deeveedee Posted July 10, 2023 Share Posted July 10, 2023 @Stefanalmare I completely disabled my SSDT-SBUS.BUS0 ACPI patch. Without the patch, macOS Ventura 13.4.1 still detects SBUS @1F,3 Spoiler and AppleSMBusController still loads Spoiler At first glance, it appears that the BUS0 ACPI patch is completely unnecessary on my HackBookPro6,2 running Ventura 13.4.1. Link to comment Share on other sites More sharing options...
Stefanalmare Posted July 10, 2023 Share Posted July 10, 2023 (edited) 8 minutes ago, deeveedee said: @Stefanalmare I completely disabled my SSDT-SBUS.BUS0 ACPI patch. Without the patch, macOS Ventura 13.4.1 still detects SBUS @1F,3 Hide contents and AppleSMBusController still loads Hide contents At first glance, it appears that the BUS0 ACPI patch is completely unnecessary on my HackBookPro6,2 running Ventura 13.4.1. H370: Spoiler z690: Spoiler Edited July 10, 2023 by Stefanalmare Link to comment Share on other sites More sharing options...
miliuco Posted July 10, 2023 Share Posted July 10, 2023 (edited) 3 hours ago, Melab said: Then what is this? This is one of the ways (not the only one) to create the macOS installer (Apple's package program that allows you to install a version of macOS on a Mac), not the OpenCore installer (which is the package that allows macOS to be installed and running on a PC). OpenCore does not have such an installer. @deeveedee @Stefanalmare I don't use any SSDT-SBUS and also have the 2 kexts loaded and the device SBUS@1F,4 in IOReg. Monterey and Sonoma. Edited July 10, 2023 by miliuco 3 Link to comment Share on other sites More sharing options...
deeveedee Posted July 10, 2023 Share Posted July 10, 2023 (edited) @miliuco I feel a bit hypocritical by removing my SSDT-SBUS ACPI patch, since I have so many other patches that are simply cosmetic. Like you and Stefanalmare, my hack (SMBIOS MBP6,2) is booting and running Ventura 13.4.1 just fine without any SBUS ACPI patching. @cankiulascmnfye Thank you again for directing me to your discord discussion. @Stefanalmare Thank you for posting your examples. Learning something new every day. EDIT: I have completely removed the SBUS ACPI patches from my HackBookPro6,2. I am no longer injecting Device Bus0 (including DVL0). com.apple.driver.AppleSMBusController is still loaded. I don't see any difference in the behavior of my hack. Edited July 11, 2023 by deeveedee 4 Link to comment Share on other sites More sharing options...
cankiulascmnfye Posted July 11, 2023 Share Posted July 11, 2023 9 hours ago, Stefanalmare said: @deeveedee I think SBUS is very important in a hack. Can be a topic discussion. Speaking about "should not be installed", I remember that without DVL0 in that rig, com.apple.driver.AppleSMBusController does not load. So, I keep it. Well, SBUS and MCHC are important so that the System Management bus works but not DVL0 which is the "Diagsvault". More info: https://github.com/acidanthera/OpenCorePkg/pull/442 2 Link to comment Share on other sites More sharing options...
cankiulascmnfye Posted July 11, 2023 Share Posted July 11, 2023 (edited) 19 hours ago, deeveedee said: Ok - I will test it in my rigs. (Just the removal of Device (DVL0) ). EDIT: @Stefanalmare Below is the IOReg dump on my HackBookPro6,2 with and without SBUS.BUS0.DLV0. My hack boots and appears to be running Ventura 13.4.1 just fine even with the missing device. IOReg with DVL0 Hide contents IOReg without DVL0 (AppleSMBusControllerICH does not load) Hide contents @Stefanalmare, @cankiulascmnfye Does it matter at all that AppleSMBusControllerICH is not loading on a hackintosh (without DLV0)? I haven't tested much, but so far, I see no difference with and without (except for IOReg). Maybe this is just cosmetic? From the info I could gather om github, it's only important that Sbus is present in IOReg. Now, if you don't inject SBUS-MCHC into the system and run kextstat | grep -E "AppleSMBusController|AppleSMBusPCI" And get com.apple.driver.AppleSMBusPCI (1.0.14d1) … you're should be fine If yu inject SSBU-MCHC containing the DVL0 device, you get 2 results in return – simply because of the DVL0 device is attached to the SMBUS: … com.apple.driver.AppleSMBusPCI (1.0.14d1)… … com.apple.driver.AppleSMBusController (1.0.18d1) … From my understanding the real Diagsvault device needs to be able wo write to addresses which are disabled by default since Intel 7 Series. So there's no point in injecting DVL0 on Wintel systems. In my case. I only have to inject SSDT-MCHC to get both results. In Sonoma, I get both results even without injecting SBUS and/or MCHC into my desktop (iMac20,2) Edited July 11, 2023 by cankiulascmnfye Link to comment Share on other sites More sharing options...
