:000   Found Clover
4:876  0:000  === [ GetEfiBootDeviceFromNvram ] =========================
4:876  0:000  Default boot entry not found
4:876  0:000  DefaultIndex=-1 and MainMenu.EntryCount=9
5:015  0:139  GUI ready
11:743  6:727   boot with args: kext-dev-mode=1 -v
11:743  0:000  BootVariable of the entry is empty
11:743  0:000  === [ StartLoader ] =======================================
11:743  0:000  Finally: ExternalClock=24MHz BusSpeed=99773kHz CPUFreq=1995MHz PIS: hw.busfrequency=96000000Hz
11:743  0:000  Loading boot.efi  status=Success
11:866  0:123  GetOSVersion: 10.12.6 (16G1314)
11:866  0:000  CSR_CFG: CSR_ALLOW_UNTRUSTED_KEXTS | CSR_ALLOW_UNRESTRICTED_FS | CSR_ALLOW_TASK_FOR_PID | CSR_ALLOW_UNRESTRICTED_DTRACE | CSR_ALLOW_UNRESTRICTED_NVRAM
11:866  0:000  Filtering KextPatches:
11:866  0:000   - [00]: com.apple.iokit.IOAHCIBlockStorage (Enable TRIM for SSD) :: BinPatch :: [OS: 10.12.6 | MatchOS: All | MatchBuild: All] ==> allowed
11:866  0:000   - [01]: com.apple.iokit.IOGraphicsFamily (Boot graphics glitch, 10.10.x/10.11.x (credit lisai9093, cecekpawon)) :: BinPatch :: [OS: 10.12.6 | MatchOS: All | MatchBuild: All] ==> allowed
11:866  0:000   - [02]: com.apple.driver.AppleBacklight (AppleBacklightInjector.kext) :: BinPatch :: [OS: 10.12.6 | MatchOS: All | MatchBuild: All] ==> allowed
11:866  0:000  Will not patch boot.efi
11:866  0:000  === [ PatchSmbios ] =======================================
11:866  0:000  insert table 9 for dev 0:0
11:866  0:000  insert table 9 for dev 0:0
11:867  0:000  Trusting SMBIOS...
11:867  0:000  Detected alternating SMBIOS channel banks
11:867  0:000  Channels: 2
11:867  0:000  Interleave: 0 2 1 3 4 6 5 7 8 10 9 11 12 14 13 15 16 18 17 19 20 22 21 23
11:867  0:000   partNum=CMSO4GX3M1A1333C9
11:867  0:000  SMBIOS Type 17 Index = 0 => 0 0:
11:867  0:000  BANK 0 DIMM0 1333MHz 4096MB
11:867  0:000   partNum=HMT351S6BFR8C-H9
11:867  0:000  SMBIOS Type 17 Index = 1 => 1 2:
11:867  0:000  BANK 1 DIMM0 1333MHz 4096MB
11:867  0:000  mTotalSystemMemory = 8192
11:867  0:000  NumberOfMemoryDevices = 2
11:867  0:000  Type20[0]->End = 0x3FFFFF, Type17[0] = 0x1000
11:867  0:000  Type20[1]->End = 0x7FFFFF, Type17[1] = 0x3000
11:867  0:000  Table 131 is present, CPUType=31
11:867  0:000  Change to: 703
11:867  0:000  === [ PatchACPI ] =========================================
11:867  0:000  Xsdt reallocation done
11:867  0:000  old FADT length=F4
11:867  0:000   SignatureFixup: 0x0 -> 0x0
11:867  0:000  Found OperationRegion(GNVS, SystemMemory, ACFBCE18, ...)
11:867  0:000  Found OperationRegion(OGNS, SystemMemory, ACFBA018, ...)
11:867  0:000  Found OperationRegion(FXEM, SystemMemory, FFD80000, ...)
11:867  0:000  Found OperationRegion(H1DA, SystemMemory, ACFBEF98, ...)
11:867  0:000  Found OperationRegion(MCHT, SystemMemory, FED10000, ...)
11:867  0:000  Found OperationRegion(RCRB, SystemMemory, FED1C000, ...)
11:867  0:000  Found OperationRegion(MDBG, SystemMemory, ACF6A018, ...)
11:870  0:003  DSDT found in Clover volume OEM folder: EFI\CLOVER\ACPI\patched\dsdt.aml
11:871  0:000  Apply DsdtFixMask=0x11400000
