Matgen84 Posted December 23, 2019 Share Posted December 23, 2019 2 hours ago, luky35 said: I like the name of this theme in the picture, or where I find it Thanks, It's a @Badruzeus theme called: Mojave. You can find it via CloverThemeManager (I think) or Badruzeus repo on GitHub ('MyCloverThemes'). I only customize the logo Link to comment Share on other sites More sharing options...
Andres ZeroCross Posted December 23, 2019 Share Posted December 23, 2019 Did we still need "FSInject.efi" in CLOVER?? When i install Clover, i read the description of FSInject.efi and it's written "Provide injection of kernel extensions from Clover folder.". Honestly, i can boot without this driver,, So when i must use it??? I just use this driver right now 1 Link to comment Share on other sites More sharing options...
Slice Posted December 24, 2019 Share Posted December 24, 2019 11 hours ago, Andres ZeroCross said: Did we still need "FSInject.efi" in CLOVER?? When i install Clover, i read the description of FSInject.efi and it's written "Provide injection of kernel extensions from Clover folder.". Honestly, i can boot without this driver,, So when i must use it??? I just use this driver right now The description is not correct. Actually FSInject allows you to ForceLoad kexts form /S/L/E 1 2 Link to comment Share on other sites More sharing options...
joevt Posted December 25, 2019 Share Posted December 25, 2019 21 hours ago, Slice said: The description is not correct. Actually FSInject allows you to ForceLoad kexts form /S/L/E What does ForceLoad mean? Does it load them like the kexts in the Clover folder? Does it force load all the kexts in /S/L/E? None from /L/E? Link to comment Share on other sites More sharing options...
Slice Posted December 25, 2019 Share Posted December 25, 2019 2 hours ago, joevt said: What does ForceLoad mean? Does it load them like the kexts in the Clover folder? Does it force load all the kexts in /S/L/E? None from /L/E? Original comment from Dmazar is here Post#30 Using extra kexts and skipping kernelcache But OS changed and rules changed. We can write <key>KernelAndKextPatches</key> <dict> <key>ForceKextsToLoad</key> <array> <string>\System\Library\Extensions\AMDRadeonX4000.kext</string> </array> to patch the kext on the fly. Same for /L/E. Volume assumed same as boot.efi used to load cache. It is needed because some system kexts are not present in kernelcache because they are not loaded by default. 2 Link to comment Share on other sites More sharing options...
ameenjuz Posted December 25, 2019 Share Posted December 25, 2019 I didn't see any new kext structure folder on Clover_v2.5k_r5101 second issue I have my VoodoI2C touchpad don't work during installation but with Opencore work my touchpad during installation my touch was working earlier version of clover boot loader I think this is kext injection bug when I install VoodoI2C.kext in system L/E then work fine anyone can tell me about that 1 Link to comment Share on other sites More sharing options...
Jief_Machak Posted December 26, 2019 Share Posted December 26, 2019 The installer doesn’t create these folders. Create some if you need. VoodooI2c is one of the reason I’ve created these folder possibility. So I confirm the voodooI2c not working in installer is NOT because of these new folder name. just create a 10_install folder and put the complete version of voodoops2controller in it and you’ll be able to install. Link to comment Share on other sites More sharing options...
ameenjuz Posted December 26, 2019 Share Posted December 26, 2019 5 hours ago, Jief_Machak said: The installer doesn’t create these folders. Create some if you need. VoodooI2c is one of the reason I’ve created these folder possibility. So I confirm the voodooI2c not working in installer is NOT because of these new folder name. just create a 10_install folder and put the complete version of voodoops2controller in it and you’ll be able to install. I didn't understand please tell me clearly Where can i create 10_install folder Link to comment Share on other sites More sharing options...
vector sigma Posted December 26, 2019 Share Posted December 26, 2019 Just now, anmool said: I didn't understand please tell me clearly Where can i create 10_install folder Try to create it in EFI/CLOVER/ACPI or in EFI/CLOVER/themes . Jokes aside, I would give it a chance in EFI/CLOVER/kexts . 1 Link to comment Share on other sites More sharing options...
pkdesign Posted December 26, 2019 Share Posted December 26, 2019 On 12/20/2019 at 11:08 AM, n.d.k said: You don't have to rename anything. Ok to make it clear for someone not understand it well. - Create a file name VolumeLabel.txt on Desktop - Open it with text editor and write #EFI or any name you want with # in front on the first line, then save it. - Mount the EFI partition (the one you install the clover on) and open up Finder click EFI on the left pane. - Drag the VolumeLabel.txt file to it (the root, not into the EFI folder) - Rename VolumeLabel.txt to .VolumeLabel.txt and it will disappear from the Finder since it's a hidden file name. Done! In Finder, you can use Shift + Command + . to show/hide the hidden files. It still says Clover Boot from EFI when I do the following: Link to comment Share on other sites More sharing options...
