Slice Posted September 30, 2021 Share Posted September 30, 2021 Download CloverV2-5140.zip, extract \CloverV2\EFI\CLOVER\drivers\off\UEFI\MemoryFix\Openruntime.efi 3 1 Link to comment Share on other sites More sharing options...
SavageAUS Posted September 30, 2021 Share Posted September 30, 2021 Download CloverV2-5140.zip, extract \CloverV2\EFI\CLOVER\drivers\off\UEFI\MemoryFix\Openruntime.efiSo if 5140 has the updated OpenRuntime then shouldn’t 5140-1 have the same OpenRuntime?Or do we have to have the 5140 OpenRuntime?Sent from my iPhone using Tapatalk 1 Link to comment Share on other sites More sharing options...
Matgen84 Posted September 30, 2021 Share Posted September 30, 2021 1 hour ago, SavageAUS said: So if 5140 has the updated OpenRuntime then shouldn’t 5140-1 have the same OpenRuntime? Or do we have to have the 5140 OpenRuntime? Sent from my iPhone using Tapatalk Right, it's the same. With OC-Integration 0.7.3 (Openruntime-v12.efi) 2 Link to comment Share on other sites More sharing options...
SavageAUS Posted September 30, 2021 Share Posted September 30, 2021 Do the new ExtendedFirmwareFeatures and ExtendedFirmwareFeaturesMask values need to be changed? Or are the defaults set to use for all?Sent from my iPhone using Tapatalk Link to comment Share on other sites More sharing options...
Jief_Machak Posted September 30, 2021 Share Posted September 30, 2021 Could check, everyone, if you boot on this : CloverX64-2021-09-30-13-35-43-83b9323-dirty-jief.zip that the memory information (in system information) is the same as with 5140.1 ? Thanks Link to comment Share on other sites More sharing options...
Slice Posted September 30, 2021 Share Posted September 30, 2021 28 minutes ago, SavageAUS said: Do the new ExtendedFirmwareFeatures and ExtendedFirmwareFeaturesMask values need to be changed? Or are the defaults set to use for all? Sent from my iPhone using Tapatalk I can't check every config so you can use default value and if not success then return to the question. Changed compared to what? To 5139 - YES, to 5140 - NO. Link to comment Share on other sites More sharing options...
Matgen84 Posted September 30, 2021 Share Posted September 30, 2021 (edited) 1 hour ago, Jief_Machak said: Could check, everyone, if you boot on this : CloverX64-2021-09-30-13-35-43-83b9323-dirty-jief.zip that the memory information (in system information) is the same as with 5140.1 ? Thanks Hi @Jief_Machak BLC don't want this new CloverX64 : Press any text * Hit any key to continue * After, I shortened his name: After Clover GUI > EXITBS START ++++++++++++++++++ and underscore 2021-09-30_12-01_CloverX64-83b9323-dirty-jief.efi.log Edited September 30, 2021 by Matgen84 1 Link to comment Share on other sites More sharing options...
Jief_Machak Posted September 30, 2021 Share Posted September 30, 2021 Just now, Matgen84 said: Hi @Jief_Machak BLC don't want this new CloverX64 : Press any text * Hit any key to continue * After, I shortened his name: After Clover GUI > EXITBS START ++++++++++++++++++ and underscore You might have a hard limit on efi file name ? If it's the case, I'm thinking a way to go around this. We'll try soon, I'll PM you. "EXITBS START ++++++++++++++++++ and underscore" : are you sure a FixUSBOwnership didn't came back to true ? Link to comment Share on other sites More sharing options...
Matgen84 Posted September 30, 2021 Share Posted September 30, 2021 (edited) 8 minutes ago, Jief_Machak said: You might have a hard limit on efi file name ? If it's the case, I'm thinking a way to go around this. We'll try soon, I'll PM you. "EXITBS START ++++++++++++++++++ and underscore" : are you sure a FixUSBOwnership didn't came back to true ? I'm very sure because I can boot successfully r5140 commit commit 83b9323 (build 29/09/2021 from my local repo). 2021-09-30_12-13_CLOVERX64-5140-83b9323.efi.log Edited September 30, 2021 by Matgen84 Link to comment Share on other sites More sharing options...
Slice Posted September 30, 2021 Share Posted September 30, 2021 6 hours ago, Jief_Machak said: Could check, everyone, if you boot on this : CloverX64-2021-09-30-13-35-43-83b9323-dirty-jief.zip that the memory information (in system information) is the same as with 5140.1 ? Thanks No start. See memory information in debug-log My Clover 0:170 0:000 Starting Clover revision: 5138 (master, commit f7add0788) on American Megatrends EFI 0:170 0:000 Build id: 20210901193835-f7add07-dirty 0:170 0:000 Build with: [Args: -D NO_GRUB_DRIVERS_EMBEDDED -D LESS_DEBUG -t GCC53 | --cmd-len=50000 -D NO_GRUB_DRIVERS_EMBEDDED -D LESS_DEBUG --conf=/Users/sergey/src/CloverBootloader/Conf -D USE_LOW_EBDA -a X64 -b RELEASE -t GCC53 -n 5 | OS: 12] 0:170 0:000 SimpleTextEx Status=Success 0:170 0:000 === [ Get Smbios ] ============================== 0:170 0:000 Type 16 Index = 0 0:170 0:000 Total Memory Slots Count = 4 0:170 0:000 Type 17 Index = 0 0:170 0:000 Ignoring insane frequency value 0MHz 0:170 0:000 Type 17 Index = 1 0:170 0:000 SmbiosTable.Type17->Speed = 2133MHz 0:170 0:000 SmbiosTable.Type17->Size = 4096MB 0:170 0:000 SmbiosTable.Type17->Bank/Device = BANK 1 ChannelA-DIMM1 0:170 0:000 SmbiosTable.Type17->Vendor = 0000 0:170 0:000 SmbiosTable.Type17->SerialNumber = 00000000 0:170 0:000 SmbiosTable.Type17->PartNumber = 0:170 0:000 Type 17 Index = 2 0:170 0:000 Ignoring insane frequency value 0MHz 0:170 0:000 Type 17 Index = 3 0:170 0:000 SmbiosTable.Type17->Speed = 2133MHz 0:170 0:000 SmbiosTable.Type17->Size = 4096MB 0:170 0:000 SmbiosTable.Type17->Bank/Device = BANK 3 ChannelB-DIMM1 0:170 0:000 SmbiosTable.Type17->Vendor = 0000 0:170 0:000 SmbiosTable.Type17->SerialNumber = 00000000 0:170 0:000 SmbiosTable.Type17->PartNumber = 0:170 0:000 Boot status=0 0:170 0:000 Running on: 'Z170X-UD5 TH' with board 'Z170X-UD5 TH-CF' 0:170 0:000 === [ GetCPUProperties ] ======================== Your version === [ Starting Clover ] ========================= Now is 30.09.2021, 16:38:09 (GMT) Starting Clover revision: 5140 (master, commit 83b93234b) on American Megatrends EFI Build id: 2021-09-30-13-35-43-83b9323-dirty-jief Build with: [jief] SimpleTextEx Status=Success === [ Get Smbios ] ============================== Type 16 Index = 0 Total Memory Slots Count = 4 SmbiosTable.Type17->Speed = 2133MHz SmbiosTable.Type17->Size = 0MB SmbiosTable.Type17->Bank/Device = BANK 1 ChannelA-DIMM1 SmbiosTable.Type17->Vendor = 0000 SmbiosTable.Type17->SerialNumber = 00000000 SmbiosTable.Type17->PartNumber = SmbiosTable.Type17->Speed = 2133MHz SmbiosTable.Type17->Size = 0MB SmbiosTable.Type17->Bank/Device = BANK 3 ChannelB-DIMM1 SmbiosTable.Type17->Vendor = 0000 SmbiosTable.Type17->SerialNumber = 00000000 SmbiosTable.Type17->PartNumber = Boot status=0 Running on: 'Z170X-UD5 TH' with board 'Z170X-UD5 TH-CF' = All zeros. Link to comment Share on other sites More sharing options...
Jief_Machak Posted September 30, 2021 Share Posted September 30, 2021 I think I may have found it. How about this one CloverX64-2021-10-01-01-27-26-83b9323-dirty-jief.zip Link to comment Share on other sites More sharing options...
PG7 Posted September 30, 2021 Share Posted September 30, 2021 On 9/30/2021 at 1:05 AM, Sherlocks said: can you check nvram -p in terminal? Spoiler Link to comment Share on other sites More sharing options...
Sherlocks Posted September 30, 2021 Share Posted September 30, 2021 Spoiler your backlight level is max. did you install nvram script for legacy? seems latest clover broken stored emulated nvram. i tested it before.before reboot, decrese low brightness then check backlight level after bootSent from my SM-N960N using Tapatalk Link to comment Share on other sites More sharing options...
yapan4 Posted October 1, 2021 Share Posted October 1, 2021 8 hours ago, Jief_Machak said: I think I may have found it. How about this one CloverX64-2021-10-01-01-27-26-83b9323-dirty-jief.zip Do not boot too yapan4_logs_1001.zip Link to comment Share on other sites More sharing options...
maclinuxG4 Posted October 1, 2021 Share Posted October 1, 2021 @jief: i propose that you reverse back before TMSC change, and set a label, then continue to integration of OC by the way, bad news i get this when i try to compile CHECK XCODE] - Building GCC 10.2.0 toolchain for x64 - to /Users/ericcoin/Desktop/CloverBootloader/toolchain/cross/bin/x86_64-clover-linux-gnu Running on Mac OS X 10.14, with x86_64 architecture. Using Xcode SDK: /Applications/Xcode.app/Contents/Developer/Platforms/MacOSX.platform/Developer/SDKs/MacOSX.sdk Status: gmp-6.2.0 not found. % Total % Received % Xferd Average Speed Time Time Time Current Dload Upload Total Spent Left Speed 0 0 0 0 0 0 0 0 --:--:-- --:--:-- --:--:-- 0 curl: (60) SSL certificate problem: certificate has expired More details here: https://curl.haxx.se/docs/sslcerts.html curl performs SSL certificate verification by default, using a "bundle" of Certificate Authority (CA) public keys (CA certs). If the default bundle file isn't adequate, you can specify an alternate file using the --cacert option. If this HTTPS server uses a certificate signed by a CA represented in the bundle, the certificate verification probably failed due to a problem with the certificate (it might be expired, or the name might not match the domain name in the URL). If you'd like to turn off curl's verification of the certificate, use the -k (or --insecure) option. HTTPS-proxy has similar options --proxy-cacert and --proxy-insecure. plz check. 1 Link to comment Share on other sites More sharing options...
Jief_Machak Posted October 1, 2021 Share Posted October 1, 2021 20 minutes ago, yapan4 said: Do not boot too yapan4_logs_1001.zip 30.17 kB · 0 downloads Now the memory seems to be read well, but maybe there is a problem at patching. I'm surprised that a problem in smbios memory prevent the boot. I didn't know that. @yapan4 Could you send me a log of a successful boot with 5140.1 ? 1 Link to comment Share on other sites More sharing options...
Jief_Machak Posted October 1, 2021 Share Posted October 1, 2021 Thanks @Slice for the first bug. Dual log was very helpful. Thanks @yapan4, I found something else. How about this one : CloverX64-2021-10-01-11-18-28-83b9323-dirty-jief.zip ? 1 Link to comment Share on other sites More sharing options...
Matgen84 Posted October 1, 2021 Share Posted October 1, 2021 1 hour ago, Jief_Machak said: Thanks @Slice for the first bug. Dual log was very helpful. Thanks @yapan4, I found something else. How about this one : CloverX64-2021-10-01-11-18-28-83b9323-dirty-jief.zip ? @Jief_Machak This CloverX64 can boot Monterey. There is something wrong with memory detection: 2132MHZ instead of 3000MHZ Now SmbiosTable.Type17->Vendor = Corsair SmbiosTable.Type17->SerialNumber = 00000000 SmbiosTable.Type17->PartNumber = CMK16GX4M2B3000C15 SMBIOS Type 17 Index = 2 => 2 1: BANK 0 DIMM1 2132MHz 8192MB(Ext:0MB) Table index 3:!trustSMBIOS !gRAM.SMBIOS.doesSlotForIndexExist(SMBIOSIndex) SPD data in use: SmbiosTable.Type17->Vendor = Corsair SmbiosTable.Type17->SerialNumber = 00000000 SmbiosTable.Type17->PartNumber = CMK16GX4M2B3000C15 SMBIOS Type 17 Index = 3 => 3 3: BANK 1 DIMM1 2132MHz 8192MB(Ext:0MB) mTotalSystemMemory = 16384 Before r5140 (master, commit 83b93234b) Type 16 Index = 0 0:102 0:000 Total Memory Slots Count = 4 0:102 0:000 Type 17 Index = 0 0:102 0:000 Ignoring insane frequency value 0MHz 0:102 0:000 Type 17 Index = 1 0:102 0:000 SmbiosTable.Type17->Speed = 3000MHz 0:102 0:000 SmbiosTable.Type17->Size = 8192MB 0:102 0:000 SmbiosTable.Type17->Bank/Device = BANK 1 ChannelA-DIMM1 0:102 0:000 SmbiosTable.Type17->Vendor = 029E 0:102 0:000 SmbiosTable.Type17->SerialNumber = 00000000 0:102 0:000 SmbiosTable.Type17->PartNumber = CMK16GX4M2B3000C15 0:102 0:000 Type 17 Index = 2 0:102 0:000 Ignoring insane frequency value 0MHz 0:102 0:000 Type 17 Index = 3 0:102 0:000 SmbiosTable.Type17->Speed = 3000MHz 0:102 0:000 SmbiosTable.Type17->Size = 8192MB 0:102 0:000 SmbiosTable.Type17->Bank/Device = BANK 3 ChannelB-DIMM1 0:102 0:000 SmbiosTable.Type17->Vendor = 029E 0:102 0:000 SmbiosTable.Type17->SerialNumber = 00000000 0:102 0:000 SmbiosTable.Type17->PartNumber = CMK16GX4M2B3000C15 0:102 0:000 Boot status=0 2021-10-01_09-41_CloverX64-2021-10-01-83b9323-dirty-jief.efi.log 2 Link to comment Share on other sites More sharing options...