11:871  0:000     drop _DSM mask=0x0000
11:871  0:000  === [ FixBiosDsdt ] =======================================
11:871  0:000  VideoCard devID=0x1168086
11:871  0:000  DisplayADR1[0] = 0x20000, DisplayADR2[0] = 0xFFFE
11:871  0:000  USBADR[0] = 0x1A0000 and PCIe = 0xFFFE
11:871  0:000  Audio HDA (addr:0x1B0000) setting specified layout-id=3 (0x3)
11:872  0:000  Found Airport Atheros at 0x1C0001, 0x0, DeviceID=0x002B
11:872  0:000  USBADR[1] = 0x1C0003 and PCIe = 0x0
11:872  0:000  USBADR[2] = 0x1D0000 and PCIe = 0xFFFE
11:872  0:000  first CPU found at 870D offset 8710
11:872  0:000  score candidate at 8709
11:872  0:000  score inserted in acpi_cpu_score _PR_
11:872  0:000  Found ACPI CPU: CPU0 | CPU1 | CPU2 | CPU3 | CPU4 | CPU5 | CPU6 | CPU7 , within the score: _PR_
11:872  0:000  Found PCIROOTUID = 0
11:872  0:000   deleting device CRT_
11:872  0:000   deleting device DVI_
11:873  0:000   deleting device SPKR
11:873  0:000   deleting device ECP_
11:873  0:000   deleting device LPT_
11:874  0:000   deleting device FDC0
11:874  0:000   deleting device ECP1
11:874  0:000   deleting device LPT1
11:875  0:000  Start PNLF Fix
11:875  0:000    indirect name=SRCB
11:875  0:000  PreCleanup XSDT: count=13, length=140
11:875  0:000  PreCleanup XSDT, corrected XSDT: count=13, length=140
11:875  0:000  === [ ACPIDropTables ] ====================================
11:875  0:000  === [ DropSSDT ] ==========================================
11:875  0:000  Drop tables from XSDT, SIGN=SSDT TableID= Length=0
11:875  0:000   Table[6]: SSDT  INSYDE    1311 dropped
11:875  0:000   Table[9]: SSDT  INSYDE    2316 dropped
11:875  0:000   Table[10]: SSDT  INSYDE    2454 dropped
11:875  0:000   Table[11]: SSDT  INSYDE    730 dropped
11:875  0:000   Table[12]: SSDT  INSYDE    861 dropped
11:875  0:000  === [ ACPIPatchedAML ] ====================================
11:875  0:000  Unsorted
11:875  0:000  Inserting SSDT.aml from EFI\CLOVER\ACPI\patched: size=1603 ... Success
11:875  0:000  Inserting SSDT-PNLF.aml from EFI\CLOVER\ACPI\patched: size=831 ... Success
11:876  0:000  CPUBase=0 and ApicCPUBase=1 ApicCPUNum=8
11:876  0:000  Cleanup XSDT: count=15, length=156
11:876  0:000  corrected XSDT count=10, length=116
11:876  0:000  === [ RestSetup macOS ] ===================================
11:876  0:000  EdidDiscovered size=128
11:876  0:000  --- Discovered EDID Table size:128
11:876  0:000  000  |  00  FF  FF  FF  FF  FF  FF  00  4C  A3
11:876  0:000  010  |  51  42  00  00  00  00  00  12  01  03
11:876  0:000  020  |  80  22  13  78  0A  87  F5  94  57  4F
11:876  0:000  030  |  8C  27  27  50  54  00  00  00  01  01
11:876  0:000  040  |  01  01  01  01  01  01  01  01  01  01
11:876  0:000  050  |  01  01  01  01  12  1B  56  72  50  00
11:876  0:000  060  |  0C  30  30  20  25  00  58  C2  10  00
11:876  0:000  070  |  00  19  00  00  00  0F  00  00  00  00
11:876  0:000  080  |  00  00  00  00  00  1E  B4  02  74  00
11:876  0:000  090  |  00  00  00  FE  00  53  41  4D  53  55
11:876  0:000  100  |  4E  47  0A  20  20  20  20  20  00  00
11:876  0:000  110  |  00  FE  00  31  35  36  41  54  30  35
