Babiloe
Babiloe
Posted
Posted (edited)

MAld0n, I can't post a new topic on post installation forum. is it on maintenance?

now i can post the topic into post installation problem...




Notebook Asus X550VX i7 - 7700hq
GTX950MX - UHD630
A1718086 - 025510ec ALC255 that works only on VoodooHDA
RTL8111 LAN

Hwinfo
https://drive.google.com/open?id=1n5rHIw-jDPCgocWJtZ0AoVlqIi6Xc7XL



Not work:
1. White Screen Wake up
EDID not a asolution
IOREG output http://www.mediafire.com/file/u7odzbaxa7bbb6a/ioregSaved.txt and EDID
http://www.mediafire.com/file/hqlapgf4luwchdf/DisplayProductID-69c.plist

https://ibb.co/faL5wx

2. Battery info status bar sometimes goes on / off like battery has off
3. Crackle Sound using   earphone using VoodooHDA
       Still investigation using patched iomatch voodooha info.plist
       The sound card can’t be using AppleALC, no sound came out using layout 3, 13, 17, 18, 27, 28, 99


I have your (Mald0n) DSDT



http://www.mediafire.com/file/lmp5yy65rblx9ne/DSDTtitomaldon2.dsl



I have re-patched again for FnKeys and Brighness Key

http://www.mediafire.com/file/5rs93ij0wco99s6/DSDTtitomaldon2editv2.aml




codec dump linux
https://drive.google.com/file/d/1pg2y76WvFYsO8vFY-2B_2OLyKMmkQ8Tg/view


latest debug
http://www.mediafire.com/file/2pjny4eq5r64ed8/debug_1383 (1).zip

clover and kext
https://drive.google.com/open?id=1n5rHIw-jDPCgocWJtZ0AoVlqIi6Xc7XL


Edited by Babiloe
Link to comment
Share on other sites
Mikentosh2016
Mikentosh2016
Posted
Posted

Thank you, thank you, thank you!!  I've been trying to reinstall Sierra on my Hackintosh for months but finally succeeded by using this link.  I can't believe it.  I'll delete the Chopintosh install in a few days after finalizing this install.

  • Like 1
Link to comment
Share on other sites
BantalBambu
BantalBambu
Posted
Posted
15 minutes ago, santes said:

Recently i am having some issue with screen flickering...i had this in past but rarely came....but now its everyday issue... so plz anyone help me...



You has installed IntelGraphicsFixup.kext and lilu.kext ?

  • Like 1
Link to comment
Share on other sites
MaLd0n
MaLd0n
Posted
  • Author
Posted
1 hour ago, rubahgeni said:

MaLd0n i created my hackintosh but at pci device not show up all device, can help me to makae DSDT



My hackintosh specification:

ASUS Z270 MAXIMUS IX CODE BIOS 1301

Core i5 7600K overclock 4.8Ghz

Memory 16GB

AMD RADEON RX 560

Use pci card broadcom wifi & bluetooth



DSDT and clover compile RunMe.app





https://www100.zippyshare.com/v/bXi8t5Ri/file.html


  • Like 2
Link to comment
Share on other sites
Mikentosh2016
Mikentosh2016
Posted
Posted (edited)
1 hour ago, santes said:

no.. i put in EFI folder





What about /System/Library/Extensions?

Edited by Mikentosh2016
More line space.
Link to comment
Share on other sites
MaLd0n
MaLd0n
Posted
  • Author
Posted
30 minutes ago, rubahgeni said:

MaLd0n, can you help me to create DSDT?



Hardware Specification

Motherboard ASUS Z170i STRIX

Processor Intel core i5 6600K 4,6Ghz

16 GB

AMD RADEON RX560



This is DSDT and compile with runme.app

https://www61.zippyshare.com/v/cih2UHkl/file.html


  • Like 2
Link to comment
Share on other sites
visin
visin
Posted
Posted

Hello MaLd0n:

The following is my Hackintosh platform：

CPU：i7 8400

MB：Galaxy B360M-M.2

RAM：G.skill DDR4 2133 8G

Audio：Alc 662-VD



Trouble for me to make DSDT, thanks
The ALC662-VD does not work. Injecting 5,7,11,12,13 does not work. How can I get him to work? AppleALC does not support ALC662-VD?



