Clover General discussion

hackaro · June 27, 2017

@hackaro,

Please post your boot.log and config.plist.

Here it is. @apianti thank you.

r!ppz · June 27, 2017

I tested both the HFS+ and APFS installation of 10.13 on my Samsung SSD 840 pro. The APFS installation takes much longer to boot. HFS+ is almost instant. I guess this will be fixed in the final release. OS itself is smooth as always.

Anyone seeing the same effect?

PMheart · June 27, 2017

I tested both the HFS+ and APFS installation of 10.13 on my Samsung SSD 840 pro. The APFS installation takes much longer to boot. HFS+ is almost instant. I guess this will be fixed in the final release. OS itself is smooth as always.

Anyone seeing the same effect?

Yes. The same on my real Mac NVMe disk. But not that serious I guess. Just a fair little bit slower than HFS+.

arsradu · June 27, 2017

@arsradu,

There is a key for custom entries called, Hidden, if you set that to true, then entries will be hidden by default and can be toggled shown/hidden with F3. It's useful for recovery entries, or other stuff you don't use regularly but might need eventually.

EDIT: Glad you got it looking like you want!

Thanks for your help. Also, I'll try that. It is pretty much what I wanted. Which is to be able to easily toggle visible/hidden those Recovery partitions in case I need them.

magnifico · June 27, 2017

Yes. The same on my real Mac NVMe disk. But not that serious I guess. Just a fair little bit slower than HFS+.

You mean only for istallation ?

SavageAUS · June 27, 2017

What is the easiest way to identify the UUID or unique number of the High Sierra recovery partition with apfs?

Sent from my SM-G930F using Tapatalk

gengik84 · June 27, 2017

What is the easiest way to identify the UUID or unique number of the High Sierra recovery partition with apfs?

Sent from my SM-G930F using Tapatalk

diskutil info /dev/diskXsx | grep UUID

Replace Xx with your "apfs volume recovery"

Show with

diskutil list

PMheart · June 27, 2017

diskutil info /dev/diskXsx | grep UUID
Replace Xx with your "apfs volume recovery"

Show with
diskutil list

What about

diskutil info Recovery | grep "Volume UUID" | awk '{print $3}'

It gave me

24E61BE6-002D-431B-9632-E01122C4A385

PMheart · June 27, 2017

You mean only for istallation ?

No. Also booting the normal system.

fusion71au · June 27, 2017

diskutil info /dev/diskXsx | grep UUID

The unique UUID for APFS Volumes that Clover uses (in its bootlog/bdmesg) is different to the one reported by the "diskutil info" command....

eg for my system, the APFS Recovery Volume is disk2s4

/dev/disk2 (synthesized):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      APFS Container Scheme -                      +50.5 GB    disk2
                                 Physical Store disk1s7
   1:                APFS Volume macOS                   30.3 GB    disk2s1
   2:                APFS Volume VM                      2.1 GB     disk2s2
   3:                APFS Volume Preboot                 18.4 MB    disk2s3
   4:                APFS Volume Recovery                505.4 MB   disk2s4

fusion71aus-MacBook-Pro:~ fusion71au$ diskutil info disk2s4 | grep UUID
   Volume UUID:              035D37E3-D29D-4793-8336-730AF9D47F15
   Disk / Partition UUID:    035D37E3-D29D-4793-8336-730AF9D47F15
fusion71aus-MacBook-Pro:~ fusion71au$ bdmesg | grep 035D37E3-D29D-4793-8336-730AF9D47F15
fusion71aus-MacBook-Pro:~ fusion71au$ bdmesg | grep Recovery
8:919  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(3,GPT,86DAF24D-5D5C-4629-BA3F-CB290BD13D88,0xE1C72D8,0x135F20)) ... skipped
9:030  0:000      Checking volume "Recovery" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x2,0x0)\HD(7,GPT,34A73EF5-D2F1-49D4-A682-FDB136B489D6,0x1F4E4800,0x5E11A88)\VenMedia(BE74FCF7-0B7C-49F3-9147-01F4042E6842,E3375D039DD293478336730AF9D47F15)) ... skipped
9:476  0:010  - [13]: 'Recovery HD'
9:477  0:000          AddLoaderEntry for Volume Name=Recovery HD
10:450  0:008  - [21]: 'Recovery'
10:453  0:002          AddLoaderEntry for Volume Name=Recovery

Note "diskutil info" command returns 035D37E3-D29D-4793-8336-730AF9D47F15

but the unique part of the UUID used by Clover shown in bootlog/bdmesg (last section after VenMedia) is E3375D039DD293478336730AF9D47F15

IMHO, better to use UUIDs shown in Clover bootlog/bdmesg for the purposes of creating Custom Entries in config.plist....