11:876  0:000  120  |  2D  48  30  37  0A  20  00  03
11:876  0:000  Intel GFX injection not set
11:876  0:000   setting specified layout-id=3 (0x3)
11:876  0:000  stringlength = 2210
11:877  0:000  CurrentMode: Width=1366 Height=768
11:877  0:000  Beginning FSInjection
FSInjectionInstall ...
- Our FSI_SIMPLE_FILE_SYSTEM_PROTOCOL installed on handle: AC037798
FSInjectionInstall ...
- Our FSI_SIMPLE_FILE_SYSTEM_PROTOCOL installed on handle: AC037798
11:877  0:000  Use origin smbios table type 1 guid.
11:878  0:000  Preparing kexts injection for arch=x86_64 from EFI\CLOVER\kexts\Other
11:878  0:000  Extra kext: EFI\CLOVER\kexts\Other\FakeSMC.kext (v.1372)
11:893  0:015    |-- PlugIn kext: EFI\CLOVER\kexts\Other\FakeSMC.kext\Contents\PlugIns\LPCSensors.kext (v.1372)
12:167  0:273    |-- PlugIn kext: EFI\CLOVER\kexts\Other\FakeSMC.kext\Contents\PlugIns\GPUSensors.kext (v.1372)
12:178  0:011    |-- PlugIn kext: EFI\CLOVER\kexts\Other\FakeSMC.kext\Contents\PlugIns\CPUSensors.kext (v.1372)
12:185  0:006    |-- PlugIn kext: EFI\CLOVER\kexts\Other\FakeSMC.kext\Contents\PlugIns\ACPISensors.kext (v.1372)
12:200  0:014  Extra kext: EFI\CLOVER\kexts\Other\VoodooPS2Controller.kext (v.1.8.29)
12:209  0:009    |-- PlugIn kext: EFI\CLOVER\kexts\Other\VoodooPS2Controller.kext\Contents\PlugIns\VoodooPS2Trackpad.kext (v.1.8.29)
12:226  0:016    |-- PlugIn kext: EFI\CLOVER\kexts\Other\VoodooPS2Controller.kext\Contents\PlugIns\VoodooPS2Mouse.kext (v.1.8.29)
12:234  0:008    |-- PlugIn kext: EFI\CLOVER\kexts\Other\VoodooPS2Controller.kext\Contents\PlugIns\VoodooPS2Keyboard.kext (v.1.8.29)
12:262  0:027  Preparing kexts injection for arch=x86_64 from EFI\CLOVER\kexts\10.12
12:262  0:000  Extra kext: EFI\CLOVER\kexts\10.12\Sinetek-rtsx.kext (v.1)
12:268  0:006  Extra kext: EFI\CLOVER\kexts\10.12\VoodooHDA.kext (v.2.9.0d10)
12:276  0:007  Extra kext: EFI\CLOVER\kexts\10.12\VoodooPS2Controller.kext (v.1.8.29)
12:286  0:009    |-- PlugIn kext: EFI\CLOVER\kexts\10.12\VoodooPS2Controller.kext\Contents\PlugIns\VoodooPS2Trackpad.kext (v.1.8.29)
12:302  0:016    |-- PlugIn kext: EFI\CLOVER\kexts\10.12\VoodooPS2Controller.kext\Contents\PlugIns\VoodooPS2Mouse.kext (v.1.8.29)
12:310  0:008    |-- PlugIn kext: EFI\CLOVER\kexts\10.12\VoodooPS2Controller.kext\Contents\PlugIns\VoodooPS2Keyboard.kext (v.1.8.29)
12:338  0:027  Extra kext: EFI\CLOVER\kexts\10.12\RealtekRTL8111.kext (v.2.2.1)
12:348  0:009  Extra kext: EFI\CLOVER\kexts\10.12\GenericUSBXHCI.kext (v.1.2.11)
12:356  0:008  Extra kext: EFI\CLOVER\kexts\10.12\FakeSMC.kext (v.1372)
12:372  0:016    |-- PlugIn kext: EFI\CLOVER\kexts\10.12\FakeSMC.kext\Contents\PlugIns\LPCSensors.kext (v.1372)
12:646  0:273    |-- PlugIn kext: EFI\CLOVER\kexts\10.12\FakeSMC.kext\Contents\PlugIns\GPUSensors.kext (v.1372)
12:657  0:011    |-- PlugIn kext: EFI\CLOVER\kexts\10.12\FakeSMC.kext\Contents\PlugIns\CPUSensors.kext (v.1372)
12:664  0:006    |-- PlugIn kext: EFI\CLOVER\kexts\10.12\FakeSMC.kext\Contents\PlugIns\ACPISensors.kext (v.1372)
12:684  0:019  Custom boot screen not used because entry has unset use graphics


