marlboro Lights Posted December 23, 2006 Share Posted December 23, 2006 the ALC888 PACKAGE WORKS on my GA-965P-DQ6 motherboard with ICH8 and ALC888 i have one output line and 2 input line : microphone and line in not 6.1 support Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-260444 Share on other sites More sharing options...
skippyretard Posted December 23, 2006 Author Share Posted December 23, 2006 I am happy to hear it works for so many people! The volume does not work for me either when using aggregate device, I do not know if that is normal. Laptops sometime have low volume because the line out is not amplified to the internal speakers. My new mobo was delivered yesterday and I am sad to say the ALC883 does not work on the MSI 945GM3-F. This makes me think I was correct about sound not working on mobo's that do not have a SPDIF_In. If I can get it to work it may be good news for those with ICH7 and ALC888 because I think they have the same problem. Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-260468 Share on other sites More sharing options...
meattattat Posted December 24, 2006 Share Posted December 24, 2006 sad to hear ALC888 with ICH7 still speachless... anyway, keep going guys! Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-260828 Share on other sites More sharing options...
Orionn Posted December 24, 2006 Share Posted December 24, 2006 ZOleg: There is a great kext for ALC882 users made by Taruga HERE TorqueX86: Thank you... I am working on an ALC888 kext right now, it should be posted sometime today. I can not be sure it will work on ICH7, so please test and post your results when it is ready. Orionn: You must use the 8.8.1 kernel for the ALC883Audio.pkg to work Ok, Thanks.... I´m just downloadind the update kernel.... I have obtained so far that my wireless intel card is detected, but does not manage to form it and they give failures me of kernel… if with the 8.8.1 with himself to solve I create it advanced enough… Thanks... Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-260887 Share on other sites More sharing options...
rewtninja Posted December 24, 2006 Share Posted December 24, 2006 Some progress with the new Azaliadriver after adding the id of my SigmaTel STAC7661 (onboard on Sony Vaio FE21M laptop), i now get an output device . No sound yet tho and it isnt visible in the system profiler but a step in the right direction. Thanks for all job sofar Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-261119 Share on other sites More sharing options...
looper Posted December 24, 2006 Share Posted December 24, 2006 (edited) Hi guys, I've got an intel GNTLKR Mobo with Sigmatel 9220 / ICH7 Audio onboard. I've downloaded and run Skippy's Azalia Audio installer. As others have mentioned HD Audio Output shows up in the preferences pane and the menu bar slider works, just no sound. I removed Extensions.kextcache and Extensions.mkext, repaired permissions, rebooted, still nothing. I want to try editing the kext as Rammjet suggested, The first Info.plist still might need to be edited to change 0880 to your particular number and remove ApplHDA.kext from Extensions folder (and of course, delete the Extensions.*kext* files). but I'm not all that sure of what I should be editing. I've opened up the Azalia kext with plist pro and I'm looking at what's in the first Info.plist. edit: I found an older post here from Rammjet about editing vendor and device ID's- so looking at the Azalia kext I found this code: AppleAzaliaAudio.kext/Contents/Info.plist <key>IOHDAudioCodecVendorID</key> <string>0x10ecffff 0x14f1ffff 0x11d4ffff 0x434dffff 0x8384ffff</string> AppleAzaliaAudio.kext/Contents/PlugIns/AppleAzaliaController.kext/Contents/Info.plist <key>IOPCIPrimaryMatch</key> <string>0x26688086 0x27d88086 0x284b8086 0x32881106 0x026c10de 0x037110de 0x03e410de 0x03f010de 0x044a10de 0x044b10de 0x437b1002 0x43831002 0x75021039</string> how can these strings be edited to add the Sigmatel 9220 Vendor ID - 8384 and Device ID - 7680? If I'm on the right track let me know, if not I'll get back in the shallow end with the other nOObs. PS Happy Holidays everyone Edited December 25, 2006 by looper Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-261173 Share on other sites More sharing options...
tokra128 Posted December 25, 2006 Share Posted December 25, 2006 looper - I am on the same situation as you are ... so far .. it seem that we are stuck ... well, I still hope that it will be a light at the end of the tunnel ... Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-261340 Share on other sites More sharing options...
skippyretard Posted December 25, 2006 Author Share Posted December 25, 2006 looper: try replacing this <key>IOHDAudioCodecVendorID</key> <string>0x10ecffff 0x14f1ffff 0x11d4ffff 0x434dffff 0x8384ffff</string> with this <key>IOHDAudioCodecVendorID</key> <string>0x83847680</string> Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-261395 Share on other sites More sharing options...
