AudioGod's Aorus Z390 Pro Patched DSDT Mini Guide and Discussion

AudioGod

By AudioGod,
in Installation Guides

 Share
5,862 posts in this topic

Recommended Posts

hackinhacker
hackinhacker
Posted
Posted (edited)

Anyone know where I can change the resolution of the OC booter?  I confirmed that it is set to MAX but every time I boot big-o size of the disk shows up middle of the screen and it is annoying.  I was wondering if anyone can help where/how I can change the disk size and disk label.



thanks

Edited by hackinhacker
Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted (edited)
8 hours ago, hackinhacker said:

Anyone know where I can change the resolution of the OC booter?  I confirmed that it is set to MAX but every time I boot big-o size of the disk shows up middle of the screen and it is annoying.  I was wondering if anyone can help where/how I can change the disk size and disk label.



thanks


Make sure the following is set in the bios

Boot -> Windows 8/10 Features -> Win 8/10 WHQL



Then in the Config.plist goto

UEFI -> Output -> Resolution

And set it to your desired Res instead of Max

Edited by AudioGod
  • Like 3
Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted
1 minute ago, WizeMan said:

Happy new year awesome people of this thread!

Happy new year to you too bro,

And a happy new year to everybody else.

Fingers crossed life will get back to some kind of normal and we can put this crappy 2020 behind us all.

Big Love Everybody. :)

  • Like 7
Link to comment
Share on other sites
kiko89
kiko89
Posted
Posted
On 12/30/2020 at 1:38 PM, AudioGod said:

So the other week I got totally sick of the crappy range that my native WiFi / Bluetooth card was giving., it wasn’t too bad but it wasn’t great so I went onto good old Amazon and ordered a replacement antenna and oh my word what a difference it makes.

Before range was limited to a few metres and super directional so if I was say on my couch using the hack via my 75inch Samsung QLED sickness I would find my Bluetooth keyboard, mouse, Xbox controller and AirPod pros would be choppy and yucky but now with the replacement antenna setup so you can’t see it but it’s about 2 meters up from the floor I now can not make the Bluetooth signal fail. I can even go into other rooms in my house and everything still works perfectly. Best Bluetooth and WiFi connection I’ve seen in my house ever. I can’t recommend replacing the cheap crappy aerials that they supply with a pcie adaptor or the fenvi range enough, infact I would say it should be replaced as standard. (that’s how big the difference is)



This is the one to get, I’m sure there are others that work just as well but this one is tried tested and working way beyond what I expected.



Eightwood External Wifi Antenna 2.4G / 5.8G Dual Frequency Magnetic Base 6dBi with RP-SMA Adapter Extension Cable 2m Compatible for Wifi Camera Wifi Card WLAN PCI Cards Wirelesse Wifi Router Bluetooth
by RFSolution
Learn more:https://www.amazon.co.uk/dp/B078X55HSD/ref=cm_sw_em_r_mt_dp_6dh7FbX4VAVGK?_encoding=UTF8&psc=1

Hi dear,

i have fenvi t919 and I want to increase my Bluetooth signal.

i have 4 antenna and I don't know which is bluetooth antenna.

Can you help me?



Thank you

Link to comment
Share on other sites
laxattack
laxattack
Posted
Posted
On 11/15/2020 at 7:57 PM, AudioGod said:


Make sure he’s using the latest OpenCore EFI on the thread, Clover doesn’t work as I haven’t updated it and the Clover Crew are still trying to make it work properly with BigSur.

Just a heads up, it turns out his Corsair Commander Pro, caused all of his issues :-(

Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted (edited)

OpenCore 0.6.5 EFI Update (Big Sur Ready), 4th January 2021

(Use With Bios Revision F12K or Newer)



The EFIs and DSDTs have now been updated to the my latest versions.

Changes made include,

AppleALC 1.5.6,

WhateverGreen 1.4.6,

IntelMausi 1.0.5,

OpenCore Updated to Revision 0.6.5 (Big Sur 11,1 Ready),

OpenCanopy is Enabled as Standard,

New OpenCanopy Icons,

Plus other minor tweaks and changes to all of the configs.



OpenCore EFI Update v0.6.5 - 04/01/2021

OC 065 19,1 Z390 Pro EFI 040121.zip - OpenCore v0.6.5, SMBios iMac19,1

OC 065 020121 1,1 Z390 Pro 040121.zip - OpenCore v0.6.5, SMBios iMacPro1,1 (IGPU Disabled)


PLEASE DON’T FORGET TO RESET YOUR NVRAM BEFORE BOOTING INTO THE NEW EFI FOR THE FIRST TIME,



Note - If your not using a 5700 XT or any other Navi GPU then remove agdpmod=pikera from the boot arguments.