deeveedee Posted July 11, 2023 Share Posted July 11, 2023 (edited) Leaving the post below for historical purposes. I have now removed Device SBUS.BUS0 ACPI patches from my HackBookPro6,2 and my HackMini8,1 (I am no longer patching SBUS (no longer adding Device BUS0 / Device BUS0.DVL0) ). After brief testing, both hacks continue to boot/run Big Sur, Montery, Ventura and Sonoma without any behaviorial/performance changes. I will continue to test. At this time, it does appear that ACPI patching of SBUS is unnecessary on hackintoshes. The only requirement for hacks is the presence of Device SBUS, which on my hacks is already present in the unpatched ACPI. ===================================================== @cankiulascmnfye I am no longer patching SBUS at all (not injecting BUS0). My HackBookPro6,2 is running Ventura 13.4.1 without any issues (at least no new issues after removing the SBUS ACPI patching) and com.apple.driver.AppleSMBusController is loaded. kextstat -a | grep -I smbu (Ventura 13.4.1) Spoiler Note that I am still adding MCHC via SSDT. EDIT: I'm booting Big Sur, Monterey, Ventura and Sonoma with the same EFI. Unlike Ventura, kextstat in Big Sur, Monterey and Sonoma shows that com.apple.driver.comAppleSMBusPCI is loaded kextstat -a | grep -I smbu (Big Sur 11.7.8, Monterey 12.6.7, Sonoma 14.0 Beta 3) Spoiler EDIT2: @cankiulascmnfye I don't know how to explain this, but after booting Big Sur, Monterey and Sonoma to test my new EFI (with the removal of SBUS ACPI patches), I rebooted Ventura 13.2.1 and Ventura 13.4.1 and com.apple.driver.comAppleSMBusPCI is now loaded in Ventura. Note that I Reset NVRAM before booting each version of macOS. kextstat -a | grep -i smbu (Ventura 13.4.1 after booting Big Sur, Monterey and Sonoma): AppleSMBusPCI is now loading Spoiler EDIT3: I now see what's happening in Ventura. AppleSMBusPCI loads at boot, but then unloads. After waiting a few minutes and rechecking kextstat, AppleSMBusPCI is no longer loaded in Ventura. kextstat -a | grep -i smbu (Ventura 13.4.1 after waiting a few minutes after booting): AppleSMBusPCI is unloaded Spoiler Edited July 11, 2023 by deeveedee 1 Link to comment Share on other sites More sharing options...
cankiulascmnfye Posted July 11, 2023 Share Posted July 11, 2023 @deeveedee I've witnessed this behavior of that driver on my system as well. At some stage I started shutting down the system before testing changed settings, just to ensure that the state of the machine is the same each time. Maybe it loads/unloads as needed. I think the important thing is that SBUS/SMBUS is present in the IO registry. 1 Link to comment Share on other sites More sharing options...
MacKonsti Posted July 11, 2023 Share Posted July 11, 2023 4 hours ago, deeveedee said: EDIT3: I now see what's happening in Ventura. AppleSMBusPCI loads at boot, but then unloads. After waiting a few minutes and rechecking kextstat, AppleSMBusPCI is no longer loaded in Ventura. Thank you again for your input and feedback @deeveedee! The question is... what about the other macOS versions, did you notice the same behaviour? Does this thing do anything by not loading, eventually...? com.apple.driver.AppleSMBusPCIcom.apple.driver.AppleSMBusController We share the same hardware between my Intel NUC8 / NUC10 and your HP Elite 800 G4/G5 (if not mistaken) so you got me thinking... Link to comment Share on other sites More sharing options...
deeveedee Posted July 11, 2023 Share Posted July 11, 2023 (edited) @MacKonsti Great to hear from you, mate! After removing all SBUS ACPI patches (no longer injecting SBUS.BUS0 / SBUS.BUS0.DVL0) I don't observe any change in behavior/performance with Big Sur, Monterey, Ventura and Sonoma on my HackBookPro6,2 or my HackMini8,1. I just made the change and am continuing to test. Edited July 11, 2023 by deeveedee 1 Link to comment Share on other sites More sharing options...