PMheart · June 27, 2017

The unique UUID for APFS Volumes that Clover uses (in its bootlog/bdmesg) is different to the one reported by the "diskutil info" command....

eg for my system, the APFS Recovery Volume is disk2s4

/dev/disk2 (synthesized):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      APFS Container Scheme -                      +50.5 GB    disk2
                                 Physical Store disk1s7
   1:                APFS Volume macOS                   30.3 GB    disk2s1
   2:                APFS Volume VM                      2.1 GB     disk2s2
   3:                APFS Volume Preboot                 18.4 MB    disk2s3
   4:                APFS Volume Recovery                505.4 MB   disk2s4

fusion71aus-MacBook-Pro:~ fusion71au$ diskutil info disk2s4 | grep "Volume UUID"
   Volume UUID:              035D37E3-D29D-4793-8336-730AF9D47F15
fusion71aus-MacBook-Pro:~ fusion71au$ bdmesg | grep 035D37E3-D29D-4793-8336-730AF9D47F15
fusion71aus-MacBook-Pro:~ fusion71au$ bdmesg | grep Recovery
8:919  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1F,0x2)\Sata(0x0,0x0,0x0)\HD(3,GPT,86DAF24D-5D5C-4629-BA3F-CB290BD13D88,0xE1C72D8,0x135F20)) ... skipped
9:030  0:000      Checking volume "Recovery" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x2,0x0)\HD(7,GPT,34A73EF5-D2F1-49D4-A682-FDB136B489D6,0x1F4E4800,0x5E11A88)\VenMedia(BE74FCF7-0B7C-49F3-9147-01F4042E6842,E3375D039DD293478336730AF9D47F15)) ... skipped
9:476  0:010  - [13]: 'Recovery HD'
9:477  0:000          AddLoaderEntry for Volume Name=Recovery HD
10:450  0:008  - [21]: 'Recovery'
10:453  0:002          AddLoaderEntry for Volume Name=Recovery

Note "diskutil info" command returns 035D37E3-D29D-4793-8336-730AF9D47F15

but the unique part of the UUID used by Clover shown in bootlog/bdmesg (last section after VenMedia) is E3375D039DD293478336730AF9D47F15

IMHO, better to use UUIDs shown in Clover bootlog/bdmesg for the purposes of creating Custom Entries in config.plist....

The only correct way to gather the UUIDs is from Clover log, isn't it?

cecekpawon · June 28, 2017

Or

diskutil apfs list

apianti · June 28, 2017

Notice that the UUIDs you obtain from diskutil or from the device path string are the same UUID just in different formats:

From diskutil:
035D37E3-D29D-4793-8336-730AF9D47F15
From device path:
E3375D03 9DD2 9347 8336 730AF9D47F15
So you can create the other from one.

SavageAUS · June 28, 2017

I've been trying for ages to get a custom entry for my High Sierra Recovery with no luck, All my other entries are working fine. What can i add to this post to gain assistance?

fusion71au · June 28, 2017

@SavageAUS,

Min info required would be your Clover boot log (output from bdmesg command in terminal), output from "diskutil list" and the complete GUI section from your config.plist ---> attach to your post so others can help you. Make sure to remove identifying serials eg MLB, ROM etc from your config.plist.

If all you are needing is to hide the Recovery Volume, you can look at post#13505. Also some background on what to look for in your boot log in post#13512.

Edit1

OK, info from your boot log:

APFS Recovery UUID for High Sierra = Vol 12 = 4F725DE47024C0499E983E1100C1CD92

Recovery HD UUID for Sierra = Vol 3 = C0401322-7F93-4508-A319-52A75A81C24C

Attached is the corrected GUI config.plist (Only changed UUID from A7BD56F8-BE2B-3C8B-A08E-9E3ED3EEE538 to 4F725DE47024C0499E983E1100C1CD92)

Good Luck!

Edit2

You might also have to add the UUID of the High Sierra volume to the loader path for the APFS Recovery volume (like for Preboot Custom Entry post#13539). What is the output of diskutil info disk1s1 | grep UUID?