Note 2 - Do not try to carry across your old OpenCore Config.plist to the new EFI as to many changes have occurred in 0.6.0. Use the new Config.plist instead.



For OpenCore Using PlistEdit Pro add your details by modifying the following

453128831_Screenshot2020-01-16at19_25_01.thumb.png.7a9beac3ccc0096941fc4a0ec07b8248.png



PLEASE NOTE - These EFIs are setup to be used with your msr Unlocked so make sure you use the correct bios settings listed below or use the F12K Unlocked Profile I have provided.



Additional Downloads

mb_bios_z390-aorus-pro_f12k.zip - Aorus Z390 Pro Bios Firmware F112K

mb_bios_z390-aorus-pro-wifi_f12j.zip - Aorus Z390 Pro Wifi Bios Firmware F112J

PlistEdit Pro.zip - PlistEdit Pro (use to edit OpenCore)


PLEASE NOTE - MSR Unlock is now baked into the BIOS as a setting so you no longer need my bios profile to unlock your MSR.



Bios Update F12K (F12J Pro Wifi) and Bios Settings


PLEASE NOTE - MSR Unlock is now baked into the BIOS as a setting so you no longer need my bios profile to unlock your MSR.



BIOS SETTINGS (Bios Revision F12k & F12j Pro Wifi)



• Enter BIOS -> Press Delete -> Enter Setup

• Save & Exit -> Load Optimized Defaults

• Boot -> CFG Lock -> Disabled

• Boot -> Windows 8/10 Features -> Win 8/10 WHQL

• Boot -> CSM Support -> Disabled (Can be set to Enabled if need be but try to have it set to Disabled first)

• Favourites -> Extreme Memory Profile (X.M.P.) -> Profile1

• Favourites -> VT-d -> Disabled (Can be set to Enabled or Disabled, Your choice)

• Settings -> IO Ports -> Internal Display Output -> PCIe 1 Slot

• Settings -> IO Ports -> Internal Graphics -> Enabled (Disabled If Using SMBios 1,1)

• Settings -> IO Ports -> DVMT Pre-Allocated -> 64M

• Settings -> IO Ports -> DVMT Total GFX0-Allocated -> 256M

• Settings -> IO Ports -> Aperture Size -> 256MB
• Settings -> IO Ports -> Wifi -> Disabled (Z390 Pro Wifi Only)

• Settings -> IO Ports -> Audio Controller -> Enabled

• Settings -> IO Ports -> Above 4G Decoding -> Enabled

• Settings -> IO Ports -> USB Configuration -> Legacy USB Support -> Auto

• Settings -> IO Ports -> USB Configuration -> XHCI Hands-off -> Enabled

• Settings -> Miscellaneous -> Software Guard Extensions (SGX) -> Disabled

• Settings -> Platform Power -> Platform Power Management -> Enabled

• Settings -> Platform Power -> ErP -> Enabled

• Settings -> Platform Power -> RC6(Render Standby) -> Enabled

• Save & Exit → Save & Exit Setup



F12K BIOS Profile With MSR Unlocked & All The Correct Settings Dialled in for you - The Easy Way

@texem has made this bios profile for you all to use that will unlock CFG on your motherboard making it play alot more friendly with the NVRam.

It also has all the bios settings listed on this guide pre done and saved onto the profile.



Z390 PRO BIOS PROFILE - F12k.zip - Use with Z390 PRO Bios Revision F12K ONLY

Z390 PRO WIFI BIOS PROFILE - F12J.zip - Use with Z390 PRO WIFI Bios Revision F12J ONLY (Coming Soon)



1 - Download the profile and save it to a USB Key

2 - Go into the bios,

3 - Load the profile,

4 - Save and exit

5 - Go straight back into the bios and save your bios to a new profile and name it Default or something like that.

6 - Save the changes and then restart and your done, your motherboard will now be CFG (MSR) Unlocked and all the correct settings will be dialled in for you.

Edited by AudioGod
  • Like 4
  • Thanks 3
Link to comment
Share on other sites
rob1980
rob1980
Posted
Posted
On 12/31/2020 at 2:51 PM, hackinhacker said:

Anyone know where I can change the resolution of the OC booter?  I confirmed that it is set to MAX but every time I boot big-o size of the disk shows up middle of the screen and it is annoying.  I was wondering if anyone can help where/how I can change the disk size and disk label.



thanks

Can you let me know if you get this sorted please.



Even after setting a custom resolution my boot up Logo's are Huge and Fugly As lol...   Ive tried Max, 3440x1440 and as low as 1024... Max sets it to where I have it now, anything else makes it even bigger!,,.. this only happened in the last couple of updates so I'm not sure what's changed?  bios settings confirmed correct also.



thanks

Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted
3 hours ago, rob1980 said:

Can you let me know if you get this sorted please.



Even after setting a custom resolution my boot up Logo's are Huge and Fugly As lol...   Ive tried Max, 3440x1440 and as low as 1024... Max sets it to where I have it now, anything else makes it even bigger!,,.. this only happened in the last couple of updates so I'm not sure what's changed?  bios settings confirmed correct also.



thanks


in the bios set,

• Boot -> Windows 8/10 Features -> Win 8/10 WHQL

Link to comment
Share on other sites
panosru
panosru
Posted
Posted

Anyone else has issues with wake from sleep? Currently running OC 0.6.4, I will upgrade now to OC 0.6.5.



$ pmset -g log | grep -e "Sleep.*due to" -e "Wake.*due to"

2020-12-29 23:17:50 +0200 Sleep               	Entering Sleep state due to 'Software Sleep pid=162': Using AC (Charge:0%)
2020-12-30 10:28:32 +0200 Wake                	Wake from Normal Sleep [CDNVA] : due to PWRB/User Using AC (Charge:0%)
2020-12-31 02:48:23 +0200 Sleep               	Entering Sleep state due to 'Software Sleep pid=162': Using AC (Charge:0%)
2020-12-31 10:54:36 +0200 DarkWake            	DarkWake from Normal Sleep [CDN] : due to XDCI CNVW/ Using AC (Charge:0%) 30 secs
2020-12-31 10:55:06 +0200 Wake                	DarkWake to FullWake from Normal Sleep [CDNVA] : due to UserActivity Assertion Using AC (Charge:0%)
2021-01-05 17:04:21 +0200 Sleep               	Entering Sleep state due to 'Software Sleep pid=161': Using AC (Charge:0%)
2021-01-05 17:05:51 +0200 Wake                	Wake from Normal Sleep [CDNVA] : due to XDCI CNVW/HID Activity Using AC (Charge:0%)
2021-01-05 17:19:38 +0200 Sleep               	Entering Sleep state due to 'Software Sleep pid=161': Using AC (Charge:0%)
2021-01-05 17:21:26 +0200 DarkWake            	DarkWake from Normal Sleep [CDN] : due to XDCI CNVW/ Using AC (Charge:0%) 45 secs
2021-01-05 17:22:11 +0200 Sleep               	Entering Sleep state due to 'Maintenance Sleep': Using AC (Charge:0%)
2021-01-05 17:24:15 +0200 Wake                	Wake from Normal Sleep [CDNVA] : due to XDCI CNVW/UserActivity Assertion Using AC (Charge:0%)

Wake on network is disabled in BIOS, also autopoweroff, powernap, standby and proximitywake are all set to 0. Configuration of OC hasn't been altered by me, it is like AudioGod's in 0.6.4 post.



I'm not sure where else I should check :/



Thanks!

Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted (edited)
15 minutes ago, panosru said:

Anyone else has issues with wake from sleep? Currently running OC 0.6.4, I will upgrade now to OC 0.6.5.






$ pmset -g log | grep -e "Sleep.*due to" -e "Wake.*due to"

2020-12-29 23:17:50 +0200 Sleep               	Entering Sleep state due to 'Software Sleep pid=162': Using AC (Charge:0%)
2020-12-30 10:28:32 +0200 Wake                	Wake from Normal Sleep [CDNVA] : due to PWRB/User Using AC (Charge:0%)
2020-12-31 02:48:23 +0200 Sleep               	Entering Sleep state due to 'Software Sleep pid=162': Using AC (Charge:0%)
2020-12-31 10:54:36 +0200 DarkWake            	DarkWake from Normal Sleep [CDN] : due to XDCI CNVW/ Using AC (Charge:0%) 30 secs
2020-12-31 10:55:06 +0200 Wake                	DarkWake to FullWake from Normal Sleep [CDNVA] : due to UserActivity Assertion Using AC (Charge:0%)
2021-01-05 17:04:21 +0200 Sleep               	Entering Sleep state due to 'Software Sleep pid=161': Using AC (Charge:0%)
2021-01-05 17:05:51 +0200 Wake                	Wake from Normal Sleep [CDNVA] : due to XDCI CNVW/HID Activity Using AC (Charge:0%)
2021-01-05 17:19:38 +0200 Sleep               	Entering Sleep state due to 'Software Sleep pid=161': Using AC (Charge:0%)
2021-01-05 17:21:26 +0200 DarkWake            	DarkWake from Normal Sleep [CDN] : due to XDCI CNVW/ Using AC (Charge:0%) 45 secs
2021-01-05 17:22:11 +0200 Sleep               	Entering Sleep state due to 'Maintenance Sleep': Using AC (Charge:0%)
2021-01-05 17:24:15 +0200 Wake                	Wake from Normal Sleep [CDNVA] : due to XDCI CNVW/UserActivity Assertion Using AC (Charge:0%)

Wake on network is disabled in BIOS, also autopoweroff, powernap, standby and proximitywake are all set to 0. Configuration of OC hasn't been altered by me, it is like AudioGod's in 0.6.4 post.



