deeveedee Posted May 9, 2021 Share Posted May 9, 2021 3 hours ago, panosru said: Also keep in mind that the devices plugged in USB3 are registered two times because a USB3 port is working both as a USB3 and as a USB2 port; thus you may see the same device connected in USB3 and USB2 (like I have for example with 4-Port USB 2.0 Hub and 4-Port USB 3.0 Hub, it is the same device but is listed two times because of the above mentioned mechanism. Are you saying that when you plug a single USB device into a single USB port, that you see that single device appear on two logical ports? That's a new one for me. I've never seen a single USB device appear simultaneously on a logical USB2 and a logical USB3 port. It's common for a single physical USB port to have multiple logical ports (e.g. a single physical USB port can be associated with one USB2 logical port and one USB3 logical port), but I've never seen a single USB device appear simultaneously on two different logical ports. That is interresting. Link to comment Share on other sites More sharing options...
panosru Posted May 9, 2021 Share Posted May 9, 2021 @tonyx86 as I said, I'm almost certain that this is the case but I'm not 100% sure; thus, someone with higher expertise on the matter could clarify that, maybe I'm wrong. I can see in my devices though that my USB hub(s) connected to a USB 3 port(s) is shown both as a USB 2.0 and 3.0 device. Also, for what I'm 99% sure is that USB 3.0/1/2 ports count as two ports, one for 3.0/1/2 and one for 2.0, in contrast with USB 2.0 which counts as one. Link to comment Share on other sites More sharing options...
deeveedee Posted May 9, 2021 Share Posted May 9, 2021 (edited) 3 minutes ago, panosru said: Also, for what I'm 99% sure is that USB 3.0/1/2 ports count as two ports, one for 3.0/1/2 and one for 2.0, in contrast with USB 2.0 which counts as one. Yes - you are correct. Each logical USB2 and logical USB3 port counts as one of the 15. Note that you can choose to "ignore" one of the logical ports to reduce your overall port count. If you have a single USB 3 port, but you know you're only using the port for a USB2 keyboard, you can delete the logical USB3 port from your port map to make room for another logical port while remaining within your 15-port limit. Edited May 9, 2021 by tonyx86 1 Link to comment Share on other sites More sharing options...
panosru Posted May 9, 2021 Share Posted May 9, 2021 Those are both two USB 3 devices connected in USB 3 ports, they are listed both as USB 2.0 and USB 3.0, what confuses me though is why the connected devices are populated under USB 2.0 instead of USB 3.0, I'll have to plug a USB 3.0 flash disk and do a speed test to make sure they work as USB 3 and not as USB 2. 1 Link to comment Share on other sites More sharing options...
deeveedee Posted May 9, 2021 Share Posted May 9, 2021 (edited) Ah - I haven't played with hubs connected to ports. If I understand your diagram, you've inserted a single hub into a single port and the hub appears as both a USB2 hub and a USB3 hub. That does make sense. I don't have a hub to test. Edited May 9, 2021 by tonyx86 Link to comment Share on other sites More sharing options...
panosru Posted May 9, 2021 Share Posted May 9, 2021 @tonyx86 that is correct indeed. Ah I just realised that in my USB 3 hub I have also connected some USB 2 devices, they appear as USB 2 devices, which is normal. My USB 3 flash disk, when I connect it to my USB 3 Hub, it appears as a USB 3 device and I just checked the speeds with Blackmagic disk speed test and it most certainly works as a USB 3 Link to comment Share on other sites More sharing options...
panosru Posted May 9, 2021 Share Posted May 9, 2021 (edited) Strange, it seems my two front USB ports are not working neither in 3.0 nor in 2.0 mode. The front USB ports should be SS/HS 09/10, but I see that on HS09 in my case is populated with my USB 2 hub which is connected to one of HS13 ports. UPDATE: I couldn't figure out how to enable SS10 in the python script, I ended up generating a USBPorts kext from Hacking tool, then edit the info.plist from the contents of USBMap.kext that @AudioGod had provided me a while ago, I removed SS06 as I don't need it, and I added SS10 and now one of my two front USB ports acts as a USB 3 as well. I'm attaching my kext here just in case. USBMap.kext.zip Edited May 10, 2021 by panosru Link to comment Share on other sites More sharing options...
pkdesign Posted May 13, 2021 Share Posted May 13, 2021 Color me confused. If you are using an AORUS Pro or Pro WiFi motherboard (if you are posting in this board you should be) @AudioGod has provided a perfectly working USBMap kext. 1 Link to comment Share on other sites More sharing options...