Attach Files is run me app to Files



https://drive.google.com/open?id=1Sh0DKBTEVj25Dw0QCZxCYApANgmw5Vxf

Link to comment
Share on other sites
MaLd0n
MaLd0n
Posted
  • Author
Posted
5 hours ago, visin said:

Hello MaLd0n:

The following is my Hackintosh platform：

CPU：i7 8400

MB：Galaxy B360M-M.2

RAM：G.skill DDR4 2133 8G

Audio：Alc 662-VD



Trouble for me to make DSDT, thanks
The ALC662-VD does not work. Injecting 5,7,11,12,13 does not work. How can I get him to work? AppleALC does not support ALC662-VD?



Attach Files is run me app to Files



https://drive.google.com/open?id=1Sh0DKBTEVj25Dw0QCZxCYApANgmw5Vxf

send me new files after reboot

CLOVER.zip

u can try...

MaLd0n 2018-04-29 às 10.39.11.png

  • Like 1
Link to comment
Share on other sites
MaLd0n
MaLd0n
Posted
  • Author
Posted
5 minutes ago, rubahgeni said:

MaLd0n, i use this clover sleep can work perfect but when shutdown my hackintosh always restart.

I try use FixShutdown, SlpSMiAtWake but this issue can't solved.



What is solution for shutdown issue?

DSDT.aml.zip

  • Like 2
Link to comment
Share on other sites
visin
visin
Posted
Posted (edited)



23 hours ago, MaLd0n said:

send me new files after reboot

CLOVER.zip

u can try...

MaLd0n 2018-04-29 às 10.39.11.png

I used the clover you provided and found the following questions:

1. Look at DSDT. There is a mistake.


2, PCI devices are only EMI Controller and UHD 630.


3, There are problems to turn off and restart.

(1) no power is cut off, the machine is still running, but there is no image on the monitor.

(2) the restart state is the same as the shutdown, and the monitor has no image.

4, Audio still do not work, I injected 5, 7, 11, 12, 13, no effect, I checked the information, some solution is in the DSDT Patch, I put it below, you see if there is any use.

（1）HDEF_Patch

#Automatically adjusted by AppleHDA Patcher.app
# original by RehabMan


#   Inject Audio info
into method label _DSM parent_label HDEF remove_entry;
into device label HDEF insert
begin
Method (_DSM, 4, NotSerialized)\n
{\n
    If (LEqual (Arg2, Zero)) { Return (Buffer() { 0x03 } ) }\n
    Return (Package()\n
    {\n
        "AAPL,slot-name", Buffer() { "Built in" },\n
        "layout-id", Buffer() { 0x05, 0x00, 0x00, 0x00 },\n
        "device_type", Buffer() { "Audio Controller" },\n
        "built-in", Buffer() { 0x00 },\n
        "PinConfigurations", Buffer() { },\n
        "hda-gfx", Buffer() { "onboard-1" }\n
    })\n
}\n
end

（2）IRQ_Fix

{\rtf1\ansi\ansicpg936\cocoartf1561\cocoasubrtf200
{\fonttbl\f0\fswiss\fcharset0 Helvetica;}
{\colortbl;\red255\green255\blue255;}
{\*\expandedcolortbl;;}
\paperw11900\paperh16840\margl1440\margr1440\vieww10800\viewh8400\viewkind0
\pard\tx566\tx1133\tx1700\tx2267\tx2834\tx3401\tx3968\tx4535\tx5102\tx5669\tx6236\tx6803\pardirnatural\partightenfactor0