I'm not sure where else I should check :/



Thanks!

Clear out then Rebuild your cache bother (hackintool can do it all in one click)

Edited by AudioGod
Link to comment
Share on other sites
eSaF
eSaF
Posted
Posted
21 minutes ago, AudioGod said:

Clear out then Rebuild your cache bother (hackintool can do it all in one click)

B  - I am sure that feature in Hackintool no longer work in BS because of the Seal Volume but maybe still works in Catalina.

  • Like 1
Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted (edited)
20 minutes ago, panosru said:

Thanks mate! I forgot about that! I just rebuild kextcache from hackintool utilities and I'll see how it goes..

Clear your nvram out straight after while your at it. :thumbsup_anim:


2 minutes ago, eSaF said:

B  - I am sure that feature in Hackintool no longer work in BS because of the Seal Volume but maybe still works in Catalina.

That’s a point...lol..what about with SIP disabled?

you can still clear your cache manually or via many a app on the App Store though. :thumbsup_anim:

Edited by AudioGod
  • Like 1
  • Thanks 1
Link to comment
Share on other sites
eSaF
eSaF
Posted
Posted

Well I must be doing something wrong because this is the result I get when I run Hackintool even with GateKeeper unlocked, although I haven't checked SIP as I always have that fully enabled. I will have to check again and see.

Spoiler

806396602_ScreenShot2021-01-05at16_45_07.thumb.png.b7e9b13d347fd1b4648021b6009134fe.png



  • Like 1
Link to comment
Share on other sites
panosru
panosru
Posted
Posted (edited)

@eSaF I re-run it:



1927359803_Screenshot2021-01-05at19_04_02.thumb.png.cf82d125d869cf5ac4443b05edabf093.png



Finder closes and opens again, then:



1300072221_Screenshot2021-01-05at19_04_17.thumb.png.7fcf9da5d1e53c4d17d42ddc795bba66.png



Sleep now seems to be working again :)

Edited by panosru
  • Like 1
Link to comment
Share on other sites
eSaF
eSaF
Posted
Posted

@panosru I got the same result as you (see pic) by disabling SIP and cleaning NVRAM but I still maintain Hackintool is not working like before but I am willing to be proven wrong. Do this test in Hackintool/Utilities/GetAppleIntelinfo (see pic) and prove me wrong if any info comes up, if it does, it means you've removed/unsealed BS data volume.

Spoiler

847921325_ScreenShot2021-01-05at17_40_58.thumb.png.bab0fe0e69e2db7eabdefe18f39aafa3.png965701378_ScreenShot2021-01-05at17_44_06.thumb.png.29cf874c0d02eaafdec2ee8f9f74fb01.png

Test is opened to anyone else.

Link to comment
Share on other sites
AudioGod
AudioGod
Posted
  • Author
Posted (edited)
6 minutes ago, eSaF said:

@panosru I got the same result as you (see pic) by disabling SIP and cleaning NVRAM but I still maintain Hackintool is not working like before but I am willing to be proven wrong. Do this test in Hackintool/Utilities/GetAppleIntelinfo (see pic) and prove me wrong if any info comes up, if it does, it means you've removed/unsealed BS data volume.

  Hide contents

847921325_ScreenShot2021-01-05at17_40_58.thumb.png.bab0fe0e69e2db7eabdefe18f39aafa3.png965701378_ScreenShot2021-01-05at17_44_06.thumb.png.29cf874c0d02eaafdec2ee8f9f74fb01.png

Test is opened to anyone else.


@eSaF Works for me buddy with SIP fully enabled. You sure your using the latest version of hackintool over there my friend?

Edited by AudioGod
Link to comment
Share on other sites
panosru
panosru
Posted
Posted (edited)

Actually AppleIntelInfo also not working for me. It asks me to restart to enable the extension, I restart, but then after I restarted it tries to re-install it again and asks for restart again.. strange. SIP for me is disabled.

Edited by panosru
Link to comment
Share on other sites
eSaF
eSaF
Posted
Posted
1 minute ago, AudioGod said:

You sure your using the latest version of hackintool over there my friend?

Ver:3.4.9 ? - I did check and it said it is  the latest - What am I missing?

1 minute ago, panosru said:

Actually AppleIntelInfo also not works for me. It asks me to restart to enable the extension, I restart, but then after I restarted it tries to re-install it again and asks for restart again.. strange. SIP for me is disabled.

Yea I get that as well but when I do and rerun it all I get is a flashing cursor and no CPU info.

Link to comment
Share on other sites
 Share
Go to topic listing
×
×
  • Create New...