Slice Posted December 26, 2019 Share Posted December 26, 2019 3 hours ago, anmool said: I didn't understand please tell me clearly Where can i create 10_install folder 22 minutes ago, pkdesign said: It still says Clover Boot from EFI when I do the following: Is it Clover version from latest github sources? Not from release. 1 Link to comment Share on other sites More sharing options...
telepati Posted December 26, 2019 Share Posted December 26, 2019 is EmuVariableUefi.efi mandatory for the Z390 motherboard? Link to comment Share on other sites More sharing options...
pkdesign Posted December 27, 2019 Share Posted December 27, 2019 4 hours ago, telepati said: is EmuVariableUefi.efi mandatory for the Z390 motherboard? It is on my board for certain. 2 Link to comment Share on other sites More sharing options...
pkdesign Posted December 27, 2019 Share Posted December 27, 2019 (edited) Originally I used Hackintool to download Clover 5101. not sure hwre they get it from. Then I checked https://github.com/CloverHackyColor/CloverBootloader and downloaded from there. Both have the same result. BTW, it also reverts to "Christmas" theme which is VERY annoying. Edited December 27, 2019 by pkdesign Link to comment Share on other sites More sharing options...
ameenjuz Posted December 27, 2019 Share Posted December 27, 2019 20 hours ago, Slice said: Is it Clover version from latest github sources? Not from release. VoodoI2C.kext is not working during installation but with Opencore work VoodooI2C was working fine during installation earlier version of clover i think that something has been changed in clover bootloader Anyone have idea Link to comment Share on other sites More sharing options...
Slice Posted December 27, 2019 Share Posted December 27, 2019 5 hours ago, anmool said: VoodoI2C.kext is not working during installation but with Opencore work VoodooI2C was working fine during installation earlier version of clover i think that something has been changed in clover bootloader Anyone have idea You should modify VoodooI2C.kext/Contents/Info.plist to have this line Link to comment Share on other sites More sharing options...
ameenjuz Posted December 27, 2019 Share Posted December 27, 2019 2 hours ago, Slice said: You should modify VoodooI2C.kext/Contents/Info.plist to have this line on latest VoodoI2C.kext v2.3 already have modified with OSBundleRequired Root I tried already didn't get work during installation I think this is clover issue on OpenCore bootloader is working fine Link to comment Share on other sites More sharing options...
Slice Posted December 28, 2019 Share Posted December 28, 2019 If you provide Clover's boot.log then we can see if the kext is loaded. Link to comment Share on other sites More sharing options...
Sherlocks Posted December 28, 2019 Share Posted December 28, 2019 (edited) On 11/11/2019 at 7:53 PM, Pene said: Hi Slice, Thank you for the response. But I think I didn't explain myself well. 0Bh is the location of of the "Attributes", not it's content. The content is newSmbiosTable.Type17->Attributes = 1 in case of Single-Rank DIMMs and newSmbiosTable.Type17->Attributes = 2 in case of Dual-Rank DIMMs. But this information is *already present* in SMBIOS, without us doing anything special in Clover. He sent me two dmidecodes from a booted Mac, for each case, with the different DIMMs installed. Look: This is the non-working case with the Single-Rank DIMMS: (notice the RANK: 1, it is present in smbios and read from the Attributes address at 0Bh): Handle 0x1101, DMI type 17, 40 bytes Memory Device Array Handle: 0x1000 Error Information Handle: No Error Total Width: 64 bits Data Width: 64 bits Size: 8192 MB Form Factor: DIMM Set: 1 Locator: DIMM0 Bank Locator: BANK 1 Type: DDR4 Type Detail: Synchronous Unbuffered (Unregistered) Speed: 2998 MT/s Manufacturer: Corsair Serial Number: 0000000000000000 Asset Tag: Not Specified Part Number: CMW16GX4M2C3000C15 Rank: 1 Configured Clock Speed: 2133 MT/s Minimum Voltage: 1.2 V Maximum Voltage: 1.2 V Configured Voltage: 1.2 V And this is the non-working case with the Dual-Rank DIMMS: (notice the RANK: 2, it is present in smbios and read from the Attributes address at 0Bh): Handle 0x1100, DMI type 17, 40 bytes Memory Device Array Handle: 0x1000 Error Information Handle: No Error Total Width: 64 bits Data Width: 64 bits Size: 8192 MB Form Factor: DIMM Set: 1 Locator: DIMM0 Bank Locator: BANK 0 Type: DDR4 Type Detail: Synchronous Unbuffered (Unregistered) Speed: 3200 MT/s Manufacturer: G Skill Intl Serial Number: 0000000000000000 Asset Tag: Not Specified Part Number: F4-3200C16-8GTZB Rank: 2 Configured Clock Speed: 2133 MT/s Minimum Voltage: 1.2 V Maximum Voltage: 1.2 V Configured Voltage: 1.2 V This is the only real difference between the chips. He has two pairs of chips that it is working OK for install with them (one pair is 2x8GB - GSKILL the other is 2x16GB - CORSAIR). Both of these are working OK for install and both are with "Rank: 2". He has only one pair with "Rank: 1" (they are more rare I think), but install keeps giving the error with them in all cases, also if using only a single DIMM, also when using both DIMMs. I don't know what we should be doing with this information, I was mentioning it as maybe together we can understand what is going on here... I tried, on my system, to add: newSmbiosTable.Attributes = 1 Just to see if it makes me also get the error (as my Rank also was 2) - but the error did not appear on my System (I don't actually have single-rank DIMMs to test with them, so I tried only to fake the rank). There are many reports on the net (at other sites) about this issue, no one mentioned the Rank, but in most cases it was closed by using other DIMMs or moving the DIMMs in other slots (on boards that have more slots). So this is a memory issue, and in my opinion is is somehow related to the Rank. long time no see. today i went home ofparents. and i checked desktop smbios type 17 Handle 0x1100, DMI type 17, 40 bytes 0000: 11 28 00 11 00 10 ff ff 40 00 40 00 00 20 09 01 0010: 01 02 1a 80 00 55 08 03 04 00 06 01 00 00 00 00 0020: 55 08 00 00 00 00 b0 04 Memory Device Array Handle: 0x1000 Error Information Handle: No Error Total Width: 64 bits Data Width: 64 bits Size: 8192 MB Form Factor: DIMM Set: 1 Locator: DIMM0 Bank Locator: BANK 0 Type: <OUT OF SPEC> Type Detail: Synchronous Speed: 2133 MHz (0.5 ns) Manufacturer: Samsung Serial Number: 090903050F06080A Asset Tag: Not Specified Part Number: M378A1K43BB1-CPB Rank: 1 Configured Clock Speed: 2133 MHz (0.5 ns) Minimum voltage: Unknown Maximum voltage: Unknown Configured voltage: 1.200 V Handle 0x1101, DMI type 17, 84 bytes 0000: 11 54 01 11 00 10 ff ff ff ff ff ff 00 00 09 02 0010: 01 02 00 80 00 00 00 00 00 00 00 00 00 00 00 00 0020: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0030: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0040: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0050: 00 00 00 00 Memory Device Array Handle: 0x1000 Error Information Handle: No Error Total Width: Unknown Data Width: Unknown Size: No Module Installed Form Factor: DIMM Set: 2 Locator: DIMM1 Bank Locator: BANK 0 Type: <OUT OF SPEC> Type Detail: Synchronous Speed: Unknown Manufacturer: Not Specified Serial Number: Not Specified Asset Tag: Not Specified Part Number: Not Specified Rank: Unknown Configured Clock Speed: Unknown Minimum voltage: Unknown Maximum voltage: Unknown Configured voltage: Unknown Handle 0x1102, DMI type 17, 84 bytes 0000: 11 54 02 11 00 10 ff ff ff ff ff ff 00 00 09 03 0010: 01 02 00 80 00 00 00 00 00 00 00 00 00 00 00 00 0020: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0030: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0040: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0050: 00 00 00 00 Memory Device Array Handle: 0x1000 Error Information Handle: No Error Total Width: Unknown Data Width: Unknown Size: No Module Installed Form Factor: DIMM Set: 3 Locator: DIMM2 Bank Locator: BANK 0 Type: <OUT OF SPEC> Type Detail: Synchronous Speed: Unknown Manufacturer: Not Specified Serial Number: Not Specified Asset Tag: Not Specified Part Number: Not Specified Rank: Unknown Configured Clock Speed: Unknown Minimum voltage: Unknown Maximum voltage: Unknown Configured voltage: Unknown Handle 0x1103, DMI type 17, 84 bytes 0000: 11 54 03 11 00 10 ff ff ff ff ff ff 00 00 09 04 0010: 01 02 00 80 00 00 00 00 00 00 00 00 00 00 00 00 0020: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0030: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0040: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0050: 00 00 00 00 Memory Device Array Handle: 0x1000 Error Information Handle: No Error Total Width: Unknown Data Width: Unknown Size: No Module Installed Form Factor: DIMM Set: 4 Locator: DIMM3 Bank Locator: BANK 0 Type: <OUT OF SPEC> Type Detail: Synchronous Speed: Unknown Manufacturer: Not Specified Serial Number: Not Specified Asset Tag: Not Specified Part Number: Not Specified Rank: Unknown Configured Clock Speed: Unknown Minimum voltage: Unknown Maximum voltage: Unknown Configured voltage: Unknown i can't install 10.14+ now from usb installer. only need to update mojave or catalina from high sierra. i will test smbios version and memory rank Edited December 28, 2019 by Sherlocks 1 Link to comment Share on other sites More sharing options...