[xXConcasXx]

On 27/3/2018 at 12:25 AM, mnfesq said:

Yours is 0x528710EC.  According to this post, it is supported:

https://www.insanelymac.com/forum/forums/topic/321080-sineteks-driver-for-realtek-rtsx-sdhc-card-readers/?do=findComment&comment=2376387

It doesn't work.. can you help me?

[mnfesq]

On 4/13/2018 at 4:49 AM, xXConcasXx said:

It doesn't work.. can you help me?

Make sure the kext is in Clover/kexts/10.13 (assuming you are using the most current version of macOS) and be sure to repair permissions and rebuild caches before you restart.  If you are still having problems, make sure you have the correct PID/VID.

[illorca1982]

hi to all and thanks for you work here.

I've a Asus rog strix gl 503vn. i've installed the beta kext and when I insert a sd card I get system restart.

any idea?

[xephrey]

Hey. I thought I'd put my experience out there too. I'm running MacOS 10.13.4 on an MSI Dominator Pro GT62VR 6RE with the ID: 0x524910EC. I also experienced slow speeds maxing out at 9 Mbps read / write as well as a kernel panic upon eject.



I'm so excited when I got it working though! Keep up the good work - this is super exciting stuff!

[oldman20]

so sad when know my card reader is USB, nit PCIe, but any hope it works, bro?



[midi-sama]

On 5/29/2018 at 11:45 AM, oldman20 said:

so sad when know my card reader is USB, nit PCIe, but any hope it works, bro?



USB should work OOB, it's USB not PCI-e.

[oldman20]

USB should work OOB, it's USB not PCI-e.

Sorry. What is it mean? My card reader shoud work? How bro??

Gửi từ SM-N950F của tôi bằng cách sử dụng Tapatalk

[Mc Jacej]

got realtek 8411 pci card reader with 5289 device id but sineteks rs kext it doesnt even load,wont work under sierra,hs and mojave beta

[Sniki]

6 hours ago, rhyker2u said:



Absolutely no idea what I'm doing, but I just downloaded that zip, unzipped in my EFI\CLOVER\kexts\Other , rebooted, and it works beautifully on a HP EliteBook 2570P with the latest High Sierra and Clover r4586:





And okay its horrifically slow, but that's because it's a Sandisk 'Ultra' microSD retrofitted into an SD adapter price at  < $20.



  Reveal hidden contents



Super happy its working!



P.S. BTW, just in case;  whoever gets an error that their file-system is read-only? Don't forget about the dreadful toggle/switch at the microSD adapter (if you use one); that's how I wasted upto a hour of my time. As every time I put it in, the switch moved along too and thus couldn't write nor perform any benchmarks

Is it working after laptop sleeps and you wake it ?

[Master1024]

my id is：

PCI\VEN_10EC&DEV_5250&SUBSYS_11F71462&REV_01



It don't work for me.

ioreg can find rtsx,but it don't work when I put sd card in my computer.

[jonny33]

The kext doesn't work under Mojave though it worked under High Sierra. Do you have any way to fix that?

[midi-sama]

34 minutes ago, jonny33 said:

The kext doesn't work under Mojave though it worked under High Sierra. Do you have any way to fix that?

Is this kext even in development anymore?

[jonny33]

I hope so even though it got some problems with the sleep I think it worked decently enough and I'll miss it in Mojave.

[feartech]

works fine under Mojave

[RrTtFfSsX]

not working on Mojave with vendor id 10ec and device id 5209.

[jonny33]

On 10/7/2018 at 11:39 PM, feartech said:

works fine under Mojave

Which version exactly you are using and which device id is your card?!!

[feartech]

22 hours ago, jonny33 said:

Which version exactly you are using and which device id is your card?!!

i use the one attached



i do get a reboot when ejecting the card though but other than that, i can still use the card to transfer data

Sinetek-rtsx.kext.zip

[jonny33]

2 hours ago, feartech said:

i use the one attached



i do get a reboot when ejecting the card though but other than that, i can still use the card to transfer data

Sinetek-rtsx.kext.zip

Really strange it doesn't do anything for me under mojave

[Magemaster1776]

I'm trying to use it on my 0x522710EC (already edited the info.plist), but the kext doesn't even load (at least i cant find it under 'kextstat' command).

Am I doing something wrong, maybe skipping some step ?

High Sierra 10.13.6, Realtek RTS5227 (10EC:5227)