MacKonsti Posted July 11, 2023 Share Posted July 11, 2023 Thanks @deeveedee just to confirm to everyone else here too, that I also disabled completely the SSDT-SBUS.aml in OpenCore config on my NUC10i7FNH (Core i7-8700B @ 3.20 GHz) declared as MacMini8,1 and rebooted. Even let it sleep. I still get both kexts being active on Ventura; but indeed on IOReg, there's no longer a tree under device SBUS. My device is according to "lspci -nn" 00:1f.4 SMBus [0c05]: Intel Corporation Comet Lake SMBus Host Controller [8086:02a3] $ kextstat | grep -E "AppleSMBusController|AppleSMBusPCI" Executing: /usr/bin/kmutil showloaded No variant specified, falling back to release 157 0 0xffffff7f958a9000 0x1000 0x1000 com.apple.driver.AppleSMBusPCI (1.0.14d1) 3B3CBC6F-07BD-3D7E-9F2F-D738A31C290D <17 7 6 3> 165 1 0xffffff7f9589d000 0x6ffd 0x6ffd com.apple.driver.AppleSMBusController (1.0.18d1) 18305D5D-1310-37BC-B654-6C034FD346E7 <164 17 16 7 6 3> I will keep using it and see if I detect anything noticeable. Thanks to everyone. 1 Link to comment Share on other sites More sharing options...
Slice Posted July 12, 2023 Share Posted July 12, 2023 sudo kextstat | grep SMBus will be enough 3 Link to comment Share on other sites More sharing options...
deeveedee Posted July 12, 2023 Share Posted July 12, 2023 (edited) 5 hours ago, Slice said: sudo kextstat | grep SMBus will be enough kextstat | grep SMBu is also enough EDIT: This reminds me of that old game show "Name that tune." Can anyone "name that tune" in fewer notes? Edited July 12, 2023 by deeveedee 1 Link to comment Share on other sites More sharing options...
cankiulascmnfye Posted July 12, 2023 Share Posted July 12, 2023 @deeveedee @Slice Well, if you use Grep SMbus, you get all sorts of other matches as well, like VoodooSMBUS if you use a trackpad… 58 4 0xffffff8002f68000 0xffe 0xffe com.apple.iokit.IOSMBusFamily (1.1) 02901024-7468-311C-98A7-896350D03A80 <7 6 3> 91 1 0xffffff8004e58000 0x18000 0x18000 de.leo-labs.VoodooSMBus (3.0) C7EA611A-7A6E-3210-800F-79585B09468C <17 7 6 3> 94 0 0xffffff8004e70000 0xf000 0xf000 com.1Revenger1.RMISMBus (1.0) 1C98C210-E89C-33DF-9DD7-36058B9AB6AC <93 91 16 7 6 3> 146 1 0xffffff7f9589d000 0x6ffd 0x6ffd com.apple.driver.AppleSMBusController (1.0.18d1) 18305D5D-1310-37BC-B654-6C034FD346E7 <58 17 16 7 6 3> That's why I don't use it. Link to comment Share on other sites More sharing options...
Slice Posted July 12, 2023 Share Posted July 12, 2023 3 hours ago, cankiulascmnfye said: @deeveedee @Slice Well, if you use Grep SMbus, you get all sorts of other matches as well, like VoodooSMBUS if you use a trackpad… 58 4 0xffffff8002f68000 0xffe 0xffe com.apple.iokit.IOSMBusFamily (1.1) 02901024-7468-311C-98A7-896350D03A80 <7 6 3> 91 1 0xffffff8004e58000 0x18000 0x18000 de.leo-labs.VoodooSMBus (3.0) C7EA611A-7A6E-3210-800F-79585B09468C <17 7 6 3> 94 0 0xffffff8004e70000 0xf000 0xf000 com.1Revenger1.RMISMBus (1.0) 1C98C210-E89C-33DF-9DD7-36058B9AB6AC <93 91 16 7 6 3> 146 1 0xffffff7f9589d000 0x6ffd 0x6ffd com.apple.driver.AppleSMBusController (1.0.18d1) 18305D5D-1310-37BC-B654-6C034FD346E7 <58 17 16 7 6 3> That's why I don't use it. So, there are some influence on SMBus from third party drivers in your case. I have Z170 Password: Executing: /usr/bin/kmutil showloaded No variant specified, falling back to release 64 2 0xffffff8002f68000 0xffe 0xffe com.apple.iokit.IOSMBusFamily (1.1) 02901024-7468-311C-98A7-896350D03A80 <7 6 3> 108 1 0xffffff7f9589d000 0x6ffd 0x6ffd com.apple.driver.AppleSMBusController (1.0.18d1) 18305D5D-1310-37BC-B654-6C034FD346E7 <64 17 16 7 6 3> 145 0 0xffffff7f958a9000 0x1000 0x1000 com.apple.driver.AppleSMBusPCI (1.0.14d1) 3B3CBC6F-07BD-3D7E-9F2F-D738A31C290D <17 7 6 3> sergey@iMac CloverBootloader % Link to comment Share on other sites More sharing options...