\f0\fs24 \cf0 #Maintained by: RehabMan for: Laptop Patches\
#system_IRQ.txt\
\
# This can fix non-working audio and also has an affect on HPET.\
#\
# Use this if you have issues with patched AppleHDA (required on almost all laptops)\
# or if you have issues with HPET (restart after wake).\
\
# IRQ fix\
into device name_hid PNP0000 code_regex IRQNoFlags\\s\\(\\)\\n\\s+\\\{(\\d+)\\\} remove_matched;\
into device name_hid PNP0100 code_regex IRQNoFlags\\s\\(\\)\\n\\s+\\\{(\\d+)\\\} remove_matched;\
into device name_hid PNP0B00 code_regex IRQNoFlags\\s\\(\\)\\n\\s+\\\{(\\d+)\\\} remove_matched;\
into device name_hid PNP0103 code_regex IRQNoFlags\\s\\(\\)\\n\\s+\\\{.*\\\} removeall_matched;\
into device name_hid PNP0103 code_regex Name\\s\\(([^,]+),\\sResourceTemplate\\s\\(\\).*\\n\\s+\\\{((?:.|\\n)*)\\\}\\) replace_matched\
begin\
Name (%1, ResourceTemplate()\\n\
\{\\n\
    IRQNoFlags() \{ 0, 8, 11, 15 \}\\n\
%2\
\})\\n\
end;}

I got the Codec#0 of the audio, but I didn't compile AppleALC.

codec#0


Verbs from Linux Codec Dump File: codec#0

Codec: Realtek ALC662 rev3   Address: 0   DevID: 283903586 (0x10ec0662)

   Jack   Color  Description                  Node     PinDefault             Original Verbs
--------------------------------------------------------------------------------------------------------
    1/8   Black  Speaker at Ext Rear         18 0x12   0x411111f0   01271cf0 01271d11 01271e11 01271f41
    1/8   Green  Line Out at Ext Rear        20 0x14   0x01014010   01471c10 01471d40 01471e01 01471f01
 Analog UNKNOWN  Speaker at Ext N/A          21 0x15   0x4017c040   01571c40 01571dc0 01571e17 01571f40
    1/8   Black  Speaker at Ext Rear         22 0x16   0x411111f0   01671cf0 01671d11 01671e11 01671f41
 Mic at Ext Rear    0x18 0x18                        27365408 01871c20 01871d90     01871ea1 01871f01
 Mic at Ext Front    0x19 0x19                        44142625 01971c21 01971d90     01971ea1 01971f02
 Line In at Ext Rear    0x1a 0x1a                        25243695 01a71c2f 01a71d30     01a71e81 01a71f01
 HP Out at Ext Front    0x1b 0x1b                        35733535 01b71c1f 01b71d40     01b71e21 01b71f02
    1/8   Black  Speaker at Ext Rear         28 0x1c   0x411111f0   01c71cf0 01c71d11 01c71e11 01c71f41
Optical UNKNOWN  Mic at Ext N/A              29 0x1d   0x40a5c641   01d71c41 01d71dc6 01d71ea5 01d71f40
    1/8   Black  Speaker at Ext Rear         30 0x1e   0x411111f0   01e71cf0 01e71d11 01e71e11 01e71f41
--------------------------------------------------------------------------------------------------------


   Jack   Color  Description                  Node     PinDefault             Modified Verbs
--------------------------------------------------------------------------------------------------------
    1/8   Green  Line Out at Ext Rear        20 0x14   0x01014010   01471c10 01471d40 01471e01 01471f01
 Analog UNKNOWN  Speaker at Ext N/A          21 0x15   0x4017c040   01571c40 01571dc0 01571e17 01571f40
 Mic at Ext Rear    0x18 0x18                        27365408 01871c20 01871d90     01871ea1 01871f01
 Mic at Ext Front    0x19 0x19                        44142625 01971c30 01971d90     01971ea1 01971f01
 Line In at Ext Rear    0x1a 0x1a                        25243695 01a71c50 01a71d30     01a71e81 01a71f01
 HP Out at Ext Front    0x1b 0x1b                        35733535 01b71c60 01b71d40     01b71e21 01b71f01
Optical UNKNOWN  Mic at Ext N/A              29 0x1d   0x40a5c641   01d71c70 01d71dc0 01d71ea5 01d71f40
--------------------------------------------------------------------------------------------------------

I re run send_Me

https://drive.google.com/open?id=16LHBuWvxh-HYT3gT1HqxRtw-WnqoTsaH





Edited by visin