Path would be in the form \UUID\boot.efi

Edit3

Added \A7BD56F8-BE2B-3C8B-A08E-9E3ED3EEE538\boot.efi to path. Hopefully this works.. GUI config_edited2.plist.zip

Legend, that was the trick. All custom entries working now

Great! Glad I could help

GUI config_edited.plist.zip

GUI config_edited2.plist.zip

SavageAUS · June 28, 2017

Ok thank you, hopefully i've removed personal stuff.

Last login: Wed Jun 28 13:06:12 on ttys000
Shanes-MBP:~ shane$ diskutil list
/dev/disk0 (internal, physical):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      GUID_partition_scheme                        *500.1 GB   disk0
   1:                        EFI EFI                     209.7 MB   disk0s1
   2:                  Apple_HFS macOS Sierra            249.4 GB   disk0s2
   3:                 Apple_Boot Recovery HD             650.0 MB   disk0s3
   4:         Microsoft Reserved                         16.8 MB    disk0s4
   5:       Microsoft Basic Data Windows 10              142.5 GB   disk0s5
   6:                 Apple_APFS                         53.1 GB    disk0s6
   7:       Apple_KernelCoreDump                         655.4 MB   disk0s7
   8:           Linux Filesystem                         21.5 GB    disk0s8
   9:           Linux Filesystem                         32.1 GB    disk0s9

/dev/disk1 (synthesized):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:      APFS Container Scheme                        +53.1 GB    disk1

/dev/disk1s1 (internal, virtual):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:                APFS Volume macOS High Sierra      +27.2 GB    disk1s1

/dev/disk1s2 (internal, virtual):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:                APFS Volume Preboot                +19.2 MB    disk1s2

/dev/disk1s3 (internal, virtual):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:                APFS Volume Recovery               +505.4 MB   disk1s3

/dev/disk1s4 (internal, virtual):
   #:                       TYPE NAME                    SIZE       IDENTIFIER
   0:                APFS Volume VM                     +1.1 GB     disk1s4

bootlog.log.txt

GUI config.plist.zip

Terminal Saved Output.zip

Slice · June 28, 2017

Notice that the UUIDs you obtain from diskutil or from the device path string are the same UUID just in different formats:

From diskutil:

035D37E3-D29D-4793-8336-730AF9D47F15

From device path:

E3375D03 9DD2 9347 8336 730AF9D47F15

So you can create the other from one.

Yes, device path string uses UEFI libraries with Little Endian numeration for UUID while Apple uses Big Endian.

Clover contains many codes for the converting but this string is new.

SavageAUS · June 28, 2017

@SavageAUS,

Min info required would be your Clover boot log (output from bdmesg command in terminal), output from "diskutil list" and the complete GUI section from your config.plist ---> attach to your post so others can help you. Make sure to remove identifying serials eg MLB, ROM etc from your config.plist.

If all you are needing is to hide the Recovery Volume, you can look at post#13505. Also some background on what to look for in your boot log in post#13512.

Edit

OK, your from your boot log:

APFS Recovery UUID for High Sierra = Vol 12 = 4F725DE47024C0499E983E1100C1CD92

Recovery HD UUID for Sierra = Vol 3 = C0401322-7F93-4508-A319-52A75A81C24C

Attached is the corrected GUI config.plist (Only changed UUID from A7BD56F8-BE2B-3C8B-A08E-9E3ED3EEE538 to 4F725DE47024C0499E983E1100C1CD92)

Good Luck!

Using 4F725DE47024C0499E983E1100C1CD92 in config didn't make any changes on my end. Do i need to add anything to the path or just 4F725DE47024C0499E983E1100C1CD92 in volume? It's just the High Sierra recovery i need to rename, Sierra's recovery is fine.

It's really strange, if i add 4F725DE47024C0499E983E1100C1CD92 to the section to hide entries, High Sierra Recovery is hidden but using 4F725DE47024C0499E983E1100C1CD92 will not allow me to rename the entry in GUI.

SavageAUS · June 28, 2017

@SavageAUS,

Min info required would be your Clover boot log (output from bdmesg command in terminal), output from "diskutil list" and the complete GUI section from your config.plist ---> attach to your post so others can help you. Make sure to remove identifying serials eg MLB, ROM etc from your config.plist.

If all you are needing is to hide the Recovery Volume, you can look at post#13505. Also some background on what to look for in your boot log in post#13512.

Edit1

OK, your from your boot log:

APFS Recovery UUID for High Sierra = Vol 12 = 4F725DE47024C0499E983E1100C1CD92

Recovery HD UUID for Sierra = Vol 3 = C0401322-7F93-4508-A319-52A75A81C24C

Attached is the corrected GUI config.plist (Only changed UUID from A7BD56F8-BE2B-3C8B-A08E-9E3ED3EEE538 to 4F725DE47024C0499E983E1100C1CD92)

Good Luck!

