Nvidia Web Driver updates for macOS High Sierra (UPDATE Nov 13, 2020)

fantomas

By fantomas,
in nVidia

 Share
2,046 posts in this topic

Recommended Posts

MICKHAEL
MICKHAEL
Posted
Posted

I would try to disable dsdt in clover dsdt option and put kext nvidiafixup 1.20

Latest kext fixes policy and black screen with signal

I am using only a single ssdt to rename gfx

And it is working

All port are working

I have not tried 4K display

sorry, but i don't see the logic. DSDT method it's the same like your SSDT just one file for all devices... i am right?

Link to comment
Share on other sites
MICKHAEL
MICKHAEL
Posted
Posted

yes you are right

HS is doing toghter nvidiawebdriver some strange behavior and it is different from user and user

If your display port is not working..I would try different ways you used before..

It is not a question about logic.. :-)



it's all about finding illogical ways :)

  • Like 1
Link to comment
Share on other sites
luk1985
luk1985
Posted
Posted

Could yo explain better this 30 bit output problem?

Wich monitor are you using?

Have you also a quadro card connected which have a native 10bit output?

Thank you



i don't think the Photoshop 30bit checkbox has something to do with the monitor output.

when switching to 10-Bit color output I get black screen. Both of my monitors support 10-Bit so I think the Problem is driver or system related.



I'm using Lilu 1.2.0 + NvidiaGraphicsFixup.kext 1.2.0 in EFI-Volume



NVIDIA GeForce GTX 1080 Ti:



  Chipsatz-Modell: NVIDIA GeForce GTX 1080 Ti

  Typ: GPU

  Bus: PCIe

  PCIe-Lane-Breite: x16

  VRAM (gesamt): 11 GB

  Hersteller: NVIDIA (0x10de)

  Geräte-ID: 0x1b06

  Versions-ID: 0x00a1

  ROM-Version: VBIOS 86.02.39.00.01

  Metal: Unterstützt, Funktionsset OSX_GPUFamily1 v2

  Displays:

Cintiq 27QHDT:

  Auflösung: 2560 x 1440 @ 60 Hz

  Framepuffertiefe: 24-Bit Farbe (ARGB8888)

  Display-Seriennummer: 0006HBQ100418

  Hauptdisplay: Ja

  Synchronisierung: Aus

  Eingeschaltet: Ja

  Rotation: Unterstützt

  Helligkeit automatisch anpassen: Nein

  Verbindungstyp: DisplayPort

CS270:

  Auflösung: 2560 x 1440

  Framepuffertiefe: 24-Bit Farbe (ARGB8888)

  Synchronisierung: Aus

  Eingeschaltet: Ja

  Rotation: Unterstützt

  Helligkeit automatisch anpassen: Nein

  Verbindungstyp: DisplayPort



Link to comment
Share on other sites
scj312
scj312
Posted
Posted

this is so strange... on my display only mouse and black screen... works ok on dvi-d. sleep also ok. I thinked maybe after web driver update will start work displayport... on Sierra worked just great

In my testing, different port combinations yielded different results. I have 2 displayport monitors and 1 hdmi working with no black screen, but if I use other combinations I end up with at least one screen black.

Link to comment
Share on other sites
MICKHAEL
MICKHAEL
Posted
Posted

to test I have installed Rextreme

I have two monitor

DELL 2707 WFP

Philips 278G4



for RESxtreme app both are 10 bit compatible...

I didn't know it

However if I set 10 bit resolution I have black screen with signal



I do not have a real 10 bit monitor to test also I think I should have need of a real 10 bit output card like a quadro card

but hey..it is only an opinion! :-)

it seems that my display is 8 bit (6bit+frc). tested with 8/10 bit output displayport=black screen + mouse. dvi-d 8bit ok/ 10bit black screen + mouse

Link to comment
Share on other sites
Cyberdevs
Cyberdevs
Posted
Posted

I have the GTX 1070 and 30-bit doesn't work for me anymore (it did in Sierra). Just get a black screen like you describe. Hopefully it comes back in a future driver update.

Photoshop does seem to support 30-bit still, strangely.

I tried to change the color depth to 30-bit few weeks ago and the same thing happened to me. It also gave me the black screen.

Link to comment
Share on other sites
captain-j
captain-j
Posted
Posted

after reading a lot about 10-bit color output, it seems we have to buy a expensive Quadro Card to use Photoshops 30-bit mode,

because PS uses Open-GL and 30-Bit open-gl needs a Quadro card…



http://nvidia.custhelp.com/app/answers/detail/a_id/3011/



I think that information is a bit out of date. Check here:

https://www.reddit.com/r/hackintosh/comments/6925uy/true_10bit_with_adobe_photoshop_is_now_possible/

Link to comment
Share on other sites
Cyberdevs
Cyberdevs
Posted
Posted

How do you reset to a working resolution_

I have now two black screen in high sierra and i can-t find where ResXtreme write its value to reset it

I have a multiple display setup. I changed one display's color depth and after I saw that it went black I used the other working one to change it back.