Treso Posted December 25, 2006 Share Posted December 25, 2006 I have an ALC883 in my notebook but there's a problem, I use the semthex kernel with 10.4.8 and I installed the ALC883 drivers (azalia also has this prob). Well, the main problem is tht auio is not synchronised and sounds choppy. u can't notice it with iTunes or quicktime, but for example, Speakable items does not work at all, or Logic Pro is giving me a synchro error between Audio and Midi everytime. Anyone knows a fix? ;P Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-261397 Share on other sites More sharing options...
homer007 Posted December 25, 2006 Share Posted December 25, 2006 I have an ALC883 in my notebook but there's a problem, I use the semthex kernel with 10.4.8 and I installed the ALC883 drivers (azalia also has this prob). Well, the main problem is tht auio is not synchronised and sounds choppy. u can't notice it with iTunes or quicktime, but for example, Speakable items does not work at all, or Logic Pro is giving me a synchro error between Audio and Midi everytime. Anyone knows a fix? ;P m8 just upgrade to the latest beta kernel then ur sound will be fixed! Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-261423 Share on other sites More sharing options...
looper Posted December 25, 2006 Share Posted December 25, 2006 looper: try replacing this<key>IOHDAudioCodecVendorID</key> <string>0x10ecffff 0x14f1ffff 0x11d4ffff 0x434dffff 0x8384ffff</string> with this <key>IOHDAudioCodecVendorID</key> <string>0x83847680</string> O.K. I gave it a shot using your instructions, then got rid of the Extensions.kextcache and Extensions.mkext files, fixed permissions and restarted, still no sound. I noticed that the physical audio jacks are not "live"with this kext loaded. using my old (working) kext (from the Jas 10.4.8 DVD) when I unplug a jack from the audio port the volume slider automagically turns itself down to about halfway (to prevent damage to ones ears I suppose). But when this kext is loaded the menu bar slider doesn't respond to physically unplugging a cable. Just an observation. Out of curiosity am I to understand that the HD audio is utilizing 2 chips whereas the "regular" sound only uses one? Thanks for the help Skippy, keep up the good work we all appreciate it. cheers Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-261521 Share on other sites More sharing options...
elviejo Posted December 26, 2006 Share Posted December 26, 2006 Hi Skippy, I hope you have a Merry Christmas, using your Azalia pkg I got sound out no line in and full lever control for the first time with Azalia, but the withdraw is no multichannel and not line in, anyway is a step in the right direction. Keep the good work. ------------------------------------------------------------------------------------------------------------------------------------------------------------- Intel915gux mobo 2 Gig ddr2 memory 2.8 p4 Ghz ( appear as 3.06 in About this Mac ) QE/CI fully working Realtek HDA Audio ALC880, 10ec0880, working Audio out 2 channels stereo and line in without boost with AppleHDA.kext from 10.4.3 Everything else working 100% Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-261721 Share on other sites More sharing options...
Wisam Posted December 26, 2006 Share Posted December 26, 2006 Thanks Skippy. I tried ALC883 3,6 ports and ALC888 but didn't work on ALC888 ICH7 We are waiting for a miracle to come. Thanks for the work though Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-261923 Share on other sites More sharing options...
jsl Posted December 26, 2006 Share Posted December 26, 2006 No lucky for me with this AppleAzaliaAudio.kext. After modification of its plists to my ALC880 & Asus A6Jc Laptop (0x10ec0880 & 0x27d88086), still no any sound output in my JaS 10.4.6. Every procedures in this board had been followed (e.g. delete AppleHDA.kext, mkext, kextcache, repair permissions,etc.) Any help for me ? Thanks for evrybody here. Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-262014 Share on other sites More sharing options...
eyemac Posted December 26, 2006 Share Posted December 26, 2006 Skippyretard... I have used the ALC882 kext (Taruga) with success and also the AppleHDA kext from 10.4.5 modified for ALC880, but that kext does NOT supply SPDIF. Yours DOES (!) but doesn't seem to work with ALC880. Have you had any try at getting your kexts to work with the 'older' ALC880?? I would be glad to test for you on my ECS MB with ALC880. Also.. there is a newer board from MSI that is MoDT and has built in DVI (!) using the Intel GMA950 graphics engine that would seem to be a great board for a HTPC setup, but uses the ALC880 chipset -- it has SPDIF which would be nice for HTPC. Thanks again for your hard work! Steve Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-262303 Share on other sites More sharing options...
skippyretard Posted December 28, 2006 Author Share Posted December 28, 2006 Treso: I agree with homer007, the original kernel did not autodetect the FSB of the CPU and caused timing issues. Please try the latest kernel on IRC and let us know if it solved your problem. looper: The HD Audio uses a controller and a codec, the controller is built-in to the southbridge. If I get some time I may try to fix the azalia kext, but my priority is the AppleHDA.kext for now. eyemac: did you edit Taruga's kext? or did it work as is? also, do they both provide output AND input? Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-263548 Share on other sites More sharing options...