Edit2

You might also have to add the UUID of the High Sierra volume to the loader path for the APFS Recovery volume (like for Preboot Custom Entry post#13539). What is the output of diskutil info disk1s1 | grep UUID?

Path would be in the form \UUID\boot.efi eg like \5A3A032A-9A07-47DF-A631-FF80D3B3EEF2\boot.efi

Output is

Shanes-MBP:~ shane$ diskutil info disk1s1 | grep UUID
   Volume UUID:              A7BD56F8-BE2B-3C8B-A08E-9E3ED3EEE538


p.p1 {margin: 0.0px 0.0px 0.0px 0.0px; font: 11.0px Menlo; color: #000000; background-color: #ffffff}
span.s1 {font-variant-ligatures: no-common-ligatures}

   Disk / Partition UUID:    A7BD56F8-BE2B-3C8B-A08E-9E3ED3EEE538

@SavageAUS,

Min info required would be your Clover boot log (output from bdmesg command in terminal), output from "diskutil list" and the complete GUI section from your config.plist ---> attach to your post so others can help you. Make sure to remove identifying serials eg MLB, ROM etc from your config.plist.

If all you are needing is to hide the Recovery Volume, you can look at post#13505. Also some background on what to look for in your boot log in post#13512.

Edit1

OK, your from your boot log:

APFS Recovery UUID for High Sierra = Vol 12 = 4F725DE47024C0499E983E1100C1CD92

Recovery HD UUID for Sierra = Vol 3 = C0401322-7F93-4508-A319-52A75A81C24C

Attached is the corrected GUI config.plist (Only changed UUID from A7BD56F8-BE2B-3C8B-A08E-9E3ED3EEE538 to 4F725DE47024C0499E983E1100C1CD92)

Good Luck!

Edit2

You might also have to add the UUID of the High Sierra volume to the loader path for the APFS Recovery volume (like for Preboot Custom Entry post#13539). What is the output of diskutil info disk1s1 | grep UUID?

Path would be in the form \UUID\boot.efi

Edit3

Added \A7BD56F8-BE2B-3C8B-A08E-9E3ED3EEE538\boot.efi to path. Hopefully this works.. GUI config_edited2.plist.zip

Legend, that was the trick. All custom entries working now :thumbsup_anim:

This is the entry.

<dict>
<key>Disabled</key>
<false/>
<key>FullTitle</key>
<string>macOS High Sierra Recovery</string>
<key>Ignore</key>
<false/>
<key>NoCaches</key>
<false/>
<key>Path</key>
<string>\A7BD56F8-BE2B-3C8B-A08E-9E3ED3EEE538\boot.efi</string>
<key>Type</key>
<string>OSXRecovery</string>
<key>Volume</key>
<string>4F725DE47024C0499E983E1100C1CD92</string>
<key>VolumeType</key>
<string>Internal</string>
</dict>
</plist>

PMheart · June 29, 2017

@Slice

Hi. I found hibernation not working with FV2 enabled. I followed your instructions on (http://www.insanelymac.com/forum/topic/304530-clover-change-explanations/?p=2313627)

Details:

- MotherBoard: GA-B75M-D3V (UEFI & Real NVRAM)

- GPT SSD with EFI and Recovery partition (You said it should be HDD, but I guess it doesn't really matter)

- macOS Sierra 10.12.5

- Clover r4097 from sf.net

- SMCHelper.efi and aptiofixv2.efi both from the pkg from sf.net

- FakeSMC 3.4.2 from (https://sourceforge.net/projects/hwsensors3.hwsensors.p/), and it is extracted from HWSensors3-rev43.pkg

- StrictHibernate = true in config.plist/Boot

- hibernatemode = 25

Extras:

- HibernationFixup.kext from (https://sourceforge.net/projects/hibernationfixup/) (Also tried without this, no luck)

- Changed smc rev for FakeSMC/Info.plist to be compatible with MacPro6,1

With these stuffs, hibernation is still not working, I got a reboot while waking. I saw you said

If you have a reboot during wake then most probably you have no correct FakeSMC.

And what's "no correct FakeSMC" exactly referring to?

Any idea?

