pepitillo Posted June 11, 2017 Share Posted June 11, 2017 Hello there, I know that is too early to ask this, but I wonder if someone has the HD530 working under HighSierra. I have a kernel panic when booting with latest Lilu and IntelGraphicsFixUp, with beta flags, and using the same config working under Sierra. Thanks Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/ Share on other sites More sharing options...
Cyberdevs Posted June 11, 2017 Share Posted June 11, 2017 Hi, Yes you can get the IntelHD530 to work. see here : post #282 and post #284 post #286 But for me the only way that I can get it to work so far is to remove the nVidia GPU from the system completely. Thanks to @vandroiy2012 1 Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2442143 Share on other sites More sharing options...
pepitillo Posted June 11, 2017 Author Share Posted June 11, 2017 The NVIDIA card might be the problem. Thanks! Enviado desde mi GT-I9195 mediante Tapatalk Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2442180 Share on other sites More sharing options...
Cyberdevs Posted June 11, 2017 Share Posted June 11, 2017 You need to test it to make sure it wasn't working on my rig because of the 1070, you might have more luck than I do Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2442186 Share on other sites More sharing options...
Slice Posted July 8, 2017 Share Posted July 8, 2017 Hello there, I know that is too early to ask this, but I wonder if someone has the HD530 working under HighSierra. I have a kernel panic when booting with latest Lilu and IntelGraphicsFixUp, with beta flags, and using the same config working under Sierra. Thanks It works without lilu & igfx. See my signature. Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2458978 Share on other sites More sharing options...
telepati Posted July 9, 2017 Share Posted July 9, 2017 It works without lilu & igfx. See my signature. How its works without lilu & igfx, are you saying working as a native? Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2459098 Share on other sites More sharing options...
Slice Posted July 10, 2017 Share Posted July 10, 2017 Yes, it works as a native. Just exclude any injection for it. 3 Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2459840 Share on other sites More sharing options...
SavageAUS Posted July 23, 2017 Share Posted July 23, 2017 I just tried to test my HD530 on my Skylake build for the first time but i cannot boot into macOS, yes my Nvidia card was still installed and i believe thats the culprit. Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467697 Share on other sites More sharing options...
Cyberdevs Posted July 23, 2017 Share Posted July 23, 2017 I just tried to test my HD530 on my Skylake build for the first time but i cannot boot into macOS, yes my Nvidia card was still installed and i believe thats the culprit. on macOS Sierra the HD530 and nVidia can work together but I never could get those to work in High Sierra. Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467729 Share on other sites More sharing options...
SavageAUS Posted July 23, 2017 Share Posted July 23, 2017 on macOS Sierra the HD530 and nVidia can work together but I never could get those to work in High Sierra.Strange. I tried in Sierra and with iGPU as primary in bios it won't boot.What patches etc do I need? Sent from my SM-G930F using Tapatalk Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467739 Share on other sites More sharing options...
Cyberdevs Posted July 23, 2017 Share Posted July 23, 2017 Strange. I tried in Sierra and with iGPU as primary in bios it won't boot. What patches etc do I need? Sent from my SM-G930F using Tapatalk change GFX0 to IGPU and change HECI to IMEI and also inject intel = true with the 0x19120000 ig-platfrom-id Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467742 Share on other sites More sharing options...
SavageAUS Posted July 23, 2017 Share Posted July 23, 2017 change GFX0 to IGPU and change HECI to IMEI and also inject intel = true with the 0x19120000 ig-platfrom-idOk I'll give that a try soon. It so t effect the Nvidia card yeah? Can leave webdrivers enabled? Sent from my SM-G930F using Tapatalk Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467748 Share on other sites More sharing options...
Cyberdevs Posted July 23, 2017 Share Posted July 23, 2017 Ok I'll give that a try soon. It so t effect the Nvidia card yeah? Can leave webdrivers enabled? Sent from my SM-G930F using Tapatalk Yes leave all the nVidia related setting as if it's the only card that you are using. Let me know how it goes. In the meanwhile I'll search for my working config for Intel and nVidia and I will send it to you. Don't forget the IntelGraphicsFixup.kext. Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467753 Share on other sites More sharing options...
SavageAUS Posted July 23, 2017 Share Posted July 23, 2017 Yes leave all the nVidia related setting as if it's the only card that you are using. Let me know how it goes. In the meanwhile I'll search for my working config for Intel and nVidia and I will send it to you. Don't forget the IntelGraphicsFixup.kext. Those additions above resulted in a kernel panic. Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467760 Share on other sites More sharing options...
