Modified boot-132 Bootloader

shardie

By shardie,
in OSx86 10.5 (Leopard)

 Share
810 posts in this topic

Recommended Posts

MACinized
MACinized
Posted
Posted
type 9f.



its been stated in the forums multiple times. please look for it before posting a question.



pardon my laziness ottoman to read all that's here in the thread. i'll try ur advice & will post a feedback.

+ + +

the thing is, you've already replied but you've still not been clear about it. so i'm getting the same error. typed 9f after swapping the discs, then typed 9f again after typing 80 for the hdd. now i really have to read EVERYTHING that's on this thread & you've not been of any help now. how sad. ;)

cackintosh33
cackintosh33
Posted
Posted

Let me start off by saying I am a newb to the osx86 scene and I am trying really hard to learn on my own but I just can't find all of the pieces to solve my problem. Please bare with me.



My System Specs:

GA-P35-DS4 rev. 2.1 mobo

Intel Q6600

XFX 8600GT XXX 256mb

CORSAIR 4GB

WDC 500GB 7200rpm

Samsung SH-S203B

Antec Sonata III case



I am currently trying to boot the retail DVD using the ga-p35-ds4 iso and I have run into some trouble. I can use the iso to get the retail Leopard DVD installed but I can't seem to get any further after install.



Video, Ethernet and sound does not work. I see from ELASTICS posting that he also does not have audio working, which is not a problem because he is using usb, so I'm not to worried about audio. But when I install NVinject.kext my system freezes at the grey startup screen. No desktop even in safe mode. NVkush.kext does the same thing. And I have no idea how to get the ethernet working.



Sorry, but I found the install of BOOT-132 a little vague. Does BOOT-132 install the kexts itself or do I need to do that myself after installing the retail DVD? I've tried both but and I still have all the same problems.



I noticed, after unpacking ELASTICS extensions.mkext there was a ton of kexts. Is it necessary to have all of those kexts. There are far fewer kexts in non-related installs as well as the generic iso.



http://forum.insanelymac.com/index.php?sho...5&start=800



Perhaps my BIOS settings is wrong. Would you mind posting BIOS setting?



My BIOS Settings

HDD smart = Enabled

CPU Hyperthreading = Enabled

Limit cpu id max 3 = disabled

no execute protect = Enabled

cpu halt c1e = disabled

cpu thermal monitor = Enabled

cpu eist = disabled

virtualization tech = Enabled



sata raid/ahci = ahci

sata port 0-3 native = enabled

usb controler = Enabled

usb 2 controller = Enabled

usb kb support = Enabled

usb mouse support = Enabled

legacy usb = Enabled

azalia codec = Enabled

onboard 1394 = Enabled

onboard lan = Enabled

lan boot rom = disabled

onboard sata/ide device = Enabled

onboard sata/ide device mode = ahci



acpi suspend type = S3

soft of by pwr button = instant off

hpet support = enabled

hpet mode = 64 bit

ottoman1384
ottoman1384
Posted
Posted
pardon my laziness ottoman to read all that's here in the thread. i'll try ur advice & will post a feedback.

+ + +

the thing is, you've already replied but you've still not been clear about it. so i'm getting the same error. typed 9f after swapping the discs, then typed 9f again after typing 80 for the hdd. now i really have to read EVERYTHING that's on this thread & you've not been of any help now. how sad. ;)



dont type 80 at all... instead of typing 80, you need to type 9f

MACinized
MACinized
Posted
Posted
dont type 80 at all... instead of typing 80, you need to type 9f



tried that too. after swapping discs, i typed "-v" then on the "80 or 81" option, i typed "9f" but i just keep on getting the "80 or 81" option.



then i tried typing "-v -f" (after disc swap) then typed "80" and everything seems to be loaded. then i got stuck after the "DMS(?) (can't remember) auditing present" line.



prior to this last line, i noted this:

Extension "com.apple.driver.AppleACPIPlatform" has immediate dependencies on both com.apple.kernel and com.apple.kpi components; use only one style.



any ideas? tnx for your time ottoman1384.

ottoman1384
ottoman1384
Posted
Posted
tried that too. after swapping discs, i typed "-v" then on the "80 or 81" option, i typed "9f" but i just keep on getting the "80 or 81" option.



then i tried typing "-v -f" (after disc swap) then typed "80" and everything seems to be loaded. then i got stuck after the "DMS(?) (can't remember) auditing present" line.



prior to this last line, i noted this:





any ideas? tnx for your time ottoman1384.



ok maybe i am misunderstading what you are doing.



what you need to do is not type in 80 or 81 at all. on the first screen press enter. then when you get the option to press 80 or 81, switch cds. then type in 9f. enter. type in -v -f. enter.



never type in 80 or 81 unless you are trying to boot from a hdd. but you are trying to boot the leopard install dvd, so you need to type in 9f.



i hope that clears things up.