Thanks in advance

savvas · June 29, 2017

@Slice

Hi. I found hibernation not working with FV2 enabled. I followed your instructions on (http://www.insanelymac.com/forum/topic/304530-clover-change-explanations/?p=2313627)

Details:

- MotherBoard: GA-B75M-D3V (UEFI & Real NVRAM)

- GPT SSD with EFI and Recovery partition (You said it should be HDD, but I guess it doesn't really matter)

- macOS Sierra 10.12.5

- Clover r4097 from sf.net

- SMCHelper.efi and aptiofixv2.efi both from the pkg from sf.net

- FakeSMC 3.4.2 from (https://sourceforge.net/projects/hwsensors3.hwsensors.p/), and it is extracted from HWSensors3-rev43.pkg

- StrictHibernate = true in config.plist/Boot

- hibernatemode = 25

Extras:

- HibernationFixup.kext from (https://sourceforge.net/projects/hibernationfixup/) (Also tried without this, no luck)

- Changed smc rev for FakeSMC/Info.plist to be compatible with MacPro6,1

With these stuffs, hibernation is still not working, I got a reboot while waking. I saw you said

And what's "no correct FakeSMC" exactly referring to?

Any idea?

Thanks in advance

Check nvram var's , especially from fakesmc. May be they still not recent and Clover uses old smc keys values

Slice · June 29, 2017

@Slice

Hi. I found hibernation not working with FV2 enabled. I followed your instructions on (http://www.insanelymac.com/forum/topic/304530-clover-change-explanations/?p=2313627)

Details:

- MotherBoard: GA-B75M-D3V (UEFI & Real NVRAM)

- GPT SSD with EFI and Recovery partition (You said it should be HDD, but I guess it doesn't really matter)

- macOS Sierra 10.12.5

- Clover r4097 from sf.net

- SMCHelper.efi and aptiofixv2.efi both from the pkg from sf.net

- FakeSMC 3.4.2 from (https://sourceforge.net/projects/hwsensors3.hwsensors.p/), and it is extracted from HWSensors3-rev43.pkg

- StrictHibernate = true in config.plist/Boot

- hibernatemode = 25

Extras:

- HibernationFixup.kext from (https://sourceforge.net/projects/hibernationfixup/) (Also tried without this, no luck)

- Changed smc rev for FakeSMC/Info.plist to be compatible with MacPro6,1

With these stuffs, hibernation is still not working, I got a reboot while waking. I saw you said

And what's "no correct FakeSMC" exactly referring to?

Any idea?

Thanks in advance

Correct FakeSMC saves all attempts to write to SMC into NVRAM. But not read back NVRAM values.

Write yes

Read no.

Hibernation depends on many factors.

First, you must have working simple sleep.

Second. Hibernate mode 25 supported with hardware NVRAM without EmuVariable if StrictHibernate set.

Otherwise with Lilu+HibernationFixup (I didn't tested).

Or set hibernatemode 29.

PMheart · June 29, 2017

Check nvram var's , especially from fakesmc. May be they still not recent and Clover uses old smc keys values

Thanks. Well, I may dig further in some days. Alright, yes, some keys can be too old...

Correct FakeSMC saves all attempts to write to SMC into NVRAM. But not read back NVRAM values.

Write yes

Read no.

Thx Slice. Is this done by SMCHelper.efi? Or do I need some changes in FakeSMC?

Slice · June 29, 2017

SMCHelper is obligatory for FV2, but I not sure about hibernation.

You don't need to change FakeSMC 3.4. It is good enough.

If you have a trouble try to catch it with DumpUefiCalls driver.

PMheart · June 29, 2017

Hibernation depends on many factors.

First, you must have working simple sleep.

Second. Hibernate mode 25 supported with hardware NVRAM without EmuVariable if StrictHibernate set.

Otherwise with Lilu+HibernationFixup (I didn't tested).

Or set hibernatemode 29.

I see. Well, I tested normal sleep (without fv2 enabled) very long time ago... And I've totally forgotten the result. I'll report in a couple of days.

Yes. The second condition is ok to me.

If I remember correctly, Apple set a restriction on determining hibernatemode, which is you can only set it to 0, 3, 25 via `pmset`, we can still patch the related plist though, it doesn't really matter.

SMCHelper is obligatory for FV2, but I not sure about hibernation.

You don't need to change FakeSMC 3.4. It is good enough.

If you have a trouble try to catch it with DumpUefiCalls driver.

Thanks for the information.

If I don't change anything in FakeSMC, then won't the smc-rev key in the default Info.plist be incorrect (for MacPro6,1)?

Is there any link for that DumpUefiCalls driver? Thanks

Clover General discussion

Recommended Posts

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites
