Pavo
Pavo
Posted
Posted

Yes, it looks like {censored} but it’s working.

Seems like it’s purely cosmetic so far.

The graphics are fine when I log in through screen sharing, it’s just the screen that is black but I’ll try HDMI instead of DVI.

The Samsung 950 PRO connected to the “HDMI port” is actually the boot drive and I get 1.4 GB/sec write and about 2 GB/sec read speeds.

If you have any tips on how to fix this (or how to change the Subsystem ID of the 10GbE card to 0x000a) please feel free to help me out.





Sent from my iPhone using Tapatalk

I would suggest uploading your entire EFI folder so we can take a look at the whole thing. Plus add system specs if not in sig.

Link to comment
Share on other sites
robertr
robertr
Posted
Posted

Ok, some more details about my setup.

I tried with an HDMI cable but it made no difference. If I connect both with DVI and HDMI the two screens are detected perfectly in OSX and I can see them through screen sharing.

Screen is detected, resolution is correct, etc. but the screen is black. (though it is active, the screen does not go to sleep or turn off)

OS: 10.13.3

Clover: 4392

LILU: 1.2.2

Whatevergreen: 1.1.4



My system:

HP Z800 motherboard, Xeon X5690 cpu, 48GB ECC RAM

PCIe2 slot0: x4, holds Samsung 950 PRO nvme boot drive. (EFI/Clover is on a USB stick since the Z800 won't load the ahci option rom from the nvme drive)

PCIe2 slot1: x16, ASUS ROG STRIX RX 580 TOP https://www.asus.com/us/Graphics-Cards/ROG-STRIX-RX580-T8G-GAMING/overview/

PCIe2 slot2: x4, empty

PCIe2 slot3: x8, empty

PCIe2 slot4: x16, empty (would normally hold an Intel 520 DA1 10GbE card)

PCI32 slot5: empty

PCIe2 slot6: x8, empty (would normally hold USB 3 card based on FL1100)



Here's a zip of my EFI folder:

https://www.dropbox.com/s/hhcryzaig2nm3pi/EFI-robertr-2018-01-30.zip?dl=0



Please tell me what more info I would need to supply, logs, etc.

If this is the wrong thread/forum, please excuse me and tell me where to post.

Cheers!







Boot log:

0:100  0:100  MemLog inited, TSC freq: 3463264042
0:100  0:000  CPU was calibrated with ACPI PM Timer
0:100  0:000  LegacyRegion2: Chipset/proc: 0x34068086
0:100  0:000   Core i7 processors (PAM 0x40-0x47)
0:100  0:000   Test PAM1=(0x41=11, 0x5a=00, 0x81=0C, 0x91=C2) at chipset 34068086
0:100  0:000  , Install = Success
0:109  0:009  BiosVideoDriverBindingStart!
0:109  0:000  BiosVideoCheckForVbe
0:109  0:000  EdidOverride not found
0:115  0:006   Edid1+
0:115  0:000   found Detail Timing 1920x1200
0:121  0:006   Edid0+
0:121  0:000   found Detail Timing 1920x1200
0:121  0:000  ... already present
0:125  0:003     0 1280x960 attr=BB - ok, edid+, working, highest, pref=0
0:125  0:000     1 640x480 attr=BB - ok, edid+, 640x480, working
0:126  0:000     2 800x600 attr=BB - ok, edid+, 800x600, working
0:126  0:000     3 1024x768 attr=BB - ok, edid+, 1024x768, working
0:127  0:000     4 1280x1024 attr=BB - ok, edid+, working, highest, pref=4
0:128  0:001     5 1400x1050 attr=BB - ok, edid-
0:130  0:001     6 1600x1200 attr=BB - ok, edid-
0:132  0:001     7 1920x1200 attr=BB - ok, edid+, working, highest, pref=7
0:132  0:000  BV new mode: 7 1920x1200
0:165  0:032   SetMode pref 7 (7) = Success
2:854  2:688
2:854  0:000  Now is 30.1.2018,  11:19:46 (GMT)
2:854  0:000  Starting Clover revision: 4392 on CLOVER EFI
2:854  0:000  Build with: [Args: -D NO_GRUB_DRIVERS_EMBEDDED -t XCODE8 | -D NO_GRUB_DRIVERS_EMBEDDED -D USE_LOW_EBDA -a X64 -b RELEASE -t XCODE8 -n 5 | OS: 10.12.6 | XCODE: 9.2]
2:854  0:000  SelfDevicePath=PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000) @CCEC4318
2:854  0:000  SelfDirPath = \EFI\CLOVER
2:854  0:000  === [ Get Smbios ] ========================================
2:854  0:000  Type 16 Index = 0
2:854  0:000  Type 16 Index = 1
2:854  0:000  Type 16 Index = 2
2:854  0:000  Total Memory Slots Count = 13
2:854  0:000  Type 17 Index = 0
2:854  0:000  SmbiosTable.Type17->Speed = 1333MHz
2:854  0:000  SmbiosTable.Type17->Size = 8192MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU0 DIMM1
2:854  0:000  SmbiosTable.Type17->Vendor = JEDEC ID:83 0B
2:854  0:000  SmbiosTable.Type17->SerialNumber = 290CB579
2:854  0:000  SmbiosTable.Type17->PartNumber = NT8GC72C4NB3NK-CG
2:854  0:000  Type 17 Index = 1
2:854  0:000  SmbiosTable.Type17->Speed = 1333MHz
2:854  0:000  SmbiosTable.Type17->Size = 8192MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU0 DIMM2
2:854  0:000  SmbiosTable.Type17->Vendor = JEDEC ID:83 0B
2:854  0:000  SmbiosTable.Type17->SerialNumber = 260E2E1B
2:854  0:000  SmbiosTable.Type17->PartNumber = NT8GC72C4NB3NK-CG
2:854  0:000  Type 17 Index = 2
2:854  0:000  SmbiosTable.Type17->Speed = 1333MHz
2:854  0:000  SmbiosTable.Type17->Size = 8192MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU0 DIMM3
2:854  0:000  SmbiosTable.Type17->Vendor = JEDEC ID:83 0B
2:854  0:000  SmbiosTable.Type17->SerialNumber = 0114A541
2:854  0:000  SmbiosTable.Type17->PartNumber = NT8GC72C4NB3NK-CG
2:854  0:000  Type 17 Index = 3
2:854  0:000  SmbiosTable.Type17->Speed = 1333MHz
2:854  0:000  SmbiosTable.Type17->Size = 8192MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU0 DIMM4
2:854  0:000  SmbiosTable.Type17->Vendor = JEDEC ID:83 0B
2:854  0:000  SmbiosTable.Type17->SerialNumber = 260E43E0
2:854  0:000  SmbiosTable.Type17->PartNumber = NT8GC72C4NB3NK-CG
2:854  0:000  Type 17 Index = 4
2:854  0:000  SmbiosTable.Type17->Speed = 1333MHz
2:854  0:000  SmbiosTable.Type17->Size = 8192MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU0 DIMM5
2:854  0:000  SmbiosTable.Type17->Vendor = JEDEC ID:83 0B
2:854  0:000  SmbiosTable.Type17->SerialNumber = 2A0E2C9E
2:854  0:000  SmbiosTable.Type17->PartNumber = NT8GC72C4NB3NK-CG
2:854  0:000  Type 17 Index = 5
2:854  0:000  SmbiosTable.Type17->Speed = 1333MHz
2:854  0:000  SmbiosTable.Type17->Size = 8192MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU0 DIMM6
2:854  0:000  SmbiosTable.Type17->Vendor = JEDEC ID:83 0B
2:854  0:000  SmbiosTable.Type17->SerialNumber = 0114E5EA
2:854  0:000  SmbiosTable.Type17->PartNumber = NT8GC72C4NB3NK-CG
2:854  0:000  Type 17 Index = 6
2:854  0:000  Ignoring insane frequency value 0MHz
2:854  0:000  SmbiosTable.Type17->Speed = 0MHz
2:854  0:000  SmbiosTable.Type17->Size = 0MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU1 DIMM1
2:854  0:000  SmbiosTable.Type17->Vendor = <null string>
2:854  0:000  SmbiosTable.Type17->SerialNumber = <null string>
2:854  0:000  SmbiosTable.Type17->PartNumber = <null string>
2:854  0:000  Type 17 Index = 7
2:854  0:000  Ignoring insane frequency value 0MHz
2:854  0:000  SmbiosTable.Type17->Speed = 0MHz
2:854  0:000  SmbiosTable.Type17->Size = 0MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU1 DIMM2
2:854  0:000  SmbiosTable.Type17->Vendor = <null string>
2:854  0:000  SmbiosTable.Type17->SerialNumber = <null string>
2:854  0:000  SmbiosTable.Type17->PartNumber = <null string>
2:854  0:000  Type 17 Index = 8
2:854  0:000  Ignoring insane frequency value 0MHz
2:854  0:000  SmbiosTable.Type17->Speed = 0MHz
2:854  0:000  SmbiosTable.Type17->Size = 0MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU1 DIMM3
2:854  0:000  SmbiosTable.Type17->Vendor = <null string>
2:854  0:000  SmbiosTable.Type17->SerialNumber = <null string>
2:854  0:000  SmbiosTable.Type17->PartNumber = <null string>
2:854  0:000  Type 17 Index = 9
2:854  0:000  Ignoring insane frequency value 0MHz
2:854  0:000  SmbiosTable.Type17->Speed = 0MHz
2:854  0:000  SmbiosTable.Type17->Size = 0MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU1 DIMM4
2:854  0:000  SmbiosTable.Type17->Vendor = <null string>
2:854  0:000  SmbiosTable.Type17->SerialNumber = <null string>
2:854  0:000  SmbiosTable.Type17->PartNumber = <null string>
2:854  0:000  Type 17 Index = 10
2:854  0:000  Ignoring insane frequency value 0MHz
2:854  0:000  SmbiosTable.Type17->Speed = 0MHz
2:854  0:000  SmbiosTable.Type17->Size = 0MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU1 DIMM5
2:854  0:000  SmbiosTable.Type17->Vendor = <null string>
2:854  0:000  SmbiosTable.Type17->SerialNumber = <null string>
2:854  0:000  SmbiosTable.Type17->PartNumber = <null string>
2:854  0:000  Type 17 Index = 11
2:854  0:000  Ignoring insane frequency value 0MHz
2:854  0:000  SmbiosTable.Type17->Speed = 0MHz
2:854  0:000  SmbiosTable.Type17->Size = 0MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU1 DIMM6
2:854  0:000  SmbiosTable.Type17->Vendor = <null string>
2:854  0:000  SmbiosTable.Type17->SerialNumber = <null string>
2:854  0:000  SmbiosTable.Type17->PartNumber = <null string>
2:854  0:000  Type 17 Index = 12
2:854  0:000  Ignoring insane frequency value 0MHz
2:854  0:000  SmbiosTable.Type17->Speed = 0MHz
2:854  0:000  SmbiosTable.Type17->Size = 34816MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  SYSTEM ROM
2:854  0:000  SmbiosTable.Type17->Vendor =
2:854  0:000  SmbiosTable.Type17->SerialNumber =
2:854  0:000  SmbiosTable.Type17->PartNumber =
2:854  0:000  Boot status=0
2:854  0:000  Running on: 'HP Z800 Workstation' with board '0AECh'
2:854  0:000  === [ GetCPUProperties ] ==================================
2:854  0:000  CPU Vendor = 756E6547 Model=206C2
2:854  0:000   The CPU supported SSE4.1
2:854  0:000  BrandString = Intel(R) Xeon(R) CPU           X5690  @ 3.47GHz
2:854  0:000   The CPU supported turbo
2:854  0:000  FSBFrequency = 134 MHz, DMI FSBFrequency = 6400 MHz, Corrected FSBFrequency = 133 MHz
2:854  0:000  MaxDiv/MinDiv: 26.0/12
2:854  0:000  Turbo: 27/27/28/28
2:854  0:000  Features: 0xBFEBFBFF
2:854  0:000  Threads: 12
2:854  0:000  Cores: 6
2:854  0:000  FSB: 133 MHz
2:854  0:000  CPU: 3466 MHz
2:854  0:000  TSC: 3466 MHz
2:854  0:000  PIS: 533 MHz
2:854  0:000  ExternalClock: 133 MHz
2:854  0:000  === [ GetDevices ] ========================================
2:854  0:000  PCI (00|00:00.00) : 8086 3406 class=060000
2:854  0:000  PCI (00|00:01.00) : 8086 3408 class=060400
2:854  0:000  PCI (00|03:00.00) : 144D A802 class=010802
2:854  0:000  PCI (00|00:03.00) : 8086 340A class=060400
2:854  0:000  PCI (00|0F:00.00) : 1002 67DF class=030000
2:854  0:000   - GFX: Model=AMD Radeon RX 480 (ATI/AMD)
2:854  0:000  PCI (00|0F:00.01) : 1002 AAF0 class=040300
2:854  0:000   - HDMI Audio:
2:854  0:000  PCI (00|00:07.00) : 8086 340E class=060400
2:854  0:000  PCI (00|00:10.00) : 8086 3425 class=080000
2:854  0:000  PCI (00|00:10.01) : 8086 3426 class=080000
2:854  0:000  PCI (00|00:11.00) : 8086 3427 class=080000
2:854  0:000  PCI (00|00:11.01) : 8086 3428 class=080000
2:854  0:000  PCI (00|00:14.00) : 8086 342E class=080000
2:854  0:000  PCI (00|00:14.01) : 8086 3422 class=080000
2:854  0:000  PCI (00|00:14.02) : 8086 3423 class=080000
2:854  0:000  PCI (00|00:15.00) : 8086 342F class=080020
2:854  0:000  PCI (00|00:1A.00) : 8086 3A37 class=0C0300
2:854  0:000  PCI (00|00:1A.01) : 8086 3A38 class=0C0300
2:854  0:000  PCI (00|00:1A.02) : 8086 3A39 class=0C0300
2:854  0:000  PCI (00|00:1A.07) : 8086 3A3C class=0C0320
2:855  0:000  PCI (00|00:1B.00) : 8086 3A3E class=040300
2:855  0:000  PCI (00|00:1C.00) : 8086 3A40 class=060400
2:855  0:000  PCI (00|00:1C.04) : 8086 3A48 class=060400
2:855  0:000  PCI (00|02:00.00) : 14E4 1684 class=020000
2:855  0:000   - LAN: 0 Vendor=Broadcom
2:855  0:000  PCI (00|00:1C.05) : 8086 3A4A class=060400
2:855  0:000  PCI (00|01:00.00) : 14E4 1684 class=020000
2:855  0:000   - LAN: 1 Vendor=Broadcom
2:855  0:000  PCI (00|00:1D.00) : 8086 3A34 class=0C0300
2:855  0:000  PCI (00|00:1D.01) : 8086 3A35 class=0C0300
2:855  0:000  PCI (00|00:1D.02) : 8086 3A36 class=0C0300
2:855  0:000  PCI (00|00:1D.07) : 8086 3A3A class=0C0320
2:855  0:000  PCI (00|00:1E.00) : 8086 244E class=060401
2:855  0:000  PCI (00|37:09.00) : 11C1 5811 class=0C0010
2:855  0:000  PCI (00|00:1F.00) : 8086 3A16 class=060100
2:855  0:000  PCI (00|00:1F.02) : 8086 2822 class=010400
2:855  0:000  PCI (00|40:03.00) : 8086 340A class=060400
2:855  0:000  PCI (00|40:07.00) : 8086 340E class=060400
2:855  0:000  PCI (00|40:09.00) : 8086 3410 class=060400
2:855  0:000  PCI (00|41:00.00) : 1000 0058 class=010000
2:855  0:000  PCI (00|40:10.00) : 8086 3425 class=080000
2:855  0:000  PCI (00|40:10.01) : 8086 3426 class=080000
2:855  0:000  PCI (00|40:11.00) : 8086 3427 class=080000
2:855  0:000  PCI (00|40:11.01) : 8086 3428 class=080000
2:855  0:000  PCI (00|40:14.00) : 8086 342E class=080000
2:855  0:000  PCI (00|40:14.01) : 8086 3422 class=080000
2:855  0:000  PCI (00|40:14.02) : 8086 3423 class=080000
2:855  0:000  PCI (00|40:15.00) : 8086 342F class=080020
2:855  0:000  PCI (00|7F:00.00) : 8086 2C70 class=060000
2:855  0:000  PCI (00|7F:00.01) : 8086 2D81 class=060000
2:855  0:000  PCI (00|7F:02.00) : 8086 2D90 class=060000
2:855  0:000  PCI (00|7F:02.01) : 8086 2D91 class=060000
2:855  0:000  PCI (00|7F:02.02) : 8086 2D92 class=060000
2:855  0:000  PCI (00|7F:02.03) : 8086 2D93 class=060000
2:855  0:000  PCI (00|7F:02.04) : 8086 2D94 class=060000
2:855  0:000  PCI (00|7F:02.05) : 8086 2D95 class=060000
2:855  0:000  PCI (00|7F:03.00) : 8086 2D98 class=060000
2:855  0:000  PCI (00|7F:03.01) : 8086 2D99 class=060000
2:855  0:000  PCI (00|7F:03.02) : 8086 2D9A class=060000
2:855  0:000  PCI (00|7F:03.04) : 8086 2D9C class=060000
2:855  0:000  PCI (00|7F:04.00) : 8086 2DA0 class=060000
2:855  0:000  PCI (00|7F:04.01) : 8086 2DA1 class=060000
2:855  0:000  PCI (00|7F:04.02) : 8086 2DA2 class=060000
2:855  0:000  PCI (00|7F:04.03) : 8086 2DA3 class=060000
2:855  0:000  PCI (00|7F:05.00) : 8086 2DA8 class=060000
2:855  0:000  PCI (00|7F:05.01) : 8086 2DA9 class=060000
2:855  0:000  PCI (00|7F:05.02) : 8086 2DAA class=060000
2:855  0:000  PCI (00|7F:05.03) : 8086 2DAB class=060000
2:855  0:000  PCI (00|7F:06.00) : 8086 2DB0 class=060000
2:855  0:000  PCI (00|7F:06.01) : 8086 2DB1 class=060000
2:855  0:000  PCI (00|7F:06.02) : 8086 2DB2 class=060000
2:855  0:000  PCI (00|7F:06.03) : 8086 2DB3 class=060000
2:855  0:000  === [ GetDefaultSettings ] ================================
2:855  0:000  Clover load options size = 0 bytes
2:907  0:051  EFI\CLOVER\config.plist loaded: Success
2:907  0:000  === [ GetListOfThemes ] ===================================
2:932  0:025  - [00]: embedded
2:945  0:012  - [00]: metal
2:997  0:051  - [01]: random
3:010  0:013  - [01]: applestyle
3:061  0:051  - [02]: newyear
3:074  0:012  - [03]: christmas
3:100  0:025  === [ Found config plists ] ===============================
3:100  0:000  - config.plist
3:126  0:025  - config-stripped-acpi.plist
3:126  0:000  - configOldHack.plist
3:139  0:012  - configNewTry.plist
3:139  0:000  === [ GetEarlyUserSettings ] ==============================
3:139  0:000  timeout set to 1
3:139  0:000  Custom boot CUSTOM_BOOT_DISABLED (0x0)
3:139  0:000  KextsToPatch: 1 requested
3:139  0:000   - [00]: AppleAHCIPort (External icons patch) :: BinPatch :: data len: 8
3:139  0:000  Default theme: applestyle
3:139  0:000  Hiding entries with string BOOTX64.EFI
3:139  0:000  === [ LoadDrivers ] =======================================
3:165  0:025  Loading AppleImageCodec-64.efi  status=Success
3:178  0:013  Loading AppleKeyAggregator-64.efi  status=Success
3:178  0:000  Loading AppleUITheme-64.efi  status=Success
3:178  0:000  Loading FirmwareVolume-64.efi  status=Success
3:191  0:013  Loading FSInject-64.efi  status=Success
3:191  0:000  Loading GrubEXFAT-64.efi  status=Success
3:204  0:013   - driver needs connecting
3:204  0:000  Loading apfs.efi  status=Success
3:264  0:059   - driver needs connecting
3:264  0:000  Loading zfs_x64.efi  status=Success
3:277  0:013   - driver needs connecting
3:277  0:000  Loading GrubISO9660-64.efi  status=Success
3:290  0:013   - driver needs connecting
3:290  0:000  Loading GrubNTFS-64.efi  status=Success
3:303  0:013   - driver needs connecting
3:303  0:000  Loading GrubUDF-64.efi  status=Success
3:303  0:000   - driver needs connecting
3:303  0:000  Loading NvmExpressDxe-64.efi  status=Success
3:316  0:013   - driver needs connecting
3:316  0:000  Loading SMCHelper-64.efi  status=Success
3:316  0:000  Loading XhciDxe-64.efi  status=Success
3:329  0:013   - driver needs connecting
3:329  0:000  8 drivers needs connecting ...
3:329  0:000  PlatformDriverOverrideProtocol->GetDriver overriden
3:329  0:000  APFS driver loaded
3:752  0:422  === [ InitScreen ] ========================================
3:752  0:000  SetScreenResolution: 1920x1200 - already set
3:752  0:000  Console modes reported: 4, available modes:
3:752  0:000   - [01]: 80x25
3:752  0:000   - [02]: 80x50
3:752  0:000   - [03]: 100x31
3:752  0:000   - [04]: 240x63 (current mode)
3:752  0:000  SetScreenResolution: 1920x1200 - already set
3:752  0:000  reinit: self device path=PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)
3:753  0:000  Using embedded font: Success
3:756  0:003  === [ GetMacAddress ] =====================================
3:756  0:000  === [ ScanSPD ] ===========================================
3:757  0:000  === [ GetAcpiTablesList ] =================================
3:757  0:000  Get Acpi Tables List from RSDT:
3:757  0:000   - [00]: FACP  TYLSBURG len=116
3:757  0:000   - [01]: APIC  TYLSBURG len=404
3:757  0:000   - [02]: ASF!  TYLSBURG len=99
3:757  0:000   - [03]: MCFG  TYLSBURG len=60
3:757  0:000   - [04]: TCPA  TYLSBURG len=50
3:757  0:000   - [05]: SLIC  SLIC-WKS len=374
3:757  0:000   - [06]: HPET  TYLSBURG len=56
3:757  0:000   - [07]: DMAR  TYLSBURG len=440
3:757  0:000   - [08]: SSDT  PPM RCM  len=16308
3:757  0:000  Calibrated TSC Frequency = 3463264042 = 3463MHz
3:757  0:000  === [ GetUserSettings ] ===================================
3:757  0:000  USB FixOwnership: yes
3:757  0:000  Dropping 3 tables:
3:757  0:000   - [00]: Drop table  signature="SSDT" (54445353) table-id="Cpu0Ist" (0074734930757043)
3:757  0:000           - set table: 54445353,   74734930757043 to drop: no
3:757  0:000   - [01]: Drop table  signature="DMAR" (52414D44)
3:757  0:000           - set table: 52414D44,                0 to drop: yes
3:757  0:000   - [02]: Drop table  signature="SSDT" (54445353) table-id="CpuPm" (0000006D50757043)
3:757  0:000           - set table: 54445353,       6D50757043 to drop: no
3:757  0:000   - final DSDT Fix mask=17EE3155
3:757  0:000  EnableC6: yes
3:758  0:000  Using ProductName from config
3:758  0:000  ProductName: MacPro5,1
3:758  0:000  Using latest BiosVersion from clover
3:758  0:000  BiosVersion: MP51.88Z.0084.B00.1708080528
3:758  0:000  BiosReleaseDate: 08/08/17
3:758  0:000  Using FirmwareFeatures from clover: 0xE80FE137
3:758  0:000  Using FirmwareFeaturesMask from clover: 0xFF1FFF3F
3:758  0:000  PlatformFeature will not set in SMBIOS
3:758  0:000  Board-ID set from config as Mac-F221BEC8
3:758  0:000  BoardType: 0xB
3:758  0:000  ChassisType: 0x6
3:758  0:000  Converted CustomUUID 105304E0-287D-5B10-9B59-BA6DA25A2CDD
3:758  0:000  QPI: use Table 132
3:938  0:180  === [ ScanVolumes ] =======================================
3:938  0:000  Found 7 volumes with blockIO
3:938  0:000  - [00]: Volume: PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)
3:949  0:011          Result of bootcode detection: bootable unknown (legacy)
3:949  0:000          USB volume
3:949  0:000  - [01]: Volume: PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)
3:961  0:011          Result of bootcode detection: bootable unknown (legacy)
3:961  0:000          USB volume
3:961  0:000          This is SelfVolume !!
3:961  0:000  - [02]: Volume: PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)
3:972  0:011          USB volume
3:972  0:000  - [03]: Volume: PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)
3:972  0:000          Result of bootcode detection: bootable unknown (legacy)
3:972  0:000  - [04]: Volume: PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)
3:972  0:000          Result of bootcode detection: bootable unknown (legacy)
3:973  0:000  - [05]: Volume: PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)
3:973  0:000  - [06]: Volume: PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)
4:008  0:035  Loading nvram.plist from Vol 'EFI' - loaded, size=3677
4:037  0:028  === [ PutNvramPlistToRtVars ] =============================
4:037  0:000   Adding Key: Clover.BackupDirOnDestVol: Size = 3, Data: 59 65 73
4:037  0:000   Adding Key: Clover.KeepBackupLimit: Size = 1, Data: 35
4:037  0:000   Adding Key: Clover.LogEveryBoot: Size = 2, Data: 31 30
4:037  0:000   Adding Key: Clover.LogLineCount: Size = 3, Data: 34 30 30
4:037  0:000   Adding Key: Clover.Theme: Size = 10, Data: 61 70 70 6C 65 73 74 79 6C 65
4:037  0:000   Adding Key: EFILoginHiDPI: Size = 4, Data: 00 00 00 00
4:037  0:000   Adding Key: SystemAudioVolume: Size = 1, Data: 80
4:037  0:000   Adding Key: SystemAudioVolumeDB: Size = 1, Data: 43
4:037  0:000   Adding Key: bluetoothActiveControllerInfo: Size = 16, Data: 01 00 12 0A 00 00 00 00 10 1D 00 15 83 36 99 9B
4:037  0:000   Adding Key: bootercfg: Size = 2, Data: 28 00
4:037  0:000   Adding Key: csr-active-config: Size = 4, Data: 67 00 00 00
4:037  0:000   Adding Key: fakesmc-key-#KEY-ui32: Size = 4, Data: 00 00 00 16
4:037  0:000   Adding Key: fakesmc-key-$Adr-ui32: Size = 4, Data: 00 00 03 00
4:037  0:000   Adding Key: fakesmc-key-$Num-ui8: Size = 1, Data: 01
4:037  0:000   Adding Key: fakesmc-key-$Num-ui8 : Size = 1, Data: 01
4:037  0:000   Adding Key: fakesmc-key-BATP-flag: Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-BEMB-flag: Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-BNum-ui8: Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-BNum-ui8 : Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-EPCI-ui32: Size = 4, Data: 02 C0 07 00
4:037  0:000   Adding Key: fakesmc-key-MSAc-ui16: Size = 2, Data: 00 00
4:037  0:000   Adding Key: fakesmc-key-MSFW-ui8: Size = 2, Data: 01 00
4:037  0:000   Adding Key: fakesmc-key-MSLD-ui8: Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-MSLD-ui8 : Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-MSPS-ui16: Size = 2, Data: 00 03
4:037  0:000   Adding Key: fakesmc-key-MSTc-ui8: Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-MSTc-ui8 : Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-MSWr-ui8: Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-MSWr-ui8 : Size = 1, Data: 19
4:037  0:000   Adding Key: fakesmc-key-RBr -ch8*: Size = 8, Data: 6B 35 00 00 00 00 00 00
4:037  0:000   Adding Key: fakesmc-key-REV -ch8*: Size = 6, Data: 01 39 0F 00 00 11
4:037  0:000   Adding Key: fakesmc-key-RMde-char: Size = 1, Data: 41
4:037  0:000   Adding Key: fakesmc-key-RPlt-ch8*: Size = 8, Data: 6B 35 00 00 00 00 00 00
4:037  0:000   Adding Key: flagstate: Size = 32, Data: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
4:037  0:000   Adding Key: fmm-computer-name: Size = 15, Data: 52 6F 62 65 72 74 73 20 4D 61 63 20 50 72 6F
4:037  0:000   Adding Key: fmm-mobileme-token-FMM: Size = 605, Data: 62 70 6C 69 73 74 30 30 D9 01 02 03 04 05 06 07 08 09 0A 0B 16 17 18 19 1A 1B 1C 56 75 73 65 72 69 64 5F 10 13 64 61 74 61 63 6C 61 73 73 50 72 6F 70 65 72 74 69 65 73 59 61 75 74 68 54 6F 6B 65 6E 58 70 65 72 73 6F 6E 49 44 58 75 73 65 72 6E 61 6D 65 57 61 64 64 54 69 6D 65 5F 10 12 65 6E 61 62 6C 65 64 44 61 74 61 63 6C 61 73 73 65 73 54 67 75 69 64 58 75 73 65 72 49 6E 66 6F 11 01 F5 D1 0C 0D 5F 10 21 63 6F 6D 2E 61 70 70 6C 65 2E 44 61 74 61 63 6C 61 73 73 2E 44 65 76 69 63 65 4C 6F 63 61 74 6F 72 D4 0E 0F 10 11 12 13 14 15 56 61 70 73 45 6E 76 58 68 6F 73 74 6E 61 6D 65 5D 61 75 74 68 4D 65 63 68 61 6E 69 73 6D 56 73 63 68 65 6D 65 5A 50 72 6F 64 75 63 74 69 6F 6E 5F 10 13 70 32 36 2D 66 6D 69 70 2E 69 63 6C 6F 75 64 2E 63 6F 6D 55 74 6F 6B 65 6E 55 68 74 74 70 73 5F 10 28 41 51 41 41 41 41 42 57 4A 6D 61 72 43 6A 6A 5A 4D 74 6E 33 6C 51 34 4D 38 34 5F 39 39 6B 6B 66 71 4D 4E 43 4A 37 49 7E 59 31 37 34 35 32 31 32 31 33 5F 10 13 72 6F 62 65 72 74 40 72 65 68 6E 6D 61 72 6B 2E 6E 65 74 23 41 D5 89 99 AB D8 5F DD A1 0C 5F 10 24 38 33 32 46 39 46 35 44 2D 45 38 41 46 2D 34 33 31 38 2D 39 36 46 31 2D 41 33 36 43 38 34 36 41 35 46 46 33 D3 1D 1E 1F 20 21 22 5F 10 15 49 6E 55 73 65 4F 77 6E 65 72 44 69 73 70 6C 61 79 4E 61 6D 65 5F 10 13 49 6E 55 73 65 4F 77 6E 65 72 46 69 72 73 74 4E 61 6D 65 5F 10 12 49 6E 55 73 65 4F 77 6E 65 72 4C 61 73 74 4E 61 6D 65 5F 10 14 4B 61 72 6C 20 52 6F 62 65 72 74 20 52 65 68 6E 6D 61 72 6B 5B 4B 61 72 6C 20 52 6F 62 65 72 74 58 52 65 68 6E 6D 61 72 6B 00 08 00 1B 00 22 00 38 00 42 00 4B 00 54 00 5C 00 71 00 76 00 7F 00 82 00 85 00 A9 00 B2 00 B9 00 C2 00 D0 00 D7 00 E2 00 F8 00 FE 01 04 01 2F 01 39 01 4F 01 58 01 5A 01 81 01 88 01 A0 01 B6 01 CB 01 E2 01 EE 00 00 00 00 00 00 02 01 00 00 00 00 00 00 00 23 00 00 00 00 00 00 00 00 00 00 00 00 00 00 01 F7
4:037  0:000   Adding Key: install-product-url: Size = 73, Data: 78 2D 6F 73 70 72 6F 64 75 63 74 3A 2F 2F 43 31 33 32 35 37 33 37 2D 34 33 45 35 2D 33 38 43 35 2D 41 39 38 30 2D 32 37 34 32 30 46 43 44 45 33 35 37 2F 6D 61 63 4F 53 25 32 30 49 6E 73 74 61 6C 6C 25 32 30 44 61 74 61
4:037  0:000   Adding Key: prev-lang:kbd: Size = 7, Data: 73 76 2D 4E 4F 3A 37
4:037  0:000   Adding Key: previous-system-uuid: Size = 36, Data: 43 31 33 32 35 37 33 37 2D 34 33 45 35 2D 33 38 43 35 2D 41 39 38 30 2D 32 37 34 32 30 46 43 44 45 33 35 37
4:037  0:000   Adding Key: rc_imgsrc_info: Size = 95, Data: 62 70 6C 69 73 74 30 30 A1 01 D1 02 03 5F 10 24 31 31 36 37 32 37 34 30 2D 38 36 39 34 2D 33 37 31 30 2D 42 44 43 39 2D 45 43 42 30 38 43 42 41 36 32 30 35 56 53 53 44 31 36 30 08 0A 0D 34 00 00 00 00 00 00 01 01 00 00 00 00 00 00 00 04 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 3B
4:037  0:000   Adding Key: security-mode: String: Size = 4, Val = 'none'
4:037  0:000  === [ InitTheme ] =========================================
4:051  0:014  Using theme 'applestyle' (EFI\CLOVER\themes\applestyle)
4:051  0:000  theme applestyle defined in NVRAM found and theme.plist parsed
4:084  0:032  Loading font from ThemeDir: Success
4:084  0:000  Choosing theme applestyle
4:084  0:000  after NVRAM boot-args=-v darkwake=0 kext-dev-mode=1 rootless=0 -rad4200 -raddvi
4:084  0:000  === [ Dump SMC keys from NVRAM ] ==========================
4:084  0:000  found AppleSMC protocol
4:084  0:000  Registered 22 SMC keys
4:084  0:000  === [ AddCustomEntries ] ==================================
4:084  0:000  Custom entry 0 Title:"MacOS Update" Path:"\Mac OS X Install Data\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"70D889FE-53D9-4DD5-B8C4-860EAC5EFB98"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 0 Title:"MacOS Update" Path:"\macOS Install Data\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"70D889FE-53D9-4DD5-B8C4-860EAC5EFB98"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 0 Title:"MacOS Update" Path:"\macOS Install Data\Locked Files\Boot Files\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"70D889FE-53D9-4DD5-B8C4-860EAC5EFB98"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 0 Title:"MacOS Update" Path:"\OS X Install Data\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"70D889FE-53D9-4DD5-B8C4-860EAC5EFB98"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 0 Title:"MacOS Update" Path:"\.IABootFiles\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"70D889FE-53D9-4DD5-B8C4-860EAC5EFB98"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 1 Title:"HS Install ssd512" Path:"\Mac OS X Install Data\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"3A3EA286-E9DF-4766-8435-FE41DE63FAC7"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 1 Title:"HS Install ssd512" Path:"\macOS Install Data\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"3A3EA286-E9DF-4766-8435-FE41DE63FAC7"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 1 Title:"HS Install ssd512" Path:"\macOS Install Data\Locked Files\Boot Files\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"3A3EA286-E9DF-4766-8435-FE41DE63FAC7"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 1 Title:"HS Install ssd512" Path:"\OS X Install Data\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"3A3EA286-E9DF-4766-8435-FE41DE63FAC7"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 1 Title:"HS Install ssd512" Path:"\.IABootFiles\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"3A3EA286-E9DF-4766-8435-FE41DE63FAC7"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  === [ ScanLoader ] ========================================
4:084  0:000  - [01]: 'EFI'
4:097  0:012  - [02]: 'HackBoot'
4:097  0:000  - [04]: 'EFI'
4:098  0:000  - [05]: 'SS950'
4:099  0:001          AddLoaderEntry for Volume Name=SS950
4:101  0:002      Check if volume Is Hibernated:
4:101  0:000      Check sleep image 'by signature':
4:103  0:001      read prefs \Library\Preferences\com.apple.PowerManagement.plist status=Success
4:103  0:000      using default sleep image name = \private\var\vm\sleepimage
4:104  0:000      sleepimage not found -> Not Found
4:104  0:000      hibernated: no - sign
4:183  0:078  - [06]: 'Recovery HD'
4:184  0:000          AddLoaderEntry for Volume Name=Recovery HD
4:185  0:001  Scanning legacy ...
4:185  0:000  === [ AddCustomTool ] =====================================
4:198  0:013  found tool \EFI\CLOVER\tools\Shell64U.efi
4:198  0:000  Checking EFI partition Volume 1 for Clover
4:198  0:000   Found Clover
4:200  0:002  === [ GetEfiBootDeviceFromNvram ] =========================
4:200  0:000   - found entry 0. 'Boot macOS from SS950', Volume 'SS950', DevicePath 'PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)\System\Library\CoreServices\boot.efii'
4:200  0:000  DefaultIndex=0 and MainMenu.EntryCount=8
4:830  0:629  GUI ready
6:886  2:056  === [ StartLoader ] =======================================
6:886  0:000  Finally: ExternalClock=133MHz BusSpeed=133202kHz CPUFreq=3463MHz PIS: hw.busfrequency=532000000Hz
6:886  0:000  Loading boot.efi  status=Success
7:194  0:308  GetOSVersion: 10.13.3 (17D47)
7:194  0:000  CSR_CFG: CSR_ALLOW_UNTRUSTED_KEXTS | CSR_ALLOW_UNRESTRICTED_FS | CSR_ALLOW_TASK_FOR_PID | CSR_ALLOW_UNRESTRICTED_DTRACE | CSR_ALLOW_UNRESTRICTED_NVRAM
7:194  0:000  Filtering KextPatches:
7:194  0:000   - [00]: AppleAHCIPort (External icons patch) :: BinPatch :: [OS: 10.13.3 | MatchOS: All | MatchBuild: All] ==> allowed
7:194  0:000  Will not patch boot.efi
7:194  0:000  === [ PatchSmbios ] =======================================
7:194  0:000  insert table 9 for dev 0:0
7:194  0:000  insert table 9 for dev 0:1
7:194  0:000  insert table 9 for dev 0:0
7:194  0:000  insert table 9 for dev 9:0
7:195  0:000  Injecting user memory modules to SMBIOS
7:195  0:000  Channels: 1
7:195  0:000  Interleave: 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
7:195  0:000   DIMM1 1333MHz 8192MB
7:195  0:000   DIMM2 1333MHz 8192MB
7:195  0:000   DIMM3 1333MHz 8192MB
7:195  0:000   DIMM4 1333MHz 8192MB
7:195  0:000   DIMM5 1333MHz 8192MB
7:195  0:000   DIMM6 1333MHz 8192MB
7:195  0:000   DIMM7 EMPTY
7:195  0:000   DIMM8 EMPTY
7:195  0:000   DIMM9 EMPTY
7:195  0:000   DIMM10 EMPTY
7:195  0:000   DIMM11 EMPTY
7:195  0:000   DIMM12 EMPTY
7:195  0:000  mTotalSystemMemory = 49152
7:195  0:000  NumberOfMemoryDevices = 12
7:196  0:000  Type20[0]->End = 0x3FFFFF, Type17[0] = 0x2000
7:196  0:000  === [ PatchACPI ] =========================================
7:196  0:000  Xsdt reallocation done
7:196  0:000  old FADT length=F4
7:196  0:000   SignatureFixup: 0x0 -> 0
7:196  0:000  Found OperationRegion(VECT, SystemMemory, F8000, ...)
7:209  0:013  Apply DsdtFixMask=0x17EE3155
7:209  0:000     drop _DSM mask=0x0000
7:209  0:000  === [ FixBiosDsdt ] =======================================
7:209  0:000  VideoCard devID=0x67DF1002
7:209  0:000  DisplayADR1[0] = 0x30000, DisplayADR2[0] = 0x0
7:209  0:000  USBADR[0] = 0x1A0000 and PCIe = 0xFFFE
7:209  0:000  USBADR[1] = 0x1A0001 and PCIe = 0xFFFE
7:209  0:000  USBADR[2] = 0x1A0002 and PCIe = 0xFFFE
7:209  0:000  USBADR[3] = 0x1A0007 and PCIe = 0xFFFE
7:209  0:000  USBADR[4] = 0x1D0000 and PCIe = 0xFFFE
7:209  0:000  USBADR[5] = 0x1D0001 and PCIe = 0xFFFE
7:209  0:000  USBADR[6] = 0x1D0002 and PCIe = 0xFFFE
7:209  0:000  USBADR[7] = 0x1D0007 and PCIe = 0xFFFE
7:210  0:000  first CPU found at 40FF offset 4102
7:210  0:000  slash found
7:210  0:000  Found ACPI CPU: CPU0 | CPU1 | CPU2 | CPU3 | CPU4 | CPU5 | CPU6 | CPU7 | CPU8 | CPU9 | CPUA | CPUB | CPUC | CPUD | CPUE | CPUF | CPUG | CPUH | CPUI | CPUJ | CPUK | CPUL | CPUM | CPUN Invalid character found in ProcessorOP 0xFFFFFFF0!
7:210  0:000  , within the score: _PR_
7:210  0:000  Found PCIROOTUID = 0
7:210  0:000  Start RTC Fix
7:210  0:000  found RTC had IRQNoFlag will move -3 bytes
7:210  0:000  ...len=AB53
7:210  0:000  new size written to 336E shift=0 len=AB53
7:210  0:000  len after correct outers AB53
7:210  0:000  Start TMR Fix
7:210  0:000  Start PIC Fix
7:210  0:000  PIC size=33 at 32A7
7:210  0:000  found PIC had IRQNoFlag will move -3 bytes
7:210  0:000  Fix Device PIC size -3
7:210  0:000  Start HPET Fix
7:211  0:000  Start Display0 Fix
7:211  0:000  Found internal video device 0 @1746
7:211  0:000  Skipping Method(_DSM) for 1002 card
7:211  0:000  now inserting Video device
7:211  0:000  ... into existing bridge
7:211  0:000  patch Display #0 of Vendor=0x1002
7:211  0:000  Start NetWork Fix
7:211  0:000  found NetWork device [0x001C0005:0] at 1D00 and Name is BRCM
7:211  0:000  NetworkADR1=1C0005 NetworkADR2=0
7:211  0:000  network DSM created, size=5C
7:211  0:000  Start Add IMEI
7:211  0:000  Start USB Fix
7:211  0:000  USB bridge[1A0000] at 1E8C, size = 4E
7:211  0:000  USB bridge[1A0001] at 1F42, size = 4E
7:211  0:000  USB bridge[1A0002] at 1FF8, size = 4E
7:211  0:000  USB bridge[1A0007] at 20FE, size = 4E
7:212  0:000  USB bridge[1D0000] at 1D9C, size = 4E
7:212  0:000  USB bridge[1D0001] at 1E52, size = 4E
7:212  0:000  USB bridge[1D0002] at 1F08, size = 4E
7:212  0:000  USB bridge[1D0007] at 21E0, size = 4E
7:212  0:000  Start _WAK Return Fix
7:212  0:000  _WAK Method need return data, will patch it.
7:212  0:000  return len=AF70
7:212  0:000   deleting device CRT_
7:212  0:000   deleting device DVI_
7:212  0:000   deleting device SPKR
7:212  0:000   deleting device ECP_
7:213  0:000   deleting device LPT_
7:213  0:000   deleting device FDC0
7:213  0:000   deleting device ECP1
7:213  0:000   deleting device LPT1
7:213  0:000  Start PNLF Fix
7:214  0:000  found PWRB at 3CF3
7:214  0:000  Start _S3D Fix
7:214  0:000  Start ADP1 fix
7:214  0:000  no device(AC) exists
7:214  0:000  Start SHUTDOWN Fix len=AF7C
7:214  0:000  PreCleanup XSDT: count=9, length=108
7:214  0:000  PreCleanup XSDT, corrected XSDT: count=9, length=108
7:214  0:000  === [ ACPIDropTables ] ====================================
7:214  0:000  Drop tables from XSDT, SIGN=DMAR TableID=TYLSBURG Length=440
7:214  0:000   Table[7]: DMAR  TYLSBURG  440 dropped
7:214  0:000  === [ PatchAllSSDT ] ======================================
7:214  0:000  Out of control with CPU numbers
7:214  0:000  CPUBase=0 and ApicCPUBase=1 ApicCPUNum=12
7:214  0:000  Maximum control=0x1A
7:214  0:000  Turbo control=0x1C
7:214  0:000  P-States: min 0xC, max 0x1C
7:214  0:000  SSDT with CPU P-States generated successfully
7:214  0:000  SSDT with CPU C-States generated successfully
7:214  0:000  Cleanup XSDT: count=11, length=124
7:214  0:000  corrected XSDT count=10, length=116
7:214  0:000  === [ RestSetup macOS ] ===================================
7:214  0:000  EdidDiscovered size=128
7:214  0:000  ---Discovered EDID Table size:128
7:214  0:000  000  |  00  FF  FF  FF  FF  FF  FF  00  04  69
7:214  0:000  010  |  A3  26  1D  0B  00  00  06  13  01  03
7:214  0:000  020  |  80  37  22  78  2A  CB  D0  A3  5A  49
7:214  0:000  030  |  A0  24  13  50  54  BF  EF  00  71  4F
7:214  0:000  040  |  01  01  81  40  81  80  95  00  B3  00
7:214  0:000  050  |  01  01  01  01  28  3C  80  A0  70  B0
7:214  0:000  060  |  23  40  30  20  36  00  26  54  21  00
7:214  0:000  070  |  00  1A  00  00  00  FF  00  39  31  4C
7:214  0:000  080  |  4D  54  43  30  30  32  38  34  35  0A
7:214  0:000  090  |  00  00  00  FD  00  32  4B  1E  55  11
7:214  0:000  100  |  00  0A  20  20  20  20  20  20  00  00
7:214  0:000  110  |  00  FC  00  41  53  55  53  20  56  4B
7:214  0:000  120  |  32  36  36  48  0A  20  01  4C
7:214  0:000  --- Patched EDID size:128
7:214  0:000  000  |  00  FF  FF  FF  FF  FF  FF  00  04  69
7:214  0:000  010  |  A3  26  1D  0B  00  00  06  13  01  03
7:214  0:000  020  |  80  37  22  78  2A  CB  D0  A3  5A  49
7:214  0:000  030  |  A0  24  13  50  54  BF  EF  00  71  4F
7:214  0:000  040  |  01  01  81  40  81  80  95  00  B3  00
7:214  0:000  050  |  01  01  01  01  28  3C  80  A0  70  B0
7:214  0:000  060  |  23  40  30  20  36  00  26  54  21  00
7:214  0:000  070  |  00  1A  00  00  00  FF  00  39  31  4C
7:214  0:000  080  |  4D  54  43  30  30  32  38  34  35  0A
7:214  0:000  090  |  00  00  00  FD  00  32  4B  1E  55  11
7:214  0:000  100  |  00  0A  20  20  20  20  20  20  00  00
7:214  0:000  110  |  00  FC  00  41  53  55  53  20  56  4B
7:214  0:000  120  |  32  36  36  48  0A  20  01  4C
7:214  0:000  ATI injection not set
7:214  0:000  Device 0 deinited
7:215  0:000  stringlength = 2736
7:215  0:000  CurrentMode: Width=1920 Height=1200
7:215  0:000  Beginning FSInjection
FSInjectionInstall ...
- Our FSI_SIMPLE_FILE_SYSTEM_PROTOCOL installed on handle: CCA1F618
FSInjectionInstall ...
- Our FSI_SIMPLE_FILE_SYSTEM_PROTOCOL installed on handle: CCA1F618
7:215  0:000  Use origin smbios table type 1 guid.
7:216  0:000  Preparing kexts injection for arch=x86_64 from EFI\CLOVER\kexts\Other
7:216  0:000  Extra kext: EFI\CLOVER\kexts\Other\Lilu.kext (v.1.2.2)
7:255  0:039  Extra kext: EFI\CLOVER\kexts\Other\WhateverGreen.kext (v.1.1.4)
7:308  0:052  Extra kext: EFI\CLOVER\kexts\Other\IOAHCIBlockStorageInjector_v1.0.0_Micky1979.kext (v.1.0.0)
7:335  0:026  Extra kext: EFI\CLOVER\kexts\Other\AHCIPortInjector_v1.0.0_Micky1979.kext (v.1.0.0)
7:368  0:033  Preparing kexts injection for arch=x86_64 from EFI\CLOVER\kexts\10.13
7:369  0:000  Custom boot screen not used because entry has unset use graphics
Link to comment
Share on other sites
Pavo
Pavo
Posted
Posted

Ok, some more details about my setup.

I tried with an HDMI cable but it made no difference. If I connect both with DVI and HDMI the two screens are detected perfectly in OSX and I can see them through screen sharing.

Screen is detected, resolution is correct, etc. but the screen is black. (though it is active, the screen does not go to sleep or turn off)

OS: 10.13.3

Clover: 4392

LILU: 1.2.2

Whatevergreen: 1.1.4



My system:

HP Z800 motherboard, Xeon X5690 cpu, 48GB ECC RAM

PCIe2 slot0: x4, holds Samsung 950 PRO nvme boot drive. (EFI/Clover is on a USB stick since the Z800 won't load the ahci option rom from the nvme drive)

PCIe2 slot1: x16, ASUS ROG STRIX RX 580 TOP https://www.asus.com/us/Graphics-Cards/ROG-STRIX-RX580-T8G-GAMING/overview/

PCIe2 slot2: x4, empty

PCIe2 slot3: x8, empty

PCIe2 slot4: x16, empty (would normally hold an Intel 520 DA1 10GbE card)

PCI32 slot5: empty

PCIe2 slot6: x8, empty (would normally hold USB 3 card based on FL1100)



Here's a zip of my EFI folder:

https://www.dropbox.com/s/hhcryzaig2nm3pi/EFI-robertr-2018-01-30.zip?dl=0



Please tell me what more info I would need to supply, logs, etc.

If this is the wrong thread/forum, please excuse me and tell me where to post.

Cheers!







Boot log:

0:100  0:100  MemLog inited, TSC freq: 3463264042
0:100  0:000  CPU was calibrated with ACPI PM Timer
0:100  0:000  LegacyRegion2: Chipset/proc: 0x34068086
0:100  0:000   Core i7 processors (PAM 0x40-0x47)
0:100  0:000   Test PAM1=(0x41=11, 0x5a=00, 0x81=0C, 0x91=C2) at chipset 34068086
0:100  0:000  , Install = Success
0:109  0:009  BiosVideoDriverBindingStart!
0:109  0:000  BiosVideoCheckForVbe
0:109  0:000  EdidOverride not found
0:115  0:006   Edid1+
0:115  0:000   found Detail Timing 1920x1200
0:121  0:006   Edid0+
0:121  0:000   found Detail Timing 1920x1200
0:121  0:000  ... already present
0:125  0:003     0 1280x960 attr=BB - ok, edid+, working, highest, pref=0
0:125  0:000     1 640x480 attr=BB - ok, edid+, 640x480, working
0:126  0:000     2 800x600 attr=BB - ok, edid+, 800x600, working
0:126  0:000     3 1024x768 attr=BB - ok, edid+, 1024x768, working
0:127  0:000     4 1280x1024 attr=BB - ok, edid+, working, highest, pref=4
0:128  0:001     5 1400x1050 attr=BB - ok, edid-
0:130  0:001     6 1600x1200 attr=BB - ok, edid-
0:132  0:001     7 1920x1200 attr=BB - ok, edid+, working, highest, pref=7
0:132  0:000  BV new mode: 7 1920x1200
0:165  0:032   SetMode pref 7 (7) = Success
2:854  2:688
2:854  0:000  Now is 30.1.2018,  11:19:46 (GMT)
2:854  0:000  Starting Clover revision: 4392 on CLOVER EFI
2:854  0:000  Build with: [Args: -D NO_GRUB_DRIVERS_EMBEDDED -t XCODE8 | -D NO_GRUB_DRIVERS_EMBEDDED -D USE_LOW_EBDA -a X64 -b RELEASE -t XCODE8 -n 5 | OS: 10.12.6 | XCODE: 9.2]
2:854  0:000  SelfDevicePath=PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000) @CCEC4318
2:854  0:000  SelfDirPath = \EFI\CLOVER
2:854  0:000  === [ Get Smbios ] ========================================
2:854  0:000  Type 16 Index = 0
2:854  0:000  Type 16 Index = 1
2:854  0:000  Type 16 Index = 2
2:854  0:000  Total Memory Slots Count = 13
2:854  0:000  Type 17 Index = 0
2:854  0:000  SmbiosTable.Type17->Speed = 1333MHz
2:854  0:000  SmbiosTable.Type17->Size = 8192MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU0 DIMM1
2:854  0:000  SmbiosTable.Type17->Vendor = JEDEC ID:83 0B
2:854  0:000  SmbiosTable.Type17->SerialNumber = 290CB579
2:854  0:000  SmbiosTable.Type17->PartNumber = NT8GC72C4NB3NK-CG
2:854  0:000  Type 17 Index = 1
2:854  0:000  SmbiosTable.Type17->Speed = 1333MHz
2:854  0:000  SmbiosTable.Type17->Size = 8192MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU0 DIMM2
2:854  0:000  SmbiosTable.Type17->Vendor = JEDEC ID:83 0B
2:854  0:000  SmbiosTable.Type17->SerialNumber = 260E2E1B
2:854  0:000  SmbiosTable.Type17->PartNumber = NT8GC72C4NB3NK-CG
2:854  0:000  Type 17 Index = 2
2:854  0:000  SmbiosTable.Type17->Speed = 1333MHz
2:854  0:000  SmbiosTable.Type17->Size = 8192MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU0 DIMM3
2:854  0:000  SmbiosTable.Type17->Vendor = JEDEC ID:83 0B
2:854  0:000  SmbiosTable.Type17->SerialNumber = 0114A541
2:854  0:000  SmbiosTable.Type17->PartNumber = NT8GC72C4NB3NK-CG
2:854  0:000  Type 17 Index = 3
2:854  0:000  SmbiosTable.Type17->Speed = 1333MHz
2:854  0:000  SmbiosTable.Type17->Size = 8192MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU0 DIMM4
2:854  0:000  SmbiosTable.Type17->Vendor = JEDEC ID:83 0B
2:854  0:000  SmbiosTable.Type17->SerialNumber = 260E43E0
2:854  0:000  SmbiosTable.Type17->PartNumber = NT8GC72C4NB3NK-CG
2:854  0:000  Type 17 Index = 4
2:854  0:000  SmbiosTable.Type17->Speed = 1333MHz
2:854  0:000  SmbiosTable.Type17->Size = 8192MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU0 DIMM5
2:854  0:000  SmbiosTable.Type17->Vendor = JEDEC ID:83 0B
2:854  0:000  SmbiosTable.Type17->SerialNumber = 2A0E2C9E
2:854  0:000  SmbiosTable.Type17->PartNumber = NT8GC72C4NB3NK-CG
2:854  0:000  Type 17 Index = 5
2:854  0:000  SmbiosTable.Type17->Speed = 1333MHz
2:854  0:000  SmbiosTable.Type17->Size = 8192MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU0 DIMM6
2:854  0:000  SmbiosTable.Type17->Vendor = JEDEC ID:83 0B
2:854  0:000  SmbiosTable.Type17->SerialNumber = 0114E5EA
2:854  0:000  SmbiosTable.Type17->PartNumber = NT8GC72C4NB3NK-CG
2:854  0:000  Type 17 Index = 6
2:854  0:000  Ignoring insane frequency value 0MHz
2:854  0:000  SmbiosTable.Type17->Speed = 0MHz
2:854  0:000  SmbiosTable.Type17->Size = 0MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU1 DIMM1
2:854  0:000  SmbiosTable.Type17->Vendor = <null string>
2:854  0:000  SmbiosTable.Type17->SerialNumber = <null string>
2:854  0:000  SmbiosTable.Type17->PartNumber = <null string>
2:854  0:000  Type 17 Index = 7
2:854  0:000  Ignoring insane frequency value 0MHz
2:854  0:000  SmbiosTable.Type17->Speed = 0MHz
2:854  0:000  SmbiosTable.Type17->Size = 0MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU1 DIMM2
2:854  0:000  SmbiosTable.Type17->Vendor = <null string>
2:854  0:000  SmbiosTable.Type17->SerialNumber = <null string>
2:854  0:000  SmbiosTable.Type17->PartNumber = <null string>
2:854  0:000  Type 17 Index = 8
2:854  0:000  Ignoring insane frequency value 0MHz
2:854  0:000  SmbiosTable.Type17->Speed = 0MHz
2:854  0:000  SmbiosTable.Type17->Size = 0MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU1 DIMM3
2:854  0:000  SmbiosTable.Type17->Vendor = <null string>
2:854  0:000  SmbiosTable.Type17->SerialNumber = <null string>
2:854  0:000  SmbiosTable.Type17->PartNumber = <null string>
2:854  0:000  Type 17 Index = 9
2:854  0:000  Ignoring insane frequency value 0MHz
2:854  0:000  SmbiosTable.Type17->Speed = 0MHz
2:854  0:000  SmbiosTable.Type17->Size = 0MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU1 DIMM4
2:854  0:000  SmbiosTable.Type17->Vendor = <null string>
2:854  0:000  SmbiosTable.Type17->SerialNumber = <null string>
2:854  0:000  SmbiosTable.Type17->PartNumber = <null string>
2:854  0:000  Type 17 Index = 10
2:854  0:000  Ignoring insane frequency value 0MHz
2:854  0:000  SmbiosTable.Type17->Speed = 0MHz
2:854  0:000  SmbiosTable.Type17->Size = 0MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU1 DIMM5
2:854  0:000  SmbiosTable.Type17->Vendor = <null string>
2:854  0:000  SmbiosTable.Type17->SerialNumber = <null string>
2:854  0:000  SmbiosTable.Type17->PartNumber = <null string>
2:854  0:000  Type 17 Index = 11
2:854  0:000  Ignoring insane frequency value 0MHz
2:854  0:000  SmbiosTable.Type17->Speed = 0MHz
2:854  0:000  SmbiosTable.Type17->Size = 0MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  CPU1 DIMM6
2:854  0:000  SmbiosTable.Type17->Vendor = <null string>
2:854  0:000  SmbiosTable.Type17->SerialNumber = <null string>
2:854  0:000  SmbiosTable.Type17->PartNumber = <null string>
2:854  0:000  Type 17 Index = 12
2:854  0:000  Ignoring insane frequency value 0MHz
2:854  0:000  SmbiosTable.Type17->Speed = 0MHz
2:854  0:000  SmbiosTable.Type17->Size = 34816MB
2:854  0:000  SmbiosTable.Type17->Bank/Device =  SYSTEM ROM
2:854  0:000  SmbiosTable.Type17->Vendor =
2:854  0:000  SmbiosTable.Type17->SerialNumber =
2:854  0:000  SmbiosTable.Type17->PartNumber =
2:854  0:000  Boot status=0
2:854  0:000  Running on: 'HP Z800 Workstation' with board '0AECh'
2:854  0:000  === [ GetCPUProperties ] ==================================
2:854  0:000  CPU Vendor = 756E6547 Model=206C2
2:854  0:000   The CPU supported SSE4.1
2:854  0:000  BrandString = Intel(R) Xeon(R) CPU           X5690  @ 3.47GHz
2:854  0:000   The CPU supported turbo
2:854  0:000  FSBFrequency = 134 MHz, DMI FSBFrequency = 6400 MHz, Corrected FSBFrequency = 133 MHz
2:854  0:000  MaxDiv/MinDiv: 26.0/12
2:854  0:000  Turbo: 27/27/28/28
2:854  0:000  Features: 0xBFEBFBFF
2:854  0:000  Threads: 12
2:854  0:000  Cores: 6
2:854  0:000  FSB: 133 MHz
2:854  0:000  CPU: 3466 MHz
2:854  0:000  TSC: 3466 MHz
2:854  0:000  PIS: 533 MHz
2:854  0:000  ExternalClock: 133 MHz
2:854  0:000  === [ GetDevices ] ========================================
2:854  0:000  PCI (00|00:00.00) : 8086 3406 class=060000
2:854  0:000  PCI (00|00:01.00) : 8086 3408 class=060400
2:854  0:000  PCI (00|03:00.00) : 144D A802 class=010802
2:854  0:000  PCI (00|00:03.00) : 8086 340A class=060400
2:854  0:000  PCI (00|0F:00.00) : 1002 67DF class=030000
2:854  0:000   - GFX: Model=AMD Radeon RX 480 (ATI/AMD)
2:854  0:000  PCI (00|0F:00.01) : 1002 AAF0 class=040300
2:854  0:000   - HDMI Audio:
2:854  0:000  PCI (00|00:07.00) : 8086 340E class=060400
2:854  0:000  PCI (00|00:10.00) : 8086 3425 class=080000
2:854  0:000  PCI (00|00:10.01) : 8086 3426 class=080000
2:854  0:000  PCI (00|00:11.00) : 8086 3427 class=080000
2:854  0:000  PCI (00|00:11.01) : 8086 3428 class=080000
2:854  0:000  PCI (00|00:14.00) : 8086 342E class=080000
2:854  0:000  PCI (00|00:14.01) : 8086 3422 class=080000
2:854  0:000  PCI (00|00:14.02) : 8086 3423 class=080000
2:854  0:000  PCI (00|00:15.00) : 8086 342F class=080020
2:854  0:000  PCI (00|00:1A.00) : 8086 3A37 class=0C0300
2:854  0:000  PCI (00|00:1A.01) : 8086 3A38 class=0C0300
2:854  0:000  PCI (00|00:1A.02) : 8086 3A39 class=0C0300
2:854  0:000  PCI (00|00:1A.07) : 8086 3A3C class=0C0320
2:855  0:000  PCI (00|00:1B.00) : 8086 3A3E class=040300
2:855  0:000  PCI (00|00:1C.00) : 8086 3A40 class=060400
2:855  0:000  PCI (00|00:1C.04) : 8086 3A48 class=060400
2:855  0:000  PCI (00|02:00.00) : 14E4 1684 class=020000
2:855  0:000   - LAN: 0 Vendor=Broadcom
2:855  0:000  PCI (00|00:1C.05) : 8086 3A4A class=060400
2:855  0:000  PCI (00|01:00.00) : 14E4 1684 class=020000
2:855  0:000   - LAN: 1 Vendor=Broadcom
2:855  0:000  PCI (00|00:1D.00) : 8086 3A34 class=0C0300
2:855  0:000  PCI (00|00:1D.01) : 8086 3A35 class=0C0300
2:855  0:000  PCI (00|00:1D.02) : 8086 3A36 class=0C0300
2:855  0:000  PCI (00|00:1D.07) : 8086 3A3A class=0C0320
2:855  0:000  PCI (00|00:1E.00) : 8086 244E class=060401
2:855  0:000  PCI (00|37:09.00) : 11C1 5811 class=0C0010
2:855  0:000  PCI (00|00:1F.00) : 8086 3A16 class=060100
2:855  0:000  PCI (00|00:1F.02) : 8086 2822 class=010400
2:855  0:000  PCI (00|40:03.00) : 8086 340A class=060400
2:855  0:000  PCI (00|40:07.00) : 8086 340E class=060400
2:855  0:000  PCI (00|40:09.00) : 8086 3410 class=060400
2:855  0:000  PCI (00|41:00.00) : 1000 0058 class=010000
2:855  0:000  PCI (00|40:10.00) : 8086 3425 class=080000
2:855  0:000  PCI (00|40:10.01) : 8086 3426 class=080000
2:855  0:000  PCI (00|40:11.00) : 8086 3427 class=080000
2:855  0:000  PCI (00|40:11.01) : 8086 3428 class=080000
2:855  0:000  PCI (00|40:14.00) : 8086 342E class=080000
2:855  0:000  PCI (00|40:14.01) : 8086 3422 class=080000
2:855  0:000  PCI (00|40:14.02) : 8086 3423 class=080000
2:855  0:000  PCI (00|40:15.00) : 8086 342F class=080020
2:855  0:000  PCI (00|7F:00.00) : 8086 2C70 class=060000
2:855  0:000  PCI (00|7F:00.01) : 8086 2D81 class=060000
2:855  0:000  PCI (00|7F:02.00) : 8086 2D90 class=060000
2:855  0:000  PCI (00|7F:02.01) : 8086 2D91 class=060000
2:855  0:000  PCI (00|7F:02.02) : 8086 2D92 class=060000
2:855  0:000  PCI (00|7F:02.03) : 8086 2D93 class=060000
2:855  0:000  PCI (00|7F:02.04) : 8086 2D94 class=060000
2:855  0:000  PCI (00|7F:02.05) : 8086 2D95 class=060000
2:855  0:000  PCI (00|7F:03.00) : 8086 2D98 class=060000
2:855  0:000  PCI (00|7F:03.01) : 8086 2D99 class=060000
2:855  0:000  PCI (00|7F:03.02) : 8086 2D9A class=060000
2:855  0:000  PCI (00|7F:03.04) : 8086 2D9C class=060000
2:855  0:000  PCI (00|7F:04.00) : 8086 2DA0 class=060000
2:855  0:000  PCI (00|7F:04.01) : 8086 2DA1 class=060000
2:855  0:000  PCI (00|7F:04.02) : 8086 2DA2 class=060000
2:855  0:000  PCI (00|7F:04.03) : 8086 2DA3 class=060000
2:855  0:000  PCI (00|7F:05.00) : 8086 2DA8 class=060000
2:855  0:000  PCI (00|7F:05.01) : 8086 2DA9 class=060000
2:855  0:000  PCI (00|7F:05.02) : 8086 2DAA class=060000
2:855  0:000  PCI (00|7F:05.03) : 8086 2DAB class=060000
2:855  0:000  PCI (00|7F:06.00) : 8086 2DB0 class=060000
2:855  0:000  PCI (00|7F:06.01) : 8086 2DB1 class=060000
2:855  0:000  PCI (00|7F:06.02) : 8086 2DB2 class=060000
2:855  0:000  PCI (00|7F:06.03) : 8086 2DB3 class=060000
2:855  0:000  === [ GetDefaultSettings ] ================================
2:855  0:000  Clover load options size = 0 bytes
2:907  0:051  EFI\CLOVER\config.plist loaded: Success
2:907  0:000  === [ GetListOfThemes ] ===================================
2:932  0:025  - [00]: embedded
2:945  0:012  - [00]: metal
2:997  0:051  - [01]: random
3:010  0:013  - [01]: applestyle
3:061  0:051  - [02]: newyear
3:074  0:012  - [03]: christmas
3:100  0:025  === [ Found config plists ] ===============================
3:100  0:000  - config.plist
3:126  0:025  - config-stripped-acpi.plist
3:126  0:000  - configOldHack.plist
3:139  0:012  - configNewTry.plist
3:139  0:000  === [ GetEarlyUserSettings ] ==============================
3:139  0:000  timeout set to 1
3:139  0:000  Custom boot CUSTOM_BOOT_DISABLED (0x0)
3:139  0:000  KextsToPatch: 1 requested
3:139  0:000   - [00]: AppleAHCIPort (External icons patch) :: BinPatch :: data len: 8
3:139  0:000  Default theme: applestyle
3:139  0:000  Hiding entries with string BOOTX64.EFI
3:139  0:000  === [ LoadDrivers ] =======================================
3:165  0:025  Loading AppleImageCodec-64.efi  status=Success
3:178  0:013  Loading AppleKeyAggregator-64.efi  status=Success
3:178  0:000  Loading AppleUITheme-64.efi  status=Success
3:178  0:000  Loading FirmwareVolume-64.efi  status=Success
3:191  0:013  Loading FSInject-64.efi  status=Success
3:191  0:000  Loading GrubEXFAT-64.efi  status=Success
3:204  0:013   - driver needs connecting
3:204  0:000  Loading apfs.efi  status=Success
3:264  0:059   - driver needs connecting
3:264  0:000  Loading zfs_x64.efi  status=Success
3:277  0:013   - driver needs connecting
3:277  0:000  Loading GrubISO9660-64.efi  status=Success
3:290  0:013   - driver needs connecting
3:290  0:000  Loading GrubNTFS-64.efi  status=Success
3:303  0:013   - driver needs connecting
3:303  0:000  Loading GrubUDF-64.efi  status=Success
3:303  0:000   - driver needs connecting
3:303  0:000  Loading NvmExpressDxe-64.efi  status=Success
3:316  0:013   - driver needs connecting
3:316  0:000  Loading SMCHelper-64.efi  status=Success
3:316  0:000  Loading XhciDxe-64.efi  status=Success
3:329  0:013   - driver needs connecting
3:329  0:000  8 drivers needs connecting ...
3:329  0:000  PlatformDriverOverrideProtocol->GetDriver overriden
3:329  0:000  APFS driver loaded
3:752  0:422  === [ InitScreen ] ========================================
3:752  0:000  SetScreenResolution: 1920x1200 - already set
3:752  0:000  Console modes reported: 4, available modes:
3:752  0:000   - [01]: 80x25
3:752  0:000   - [02]: 80x50
3:752  0:000   - [03]: 100x31
3:752  0:000   - [04]: 240x63 (current mode)
3:752  0:000  SetScreenResolution: 1920x1200 - already set
3:752  0:000  reinit: self device path=PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)
3:753  0:000  Using embedded font: Success
3:756  0:003  === [ GetMacAddress ] =====================================
3:756  0:000  === [ ScanSPD ] ===========================================
3:757  0:000  === [ GetAcpiTablesList ] =================================
3:757  0:000  Get Acpi Tables List from RSDT:
3:757  0:000   - [00]: FACP  TYLSBURG len=116
3:757  0:000   - [01]: APIC  TYLSBURG len=404
3:757  0:000   - [02]: ASF!  TYLSBURG len=99
3:757  0:000   - [03]: MCFG  TYLSBURG len=60
3:757  0:000   - [04]: TCPA  TYLSBURG len=50
3:757  0:000   - [05]: SLIC  SLIC-WKS len=374
3:757  0:000   - [06]: HPET  TYLSBURG len=56
3:757  0:000   - [07]: DMAR  TYLSBURG len=440
3:757  0:000   - [08]: SSDT  PPM RCM  len=16308
3:757  0:000  Calibrated TSC Frequency = 3463264042 = 3463MHz
3:757  0:000  === [ GetUserSettings ] ===================================
3:757  0:000  USB FixOwnership: yes
3:757  0:000  Dropping 3 tables:
3:757  0:000   - [00]: Drop table  signature="SSDT" (54445353) table-id="Cpu0Ist" (0074734930757043)
3:757  0:000           - set table: 54445353,   74734930757043 to drop: no
3:757  0:000   - [01]: Drop table  signature="DMAR" (52414D44)
3:757  0:000           - set table: 52414D44,                0 to drop: yes
3:757  0:000   - [02]: Drop table  signature="SSDT" (54445353) table-id="CpuPm" (0000006D50757043)
3:757  0:000           - set table: 54445353,       6D50757043 to drop: no
3:757  0:000   - final DSDT Fix mask=17EE3155
3:757  0:000  EnableC6: yes
3:758  0:000  Using ProductName from config
3:758  0:000  ProductName: MacPro5,1
3:758  0:000  Using latest BiosVersion from clover
3:758  0:000  BiosVersion: MP51.88Z.0084.B00.1708080528
3:758  0:000  BiosReleaseDate: 08/08/17
3:758  0:000  Using FirmwareFeatures from clover: 0xE80FE137
3:758  0:000  Using FirmwareFeaturesMask from clover: 0xFF1FFF3F
3:758  0:000  PlatformFeature will not set in SMBIOS
3:758  0:000  Board-ID set from config as Mac-F221BEC8
3:758  0:000  BoardType: 0xB
3:758  0:000  ChassisType: 0x6
3:758  0:000  Converted CustomUUID 105304E0-287D-5B10-9B59-BA6DA25A2CDD
3:758  0:000  QPI: use Table 132
3:938  0:180  === [ ScanVolumes ] =======================================
3:938  0:000  Found 7 volumes with blockIO
3:938  0:000  - [00]: Volume: PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)
3:949  0:011          Result of bootcode detection: bootable unknown (legacy)
3:949  0:000          USB volume
3:949  0:000  - [01]: Volume: PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)
3:961  0:011          Result of bootcode detection: bootable unknown (legacy)
3:961  0:000          USB volume
3:961  0:000          This is SelfVolume !!
3:961  0:000  - [02]: Volume: PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)
3:972  0:011          USB volume
3:972  0:000  - [03]: Volume: PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)
3:972  0:000          Result of bootcode detection: bootable unknown (legacy)
3:972  0:000  - [04]: Volume: PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)
3:972  0:000          Result of bootcode detection: bootable unknown (legacy)
3:973  0:000  - [05]: Volume: PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)
3:973  0:000  - [06]: Volume: PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)
4:008  0:035  Loading nvram.plist from Vol 'EFI' - loaded, size=3677
4:037  0:028  === [ PutNvramPlistToRtVars ] =============================
4:037  0:000   Adding Key: Clover.BackupDirOnDestVol: Size = 3, Data: 59 65 73
4:037  0:000   Adding Key: Clover.KeepBackupLimit: Size = 1, Data: 35
4:037  0:000   Adding Key: Clover.LogEveryBoot: Size = 2, Data: 31 30
4:037  0:000   Adding Key: Clover.LogLineCount: Size = 3, Data: 34 30 30
4:037  0:000   Adding Key: Clover.Theme: Size = 10, Data: 61 70 70 6C 65 73 74 79 6C 65
4:037  0:000   Adding Key: EFILoginHiDPI: Size = 4, Data: 00 00 00 00
4:037  0:000   Adding Key: SystemAudioVolume: Size = 1, Data: 80
4:037  0:000   Adding Key: SystemAudioVolumeDB: Size = 1, Data: 43
4:037  0:000   Adding Key: bluetoothActiveControllerInfo: Size = 16, Data: 01 00 12 0A 00 00 00 00 10 1D 00 15 83 36 99 9B
4:037  0:000   Adding Key: bootercfg: Size = 2, Data: 28 00
4:037  0:000   Adding Key: csr-active-config: Size = 4, Data: 67 00 00 00
4:037  0:000   Adding Key: fakesmc-key-#KEY-ui32: Size = 4, Data: 00 00 00 16
4:037  0:000   Adding Key: fakesmc-key-$Adr-ui32: Size = 4, Data: 00 00 03 00
4:037  0:000   Adding Key: fakesmc-key-$Num-ui8: Size = 1, Data: 01
4:037  0:000   Adding Key: fakesmc-key-$Num-ui8 : Size = 1, Data: 01
4:037  0:000   Adding Key: fakesmc-key-BATP-flag: Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-BEMB-flag: Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-BNum-ui8: Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-BNum-ui8 : Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-EPCI-ui32: Size = 4, Data: 02 C0 07 00
4:037  0:000   Adding Key: fakesmc-key-MSAc-ui16: Size = 2, Data: 00 00
4:037  0:000   Adding Key: fakesmc-key-MSFW-ui8: Size = 2, Data: 01 00
4:037  0:000   Adding Key: fakesmc-key-MSLD-ui8: Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-MSLD-ui8 : Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-MSPS-ui16: Size = 2, Data: 00 03
4:037  0:000   Adding Key: fakesmc-key-MSTc-ui8: Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-MSTc-ui8 : Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-MSWr-ui8: Size = 1, Data: 00
4:037  0:000   Adding Key: fakesmc-key-MSWr-ui8 : Size = 1, Data: 19
4:037  0:000   Adding Key: fakesmc-key-RBr -ch8*: Size = 8, Data: 6B 35 00 00 00 00 00 00
4:037  0:000   Adding Key: fakesmc-key-REV -ch8*: Size = 6, Data: 01 39 0F 00 00 11
4:037  0:000   Adding Key: fakesmc-key-RMde-char: Size = 1, Data: 41
4:037  0:000   Adding Key: fakesmc-key-RPlt-ch8*: Size = 8, Data: 6B 35 00 00 00 00 00 00
4:037  0:000   Adding Key: flagstate: Size = 32, Data: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
4:037  0:000   Adding Key: fmm-computer-name: Size = 15, Data: 52 6F 62 65 72 74 73 20 4D 61 63 20 50 72 6F
4:037  0:000   Adding Key: fmm-mobileme-token-FMM: Size = 605, Data: 62 70 6C 69 73 74 30 30 D9 01 02 03 04 05 06 07 08 09 0A 0B 16 17 18 19 1A 1B 1C 56 75 73 65 72 69 64 5F 10 13 64 61 74 61 63 6C 61 73 73 50 72 6F 70 65 72 74 69 65 73 59 61 75 74 68 54 6F 6B 65 6E 58 70 65 72 73 6F 6E 49 44 58 75 73 65 72 6E 61 6D 65 57 61 64 64 54 69 6D 65 5F 10 12 65 6E 61 62 6C 65 64 44 61 74 61 63 6C 61 73 73 65 73 54 67 75 69 64 58 75 73 65 72 49 6E 66 6F 11 01 F5 D1 0C 0D 5F 10 21 63 6F 6D 2E 61 70 70 6C 65 2E 44 61 74 61 63 6C 61 73 73 2E 44 65 76 69 63 65 4C 6F 63 61 74 6F 72 D4 0E 0F 10 11 12 13 14 15 56 61 70 73 45 6E 76 58 68 6F 73 74 6E 61 6D 65 5D 61 75 74 68 4D 65 63 68 61 6E 69 73 6D 56 73 63 68 65 6D 65 5A 50 72 6F 64 75 63 74 69 6F 6E 5F 10 13 70 32 36 2D 66 6D 69 70 2E 69 63 6C 6F 75 64 2E 63 6F 6D 55 74 6F 6B 65 6E 55 68 74 74 70 73 5F 10 28 41 51 41 41 41 41 42 57 4A 6D 61 72 43 6A 6A 5A 4D 74 6E 33 6C 51 34 4D 38 34 5F 39 39 6B 6B 66 71 4D 4E 43 4A 37 49 7E 59 31 37 34 35 32 31 32 31 33 5F 10 13 72 6F 62 65 72 74 40 72 65 68 6E 6D 61 72 6B 2E 6E 65 74 23 41 D5 89 99 AB D8 5F DD A1 0C 5F 10 24 38 33 32 46 39 46 35 44 2D 45 38 41 46 2D 34 33 31 38 2D 39 36 46 31 2D 41 33 36 43 38 34 36 41 35 46 46 33 D3 1D 1E 1F 20 21 22 5F 10 15 49 6E 55 73 65 4F 77 6E 65 72 44 69 73 70 6C 61 79 4E 61 6D 65 5F 10 13 49 6E 55 73 65 4F 77 6E 65 72 46 69 72 73 74 4E 61 6D 65 5F 10 12 49 6E 55 73 65 4F 77 6E 65 72 4C 61 73 74 4E 61 6D 65 5F 10 14 4B 61 72 6C 20 52 6F 62 65 72 74 20 52 65 68 6E 6D 61 72 6B 5B 4B 61 72 6C 20 52 6F 62 65 72 74 58 52 65 68 6E 6D 61 72 6B 00 08 00 1B 00 22 00 38 00 42 00 4B 00 54 00 5C 00 71 00 76 00 7F 00 82 00 85 00 A9 00 B2 00 B9 00 C2 00 D0 00 D7 00 E2 00 F8 00 FE 01 04 01 2F 01 39 01 4F 01 58 01 5A 01 81 01 88 01 A0 01 B6 01 CB 01 E2 01 EE 00 00 00 00 00 00 02 01 00 00 00 00 00 00 00 23 00 00 00 00 00 00 00 00 00 00 00 00 00 00 01 F7
4:037  0:000   Adding Key: install-product-url: Size = 73, Data: 78 2D 6F 73 70 72 6F 64 75 63 74 3A 2F 2F 43 31 33 32 35 37 33 37 2D 34 33 45 35 2D 33 38 43 35 2D 41 39 38 30 2D 32 37 34 32 30 46 43 44 45 33 35 37 2F 6D 61 63 4F 53 25 32 30 49 6E 73 74 61 6C 6C 25 32 30 44 61 74 61
4:037  0:000   Adding Key: prev-lang:kbd: Size = 7, Data: 73 76 2D 4E 4F 3A 37
4:037  0:000   Adding Key: previous-system-uuid: Size = 36, Data: 43 31 33 32 35 37 33 37 2D 34 33 45 35 2D 33 38 43 35 2D 41 39 38 30 2D 32 37 34 32 30 46 43 44 45 33 35 37
4:037  0:000   Adding Key: rc_imgsrc_info: Size = 95, Data: 62 70 6C 69 73 74 30 30 A1 01 D1 02 03 5F 10 24 31 31 36 37 32 37 34 30 2D 38 36 39 34 2D 33 37 31 30 2D 42 44 43 39 2D 45 43 42 30 38 43 42 41 36 32 30 35 56 53 53 44 31 36 30 08 0A 0D 34 00 00 00 00 00 00 01 01 00 00 00 00 00 00 00 04 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 3B
4:037  0:000   Adding Key: security-mode: String: Size = 4, Val = 'none'
4:037  0:000  === [ InitTheme ] =========================================
4:051  0:014  Using theme 'applestyle' (EFI\CLOVER\themes\applestyle)
4:051  0:000  theme applestyle defined in NVRAM found and theme.plist parsed
4:084  0:032  Loading font from ThemeDir: Success
4:084  0:000  Choosing theme applestyle
4:084  0:000  after NVRAM boot-args=-v darkwake=0 kext-dev-mode=1 rootless=0 -rad4200 -raddvi
4:084  0:000  === [ Dump SMC keys from NVRAM ] ==========================
4:084  0:000  found AppleSMC protocol
4:084  0:000  Registered 22 SMC keys
4:084  0:000  === [ AddCustomEntries ] ==================================
4:084  0:000  Custom entry 0 Title:"MacOS Update" Path:"\Mac OS X Install Data\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"70D889FE-53D9-4DD5-B8C4-860EAC5EFB98"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 0 Title:"MacOS Update" Path:"\macOS Install Data\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"70D889FE-53D9-4DD5-B8C4-860EAC5EFB98"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 0 Title:"MacOS Update" Path:"\macOS Install Data\Locked Files\Boot Files\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"70D889FE-53D9-4DD5-B8C4-860EAC5EFB98"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 0 Title:"MacOS Update" Path:"\OS X Install Data\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"70D889FE-53D9-4DD5-B8C4-860EAC5EFB98"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 0 Title:"MacOS Update" Path:"\.IABootFiles\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"70D889FE-53D9-4DD5-B8C4-860EAC5EFB98"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 1 Title:"HS Install ssd512" Path:"\Mac OS X Install Data\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"3A3EA286-E9DF-4766-8435-FE41DE63FAC7"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 1 Title:"HS Install ssd512" Path:"\macOS Install Data\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"3A3EA286-E9DF-4766-8435-FE41DE63FAC7"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 1 Title:"HS Install ssd512" Path:"\macOS Install Data\Locked Files\Boot Files\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"3A3EA286-E9DF-4766-8435-FE41DE63FAC7"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 1 Title:"HS Install ssd512" Path:"\OS X Install Data\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"3A3EA286-E9DF-4766-8435-FE41DE63FAC7"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  Custom entry 1 Title:"HS Install ssd512" Path:"\.IABootFiles\boot.efi" Options:"-nsuoff" Type:11 Flags:0x12 matching Volume:"3A3EA286-E9DF-4766-8435-FE41DE63FAC7"
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(1,GPT,D97E0C81-9A4B-43CD-BEC4-ACA749E5A50A,0x28,0x64000)) ... skipped because media is ignored
4:084  0:000      Checking volume "HackBoot" (PcieRoot(0x0)\Pci(0x1D,0x7)\USB(0x4,0x0)\HD(2,GPT,A5488874-DD5C-4BC1-AE55-D8D134F11C14,0x64028,0x3A2FFB0)) ... skipped because media is ignored
4:084  0:000      Checking volume "EFI" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(1,GPT,3DAC9625-CD4D-4F16-9AAB-3FEB2A0825F3,0x28,0x64000)) ... skipped
4:084  0:000      Checking volume "SS950" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)) ... skipped
4:084  0:000      Checking volume "Recovery HD" (PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(3,GPT,E83EB70D-9EBF-44F6-9560-0D15058E1AE2,0x3B8AB368,0x135F20)) ... skipped
4:084  0:000  === [ ScanLoader ] ========================================
4:084  0:000  - [01]: 'EFI'
4:097  0:012  - [02]: 'HackBoot'
4:097  0:000  - [04]: 'EFI'
4:098  0:000  - [05]: 'SS950'
4:099  0:001          AddLoaderEntry for Volume Name=SS950
4:101  0:002      Check if volume Is Hibernated:
4:101  0:000      Check sleep image 'by signature':
4:103  0:001      read prefs \Library\Preferences\com.apple.PowerManagement.plist status=Success
4:103  0:000      using default sleep image name = \private\var\vm\sleepimage
4:104  0:000      sleepimage not found -> Not Found
4:104  0:000      hibernated: no - sign
4:183  0:078  - [06]: 'Recovery HD'
4:184  0:000          AddLoaderEntry for Volume Name=Recovery HD
4:185  0:001  Scanning legacy ...
4:185  0:000  === [ AddCustomTool ] =====================================
4:198  0:013  found tool \EFI\CLOVER\tools\Shell64U.efi
4:198  0:000  Checking EFI partition Volume 1 for Clover
4:198  0:000   Found Clover
4:200  0:002  === [ GetEfiBootDeviceFromNvram ] =========================
4:200  0:000   - found entry 0. 'Boot macOS from SS950', Volume 'SS950', DevicePath 'PcieRoot(0x0)\Pci(0x1,0x0)\Pci(0x0,0x0)\NVMe(0x1,7F-0F-16-5A-53-38-25-00)\HD(2,GPT,A9072CE1-1747-425D-B310-142B4C924B13,0x64028,0x3B847340)\System\Library\CoreServices\boot.efii'
4:200  0:000  DefaultIndex=0 and MainMenu.EntryCount=8
4:830  0:629  GUI ready
6:886  2:056  === [ StartLoader ] =======================================
6:886  0:000  Finally: ExternalClock=133MHz BusSpeed=133202kHz CPUFreq=3463MHz PIS: hw.busfrequency=532000000Hz
6:886  0:000  Loading boot.efi  status=Success
7:194  0:308  GetOSVersion: 10.13.3 (17D47)
7:194  0:000  CSR_CFG: CSR_ALLOW_UNTRUSTED_KEXTS | CSR_ALLOW_UNRESTRICTED_FS | CSR_ALLOW_TASK_FOR_PID | CSR_ALLOW_UNRESTRICTED_DTRACE | CSR_ALLOW_UNRESTRICTED_NVRAM
7:194  0:000  Filtering KextPatches:
7:194  0:000   - [00]: AppleAHCIPort (External icons patch) :: BinPatch :: [OS: 10.13.3 | MatchOS: All | MatchBuild: All] ==> allowed
7:194  0:000  Will not patch boot.efi
7:194  0:000  === [ PatchSmbios ] =======================================
7:194  0:000  insert table 9 for dev 0:0
7:194  0:000  insert table 9 for dev 0:1
7:194  0:000  insert table 9 for dev 0:0
7:194  0:000  insert table 9 for dev 9:0
7:195  0:000  Injecting user memory modules to SMBIOS
7:195  0:000  Channels: 1
7:195  0:000  Interleave: 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
7:195  0:000   DIMM1 1333MHz 8192MB
7:195  0:000   DIMM2 1333MHz 8192MB
7:195  0:000   DIMM3 1333MHz 8192MB
7:195  0:000   DIMM4 1333MHz 8192MB
7:195  0:000   DIMM5 1333MHz 8192MB
7:195  0:000   DIMM6 1333MHz 8192MB
7:195  0:000   DIMM7 EMPTY
7:195  0:000   DIMM8 EMPTY
7:195  0:000   DIMM9 EMPTY
7:195  0:000   DIMM10 EMPTY
7:195  0:000   DIMM11 EMPTY
7:195  0:000   DIMM12 EMPTY
7:195  0:000  mTotalSystemMemory = 49152
7:195  0:000  NumberOfMemoryDevices = 12
7:196  0:000  Type20[0]->End = 0x3FFFFF, Type17[0] = 0x2000
7:196  0:000  === [ PatchACPI ] =========================================
7:196  0:000  Xsdt reallocation done
7:196  0:000  old FADT length=F4
7:196  0:000   SignatureFixup: 0x0 -> 0
7:196  0:000  Found OperationRegion(VECT, SystemMemory, F8000, ...)
7:209  0:013  Apply DsdtFixMask=0x17EE3155
7:209  0:000     drop _DSM mask=0x0000
7:209  0:000  === [ FixBiosDsdt ] =======================================
7:209  0:000  VideoCard devID=0x67DF1002
7:209  0:000  DisplayADR1[0] = 0x30000, DisplayADR2[0] = 0x0
7:209  0:000  USBADR[0] = 0x1A0000 and PCIe = 0xFFFE
7:209  0:000  USBADR[1] = 0x1A0001 and PCIe = 0xFFFE
7:209  0:000  USBADR[2] = 0x1A0002 and PCIe = 0xFFFE
7:209  0:000  USBADR[3] = 0x1A0007 and PCIe = 0xFFFE
7:209  0:000  USBADR[4] = 0x1D0000 and PCIe = 0xFFFE
7:209  0:000  USBADR[5] = 0x1D0001 and PCIe = 0xFFFE
7:209  0:000  USBADR[6] = 0x1D0002 and PCIe = 0xFFFE
7:209  0:000  USBADR[7] = 0x1D0007 and PCIe = 0xFFFE
7:210  0:000  first CPU found at 40FF offset 4102
7:210  0:000  slash found
7:210  0:000  Found ACPI CPU: CPU0 | CPU1 | CPU2 | CPU3 | CPU4 | CPU5 | CPU6 | CPU7 | CPU8 | CPU9 | CPUA | CPUB | CPUC | CPUD | CPUE | CPUF | CPUG | CPUH | CPUI | CPUJ | CPUK | CPUL | CPUM | CPUN Invalid character found in ProcessorOP 0xFFFFFFF0!
7:210  0:000  , within the score: _PR_
7:210  0:000  Found PCIROOTUID = 0
7:210  0:000  Start RTC Fix
7:210  0:000  found RTC had IRQNoFlag will move -3 bytes
7:210  0:000  ...len=AB53
7:210  0:000  new size written to 336E shift=0 len=AB53
7:210  0:000  len after correct outers AB53
7:210  0:000  Start TMR Fix
7:210  0:000  Start PIC Fix
7:210  0:000  PIC size=33 at 32A7
7:210  0:000  found PIC had IRQNoFlag will move -3 bytes
7:210  0:000  Fix Device PIC size -3
7:210  0:000  Start HPET Fix
7:211  0:000  Start Display0 Fix
7:211  0:000  Found internal video device 0 @1746
7:211  0:000  Skipping Method(_DSM) for 1002 card
7:211  0:000  now inserting Video device
7:211  0:000  ... into existing bridge
7:211  0:000  patch Display #0 of Vendor=0x1002
7:211  0:000  Start NetWork Fix
7:211  0:000  found NetWork device [0x001C0005:0] at 1D00 and Name is BRCM
7:211  0:000  NetworkADR1=1C0005 NetworkADR2=0
7:211  0:000  network DSM created, size=5C
7:211  0:000  Start Add IMEI
7:211  0:000  Start USB Fix
7:211  0:000  USB bridge[1A0000] at 1E8C, size = 4E
7:211  0:000  USB bridge[1A0001] at 1F42, size = 4E
7:211  0:000  USB bridge[1A0002] at 1FF8, size = 4E
7:211  0:000  USB bridge[1A0007] at 20FE, size = 4E
7:212  0:000  USB bridge[1D0000] at 1D9C, size = 4E
7:212  0:000  USB bridge[1D0001] at 1E52, size = 4E
7:212  0:000  USB bridge[1D0002] at 1F08, size = 4E
7:212  0:000  USB bridge[1D0007] at 21E0, size = 4E
7:212  0:000  Start _WAK Return Fix
7:212  0:000  _WAK Method need return data, will patch it.
7:212  0:000  return len=AF70
7:212  0:000   deleting device CRT_
7:212  0:000   deleting device DVI_
7:212  0:000   deleting device SPKR
7:212  0:000   deleting device ECP_
7:213  0:000   deleting device LPT_
7:213  0:000   deleting device FDC0
7:213  0:000   deleting device ECP1
7:213  0:000   deleting device LPT1
7:213  0:000  Start PNLF Fix
7:214  0:000  found PWRB at 3CF3
7:214  0:000  Start _S3D Fix
7:214  0:000  Start ADP1 fix
7:214  0:000  no device(AC) exists
7:214  0:000  Start SHUTDOWN Fix len=AF7C
7:214  0:000  PreCleanup XSDT: count=9, length=108
7:214  0:000  PreCleanup XSDT, corrected XSDT: count=9, length=108
7:214  0:000  === [ ACPIDropTables ] ====================================
7:214  0:000  Drop tables from XSDT, SIGN=DMAR TableID=TYLSBURG Length=440
7:214  0:000   Table[7]: DMAR  TYLSBURG  440 dropped
7:214  0:000  === [ PatchAllSSDT ] ======================================
7:214  0:000  Out of control with CPU numbers
7:214  0:000  CPUBase=0 and ApicCPUBase=1 ApicCPUNum=12
7:214  0:000  Maximum control=0x1A
7:214  0:000  Turbo control=0x1C
7:214  0:000  P-States: min 0xC, max 0x1C
7:214  0:000  SSDT with CPU P-States generated successfully
7:214  0:000  SSDT with CPU C-States generated successfully
7:214  0:000  Cleanup XSDT: count=11, length=124
7:214  0:000  corrected XSDT count=10, length=116
7:214  0:000  === [ RestSetup macOS ] ===================================
7:214  0:000  EdidDiscovered size=128
7:214  0:000  ---Discovered EDID Table size:128
7:214  0:000  000  |  00  FF  FF  FF  FF  FF  FF  00  04  69
7:214  0:000  010  |  A3  26  1D  0B  00  00  06  13  01  03
7:214  0:000  020  |  80  37  22  78  2A  CB  D0  A3  5A  49
7:214  0:000  030  |  A0  24  13  50  54  BF  EF  00  71  4F
7:214  0:000  040  |  01  01  81  40  81  80  95  00  B3  00
7:214  0:000  050  |  01  01  01  01  28  3C  80  A0  70  B0
7:214  0:000  060  |  23  40  30  20  36  00  26  54  21  00
7:214  0:000  070  |  00  1A  00  00  00  FF  00  39  31  4C
7:214  0:000  080  |  4D  54  43  30  30  32  38  34  35  0A
7:214  0:000  090  |  00  00  00  FD  00  32  4B  1E  55  11
7:214  0:000  100  |  00  0A  20  20  20  20  20  20  00  00
7:214  0:000  110  |  00  FC  00  41  53  55  53  20  56  4B
7:214  0:000  120  |  32  36  36  48  0A  20  01  4C
7:214  0:000  --- Patched EDID size:128
7:214  0:000  000  |  00  FF  FF  FF  FF  FF  FF  00  04  69
7:214  0:000  010  |  A3  26  1D  0B  00  00  06  13  01  03
7:214  0:000  020  |  80  37  22  78  2A  CB  D0  A3  5A  49
7:214  0:000  030  |  A0  24  13  50  54  BF  EF  00  71  4F
7:214  0:000  040  |  01  01  81  40  81  80  95  00  B3  00
7:214  0:000  050  |  01  01  01  01  28  3C  80  A0  70  B0
7:214  0:000  060  |  23  40  30  20  36  00  26  54  21  00
7:214  0:000  070  |  00  1A  00  00  00  FF  00  39  31  4C
7:214  0:000  080  |  4D  54  43  30  30  32  38  34  35  0A
7:214  0:000  090  |  00  00  00  FD  00  32  4B  1E  55  11
7:214  0:000  100  |  00  0A  20  20  20  20  20  20  00  00
7:214  0:000  110  |  00  FC  00  41  53  55  53  20  56  4B
7:214  0:000  120  |  32  36  36  48  0A  20  01  4C
7:214  0:000  ATI injection not set
7:214  0:000  Device 0 deinited
7:215  0:000  stringlength = 2736
7:215  0:000  CurrentMode: Width=1920 Height=1200
7:215  0:000  Beginning FSInjection
FSInjectionInstall ...
- Our FSI_SIMPLE_FILE_SYSTEM_PROTOCOL installed on handle: CCA1F618
FSInjectionInstall ...
- Our FSI_SIMPLE_FILE_SYSTEM_PROTOCOL installed on handle: CCA1F618
7:215  0:000  Use origin smbios table type 1 guid.
7:216  0:000  Preparing kexts injection for arch=x86_64 from EFI\CLOVER\kexts\Other
7:216  0:000  Extra kext: EFI\CLOVER\kexts\Other\Lilu.kext (v.1.2.2)
7:255  0:039  Extra kext: EFI\CLOVER\kexts\Other\WhateverGreen.kext (v.1.1.4)
7:308  0:052  Extra kext: EFI\CLOVER\kexts\Other\IOAHCIBlockStorageInjector_v1.0.0_Micky1979.kext (v.1.0.0)
7:335  0:026  Extra kext: EFI\CLOVER\kexts\Other\AHCIPortInjector_v1.0.0_Micky1979.kext (v.1.0.0)
7:368  0:033  Preparing kexts injection for arch=x86_64 from EFI\CLOVER\kexts\10.13
7:369  0:000  Custom boot screen not used because entry has unset use graphics

Could you go to Clover boot menu and hit F4 so that Clover can dump your original DSDT. They will be located in EFI>Clover>ACPI>orgin after. will need to look at those also.

Link to comment
Share on other sites
robertr
robertr
Posted
Posted

Try this using a different USB than the one you are using right now. So you don't lose your working USB. If it works and boots into desktop I need a ioreg dump please.

Since this is a BIOS board I added back the Drivers64 folder.

It did boot but screen went black.

Here's the ioreg dump, it's 1:50am here now so I'll soon go to bed.

EDIT: This is a bit off topic but would it be possible to inject a different Subsystem ID for the 10Gb Network card?

Vendor ID: 0x8086

Device ID: 0x10fb

Subsystem Vendor ID: 0x8086

Subsystem ID: 0x0006 <-- THIS needs to be 0x000a for the drivers to load. It would be nice to not have to flash the card.

ioreg
+-o Root  <class IORegistryEntry, id 0x100000100, retain 10>
  +-o MacPro5,1  <class IOPlatformExpertDevice, id 0x100000111, registered, matched, active, busy 0 (36466 ms), retain 51>
    +-o AppleACPIPlatformExpert  <class AppleACPIPlatformExpert, id 0x100000112, registered, matched, active, busy 0 (36172 ms), retain 64>
    | +-o IOPMrootDomain  <class IOPMrootDomain, id 0x100000115, registered, matched, active, busy 0 (103 ms), retain 85>
    | | +-o IORootParent  <class IORootParent, id 0x100000116, !registered, !matched, active, busy 0, retain 7>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000002fc, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000002ff, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000302, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000303, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000304, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000307, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x10000030c, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000310, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000311, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000312, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000313, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000314, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000315, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000318, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x10000031e, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000322, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000323, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000324, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000329, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000332, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000003ae, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000003b7, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000484, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x10000048c, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000493, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x10000049f, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004a0, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004a3, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004a7, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004a8, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004a9, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004ac, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004b2, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004b4, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004b6, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d1, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d2, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d3, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d4, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d5, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d6, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d7, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d9, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004db, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004dc, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004de, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004e0, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004e6, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004e7, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004e8, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004e9, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004f0, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004f1, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004f2, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004f8, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004f9, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004fa, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000504, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x10000050a, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x10000050c, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x10000050f, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000511, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000518, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000528, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000529, !registered, !matched, active, busy 0, retain 5>
    | +-o IOPCIMessagedInterruptController  <class IOPCIMessagedInterruptController, id 0x100000127, registered, matched, active, busy 0 (0 ms), retain 7>
    | +-o cpus  <class IOPlatformDevice, id 0x100000128, registered, matched, active, busy 0 (0 ms), retain 30>
    | +-o CPU0@0  <class IOACPIPlatformDevice, id 0x100000129, registered, matched, active, busy 0 (6277 ms), retain 9>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x100000142, registered, matched, active, busy 0 (5634 ms), retain 8>
    | | | +-o AppleACPICPUInterruptController  <class AppleACPICPUInterruptController, id 0x10000015b, registered, matched, active, busy 0 (0 ms), retain 6>
    | | | +-o ACPI_SMC_PlatformPlugin  <class ACPI_SMC_PlatformPlugin, id 0x10000032f, registered, matched, active, busy 0 (5627 ms), retain 13>
    | | |   +-o AGPMEnabler  <class IOPlatformPluginDevice, id 0x1000003b8, registered, matched, active, busy 0 (14 ms), retain 7>
    | | |   | +-o AGPMController  <class AGPMController, id 0x1000003c0, !registered, !matched, active, busy 0, retain 4>
    | | |   +-o AppleTyMCEDriver  <class AppleTyMCEDriver, id 0x1000003be, registered, matched, active, busy 0 (0 ms), retain 6>
    | | |     +-o AppleTyMCEInterruptController  <class AppleTyMCEInterruptController, id 0x1000003ed, registered, matched, active, busy 0 (0 ms), retain 7>
    | | +-o CPUSensors  <class CPUSensors, id 0x100000143, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU1@2  <class IOACPIPlatformDevice, id 0x10000012a, registered, matched, active, busy 0 (590 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x100000144, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU2@4  <class IOACPIPlatformDevice, id 0x10000012b, registered, matched, active, busy 0 (591 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x100000145, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU3@10  <class IOACPIPlatformDevice, id 0x10000012c, registered, matched, active, busy 0 (592 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x100000146, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU4@12  <class IOACPIPlatformDevice, id 0x10000012d, registered, matched, active, busy 0 (593 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x100000147, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU5@14  <class IOACPIPlatformDevice, id 0x10000012e, registered, matched, active, busy 0 (594 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x100000148, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU6@1  <class IOACPIPlatformDevice, id 0x10000012f, registered, matched, active, busy 0 (595 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x100000149, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU7@3  <class IOACPIPlatformDevice, id 0x100000130, registered, matched, active, busy 0 (597 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x10000014a, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU8@5  <class IOACPIPlatformDevice, id 0x100000131, registered, matched, active, busy 0 (598 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x10000014b, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU9@11  <class IOACPIPlatformDevice, id 0x100000132, registered, matched, active, busy 0 (599 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x10000014c, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPUA@13  <class IOACPIPlatformDevice, id 0x100000133, registered, matched, active, busy 0 (600 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x10000014d, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPUB@15  <class IOACPIPlatformDevice, id 0x100000134, registered, matched, active, busy 0 (601 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x10000014e, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPUC  <class IOACPIPlatformDevice, id 0x100000135, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUD  <class IOACPIPlatformDevice, id 0x100000136, registered, matched, active, busy 0 (601 ms), retain 7>
    | +-o CPUE  <class IOACPIPlatformDevice, id 0x100000137, registered, matched, active, busy 0 (601 ms), retain 7>
    | +-o CPUF  <class IOACPIPlatformDevice, id 0x100000138, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUG  <class IOACPIPlatformDevice, id 0x100000139, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUH  <class IOACPIPlatformDevice, id 0x10000013a, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUI  <class IOACPIPlatformDevice, id 0x10000013b, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUJ  <class IOACPIPlatformDevice, id 0x10000013c, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUK  <class IOACPIPlatformDevice, id 0x10000013d, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUL  <class IOACPIPlatformDevice, id 0x10000013e, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUM  <class IOACPIPlatformDevice, id 0x10000013f, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUN  <class IOACPIPlatformDevice, id 0x100000140, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o io-apic@fec00000  <class IOACPIPlatformDevice, id 0x100000141, registered, matched, active, busy 0 (24 ms), retain 7>
    | | +-o AppleAPICInterruptController  <class AppleAPICInterruptController, id 0x10000015d, registered, matched, active, busy 0 (0 ms), retain 12>
    | +-o io-apic@fec10000  <class IOACPIPlatformDevice, id 0x10000015c, registered, matched, active, busy 0 (1 ms), retain 7>
    | | +-o AppleAPICInterruptController  <class AppleAPICInterruptController, id 0x10000015e, registered, matched, active, busy 0 (0 ms), retain 7>
    | +-o AppleACPIEventController  <class AppleACPIEventController, id 0x10000015f, !registered, !matched, active, busy 0, retain 6>
    | +-o bios  <class IOPlatformDevice, id 0x100000162, registered, matched, active, busy 0 (0 ms), retain 6>
    | | +-o AppleSMBIOS  <class AppleSMBIOS, id 0x100000163, registered, matched, active, busy 0 (0 ms), retain 5>
    | +-o PCI0@0  <class IOACPIPlatformDevice, id 0x100000168, registered, matched, active, busy 0 (11542 ms), retain 86>
    | | +-o AppleACPIPCI  <class AppleACPIPCI, id 0x1000001d8, registered, matched, active, busy 0 (11171 ms), retain 61>
    | |   +-o MCHC@0  <class IOPCIDevice, id 0x1000001cb, registered, matched, active, busy 0 (30 ms), retain 8>
    | |   +-o IOH1@1  <class IOPCIDevice, id 0x1000001b2, registered, matched, active, busy 0 (95 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x10000028c, registered, matched, active, busy 0 (34 ms), retain 8>
    | |   |   +-o SLT1@0  <class IOPCIDevice, id 0x1000001b3, registered, matched, active, busy 0 (34 ms), retain 13>
    | |   |     +-o IONVMeController  <class IONVMeController, id 0x1000002a9, registered, matched, active, busy 0 (2 ms), retain 10>
    | |   |       +-o IONVMeBlockStorageDevice@1  <class IONVMeBlockStorageDevice, id 0x1000002bc, registered, matched, active, busy 0 (2 ms), retain 12>
    | |   |         +-o IOBlockStorageDriver  <class IOBlockStorageDriver, id 0x1000002bd, registered, matched, active, busy 0 (2 ms), retain 9>
    | |   |           +-o Samsung SSD 950 PRO 512GB Media  <class IOMedia, id 0x1000002be, registered, matched, active, busy 0 (2 ms), retain 17>
    | |   |             +-o IOMediaBSDClient  <class IOMediaBSDClient, id 0x1000002bf, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   |             +-o IOGUIDPartitionScheme  <class IOGUIDPartitionScheme, id 0x1000002c1, !registered, !matched, active, busy 0 (0 ms), retain 8>
    | |   |               +-o EFI System Partition@1  <class IOMedia, id 0x1000002c4, registered, matched, active, busy 0 (0 ms), retain 15>
    | |   |               | +-o IOMediaBSDClient  <class IOMediaBSDClient, id 0x1000002c7, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   |               +-o Untitled 2@2  <class IOMedia, id 0x1000002c5, registered, matched, active, busy 0 (0 ms), retain 17>
    | |   |               | +-o IOMediaBSDClient  <class IOMediaBSDClient, id 0x1000002c8, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   |               +-o Untitled 3@3  <class IOMedia, id 0x1000002c6, registered, matched, active, busy 0 (0 ms), retain 15>
    | |   |                 +-o IOMediaBSDClient  <class IOMediaBSDClient, id 0x1000002c9, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   +-o IOH3@3  <class IOPCIDevice, id 0x1000001b4, registered, matched, active, busy 0 (5737 ms), retain 12>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x100000277, registered, matched, active, busy 0 (5681 ms), retain 10>
    | |   |   +-o GFX0@0  <class IOPCIDevice, id 0x1000001b5, registered, matched, active, busy 0 (5673 ms), retain 32>
    | |   |   | +-o RadeonSensors  <class RadeonSensors, id 0x100000295, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | +-o AMDRadeonX4000_AMDRadeonHWServicesBaffin  <class AMDRadeonX4000_AMDRadeonHWServicesBaffin, id 0x100000338, registered, matched, active, busy 0 (2 ms), retain 6>
    | |   |   | | +-o AMDRadeonX4000_AMDRadeonHWLibs  <class AMDRadeonX4000_AMDRadeonHWLibs, id 0x100000343, !registered, !matched, active, busy 0, retain 4>
    | |   |   | +-o AMD9500ControllerWrangler  <class AMD9500ControllerWrangler, id 0x100000339, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |   | | +-o AppleGraphicsDeviceControlClient  <class AppleGraphicsDeviceControlClient, id 0x100000461, !registered, !matched, active, busy 0, retain 5>
    | |   |   | | +-o AppleGraphicsDeviceControlClient  <class AppleGraphicsDeviceControlClient, id 0x100000478, !registered, !matched, active, busy 0, retain 5>
    | |   |   | +-o AMDSupport  <class AMDSupport, id 0x10000033a, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | +-o AMD9500Controller@t  <class AMD9500Controller, id 0x10000035b, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | +-o ATY,AMD,RadeonFramebuffer@0  <class AtiFbStub, id 0x1000003af, registered, matched, active, busy 0 (4775 ms), retain 8>
    | |   |   | | +-o AMDFramebufferVIB  <class AMDFramebuffer, id 0x1000003c2, registered, matched, active, busy 0 (3 ms), retain 17>
    | |   |   | |   +-o AGPM  <class AGPM, id 0x1000003c7, registered, matched, active, busy 0 (1 ms), retain 9>
    | |   |   | |   | +-o gpu-control  <class IOService, id 0x1000003c8, registered, matched, active, busy 0 (1 ms), retain 7>
    | |   |   | |   |   +-o IOHWControl  <class IOHWControl, id 0x100000450, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |   | |   +-o AppleMCCSControlModule  <class AppleMCCSControlModule, id 0x1000003c9, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   |   | |   | +-o AppleMCCSParameterHandler  <class AppleMCCSParameterHandler, id 0x1000003cb, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o AppleUpstreamUserClientDriver  <class AppleUpstreamUserClientDriver, id 0x1000003ca, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferI2CInterface  <class IOFramebufferI2CInterface, id 0x10000044d, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferUserClient  <class IOFramebufferUserClient, id 0x100000460, !registered, !matched, active, busy 0, retain 5>
    | |   |   | +-o ATY,AMD,RadeonFramebuffer@1  <class AtiFbStub, id 0x1000003b0, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |   | | +-o AMDFramebufferVIB  <class AMDFramebuffer, id 0x1000003cc, registered, matched, active, busy 0 (0 ms), retain 15>
    | |   |   | |   +-o AppleMCCSControlModule  <class AppleMCCSControlModule, id 0x1000003cf, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   |   | |   | +-o AppleMCCSParameterHandler  <class AppleMCCSParameterHandler, id 0x1000003d1, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o AppleUpstreamUserClientDriver  <class AppleUpstreamUserClientDriver, id 0x1000003d0, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferI2CInterface  <class IOFramebufferI2CInterface, id 0x10000044e, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferUserClient  <class IOFramebufferUserClient, id 0x100000462, !registered, !matched, active, busy 0, retain 5>
    | |   |   | +-o ATY,AMD,RadeonFramebuffer@2  <class AtiFbStub, id 0x1000003b1, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |   | | +-o AMDFramebufferVIB  <class AMDFramebuffer, id 0x1000003d2, registered, matched, active, busy 0 (0 ms), retain 15>
    | |   |   | |   +-o AppleMCCSControlModule  <class AppleMCCSControlModule, id 0x1000003d5, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   |   | |   | +-o AppleMCCSParameterHandler  <class AppleMCCSParameterHandler, id 0x1000003d7, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o AppleUpstreamUserClientDriver  <class AppleUpstreamUserClientDriver, id 0x1000003d6, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferI2CInterface  <class IOFramebufferI2CInterface, id 0x100000451, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferUserClient  <class IOFramebufferUserClient, id 0x100000463, !registered, !matched, active, busy 0, retain 5>
    | |   |   | +-o ATY,AMD,RadeonFramebuffer@3  <class AtiFbStub, id 0x1000003b2, registered, matched, active, busy 0 (1 ms), retain 8>
    | |   |   | | +-o AMDFramebufferVIB  <class AMDFramebuffer, id 0x1000003d8, registered, matched, active, busy 0 (1 ms), retain 17>
    | |   |   | |   +-o AppleMCCSControlModule  <class AppleMCCSControlModule, id 0x1000003db, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   |   | |   | +-o AppleMCCSParameterHandler  <class AppleMCCSParameterHandler, id 0x1000003dd, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o AppleUpstreamUserClientDriver  <class AppleUpstreamUserClientDriver, id 0x1000003dc, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferI2CInterface  <class IOFramebufferI2CInterface, id 0x100000452, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o display0  <class IODisplayConnect, id 0x100000453, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   |   | |   | +-o AppleDisplay  <class AppleDisplay, id 0x100000455, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |   | |   +-o IOFramebufferUserClient  <class IOFramebufferUserClient, id 0x100000464, !registered, !matched, active, busy 0, retain 5>
    | |   |   | +-o ATY,AMD,RadeonFramebuffer@4  <class AtiFbStub, id 0x1000003b3, registered, matched, active, busy 0 (2 ms), retain 8>
    | |   |   | | +-o AMDFramebufferVIB  <class AMDFramebuffer, id 0x1000003de, registered, matched, active, busy 0 (1 ms), retain 15>
    | |   |   | |   +-o AppleMCCSControlModule  <class AppleMCCSControlModule, id 0x1000003e1, registered, matched, active, busy 0 (1 ms), retain 7>
    | |   |   | |   | +-o AppleMCCSParameterHandler  <class AppleMCCSParameterHandler, id 0x1000003e5, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o AppleUpstreamUserClientDriver  <class AppleUpstreamUserClientDriver, id 0x1000003e2, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferI2CInterface  <class IOFramebufferI2CInterface, id 0x10000045e, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferUserClient  <class IOFramebufferUserClient, id 0x100000465, !registered, !matched, active, busy 0, retain 5>
    | |   |   | +-o AtiDeviceControl  <class AtiDeviceControl, id 0x1000003e7, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   |   | | +-o AppleGraphicsDeviceControlClient  <class AppleGraphicsDeviceControlClient, id 0x100000479, !registered, !matched, active, busy 0, retain 5>
    | |   |   | +-o AMDRadeonX4200_AMDEllesmereGraphicsAccelerator  <class AMDRadeonX4200_AMDEllesmereGraphicsAccelerator, id 0x10000035c, registered, matched, active, busy 0 (1 ms), retain 66>
    | |   |   |   +-o AMDRadeonX4200_AMDAccel2DContext  <class AMDRadeonX4200_AMDAccel2DContext, id 0x100000473, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccel2DContext  <class AMDRadeonX4200_AMDAccel2DContext, id 0x100000474, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccel2DContext  <class AMDRadeonX4200_AMDAccel2DContext, id 0x100000475, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccel2DContext  <class AMDRadeonX4200_AMDAccel2DContext, id 0x100000476, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccel2DContext  <class AMDRadeonX4200_AMDAccel2DContext, id 0x100000477, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x10000047b, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x10000047d, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x10000047f, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x100000480, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x100000481, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x100000482, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x100000483, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x100000485, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x100000486, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDSIGLContext  <class AMDRadeonX4200_AMDSIGLContext, id 0x100000487, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x100000489, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x10000048a, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004ae, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004af, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x1000004b0, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x1000004b1, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004b7, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004b8, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x1000004b9, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x1000004ba, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004bc, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004bd, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x1000004be, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x1000004c3, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x1000004c4, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004ca, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004cb, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x1000004cc, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x1000004cd, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004ce, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x1000004d0, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004eb, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004ec, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x1000004ed, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x1000004ee, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004f4, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004f5, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x1000004f6, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x1000004f7, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x100000506, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x100000507, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x100000508, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x100000509, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x100000513, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x100000515, !registered, !matched, active, busy 0, retain 7>
    | |   |   |   +-o AMDRadeonX4200_AMDSIGLContext  <class AMDRadeonX4200_AMDSIGLContext, id 0x100000516, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDCICLContext  <class AMDRadeonX4200_AMDCICLContext, id 0x100000517, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x10000051a, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x10000051b, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x10000051c, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x10000051d, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x10000052b, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x10000052c, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x10000052d, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x10000052e, !registered, !matched, active, busy 0, retain 6>
    | |   |   +-o HDEF@0,1  <class IOPCIDevice, id 0x100000242, registered, matched, active, busy 0 (96 ms), retain 10>
    | |   |     +-o AppleHDAController@0,1  <class AppleHDAController, id 0x100000342, registered, matched, active, busy 0 (28 ms), retain 9>
    | |   |       +-o IOHDACodecDevice@0,1,0  <class IOHDACodecDevice, id 0x10000035f, registered, matched, active, busy 0 (28 ms), retain 7>
    | |   |         +-o IOHDACodecDriver  <class IOHDACodecDriver, id 0x100000361, !registered, !matched, active, busy 0 (27 ms), retain 5>
    | |   |           +-o IOHDACodecFunction@0,1,0,1  <class IOHDACodecFunction, id 0x100000362, registered, matched, active, busy 0 (27 ms), retain 7>
    | |   |             +-o AppleHDACodecGeneric  <class AppleHDACodecGeneric, id 0x100000363, registered, matched, active, busy 0 (5 ms), retain 6>
    | |   |               +-o AppleHDAHDMI_DPDriver  <class AppleHDAHDMI_DPDriver, id 0x100000366, registered, matched, active, busy 0 (2 ms), retain 7>
    | |   |                 +-o AppleHDAEngineOutputDP@0,1,0,1,5  <class AppleHDAEngineOutputDP, id 0x100000457, registered, matched, active, busy 0 (2 ms), retain 25>
    | |   |                   +-o AppleHDAStream  <class AppleHDAStream, id 0x100000458, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |                   +-o AppleHDAAudioSelectorControlDP  <class AppleHDAAudioSelectorControlDP, id 0x100000459, !registered, !matched, active, busy 0, retain 8>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x10000045c, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioSelectorControl  <class IOAudioSelectorControl, id 0x10000045a, !registered, !matched, active, busy 0 (0 ms), retain 27>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x10000045d, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004bf, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004c0, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004c1, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004c2, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004c7, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004e2, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004e3, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004fd, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x10000050e, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x100000530, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o AudioAUUCDriver  <class AudioAUUCDriver, id 0x10000045b, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x10000045f, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x100000466, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x100000467, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x100000468, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x10000046c, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x1000004a1, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x1000004a5, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x1000004c6, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x1000004fc, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x10000050d, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x10000052f, !registered, !matched, active, busy 0, retain 6>
    | |   +-o IOH7@7  <class IOPCIDevice, id 0x1000001b6, registered, matched, active, busy 0 (63 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x10000029b, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   +-o pci8086,3425@10  <class IOPCIDevice, id 0x10000023a, registered, matched, active, busy 0 (40 ms), retain 8>
    | |   +-o pci8086,3426@10,1  <class IOPCIDevice, id 0x10000023b, registered, matched, active, busy 0 (41 ms), retain 8>
    | |   +-o pci8086,3427@11  <class IOPCIDevice, id 0x10000023c, registered, matched, active, busy 0 (43 ms), retain 8>
    | |   +-o pci8086,3428@11,1  <class IOPCIDevice, id 0x10000023d, registered, matched, active, busy 0 (38 ms), retain 8>
    | |   +-o IH20@14  <class IOPCIDevice, id 0x1000001b0, registered, matched, active, busy 0 (42 ms), retain 8>
    | |   +-o pci8086,3422@14,1  <class IOPCIDevice, id 0x10000023e, registered, matched, active, busy 0 (40 ms), retain 8>
    | |   +-o pci8086,3423@14,2  <class IOPCIDevice, id 0x10000023f, registered, matched, active, busy 0 (42 ms), retain 8>
    | |   +-o pci8086,342f@15  <class IOPCIDevice, id 0x100000240, registered, matched, active, busy 0 (41 ms), retain 8>
    | |   +-o USB4@1A  <class IOPCIDevice, id 0x1000001c5, registered, matched, active, busy 0 (54 ms), retain 8>
    | |   +-o USB5@1A,1  <class IOPCIDevice, id 0x1000001c6, registered, matched, active, busy 0 (55 ms), retain 11>
    | |   | +-o USB5@3a000000  <class AppleUSBUHCIPCI, id 0x10000027d, registered, matched, active, busy 0 (0 ms), retain 286>
    | |   |   +-o AppleUSBUHCIPort@3a100000  <class AppleUSBUHCIPort, id 0x1000002e7, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |   +-o AppleUSBUHCIPort@3a200000  <class AppleUSBUHCIPort, id 0x1000002ec, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   +-o USB6@1A,2  <class IOPCIDevice, id 0x1000001c7, registered, matched, active, busy 0 (54 ms), retain 11>
    | |   | +-o USB6@5a000000  <class AppleUSBUHCIPCI, id 0x10000027e, registered, matched, active, busy 0 (0 ms), retain 286>
    | |   |   +-o AppleUSBUHCIPort@5a100000  <class AppleUSBUHCIPort, id 0x1000002d3, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |   +-o AppleUSBUHCIPort@5a200000  <class AppleUSBUHCIPort, id 0x1000002e5, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   +-o EUS2@1A,7  <class IOPCIDevice, id 0x1000001c9, registered, matched, active, busy 0 (55 ms), retain 11>
    | |   | +-o EUS2@fa000000  <class AppleUSBEHCIPCI, id 0x100000280, registered, matched, active, busy 0 (1 ms), retain 97>
    | |   |   +-o AppleUSBEHCIPort@fa100000  <class AppleUSBEHCIPort, id 0x1000002df, registered, matched, active, busy 0 (0 ms), retain 11>
    | |   |   +-o AppleUSBEHCIPort@fa200000  <class AppleUSBEHCIPort, id 0x1000002e0, registered, matched, active, busy 0 (0 ms), retain 11>
    | |   |   +-o AppleUSBEHCIPort@fa300000  <class AppleUSBEHCIPort, id 0x1000002e1, registered, matched, active, busy 0 (0 ms), retain 14>
    | |   |   +-o AppleUSBEHCIPort@fa400000  <class AppleUSBEHCIPort, id 0x1000002e2, registered, matched, active, busy 0 (0 ms), retain 14>
    | |   |   +-o AppleUSBEHCIPort@fa500000  <class AppleUSBEHCIPort, id 0x1000002e3, registered, matched, active, busy 0 (0 ms), retain 14>
    | |   |   +-o AppleUSBEHCIPort@fa600000  <class AppleUSBEHCIPort, id 0x1000002e4, registered, matched, active, busy 0 (0 ms), retain 14>
    | |   +-o HDEF@1B  <class IOPCIDevice, id 0x1000001ca, registered, matched, active, busy 0 (261 ms), retain 10>
    | |   | +-o AppleHDAController@1B  <class AppleHDAController, id 0x100000369, !registered, !matched, active, busy 0, retain 8>
    | |   |   +-o IOHDACodecDevice@1B,0  <class IOHDACodecDevice, id 0x10000036a, !registered, !matched, active, busy 0, retain 5>
    | |   |   +-o IOHDACodecDevice@1B,1  <class IOHDACodecDevice, id 0x10000036b, !registered, !matched, active, busy 0, retain 5>
    | |   |   +-o IOHDACodecDevice@1B,2  <class IOHDACodecDevice, id 0x10000036c, !registered, !matched, active, busy 0, retain 5>
    | |   |   +-o IOHDACodecDevice@1B,3  <class IOHDACodecDevice, id 0x10000036d, !registered, !matched, active, busy 0, retain 5>
    | |   +-o PCX1@1C  <class IOPCIDevice, id 0x1000001b9, registered, matched, active, busy 0 (55 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x100000296, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   +-o PCX5@1C,4  <class IOPCIDevice, id 0x1000001bb, registered, matched, active, busy 0 (217 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x10000029d, registered, matched, active, busy 0 (162 ms), retain 8>
    | |   |   +-o BRCM@0  <class IOPCIDevice, id 0x1000001bc, registered, matched, active, busy 0 (162 ms), retain 10>
    | |   |     +-o BCM5701Enet  <class BCM5701Enet, id 0x1000002ab, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |       +-o en4  <class IOEthernetAVBInterface, id 0x1000002cf, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |         +-o IONetworkStack  <class IONetworkStack, id 0x10000026c, registered, matched, active, busy 0 (0 ms), retain 12>
    | |   |           +-o IONetworkStackUserClient  <class IONetworkStackUserClient, id 0x100000301, !registered, !matched, active, busy 0, retain 5>
    | |   +-o PCX6@1C,5  <class IOPCIDevice, id 0x1000001bd, registered, matched, active, busy 0 (211 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x100000286, registered, matched, active, busy 0 (162 ms), retain 8>
    | |   |   +-o BRCM@0  <class IOPCIDevice, id 0x1000001be, registered, matched, active, busy 0 (162 ms), retain 10>
    | |   |     +-o BCM5701Enet  <class BCM5701Enet, id 0x1000002a7, registered, matched, active, busy 0 (6 ms), retain 10>
    | |   |       +-o en5  <class IOEthernetAVBInterface, id 0x1000002ce, registered, matched, active, busy 0 (6 ms), retain 10>
    | |   |         +-o IONetworkStack  <class IONetworkStack, id 0x10000026c, registered, matched, active, busy 0 (0 ms), retain 12>
    | |   |           +-o IONetworkStackUserClient  <class IONetworkStackUserClient, id 0x100000301, !registered, !matched, active, busy 0, retain 5>
    | |   +-o USB1@1D  <class IOPCIDevice, id 0x1000001c2, registered, matched, active, busy 0 (47 ms), retain 8>
    | |   +-o USB2@1D,1  <class IOPCIDevice, id 0x1000001c3, registered, matched, active, busy 0 (178 ms), retain 11>
    | |   | +-o USB2@3d000000  <class AppleUSBUHCIPCI, id 0x100000283, registered, matched, active, busy 0 (130 ms), retain 310>
    | |   |   +-o AppleUSBUHCIPort@3d100000  <class AppleUSBUHCIPort, id 0x1000002de, registered, matched, active, busy 0 (33 ms), retain 15>
    | |   |   | +-o Razer Naga 2014@3d100000  <class IOUSBHostDevice, id 0x100000372, registered, matched, active, busy 0 (33 ms), retain 31>
    | |   |   |   +-o AppleUSBHostLegacyClient  <class AppleUSBHostLegacyClient, id 0x100000382, !registered, !matched, active, busy 0, retain 10>
    | |   |   |   +-o AppleUSBHostCompositeDevice  <class AppleUSBHostCompositeDevice, id 0x10000038d, !registered, !matched, active, busy 0, retain 4>
    | |   |   |   +-o IOUSBHostInterface@0  <class IOUSBHostInterface, id 0x10000038f, !registered, !matched, active, busy 0, retain 7>
    | |   |   |   +-o IOUSBHostInterface@1  <class IOUSBHostInterface, id 0x100000390, !registered, !matched, active, busy 0, retain 7>
    | |   |   |   +-o IOUSBHostInterface@2  <class IOUSBHostInterface, id 0x100000391, !registered, !matched, active, busy 0, retain 7>
    | |   |   +-o AppleUSBUHCIPort@3d200000  <class AppleUSBUHCIPort, id 0x1000002f9, registered, matched, active, busy 0 (97 ms), retain 15>
    | |   |     +-o IOUSBHostDevice@3d200000  <class IOUSBHostDevice, id 0x1000003a2, registered, matched, active, busy 0 (97 ms), retain 30>
    | |   |       +-o AppleUSBHostLegacyClient  <class AppleUSBHostLegacyClient, id 0x100000412, !registered, !matched, active, busy 0, retain 8>
    | |   |       +-o AppleUSB20KeyboardHub@3d200000  <class AppleUSB20KeyboardHub, id 0x100000417, registered, matched, active, busy 0 (91 ms), retain 19>
    | |   |       | +-o AppleUSB20HubPort@3d220000  <class AppleUSB20HubPort, id 0x10000041c, registered, matched, active, busy 0 (91 ms), retain 16>
    | |   |       | | +-o Apple Keyboard@3d220000  <class IOUSBHostDevice, id 0x100000422, registered, matched, active, busy 0 (90 ms), retain 29>
    | |   |       | |   +-o AppleUSBHostLegacyClient  <class AppleUSBHostLegacyClient, id 0x100000425, !registered, !matched, active, busy 0, retain 8>
    | |   |       | |   +-o AppleUSBHostCompositeDevice  <class AppleUSBHostCompositeDevice, id 0x10000042b, !registered, !matched, active, busy 0, retain 4>
    | |   |       | |   +-o IOUSBHostInterface@0  <class IOUSBHostInterface, id 0x10000042c, registered, matched, active, busy 0 (30 ms), retain 11>
    | |   |       | |   | +-o IOUSBHostHIDDevice@3d220000,0  <class IOUSBHostHIDDevice, id 0x100000433, registered, matched, active, busy 0 (14 ms), retain 8>
    | |   |       | |   |   +-o IOHIDInterface  <class IOHIDInterface, id 0x10000043a, registered, matched, active, busy 0 (14 ms), retain 7>
    | |   |       | |   |   | +-o AppleHIDKeyboardEventDriver  <class AppleHIDKeyboardEventDriver, id 0x10000043b, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |       | |   |   |   +-o IOHIDEventServiceUserClient  <class IOHIDEventServiceUserClient, id 0x100000441, !registered, !matched, active, busy 0, retain 6>
    | |   |       | |   |   +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x10000048f, !registered, !matched, active, busy 0, retain 6>
    | |   |       | |   +-o IOUSBHostInterface@1  <class IOUSBHostInterface, id 0x10000042d, registered, matched, active, busy 0 (59 ms), retain 11>
    | |   |       | |     +-o IOUSBHostHIDDevice@3d220000,1  <class IOUSBHostHIDDevice, id 0x100000438, registered, matched, active, busy 0 (46 ms), retain 8>
    | |   |       | |       +-o IOHIDInterface  <class IOHIDInterface, id 0x10000043e, registered, matched, active, busy 0 (45 ms), retain 7>
    | |   |       | |       | +-o IOHIDEventDriver  <class IOHIDEventDriver, id 0x10000043f, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |       | |       |   +-o IOHIDEventServiceUserClient  <class IOHIDEventServiceUserClient, id 0x100000443, !registered, !matched, active, busy 0, retain 6>
    | |   |       | |       +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x10000048e, !registered, !matched, active, busy 0, retain 6>
    | |   |       | +-o AppleUSB20HubPort@3d210000  <class AppleUSB20HubPort, id 0x10000041d, registered, matched, active, busy 0 (0 ms), retain 12>
    | |   |       | +-o AppleUSB20HubPort@3d230000  <class AppleUSB20HubPort, id 0x10000041e, registered, matched, active, busy 0 (0 ms), retain 12>
    | |   |       +-o IOUSBHostInterface@0  <class IOUSBHostInterface, id 0x10000041a, !registered, !matched, active, busy 0, retain 9>
    | |   +-o USB3@1D,2  <class IOPCIDevice, id 0x1000001c4, registered, matched, active, busy 0 (5237 ms), retain 14>
    | |   | +-o USB3@5d000000  <class AppleUSBUHCIPCI, id 0x100000284, registered, matched, active, busy 0 (5190 ms), retain 293>
    | |   |   +-o AppleUSBUHCIPort@5d100000  <class AppleUSBUHCIPort, id 0x1000002f5, registered, matched, active, busy 0 (5190 ms), retain 16>
    | |   |   | +-o Mass Storage Device@5d100000  <class IOUSBHostDevice, id 0x100000371, registered, matched, active, busy 0 (5190 ms), retain 25>
    | |   |   |   +-o AppleUSBHostLegacyClient  <class AppleUSBHostLegacyClient, id 0x100000378, !registered, !matched, active, busy 0, retain 8>
    | |   |   |   +-o AppleUSBHostCompositeDevice  <class AppleUSBHostCompositeDevice, id 0x100000387, !registered, !matched, active, busy 0, retain 4>
    | |   |   |   +-o IOUSBHostInterface@0  <class IOUSBHostInterface, id 0x10000038a, registered, matched, active, busy 0 (5182 ms), retain 12>
    | |   |   |     +-o IOUSBMassStorageInterfaceNub  <class IOUSBMassStorageInterfaceNub, id 0x100000392, registered, matched, active, busy 0 (5180 ms), retain 10>
    | |   |   |       +-o IOUSBMassStorageDriverNub  <class IOUSBMassStorageDriverNub, id 0x100000395, registered, matched, active, busy 0 (5180 ms), retain 11>
    | |   |   |         +-o IOUSBMassStorageDriver  <class IOUSBMassStorageDriver, id 0x100000398, !registered, !matched, active, busy 0 (5179 ms), retain 9>
    | |   |   |           +-o IOSCSILogicalUnitNub@0  <class IOSCSILogicalUnitNub, id 0x10000039e, registered, matched, active, busy 0 (4697 ms), retain 8>
    | |   |   |             +-o IOSCSIPeripheralDeviceType00  <class IOSCSIPeripheralDeviceType00, id 0x1000003c4, !registered, !matched, active, busy 0 (63 ms), retain 9>
    | |   |   |               +-o IOBlockStorageServices  <class IOBlockStorageServices, id 0x1000003e4, registered, matched, active, busy 0 (63 ms), retain 6>
    | |   |   |                 +-o IOBlockStorageDriver  <class IOBlockStorageDriver, id 0x1000003e6, registered, matched, active, busy 0 (62 ms), retain 9>
    | |   |   |                   +-o JetFlash Transcend 32GB Media  <class IOMedia, id 0x1000003fb, registered, matched, active, busy 0 (62 ms), retain 17>
    | |   |   |                     +-o IOMediaBSDClient  <class IOMediaBSDClient, id 0x1000003fc, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   |   |                     +-o IOGUIDPartitionScheme  <class IOGUIDPartitionScheme, id 0x1000003fe, !registered, !matched, active, busy 0 (0 ms), retain 7>
    | |   |   |                       +-o EFI System Partition@1  <class IOMedia, id 0x100000401, registered, matched, active, busy 0 (0 ms), retain 15>
    | |   |   |                       | +-o IOMediaBSDClient  <class IOMediaBSDClient, id 0x100000403, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   |   |                       +-o Untitled 2@2  <class IOMedia, id 0x100000402, registered, matched, active, busy 0 (0 ms), retain 16>
    | |   |   |                         +-o IOMediaBSDClient  <class IOMediaBSDClient, id 0x100000404, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   |   +-o AppleUSBUHCIPort@5d200000  <class AppleUSBUHCIPort, id 0x1000002f6, registered, matched, active, busy 0 (0 ms), retain 11>
    | |   +-o EUS1@1D,7  <class IOPCIDevice, id 0x1000001c8, registered, matched, active, busy 0 (45 ms), retain 8>
    | |   +-o HUB@1E  <class IOPCIDevice, id 0x1000001bf, registered, matched, active, busy 0 (56 ms), retain 12>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x10000029e, registered, matched, active, busy 0 (8 ms), retain 8>
    | |   |   +-o FIRE@9  <class IOPCIDevice, id 0x1000001c1, registered, matched, active, busy 0 (8 ms), retain 10>
    | |   |     +-o AppleFWOHCI  <class AppleFWOHCI, id 0x1000002ae, !registered, !matched, active, busy 0 (5 ms), retain 6>
    | |   |       +-o IOFireWireController  <class IOFireWireController, id 0x1000002b0, registered, matched, active, busy 0 (5 ms), retain 10>
    | |   |         +-o IOFireWireLocalNode  <class IOFireWireLocalNode, id 0x1000002d1, registered, matched, active, busy 0 (5 ms), retain 13>
    | |   |           +-o IOFireWireUserClientIniter  <class IOFireWireUserClientIniter, id 0x1000002d2, !registered, !matched, active, busy 0, retain 4>
    | |   |           +-o IOFireWireUserClientIniter  <class IOFireWireUserClientIniter, id 0x10000032a, !registered, !matched, active, busy 0, retain 4>
    | |   |           +-o IOFireWireIP  <class IOFireWireIP, id 0x10000032b, registered, matched, active, busy 0 (2 ms), retain 7>
    | |   |             +-o fw0  <class IOFWInterface, id 0x10000032d, registered, matched, active, busy 0 (2 ms), retain 10>
    | |   |               +-o IONetworkStack  <class IONetworkStack, id 0x10000026c, registered, matched, active, busy 0 (0 ms), retain 12>
    | |   |                 +-o IONetworkStackUserClient  <class IONetworkStackUserClient, id 0x100000301, !registered, !matched, active, busy 0, retain 5>
    | |   +-o LPCB@1F  <class IOPCIDevice, id 0x1000001b1, registered, matched, active, busy 0 (5963 ms), retain 23>
    | |   | +-o AppleLPC  <class AppleLPC, id 0x1000003f1, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   | +-o com_apple_driver_eficheck  <class com_apple_driver_eficheck, id 0x1000003f3, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   +-o pci8086,2822@1F,2  <class IOPCIDevice, id 0x100000241, registered, matched, active, busy 0 (6706 ms), retain 17>
    | |     +-o AppleICH8AHCI  <class AppleICH8AHCI, id 0x100000299, registered, matched, active, busy 0 (0 ms), retain 24>
    | |       +-o PRT0@0  <class AppleAHCIPort, id 0x1000002b4, registered, matched, active, busy 0 (0 ms), retain 9>
    | |       +-o PRT1@1  <class AppleAHCIPort, id 0x1000002f3, registered, matched, active, busy 0 (0 ms), retain 9>
    | |       +-o PRT2@2  <class AppleAHCIPort, id 0x1000002f7, registered, matched, active, busy 0 (0 ms), retain 9>
    | |       +-o PRT3@3  <class AppleAHCIPort, id 0x1000002fa, registered, matched, active, busy 0 (0 ms), retain 9>
    | |       +-o PRT4@4  <class AppleAHCIPort, id 0x100000320, registered, matched, active, busy 0 (0 ms), retain 9>
    | |       +-o PRT5@5  <class AppleAHCIPort, id 0x1000003a7, registered, matched, active, busy 0 (0 ms), retain 9>
    | +-o HPET  <class IOACPIPlatformDevice, id 0x10000016b, registered, matched, active, busy 0 (5 ms), retain 8>
    | | +-o AppleHPET  <class AppleHPET, id 0x1000001de, !registered, !matched, active, busy 0, retain 4>
    | +-o RTC  <class IOACPIPlatformDevice, id 0x10000016c, registered, matched, active, busy 0 (257 ms), retain 9>
    | | +-o AppleRTC  <class AppleRTC, id 0x1000001da, registered, matched, active, busy 0 (0 ms), retain 7>
    | +-o DMAC  <class IOACPIPlatformDevice, id 0x10000016d, registered, matched, active, busy 0 (3 ms), retain 7>
    | +-o EC  <class IOACPIPlatformDevice, id 0x10000016e, registered, matched, active, busy 0 (257 ms), retain 9>
    | | +-o AppleBusPowerController  <class AppleBusPowerController, id 0x1000001dc, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o ALS0  <class IOACPIPlatformDevice, id 0x10000016f, registered, matched, active, busy 0 (386 ms), retain 7>
    | +-o NCP  <class IOACPIPlatformDevice, id 0x100000170, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o PIC  <class IOACPIPlatformDevice, id 0x100000171, registered, matched, active, busy 0 (3 ms), retain 7>
    | +-o TIME  <class IOACPIPlatformDevice, id 0x100000172, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o PS2M  <class IOACPIPlatformDevice, id 0x100000173, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o KBD  <class IOACPIPlatformDevice, id 0x100000174, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o APIC  <class IOACPIPlatformDevice, id 0x100000175, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o TPM  <class IOACPIPlatformDevice, id 0x100000176, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o SBD1  <class IOACPIPlatformDevice, id 0x10000019e, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o SBD2  <class IOACPIPlatformDevice, id 0x10000019f, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o SBD3  <class IOACPIPlatformDevice, id 0x1000001a0, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o PCI1@0  <class IOACPIPlatformDevice, id 0x1000001a1, registered, matched, active, busy 0 (1762 ms), retain 29>
    | | +-o AppleACPIPCI  <class AppleACPIPCI, id 0x1000001d9, registered, matched, active, busy 0 (1472 ms), retain 30>
    | |   +-o IOH3@3  <class IOPCIDevice, id 0x1000001d2, registered, matched, active, busy 0 (169 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x100000245, registered, matched, active, busy 0 (45 ms), retain 8>
    | |   |   +-o SLT5@0  <class IOPCIDevice, id 0x1000001d3, registered, matched, active, busy 0 (45 ms), retain 9>
    | |   +-o IOH7@7  <class IOPCIDevice, id 0x1000001d4, registered, matched, active, busy 0 (143 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x100000243, registered, matched, active, busy 0 (65 ms), retain 8>
    | |   |   +-o SLT7@0  <class IOPCIDevice, id 0x1000001d5, registered, matched, active, busy 0 (65 ms), retain 12>
    | |   |     +-o SLT7@00000000  <class AppleUSBXHCIFL1100, id 0x100000292, registered, matched, active, busy 0 (0 ms), retain 54>
    | |   |       +-o AppleUSB20XHCIPort@00100000  <class AppleUSB20XHCIPort, id 0x1000002b6, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |       +-o AppleUSB20XHCIPort@00200000  <class AppleUSB20XHCIPort, id 0x1000002b7, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |       +-o AppleUSB20XHCIPort@00300000  <class AppleUSB20XHCIPort, id 0x1000002b8, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |       +-o AppleUSB20XHCIPort@00400000  <class AppleUSB20XHCIPort, id 0x1000002b9, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |       +-o AppleUSB30XHCIPort@00500000  <class AppleUSB30XHCIPort, id 0x1000002ba, registered, matched, active, busy 0 (0 ms), retain 13>
    | |   |       +-o AppleUSB30XHCIPort@00600000  <class AppleUSB30XHCIPort, id 0x1000002d0, registered, matched, active, busy 0 (0 ms), retain 13>
    | |   |       +-o AppleUSB30XHCIPort@00700000  <class AppleUSB30XHCIPort, id 0x1000002d4, registered, matched, active, busy 0 (0 ms), retain 13>
    | |   |       +-o AppleUSB30XHCIPort@00800000  <class AppleUSB30XHCIPort, id 0x1000002d5, registered, matched, active, busy 0 (0 ms), retain 13>
    | |   +-o IOH9@9  <class IOPCIDevice, id 0x1000001d6, registered, matched, active, busy 0 (1472 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x100000246, registered, matched, active, busy 0 (1394 ms), retain 8>
    | |   |   +-o SAS0@0  <class IOPCIDevice, id 0x1000001d7, registered, matched, active, busy 0 (1394 ms), retain 10>
    | |   |     +-o AppleLSIFusionSAS  <class AppleLSIFusionSAS, id 0x100000263, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   +-o pci8086,3425@10  <class IOPCIDevice, id 0x1000001f7, registered, matched, active, busy 0 (13 ms), retain 8>
    | |   +-o pci8086,3426@10,1  <class IOPCIDevice, id 0x1000001f8, registered, matched, active, busy 0 (13 ms), retain 8>
    | |   +-o pci8086,3427@11  <class IOPCIDevice, id 0x1000001f9, registered, matched, active, busy 0 (13 ms), retain 8>
    | |   +-o pci8086,3428@11,1  <class IOPCIDevice, id 0x1000001fa, registered, matched, active, busy 0 (13 ms), retain 8>
    | |   +-o IH20@14  <class IOPCIDevice, id 0x1000001d1, registered, matched, active, busy 0 (12 ms), retain 8>
    | |   +-o pci8086,3422@14,1  <class IOPCIDevice, id 0x1000001fb, registered, matched, active, busy 0 (13 ms), retain 8>
    | |   +-o pci8086,3423@14,2  <class IOPCIDevice, id 0x1000001fc, registered, matched, active, busy 0 (12 ms), retain 8>
    | |   +-o pci8086,342f@15  <class IOPCIDevice, id 0x1000001fd, registered, matched, active, busy 0 (12 ms), retain 8>
    | +-o VTD1  <class IOACPIPlatformDevice, id 0x1000001a9, registered, matched, active, busy 0 (3 ms), retain 7>
    | +-o NHL1@0  <class IOACPIPlatformDevice, id 0x1000001aa, registered, matched, active, busy 0 (367 ms), retain 35>
    | | +-o AppleACPIPCI  <class AppleACPIPCI, id 0x1000001db, registered, matched, active, busy 0 (48 ms), retain 55>
    | |   +-o pci8086,2c70@0  <class IOPCIDevice, id 0x10000020a, registered, matched, active, busy 0 (2 ms), retain 8>
    | |   +-o pci8086,2d81@0,1  <class IOPCIDevice, id 0x10000020b, registered, matched, active, busy 0 (3 ms), retain 8>
    | |   +-o pci8086,2d90@2  <class IOPCIDevice, id 0x10000020c, registered, matched, active, busy 0 (14 ms), retain 8>
    | |   +-o pci8086,2d91@2,1  <class IOPCIDevice, id 0x10000020d, registered, matched, active, busy 0 (45 ms), retain 8>
    | |   +-o pci8086,2d92@2,2  <class IOPCIDevice, id 0x10000020e, registered, matched, active, busy 0 (46 ms), retain 8>
    | |   +-o pci8086,2d93@2,3  <class IOPCIDevice, id 0x10000020f, registered, matched, active, busy 0 (45 ms), retain 8>
    | |   +-o pci8086,2d94@2,4  <class IOPCIDevice, id 0x100000210, registered, matched, active, busy 0 (48 ms), retain 8>
    | |   +-o pci8086,2d95@2,5  <class IOPCIDevice, id 0x100000211, registered, matched, active, busy 0 (46 ms), retain 8>
    | |   +-o pci8086,2d98@3  <class IOPCIDevice, id 0x100000212, registered, matched, active, busy 0 (48 ms), retain 8>
    | |   +-o pci8086,2d99@3,1  <class IOPCIDevice, id 0x100000213, registered, matched, active, busy 0 (44 ms), retain 8>
    | |   +-o pci8086,2d9a@3,2  <class IOPCIDevice, id 0x100000214, registered, matched, active, busy 0 (46 ms), retain 8>
    | |   +-o pci8086,2d9c@3,4  <class IOPCIDevice, id 0x100000215, registered, matched, active, busy 0 (41 ms), retain 8>
    | |   +-o pci8086,2da0@4  <class IOPCIDevice, id 0x100000216, registered, matched, active, busy 0 (47 ms), retain 8>
    | |   +-o pci8086,2da1@4,1  <class IOPCIDevice, id 0x100000217, registered, matched, active, busy 0 (43 ms), retain 8>
    | |   +-o pci8086,2da2@4,2  <class IOPCIDevice, id 0x100000218, registered, matched, active, busy 0 (46 ms), retain 8>
    | |   +-o pci8086,2da3@4,3  <class IOPCIDevice, id 0x100000219, registered, matched, active, busy 0 (47 ms), retain 8>
    | |   +-o pci8086,2da8@5  <class IOPCIDevice, id 0x10000021a, registered, matched, active, busy 0 (45 ms), retain 8>
    | |   +-o pci8086,2da9@5,1  <class IOPCIDevice, id 0x10000021b, registered, matched, active, busy 0 (39 ms), retain 8>
    | |   +-o pci8086,2daa@5,2  <class IOPCIDevice, id 0x10000021c, registered, matched, active, busy 0 (46 ms), retain 8>
    | |   +-o pci8086,2dab@5,3  <class IOPCIDevice, id 0x10000021d, registered, matched, active, busy 0 (47 ms), retain 8>
    | |   +-o pci8086,2db0@6  <class IOPCIDevice, id 0x10000021e, registered, matched, active, busy 0 (47 ms), retain 8>
    | |   +-o pci8086,2db1@6,1  <class IOPCIDevice, id 0x10000021f, registered, matched, active, busy 0 (42 ms), retain 8>
    | |   +-o pci8086,2db2@6,2  <class IOPCIDevice, id 0x100000220, registered, matched, active, busy 0 (45 ms), retain 8>
    | |   +-o pci8086,2db3@6,3  <class IOPCIDevice, id 0x100000221, registered, matched, active, busy 0 (44 ms), retain 8>
    | +-o SLPB  <class IOACPIPlatformDevice, id 0x1000001ab, registered, matched, active, busy 0 (5 ms), retain 8>
    | | +-o AppleACPIButton  <class AppleACPIButton, id 0x1000001e0, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   +-o IOHIDEventServiceUserClient  <class IOHIDEventServiceUserClient, id 0x10000030f, !registered, !matched, active, busy 0, retain 6>
    | +-o PNLF@0  <class IOACPIPlatformDevice, id 0x1000001ac, registered, matched, active, busy 0 (30046 ms), retain 10>
    | | +-o AppleMCCSControlCello  <class AppleMCCSControlCello, id 0x100000334, !registered, !matched, active, busy 0, retain 4>
    | +-o MBRD  <class IOACPIPlatformDevice, id 0x1000001ad, registered, matched, active, busy 0 (3 ms), retain 7>
    | +-o PBTN  <class IOACPIPlatformDevice, id 0x1000001ae, registered, matched, active, busy 0 (6 ms), retain 9>
    | | +-o AppleACPIButton  <class AppleACPIButton, id 0x1000001df, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   +-o IOHIDEventServiceUserClient  <class IOHIDEventServiceUserClient, id 0x10000030e, !registered, !matched, active, busy 0, retain 6>
    | +-o WMID  <class IOACPIPlatformDevice, id 0x1000001af, registered, matched, active, busy 0 (3 ms), retain 7>
    | +-o FSMC  <class FakeSMC, id 0x1000001e2, registered, matched, active, busy 0 (0 ms), retain 7>
    | +-o SMC  <class FakeSMCDevice, id 0x1000001e5, registered, matched, active, busy 0 (34 ms), retain 8>
    | | +-o AppleSMC  <class AppleSMC, id 0x1000001e6, registered, matched, active, busy 0 (32 ms), retain 8>
    | |   +-o SMCWatchDogTimer  <class SMCWatchDogTimer, id 0x1000001e8, registered, matched, active, busy 0 (32 ms), retain 8>
    | |   | +-o AppleOSXWatchdog  <class AppleOSXWatchdog, id 0x100000330, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   |   +-o AppleOSXWatchdogClient  <class AppleOSXWatchdogClient, id 0x100000331, !registered, !matched, active, busy 0, retain 5>
    | |   +-o AppleSMCClient  <class AppleSMCClient, id 0x100000328, !registered, !matched, active, busy 0, retain 6>
    | +-o AppleEFIRuntime  <class AppleEFIRuntime, id 0x1000001e3, registered, matched, active, busy 0 (0 ms), retain 8>
    |   +-o AppleEFINVRAM  <class AppleEFINVRAM, id 0x1000001e9, registered, matched, active, busy 0 (0 ms), retain 10>
    +-o IOResources  <class IOResources, id 0x100000114, registered, matched, active, busy 0 (5702 ms), retain 47>
      +-o AppleIntelCPUPowerManagement  <class NullCPUPowerManagement, id 0x100000118, !registered, !matched, active, busy 0, retain 4>
      +-o IOReportHub  <class IOReportHub, id 0x100000119, registered, matched, active, busy 0 (7 ms), retain 6>
      | +-o IOReportUserClient  <class IOReportUserClient, id 0x100000327, !registered, !matched, active, busy 0, retain 5>
      +-o FakeSMCKeyStore  <class FakeSMCKeyStore, id 0x10000011a, registered, matched, active, busy 0 (7 ms), retain 11>
      | +-o FakeSMCKeyStoreUserClient  <class FakeSMCKeyStoreUserClient, id 0x1000004e4, !registered, !matched, active, busy 0, retain 5>
      +-o IOTimeSyncClockManager  <class IOTimeSyncClockManager, id 0x10000011b, registered, matched, active, busy 0 (0 ms), retain 6>
      +-o IOHDIXController  <class IOHDIXController, id 0x10000011c, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o IOBufferCopyEngineTestDummy  <class IOBufferCopyEngineTestDummy, id 0x10000011e, registered, matched, active, busy 0 (10 ms), retain 5>
      +-o AppleCredentialManager  <class AppleCredentialManager, id 0x10000011f, registered, matched, active, busy 0 (4 ms), retain 7>
      | +-o AppleCredentialManagerUserClient  <class AppleCredentialManagerUserClient, id 0x100000499, !registered, !matched, active, busy 0, retain 5>
      +-o AppleKeyStore  <class AppleKeyStore, id 0x100000120, registered, matched, active, busy 0 (7 ms), retain 17>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x100000316, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x10000049a, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x10000049d, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x10000049e, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x1000004a4, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x1000004aa, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x1000004c8, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x1000004da, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x1000004ef, !registered, !matched, active, busy 0, retain 6>
      +-o AppleFDEKeyStore  <class AppleFDEKeyStore, id 0x100000122, registered, matched, active, busy 0 (0 ms), retain 6>
      +-o WhateverGreen  <class WhateverGreen, id 0x100000123, !registered, !matched, active, busy 0, retain 4>
      +-o Lilu  <class Lilu, id 0x100000124, !registered, !matched, active, busy 0, retain 4>
      +-o AppleUSBHostResources  <class AppleUSBHostResources, id 0x1000001ef, registered, matched, active, busy 0 (5197 ms), retain 42>
      | +-o AppleUSBLegacyRoot  <class AppleUSBLegacyRoot, id 0x1000001f3, registered, matched, active, busy 0 (5196 ms), retain 21>
      | | +-o AppleUSBUHCI@5d000000  <class AppleUSBController, id 0x100000374, registered, matched, active, busy 0 (21 ms), retain 9>
      | | | +-o AppleUSBUHCI Root Hub Simulation@5d000000  <class AppleUSBRootHubDevice, id 0x100000375, registered, matched, active, busy 0 (4 ms), retain 9>
      | | | +-o Mass Storage Device@5d100000  <class AppleUSBDevice, id 0x100000377, registered, matched, active, busy 0 (21 ms), retain 11>
      | | |   +-o AppleUSBInterface@0  <class AppleUSBInterface, id 0x10000038b, registered, matched, active, busy 0 (20 ms), retain 5>
      | | +-o AppleUSBUHCI@3d000000  <class AppleUSBController, id 0x10000037d, registered, matched, active, busy 0 (5184 ms), retain 13>
      | |   +-o AppleUSBUHCI Root Hub Simulation@3d000000  <class AppleUSBRootHubDevice, id 0x10000037e, registered, matched, active, busy 0 (4 ms), retain 10>
      | |   +-o Razer Naga 2014@3d100000  <class AppleUSBDevice, id 0x100000381, registered, matched, active, busy 0 (5162 ms), retain 28>
      | |   | +-o AppleUSBInterface@0  <class AppleUSBInterface, id 0x100000397, registered, matched, active, busy 0 (52 ms), retain 9>
      | |   | | +-o RzHidInterface  <class RzHidInterface, id 0x10000039a, registered, matched, active, busy 0 (24 ms), retain 17>
      | |   | |   +-o RzHidDevice  <class RzHidDevice, id 0x10000039d, registered, matched, active, busy 0 (0 ms), retain 9>
      | |   | |   | +-o RzUserClient  <class RzUserClient, id 0x1000004fb, !registered, !matched, active, busy 0, retain 5>
      | |   | |   +-o IOHIDInterface  <class IOHIDInterface, id 0x1000003a0, registered, matched, active, busy 0 (23 ms), retain 7>
      | |   | |   | +-o IOHIDEventDriver  <class IOHIDEventDriver, id 0x1000003a1, registered, matched, active, busy 0 (7 ms), retain 9>
      | |   | |   |   +-o IOHIDEventServiceUserClient  <class IOHIDEventServiceUserClient, id 0x1000003a4, !registered, !matched, active, busy 0, retain 6>
      | |   | |   +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x100000492, !registered, !matched, active, busy 0, retain 6>
      | |   | |   +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x1000004ff, !registered, !matched, active, busy 0, retain 6>
      | |   | |   +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x100000510, !registered, !matched, active, busy 0, retain 6>
      | |   | |   +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x100000512, !registered, !matched, active, busy 0, retain 6>
      | |   | +-o AppleUSBInterface@1  <class AppleUSBInterface, id 0x1000003a6, registered, matched, active, busy 0 (5081 ms), retain 9>
      | |   | | +-o RzHidInterface  <class RzHidInterface, id 0x1000003a9, registered, matched, active, busy 0 (5056 ms), retain 10>
      | |   | |   +-o IOHIDInterface  <class IOHIDInterface, id 0x1000003ab, registered, matched, active, busy 0 (5056 ms), retain 7>
      | |   | |   | +-o IOHIDEventDriver  <class IOHIDEventDriver, id 0x1000003ac, registered, matched, active, busy 0 (5039 ms), retain 8>
      | |   | |   |   +-o IOHIDEventServiceUserClient  <class IOHIDEventServiceUserClient, id 0x1000003bc, !registered, !matched, active, busy 0, retain 6>
      | |   | |   +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x100000491, !registered, !matched, active, busy 0, retain 6>
      | |   | +-o AppleUSBInterface@2  <class AppleUSBInterface, id 0x1000003bf, registered, matched, active, busy 0 (50 ms), retain 9>
      | |   | | +-o RzHidInterface  <class RzHidInterface, id 0x1000003e9, registered, matched, active, busy 0 (27 ms), retain 10>
      | |   | |   +-o IOHIDInterface  <class IOHIDInterface, id 0x1000003eb, registered, matched, active, busy 0 (27 ms), retain 7>
      | |   | |   | +-o IOHIDEventDriver  <class IOHIDEventDriver, id 0x1000003ec, registered, matched, active, busy 0 (0 ms), retain 9>
      | |   | |   |   +-o IOHIDEventServiceUserClient  <class IOHIDEventServiceUserClient, id 0x1000003f0, !registered, !matched, active, busy 0, retain 6>
      | |   | |   +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x100000490, !registered, !matched, active, busy 0, retain 6>
      | |   | +-o RzDeviceEngine  <class IOUSBDeviceUserClientV2, id 0x1000004fe, !registered, !matched, active, busy 0, retain 5>
      | |   +-o IOUSBHostDevice@3d200000  <class AppleUSBDevice, id 0x100000411, registered, matched, active, busy 0 (0 ms), retain 12>
      | |   | +-o AppleUSBInterface@0  <class AppleUSBInterface, id 0x10000041b, !registered, !matched, active, busy 0, retain 4>
      | |   +-o Apple Keyboard@3d220000  <class AppleUSBDevice, id 0x100000424, registered, matched, active, busy 0 (20 ms), retain 13>
      | |     +-o AppleUSBInterface@0  <class AppleUSBInterface, id 0x10000042e, registered, matched, active, busy 0 (9 ms), retain 5>
      | |     +-o AppleUSBInterface@1  <class AppleUSBInterface, id 0x100000432, registered, matched, active, busy 0 (9 ms), retain 5>
      | +-o AppleUSBHostPacketFilterService  <class AppleUSBHostPacketFilterService, id 0x1000001f5, !registered, !matched, active, busy 0, retain 4>
      +-o net_lundman_zfs_zvol  <class net_lundman_zfs_zvol, id 0x10000026b, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o IONetworkStack  <class IONetworkStack, id 0x10000026c, registered, matched, active, busy 0 (0 ms), retain 12>
      | +-o IONetworkStackUserClient  <class IONetworkStackUserClient, id 0x100000301, !registered, !matched, active, busy 0, retain 5>
      +-o IOHIDResource  <class IOHIDResource, id 0x10000026d, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o IOHIDSystem  <class IOHIDSystem, id 0x10000026e, registered, matched, active, busy 0 (0 ms), retain 18>
      | +-o IOHIDEventSystemUserClient  <class IOHIDEventSystemUserClient, id 0x10000030d, !registered, !matched, active, busy 0, retain 5>
      | +-o IOHIDUserClient  <class IOHIDUserClient, id 0x100000444, !registered, !matched, active, busy 0, retain 5>
      | +-o IOHIDParamUserClient  <class IOHIDParamUserClient, id 0x100000445, !registered, !matched, active, busy 0, retain 7>
      +-o at_obdev_LSNKE  <class at_obdev_LSNKE, id 0x10000026f, registered, matched, active, busy 0 (0 ms), retain 12>
      | +-o IORegistryDescriptorC3  <class IORegistryDescriptorC3, id 0x100000319, !registered, !matched, active, busy 0, retain 7>
      | +-o IORegistryDescriptorC5  <class IORegistryDescriptorC5, id 0x10000031a, !registered, !matched, active, busy 0, retain 5>
      | +-o IORegistryDescriptorC5  <class IORegistryDescriptorC5, id 0x10000031b, !registered, !matched, active, busy 0, retain 5>
      | +-o IORegistryDescriptorC5  <class IORegistryDescriptorC5, id 0x10000031c, !registered, !matched, active, busy 0, retain 5>
      | +-o IORegistryDescriptorC5  <class IORegistryDescriptorC5, id 0x10000031d, !registered, !matched, active, busy 0, retain 5>
      | +-o IORegistryDescriptorC2  <class IORegistryDescriptorC2, id 0x1000004ab, !registered, !matched, active, busy 0, retain 5>
      | +-o IORegistryDescriptorC4  <class IORegistryDescriptorC4, id 0x1000004dd, !registered, !matched, active, busy 0, retain 5>
      +-o AppleMobileFileIntegrity  <class AppleMobileFileIntegrity, id 0x100000270, registered, matched, active, busy 0 (0 ms), retain 6>
      +-o com_apple_filesystems_hfs_encodings  <class com_apple_filesystems_hfs_encodings, id 0x100000272, !registered, !matched, active, busy 0, retain 4>
      +-o com_apple_filesystems_hfs  <class com_apple_filesystems_hfs, id 0x100000273, !registered, !matched, active, busy 0, retain 4>
      +-o com_apple_BootCache  <class com_apple_BootCache, id 0x100000274, !registered, !matched, active, busy 0, retain 4>
      +-o com_apple_AppleFSCompression_AppleFSCompressionTypeZlib  <class com_apple_AppleFSCompression_AppleFSCompressionTypeZlib, id 0x100000275, !registered, !matched, active, busy 0, retain 4>
      +-o com_apple_AppleFSCompression_AppleFSCompressionTypeDataless  <class com_apple_AppleFSCompression_AppleFSCompressionTypeDataless, id 0x100000276, !registered, !matched, active, busy 0, retain 4>
      +-o AppleSCSISubsystemGlobals  <class AppleSCSISubsystemGlobals, id 0x1000002fd, registered, matched, active, busy 0 (0 ms), retain 6>
      +-o AppleIntelSlowAdaptiveClockingManager  <class AppleIntelSlowAdaptiveClockingManager, id 0x100000344, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o AppleGPUWrangler  <class AppleGPUWrangler, id 0x100000345, registered, matched, active, busy 0 (3 ms), retain 8>
      | +-o AppleGraphicsDeviceControlPlugin  <class AppleGraphicsDeviceControlPlugin, id 0x100000351, registered, matched, active, busy 0 (0 ms), retain 7>
      | | +-o AGDCPluginDisplayMetrics  <class AGDCPluginDisplayMetrics, id 0x100000352, !registered, !matched, active, busy 0, retain 5>
      | +-o AppleGPUWranglerClient  <class AppleGPUWranglerClient, id 0x10000036e, !registered, !matched, active, busy 0, retain 5>
      | +-o AppleGPUWranglerClient  <class AppleGPUWranglerClient, id 0x10000047a, !registered, !matched, active, busy 0, retain 5>
      +-o AppleHV  <class AppleHV, id 0x100000347, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o AppleSSE  <class AppleSSE, id 0x100000348, registered, matched, active, busy 0 (0 ms), retain 8>
      +-o Dont_Steal_Mac_OS_X  <class Dont_Steal_Mac_OS_X, id 0x100000349, !registered, !matched, active, busy 0, retain 5>
      +-o IOBluetoothHCIController  <class IOBluetoothHCIController, id 0x10000034a, !registered, !matched, active, busy 0, retain 4>
      +-o IOBluetoothSerialManager  <class IOBluetoothSerialManager, id 0x10000034b, registered, matched, active, busy 0 (1 ms), retain 6>
      | +-o IOBluetoothSerialClient  <class IOBluetoothSerialClient, id 0x100000355, !registered, !matched, active, busy 0 (0 ms), retain 5>
      |   +-o IOBluetoothSerialClientSerialStreamSync  <class IOBluetoothSerialClientSerialStreamSync, id 0x100000359, registered, matched, active, busy 0 (0 ms), retain 6>
      |     +-o IOSerialBSDClient  <class IOSerialBSDClient, id 0x10000035a, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o IODisplayWrangler  <class IODisplayWrangler, id 0x10000034c, registered, matched, active, busy 0 (1 ms), retain 10>
      | +-o IOAccelerationUserClient  <class IOAccelerationUserClient, id 0x10000047e, !registered, !matched, active, busy 0, retain 5>
      +-o IOSurfaceRoot  <class IOSurfaceRoot, id 0x10000034d, registered, matched, active, busy 0 (1 ms), retain 24>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x10000047c, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x1000004ad, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x1000004b5, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x1000004bb, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x1000004c9, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x1000004cf, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x1000004ea, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x1000004f3, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x100000505, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x100000514, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x100000519, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x10000052a, !registered, !matched, active, busy 0, retain 5>
      +-o IOUserEthernetResource  <class IOUserEthernetResource, id 0x10000034e, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o com_apple_driver_pmtelemetry  <class com_apple_driver_pmtelemetry, id 0x10000034f, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o com_mologie_NVWebDriverLibValFix  <class com_mologie_NVWebDriverLibValFix, id 0x100000350, !registered, !matched, active, busy 0, retain 4>
      +-o org_virtualbox_SupDrv  <class org_virtualbox_SupDrv, id 0x1000003fa, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o org_virtualbox_VBoxUSB  <class org_virtualbox_VBoxUSB, id 0x100000406, registered, matched, active, busy 0 (1 ms), retain 5>
Link to comment
Share on other sites
Pavo
Pavo
Posted
Posted



