zfire89 Posted September 24, 2005 Share Posted September 24, 2005 It didnt work for both my mx440 and mx4000 Link to comment Share on other sites More sharing options...
kaldare Posted September 25, 2005 Share Posted September 25, 2005 I have a working AGP environment now thanks to all the help from you!!! Don't see any difference for now but I assume it's important to see AGP listed as I know I couldn't get my card installed correctly under windows when the Via Chipset AGP to PCI was not installed. So hopefully this will help me with futher driver versions for the NVidia cards. I have the exact same AGP Bridge as you do and I can't get it to work. Can you show me exactly what you have in info.plist? Link to comment Share on other sites More sharing options...
trexplorer Posted September 25, 2005 Share Posted September 25, 2005 I was able to load the driver after changing the Vendor ID to 0x014110DE for my MSI 6600 PCIE card. It is now recognized as a GForce 6600 PCI card under OS X System Profiler. QE and CoreImage are still unsupported and I don't see much of a speed diffirence in video or any other functions. But it is an important step in the right direction - keep up the great work. Cheers ... Link to comment Share on other sites More sharing options...
jordanvanbergen Posted September 25, 2005 Share Posted September 25, 2005 I have the exact same AGP Bridge as you do and I can't get it to work. Can you show me exactly what you have in info.plist? I'm not copying everything, only the AGP key as it worked for me: <key>AppleI386AGP</key> <dict> <key>CFBundleIdentifier</key> <string>com.apple.driver.AppleI386PCI</string> <key>IOAGPFlags</key> <integer>65537</integer> <key>IOClass</key> <string>AppleI386AGP</string> <key>IONameMatch</key> <array> <string>pci1106,b188</string> </array> <key>IOProbeScore</key> <integer>80000</integer> <key>IOProviderClass</key> <string>IOPCIDevice</string> </dict> That's the one. Clear your kext cache en reboot and see if it works. Regards Jordan Link to comment Share on other sites More sharing options...
reedog117 Posted September 26, 2005 Author Share Posted September 26, 2005 If you're seeing errors such as: extension ".........IPGraphicsFamily" cannot be found Can't determine dependencies for com.free.driver.NVIDIA Couldn't alloc class "NVIDIA" I fixed it by changing something in the extension (IOGraphicsFamily.kext in this example) Info.plist Specifically, I changed the OSBundleRequired setting so it looked like the one below. <key>OSBundleRequired</key> <string>Root</string> I then made sure to delete Extensions.mkext and Extensions.kextcache from /System/Library before restarting. I think the problem was that the system would try loading NVidia.kext before those other libraries, but don't ask me; I'm not an OSX expert by any means. Link to comment Share on other sites More sharing options...
CyberTron Posted September 26, 2005 Share Posted September 26, 2005 If you're seeing errors such as: extension ".........IPGraphicsFamily" cannot be found Can't determine dependencies for com.free.driver.NVIDIA Couldn't alloc class "NVIDIA" I fixed it by changing something in the extension (IOGraphicsFamily.kext in this example) Info.plist Specifically, I changed the OSBundleRequired setting so it looked like the one below. <key>OSBundleRequired</key> <string>Root</string> I then made sure to delete Extensions.mkext and Extensions.kextcache from /System/Library before restarting. I think the problem was that the system would try loading NVidia.kext before those other libraries, but don't ask me; I'm not an OSX expert by any means. Thanx, that did it for me Now I have sound, graphics , agp , wireless and ordnary ethernet up and running Link to comment Share on other sites More sharing options...
colby Posted September 26, 2005 Share Posted September 26, 2005 Well, it's working well here with a 6200 (turbocache) using the PCIe slot on a MSI neo4 platinum. I just had to add the ID for my PCIe slot to the applei386pci.kext (the string for this board is: pci10de,5c), and add the string for my vidcard (0x016110de&0xfff8ffff) to the NVidia kext. I honestly am noticing a slight improvement in the speed and responsiveness of the gui. It's very subtle, and may just be wishfull thinking, but it really seems to be there. Link to comment Share on other sites More sharing options...
Kevin Sherman Posted September 26, 2005 Share Posted September 26, 2005 I KNOW this will be a dump question... (BTW, I was able to get the SysInfo to detect that I had a 6600GT with no problem, though nothing really changed outside of a name reckognition) but I noticed that there are several GeForce.kext's and ATIRadeon.kext's that say they are drivers... cant any of those Info.plist's be modified with a specific vendo ID to work? Link to comment Share on other sites More sharing options...
vince29 Posted September 26, 2005 Share Posted September 26, 2005 thmacvidia website seems to be down, is that serious or just a server crash ? BTW, Kevin, the Nvidia drivers provided with osx86 are incomplete, NVDAResman.kext can't load due to missing functions. As for the ATI drivers, I haven't read much about it since I don't have any ATI GPU, but it seems that they work with a lot of problems with very few cards. Link to comment Share on other sites More sharing options...
TerraPhantm Posted September 26, 2005 Share Posted September 26, 2005 Detects my 7800GTX, but like everyone else QE and CI are still not enabled. Chipset Model: GeForce 7800 GTX Type: VGA-Compatible Controller Bus: PCI Vendor: nVIDIA (0x10de) Device ID: 0x0091 Revision ID: 0x00a1 Displays: Display: Resolution: 1024 x 768 Depth: 32-bit Color Core Image: Not Supported Main Display: Yes Mirror: Off Online: Yes Quartz Extreme: Not Supported Link to comment Share on other sites More sharing options...
reedog117 Posted September 27, 2005 Author Share Posted September 27, 2005 If you're seeing errors such as: extension ".........IPGraphicsFamily" cannot be found Can't determine dependencies for com.free.driver.NVIDIA Couldn't alloc class "NVIDIA" I fixed it by changing something in the extension (IOGraphicsFamily.kext in this example) Info.plist Specifically, I changed the OSBundleRequired setting so it looked like the one below. <key>OSBundleRequired</key> <string>Root</string> I then made sure to delete Extensions.mkext and Extensions.kextcache from /System/Library before restarting. I think the problem was that the system would try loading NVidia.kext before those other libraries, but don't ask me; I'm not an OSX expert by any means. Okay... now a couple of reboots later it stopped loading again. argh!! I think this is some sort of extension caching problem. Does anyone know how to fix this?? Link to comment Share on other sites More sharing options...
g0nned Posted September 28, 2005 Share Posted September 28, 2005 I want to try adding the agp bridge id to the applei386 kext to see if the card is recognized as agp but i can't figure out the freaking id, anyone knows the id of the nforce3 250 Agp controller ? I am on same situation Myzar K8N Neo2 Platinum NF3 250 Let me know if u got something. tks Link to comment Share on other sites More sharing options...
Chebyshev Posted September 28, 2005 Share Posted September 28, 2005 I am on same situation Myzar K8N Neo2 Platinum NF3 250 Let me know if u got something. tks Vendor ID is 10de and the device id is 00e2. So you'd put in pci10de,e2. This worked for me. Link to comment Share on other sites More sharing options...
g0nned Posted September 28, 2005 Share Posted September 28, 2005 Vendor ID is 10de and the device id is 00e2. So you'd put in pci10de,e2. This worked for me. Tks for help i will try Link to comment Share on other sites More sharing options...
nek Posted September 29, 2005 Share Posted September 29, 2005 Thanks for all the replies in that topic I finally got this: Chipset Model: GeForce FX 5600SE Type: VGA-Compatible Controller Bus: AGP Vendor: nVIDIA (0x10de) Device ID: 0x0314 Revision ID: 0x00a1 Displays: Display: Resolution: 1024 x 768 Depth: 32-bit Color Core Image: Not Supported Main Display: Yes Mirror: Off Online: Yes Quartz Extreme: Not Supported I think that's as far as it gets on the nvidia cards right? I still can't get the refresh to go to 85 :/ I can't understand the boot method for fixing VESA3 yet. Any other method for refresh rate? thanks Link to comment Share on other sites More sharing options...
vigilante Posted September 30, 2005 Share Posted September 30, 2005 erm...does this mean you guys can run dual display? Considering how it's sorta a driver.. Link to comment Share on other sites More sharing options...
Españoleitor Posted September 30, 2005 Share Posted September 30, 2005 Chipset Model: GeForce 3 Ti 200 (128MB) Type: VGA-Compatible Controller Bus: AGP Vendor: nVIDIA (0x10de) Device ID: 0x0314 Revision ID: 0x00a1 Displays: Display: Resolution: 1024 x 768 Depth: 32-bit Color Core Image: Not Supported Main Display: Yes Mirror: Off Online: Yes Quartz Extreme: Not Supported I need 1280*1024*32@75 but i have only 1024*768*32@60 Link to comment Share on other sites More sharing options...
Kevin Sherman Posted September 30, 2005 Share Posted September 30, 2005 at Darwin boot-up, type "Graphics Mode"="1280x1024x32" I dont *thing* your card is Vesa 3.0 compatible, so you well not be ablt to set a refresh rate. Link to comment Share on other sites More sharing options...
Españoleitor Posted September 30, 2005 Share Posted September 30, 2005 Yes, kevin my card is vesa 3.0 compatible, but If I set the graphics mode on the startup, only can see the screen in black and white :S Link to comment Share on other sites More sharing options...
nek Posted September 30, 2005 Share Posted September 30, 2005 did u try to type ?video at boot to see what resolutions u can use? you can also try the VESA boot fix posted here: http://forum.osx86project.org/index.php?s=...indpost&p=18759 make sure you have the darwin iso or you wont be able to use the startupfiletool command like me lol Link to comment Share on other sites More sharing options...
Españoleitor Posted October 3, 2005 Share Posted October 3, 2005 Tes I try, when I type ?video he said that I can use 1280x1024x32@75 I try the VESA fix, but It´s very hard for me Link to comment Share on other sites More sharing options...
Roland77 Posted October 3, 2005 Share Posted October 3, 2005 I'm confused... I already have the NVidia.kext running, in system profiler my card is detected correctly; 6600GT pci-e BUT It still shows the bus: PCI Now I understand I have to use the AppleI386 kext from the other topic, I know I have to edit the Info.plist inthere, np with all that. I just dont know what Vendor / Device ID to add in there .... I have a nForce4 SLI motherboard from Asus, so there is no PCI-AGP bridge in there. If I understand correctly, I will need to edit it, but which device do I take if I have pci-e and no AGP ?? And if I finally get the right ID, will it show as 6600GT on AGP, even if its on PCI-express ?? help me out here, I'm kinda lost Link to comment Share on other sites More sharing options...
macgirl Posted October 3, 2005 Share Posted October 3, 2005 I'm confused... I already have the NVidia.kext running, in system profiler my card is detected correctly; 6600GT pci-e BUT It still shows the bus: PCI Now I understand I have to use the AppleI386 kext from the other topic, I know I have to edit the Info.plist inthere, np with all that. I just dont know what Vendor / Device ID to add in there .... I have a nForce4 SLI motherboard from Asus, so there is no PCI-AGP bridge in there. If I understand correctly, I will need to edit it, but which device do I take if I have pci-e and no AGP ?? And if I finally get the right ID, will it show as 6600GT on AGP, even if its on PCI-express ?? help me out here, I'm kinda lost Even if you edit the AppleI386 kext it wont show AGP or PCI-E, because at the moment there is no PCI-E cards "supported" by Mac OS X, even the Intel GMA 900 is recognized as PCI. If you read my post http://forum.osx86project.org/index.php?sh...indpost&p=18543 it says the kext can be loaded but no difference in the System Profiler. If you want to add the Device ID of your PCI-E slot look at Windows for PCI2PCI bridge. My Motheboard has 4 PCI-E slots, one of them for the VideoCard Here is a pic of Device Manager in Windows, I select View Devices by connection: Link to comment Share on other sites More sharing options...
macintox Posted October 3, 2005 Share Posted October 3, 2005 The Nvidia.kext loads fine for me (without modifications in the info.plists). May be because my mainboard is Intel, I think. The refresh rate fix from Trac works ok too, and then I changed the boot to try to fix the problem of the black&white colors above 1024x768. I discovered that some GeForces doesnt support 32bit VESA modes above 1024x768, only 16 bit modes, but darwin boot cannot detect these modes because it only works with 16 bit modes like 5 / 5 / 5 bits (5 bits for each basic colors) and Geforce uses the 5 / 6 / 5 (6 bits for green) model instead. So, even patching the boot file to detect 5 / 6 / 5, the display doesnt show the colors correctly. Now, instead of a black&white desktop, I have colors with a moiré (pattern effect). The display settings shows "1280x1024 thousands of colors", but its a almost unusable mode. As 1024x768@85 is now aceptable for me, I'll stay waiting for the people at macvidia for a driver version that supports more higher modes. Link to comment Share on other sites More sharing options...
sam_the_killer Posted October 3, 2005 Share Posted October 3, 2005 pls help me setting up GeForce FX5200 AGP(256 MB) card on my AMD Athlon 64 2800+ ASUS K8N board by providing me the required vendor id, device id and revision id. Link to comment Share on other sites More sharing options...
