loonymonkey
loonymonkey
Posted
Posted
Now I have one last issue left and that is the restart. Restart from windows works but in osx it restarts and halts on boot, before bios and displays a black screen, any ideas lads?



This happen to me when I installed to IDE. When I installed via VMWare to my SATA drive, then copied the Nforce4 kext over, this doesnt happen anymore.

bellomo
bellomo
Posted
Posted

Hi guys !!



Firslty congratulations for incredible work done !!



I'm trying to install 10.4.8 Jas dvd + all path in correct order on

amd x2 + Asus m2n32-sli deluxe mobo with sata drive.

During boot kext AppleNForceATA get loaded but

during install there is no drive selectable !!

In disk utility i can see my disk with all partitions but if

i try to erase partition 3 (primary reserved for osx86) it hangs

with the spinning wheel and probably doing nothing.



I've tried also with Silicon 3132 driver for other controller

but it get not loaded on boot (apparently).



Any help ?



Many thanks !!



Max.

loonymonkey
loonymonkey
Posted
Posted
Hi guys !!



Firslty congratulations for incredible work done !!



I'm trying to install 10.4.8 Jas dvd + all path in correct order on

amd x2 + Asus m2n32-sli deluxe mobo with sata drive.

During boot kext AppleNForceATA get loaded but

during install there is no drive selectable !!

In disk utility i can see my disk with all partitions but if

i try to erase partition 3 (primary reserved for osx86) it hangs

with the spinning wheel and probably doing nothing.



I've tried also with Silicon 3132 driver for other controller

but it get not loaded on boot (apparently).



Any help ?



Many thanks !!



Max.



Did you try installing with VMWare ?

Guest Snowski
Guest Snowski
Posted
Posted
This happen to me when I installed to IDE. When I installed via VMWare to my SATA drive, then copied the Nforce4 kext over, this doesnt happen anymore.



Sounds to good to be true, are you sure the ATA/SATA could have something to do with it?

I'll try to copy an image of this ATA drive over to the SATA and try to make it bootable.



Thx for the info

loonymonkey
loonymonkey
Posted
Posted
Sounds to good to be true, are you sure the ATA/SATA could have something to do with it?

I'll try to copy an image of this ATA drive over to the SATA and try to make it bootable.



Thx for the info



I tried copying my IDE image to SATA, it didn't work. What I did (as previously mentioned in this thread) was install via VMWare to the SATA partition. After everything was setup, I was able to boot nativley from the SATA partiton. Checkout my post about this for more info.

Guest Snowski
Guest Snowski
Posted
Posted

Hmm, but that means I will have to start all over from install point and that is a long way.

I have been using this OS for quite a while now.

I made backups with Superduper though so do you think I could install OSX to the SATA and then replace with my backup?



Thx

loonymonkey
loonymonkey
Posted
Posted
Hmm, but that means I will have to start all over from install point and that is a long way.

I have been using this OS for quite a while now.

I made backups with Superduper though so do you think I could install OSX to the SATA and then replace with my backup?



Thx



I don't know. I spent hours and hours tryinig to get things to work. In the end, I wiped the IDE install, and did the VMWare install.

skyywalker
skyywalker
Posted
Posted

sorry snowski..

i didn't check the link i gave..

i don't know if it was broken..

i'll upload the installer here..



for those who didn't know how to install Nforce4 SATA driver,

or to lazy to type in terminal,download these installer and run it..







Niall Douglas
Niall Douglas
Posted
Posted

Hi,



I have the MCP51 lockup-on-write problem here too with my Nvidia 650i chipset based motherboard. I was the guy who originally implemented a SpeedStep driver for 10.4.4 (see http://forum.insanelymac.com/index.php?sho...915&st=380) so if someone has some source for the Domenico 'MeDevil' Colella implementation of the NForceATA driver, I might just be able to help.



My apologies if it's already been posted - I did search the topic and didn't find anything. Sources would be important to see what's already been done.



Cheers,

Niall

meesterlars
meesterlars
Posted
Posted
Hi,



I have the MCP51 lockup-on-write problem here too with my Nvidia 650i chipset based motherboard. I was the guy who originally implemented a SpeedStep driver for 10.4.4 (see http://forum.insanelymac.com/index.php?sho...915&st=380) so if someone has some source for the Domenico 'MeDevil' Colella implementation of the NForceATA driver, I might just be able to help.



