Slice Posted January 4, 2009 Share Posted January 4, 2009 I have full success with AppleHDA 1.4.0 but no any achievements with versions 1.5.6 - 1.6.2. I think the topic is not full about the patching. Link to comment Share on other sites More sharing options...
epborden Posted January 4, 2009 Share Posted January 4, 2009 Every time I create my kext and put it in extensions folder I get this message The system extension "/System/Library/Extensions/nameofextensionhere.kext/Contents/Plugins/HDAEnabler.kext" was installed improperly and cannot be used. Please try reinstalling it or contact the product's vendor for an update. How can I fix this problem? Link to comment Share on other sites More sharing options...
Slice Posted January 5, 2009 Share Posted January 5, 2009 Every time I create my kext and put it in extensions folder I get this message The system extension "/System/Library/Extensions/nameofextensionhere.kext/Contents/Plugins/HDAEnabler.kext" was installed improperly and cannot be used. Please try reinstalling it or contact the product's vendor for an update. How can I fix this problem? lol Link to comment Share on other sites More sharing options...
Genex Posted January 5, 2009 Share Posted January 5, 2009 good one ! Link to comment Share on other sites More sharing options...
lwy7814 Posted January 7, 2009 Share Posted January 7, 2009 I got my ALC883 work with ICH7. But from system log it shows something wrong as below: Jan 7 12:07:29 localhost kernel[0]: Sound assertion "0 != result" failed in "/SourceCache/AppleHDA/AppleHDA-157.1.24/AppleHDA/AppleHDAWidgetALC262.cpp" at line 73 goto Exit Jan 7 12:07:29 localhost kernel[0]: Sound assertion "0 != result" failed in "/SourceCache/AppleHDA/AppleHDA-157.1.24/AppleHDA/AppleHDAWidget.cpp" at line 1341 goto handler every 5 seconds it shows the same info. Is there anybody can fix this problem. My laptop is Acer5580 with 10.5.5. Link to comment Share on other sites More sharing options...
alborto Posted January 8, 2009 Share Posted January 8, 2009 Hello guys, any news about adi1988b? Thanks all. Link to comment Share on other sites More sharing options...
gorg Posted January 9, 2009 Share Posted January 9, 2009 Hello guys, any news about adi1988b?Thanks all. Used to work on my Asus P5E motherboard until 10.5.5. Not anymore since I updated to 10.5.6 Link to comment Share on other sites More sharing options...
Monkey_@@ Posted January 15, 2009 Share Posted January 15, 2009 Does anyone got the sound working after sleep wake-up??? Link to comment Share on other sites More sharing options...
Master Chief Posted January 25, 2009 Share Posted January 25, 2009 Does anyone got the sound working after sleep wake-up??? I did a quick sleep/wake up cycle to verify sound output in iTunes, and system sounds also still work - though my USB keyboard numlock state is gone (what the beep)! LOL I wish that I had checked this thread earlier, but I probably didn't because of this "10.5.2 and above". Well maybe this is better. After all now I know how things work - it took some time to wade through the HDA specifications, but whatever. Time to write a PHP script to convert Linux codecs. Link to comment Share on other sites More sharing options...
Toasted Logic Posted January 28, 2009 Share Posted January 28, 2009 MadTux, Thanks for such a great guide! I have been able to make OSX recognize my inputs/outputs by following your guide, however I couldn't get anything but random clicks and bleeps out of the speakers. Nothing else came close to working though. I have tried with and without my codec verbs, but can't get it working. I am having a real hard time reading my codec dump. The connections aren't showing up with an asterisk (*) so I have no idea what node numbers to try. Do you think you can read my codec dump if you get a spare 10 minutes? I really need help with my node numbers, and it would be much appreciated. Everyone with an ALC663 sound chip will be in your debt. PS - For some reason, when I last tried this guide my HDAEnabler.kext was causing OSX to boot into a black screen. It doesn't panic, but it's unusable. I have to boot into safe mode, delete HDAEnabler and reboot to get my desktop back. Thoughts anyone? M70VM_ALC663.txt Link to comment Share on other sites More sharing options...
Sam2x Posted January 31, 2009 Share Posted January 31, 2009 Plz Help i have HP 6710B with AD1981 i'm in mac osx 10.5.6 codec0_dump.txt InitVerbs.txt Link to comment Share on other sites More sharing options...