I guess you can plug one of your displays to another video output on your GPU and it will be detected with the original settings and revert back the color depth on the other one that it is still connected to the same output as you changed the settings on, and so on.

Link to comment
Share on other sites
Cyberdevs
Cyberdevs
Posted
Posted

I did two error..  :)

I will try your advice

changed from first monitor hdmi1 to 2 and second monitor from dvi to display port but nothing

always black screen with "10 bit" signal



I have to find preferences user display setting or if available ResXtreme plist

Try removing "com.apple.windowserver.plist" from library/prefrences.



ResXtreme changes the PixelEncoding from: --------RRRRRRRRGGGGGGGGBBBBBBBB (24Bit) to --RRRRRRRRRRGGGGGGGGGGBBBBBBBBBB (32Bit)

Link to comment
Share on other sites
Cyberdevs
Cyberdevs
Posted
Posted

almost done

now i see login page in both my monitor

But when i insert password black screen again on botn monitors

Maybe a user setting to delete?

When I change the color depth these files change as well:



~/Library/Preferences/ByHost/com.apple.loginwindows.........plist

~/Library/Preferences/ByHost/com.apple.windowserver.........plist



and



~/Library/Preferences/com.apple.spaces.plist





You can remove the whole "ByHost" folder form your user folder because the files have a tail like: com.apple.loginwindow.DDE707F3-3801-5E48-93A9-B970C08725F7 that might be different from your system,

Link to comment
Share on other sites
Cyberdevs
Cyberdevs
Posted
Posted

Can someone help me get this driver to install? I've tried all the tutorials and still nothing...

On which system you can't get it to work? Do you have EmuVaraiableUEFI.efi installed? and do you have NvidiaWeb checked?

"~/Library/Preferences/ByHost/com.apple.windowserver.........plist"

deleting this solved my problem

Thank you

I have deleted from a 10.13.1 beta 3 because in 10.12.6 I can't see no username folder and many other

Off-Topic but might be useful: (Feel free to delete if you must)



macOS reads the preferences files from /library/preferences and the /System folders and based on those files it will create a another version of them to ~/Library/Preferences so users can have their customized settings. So when we create another user macOS will copy the basic files and settings from /Library/Preferences to new user's Library.

Link to comment
Share on other sites
alez88
alez88
Posted
Posted

Great  B)

Well I'm happy if it can help, that's the goal



u think that it'll be the new procedure for update to new versions?
(create custom package, uninstall, update and last install the custom package?)

it was the only form to avoid the gIOScreenLockState 3 error ... so thank you so much for your work
Link to comment
Share on other sites
chris1111
chris1111
Posted
Posted



u think that it'll be the new procedure for update to new versions?
(create custom package, uninstall, update and last install the custom package?)

it was the only form to avoid the gIOScreenLockState 3 error ... so thank you so much for your work





For my part it is a very good method pending the new Official Drivers
this allows us to test the Betas OS
Link to comment
Share on other sites
DPyro
DPyro
Posted
Posted

On which system you can't get it to work? Do you have EmuVaraiableUEFI.efi installed? and do you have NvidiaWeb checked?



On my Ryzen system, Nvidiaweb checked and EmuVaraiableUEFI.efi is grey in clover config.



EDIT: Nevermind. On the patcher when I ran it, it would still give that warning but ended up installing ok. I also added the fixup kext.

Link to comment
Share on other sites
jsl
jsl
Posted
Posted

Hello, Is it possible fix screen flickering on Fermi GTX550 TI card? Both native and web driver(lilu+NvidiaGraphicsFixup) with Inject Nvidia starting but flickering. I tried with SMBIOS iMac10.1, iMac13.2, iMac14.2 - same result.

Please try change colors from Billion to Million with SwitchResX.

Link to comment
Share on other sites
chris1111
chris1111
Posted
Posted

macOS High Sierra Beta 10.13.1 5 (17B46a)

Works perfect again same method, Install Update , Reboot

Create Package with  Nividia Payload Packager;  install  MyWebDriver.pkg☞ (17B46a) Voila  B)

EDIT**

Test Nividia Payload Packager; with this new Driver here and Works good B)

Thanks @Asgorath








Benchmark not really bad for a s mall Geforce GT 1030 2 gig :)

⬇︎













Link to comment