My apologies if it's already been posted - I did search the topic and didn't find anything. Sources would be important to see what's already been done.



Cheers,

Niall



Ah, Niall, I remember you from the speedstep days. You did some great work. I was also very thankful for your start-to-finish guide on installing OS X.



I, too, have a 650i motherboard. Knowing that you could be helping with the NForce driver fills me with great confidence :thumbsup_anim:



Glad to hear you're possibly going to be taking a slog at this. Huzzah!

ninjapig
ninjapig
Posted
Posted

Word.





is the nforce4sata channel still up?



I haven't seen it in the irc channel list lately.....







I don't know if a lot of people don't know this but in the main forum page on the bottom there are direct links and a java based irc system.



Please visit if you can.

yuno
yuno
Posted
Posted
It would also be useful for anybody using an AMD nForce 6100/6150 IGP-based mobo as they also use the MCP51 (nF430) southbridge. :P



Right. And I have no idea how much difference between MCP5x and MCP6x but I really hope Gurus don't forget about MCP61 either.



One of my mobo has MCP61 (Gigabyte GA-M61P-S3, the 1-chip version of 6150SE+430 on it) and I wanna using this without AppleGenericPCATA.

Niall Douglas
Niall Douglas
Posted
Posted
https://developer.berlios.de/projects/nforce4sata/



but according to MeDevil these are outdated.



After a very large amount of hassle, I have finally got the 10.4.8 JaS release onto a PATA drive which (after many hours of hassle) boots into Mac OS X. Then still more hassle happened trying to get my Netgear WG311T wireless network card to be recognised and used (it turned out to be too easy to have seen sooner).



I have removed the medevil kext completely as it was causing hangs on my 650i motherboard but I would like to report that if I disabled the SATA controller in the BIOS, they run flawlessly and the PATA drives are considerably faster.



I have been looking through the source for the kext above - it looks like a clone of the AppleIntelPIIXATA source but with the Nvidia values poked in where appropriate. Is this a fair assessment?



I notice that in the SVN edition of the medevil kext, all SATA support is commented out. Can someone tell me what has been altered since last SVN update, and even better could medevil commit his latest changes to SVN?



I'm thinking it's some kind of DMA write transfer bug in the Nvidia controller. It'll probably have some misspeced oddity the Microsoft and other drivers don't see for some reason. Sadly, we're just going to have to trial & error till we get it though I am tempted to completely rewrite the driver based on a direct derivation from IOPCIATA for clarity.



Anyway, bedtime now. Comments & Thoughts much appreciated.



Cheers,

Niall

Snerler
Snerler
Posted
Posted

https://developer.berlios.de/projects/nforce4sata/



After placing the .kext file into the extentions folder my SATA drive works fine afte 1 reboot, sometimes after 2 reboots, but after that i get an error that the extention was not installed correctly.



I dont know if I am installing it correctly, and i cant seem to find installation instructions... Is there something i have to do other than to copy into the extentions folder?

AppleIIGuy
AppleIIGuy
Posted
Posted
https://developer.berlios.de/projects/nforce4sata/



After placing the .kext file into the extentions folder my SATA drive works fine afte 1 reboot, sometimes after 2 reboots, but after that i get an error that the extention was not installed correctly.



I dont know if I am installing it correctly, and i cant seem to find installation instructions... Is there something i have to do other than to copy into the extentions folder?

The KEXT MUST be put here for it to work correctly



/System/Library/Extensions/IOATAFamily.kext/Contents/PlugIns

SteveStar
SteveStar
Posted
Posted

Hey



Can someone please tell me if you can install osx 10.4.6 (JaS) on a nforce 4 SATA system?!



And if it's possible can someone make a new understandable guide (for noobs) for it because it's a bit confusing all the replies together.



Many thnx

jape
jape
Posted
Posted
The KEXT MUST be put here for it to work correctly



/System/Library/Extensions/IOATAFamily.kext/Contents/PlugIns

Not really (that being pure cosmetic -- matching will be done if you put it at the root. I have mine there.). However Murphy's Law is present...