Xess666 Posted February 4, 2009 Share Posted February 4, 2009 Hi I try to patch AppleHDA.kext for ad1986a but nothing happen in sound preference. and in System Profiler have just load AppleHda & AppleHDAController. So I look in system log found some error about my AppleHDA.kext Feb 4 19:57:30 localhost kernel[0]: Sound assertion "32 < fNumProcessingCoefficients" failed in "/SourceCache/AppleHDA/AppleHDA-157.1.24/AppleHDA/AppleHDAWidget.cpp" at line 268 goto ExitFeb 4 19:57:30 localhost kernel[0]: Sound assertion "0 != result" failed in "/SourceCache/AppleHDA/AppleHDA-157.1.24/AppleHDA/AppleHDAFunctionGroup.cpp" at line 114 goto Exit Feb 4 19:57:30 localhost kernel[0]: Sound assertion "0 != err" failed in "/SourceCache/AppleHDA/AppleHDA-157.1.24/AppleHDA/AppleHDACodecGeneric.cpp" at line 154 goto ExitError Feb 4 20:03:39 Hackbook-Pro AppleHDAPatcherv1.20[331]: NSDocumentController Info.plist warning: The values of CFBundleTypeRole entries must be 'Editor', 'Viewer', 'None', or 'Shell'. What should i do? Thank Link to comment Share on other sites More sharing options...
iceraven Posted February 8, 2009 Share Posted February 8, 2009 Hi people! Can anyone help me? I've got Asus F3T Amd Turion laptop. Leo4All 4.1 installed my audio chipset is MCP51 HDA. Codec: Realtek ALC660 Address: 0 Vendor Id: 0x10ec0861 Subsystem Id: 0x10430000 Revision Id: 0x100340 I've tried several kext's 861-vd, 660, 660-vd, 861 (by Taruga) Only 861 is working, but the sound comes out only when mouse is moving. Other versions either fo not play sound or even do not show as a audio device. Can somebody help with this? Thanks! dump.txt Link to comment Share on other sites More sharing options...
barmOSx Posted February 19, 2009 Share Posted February 19, 2009 Hi MadTux and hi guys, can you help me with audio card of my notebook? In Everest is recognized ALC660 but MadTux's driver for alc660 don't work for me. In Ubuntu 8.10 the audio card works correctly but it's recognized ALC861. The AppleHDA patcher by taruga with my codec dump don't solving my problem. Can you help me, please? I attach my code dump from linux. Thank you so much. Excuse me for my bd english. BarmOSX codec.txt Link to comment Share on other sites More sharing options...
gary88 Posted February 19, 2009 Share Posted February 19, 2009 Hi to all, did a new try on adi ad 2000b this time i began with the original 10.5.6 applehda.kext I applied all codec ID´s I inserted pinconfig verbs (they are equal to ad 1988b) I changed codec ID 8B19D411 (AD 1988) to 9B98D411 (AD 2000b) in apple hda unix file installed hda enabler so following happens: I have the devices in the system profiler:Intel High Definition Audio: Device ID: 0x10438311 Audio ID: 12 Available Devices: Headphone: Connection: 1/8 inch Jack Line Out: Connection: 1/8 inch Jack S/P-DIF Out: Connection: Optical Microphone: Connection: 1/8 inch Jack but no sound, no ports in the systempreferences from console I got following message: 2/19/09 1:35:43 PM kernel Sound assertion "0 != buildPathSets ( pathGroupArray )" failed in "/SourceCache/AppleHDA/AppleHDA-162.1.37/Apple/HDAd/rAvppl/ HeHDyApAEpnigci.nce:.2c3p4p " aHt olsitn eA 196P IgCo t op hEyx i0xFtE 2/19/09 1:35:43 PM kernel Sound assertion "0 != result" failed in "/SourceCache/AppleHDA/AppleHDA-162.1.37/AppleHDA/AppleHDADriver.cpp" at line 1366 goto Exit 2/19/09 1:35:43 PM kernel Sound assertion "0 != createAudioEngines ( fPathMap_aDriverInstance )" failed in "/SourceCache/AppleHDA/AppleHDA-162.1.37/AppleHDA/AppleHDADriver.cpp" at line 127 goto Exit 2/19/09 1:35:43 PM kernel Sound assertion "!result" failed in "/SourceCache/AppleHDA/AppleHDA-162.1.37/AppleHDA/AppleHDAPath.cpp" at line 527 goto handler 2/19/09 1:35:43 PM kernel Sound assertion "!path->initPathFromXML ( path_aArrayOfNodeIdDictionaries, functionGroup )" failed in "/SourceCache/AppleHDA/AppleHDA-162.1.37/AppleHDA/AppleHDAPathSet.cpp" at line 74 goto Exit 2/19/09 1:35:43 PM kernel Sound assertion "!pathSet->initPathSetFromXML ( pathSet_aArrayOfPathArrays, fHDAFunctionGroup )" failed in "/SourceCache/AppleHDA/AppleHDA-162.1.37/AppleHDA/AppleHDAEngine.cpp" at line 789 goto Exit 2/19/09 1:35:43 PM kernel Sound assertion "0 != result" failed in "/SourceCache/AppleHDA/AppleHDA-162.1.37/AppleHDA/AppleHDAEngine.cpp" at line 7039 goto Exit 2/19/09 1:35:43 PM kernel Sound assertion "0 != buildPathSets ( pathGroupArray )" failed in "/SourceCache/AppleHDA/AppleHDA-162.1.37/AppleHDA/AppleHDAEngine.cpp" at line 196 goto Exit 2/19/09 1:35:43 PM kernel Sound assertion "0 != result" failed in "/SourceCache/AppleHDA/AppleHDA-162.1.37/AppleHDA/AppleHDADriver.cpp" at line 1366 goto Exit 2/19/09 1:35:43 PM kernel Sound assertion "0 != createAudioEngines ( fPathMap_aDriverInstance )" failed in "/SourceCache/AppleHDA/AppleHDA-162.1.37/AppleHDA/AppleHDADriver.cpp" at line 127 goto Exit Does anyboda knows what to do ? Thanks ! Greetings ! Gary Link to comment Share on other sites More sharing options...