yapan4 Posted October 1, 2021 Share Posted October 1, 2021 Sorry, @Jief_Machak, i can test before- after- work only:-( 2 Link to comment Share on other sites More sharing options...
SavageAUS Posted October 1, 2021 Share Posted October 1, 2021 I can no longer boot arch Linux with clover 5140.1. Booting from uefi boot picker works. Was working with 5138 and 5139. Sent from my iPhone using Tapatalk 1 1 Link to comment Share on other sites More sharing options...
Slice Posted October 1, 2021 Share Posted October 1, 2021 7 hours ago, Jief_Machak said: Thanks @Slice for the first bug. Dual log was very helpful. Thanks @yapan4, I found something else. How about this one : CloverX64-2021-10-01-11-18-28-83b9323-dirty-jief.zip ? Successfully booted by the version. There is non-significant memory difference with stock 5140 2133 is better then 2132 🤪 3 Link to comment Share on other sites More sharing options...
yapan4 Posted October 1, 2021 Share Posted October 1, 2021 ...and my two cents yapan4_1001_2.zip Link to comment Share on other sites More sharing options...
Slice Posted October 1, 2021 Share Posted October 1, 2021 9 hours ago, maclinuxG4 said: @jief: i propose that you reverse back before TMSC change, and set a label, then continue to integration of OC by the way, bad news i get this when i try to compile CHECK XCODE] - Building GCC 10.2.0 toolchain for x64 - to /Users/ericcoin/Desktop/CloverBootloader/toolchain/cross/bin/x86_64-clover-linux-gnu Running on Mac OS X 10.14, with x86_64 architecture. Using Xcode SDK: /Applications/Xcode.app/Contents/Developer/Platforms/MacOSX.platform/Developer/SDKs/MacOSX.sdk Status: gmp-6.2.0 not found. % Total % Received % Xferd Average Speed Time Time Time Current Dload Upload Total Spent Left Speed 0 0 0 0 0 0 0 0 --:--:-- --:--:-- --:--:-- 0 curl: (60) SSL certificate problem: certificate has expired More details here: https://curl.haxx.se/docs/sslcerts.html curl performs SSL certificate verification by default, using a "bundle" of Certificate Authority (CA) public keys (CA certs). If the default bundle file isn't adequate, you can specify an alternate file using the --cacert option. If this HTTPS server uses a certificate signed by a CA represented in the bundle, the certificate verification probably failed due to a problem with the certificate (it might be expired, or the name might not match the domain name in the URL). If you'd like to turn off curl's verification of the certificate, use the -k (or --insecure) option. HTTPS-proxy has similar options --proxy-cacert and --proxy-insecure. plz check. I don't know what is your problem. Certificate for curl? I downloaded this without a problem sergey@iMac2017 src % curl -f -o download.tmp --remote-name https://ftp.gnu.org/gnu/gmp/${GMP_VERSION}.tar.xz % Total % Received % Xferd Average Speed Time Time Time Current Dload Upload Total Spent Left Speed 100 1965k 100 1965k 0 0 1362k 0 0:00:01 0:00:01 --:--:-- 1368k 1 1 Link to comment Share on other sites More sharing options...
Matgen84 Posted October 1, 2021 Share Posted October 1, 2021 (edited) @Jief_Machak In my Z390 BIOS, XMP Profile is activated (2133MHZ---> 3000MHZ). Not in config.plist: <key>XMPDetection</key> <integer>-1</integer> With r5140 (master, commit 83b93234b) from my local repo: Clover detects 3000MHZ (BIOS Information). CLOVERX64-2021-10-01-11-18-28-83b93234b-dirty-jief: displays only 2132MHZ as I said in my previous post. @Jief_Machak EDIT: in both case <key>Trust</key> <true/> Edited October 1, 2021 by Matgen84 Link to comment Share on other sites More sharing options...
Slice Posted October 1, 2021 Share Posted October 1, 2021 I made one more experiment: with stock Clover 5140.1 I set in config.plist SMBIOS->Trust=NO and got new System Information Link to comment Share on other sites More sharing options...