aberracus Posted December 28, 2006 Share Posted December 28, 2006 Skippy FYI, i have tried your installer and i now have line in line out an d mic all working, but to make it working i had to install alc883 ich7 with 3 channels + digital i do not have a digital ot port but its supported in an addtional bracket.... BTW i have tried with the agregate using Line out + line in + mic but no 5.1 im doing something wrong? Apple HDA sound MUCH BETTER than Azalia Thanks! Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-263565 Share on other sites More sharing options...
eyemac Posted December 28, 2006 Share Posted December 28, 2006 Skippy.. I tried to edit Taruga's kext (ALC882) by changing the vender and device ID's according to previous instructions to do so on this forum (and the same vender id code additions that got my 10.4.5 AppleHDA kext working. . However, with that mod, I got nothing at all.. ie the kext did not load and there was no line in or out. I did not have the Azalia kext in the extensions folder with the AppleHDA kext as I had found the in order to get AppleHDA.kext working (10.4.5 native moded for ALC880), Azalia kext had to be removed. THAT mod, DID work, and provided Line In and Line out. I am using it currently. However, it did NOT provide SPDIF even though my MB supports both SPDIF In and Out. I thought I might be able to get SPDIF working using the udated kext (Taruga), but was unsuccessful. Have you had any success using YOUR ALC883 kext with ALC880 with SPDIF as well? If a mod was needed can you explain what you did to get ALC880 working with your ALC883? eyemac (steve) Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-263599 Share on other sites More sharing options...
skippyretard Posted December 28, 2006 Author Share Posted December 28, 2006 eyemac: I understand now, I am a little slow today. If you attach the kext that works for you, I will try to get the SPDIF working. Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-263752 Share on other sites More sharing options...
asstastic Posted December 30, 2006 Share Posted December 30, 2006 skippy, the 3 port 883 patch works for my acer 5672 laptop using ich7m. The internal mic is detected and i have no way to test the line in or external mic. this is the good news. bad news is the headphone jack still doesn't work and the sound randomly drops out on me for no apparent reason and refuses to work untill i reboot; just like it did when i was using an edited appleazalia. unless other people are reporting these sorts of problems as well i'm convinced this is merely my laptop being a buggy p.o.s. and not an error in your wonderfull hack. cheers and happy holidays. -ass Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-264941 Share on other sites More sharing options...
Blamazs Posted December 31, 2006 Share Posted December 31, 2006 Hi! Sorry, i don't speak english. Asrock 775i945GZ motherboard ICH7 Setup AzaliaAudio.pkg Sound working, Front speaker line, but MIC in not working! I have mic in for skype,ichat. Please help me! Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-265442 Share on other sites More sharing options...
homer007 Posted January 1, 2007 Share Posted January 1, 2007 skippy, the 3 port 883 patch works for my acer 5672 laptop using ich7m. The internal mic is detected and i have no way to test the line in or external mic. this is the good news. bad news is the headphone jack still doesn't work and the sound randomly drops out on me for no apparent reason and refuses to work untill i reboot; just like it did when i was using an edited appleazalia. unless other people are reporting these sorts of problems as well i'm convinced this is merely my laptop being a buggy p.o.s. and not an error in your wonderfull hack. cheers and happy holidays. -ass m8 didnt u read my post before just upgrade to the latest kernel and ur sound will be fixed. Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-266248 Share on other sites More sharing options...
Prawker Posted January 2, 2007 Share Posted January 2, 2007 THANK YOU SOOOO MUCH FOR THIS, I HAVE BEEN TRYING TO GET MY AUDIO INPUT WORKING FOR EVER AND THIS FINALLY DID THE TRICK!! Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-266414 Share on other sites More sharing options...
jsl Posted January 2, 2007 Share Posted January 2, 2007 (edited) My audio problems are solved now. 1. Remove -x (safe boot) from my com.apple.Boot.plist 2. Using AppleHDA.kext (1.1.0a17) and remove AppleAzaliaAudio.kext 3. Set correct parameters: 0x10ec0880 0x27d88086 in AppleHDA.kext 4. verify it by kextload -t 5. After reboot I can use Mic In and Stereo Out from my ALC880 in laptop Asus A6JC Another incomplete solution: 1. Remove -x (safe boot) from my com.apple.Boot.plist 2. Using AppleAzaliaAudio.kext(1.0.0d0) and remove AppleHDA.kext 3. Set correct parameters: 0x10ec0880 0x27d88086 in AppleAzaliaAudio.kext 4. verify it by kextload -t 5. After reboot I can get Stereo Out without Mic In from my ALC880 in laptop Asus A6JC My solution is different from others and I think it's due to my Hac OS is 10.4.6/8.4.1 instead of 10.4.8/8.8.1 Edited January 3, 2007 by jsl Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-266468 Share on other sites More sharing options...
skippyretard Posted January 2, 2007 Author Share Posted January 2, 2007 jsl: can you post the applehda.kext that is working for you? I would like to take a look at it. Link to comment https://www.insanelymac.com/forum/topic/36520-alc88x-1048-kext/page/2/#findComment-266545 Share on other sites More sharing options...