Max.1974 Posted July 13, 2023 Share Posted July 13, 2023 Where is good to go? 😁 Link to comment Share on other sites More sharing options...
mnfesq Posted July 14, 2023 Share Posted July 14, 2023 I have a general question that is not exclusively related to OC but here goes: I am trying to completely disable SIP. I am using the csr-active-config FF0F0000. When I run csrutil status, I get this: mnfesq@HPEnvy17 ~ % csrutil status System Integrity Protection status: unknown (Custom Configuration). Configuration: Apple Internal: disabled Kext Signing: disabled Filesystem Protections: disabled Debugging Restrictions: disabled DTrace Restrictions: disabled NVRAM Protections: disabled BaseSystem Verification: disabled This is an unsupported configuration, likely to break in the future and leave your machine in an unknown state. This "custom configuration" appears to me to disable all of SIP's functions but I cannot get csrutil to recognize SIP as disabled. Is there a different csr-active-config I can use that makes that happen? Am I better off using csr-active-config 00000000 and then disabling SIP in recovery mode like Mac users do? Suggestions appreciated. Link to comment Share on other sites More sharing options...
Slice Posted July 15, 2023 Share Posted July 15, 2023 Why not "csrutil disable"? 1 Link to comment Share on other sites More sharing options...
deeveedee Posted July 15, 2023 Share Posted July 15, 2023 (edited) 21 hours ago, mnfesq said: When I run csrutil status, I get this: This is an unsupported configuration This explains why you get an "unknown" status when you use csrutil to query SIP status. Edited July 15, 2023 by deeveedee Link to comment Share on other sites More sharing options...
STLVNUB Posted July 15, 2023 Share Posted July 15, 2023 (edited) Well I Finally Found An EFI Folder That Works 😃 GoodBye Clover, It's Been A Wild Ride 😇 Boy Is OC Fast, Good Job Developers Edited July 15, 2023 by STLVNUB 3 Link to comment Share on other sites More sharing options...
mnfesq Posted July 15, 2023 Share Posted July 15, 2023 (edited) 8 hours ago, deeveedee said: This explains why you get an "unknown" status when you use csrutil to query SIP status. I finally found the csr-active-config that disables SIP completely. Thank you @miliuco. Edited July 15, 2023 by mnfesq Link to comment Share on other sites More sharing options...
pananning Posted July 19, 2023 Share Posted July 19, 2023 Hi all, in the second stage of booting, it gets stuck at about halfway down the progress bar for 3 to 4 minutes, guessing that the SATA mechanical hard disk is causing the problem, how do I shield the SATA mechanical hard disk? Link to comment Share on other sites More sharing options...
cankiulascmnfye Posted July 19, 2023 Share Posted July 19, 2023 Quote OC Releases is behind schedule pretty hard this month (Official Release It's still on 0.9.3). Usually, the next milestone should is released the first Tuesday of any given month, iirc. 1 Link to comment Share on other sites More sharing options...
Stefanalmare Posted July 19, 2023 Share Posted July 19, 2023 6 hours ago, pananning said: Hi all, in the second stage of booting, it gets stuck at about halfway down the progress bar for 3 to 4 minutes, guessing that the SATA mechanical hard disk is causing the problem, how do I shield the SATA mechanical hard disk? If you think that the culprit is SATA HDD, unplug the power or/and SATA cable on it during the installation. 1 Link to comment Share on other sites More sharing options...
eSaF Posted July 19, 2023 Share Posted July 19, 2023 7 hours ago, pananning said: guessing that the SATA mechanical hard disk is causing the problem, Are we still using mechanical hard drives!!!!???? As @Stefanalmare suggested, isolate by unplugging the Sata Cable to that Drive and you should be fine unless that is the drive you're trying the installation on. If that is the case then you're in for a hard time. Link to comment Share on other sites More sharing options...