Since this is a BIOS board I added back the Drivers64 folder.

It did boot but screen went black.

Here's the ioreg dump, it's 1:50am here now so I'll soon go to bed.

EDIT: This is a bit off topic but would it be possible to inject a different Subsystem ID for the 10Gb Network card?

Vendor ID: 0x8086

Device ID: 0x10fb

Subsystem Vendor ID: 0x8086

Subsystem ID: 0x0006 <-- THIS needs to be 0x000a for the drivers to load. It would be nice to not have to flash the card.

ioreg
+-o Root  <class IORegistryEntry, id 0x100000100, retain 10>
  +-o MacPro5,1  <class IOPlatformExpertDevice, id 0x100000111, registered, matched, active, busy 0 (36466 ms), retain 51>
    +-o AppleACPIPlatformExpert  <class AppleACPIPlatformExpert, id 0x100000112, registered, matched, active, busy 0 (36172 ms), retain 64>
    | +-o IOPMrootDomain  <class IOPMrootDomain, id 0x100000115, registered, matched, active, busy 0 (103 ms), retain 85>
    | | +-o IORootParent  <class IORootParent, id 0x100000116, !registered, !matched, active, busy 0, retain 7>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000002fc, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000002ff, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000302, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000303, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000304, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000307, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x10000030c, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000310, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000311, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000312, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000313, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000314, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000315, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000318, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x10000031e, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000322, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000323, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000324, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000329, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000332, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000003ae, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000003b7, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000484, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x10000048c, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000493, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x10000049f, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004a0, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004a3, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004a7, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004a8, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004a9, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004ac, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004b2, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004b4, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004b6, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d1, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d2, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d3, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d4, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d5, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d6, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d7, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004d9, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004db, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004dc, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004de, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004e0, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004e6, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004e7, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004e8, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004e9, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004f0, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004f1, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004f2, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004f8, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004f9, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x1000004fa, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000504, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x10000050a, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x10000050c, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x10000050f, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000511, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000518, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000528, !registered, !matched, active, busy 0, retain 5>
    | | +-o RootDomainUserClient  <class RootDomainUserClient, id 0x100000529, !registered, !matched, active, busy 0, retain 5>
    | +-o IOPCIMessagedInterruptController  <class IOPCIMessagedInterruptController, id 0x100000127, registered, matched, active, busy 0 (0 ms), retain 7>
    | +-o cpus  <class IOPlatformDevice, id 0x100000128, registered, matched, active, busy 0 (0 ms), retain 30>
    | +-o CPU0@0  <class IOACPIPlatformDevice, id 0x100000129, registered, matched, active, busy 0 (6277 ms), retain 9>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x100000142, registered, matched, active, busy 0 (5634 ms), retain 8>
    | | | +-o AppleACPICPUInterruptController  <class AppleACPICPUInterruptController, id 0x10000015b, registered, matched, active, busy 0 (0 ms), retain 6>
    | | | +-o ACPI_SMC_PlatformPlugin  <class ACPI_SMC_PlatformPlugin, id 0x10000032f, registered, matched, active, busy 0 (5627 ms), retain 13>
    | | |   +-o AGPMEnabler  <class IOPlatformPluginDevice, id 0x1000003b8, registered, matched, active, busy 0 (14 ms), retain 7>
    | | |   | +-o AGPMController  <class AGPMController, id 0x1000003c0, !registered, !matched, active, busy 0, retain 4>
    | | |   +-o AppleTyMCEDriver  <class AppleTyMCEDriver, id 0x1000003be, registered, matched, active, busy 0 (0 ms), retain 6>
    | | |     +-o AppleTyMCEInterruptController  <class AppleTyMCEInterruptController, id 0x1000003ed, registered, matched, active, busy 0 (0 ms), retain 7>
    | | +-o CPUSensors  <class CPUSensors, id 0x100000143, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU1@2  <class IOACPIPlatformDevice, id 0x10000012a, registered, matched, active, busy 0 (590 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x100000144, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU2@4  <class IOACPIPlatformDevice, id 0x10000012b, registered, matched, active, busy 0 (591 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x100000145, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU3@10  <class IOACPIPlatformDevice, id 0x10000012c, registered, matched, active, busy 0 (592 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x100000146, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU4@12  <class IOACPIPlatformDevice, id 0x10000012d, registered, matched, active, busy 0 (593 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x100000147, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU5@14  <class IOACPIPlatformDevice, id 0x10000012e, registered, matched, active, busy 0 (594 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x100000148, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU6@1  <class IOACPIPlatformDevice, id 0x10000012f, registered, matched, active, busy 0 (595 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x100000149, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU7@3  <class IOACPIPlatformDevice, id 0x100000130, registered, matched, active, busy 0 (597 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x10000014a, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU8@5  <class IOACPIPlatformDevice, id 0x100000131, registered, matched, active, busy 0 (598 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x10000014b, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPU9@11  <class IOACPIPlatformDevice, id 0x100000132, registered, matched, active, busy 0 (599 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x10000014c, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPUA@13  <class IOACPIPlatformDevice, id 0x100000133, registered, matched, active, busy 0 (600 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x10000014d, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPUB@15  <class IOACPIPlatformDevice, id 0x100000134, registered, matched, active, busy 0 (601 ms), retain 8>
    | | +-o AppleACPICPU  <class AppleACPICPU, id 0x10000014e, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o CPUC  <class IOACPIPlatformDevice, id 0x100000135, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUD  <class IOACPIPlatformDevice, id 0x100000136, registered, matched, active, busy 0 (601 ms), retain 7>
    | +-o CPUE  <class IOACPIPlatformDevice, id 0x100000137, registered, matched, active, busy 0 (601 ms), retain 7>
    | +-o CPUF  <class IOACPIPlatformDevice, id 0x100000138, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUG  <class IOACPIPlatformDevice, id 0x100000139, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUH  <class IOACPIPlatformDevice, id 0x10000013a, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUI  <class IOACPIPlatformDevice, id 0x10000013b, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUJ  <class IOACPIPlatformDevice, id 0x10000013c, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUK  <class IOACPIPlatformDevice, id 0x10000013d, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUL  <class IOACPIPlatformDevice, id 0x10000013e, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUM  <class IOACPIPlatformDevice, id 0x10000013f, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o CPUN  <class IOACPIPlatformDevice, id 0x100000140, registered, matched, active, busy 0 (602 ms), retain 7>
    | +-o io-apic@fec00000  <class IOACPIPlatformDevice, id 0x100000141, registered, matched, active, busy 0 (24 ms), retain 7>
    | | +-o AppleAPICInterruptController  <class AppleAPICInterruptController, id 0x10000015d, registered, matched, active, busy 0 (0 ms), retain 12>
    | +-o io-apic@fec10000  <class IOACPIPlatformDevice, id 0x10000015c, registered, matched, active, busy 0 (1 ms), retain 7>
    | | +-o AppleAPICInterruptController  <class AppleAPICInterruptController, id 0x10000015e, registered, matched, active, busy 0 (0 ms), retain 7>
    | +-o AppleACPIEventController  <class AppleACPIEventController, id 0x10000015f, !registered, !matched, active, busy 0, retain 6>
    | +-o bios  <class IOPlatformDevice, id 0x100000162, registered, matched, active, busy 0 (0 ms), retain 6>
    | | +-o AppleSMBIOS  <class AppleSMBIOS, id 0x100000163, registered, matched, active, busy 0 (0 ms), retain 5>
    | +-o PCI0@0  <class IOACPIPlatformDevice, id 0x100000168, registered, matched, active, busy 0 (11542 ms), retain 86>
    | | +-o AppleACPIPCI  <class AppleACPIPCI, id 0x1000001d8, registered, matched, active, busy 0 (11171 ms), retain 61>
    | |   +-o MCHC@0  <class IOPCIDevice, id 0x1000001cb, registered, matched, active, busy 0 (30 ms), retain 8>
    | |   +-o IOH1@1  <class IOPCIDevice, id 0x1000001b2, registered, matched, active, busy 0 (95 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x10000028c, registered, matched, active, busy 0 (34 ms), retain 8>
    | |   |   +-o SLT1@0  <class IOPCIDevice, id 0x1000001b3, registered, matched, active, busy 0 (34 ms), retain 13>
    | |   |     +-o IONVMeController  <class IONVMeController, id 0x1000002a9, registered, matched, active, busy 0 (2 ms), retain 10>
    | |   |       +-o IONVMeBlockStorageDevice@1  <class IONVMeBlockStorageDevice, id 0x1000002bc, registered, matched, active, busy 0 (2 ms), retain 12>
    | |   |         +-o IOBlockStorageDriver  <class IOBlockStorageDriver, id 0x1000002bd, registered, matched, active, busy 0 (2 ms), retain 9>
    | |   |           +-o Samsung SSD 950 PRO 512GB Media  <class IOMedia, id 0x1000002be, registered, matched, active, busy 0 (2 ms), retain 17>
    | |   |             +-o IOMediaBSDClient  <class IOMediaBSDClient, id 0x1000002bf, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   |             +-o IOGUIDPartitionScheme  <class IOGUIDPartitionScheme, id 0x1000002c1, !registered, !matched, active, busy 0 (0 ms), retain 8>
    | |   |               +-o EFI System Partition@1  <class IOMedia, id 0x1000002c4, registered, matched, active, busy 0 (0 ms), retain 15>
    | |   |               | +-o IOMediaBSDClient  <class IOMediaBSDClient, id 0x1000002c7, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   |               +-o Untitled 2@2  <class IOMedia, id 0x1000002c5, registered, matched, active, busy 0 (0 ms), retain 17>
    | |   |               | +-o IOMediaBSDClient  <class IOMediaBSDClient, id 0x1000002c8, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   |               +-o Untitled 3@3  <class IOMedia, id 0x1000002c6, registered, matched, active, busy 0 (0 ms), retain 15>
    | |   |                 +-o IOMediaBSDClient  <class IOMediaBSDClient, id 0x1000002c9, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   +-o IOH3@3  <class IOPCIDevice, id 0x1000001b4, registered, matched, active, busy 0 (5737 ms), retain 12>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x100000277, registered, matched, active, busy 0 (5681 ms), retain 10>
    | |   |   +-o GFX0@0  <class IOPCIDevice, id 0x1000001b5, registered, matched, active, busy 0 (5673 ms), retain 32>
    | |   |   | +-o RadeonSensors  <class RadeonSensors, id 0x100000295, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | +-o AMDRadeonX4000_AMDRadeonHWServicesBaffin  <class AMDRadeonX4000_AMDRadeonHWServicesBaffin, id 0x100000338, registered, matched, active, busy 0 (2 ms), retain 6>
    | |   |   | | +-o AMDRadeonX4000_AMDRadeonHWLibs  <class AMDRadeonX4000_AMDRadeonHWLibs, id 0x100000343, !registered, !matched, active, busy 0, retain 4>
    | |   |   | +-o AMD9500ControllerWrangler  <class AMD9500ControllerWrangler, id 0x100000339, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |   | | +-o AppleGraphicsDeviceControlClient  <class AppleGraphicsDeviceControlClient, id 0x100000461, !registered, !matched, active, busy 0, retain 5>
    | |   |   | | +-o AppleGraphicsDeviceControlClient  <class AppleGraphicsDeviceControlClient, id 0x100000478, !registered, !matched, active, busy 0, retain 5>
    | |   |   | +-o AMDSupport  <class AMDSupport, id 0x10000033a, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | +-o AMD9500Controller@t  <class AMD9500Controller, id 0x10000035b, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | +-o ATY,AMD,RadeonFramebuffer@0  <class AtiFbStub, id 0x1000003af, registered, matched, active, busy 0 (4775 ms), retain 8>
    | |   |   | | +-o AMDFramebufferVIB  <class AMDFramebuffer, id 0x1000003c2, registered, matched, active, busy 0 (3 ms), retain 17>
    | |   |   | |   +-o AGPM  <class AGPM, id 0x1000003c7, registered, matched, active, busy 0 (1 ms), retain 9>
    | |   |   | |   | +-o gpu-control  <class IOService, id 0x1000003c8, registered, matched, active, busy 0 (1 ms), retain 7>
    | |   |   | |   |   +-o IOHWControl  <class IOHWControl, id 0x100000450, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |   | |   +-o AppleMCCSControlModule  <class AppleMCCSControlModule, id 0x1000003c9, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   |   | |   | +-o AppleMCCSParameterHandler  <class AppleMCCSParameterHandler, id 0x1000003cb, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o AppleUpstreamUserClientDriver  <class AppleUpstreamUserClientDriver, id 0x1000003ca, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferI2CInterface  <class IOFramebufferI2CInterface, id 0x10000044d, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferUserClient  <class IOFramebufferUserClient, id 0x100000460, !registered, !matched, active, busy 0, retain 5>
    | |   |   | +-o ATY,AMD,RadeonFramebuffer@1  <class AtiFbStub, id 0x1000003b0, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |   | | +-o AMDFramebufferVIB  <class AMDFramebuffer, id 0x1000003cc, registered, matched, active, busy 0 (0 ms), retain 15>
    | |   |   | |   +-o AppleMCCSControlModule  <class AppleMCCSControlModule, id 0x1000003cf, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   |   | |   | +-o AppleMCCSParameterHandler  <class AppleMCCSParameterHandler, id 0x1000003d1, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o AppleUpstreamUserClientDriver  <class AppleUpstreamUserClientDriver, id 0x1000003d0, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferI2CInterface  <class IOFramebufferI2CInterface, id 0x10000044e, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferUserClient  <class IOFramebufferUserClient, id 0x100000462, !registered, !matched, active, busy 0, retain 5>
    | |   |   | +-o ATY,AMD,RadeonFramebuffer@2  <class AtiFbStub, id 0x1000003b1, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |   | | +-o AMDFramebufferVIB  <class AMDFramebuffer, id 0x1000003d2, registered, matched, active, busy 0 (0 ms), retain 15>
    | |   |   | |   +-o AppleMCCSControlModule  <class AppleMCCSControlModule, id 0x1000003d5, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   |   | |   | +-o AppleMCCSParameterHandler  <class AppleMCCSParameterHandler, id 0x1000003d7, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o AppleUpstreamUserClientDriver  <class AppleUpstreamUserClientDriver, id 0x1000003d6, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferI2CInterface  <class IOFramebufferI2CInterface, id 0x100000451, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferUserClient  <class IOFramebufferUserClient, id 0x100000463, !registered, !matched, active, busy 0, retain 5>
    | |   |   | +-o ATY,AMD,RadeonFramebuffer@3  <class AtiFbStub, id 0x1000003b2, registered, matched, active, busy 0 (1 ms), retain 8>
    | |   |   | | +-o AMDFramebufferVIB  <class AMDFramebuffer, id 0x1000003d8, registered, matched, active, busy 0 (1 ms), retain 17>
    | |   |   | |   +-o AppleMCCSControlModule  <class AppleMCCSControlModule, id 0x1000003db, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   |   | |   | +-o AppleMCCSParameterHandler  <class AppleMCCSParameterHandler, id 0x1000003dd, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o AppleUpstreamUserClientDriver  <class AppleUpstreamUserClientDriver, id 0x1000003dc, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferI2CInterface  <class IOFramebufferI2CInterface, id 0x100000452, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o display0  <class IODisplayConnect, id 0x100000453, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   |   | |   | +-o AppleDisplay  <class AppleDisplay, id 0x100000455, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |   | |   +-o IOFramebufferUserClient  <class IOFramebufferUserClient, id 0x100000464, !registered, !matched, active, busy 0, retain 5>
    | |   |   | +-o ATY,AMD,RadeonFramebuffer@4  <class AtiFbStub, id 0x1000003b3, registered, matched, active, busy 0 (2 ms), retain 8>
    | |   |   | | +-o AMDFramebufferVIB  <class AMDFramebuffer, id 0x1000003de, registered, matched, active, busy 0 (1 ms), retain 15>
    | |   |   | |   +-o AppleMCCSControlModule  <class AppleMCCSControlModule, id 0x1000003e1, registered, matched, active, busy 0 (1 ms), retain 7>
    | |   |   | |   | +-o AppleMCCSParameterHandler  <class AppleMCCSParameterHandler, id 0x1000003e5, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o AppleUpstreamUserClientDriver  <class AppleUpstreamUserClientDriver, id 0x1000003e2, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferI2CInterface  <class IOFramebufferI2CInterface, id 0x10000045e, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |   | |   +-o IOFramebufferUserClient  <class IOFramebufferUserClient, id 0x100000465, !registered, !matched, active, busy 0, retain 5>
    | |   |   | +-o AtiDeviceControl  <class AtiDeviceControl, id 0x1000003e7, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   |   | | +-o AppleGraphicsDeviceControlClient  <class AppleGraphicsDeviceControlClient, id 0x100000479, !registered, !matched, active, busy 0, retain 5>
    | |   |   | +-o AMDRadeonX4200_AMDEllesmereGraphicsAccelerator  <class AMDRadeonX4200_AMDEllesmereGraphicsAccelerator, id 0x10000035c, registered, matched, active, busy 0 (1 ms), retain 66>
    | |   |   |   +-o AMDRadeonX4200_AMDAccel2DContext  <class AMDRadeonX4200_AMDAccel2DContext, id 0x100000473, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccel2DContext  <class AMDRadeonX4200_AMDAccel2DContext, id 0x100000474, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccel2DContext  <class AMDRadeonX4200_AMDAccel2DContext, id 0x100000475, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccel2DContext  <class AMDRadeonX4200_AMDAccel2DContext, id 0x100000476, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccel2DContext  <class AMDRadeonX4200_AMDAccel2DContext, id 0x100000477, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x10000047b, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x10000047d, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x10000047f, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x100000480, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x100000481, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x100000482, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x100000483, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x100000485, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x100000486, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDSIGLContext  <class AMDRadeonX4200_AMDSIGLContext, id 0x100000487, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x100000489, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x10000048a, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004ae, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004af, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x1000004b0, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x1000004b1, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004b7, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004b8, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x1000004b9, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x1000004ba, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004bc, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004bd, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x1000004be, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x1000004c3, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSurface  <class AMDRadeonX4200_AMDAccelSurface, id 0x1000004c4, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004ca, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004cb, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x1000004cc, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x1000004cd, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004ce, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x1000004d0, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004eb, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004ec, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x1000004ed, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x1000004ee, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004f4, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x1000004f5, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x1000004f6, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x1000004f7, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x100000506, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x100000507, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x100000508, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x100000509, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x100000513, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x100000515, !registered, !matched, active, busy 0, retain 7>
    | |   |   |   +-o AMDRadeonX4200_AMDSIGLContext  <class AMDRadeonX4200_AMDSIGLContext, id 0x100000516, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDCICLContext  <class AMDRadeonX4200_AMDCICLContext, id 0x100000517, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x10000051a, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x10000051b, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x10000051c, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x10000051d, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x10000052b, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelDevice  <class AMDRadeonX4200_AMDAccelDevice, id 0x10000052c, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelSharedUserClient  <class AMDRadeonX4200_AMDAccelSharedUserClient, id 0x10000052d, !registered, !matched, active, busy 0, retain 6>
    | |   |   |   +-o AMDRadeonX4200_AMDAccelCommandQueue  <class AMDRadeonX4200_AMDAccelCommandQueue, id 0x10000052e, !registered, !matched, active, busy 0, retain 6>
    | |   |   +-o HDEF@0,1  <class IOPCIDevice, id 0x100000242, registered, matched, active, busy 0 (96 ms), retain 10>
    | |   |     +-o AppleHDAController@0,1  <class AppleHDAController, id 0x100000342, registered, matched, active, busy 0 (28 ms), retain 9>
    | |   |       +-o IOHDACodecDevice@0,1,0  <class IOHDACodecDevice, id 0x10000035f, registered, matched, active, busy 0 (28 ms), retain 7>
    | |   |         +-o IOHDACodecDriver  <class IOHDACodecDriver, id 0x100000361, !registered, !matched, active, busy 0 (27 ms), retain 5>
    | |   |           +-o IOHDACodecFunction@0,1,0,1  <class IOHDACodecFunction, id 0x100000362, registered, matched, active, busy 0 (27 ms), retain 7>
    | |   |             +-o AppleHDACodecGeneric  <class AppleHDACodecGeneric, id 0x100000363, registered, matched, active, busy 0 (5 ms), retain 6>
    | |   |               +-o AppleHDAHDMI_DPDriver  <class AppleHDAHDMI_DPDriver, id 0x100000366, registered, matched, active, busy 0 (2 ms), retain 7>
    | |   |                 +-o AppleHDAEngineOutputDP@0,1,0,1,5  <class AppleHDAEngineOutputDP, id 0x100000457, registered, matched, active, busy 0 (2 ms), retain 25>
    | |   |                   +-o AppleHDAStream  <class AppleHDAStream, id 0x100000458, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |                   +-o AppleHDAAudioSelectorControlDP  <class AppleHDAAudioSelectorControlDP, id 0x100000459, !registered, !matched, active, busy 0, retain 8>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x10000045c, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioSelectorControl  <class IOAudioSelectorControl, id 0x10000045a, !registered, !matched, active, busy 0 (0 ms), retain 27>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x10000045d, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004bf, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004c0, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004c1, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004c2, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004c7, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004e2, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004e3, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x1000004fd, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x10000050e, !registered, !matched, active, busy 0, retain 6>
    | |   |                   | +-o IOAudioControlUserClient  <class IOAudioControlUserClient, id 0x100000530, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o AudioAUUCDriver  <class AudioAUUCDriver, id 0x10000045b, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x10000045f, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x100000466, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x100000467, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x100000468, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x10000046c, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x1000004a1, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x1000004a5, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x1000004c6, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x1000004fc, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x10000050d, !registered, !matched, active, busy 0, retain 6>
    | |   |                   +-o IOAudioEngineUserClient  <class IOAudioEngineUserClient, id 0x10000052f, !registered, !matched, active, busy 0, retain 6>
    | |   +-o IOH7@7  <class IOPCIDevice, id 0x1000001b6, registered, matched, active, busy 0 (63 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x10000029b, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   +-o pci8086,3425@10  <class IOPCIDevice, id 0x10000023a, registered, matched, active, busy 0 (40 ms), retain 8>
    | |   +-o pci8086,3426@10,1  <class IOPCIDevice, id 0x10000023b, registered, matched, active, busy 0 (41 ms), retain 8>
    | |   +-o pci8086,3427@11  <class IOPCIDevice, id 0x10000023c, registered, matched, active, busy 0 (43 ms), retain 8>
    | |   +-o pci8086,3428@11,1  <class IOPCIDevice, id 0x10000023d, registered, matched, active, busy 0 (38 ms), retain 8>
    | |   +-o IH20@14  <class IOPCIDevice, id 0x1000001b0, registered, matched, active, busy 0 (42 ms), retain 8>
    | |   +-o pci8086,3422@14,1  <class IOPCIDevice, id 0x10000023e, registered, matched, active, busy 0 (40 ms), retain 8>
    | |   +-o pci8086,3423@14,2  <class IOPCIDevice, id 0x10000023f, registered, matched, active, busy 0 (42 ms), retain 8>
    | |   +-o pci8086,342f@15  <class IOPCIDevice, id 0x100000240, registered, matched, active, busy 0 (41 ms), retain 8>
    | |   +-o USB4@1A  <class IOPCIDevice, id 0x1000001c5, registered, matched, active, busy 0 (54 ms), retain 8>
    | |   +-o USB5@1A,1  <class IOPCIDevice, id 0x1000001c6, registered, matched, active, busy 0 (55 ms), retain 11>
    | |   | +-o USB5@3a000000  <class AppleUSBUHCIPCI, id 0x10000027d, registered, matched, active, busy 0 (0 ms), retain 286>
    | |   |   +-o AppleUSBUHCIPort@3a100000  <class AppleUSBUHCIPort, id 0x1000002e7, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |   +-o AppleUSBUHCIPort@3a200000  <class AppleUSBUHCIPort, id 0x1000002ec, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   +-o USB6@1A,2  <class IOPCIDevice, id 0x1000001c7, registered, matched, active, busy 0 (54 ms), retain 11>
    | |   | +-o USB6@5a000000  <class AppleUSBUHCIPCI, id 0x10000027e, registered, matched, active, busy 0 (0 ms), retain 286>
    | |   |   +-o AppleUSBUHCIPort@5a100000  <class AppleUSBUHCIPort, id 0x1000002d3, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |   +-o AppleUSBUHCIPort@5a200000  <class AppleUSBUHCIPort, id 0x1000002e5, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   +-o EUS2@1A,7  <class IOPCIDevice, id 0x1000001c9, registered, matched, active, busy 0 (55 ms), retain 11>
    | |   | +-o EUS2@fa000000  <class AppleUSBEHCIPCI, id 0x100000280, registered, matched, active, busy 0 (1 ms), retain 97>
    | |   |   +-o AppleUSBEHCIPort@fa100000  <class AppleUSBEHCIPort, id 0x1000002df, registered, matched, active, busy 0 (0 ms), retain 11>
    | |   |   +-o AppleUSBEHCIPort@fa200000  <class AppleUSBEHCIPort, id 0x1000002e0, registered, matched, active, busy 0 (0 ms), retain 11>
    | |   |   +-o AppleUSBEHCIPort@fa300000  <class AppleUSBEHCIPort, id 0x1000002e1, registered, matched, active, busy 0 (0 ms), retain 14>
    | |   |   +-o AppleUSBEHCIPort@fa400000  <class AppleUSBEHCIPort, id 0x1000002e2, registered, matched, active, busy 0 (0 ms), retain 14>
    | |   |   +-o AppleUSBEHCIPort@fa500000  <class AppleUSBEHCIPort, id 0x1000002e3, registered, matched, active, busy 0 (0 ms), retain 14>
    | |   |   +-o AppleUSBEHCIPort@fa600000  <class AppleUSBEHCIPort, id 0x1000002e4, registered, matched, active, busy 0 (0 ms), retain 14>
    | |   +-o HDEF@1B  <class IOPCIDevice, id 0x1000001ca, registered, matched, active, busy 0 (261 ms), retain 10>
    | |   | +-o AppleHDAController@1B  <class AppleHDAController, id 0x100000369, !registered, !matched, active, busy 0, retain 8>
    | |   |   +-o IOHDACodecDevice@1B,0  <class IOHDACodecDevice, id 0x10000036a, !registered, !matched, active, busy 0, retain 5>
    | |   |   +-o IOHDACodecDevice@1B,1  <class IOHDACodecDevice, id 0x10000036b, !registered, !matched, active, busy 0, retain 5>
    | |   |   +-o IOHDACodecDevice@1B,2  <class IOHDACodecDevice, id 0x10000036c, !registered, !matched, active, busy 0, retain 5>
    | |   |   +-o IOHDACodecDevice@1B,3  <class IOHDACodecDevice, id 0x10000036d, !registered, !matched, active, busy 0, retain 5>
    | |   +-o PCX1@1C  <class IOPCIDevice, id 0x1000001b9, registered, matched, active, busy 0 (55 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x100000296, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   +-o PCX5@1C,4  <class IOPCIDevice, id 0x1000001bb, registered, matched, active, busy 0 (217 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x10000029d, registered, matched, active, busy 0 (162 ms), retain 8>
    | |   |   +-o BRCM@0  <class IOPCIDevice, id 0x1000001bc, registered, matched, active, busy 0 (162 ms), retain 10>
    | |   |     +-o BCM5701Enet  <class BCM5701Enet, id 0x1000002ab, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |       +-o en4  <class IOEthernetAVBInterface, id 0x1000002cf, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |         +-o IONetworkStack  <class IONetworkStack, id 0x10000026c, registered, matched, active, busy 0 (0 ms), retain 12>
    | |   |           +-o IONetworkStackUserClient  <class IONetworkStackUserClient, id 0x100000301, !registered, !matched, active, busy 0, retain 5>
    | |   +-o PCX6@1C,5  <class IOPCIDevice, id 0x1000001bd, registered, matched, active, busy 0 (211 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x100000286, registered, matched, active, busy 0 (162 ms), retain 8>
    | |   |   +-o BRCM@0  <class IOPCIDevice, id 0x1000001be, registered, matched, active, busy 0 (162 ms), retain 10>
    | |   |     +-o BCM5701Enet  <class BCM5701Enet, id 0x1000002a7, registered, matched, active, busy 0 (6 ms), retain 10>
    | |   |       +-o en5  <class IOEthernetAVBInterface, id 0x1000002ce, registered, matched, active, busy 0 (6 ms), retain 10>
    | |   |         +-o IONetworkStack  <class IONetworkStack, id 0x10000026c, registered, matched, active, busy 0 (0 ms), retain 12>
    | |   |           +-o IONetworkStackUserClient  <class IONetworkStackUserClient, id 0x100000301, !registered, !matched, active, busy 0, retain 5>
    | |   +-o USB1@1D  <class IOPCIDevice, id 0x1000001c2, registered, matched, active, busy 0 (47 ms), retain 8>
    | |   +-o USB2@1D,1  <class IOPCIDevice, id 0x1000001c3, registered, matched, active, busy 0 (178 ms), retain 11>
    | |   | +-o USB2@3d000000  <class AppleUSBUHCIPCI, id 0x100000283, registered, matched, active, busy 0 (130 ms), retain 310>
    | |   |   +-o AppleUSBUHCIPort@3d100000  <class AppleUSBUHCIPort, id 0x1000002de, registered, matched, active, busy 0 (33 ms), retain 15>
    | |   |   | +-o Razer Naga 2014@3d100000  <class IOUSBHostDevice, id 0x100000372, registered, matched, active, busy 0 (33 ms), retain 31>
    | |   |   |   +-o AppleUSBHostLegacyClient  <class AppleUSBHostLegacyClient, id 0x100000382, !registered, !matched, active, busy 0, retain 10>
    | |   |   |   +-o AppleUSBHostCompositeDevice  <class AppleUSBHostCompositeDevice, id 0x10000038d, !registered, !matched, active, busy 0, retain 4>
    | |   |   |   +-o IOUSBHostInterface@0  <class IOUSBHostInterface, id 0x10000038f, !registered, !matched, active, busy 0, retain 7>
    | |   |   |   +-o IOUSBHostInterface@1  <class IOUSBHostInterface, id 0x100000390, !registered, !matched, active, busy 0, retain 7>