Cyberdevs Posted July 23, 2017 Share Posted July 23, 2017 Ok let me see if I can find the EFI folder that I used on dual GPU and double check the settings. Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467765 Share on other sites More sharing options...
SavageAUS Posted July 23, 2017 Share Posted July 23, 2017 Ok let me see if I can find the EFI folder that I used on dual GPU and double check the settings. DVMT Pre-Alloc 64M DVMT Total 256M Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467768 Share on other sites More sharing options...
Cyberdevs Posted July 23, 2017 Share Posted July 23, 2017 DVMT Pre-Alloc 64M DVMT Total 256M Yes but you can try with Pre-Alloc set to 128 MB. some times it helps to get rid of the KP. Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467777 Share on other sites More sharing options...
SavageAUS Posted July 23, 2017 Share Posted July 23, 2017 Yes but you can try with Pre-Alloc set to 128 MB. some times it helps to get rid of the KP. Kernel panic with 96 and 128. Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467780 Share on other sites More sharing options...
Cyberdevs Posted July 23, 2017 Share Posted July 23, 2017 I can boot normally with this config. Although I have no display on the TV that is connected to my intel gpu but no KP here. I have another file which has output ok on the tv but I haven't found it yet. Kernel panic with 96 and 128. I found it I have 3 displays working with this EFI folder. config.plist.zip nVidia and HD530 working on macOS Sierra Z170X-Gaming 5.zip Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467783 Share on other sites More sharing options...
SavageAUS Posted July 23, 2017 Share Posted July 23, 2017 I can boot normally with this config. Although I have no display on the TV that is connected to my intel gpu but no KP here. I have another file which has output ok on the tv but I haven't found it yet. I found it I have 3 displays working with this EFI folder. With the first one I got kp still not tested new ones yet, it's not a big deal as I have the Nvidia card but would always be nice to know if the Nvidia card ever fails I've got a fall back. Sent from my SM-G930F using Tapatalk Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467786 Share on other sites More sharing options...
Cyberdevs Posted July 23, 2017 Share Posted July 23, 2017 With the first one I got kp still not tested new ones yet, it's not a big deal as I have the Nvidia card but would always be nice to know if the Nvidia card ever fails I've got a fall back. Sent from my SM-G930F using Tapatalk Well both of them work on my end. I'm not sure why you get the KP. but if it works on my setup it should have work on yours as well because we almost have the same setup. BUT as I mentioned before it's not working with High Sierra and I haven't started to use High Sierra on my SkyLake yet so maybe later I'll give it another try and see if I can find a way to get them to work together. Let me know how the EFI folder worked out if you tested it. Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467789 Share on other sites More sharing options...
SavageAUS Posted July 23, 2017 Share Posted July 23, 2017 Well both of them work on my end. I'm not sure why you get the KP. but if it works on my setup it should have work on yours as well because we almost have the same setup. BUT as I mentioned before it's not working with High Sierra and I haven't started to use High Sierra on my SkyLake yet so maybe later I'll give it another try and see if I can find a way to get them to work together. Let me know how the EFI folder worked out if you tested it. I didn't use your efi folder just the config.plist details. Even with that I still get kp. I'll attach my config.plist soon (feeding son). config.plist.zip Sent from my SM-G930F using Tapatalk Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467795 Share on other sites More sharing options...
Cyberdevs Posted July 23, 2017 Share Posted July 23, 2017 I didn't use your efi folder just the config.plist details. Even with that I still get kp. I'll attach my config.plist soon (feeding son). Sent from my SM-G930F using Tapatalk Oh, my goodness Oki doki, I have to go out of several hours and we will continue troubleshooting the issue when I get back. Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2467798 Share on other sites More sharing options...
Cyberdevs Posted July 31, 2017 Share Posted July 31, 2017 I didn't use your efi folder just the config.plist details. Even with that I still get kp. I'll attach my config.plist soon (feeding son). config.plist.zip Sent from my SM-G930F using Tapatalk Sorry totally forgot about posting the results. I tried your config.plist no KP but macOS High Sierra can't boot it hangs on AppleACPICPU.kext kext stall error or sth like that. Link to comment https://www.insanelymac.com/forum/topic/324383-question-intel-hd-530-high-sierra-support/#findComment-2472226 Share on other sites More sharing options...