Pieroman Posted May 14, 2021 Share Posted May 14, 2021 10 hours ago, pkdesign said: a perfectly working USBMap kext Of course it's working and @AudioGod has done a great job, but given the port limit some choices have been made. Depending on the chosen case there are a lot of front panel configurations that can't be covered by a single map (mine has a working USB3 port and a USB-C port that isn't active with the provided map for example). 1 Link to comment Share on other sites More sharing options...
texem Posted May 14, 2021 Share Posted May 14, 2021 just try this kext .. front panel ports are all working here on a "Fractal Design Define R6 USB-C" It's just a re-created ( 1,1 ) kext using the python tool . i reverted the port names ( HSxx and SSxx) to the old ones after kext gen. USBMap.kext.zip 1 Link to comment Share on other sites More sharing options...
eSaF Posted May 14, 2021 Share Posted May 14, 2021 @pkdesign and @Pieroman - I am no expert by any stretch of the imagination but I think that the latest batch of BS updates has slightly altered how some USB ports are powered and as our Hacks come in many different configs even if the chipset is similar, we are finding a difference in previous good working USB map. Some members has found a temporary working solution by removing USB port limit. My situation consists of a once good working Wake/Sleep operation is now flaky, sometimes it works other times it wakes instantly but until a more permanent solution is found, I can't be arsed to {censored} around with it again . @texem - Where have you been Bro, I missed the fire in the Forum but hopefully now it's back! 2 1 Link to comment Share on other sites More sharing options...
xtddd Posted May 15, 2021 Share Posted May 15, 2021 18 hours ago, texem said: just try this kext .. front panel ports are all working here on a "Fractal Design Define R6 USB-C" It's just a re-created ( 1,1 ) kext using the python tool . i reverted the port names ( HSxx and SSxx) to the old ones after kext gen. USBMap.kext.zip 2.39 kB · 7 downloads this kext is for z390 aorus pro? Link to comment Share on other sites More sharing options...
AudioGod Posted May 15, 2021 Author Share Posted May 15, 2021 5 hours ago, xtddd said: this kext is for z390 aorus pro? He wouldn’t of posted on the Z390 Pro thread if it wasn’t brother…. 2 Link to comment Share on other sites More sharing options...
dredhorse Posted May 17, 2021 Share Posted May 17, 2021 On 5/14/2021 at 11:14 AM, eSaF said: @pkdesign and @Pieroman - I am no expert by any stretch of the imagination but I think that the latest batch of BS updates has slightly altered how some USB ports are powered and as our Hacks come in many different configs even if the chipset is similar, we are finding a difference in previous good working USB map. Some members has found a temporary working solution by removing USB port limit. My situation consists of a once good working Wake/Sleep operation is now flaky, sometimes it works other times it wakes instantly but until a more permanent solution is found, I can't be arsed to {censored} around with it again . @texem - Where have you been Bro, I missed the fire in the Forum but hopefully now it's back! I agree, at the moment I'm struggling with getting to work USB at all, running the quirk atm and need to look into creating my own USB kext, I just wonder why. Link to comment Share on other sites More sharing options...
pkdesign Posted May 18, 2021 Share Posted May 18, 2021 I guess sticking with Mojave has served me well Link to comment Share on other sites More sharing options...
rob1980 Posted May 22, 2021 Share Posted May 22, 2021 Bit behind but thanks @AudioGod just updated to 0.69 without any issues. Bit behind but thanks @AudioGod just updated to 0.69 without any issues. 1 Link to comment Share on other sites More sharing options...
Neolo Posted May 24, 2021 Share Posted May 24, 2021 Opencore stuck at apple logo Z390 Designare, can't boot in anything, useless. 2 1 Link to comment Share on other sites More sharing options...