    | |   |   |   +-o IOUSBHostInterface@2  <class IOUSBHostInterface, id 0x100000391, !registered, !matched, active, busy 0, retain 7>
    | |   |   +-o AppleUSBUHCIPort@3d200000  <class AppleUSBUHCIPort, id 0x1000002f9, registered, matched, active, busy 0 (97 ms), retain 15>
    | |   |     +-o IOUSBHostDevice@3d200000  <class IOUSBHostDevice, id 0x1000003a2, registered, matched, active, busy 0 (97 ms), retain 30>
    | |   |       +-o AppleUSBHostLegacyClient  <class AppleUSBHostLegacyClient, id 0x100000412, !registered, !matched, active, busy 0, retain 8>
    | |   |       +-o AppleUSB20KeyboardHub@3d200000  <class AppleUSB20KeyboardHub, id 0x100000417, registered, matched, active, busy 0 (91 ms), retain 19>
    | |   |       | +-o AppleUSB20HubPort@3d220000  <class AppleUSB20HubPort, id 0x10000041c, registered, matched, active, busy 0 (91 ms), retain 16>
    | |   |       | | +-o Apple Keyboard@3d220000  <class IOUSBHostDevice, id 0x100000422, registered, matched, active, busy 0 (90 ms), retain 29>
    | |   |       | |   +-o AppleUSBHostLegacyClient  <class AppleUSBHostLegacyClient, id 0x100000425, !registered, !matched, active, busy 0, retain 8>
    | |   |       | |   +-o AppleUSBHostCompositeDevice  <class AppleUSBHostCompositeDevice, id 0x10000042b, !registered, !matched, active, busy 0, retain 4>
    | |   |       | |   +-o IOUSBHostInterface@0  <class IOUSBHostInterface, id 0x10000042c, registered, matched, active, busy 0 (30 ms), retain 11>
    | |   |       | |   | +-o IOUSBHostHIDDevice@3d220000,0  <class IOUSBHostHIDDevice, id 0x100000433, registered, matched, active, busy 0 (14 ms), retain 8>
    | |   |       | |   |   +-o IOHIDInterface  <class IOHIDInterface, id 0x10000043a, registered, matched, active, busy 0 (14 ms), retain 7>
    | |   |       | |   |   | +-o AppleHIDKeyboardEventDriver  <class AppleHIDKeyboardEventDriver, id 0x10000043b, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |       | |   |   |   +-o IOHIDEventServiceUserClient  <class IOHIDEventServiceUserClient, id 0x100000441, !registered, !matched, active, busy 0, retain 6>
    | |   |       | |   |   +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x10000048f, !registered, !matched, active, busy 0, retain 6>
    | |   |       | |   +-o IOUSBHostInterface@1  <class IOUSBHostInterface, id 0x10000042d, registered, matched, active, busy 0 (59 ms), retain 11>
    | |   |       | |     +-o IOUSBHostHIDDevice@3d220000,1  <class IOUSBHostHIDDevice, id 0x100000438, registered, matched, active, busy 0 (46 ms), retain 8>
    | |   |       | |       +-o IOHIDInterface  <class IOHIDInterface, id 0x10000043e, registered, matched, active, busy 0 (45 ms), retain 7>
    | |   |       | |       | +-o IOHIDEventDriver  <class IOHIDEventDriver, id 0x10000043f, registered, matched, active, busy 0 (0 ms), retain 8>
    | |   |       | |       |   +-o IOHIDEventServiceUserClient  <class IOHIDEventServiceUserClient, id 0x100000443, !registered, !matched, active, busy 0, retain 6>
    | |   |       | |       +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x10000048e, !registered, !matched, active, busy 0, retain 6>
    | |   |       | +-o AppleUSB20HubPort@3d210000  <class AppleUSB20HubPort, id 0x10000041d, registered, matched, active, busy 0 (0 ms), retain 12>
    | |   |       | +-o AppleUSB20HubPort@3d230000  <class AppleUSB20HubPort, id 0x10000041e, registered, matched, active, busy 0 (0 ms), retain 12>
    | |   |       +-o IOUSBHostInterface@0  <class IOUSBHostInterface, id 0x10000041a, !registered, !matched, active, busy 0, retain 9>
    | |   +-o USB3@1D,2  <class IOPCIDevice, id 0x1000001c4, registered, matched, active, busy 0 (5237 ms), retain 14>
    | |   | +-o USB3@5d000000  <class AppleUSBUHCIPCI, id 0x100000284, registered, matched, active, busy 0 (5190 ms), retain 293>
    | |   |   +-o AppleUSBUHCIPort@5d100000  <class AppleUSBUHCIPort, id 0x1000002f5, registered, matched, active, busy 0 (5190 ms), retain 16>
    | |   |   | +-o Mass Storage Device@5d100000  <class IOUSBHostDevice, id 0x100000371, registered, matched, active, busy 0 (5190 ms), retain 25>
    | |   |   |   +-o AppleUSBHostLegacyClient  <class AppleUSBHostLegacyClient, id 0x100000378, !registered, !matched, active, busy 0, retain 8>
    | |   |   |   +-o AppleUSBHostCompositeDevice  <class AppleUSBHostCompositeDevice, id 0x100000387, !registered, !matched, active, busy 0, retain 4>
    | |   |   |   +-o IOUSBHostInterface@0  <class IOUSBHostInterface, id 0x10000038a, registered, matched, active, busy 0 (5182 ms), retain 12>
    | |   |   |     +-o IOUSBMassStorageInterfaceNub  <class IOUSBMassStorageInterfaceNub, id 0x100000392, registered, matched, active, busy 0 (5180 ms), retain 10>
    | |   |   |       +-o IOUSBMassStorageDriverNub  <class IOUSBMassStorageDriverNub, id 0x100000395, registered, matched, active, busy 0 (5180 ms), retain 11>
    | |   |   |         +-o IOUSBMassStorageDriver  <class IOUSBMassStorageDriver, id 0x100000398, !registered, !matched, active, busy 0 (5179 ms), retain 9>
    | |   |   |           +-o IOSCSILogicalUnitNub@0  <class IOSCSILogicalUnitNub, id 0x10000039e, registered, matched, active, busy 0 (4697 ms), retain 8>
    | |   |   |             +-o IOSCSIPeripheralDeviceType00  <class IOSCSIPeripheralDeviceType00, id 0x1000003c4, !registered, !matched, active, busy 0 (63 ms), retain 9>
    | |   |   |               +-o IOBlockStorageServices  <class IOBlockStorageServices, id 0x1000003e4, registered, matched, active, busy 0 (63 ms), retain 6>
    | |   |   |                 +-o IOBlockStorageDriver  <class IOBlockStorageDriver, id 0x1000003e6, registered, matched, active, busy 0 (62 ms), retain 9>
    | |   |   |                   +-o JetFlash Transcend 32GB Media  <class IOMedia, id 0x1000003fb, registered, matched, active, busy 0 (62 ms), retain 17>
    | |   |   |                     +-o IOMediaBSDClient  <class IOMediaBSDClient, id 0x1000003fc, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   |   |                     +-o IOGUIDPartitionScheme  <class IOGUIDPartitionScheme, id 0x1000003fe, !registered, !matched, active, busy 0 (0 ms), retain 7>
    | |   |   |                       +-o EFI System Partition@1  <class IOMedia, id 0x100000401, registered, matched, active, busy 0 (0 ms), retain 15>
    | |   |   |                       | +-o IOMediaBSDClient  <class IOMediaBSDClient, id 0x100000403, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   |   |                       +-o Untitled 2@2  <class IOMedia, id 0x100000402, registered, matched, active, busy 0 (0 ms), retain 16>
    | |   |   |                         +-o IOMediaBSDClient  <class IOMediaBSDClient, id 0x100000404, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   |   +-o AppleUSBUHCIPort@5d200000  <class AppleUSBUHCIPort, id 0x1000002f6, registered, matched, active, busy 0 (0 ms), retain 11>
    | |   +-o EUS1@1D,7  <class IOPCIDevice, id 0x1000001c8, registered, matched, active, busy 0 (45 ms), retain 8>
    | |   +-o HUB@1E  <class IOPCIDevice, id 0x1000001bf, registered, matched, active, busy 0 (56 ms), retain 12>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x10000029e, registered, matched, active, busy 0 (8 ms), retain 8>
    | |   |   +-o FIRE@9  <class IOPCIDevice, id 0x1000001c1, registered, matched, active, busy 0 (8 ms), retain 10>
    | |   |     +-o AppleFWOHCI  <class AppleFWOHCI, id 0x1000002ae, !registered, !matched, active, busy 0 (5 ms), retain 6>
    | |   |       +-o IOFireWireController  <class IOFireWireController, id 0x1000002b0, registered, matched, active, busy 0 (5 ms), retain 10>
    | |   |         +-o IOFireWireLocalNode  <class IOFireWireLocalNode, id 0x1000002d1, registered, matched, active, busy 0 (5 ms), retain 13>
    | |   |           +-o IOFireWireUserClientIniter  <class IOFireWireUserClientIniter, id 0x1000002d2, !registered, !matched, active, busy 0, retain 4>
    | |   |           +-o IOFireWireUserClientIniter  <class IOFireWireUserClientIniter, id 0x10000032a, !registered, !matched, active, busy 0, retain 4>
    | |   |           +-o IOFireWireIP  <class IOFireWireIP, id 0x10000032b, registered, matched, active, busy 0 (2 ms), retain 7>
    | |   |             +-o fw0  <class IOFWInterface, id 0x10000032d, registered, matched, active, busy 0 (2 ms), retain 10>
    | |   |               +-o IONetworkStack  <class IONetworkStack, id 0x10000026c, registered, matched, active, busy 0 (0 ms), retain 12>
    | |   |                 +-o IONetworkStackUserClient  <class IONetworkStackUserClient, id 0x100000301, !registered, !matched, active, busy 0, retain 5>
    | |   +-o LPCB@1F  <class IOPCIDevice, id 0x1000001b1, registered, matched, active, busy 0 (5963 ms), retain 23>
    | |   | +-o AppleLPC  <class AppleLPC, id 0x1000003f1, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   | +-o com_apple_driver_eficheck  <class com_apple_driver_eficheck, id 0x1000003f3, registered, matched, active, busy 0 (0 ms), retain 5>
    | |   +-o pci8086,2822@1F,2  <class IOPCIDevice, id 0x100000241, registered, matched, active, busy 0 (6706 ms), retain 17>
    | |     +-o AppleICH8AHCI  <class AppleICH8AHCI, id 0x100000299, registered, matched, active, busy 0 (0 ms), retain 24>
    | |       +-o PRT0@0  <class AppleAHCIPort, id 0x1000002b4, registered, matched, active, busy 0 (0 ms), retain 9>
    | |       +-o PRT1@1  <class AppleAHCIPort, id 0x1000002f3, registered, matched, active, busy 0 (0 ms), retain 9>
    | |       +-o PRT2@2  <class AppleAHCIPort, id 0x1000002f7, registered, matched, active, busy 0 (0 ms), retain 9>
    | |       +-o PRT3@3  <class AppleAHCIPort, id 0x1000002fa, registered, matched, active, busy 0 (0 ms), retain 9>
    | |       +-o PRT4@4  <class AppleAHCIPort, id 0x100000320, registered, matched, active, busy 0 (0 ms), retain 9>
    | |       +-o PRT5@5  <class AppleAHCIPort, id 0x1000003a7, registered, matched, active, busy 0 (0 ms), retain 9>
    | +-o HPET  <class IOACPIPlatformDevice, id 0x10000016b, registered, matched, active, busy 0 (5 ms), retain 8>
    | | +-o AppleHPET  <class AppleHPET, id 0x1000001de, !registered, !matched, active, busy 0, retain 4>
    | +-o RTC  <class IOACPIPlatformDevice, id 0x10000016c, registered, matched, active, busy 0 (257 ms), retain 9>
    | | +-o AppleRTC  <class AppleRTC, id 0x1000001da, registered, matched, active, busy 0 (0 ms), retain 7>
    | +-o DMAC  <class IOACPIPlatformDevice, id 0x10000016d, registered, matched, active, busy 0 (3 ms), retain 7>
    | +-o EC  <class IOACPIPlatformDevice, id 0x10000016e, registered, matched, active, busy 0 (257 ms), retain 9>
    | | +-o AppleBusPowerController  <class AppleBusPowerController, id 0x1000001dc, registered, matched, active, busy 0 (0 ms), retain 6>
    | +-o ALS0  <class IOACPIPlatformDevice, id 0x10000016f, registered, matched, active, busy 0 (386 ms), retain 7>
    | +-o NCP  <class IOACPIPlatformDevice, id 0x100000170, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o PIC  <class IOACPIPlatformDevice, id 0x100000171, registered, matched, active, busy 0 (3 ms), retain 7>
    | +-o TIME  <class IOACPIPlatformDevice, id 0x100000172, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o PS2M  <class IOACPIPlatformDevice, id 0x100000173, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o KBD  <class IOACPIPlatformDevice, id 0x100000174, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o APIC  <class IOACPIPlatformDevice, id 0x100000175, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o TPM  <class IOACPIPlatformDevice, id 0x100000176, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o SBD1  <class IOACPIPlatformDevice, id 0x10000019e, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o SBD2  <class IOACPIPlatformDevice, id 0x10000019f, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o SBD3  <class IOACPIPlatformDevice, id 0x1000001a0, registered, matched, active, busy 0 (4 ms), retain 7>
    | +-o PCI1@0  <class IOACPIPlatformDevice, id 0x1000001a1, registered, matched, active, busy 0 (1762 ms), retain 29>
    | | +-o AppleACPIPCI  <class AppleACPIPCI, id 0x1000001d9, registered, matched, active, busy 0 (1472 ms), retain 30>
    | |   +-o IOH3@3  <class IOPCIDevice, id 0x1000001d2, registered, matched, active, busy 0 (169 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x100000245, registered, matched, active, busy 0 (45 ms), retain 8>
    | |   |   +-o SLT5@0  <class IOPCIDevice, id 0x1000001d3, registered, matched, active, busy 0 (45 ms), retain 9>
    | |   +-o IOH7@7  <class IOPCIDevice, id 0x1000001d4, registered, matched, active, busy 0 (143 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x100000243, registered, matched, active, busy 0 (65 ms), retain 8>
    | |   |   +-o SLT7@0  <class IOPCIDevice, id 0x1000001d5, registered, matched, active, busy 0 (65 ms), retain 12>
    | |   |     +-o SLT7@00000000  <class AppleUSBXHCIFL1100, id 0x100000292, registered, matched, active, busy 0 (0 ms), retain 54>
    | |   |       +-o AppleUSB20XHCIPort@00100000  <class AppleUSB20XHCIPort, id 0x1000002b6, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |       +-o AppleUSB20XHCIPort@00200000  <class AppleUSB20XHCIPort, id 0x1000002b7, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |       +-o AppleUSB20XHCIPort@00300000  <class AppleUSB20XHCIPort, id 0x1000002b8, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |       +-o AppleUSB20XHCIPort@00400000  <class AppleUSB20XHCIPort, id 0x1000002b9, registered, matched, active, busy 0 (0 ms), retain 10>
    | |   |       +-o AppleUSB30XHCIPort@00500000  <class AppleUSB30XHCIPort, id 0x1000002ba, registered, matched, active, busy 0 (0 ms), retain 13>
    | |   |       +-o AppleUSB30XHCIPort@00600000  <class AppleUSB30XHCIPort, id 0x1000002d0, registered, matched, active, busy 0 (0 ms), retain 13>
    | |   |       +-o AppleUSB30XHCIPort@00700000  <class AppleUSB30XHCIPort, id 0x1000002d4, registered, matched, active, busy 0 (0 ms), retain 13>
    | |   |       +-o AppleUSB30XHCIPort@00800000  <class AppleUSB30XHCIPort, id 0x1000002d5, registered, matched, active, busy 0 (0 ms), retain 13>
    | |   +-o IOH9@9  <class IOPCIDevice, id 0x1000001d6, registered, matched, active, busy 0 (1472 ms), retain 11>
    | |   | +-o IOPP  <class IOPCI2PCIBridge, id 0x100000246, registered, matched, active, busy 0 (1394 ms), retain 8>
    | |   |   +-o SAS0@0  <class IOPCIDevice, id 0x1000001d7, registered, matched, active, busy 0 (1394 ms), retain 10>
    | |   |     +-o AppleLSIFusionSAS  <class AppleLSIFusionSAS, id 0x100000263, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   +-o pci8086,3425@10  <class IOPCIDevice, id 0x1000001f7, registered, matched, active, busy 0 (13 ms), retain 8>
    | |   +-o pci8086,3426@10,1  <class IOPCIDevice, id 0x1000001f8, registered, matched, active, busy 0 (13 ms), retain 8>
    | |   +-o pci8086,3427@11  <class IOPCIDevice, id 0x1000001f9, registered, matched, active, busy 0 (13 ms), retain 8>
    | |   +-o pci8086,3428@11,1  <class IOPCIDevice, id 0x1000001fa, registered, matched, active, busy 0 (13 ms), retain 8>
    | |   +-o IH20@14  <class IOPCIDevice, id 0x1000001d1, registered, matched, active, busy 0 (12 ms), retain 8>
    | |   +-o pci8086,3422@14,1  <class IOPCIDevice, id 0x1000001fb, registered, matched, active, busy 0 (13 ms), retain 8>
    | |   +-o pci8086,3423@14,2  <class IOPCIDevice, id 0x1000001fc, registered, matched, active, busy 0 (12 ms), retain 8>
    | |   +-o pci8086,342f@15  <class IOPCIDevice, id 0x1000001fd, registered, matched, active, busy 0 (12 ms), retain 8>
    | +-o VTD1  <class IOACPIPlatformDevice, id 0x1000001a9, registered, matched, active, busy 0 (3 ms), retain 7>
    | +-o NHL1@0  <class IOACPIPlatformDevice, id 0x1000001aa, registered, matched, active, busy 0 (367 ms), retain 35>
    | | +-o AppleACPIPCI  <class AppleACPIPCI, id 0x1000001db, registered, matched, active, busy 0 (48 ms), retain 55>
    | |   +-o pci8086,2c70@0  <class IOPCIDevice, id 0x10000020a, registered, matched, active, busy 0 (2 ms), retain 8>
    | |   +-o pci8086,2d81@0,1  <class IOPCIDevice, id 0x10000020b, registered, matched, active, busy 0 (3 ms), retain 8>
    | |   +-o pci8086,2d90@2  <class IOPCIDevice, id 0x10000020c, registered, matched, active, busy 0 (14 ms), retain 8>
    | |   +-o pci8086,2d91@2,1  <class IOPCIDevice, id 0x10000020d, registered, matched, active, busy 0 (45 ms), retain 8>
    | |   +-o pci8086,2d92@2,2  <class IOPCIDevice, id 0x10000020e, registered, matched, active, busy 0 (46 ms), retain 8>
    | |   +-o pci8086,2d93@2,3  <class IOPCIDevice, id 0x10000020f, registered, matched, active, busy 0 (45 ms), retain 8>
    | |   +-o pci8086,2d94@2,4  <class IOPCIDevice, id 0x100000210, registered, matched, active, busy 0 (48 ms), retain 8>
    | |   +-o pci8086,2d95@2,5  <class IOPCIDevice, id 0x100000211, registered, matched, active, busy 0 (46 ms), retain 8>
    | |   +-o pci8086,2d98@3  <class IOPCIDevice, id 0x100000212, registered, matched, active, busy 0 (48 ms), retain 8>
    | |   +-o pci8086,2d99@3,1  <class IOPCIDevice, id 0x100000213, registered, matched, active, busy 0 (44 ms), retain 8>
    | |   +-o pci8086,2d9a@3,2  <class IOPCIDevice, id 0x100000214, registered, matched, active, busy 0 (46 ms), retain 8>
    | |   +-o pci8086,2d9c@3,4  <class IOPCIDevice, id 0x100000215, registered, matched, active, busy 0 (41 ms), retain 8>
    | |   +-o pci8086,2da0@4  <class IOPCIDevice, id 0x100000216, registered, matched, active, busy 0 (47 ms), retain 8>
    | |   +-o pci8086,2da1@4,1  <class IOPCIDevice, id 0x100000217, registered, matched, active, busy 0 (43 ms), retain 8>
    | |   +-o pci8086,2da2@4,2  <class IOPCIDevice, id 0x100000218, registered, matched, active, busy 0 (46 ms), retain 8>
    | |   +-o pci8086,2da3@4,3  <class IOPCIDevice, id 0x100000219, registered, matched, active, busy 0 (47 ms), retain 8>
    | |   +-o pci8086,2da8@5  <class IOPCIDevice, id 0x10000021a, registered, matched, active, busy 0 (45 ms), retain 8>
    | |   +-o pci8086,2da9@5,1  <class IOPCIDevice, id 0x10000021b, registered, matched, active, busy 0 (39 ms), retain 8>
    | |   +-o pci8086,2daa@5,2  <class IOPCIDevice, id 0x10000021c, registered, matched, active, busy 0 (46 ms), retain 8>
    | |   +-o pci8086,2dab@5,3  <class IOPCIDevice, id 0x10000021d, registered, matched, active, busy 0 (47 ms), retain 8>
    | |   +-o pci8086,2db0@6  <class IOPCIDevice, id 0x10000021e, registered, matched, active, busy 0 (47 ms), retain 8>
    | |   +-o pci8086,2db1@6,1  <class IOPCIDevice, id 0x10000021f, registered, matched, active, busy 0 (42 ms), retain 8>
    | |   +-o pci8086,2db2@6,2  <class IOPCIDevice, id 0x100000220, registered, matched, active, busy 0 (45 ms), retain 8>
    | |   +-o pci8086,2db3@6,3  <class IOPCIDevice, id 0x100000221, registered, matched, active, busy 0 (44 ms), retain 8>
    | +-o SLPB  <class IOACPIPlatformDevice, id 0x1000001ab, registered, matched, active, busy 0 (5 ms), retain 8>
    | | +-o AppleACPIButton  <class AppleACPIButton, id 0x1000001e0, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   +-o IOHIDEventServiceUserClient  <class IOHIDEventServiceUserClient, id 0x10000030f, !registered, !matched, active, busy 0, retain 6>
    | +-o PNLF@0  <class IOACPIPlatformDevice, id 0x1000001ac, registered, matched, active, busy 0 (30046 ms), retain 10>
    | | +-o AppleMCCSControlCello  <class AppleMCCSControlCello, id 0x100000334, !registered, !matched, active, busy 0, retain 4>
    | +-o MBRD  <class IOACPIPlatformDevice, id 0x1000001ad, registered, matched, active, busy 0 (3 ms), retain 7>
    | +-o PBTN  <class IOACPIPlatformDevice, id 0x1000001ae, registered, matched, active, busy 0 (6 ms), retain 9>
    | | +-o AppleACPIButton  <class AppleACPIButton, id 0x1000001df, registered, matched, active, busy 0 (0 ms), retain 7>
    | |   +-o IOHIDEventServiceUserClient  <class IOHIDEventServiceUserClient, id 0x10000030e, !registered, !matched, active, busy 0, retain 6>
    | +-o WMID  <class IOACPIPlatformDevice, id 0x1000001af, registered, matched, active, busy 0 (3 ms), retain 7>
    | +-o FSMC  <class FakeSMC, id 0x1000001e2, registered, matched, active, busy 0 (0 ms), retain 7>
    | +-o SMC  <class FakeSMCDevice, id 0x1000001e5, registered, matched, active, busy 0 (34 ms), retain 8>
    | | +-o AppleSMC  <class AppleSMC, id 0x1000001e6, registered, matched, active, busy 0 (32 ms), retain 8>
    | |   +-o SMCWatchDogTimer  <class SMCWatchDogTimer, id 0x1000001e8, registered, matched, active, busy 0 (32 ms), retain 8>
    | |   | +-o AppleOSXWatchdog  <class AppleOSXWatchdog, id 0x100000330, registered, matched, active, busy 0 (0 ms), retain 6>
    | |   |   +-o AppleOSXWatchdogClient  <class AppleOSXWatchdogClient, id 0x100000331, !registered, !matched, active, busy 0, retain 5>
    | |   +-o AppleSMCClient  <class AppleSMCClient, id 0x100000328, !registered, !matched, active, busy 0, retain 6>
    | +-o AppleEFIRuntime  <class AppleEFIRuntime, id 0x1000001e3, registered, matched, active, busy 0 (0 ms), retain 8>
    |   +-o AppleEFINVRAM  <class AppleEFINVRAM, id 0x1000001e9, registered, matched, active, busy 0 (0 ms), retain 10>
    +-o IOResources  <class IOResources, id 0x100000114, registered, matched, active, busy 0 (5702 ms), retain 47>
      +-o AppleIntelCPUPowerManagement  <class NullCPUPowerManagement, id 0x100000118, !registered, !matched, active, busy 0, retain 4>
      +-o IOReportHub  <class IOReportHub, id 0x100000119, registered, matched, active, busy 0 (7 ms), retain 6>
      | +-o IOReportUserClient  <class IOReportUserClient, id 0x100000327, !registered, !matched, active, busy 0, retain 5>
      +-o FakeSMCKeyStore  <class FakeSMCKeyStore, id 0x10000011a, registered, matched, active, busy 0 (7 ms), retain 11>
      | +-o FakeSMCKeyStoreUserClient  <class FakeSMCKeyStoreUserClient, id 0x1000004e4, !registered, !matched, active, busy 0, retain 5>
      +-o IOTimeSyncClockManager  <class IOTimeSyncClockManager, id 0x10000011b, registered, matched, active, busy 0 (0 ms), retain 6>
      +-o IOHDIXController  <class IOHDIXController, id 0x10000011c, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o IOBufferCopyEngineTestDummy  <class IOBufferCopyEngineTestDummy, id 0x10000011e, registered, matched, active, busy 0 (10 ms), retain 5>
      +-o AppleCredentialManager  <class AppleCredentialManager, id 0x10000011f, registered, matched, active, busy 0 (4 ms), retain 7>
      | +-o AppleCredentialManagerUserClient  <class AppleCredentialManagerUserClient, id 0x100000499, !registered, !matched, active, busy 0, retain 5>
      +-o AppleKeyStore  <class AppleKeyStore, id 0x100000120, registered, matched, active, busy 0 (7 ms), retain 17>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x100000316, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x10000049a, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x10000049d, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x10000049e, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x1000004a4, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x1000004aa, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x1000004c8, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x1000004da, !registered, !matched, active, busy 0, retain 6>
      | +-o AppleKeyStoreUserClient  <class AppleKeyStoreUserClient, id 0x1000004ef, !registered, !matched, active, busy 0, retain 6>
      +-o AppleFDEKeyStore  <class AppleFDEKeyStore, id 0x100000122, registered, matched, active, busy 0 (0 ms), retain 6>
      +-o WhateverGreen  <class WhateverGreen, id 0x100000123, !registered, !matched, active, busy 0, retain 4>
      +-o Lilu  <class Lilu, id 0x100000124, !registered, !matched, active, busy 0, retain 4>
      +-o AppleUSBHostResources  <class AppleUSBHostResources, id 0x1000001ef, registered, matched, active, busy 0 (5197 ms), retain 42>
      | +-o AppleUSBLegacyRoot  <class AppleUSBLegacyRoot, id 0x1000001f3, registered, matched, active, busy 0 (5196 ms), retain 21>
      | | +-o AppleUSBUHCI@5d000000  <class AppleUSBController, id 0x100000374, registered, matched, active, busy 0 (21 ms), retain 9>
      | | | +-o AppleUSBUHCI Root Hub Simulation@5d000000  <class AppleUSBRootHubDevice, id 0x100000375, registered, matched, active, busy 0 (4 ms), retain 9>
      | | | +-o Mass Storage Device@5d100000  <class AppleUSBDevice, id 0x100000377, registered, matched, active, busy 0 (21 ms), retain 11>
      | | |   +-o AppleUSBInterface@0  <class AppleUSBInterface, id 0x10000038b, registered, matched, active, busy 0 (20 ms), retain 5>
      | | +-o AppleUSBUHCI@3d000000  <class AppleUSBController, id 0x10000037d, registered, matched, active, busy 0 (5184 ms), retain 13>
      | |   +-o AppleUSBUHCI Root Hub Simulation@3d000000  <class AppleUSBRootHubDevice, id 0x10000037e, registered, matched, active, busy 0 (4 ms), retain 10>
      | |   +-o Razer Naga 2014@3d100000  <class AppleUSBDevice, id 0x100000381, registered, matched, active, busy 0 (5162 ms), retain 28>
      | |   | +-o AppleUSBInterface@0  <class AppleUSBInterface, id 0x100000397, registered, matched, active, busy 0 (52 ms), retain 9>
      | |   | | +-o RzHidInterface  <class RzHidInterface, id 0x10000039a, registered, matched, active, busy 0 (24 ms), retain 17>
      | |   | |   +-o RzHidDevice  <class RzHidDevice, id 0x10000039d, registered, matched, active, busy 0 (0 ms), retain 9>
      | |   | |   | +-o RzUserClient  <class RzUserClient, id 0x1000004fb, !registered, !matched, active, busy 0, retain 5>
      | |   | |   +-o IOHIDInterface  <class IOHIDInterface, id 0x1000003a0, registered, matched, active, busy 0 (23 ms), retain 7>
      | |   | |   | +-o IOHIDEventDriver  <class IOHIDEventDriver, id 0x1000003a1, registered, matched, active, busy 0 (7 ms), retain 9>
      | |   | |   |   +-o IOHIDEventServiceUserClient  <class IOHIDEventServiceUserClient, id 0x1000003a4, !registered, !matched, active, busy 0, retain 6>
      | |   | |   +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x100000492, !registered, !matched, active, busy 0, retain 6>
      | |   | |   +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x1000004ff, !registered, !matched, active, busy 0, retain 6>
      | |   | |   +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x100000510, !registered, !matched, active, busy 0, retain 6>
      | |   | |   +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x100000512, !registered, !matched, active, busy 0, retain 6>
      | |   | +-o AppleUSBInterface@1  <class AppleUSBInterface, id 0x1000003a6, registered, matched, active, busy 0 (5081 ms), retain 9>
      | |   | | +-o RzHidInterface  <class RzHidInterface, id 0x1000003a9, registered, matched, active, busy 0 (5056 ms), retain 10>
      | |   | |   +-o IOHIDInterface  <class IOHIDInterface, id 0x1000003ab, registered, matched, active, busy 0 (5056 ms), retain 7>
      | |   | |   | +-o IOHIDEventDriver  <class IOHIDEventDriver, id 0x1000003ac, registered, matched, active, busy 0 (5039 ms), retain 8>
      | |   | |   |   +-o IOHIDEventServiceUserClient  <class IOHIDEventServiceUserClient, id 0x1000003bc, !registered, !matched, active, busy 0, retain 6>
      | |   | |   +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x100000491, !registered, !matched, active, busy 0, retain 6>
      | |   | +-o AppleUSBInterface@2  <class AppleUSBInterface, id 0x1000003bf, registered, matched, active, busy 0 (50 ms), retain 9>
      | |   | | +-o RzHidInterface  <class RzHidInterface, id 0x1000003e9, registered, matched, active, busy 0 (27 ms), retain 10>
      | |   | |   +-o IOHIDInterface  <class IOHIDInterface, id 0x1000003eb, registered, matched, active, busy 0 (27 ms), retain 7>
      | |   | |   | +-o IOHIDEventDriver  <class IOHIDEventDriver, id 0x1000003ec, registered, matched, active, busy 0 (0 ms), retain 9>
      | |   | |   |   +-o IOHIDEventServiceUserClient  <class IOHIDEventServiceUserClient, id 0x1000003f0, !registered, !matched, active, busy 0, retain 6>
      | |   | |   +-o IOHIDLibUserClient  <class IOHIDLibUserClient, id 0x100000490, !registered, !matched, active, busy 0, retain 6>
      | |   | +-o RzDeviceEngine  <class IOUSBDeviceUserClientV2, id 0x1000004fe, !registered, !matched, active, busy 0, retain 5>
      | |   +-o IOUSBHostDevice@3d200000  <class AppleUSBDevice, id 0x100000411, registered, matched, active, busy 0 (0 ms), retain 12>
      | |   | +-o AppleUSBInterface@0  <class AppleUSBInterface, id 0x10000041b, !registered, !matched, active, busy 0, retain 4>
      | |   +-o Apple Keyboard@3d220000  <class AppleUSBDevice, id 0x100000424, registered, matched, active, busy 0 (20 ms), retain 13>
      | |     +-o AppleUSBInterface@0  <class AppleUSBInterface, id 0x10000042e, registered, matched, active, busy 0 (9 ms), retain 5>
      | |     +-o AppleUSBInterface@1  <class AppleUSBInterface, id 0x100000432, registered, matched, active, busy 0 (9 ms), retain 5>
      | +-o AppleUSBHostPacketFilterService  <class AppleUSBHostPacketFilterService, id 0x1000001f5, !registered, !matched, active, busy 0, retain 4>
      +-o net_lundman_zfs_zvol  <class net_lundman_zfs_zvol, id 0x10000026b, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o IONetworkStack  <class IONetworkStack, id 0x10000026c, registered, matched, active, busy 0 (0 ms), retain 12>
      | +-o IONetworkStackUserClient  <class IONetworkStackUserClient, id 0x100000301, !registered, !matched, active, busy 0, retain 5>
      +-o IOHIDResource  <class IOHIDResource, id 0x10000026d, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o IOHIDSystem  <class IOHIDSystem, id 0x10000026e, registered, matched, active, busy 0 (0 ms), retain 18>
      | +-o IOHIDEventSystemUserClient  <class IOHIDEventSystemUserClient, id 0x10000030d, !registered, !matched, active, busy 0, retain 5>
      | +-o IOHIDUserClient  <class IOHIDUserClient, id 0x100000444, !registered, !matched, active, busy 0, retain 5>
      | +-o IOHIDParamUserClient  <class IOHIDParamUserClient, id 0x100000445, !registered, !matched, active, busy 0, retain 7>
      +-o at_obdev_LSNKE  <class at_obdev_LSNKE, id 0x10000026f, registered, matched, active, busy 0 (0 ms), retain 12>
      | +-o IORegistryDescriptorC3  <class IORegistryDescriptorC3, id 0x100000319, !registered, !matched, active, busy 0, retain 7>
      | +-o IORegistryDescriptorC5  <class IORegistryDescriptorC5, id 0x10000031a, !registered, !matched, active, busy 0, retain 5>
      | +-o IORegistryDescriptorC5  <class IORegistryDescriptorC5, id 0x10000031b, !registered, !matched, active, busy 0, retain 5>
      | +-o IORegistryDescriptorC5  <class IORegistryDescriptorC5, id 0x10000031c, !registered, !matched, active, busy 0, retain 5>
      | +-o IORegistryDescriptorC5  <class IORegistryDescriptorC5, id 0x10000031d, !registered, !matched, active, busy 0, retain 5>
      | +-o IORegistryDescriptorC2  <class IORegistryDescriptorC2, id 0x1000004ab, !registered, !matched, active, busy 0, retain 5>
      | +-o IORegistryDescriptorC4  <class IORegistryDescriptorC4, id 0x1000004dd, !registered, !matched, active, busy 0, retain 5>
      +-o AppleMobileFileIntegrity  <class AppleMobileFileIntegrity, id 0x100000270, registered, matched, active, busy 0 (0 ms), retain 6>
      +-o com_apple_filesystems_hfs_encodings  <class com_apple_filesystems_hfs_encodings, id 0x100000272, !registered, !matched, active, busy 0, retain 4>
      +-o com_apple_filesystems_hfs  <class com_apple_filesystems_hfs, id 0x100000273, !registered, !matched, active, busy 0, retain 4>
      +-o com_apple_BootCache  <class com_apple_BootCache, id 0x100000274, !registered, !matched, active, busy 0, retain 4>
      +-o com_apple_AppleFSCompression_AppleFSCompressionTypeZlib  <class com_apple_AppleFSCompression_AppleFSCompressionTypeZlib, id 0x100000275, !registered, !matched, active, busy 0, retain 4>
      +-o com_apple_AppleFSCompression_AppleFSCompressionTypeDataless  <class com_apple_AppleFSCompression_AppleFSCompressionTypeDataless, id 0x100000276, !registered, !matched, active, busy 0, retain 4>
      +-o AppleSCSISubsystemGlobals  <class AppleSCSISubsystemGlobals, id 0x1000002fd, registered, matched, active, busy 0 (0 ms), retain 6>
      +-o AppleIntelSlowAdaptiveClockingManager  <class AppleIntelSlowAdaptiveClockingManager, id 0x100000344, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o AppleGPUWrangler  <class AppleGPUWrangler, id 0x100000345, registered, matched, active, busy 0 (3 ms), retain 8>
      | +-o AppleGraphicsDeviceControlPlugin  <class AppleGraphicsDeviceControlPlugin, id 0x100000351, registered, matched, active, busy 0 (0 ms), retain 7>
      | | +-o AGDCPluginDisplayMetrics  <class AGDCPluginDisplayMetrics, id 0x100000352, !registered, !matched, active, busy 0, retain 5>
      | +-o AppleGPUWranglerClient  <class AppleGPUWranglerClient, id 0x10000036e, !registered, !matched, active, busy 0, retain 5>
      | +-o AppleGPUWranglerClient  <class AppleGPUWranglerClient, id 0x10000047a, !registered, !matched, active, busy 0, retain 5>
      +-o AppleHV  <class AppleHV, id 0x100000347, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o AppleSSE  <class AppleSSE, id 0x100000348, registered, matched, active, busy 0 (0 ms), retain 8>
      +-o Dont_Steal_Mac_OS_X  <class Dont_Steal_Mac_OS_X, id 0x100000349, !registered, !matched, active, busy 0, retain 5>
      +-o IOBluetoothHCIController  <class IOBluetoothHCIController, id 0x10000034a, !registered, !matched, active, busy 0, retain 4>
      +-o IOBluetoothSerialManager  <class IOBluetoothSerialManager, id 0x10000034b, registered, matched, active, busy 0 (1 ms), retain 6>
      | +-o IOBluetoothSerialClient  <class IOBluetoothSerialClient, id 0x100000355, !registered, !matched, active, busy 0 (0 ms), retain 5>
      |   +-o IOBluetoothSerialClientSerialStreamSync  <class IOBluetoothSerialClientSerialStreamSync, id 0x100000359, registered, matched, active, busy 0 (0 ms), retain 6>
      |     +-o IOSerialBSDClient  <class IOSerialBSDClient, id 0x10000035a, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o IODisplayWrangler  <class IODisplayWrangler, id 0x10000034c, registered, matched, active, busy 0 (1 ms), retain 10>
      | +-o IOAccelerationUserClient  <class IOAccelerationUserClient, id 0x10000047e, !registered, !matched, active, busy 0, retain 5>
      +-o IOSurfaceRoot  <class IOSurfaceRoot, id 0x10000034d, registered, matched, active, busy 0 (1 ms), retain 24>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x10000047c, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x1000004ad, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x1000004b5, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x1000004bb, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x1000004c9, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x1000004cf, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x1000004ea, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x1000004f3, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x100000505, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x100000514, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x100000519, !registered, !matched, active, busy 0, retain 5>
      | +-o IOSurfaceRootUserClient  <class IOSurfaceRootUserClient, id 0x10000052a, !registered, !matched, active, busy 0, retain 5>
      +-o IOUserEthernetResource  <class IOUserEthernetResource, id 0x10000034e, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o com_apple_driver_pmtelemetry  <class com_apple_driver_pmtelemetry, id 0x10000034f, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o com_mologie_NVWebDriverLibValFix  <class com_mologie_NVWebDriverLibValFix, id 0x100000350, !registered, !matched, active, busy 0, retain 4>
      +-o org_virtualbox_SupDrv  <class org_virtualbox_SupDrv, id 0x1000003fa, registered, matched, active, busy 0 (0 ms), retain 5>
      +-o org_virtualbox_VBoxUSB  <class org_virtualbox_VBoxUSB, id 0x100000406, registered, matched, active, busy 0 (1 ms), retain 5>