deniskacool Posted February 22, 2009 Share Posted February 22, 2009 Just wonder if anyone had success of getting Sigmatel 7661 to work on leoforall 10.5.6? Driving me nuts... Been trying to get it going for about a month now and no success... I am trying to get it going on vaio sz330p. Got everything else working, Just the sound Link to comment Share on other sites More sharing options...
undo_undo Posted February 25, 2009 Share Posted February 25, 2009 If I have Pinconfig from Vista (byte flipped), do I still need linux codec dump for my Alc888? Link to comment Share on other sites More sharing options...
psychotropic Posted March 6, 2009 Share Posted March 6, 2009 I got a fun little challenge here. I have an ALC272 on a Qosmio X305-Q701. This laptop has 4 speakers and a built-in subwoofer. I've been beating my head on this for weeks now. Enclosed is my linux dump and byte-flipped pinconfig. I'm also including a linux dump with all the hexes converted to decimal. My device ID is 0x10EC0272 which is 283902578 in decimal and I have an Intel HDA Controller, 0x293E8086 So far I have patched the AppleHDA in the MacOS folder and placed my decimals where they need to be. I have patched my AppleHDA with both 7202EC10 and installed it, no go. I then repatched it using 10EC0272 and still no go. Sometimes I get no errors and nothing loads or I get a link/load error. When I attempt to do a kextload from the terminal I get a whole lot of "multiple definitions of symbol..." I'm also attaching my AppleHDA.kext. Hopefully someone can help me because I'm about to throw a Qosmio out a window... Thanks! alc272.txt pinstuff.txt ALC272AppleHDA.kext.zip ALC272decimalconverteddump.txt Link to comment Share on other sites More sharing options...
LatinMcG Posted April 9, 2009 Share Posted April 9, 2009 im here in behalf of all the DG45id and similar users with Codec: IDT 92HD73E1X5 Address: 2 Vendor Id: 0x111d7676 = 287143542 Subsystem Id: 0x80865002 Revision Id: 0x100202 this board has optical out and hdmi so the pinout config is a little intresting in the codec dump anyone got any ideas.. should i start from the applehda in 10.5.6 as i hear it has changed to manualy patch ? Link to comment Share on other sites More sharing options...
ronalith Posted April 16, 2009 Share Posted April 16, 2009 I´m trying to make work 5.1 audio in a ALC888s for a MSI X58 Pro, but so far I´m out of luck. This is what I got, if someone can give me some help it would be great. I have followed the king´s guide. In the zip you´ll find my codec dump, the graph and the kexts I did. I´m using them in the Extra folder of the EFI partition. If you need any more information please let me know. Thanks in advance. UPDATE: Got it working with voodoohda alc888s.zip Link to comment Share on other sites More sharing options...
webg3brasil Posted April 26, 2009 Share Posted April 26, 2009 solution ADI 1986a SoundMax VT8237 (A8V-X) AzaliaAudio ? Install Retail 10.5.6 ok Boot 132 ok lan ok video ok sound (not working) == need for patch Link to comment Share on other sites More sharing options...
righteye Posted May 2, 2009 Share Posted May 2, 2009 Hello, Nice How-TO. What i can do with this? Can you give as some info on that? My understandings are that this is not a 882 like here The address is 0 but the result of using bout solutions are the same, no sound. Using the Taruga's patcheri have the sound working Out and In but ... not the BuiltInMic and 2 of 4 BuiltInSpeakers (the 2 that are not working are for Bass) What can we do with the info provided in the link above? Thanks, righteye Link to comment Share on other sites More sharing options...
macuserzu Posted June 16, 2009 Share Posted June 16, 2009 hay everyone. here is my audio hardware info and linux codec dump..please help me.. IDT 92HD206 8-channel codec_dump.txt Link to comment Share on other sites More sharing options...
buridda Posted August 17, 2009 Share Posted August 17, 2009 wrong post in the wrong topic.. sorry!! :§ Link to comment Share on other sites More sharing options...
oneduality Posted August 31, 2009 Share Posted August 31, 2009 I've been reading guides and following various sets of instructions for weeks and I can't get my audio to work .. My laptop is a Gateway T-1625 Audio: Sigmatal HD (STAC905X) based on the ATI RS690(M) chipset I'm stuck in 1024x768 but I can live with that, the audio would be something I'd like to figure out a resolution to .. I've tried several of the sigmatel drivers to no avail .. could anyone offer any assistance? Link to comment Share on other sites More sharing options...