AudioGod Posted May 24, 2021 Author Share Posted May 24, 2021 (edited) 7 hours ago, Neolo said: Opencore stuck at apple logo Z390 Designare, can't boot in anything, useless. The EFI isn’t designed to work with your board so what do you expect? Try here! Edited May 24, 2021 by AudioGod 1 Link to comment Share on other sites More sharing options...
eSaF Posted May 24, 2021 Share Posted May 24, 2021 1 hour ago, AudioGod said: The EFI isn’t designed to work with your board so I what do you expect? How about miracles B!!!!! 3 Link to comment Share on other sites More sharing options...
dsynos80 Posted May 24, 2021 Share Posted May 24, 2021 Hello everyone! Its been a long time, i hope everyone is well and healthy! Still on latest Catalina, i have decided to migrate to OpenCore. -Downloaded Latest AG's magic EFI -Replaced Clover with OC -Entered my details -Added Titan Ridge TB3 SSDT in proper folder -Added IntelBluetooth files, integrated them in config.plist -Rebooted. System booted fine, Thunderbolt and Firewire with adapters works great, Intel Wifi too! Has anyone managed to make bluetooth work, it seems a no go, i even tried putting the kexts after USBMap.kext. Bluetooth is not available, it cannot seem to load the kexts. Any help? Link to comment Share on other sites More sharing options...
AudioGod Posted May 24, 2021 Author Share Posted May 24, 2021 29 minutes ago, dsynos80 said: Hello everyone! Its been a long time, i hope everyone is well and healthy! Still on latest Catalina, i have decided to migrate to OpenCore. -Downloaded Latest AG's magic EFI -Replaced Clover with OC -Entered my details -Added Titan Ridge TB3 SSDT in proper folder -Added IntelBluetooth files, integrated them in config.plist -Rebooted. System booted fine, Thunderbolt and Firewire with adapters works great, Intel Wifi too! Has anyone managed to make bluetooth work, it seems a no go, i even tried putting the kexts after USBMap.kext. Bluetooth is not available, it cannot seem to load the kexts. Any help? You need to add Bluetooth to the usb.map as I never used the WiFi version of the board so never mapped the port. 1 Link to comment Share on other sites More sharing options...
eSaF Posted May 24, 2021 Share Posted May 24, 2021 28 minutes ago, AudioGod said: You need to add Bluetooth to the usb.map as I never used the WiFi version of the board so never mapped the port. @dsynos80 Hi - You have the same board as mine but I don't know if you're trying to use the inbuilt WiFi/B/Tooth whereas I am using a compatible OS X card. Here is my USBMap.kext based on my setup, you can always try it and see if it works for you. USBMap.kext.zip Link to comment Share on other sites More sharing options...
AudioGod Posted May 24, 2021 Author Share Posted May 24, 2021 19 minutes ago, eSaF said: @dsynos80 Hi - You have the same board as mine but I don't know if you're trying to use the inbuilt WiFi/B/Tooth whereas I am using a compatible OS X card. Here is my USBMap.kext based on my setup, you can always try it and see if it works for you. USBMap.kext.zip 2.39 kB · 1 download That will only work if you have mapped the Intel Bluetooth inside the USBMap Link to comment Share on other sites More sharing options...
eSaF Posted May 24, 2021 Share Posted May 24, 2021 5 minutes ago, AudioGod said: That will only work if you have mapped the Intel Bluetooth inside the USBMap Ok B - I wasn't sure how his setup is whether he's using the builtin one or an independent card either way how much would it hurt for him to try it one way or another? At this stage, nothing to lose but in reality he should try and map his USB layout for a better result. Link to comment Share on other sites More sharing options...
dsynos80 Posted May 24, 2021 Share Posted May 24, 2021 (edited) Wow that was fast!! Thank you both! esaf your usb map didnt work for me. it also disabled my top usb2.0 ports. And yes i have the Wifi Version and trying to use the intel CNVi. Ah, i see you use 1.1 i use 19.1 Edited May 24, 2021 by dsynos80 Link to comment Share on other sites More sharing options...