Sherlocks Posted December 28, 2019 Share Posted December 28, 2019 (edited) 5 hours ago, Sherlocks said: long time no see. today i went home ofparents. and i checked desktop smbios type 17 Handle 0x1100, DMI type 17, 40 bytes 0000: 11 28 00 11 00 10 ff ff 40 00 40 00 00 20 09 01 0010: 01 02 1a 80 00 55 08 03 04 00 06 01 00 00 00 00 0020: 55 08 00 00 00 00 b0 04 Memory Device Array Handle: 0x1000 Error Information Handle: No Error Total Width: 64 bits Data Width: 64 bits Size: 8192 MB Form Factor: DIMM Set: 1 Locator: DIMM0 Bank Locator: BANK 0 Type: <OUT OF SPEC> Type Detail: Synchronous Speed: 2133 MHz (0.5 ns) Manufacturer: Samsung Serial Number: 090903050F06080A Asset Tag: Not Specified Part Number: M378A1K43BB1-CPB Rank: 1 Configured Clock Speed: 2133 MHz (0.5 ns) Minimum voltage: Unknown Maximum voltage: Unknown Configured voltage: 1.200 V Handle 0x1101, DMI type 17, 84 bytes 0000: 11 54 01 11 00 10 ff ff ff ff ff ff 00 00 09 02 0010: 01 02 00 80 00 00 00 00 00 00 00 00 00 00 00 00 0020: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0030: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0040: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0050: 00 00 00 00 Memory Device Array Handle: 0x1000 Error Information Handle: No Error Total Width: Unknown Data Width: Unknown Size: No Module Installed Form Factor: DIMM Set: 2 Locator: DIMM1 Bank Locator: BANK 0 Type: <OUT OF SPEC> Type Detail: Synchronous Speed: Unknown Manufacturer: Not Specified Serial Number: Not Specified Asset Tag: Not Specified Part Number: Not Specified Rank: Unknown Configured Clock Speed: Unknown Minimum voltage: Unknown Maximum voltage: Unknown Configured voltage: Unknown Handle 0x1102, DMI type 17, 84 bytes 0000: 11 54 02 11 00 10 ff ff ff ff ff ff 00 00 09 03 0010: 01 02 00 80 00 00 00 00 00 00 00 00 00 00 00 00 0020: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0030: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0040: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0050: 00 00 00 00 Memory Device Array Handle: 0x1000 Error Information Handle: No Error Total Width: Unknown Data Width: Unknown Size: No Module Installed Form Factor: DIMM Set: 3 Locator: DIMM2 Bank Locator: BANK 0 Type: <OUT OF SPEC> Type Detail: Synchronous Speed: Unknown Manufacturer: Not Specified Serial Number: Not Specified Asset Tag: Not Specified Part Number: Not Specified Rank: Unknown Configured Clock Speed: Unknown Minimum voltage: Unknown Maximum voltage: Unknown Configured voltage: Unknown Handle 0x1103, DMI type 17, 84 bytes 0000: 11 54 03 11 00 10 ff ff ff ff ff ff 00 00 09 04 0010: 01 02 00 80 00 00 00 00 00 00 00 00 00 00 00 00 0020: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0030: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0040: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0050: 00 00 00 00 Memory Device Array Handle: 0x1000 Error Information Handle: No Error Total Width: Unknown Data Width: Unknown Size: No Module Installed Form Factor: DIMM Set: 4 Locator: DIMM3 Bank Locator: BANK 0 Type: <OUT OF SPEC> Type Detail: Synchronous Speed: Unknown Manufacturer: Not Specified Serial Number: Not Specified Asset Tag: Not Specified Part Number: Not Specified Rank: Unknown Configured Clock Speed: Unknown Minimum voltage: Unknown Maximum voltage: Unknown Configured voltage: Unknown i can't install 10.14+ now from usb installer. only need to update mojave or catalina from high sierra. i will test smbios version and memory rank info. laptop: everything is okay desktop: always data error when install macos from usb installer on 10.14+. okay. tested it. no effect memory rank part. i checked my laptop. my laptop single channel ram and needed to add memory info in smbios in config to avoid memory error. i added memory info in config like my laptop. there is no problem. finally i skipped data error message when install macos catalina from usb installer. i dont know and not sure exact problem. Edited December 28, 2019 by Sherlocks 2 Link to comment Share on other sites More sharing options...