I need a ioreg dump using ioregistryviewer

Link to comment
Share on other sites
  • 1 month later...
Cyberdevs
Cyberdevs
Posted
Posted (edited)

Hi guys,

I recently switched from my 1070 to an AMD RX 580, the temperature is about 50C to 53C, can anyone please share their GPU temps for comparison?

I know this (Asus ROG Strix) should be around 38 while idle (in windows of course) but I don't put any load on it and the temps are as I said.

I'm using a customized SSDT but with WEG the results is the same.

Thanks for your precious input.

Edited by Cyberdevs
Link to comment
Share on other sites
EdoardoConti
EdoardoConti
Posted
Posted (edited)

Hi, I've problems with my RX 460.

It's recognised in "About this Mac" but MacX video converter pro doesn't see a GPU so HW encoding is not supported. Geekbench mark 30K when others RX 460 get 70K+ .

I tried BruceX benchmark on FCPX and I took 1m22s and the master file was glitched ( left side totally green ) .

5aabf4f222eaf_ScreenShot2018-03-16at17_45_00.png.fe7f9aa74c45ea569c338a0988848341.png

Debug file: https://www.dropbox.com/s/2y99cd2g0llcykm/Send me Contis-iMac.homenet.telecomitalia.it_160318.zip?dl=0

( I can't upload a .zip file as attachment: error -200 )



Edited by EdoardoConti
Link to comment
Share on other sites
robertr
robertr
Posted
Posted (edited)
On 2018-03-14 at 4:58 PM, Cyberdevs said:

Hu guys,

I recently switched from my 1070 to an AMD RX 580, the temperature is about 50C to 53C, can anyone please share their GPU temps for comparison?

I know this (Asus ROG Strix) should be around 38 while idle (in windows of course) but I don't put any load on it and the temps are as I said.

I'm using a customized SSDT but with WEG the results is the same.

Thanks for your precious input.

I have the ASUS ROG STRIX RX 580 TOP 8GB (factory overclock) and it's running at around 45°C idle. (fans not running)
Reaching about 73°C after a few minutes of FurMark Stress Test, 105 fps @ 1680x1050.
Geekbench 4 Metal: 142688
Geekbench 4 OpenCL: 134945

Edited by robertr
  • Thanks 1
Link to comment
Share on other sites
  • 3 weeks later...
Cyberdevs
Cyberdevs
Posted
Posted

No it's not normal, make sure that you have it set as primary GPU in BIOS and make sure the the GOP settings are also correct.

1 minute ago, telepati said:

I am getting the signal loss on boot with RX560 is that normal?



Link to comment
Share on other sites
telepati
telepati
Posted
Posted (edited)
32 minutes ago, Cyberdevs said:

No it's not normal, make sure that you have it set as primary GPU in BIOS and make sure the the GOP settings are also correct.



2

These are my settings and tried combination;

BIOS;

Primary is PEG

CSM disabled and this patch;

<key>KextsToPatch</key>
        <array>
            <dict>
                <key>Comment</key>
                <string>Disable board-id check to prevent no signal © lvs1974, Pike R. Alpha, vit9696</string>
                <key>Disabled</key>
                <false/>
                <key>Find</key>
                <data>
                ugUAAAA=
                </data>
                <key>InfoPlistPatch</key>
                <false/>
                <key>Name</key>
                <string>com.apple.driver.AppleGraphicsDevicePolicy</string>
                <key>Replace</key>
                <data>
                ugAAAAA=
                </data>
            </dict>
        </array>

I also tried this combination;

BIOS Primary PEG,

WhateverGreen.kext + Lilu.kext

Nothing change with this combination same signal loss on boot.

Should I need Rename PEGP to GFX0?

What is the GOP?





Edited by telepati
Link to comment
Share on other sites
telepati
telepati
Posted
Posted (edited)
11 minutes ago, Cyberdevs said:

GOP is how the UEFI manages the video output trough GPU's UEFI BIOS.

Is fast boot disables in BIOS?

How to find this GOP settings?

Yes, FastBoot is disabled.

These are full settings of my BIOS;

Ai Tweaker --> DRAM Frequency --> Set to 2400MHz
Advanced --> System Agent (SA) Configuration --> VT-d Disabled
Advanced --> (SA) Configuration --> Graphics Configuration --> Primary Display --> PEG
Advanced --> (SA) Configuration --> Graphics Configuration --> IGPU Multi-Monitor --> Disabled
Advanced --> (SA) Configuration --> IOAPIC 24-119 Entries --> Disabled
Advanced --> USB Configuration --> XHCI Handoff --> Enabled
Advanced --> USB Configuration --> Legacy USB Support --> Disabled
Advanced --> Onboard Devices Configuration --> Serial Port Configuration --> Serial Port Off
Boot --> CSM (Compatibility Support Module) Launch CSM --> Disabled
Boot --> Fast Boot --> Disable
Secure Boot --> OS Type > Other OS

Edited by telepati
Link to comment
Share on other sites
telepati
telepati
Posted
Posted
1 hour ago, Cyberdevs said:

What about iGPU is it also disabled?

Yes, IGPU is disabled.

1 hour ago, Cyberdevs said:

Give this folder a try

https://www.dropbox.com/s/wucd5vq53du244l/Working 02 - SSDT for RX 560 and CPU.zip?dl=0

I will try with your files.

I want to ask you this, in ioreg RX560 using AMDRadeonX4000_AMDBaffinGraphicsAccelerator is that correct? I attached my ioreg.



Murat’s Mac.zip

Link to comment
Share on other sites
Cyberdevs
Cyberdevs
Posted
Posted
9 minutes ago, telepati said:

Yes, IGPU is disabled.

I will try with your files.

I want to ask you this, in ioreg RX560 using AMDRadeonX4000_AMDBaffinGraphicsAccelerator is that correct? I attached my ioreg.

Yes that frame buffer is correct. There is an SSDT in my EFI folder which uses the Acre framebuffer. I created that SSDT for my Asus Strix RX 560 OC you can remove it if you are using a different GPU.

Just remember if you are using WhateverGreen don't use InjectATI and do not inject any framebuffer via clover.

Link to comment
Share on other sites
telepati
telepati
Posted
Posted
15 minutes ago, Cyberdevs said:

Yes that frame buffer is correct. There is an SSDT in my EFI folder which uses the Acre framebuffer. I created that SSDT for my Asus Strix RX 560 OC you can remove it if you are using a different GPU.

Just remember if you are using WhateverGreen don't use InjectATI and do not inject any framebuffer via clover.

Thank you. My GPU is Asus Strix RX560 OC but I added but it looks does not load.

Unsupported ATI card! Device ID: [1002:67FF] Subsystem ID: [04BE1043]

I also attached my CLOVER folder. Could you please check?