Pene Posted December 28, 2019 Share Posted December 28, 2019 3 hours ago, Sherlocks said: info. laptop: everything is okay desktop: always data error when install macos from usb installer on 10.14+. okay. tested it. no effect memory rank part. i checked my laptop. my laptop single channel ram and needed to add memory info in smbios in config to avoid memory error. i added memory info in config like my laptop. there is no problem. finally i skipped data error message when install macos catalina from usb installer. i dont know and not sure exact problem. Hi, What memory info did you add exactly? Also, how does dmi dump look after you added memory info? Link to comment Share on other sites More sharing options...
ameenjuz Posted December 28, 2019 Share Posted December 28, 2019 14 hours ago, Slice said: If you provide Clover's boot.log then we can see if the kext is loaded. preboot log attached preboot.log Link to comment Share on other sites More sharing options...
Slice Posted December 28, 2019 Share Posted December 28, 2019 1 hour ago, anmool said: preboot log attached preboot.log It looks like all needed kexts are successfully loaded including VoodooI2C and VoodooPS2. I just don't know why both should be used. AFAIK PS2 is a bus and I2C is another bus. You should use one or another, but I don't know the logic of these kexts. You should ask something else. At my side Clover does all work. Link to comment Share on other sites More sharing options...
apianti Posted December 28, 2019 Share Posted December 28, 2019 Random musings, no idea if anyone will understand who I am talking to but eh... I am confused why you are not using the device path to show the booted device as well, so you can actually tell what volume it is since there are often multiple EFI partitions. It should be probably hidden by default but maybe the debug options can enable it as well as a specific option (unless that option is false then don't enable at all). The thing about stack allocation vs. dynamic allocation, the stack size can be set and may not be set to something reasonable for a large usage like multiple kilobytes. So allocating large chunks of memory dynamically is way better, also slice's solution allows the strings to be any size that can be allocated, the other truncates the string to the static size. You can't write c++ code because of the standard c++ library it would require writing a standard library for almost every significant version of every compiler to match the internal structures of how the the library and objects are initialized and destroyed. It can be done but it's not pleasant and compiler changes could break it, like you would need four different versions for VS 2012/13, 2015, 2017, and 2019. You would also need them for different versions of xcode/clang and gcc. Do the tables match before and after you set them manually? I notice it says Set 1, 2, 3, and 4, I don't think you should have more than 2 sets (the unpopulated ones should have a zero...), since you should probably only have a dual channel memory controller. What are you table 16's, 19's, and 20's in each of these cases? Ok, I'm going to disappear into the night again. Link to comment Share on other sites More sharing options...
pkdesign Posted December 28, 2019 Share Posted December 28, 2019 On 12/26/2019 at 4:18 PM, telepati said: is EmuVariableUefi.efi mandatory for the Z390 motherboard? I just switched my config over to the one located here: It works perfectly right now. I have been trying for months to get rid of the OsxAptioFix2Drv-free2000.efi driver and absolutely nothing worked until now. I am using the VirtualSMC now but want to go back to FakleSMC. Not entirely sure why other than sensors. 1 1 Link to comment Share on other sites More sharing options...