Spoiler

0:100  0:100  MemLog inited, TSC freq: 4008548110
0:100  0:000  CPU was calibrated with RTC
0:100  0:000
0:100  0:000  Now is 5.4.2018,  17:56:35 (GMT)
0:100  0:000  Starting Clover revision: 4423.RM-4614.23304(cf0897a3.8907451b54)  on American Megatrends EFI
0:100  0:000  Build with: [Args: -mc --no-usb -D NO_GRUB_DRIVERS_EMBEDDED -t XCODE8 | -D DISABLE_USB_SUPPORT -D NO_GRUB_DRIVERS_EMBEDDED -D USE_BIOS_BLOCKIO -D USE_LOW_EBDA -a X64 -b RELEASE -t XCODE8 -n 9 | OS: 10.13.4 | XCODE: 9.3]
0:100  0:000  SelfDevicePath=PciRoot(0x0)\Pci(0x1D,0x0)\Pci(0x0,0x0)\NVMe(0x1,39-21-B0-71-54-38-25-00)\HD(1,GPT,AF79C475-E530-4EED-9472-1DAFD6548501,0x28,0x64000) @8B0FBB18
0:100  0:000  SelfDirPath = \EFI\BOOT
0:100  0:000  === [ Get Smbios ] ========================================
0:100  0:000  Type 16 Index = 0
0:100  0:000  Total Memory Slots Count = 4
0:100  0:000  Type 17 Index = 0
0:100  0:000  SmbiosTable.Type17->Speed = 2400MHz
0:100  0:000  SmbiosTable.Type17->Size = 16384MB
0:100  0:000  SmbiosTable.Type17->Bank/Device = BANK 0 ChannelA-DIMM1
0:100  0:000  SmbiosTable.Type17->Vendor = CRUCIAL
0:100  0:000  SmbiosTable.Type17->SerialNumber = A1176A1D
0:100  0:000  SmbiosTable.Type17->PartNumber = BLS16G4D240FSB.16FAD
0:100  0:000  Type 17 Index = 1
0:100  0:000  SmbiosTable.Type17->Speed = 2400MHz
0:100  0:000  SmbiosTable.Type17->Size = 16384MB
0:100  0:000  SmbiosTable.Type17->Bank/Device = BANK 1 ChannelA-DIMM2
0:100  0:000  SmbiosTable.Type17->Vendor = CRUCIAL
0:100  0:000  SmbiosTable.Type17->SerialNumber = A1176A23
0:100  0:000  SmbiosTable.Type17->PartNumber = BLS16G4D240FSB.16FAD
0:100  0:000  Type 17 Index = 2
0:100  0:000  SmbiosTable.Type17->Speed = 2400MHz
0:100  0:000  SmbiosTable.Type17->Size = 16384MB
0:100  0:000  SmbiosTable.Type17->Bank/Device = BANK 2 ChannelB-DIMM1
0:100  0:000  SmbiosTable.Type17->Vendor = CRUCIAL
0:100  0:000  SmbiosTable.Type17->SerialNumber = A41802CD
0:100  0:000  SmbiosTable.Type17->PartNumber = BLS16G4D240FSB.16FAD
0:100  0:000  Type 17 Index = 3
0:100  0:000  SmbiosTable.Type17->Speed = 2400MHz
0:100  0:000  SmbiosTable.Type17->Size = 16384MB
0:100  0:000  SmbiosTable.Type17->Bank/Device = BANK 3 ChannelB-DIMM2
0:100  0:000  SmbiosTable.Type17->Vendor = CRUCIAL
0:100  0:000  SmbiosTable.Type17->SerialNumber = A41802D0
0:100  0:000  SmbiosTable.Type17->PartNumber = BLS16G4D240FSB.16FAD
0:100  0:000  Boot status=0
0:100  0:000  Running on: 'System Product Name' with board 'Z170-A'
0:100  0:000  === [ GetCPUProperties ] ==================================
0:100  0:000  CPU Vendor = 756E6547 Model=506E3
0:100  0:000   The CPU supported SSE4.1
0:100  0:000  BrandString = Intel(R) Core(TM) i7-6700K CPU @ 4.00GHz
0:100  0:000   The CPU supported turbo
0:100  0:000  MSR 0x35               40008
0:100  0:000   TSC/CCC Information Leaf:
0:100  0:000    numerator     : 334
0:100  0:000    denominator   : 2
0:100  0:000   Calibrated ARTFrequency: 24003282
0:100  0:000  MSR 0xE2 before patch 00000000
0:100  0:000  MSR 0xCE              00080838_F1012800
0:100  0:000  corrected FLEX_RATIO = E0000
0:100  0:000  MSR 0x1B0             00000000
0:100  0:000  FSBFrequency = 100 MHz, DMI FSBFrequency = 100 MHz, Corrected FSBFrequency = 100 MHz
0:100  0:000  MaxDiv/MinDiv: 40.0/8
0:100  0:000  Turbo: 42/42/42/42
0:100  0:000  Features: 0xBFEBFBFF
0:100  0:000  Threads: 8
0:100  0:000  Cores: 4
0:100  0:000  FSB: 100 MHz
0:100  0:000  CPU: 4000 MHz
0:100  0:000  TSC: 4000 MHz
0:100  0:000  PIS: 100 MHz
0:100  0:000  ExternalClock: 25 MHz
0:100  0:000  === [ GetDevices ] ========================================
0:100  0:000  PCI (00|00:00.00) : 8086 191F class=060000
0:100  0:000  PCI (00|00:01.00) : 8086 1901 class=060400
0:100  0:000  PCI (00|01:00.00) : 1002 67FF class=030000
0:100  0:000   - GFX: Model=AMD Radeon RX 560 (ATI/AMD)
0:101  0:000  PCI (00|01:00.01) : 1002 AAE0 class=040300
0:101  0:000   - HDMI Audio:
0:101  0:000  PCI (00|00:14.00) : 8086 A12F class=0C0330
0:101  0:000  PCI (00|00:16.00) : 8086 A13A class=078000
0:101  0:000  PCI (00|00:17.00) : 8086 A102 class=010601
0:101  0:000  PCI (00|00:1B.00) : 8086 A167 class=060400
0:101  0:000  PCI (00|00:1C.00) : 8086 A110 class=060400
0:101  0:000  PCI (00|03:00.00) : 1B21 1242 class=0C0330
0:101  0:000  PCI (00|00:1C.02) : 8086 A112 class=060400
0:101  0:000  PCI (00|04:00.00) : 1B21 1080 class=060400
0:101  0:000  PCI (00|00:1C.05) : 8086 A115 class=060400
0:101  0:000  PCI (00|06:00.00) : 14E4 43A0 class=028000
0:101  0:000   - WIFI: Vendor=Broadcom
0:101  0:000  PCI (00|00:1C.07) : 8086 A117 class=060400
0:101  0:000  PCI (00|07:00.00) : 1B73 1100 class=0C0330
0:101  0:000  PCI (00|00:1D.00) : 8086 A118 class=060400
0:101  0:000  PCI (00|08:00.00) : 144D A804 class=010802
0:101  0:000  PCI (00|00:1F.00) : 8086 A145 class=060100
0:101  0:000  PCI (00|00:1F.02) : 8086 A121 class=058000
0:101  0:000  PCI (00|00:1F.03) : 8086 A170 class=040300
0:101  0:000  PCI (00|00:1F.04) : 8086 A123 class=0C0500
0:101  0:000  PCI (00|00:1F.06) : 8086 15B8 class=020000
0:101  0:000   - LAN: 0 Vendor=Intel
0:101  0:000  === [ GetDefaultSettings ] ================================
0:101  0:000  Clover load options size = 0 bytes
0:103  0:001  EFI\CLOVER\config.plist loaded: Success
0:103  0:000  === [ GetListOfThemes ] ===================================
0:103  0:000  - [00]: tonymacx86
0:104  0:000  === [ Found config plists ] ===============================
0:104  0:000  - config.plist
0:104  0:000  === [ GetEarlyUserSettings ] ==============================
0:104  0:000  timeout set to 2
0:104  0:000  Custom boot CUSTOM_BOOT_DISABLED (0x0)
0:104  0:000  KextsToPatch: 5 requested
0:104  0:000   - [00]: com.apple.driver.AppleAHCIPort (External icons patch) :: MatchOS: 10.13.x :: BinPatch :: data len: 8
0:104  0:000   - [01]: com.apple.driver.usb.AppleUSBXHCI (USB 10.13.4+ by PMHeart) :: MatchOS: 10.13.x :: BinPatch :: data len: 10
0:104  0:000   - patch disabled at config
0:104  0:000   - [02]: com.apple.driver.AppleMikeyDriver (Patch Assertions) :: MatchOS: 10.11.x,10.12.x,10.13.x :: BinPatch :: data len: 16
0:104  0:000   - [03]: AppleUSBXHCIPCI (change 15 port limit to 26 in XHCI kext (100-series)) :: BinPatch :: data len: 4
0:104  0:000   - [04]: com.apple.driver.AppleGraphicsDevicePolicy (Disable board-id check to prevent no signal © lvs1974, Pike R. Alpha, vit9696) :: BinPatch :: data len: 5
0:104  0:000  Default theme: tonymacx86
0:104  0:000  Hiding entries with string Preboot
0:104  0:000  Hiding entries with string Windows
0:104  0:000  ** Warning: unknown custom entry Type 'Other'
0:104  0:000  === [ LoadDrivers ] =======================================
0:105  0:000  Loading FSInject-64.efi  status=Success
0:106  0:001  Loading HFSPlus.efi  status=Success
0:108  0:001   - driver needs connecting
0:108  0:000  Loading AptioMemoryFix.efi  status=Success
0:109  0:001  Loading SMCHelper-64.efi  status=Success
0:110  0:001  1 drivers needs connecting ...
0:110  0:000  PlatformDriverOverrideProtocol->GetDriver overriden
0:110  0:000  HFS+ driver loaded
0:110  0:000  Searching for invalid DiskIo BY_DRIVER connects: not found, all ok
0:415  0:304  === [ InitScreen ] ========================================
0:415  0:000  SetScreenResolution: 1920x1080 - already set
0:415  0:000  Console modes reported: 4, available modes:
0:415  0:000   - [01]: 80x25 (current mode)
0:415  0:000   - [02]: 80x50
0:415  0:000   - [03]: 100x31
0:415  0:000   - [04]: 240x56
0:415  0:000  reinit: self device path=PciRoot(0x0)\Pci(0x1D,0x0)\Pci(0x0,0x0)\NVMe(0x1,39-21-B0-71-54-38-25-00)\HD(1,GPT,AF79C475-E530-4EED-9472-1DAFD6548501,0x28,0x64000)
0:415  0:000  === [ GetMacAddress ] =====================================
0:415  0:000   get legacy LAN MAC, 1 card found
0:415  0:000  Legacy MAC address of LAN #0= 9C:5C:8E:6E:D6:95:
0:415  0:000  === [ ScanSPD ] ===========================================
0:415  0:000  SMBus device : 8086 A123 class=0C0500 status=Success
0:415  0:000  SMBus CmdReg: 0x3
0:415  0:000  Scanning SMBus [8086:A123], mmio: 0xDFF4A004, ioport: 0xF000, hostc: 0x11
0:415  0:000  Slots to scan [8]...
0:416  0:000  SPD[0]: Got invalid type 0 @0x50. Will set page and retry.
0:416  0:000  SPD[0]: Type 12 @0x50
0:434  0:017  XMP Profile1: 7*125 -42 ns
0:434  0:000  Found module with XMP version 2.0
0:434  0:000  Using XMP Profile1 instead of standard frequency 2400MHz
0:434  0:000  DDR speed 2400MHz
0:434  0:000  Slot: 0 Type 26 16384MB 2400MHz Vendor=Crucial Technology PartNo=BLS16G4D240FSB.16FAD SerialNo=0A010107060A010D
0:435  0:000  SPD[1]: Type 12 @0x51
0:453  0:017  XMP Profile1: 7*125 -42 ns
0:453  0:000  Found module with XMP version 2.0
0:453  0:000  Using XMP Profile1 instead of standard frequency 2400MHz
0:453  0:000  DDR speed 2400MHz
0:453  0:000  Slot: 1 Type 26 16384MB 2400MHz Vendor=Crucial Technology PartNo=BLS16G4D240FSB.16FAD SerialNo=0A010107060A0203
0:453  0:000  SPD[2]: Type 12 @0x52
0:471  0:017  XMP Profile1: 7*125 -42 ns
0:471  0:000  Found module with XMP version 2.0
0:471  0:000  Using XMP Profile1 instead of standard frequency 2400MHz
0:471  0:000  DDR speed 2400MHz
0:471  0:000  Slot: 2 Type 26 16384MB 2400MHz Vendor=Crucial Technology PartNo=BLS16G4D240FSB.16FAD SerialNo=0A04010800020C0D
0:472  0:000  SPD[3]: Type 12 @0x53
0:490  0:017  XMP Profile1: 7*125 -42 ns
0:490  0:000  Found module with XMP version 2.0
0:490  0:000  Using XMP Profile1 instead of standard frequency 2400MHz
0:490  0:000  DDR speed 2400MHz
0:490  0:000  Slot: 3 Type 26 16384MB 2400MHz Vendor=Crucial Technology PartNo=BLS16G4D240FSB.16FAD SerialNo=0A04010800020D00
0:490  0:000  === [ GetAcpiTablesList ] =================================
0:490  0:000  Get Acpi Tables List from RSDT:
0:490  0:000   - [00]: FACP  A M I  len=132
0:490  0:000   - [01]: APIC  A M I  len=188
0:490  0:000   - [02]: FPDT  A M I  len=68
0:490  0:000   - [04]: MCFG  A M I  len=60
0:490  0:000   - [05]: SSDT  SataTabl len=912
0:490  0:000   - [06]: FIDT  A M I len=156
0:490  0:000   - [07]: SSDT  SaSsdt  len=12628
0:490  0:000   - [08]: SSDT  PegSsdt len=9534
0:490  0:000   - [09]: HPET  SKL len=56
0:490  0:000   - [10]: SSDT  OEM_RTD3 len=36
0:490  0:000   - [11]: SSDT  xh_rvp08 len=2835
0:490  0:000   - [12]: UEFI  EDK2     len=66
0:490  0:000   - [13]: SSDT  CpuSsdt len=3806
0:490  0:000   - [14]: LPIT  SKL len=148
0:490  0:000   - [15]: WSMT  SKL len=40
0:490  0:000   - [16]: SSDT  sensrhub len=671
0:490  0:000   - [17]: SSDT  PtidDevc len=12290
0:490  0:000   - [18]: DBGP   len=52
0:490  0:000   - [19]: DBG2   len=84
0:490  0:000   - [20]: BGRT  A M I  len=56
0:490  0:000  Calibrated TSC Frequency = 4008548110 = 4008MHz
0:490  0:000  === [ GetUserSettings ] ===================================
0:490  0:000  USB FixOwnership: yes
0:490  0:000  Dropping 1 tables:
0:490  0:000   - [00]: Drop table  signature="DMAR" (52414D44)
0:490  0:000           - set table: 52414D44,                0 to drop: no
0:490  0:000   - final DSDT Fix mask=70400000
0:490  0:000  PatchesDSDT: 6 requested
0:490  0:000   - [00]: (change GFX0 to IGPU) lenToFind: 4, lenToReplace: 4, Target Bridge: <null string>
0:490  0:000   - [01]: (change HDAS to HDEF) lenToFind: 4, lenToReplace: 4, Target Bridge: <null string>
0:490  0:000   - [02]: (change HECI to IMEI) lenToFind: 4, lenToReplace: 4, Target Bridge: <null string>
0:490  0:000   - [03]: (change SAT0 to SATA) lenToFind: 4, lenToReplace: 4, Target Bridge: <null string>
0:490  0:000   - [04]: (change Z170-A UART) lenToFind: 4, lenToReplace: 4, Target Bridge: <null string>
0:490  0:000   - [05]: (AMD/Nvidia GPU PM- Rename PEGP to GFX0) lenToFind: 4, lenToReplace: 4, Target Bridge: <null string>
0:490  0:000  Using ProductName from config: iMac17,1
0:490  0:000  Using latest BiosVersion from clover
0:490  0:000  BiosVersion: IM171.88Z.0151.B00.1802080854
0:490  0:000  BiosReleaseDate: 02/08/2018
0:490  0:000  Using FirmwareFeatures from config: 0xFC0FE137
0:490  0:000  Using FirmwareFeaturesMask from config: 0xFF1FFF3F
0:490  0:000  Board-ID set from config as Mac-65CE76090165799A
0:490  0:000  BoardType: 0xA
0:490  0:000  ChassisType: 0x9
0:491  0:000  === [ ScanVolumes ] =======================================
0:491  0:000  Found 19 volumes with blockIO
0:491  0:000  - [00]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x2,0xFFFF,0x0)
0:492  0:000  - [01]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x3,0xFFFF,0x0)
0:494  0:002  - [02]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x4,0xFFFF,0x0)
0:495  0:000  - [03]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x5,0xFFFF,0x0)
0:495  0:000  - [04]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x2,0xFFFF,0x0)\HD(1,GPT,0F44F337-B09C-4BD2-A501-6843A254C351,0x28,0x64000)
0:496  0:000          Result of bootcode detection: bootable unknown (legacy)
0:498  0:001  - [05]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x2,0xFFFF,0x0)\HD(2,GPT,A86CE3C2-E833-423F-89C9-4350048DFCF3,0x64028,0xE8D64860)
0:498  0:000  - [06]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x3,0xFFFF,0x0)\HD(1,GPT,2FA8CE9F-9D61-11E7-9BCF-B418D1E75E8C,0x800,0x199008)
0:499  0:000          Result of bootcode detection: bootable Windows (vista,win)
0:499  0:000  - [07]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x3,0xFFFF,0x0)\HD(2,GPT,7B2E0D43-F7A1-45AC-9CB3-83238F6961CB,0x199808,0x64008)
0:500  0:000          Result of bootcode detection: bootable Windows (vista,win)
0:502  0:001  - [08]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x3,0xFFFF,0x0)\HD(3,GPT,2FA8CEA1-9D61-11E7-9BCF-B418D1E75E8C,0x1FD810,0x8008)
0:502  0:000  - [09]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x3,0xFFFF,0x0)\HD(4,GPT,2FA8CEA2-9D61-11E7-9BCF-B418D1E75E8C,0x205818,0x1A047855)
0:503  0:000          Result of bootcode detection: bootable Windows (vista,win)
0:503  0:000          hiding this volume
0:503  0:000  - [10]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x3,0xFFFF,0x0)\HD(5,GPT,D72BCAF0-EC9C-418E-B560-2C1A6A3DACAC,0x1A24D800,0xE4000)
0:503  0:000          Result of bootcode detection: bootable Windows (vista,win)
0:503  0:000  - [11]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x4,0xFFFF,0x0)\HD(1,GPT,5FCCCA38-0704-41A4-A860-4E8B57A241D0,0x28,0x64000)
0:504  0:000          Result of bootcode detection: bootable unknown (legacy)
0:506  0:001  - [12]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x4,0xFFFF,0x0)\HD(2,GPT,CEED4E03-5899-436C-A6F6-76BA457938D5,0x64028,0x74662D60)
0:507  0:000  - [13]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x5,0xFFFF,0x0)\HD(1,GPT,F98067FD-F23B-4120-B99B-2E03DEB71630,0x28,0x64000)
0:507  0:000          Result of bootcode detection: bootable unknown (legacy)
0:509  0:001  - [14]: Volume: PciRoot(0x0)\Pci(0x17,0x0)\Sata(0x5,0xFFFF,0x0)\HD(2,GPT,2134938F-F958-4DA5-891A-656F5C38D744,0x64028,0xE8D64860)
0:509  0:000  - [15]: Volume: PciRoot(0x0)\Pci(0x1D,0x0)\Pci(0x0,0x0)\NVMe(0x1,39-21-B0-71-54-38-25-00)
0:509  0:000  - [16]: Volume: PciRoot(0x0)\Pci(0x1D,0x0)\Pci(0x0,0x0)\NVMe(0x1,39-21-B0-71-54-38-25-00)\HD(1,GPT,AF79C475-E530-4EED-9472-1DAFD6548501,0x28,0x64000)
0:510  0:000          Result of bootcode detection: bootable unknown (legacy)
0:510  0:000          This is SelfVolume !!
0:510  0:000  - [17]: Volume: PciRoot(0x0)\Pci(0x1D,0x0)\Pci(0x0,0x0)\NVMe(0x1,39-21-B0-71-54-38-25-00)\HD(2,GPT,6B9D57DD-9F38-4251-A48F-45D236385B8D,0x64028,0x1CFEBA00)
0:510  0:000  - [18]: Volume: PciRoot(0x0)\Pci(0x1D,0x0)\Pci(0x0,0x0)\NVMe(0x1,39-21-B0-71-54-38-25-00)\HD(3,GPT,E4652687-8F47-496B-A964-E8285147E4B1,0x1D04FA28,0x135F20)
0:510  0:000  === [ InitTheme ] =========================================
0:511  0:000  Using theme 'tonymacx86' (EFI\CLOVER\themes\tonymacx86)
0:511  0:000  Loading font from ThemeDir: Error
0:512  0:000  Choosing theme tonymacx86
0:512  0:000  after NVRAM boot-args=shikigva=25 uia_exclude=HS03;HS04;HS07;HS08;HS11;HS12;HS13;SS03;SS04;SS07;SS08;SS09;SS10; -disablegfxfirmware
0:512  0:000  === [ Dump SMC keys from NVRAM ] ==========================
0:512  0:000  found AppleSMC protocol
0:592  0:079  Registered 17 SMC keys
0:594  0:002  === [ AddCustomEntries ] ==================================
0:594  0:000  Custom entry 0 skipped because it is hidden.
0:594  0:000  === [ ScanLoader ] ========================================
0:594  0:000  - [04]: 'EFI'
0:611  0:016  - [05]: 'Design Element'
0:611  0:000  - [06]: ''
0:611  0:000  - [07]: 'EFI'
0:627  0:015          AddLoaderEntry for Volume Name=EFI
0:627  0:000      Not match custom entry 0: Type: not match
0:636  0:009  - [09]: 'Windows 10', hidden
0:636  0:000  - [10]: ''
0:636  0:000  - [11]: 'EFI'
0:652  0:015  - [12]: 'Back Up'
0:652  0:000  - [13]: 'EFI'
0:668  0:015  - [14]: 'Time Machine'
0:668  0:000  - [16]: 'EFI'
0:670  0:001  - [17]: 'High Sierra'
0:671  0:000          AddLoaderEntry for Volume Name=High Sierra
0:671  0:000      Not match custom entry 0: Type: not match
0:671  0:000      Check if volume Is Hibernated:
0:671  0:000      Check sleep image 'by signature':
0:672  0:000      read prefs \Library\Preferences\com.apple.PowerManagement.plist status=Success
0:672  0:000      using default sleep image name = \private\var\vm\sleepimage
0:673  0:000      no valid sleep image offset was found
0:673  0:000       sleepimage offset could not be acquired
0:673  0:000      hibernated: no - sign
0:674  0:001  - [18]: 'Recovery HD'
0:675  0:000          AddLoaderEntry for Volume Name=Recovery HD
0:675  0:000      Not match custom entry 0: Type: not match
0:676  0:001  === [ AddCustomTool ] =====================================
0:676  0:000  found tool \EFI\CLOVER\tools\Shell64U.efi
0:676  0:000  Checking EFI partition Volume 4 for Clover
0:679  0:002  Checking EFI partition Volume 7 for Clover
0:682  0:003  Checking EFI partition Volume 11 for Clover
0:685  0:002  Checking EFI partition Volume 13 for Clover
0:688  0:002  Checking EFI partition Volume 16 for Clover
0:688  0:000   Found Clover
0:689  0:001  === [ GetEfiBootDeviceFromNvram ] =========================
0:690  0:000   - found entry 1. 'Boot macOS from High Sierra', Volume 'High Sierra', DevicePath 'PciRoot(0x0)\Pci(0x1D,0x0)\Pci(0x0,0x0)\NVMe(0x1,39-21-B0-71-54-38-25-00)\HD(2,GPT,6B9D57DD-9F38-4251-A48F-45D236385B8D,0x64028,0x1CFEBA00)\System\Library\CoreServices\boot.efii'
0:690  0:000  DefaultIndex=1 and MainMenu.EntryCount=9
0:799  0:108  GUI ready
3:803  3:004  === [ StartLoader ] =======================================
3:803  0:000  Finally: ExternalClock=25MHz BusSpeed=100213kHz CPUFreq=4009MHz PIS: hw.busfrequency=100000000Hz
3:803  0:000  Loading boot.efi  status=Success
3:860  0:056  GetOSVersion: 10.13.4 (17E199)
3:860  0:000  CSR_CFG: CSR_ALLOW_UNTRUSTED_KEXTS | CSR_ALLOW_UNRESTRICTED_FS | CSR_ALLOW_TASK_FOR_PID | CSR_ALLOW_UNRESTRICTED_DTRACE | CSR_ALLOW_UNRESTRICTED_NVRAM
3:860  0:000  Filtering KextPatches:
3:860  0:000   - [00]: com.apple.driver.AppleAHCIPort (External icons patch) :: BinPatch :: [OS: 10.13.4 | MatchOS: 10.13.x | MatchBuild: All] ==> allowed
3:860  0:000   - [01]: com.apple.driver.usb.AppleUSBXHCI (USB 10.13.4+ by PMHeart) :: BinPatch :: [OS: 10.13.4 | MatchOS: 10.13.x | MatchBuild: All] ==> disabled by user
3:860  0:000   - [02]: com.apple.driver.AppleMikeyDriver (Patch Assertions) :: BinPatch :: [OS: 10.13.4 | MatchOS: 10.11.x,10.12.x,10.13.x | MatchBuild: All] ==> allowed
3:860  0:000   - [03]: AppleUSBXHCIPCI (change 15 port limit to 26 in XHCI kext (100-series)) :: BinPatch :: [OS: 10.13.4 | MatchOS: All | MatchBuild: All] ==> allowed
3:860  0:000   - [04]: com.apple.driver.AppleGraphicsDevicePolicy (Disable board-id check to prevent no signal © lvs1974, Pike R. Alpha, vit9696) :: BinPatch :: [OS: 10.13.4 | MatchOS: All | MatchBuild: All] ==> allowed
3:860  0:000  Will not patch boot.efi
3:860  0:000  === [ PatchSmbios ] =======================================
3:860  0:000  insert table 9 for dev 0:0
3:860  0:000  insert table 9 for dev 0:1
3:860  0:000  insert table 9 for dev 1F:6
3:860  0:000  insert table 9 for dev 0:0
3:861  0:000  Trusting SMBIOS...
3:861  0:000  Channels: 2
3:861  0:000  Interleave: 0 2 1 3 4 6 5 7 8 10 9 11 12 14 13 15 16 18 17 19 20 22 21 23
3:861  0:000   partNum=BLS16G4D240FSB.16FAD
3:861  0:000  SMBIOS Type 17 Index = 0 => 0 0:
3:861  0:000  BANK 0 DIMM0 2400MHz 16384MB
3:861  0:000   partNum=BLS16G4D240FSB.16FAD
3:861  0:000  SMBIOS Type 17 Index = 1 => 2 2:
3:861  0:000  BANK 1 DIMM0 2400MHz 16384MB
3:861  0:000   partNum=BLS16G4D240FSB.16FAD
3:861  0:000  SMBIOS Type 17 Index = 2 => 1 1:
3:861  0:000  BANK 0 DIMM1 2400MHz 16384MB
3:861  0:000   partNum=BLS16G4D240FSB.16FAD
3:861  0:000  SMBIOS Type 17 Index = 3 => 3 3:
3:861  0:000  BANK 1 DIMM1 2400MHz 16384MB
3:861  0:000  mTotalSystemMemory = 65536
3:861  0:000  NumberOfMemoryDevices = 4
3:861  0:000  Type20[0]->End = 0xFFFFFF, Type17[0] = 0x4000
3:861  0:000  Type20[1]->End = 0x2FFFFFF, Type17[2] = 0x10000
3:861  0:000  Type20[2]->End = 0x1FFFFFF, Type17[1] = 0x18000
3:861  0:000  Table 131 is present, CPUType=10
3:861  0:000  Change to: 705
3:861  0:000  === [ PatchACPI ] =========================================
3:861  0:000  Xsdt reallocation done
3:861  0:000  old FADT length=114
3:861  0:000   SignatureFixup: 0xF7230E75 -> 0x0
3:861  0:000  Found OperationRegion(GNVS, SystemMemory, 8F067000, ...)
3:861  0:000  Found OperationRegion(CPSB, SystemMemory, 8E7D5F98, ...)
3:861  0:000  Found OperationRegion(PNVA, SystemMemory, 8F06C018, ...)
3:861  0:000  Found OperationRegion(THBA, SystemMemory, FE200000, ...)
3:862  0:000  Found OperationRegion(ITSS, SystemMemory, FDC43100, ...)
3:862  0:000  Found OperationRegion(RAMW, SystemMemory, 8ED45018, ...)
3:862  0:000  Found OperationRegion(TMMB, SystemMemory, FED40000, ...)
3:862  0:000  Found OperationRegion(CRBD, SystemMemory, FED40000, ...)
3:862  0:000  Found OperationRegion(TPMR, SystemMemory, FFFFFFFF, ...)
3:862  0:000  Found OperationRegion(ATNV, SystemMemory, FFFF0000, ...)
3:862  0:000  Found OperationRegion(RAMX, SystemMemory, 8F06CD18, ...)
3:862  0:000  Found OperationRegion(GPBX, SystemMemory, FDAE0400, ...)
3:862  0:000  DSDT found in Clover volume OEM folder: EFI\CLOVER\ACPI\patched\DSDT.aml
3:863  0:001  Apply DsdtFixMask=0x70400000
3:863  0:000     drop _DSM mask=0x0000
3:863  0:000  === [ FixBiosDsdt ] =======================================
3:863  0:000  VideoCard devID=0x67FF1002
3:863  0:000  DisplayADR1[0] = 0x10000, DisplayADR2[0] = 0x0
3:863  0:000  USBADR[0] = 0x140000 and PCIe = 0xFFFE
3:863  0:000  USBADR[1] = 0x1C0000 and PCIe = 0x0
3:863  0:000  Found Airport BCM at 0x1C0005, 0x0
3:863  0:000  USBADR[2] = 0x1C0007 and PCIe = 0x0
3:863  0:000  Audio HDA (addr:0x1F0003) setting specified layout-id=1 (0x1)
3:863  0:000  Patching DSDT:
3:863  0:000   - [change GFX0 to IGPU]: pattern 47465830, bin not found / already patched!
3:864  0:000   - [change HDAS to HDEF]: pattern 48444153, bin not found / already patched!
3:864  0:000   - [change HECI to IMEI]: pattern 48454349, bin not found / already patched!
3:864  0:000   - [change SAT0 to SATA]: pattern 53415430, bin not found / already patched!
3:864  0:000   - [change Z170-A UART]: pattern 41D00501, bin not found / already patched!
3:864  0:000   - [AMD/Nvidia GPU PM- Rename PEGP to GFX0]: pattern 50454750, patched at: [ (43E6) (E3) (31) (12849) ]
3:864  0:000  first CPU found at BB9C offset BB9F
3:864  0:000  score candidate at BB98
3:864  0:000  score inserted in acpi_cpu_score _PR_
3:864  0:000  Found ACPI CPU: CPU0 | CPU1 | CPU2 | CPU3 | CPU4 | CPU5 | CPU6 | CPU7 , within the score: _PR_
3:865  0:000  Found PCIROOTUID = 0
3:865  0:000   deleting device CRT_
3:865  0:000   deleting device DVI_
3:866  0:000   deleting device SPKR
3:866  0:000   deleting device ECP_
3:866  0:000   deleting device LPT_
3:866  0:000   deleting device FDC0
3:867  0:000   deleting device ECP1
3:867  0:000   deleting device LPT1
3:867  0:000  OperationRegion (GNVS...) corrected to addr=0x8F067000
3:867  0:000  OperationRegion (CPSB...) corrected to addr=0x8E7D5F98
3:867  0:000    indirect name=PNVB
3:867  0:000  OperationRegion (PNVA...) corrected to addr=0x8F06C018
3:867  0:000  OperationRegion (THBA...) corrected to addr=0xFE200000
3:868  0:000    indirect name=RAMB
3:868  0:000  OperationRegion (RAMW...) corrected to addr=0x8ED45018
3:868  0:000    indirect name=TPMM
3:868  0:000    indirect name=FTPM
3:868  0:000    indirect name=PPIM
3:868  0:000    indirect name=RAMS
3:868  0:000  OperationRegion (RAMX...) corrected to addr=0x8F06CD18
3:868  0:000  Start Mutex Fix
3:868  0:000  PreCleanup XSDT: count=21, length=204
3:868  0:000  PreCleanup XSDT, corrected XSDT: count=21, length=204
3:868  0:000  === [ ACPIPatchedAML ] ====================================
3:868  0:000  AutoMerge pass 1
3:868  0:000  Unsorted
3:868  0:000  Inserting SSDT-RX-560.aml from EFI\CLOVER\ACPI\patched: ignore on pass 1
3:868  0:000  === [ ACPIDropTables ] ====================================
3:868  0:000  === [ PatchAllSSDT ] ======================================
3:868  0:000  Patch table: SSDT  SataTabl len=0x390
3:868  0:000  0. [change GFX0 to IGPU]: pattern 47465830, bin not found / already patched!
3:868  0:000  1. [change HDAS to HDEF]: pattern 48444153, bin not found / already patched!
3:868  0:000  2. [change HECI to IMEI]: pattern 48454349, bin not found / already patched!
3:868  0:000  3. [change SAT0 to SATA]: pattern 53415430, patched at: [ (2D) (A7) ]
3:868  0:000  4. [change Z170-A UART]: pattern 41D00501, bin not found / already patched!
3:868  0:000  5. [AMD/Nvidia GPU PM- Rename PEGP to GFX0]: pattern 50454750, bin not found / already patched!
3:868  0:000  Patch table: SSDT  SaSsdt  len=0x3154
3:868  0:000  0. [change GFX0 to IGPU]: pattern 47465830, patched at: [ (2D) (20) (46) (29B) (1C8A) (A3A) (1D) (6EC) ]
3:868  0:000  1. [change HDAS to HDEF]: pattern 48444153, bin not found / already patched!
3:868  0:000  2. [change HECI to IMEI]: pattern 48454349, bin not found / already patched!
3:868  0:000  3. [change SAT0 to SATA]: pattern 53415430, bin not found / already patched!
3:868  0:000  4. [change Z170-A UART]: pattern 41D00501, bin not found / already patched!
3:868  0:000  5. [AMD/Nvidia GPU PM- Rename PEGP to GFX0]: pattern 50454750, bin not found / already patched!
3:868  0:000  Patch table: SSDT  PegSsdt len=0x253E
3:868  0:000  0. [change GFX0 to IGPU]: pattern 47465830, bin not found / already patched!
3:868  0:000  1. [change HDAS to HDEF]: pattern 48444153, bin not found / already patched!
3:868  0:000  2. [change HECI to IMEI]: pattern 48454349, bin not found / already patched!
3:868  0:000  3. [change SAT0 to SATA]: pattern 53415430, bin not found / already patched!
3:868  0:000  4. [change Z170-A UART]: pattern 41D00501, bin not found / already patched!
3:868  0:000  5. [AMD/Nvidia GPU PM- Rename PEGP to GFX0]: pattern 50454750, patched at: [ (233) (24) (24) (401) (13) (32E) (13) (330) (13) ]
3:868  0:000  Patch table: SSDT  OEM_RTD3 len=0x24
3:868  0:000  0. [change GFX0 to IGPU]: pattern 47465830, the patch is too large!
3:868  0:000  1. [change HDAS to HDEF]: pattern 48444153, the patch is too large!
3:868  0:000  2. [change HECI to IMEI]: pattern 48454349, the patch is too large!
3:868  0:000  3. [change SAT0 to SATA]: pattern 53415430, the patch is too large!
3:868  0:000  4. [change Z170-A UART]: pattern 41D00501, the patch is too large!
3:868  0:000  5. [AMD/Nvidia GPU PM- Rename PEGP to GFX0]: pattern 50454750, the patch is too large!
3:868  0:000  Patch table: SSDT  xh_rvp08 len=0xB13
3:868  0:000  0. [change GFX0 to IGPU]: pattern 47465830, bin not found / already patched!
3:868  0:000  1. [change HDAS to HDEF]: pattern 48444153, bin not found / already patched!
3:868  0:000  2. [change HECI to IMEI]: pattern 48454349, bin not found / already patched!
3:868  0:000  3. [change SAT0 to SATA]: pattern 53415430, bin not found / already patched!
3:868  0:000  4. [change Z170-A UART]: pattern 41D00501, bin not found / already patched!
3:868  0:000  5. [AMD/Nvidia GPU PM- Rename PEGP to GFX0]: pattern 50454750, bin not found / already patched!
3:868  0:000  Patch table: SSDT  CpuSsdt len=0xEDE
3:868  0:000  0. [change GFX0 to IGPU]: pattern 47465830, bin not found / already patched!
3:868  0:000  1. [change HDAS to HDEF]: pattern 48444153, bin not found / already patched!
3:868  0:000  2. [change HECI to IMEI]: pattern 48454349, bin not found / already patched!
3:868  0:000  3. [change SAT0 to SATA]: pattern 53415430, bin not found / already patched!
3:868  0:000  4. [change Z170-A UART]: pattern 41D00501, bin not found / already patched!
3:868  0:000  5. [AMD/Nvidia GPU PM- Rename PEGP to GFX0]: pattern 50454750, bin not found / already patched!
3:868  0:000  Patch table: SSDT  sensrhub len=0x29F
3:868  0:000  0. [change GFX0 to IGPU]: pattern 47465830, bin not found / already patched!
3:868  0:000  1. [change HDAS to HDEF]: pattern 48444153, bin not found / already patched!
3:868  0:000  2. [change HECI to IMEI]: pattern 48454349, bin not found / already patched!
3:868  0:000  3. [change SAT0 to SATA]: pattern 53415430, bin not found / already patched!
3:868  0:000  4. [change Z170-A UART]: pattern 41D00501, bin not found / already patched!
3:868  0:000  5. [AMD/Nvidia GPU PM- Rename PEGP to GFX0]: pattern 50454750, bin not found / already patched!
3:868  0:000  Patch table: SSDT  PtidDevc len=0x3002
3:868  0:000  0. [change GFX0 to IGPU]: pattern 47465830, bin not found / already patched!
3:868  0:000  1. [change HDAS to HDEF]: pattern 48444153, bin not found / already patched!
3:868  0:000  2. [change HECI to IMEI]: pattern 48454349, bin not found / already patched!
3:868  0:000  3. [change SAT0 to SATA]: pattern 53415430, bin not found / already patched!
3:868  0:000  4. [change Z170-A UART]: pattern 41D00501, bin not found / already patched!
3:868  0:000  5. [AMD/Nvidia GPU PM- Rename PEGP to GFX0]: pattern 50454750, bin not found / already patched!
3:868  0:000  === [ ACPIPatchedAML ] ====================================
3:868  0:000  AutoMerge pass 2
3:868  0:000  Unsorted
3:868  0:000  Inserting SSDT-RX-560.aml from EFI\CLOVER\ACPI\patched: size=528 ... Success
3:869  0:000  CPUBase=0 and ApicCPUBase=1 ApicCPUNum=1
3:869  0:000  Cleanup XSDT: count=22, length=212
3:869  0:000  corrected XSDT count=21, length=204
3:869  0:000  === [ RestSetup macOS ] ===================================
3:869  0:000  EdidDiscovered size=128
3:869  0:000  --- Discovered EDID Table size:128
3:869  0:000  000  |  00  FF  FF  FF  FF  FF  FF  00  22  F0
3:869  0:000  010  |  41  29  01  01  01  01  07  15  01  03
3:869  0:000  020  |  80  3C  22  78  2A  F8  35  A4  56  4F
3:869  0:000  030  |  9D  27  11  50  54  A1  08  00  81  C0
3:869  0:000  040  |  81  80  95  00  B3  00  D1  C0  01  01
3:869  0:000  050  |  01  01  01  01  02  3A  80  18  71  38
3:869  0:000  060  |  2D  40  58  2C  45  00  56  51  21  00
3:869  0:000  070  |  00  1E  00  00  00  FD  00  32  4C  18
3:869  0:000  080  |  5E  11  00  0A  20  20  20  20  20  20
3:869  0:000  090  |  00  00  00  FC  00  48  50  20  32  37
3:869  0:000  100  |  31  31  0A  20  20  20  20  20  00  00
3:869  0:000  110  |  00  FF  00  43  4E  4B  31  30  37  30
3:869  0:000  120  |  59  31  4B  0A  20  20  01  DC
3:869  0:000  Unsupported ATI card! Device ID: [1002:67FF] Subsystem ID: [04BE1043]
3:869  0:000  search for brothers family
3:869  0:000  ...compatible config is not found
3:869  0:000   RCBA disabled; cannot use it
3:869  0:000   setting specified layout-id=1 (0x1)
3:869  0:000  stringlength = 2282
3:869  0:000  CurrentMode: Width=1920 Height=1080
3:869  0:000  Beginning FSInjection
FSInjectionInstall ...
- Our FSI_SIMPLE_FILE_SYSTEM_PROTOCOL installed on handle: 8B0FBA58
FSInjectionInstall ...
- Our FSI_SIMPLE_FILE_SYSTEM_PROTOCOL installed on handle: 8B0FBA58
3:878  0:008  Use origin smbios table type 1 guid.
3:892  0:014  Preparing kexts injection for arch=x86_64 from EFI\CLOVER\kexts\Other
3:893  0:001  SetScreenResolution: 1920x1080 - already set
3:893  0:000  Custom boot is disabled






CLOVER.zip

Link to comment
Share on other sites
 Share
Go to topic listing
×
×
  • Create New...