MACinized
MACinized
Posted
Posted
ok maybe i am misunderstading what you are doing.



what you need to do is not type in 80 or 81 at all. on the first screen press enter. then when you get the option to press 80 or 81, switch cds. then type in 9f. enter. type in -v -f. enter.



never type in 80 or 81 unless you are trying to boot from a hdd. but you are trying to boot the leopard install dvd, so you need to type in 9f.



i hope that clears things up.

can't wait to try this when i get home. tnx again. hopefully i'll get things done.

mrl3ig65
mrl3ig65
Posted
Posted

@ottoman :





instead of 81, you need to input 9f



you insert the boot cd. then once it loads and gives you the option to enter a number, replace the boot cd with the leopard dvd. then insert 9f and it should start loading the install dvd.



but i really don't know it would work on your laptop.

it's worth a try though.



thanks it kinda worked the dvd was working but it would hang on the boot screen and by boot screen i mean the screen that you get when you boot in to osx already installed and used the -v flag and it just hangs there. i am useing the orgial iso also the setup take a longggg time to load is this normal? should i add kext? and if so which ones??? well i hope to hear from anyone that can help.

P.s i used the -v -f flags and 9f

ottoman1384
ottoman1384
Posted
Posted
@ottoman - did you get your p35 ds3l working with the modified boot 132 bootloader? If yes, can you please post the iso used and any other information. As you can see from my post above, i'm having some trouble.



Thanks,



i have a ds3l, not a p35. i got it installed with elastics iso. but not all features worked off the bat. wireless pci card didnt work. ethernet was flaky at best. you're gonna have to add some kexts depending on your video card,etc.



i just tried it out. im not using it as my main setup. im still using kalyway @ 10.5.4

but i've been able to recover from back up using boot 132 and original leopard dvd.



so, thats what i mainly use it for.



good luck

djspacee
djspacee
Posted
Posted

It's a great piece of software and the guys who came up with this have done a wicked job. I was really happy when I got this setup and running and could update from software update, I think it's genius. The only thing I have a problem with is the boot itself. There seems to be a huge gap with osx86 that the bootloader itself is not capable of multi-booting, grub is difficult to setup with it (standard EFI darwin boot or chameleon, and with Guid Partition Table this becomes next to impossible) and chain0 doesn't always work. Meaning that we don't have a bootloader which is fairly easy to configure and can boot other operating systems for us unless they are on the same partition as the drive we're booting. I do not want to switch back to havin my osx86 and windows installs on the same partition, because I have dedicated drives for each...

I've noticed that the chameleon-DFE bootloader has the ability to select other operating systems and boot them. The only thing that is bugging me is the fact that there doesn't seem to be anyway to configure it so that it comes uop with a menu rather than defaulting the drive that it is installed on. I know that the chameleon DFE bootloader loads the extensions for the OSX install, but I wonder if it would be possible to not load these drivers, say if u sel;ected another operating system, configuring chameleon to boot other operating systems. This would make things a lot easier and save having to go into bios every time i want to boot windows.



If this really isn't possible, I'd still like to be able to make the bootloader actually load the operating system for me like standard chameleon does, rather than just stopping on a command prompt... anyone have any ideas?



also if anyone knows a method to get grub working for a GPT i would be very grateful....



Cheers Guys

santitf
santitf
Posted
Posted

Hi everybody:

Finally i was install de Retail DVD with the GA-P35-DS4_ISO from Elastic

http://www.mediafire.com/?0g8v3pxntz4 (Thanks Jimmy Mallmann) in a Asus P5K with P35 chipset.

But when leopard starts install i can't do it in my MBR HD.

I read here:

http://forum.insanelymac.com/lofiversion/i...hp/t116505.html

and i make with toast 9 a DVD with retail leo+boot 132 from Elastic.

I install leopard in my MBR partition and update to 10.5.4 without problems :D

Thanks!!!

one9092002
one9092002
Posted
Posted
Hi guys and gels.



ive used this method: http://forum.insanelymac.com/index.php?sho...mp;#entry805274 but i keep getting an error after the -v flag.



the error is :

AppleHDAController:: start ERROR no layout-id found

AppleHDA.kext failed to load. unable to locate "layout-id" property



Ive added a working AppleHDA.kext but still the same error.



Pleae help if you know the solution.



BTW: Im using Kalyway 10.5.2 install DVD with vanilla. So I know that the kext im using are working.





okay i am using leopard server it boots fine with the grub dfe.iso..but when i do the kaly to boot from hard drive. the first thing i do is move the files from cd:/boot/initrd.img and mount in there i seee extensions file and move them into kaly content folder and then i run the installer....i also trying booted up -v...and i get the error package 0 didn't get an hpet ..what im i doin wrong? and my jmicron ata controller does not work any suggestions plz

MACinized
MACinized
Posted
Posted

since boot-132 loads the necessary files to make a grey pc "pretend" as if it's a real mac, then would it be possible that having successfully installed a retail leopard, boot camp would be of use? pardon my ignorance of any technicalities. :)

one9092002
one9092002
Posted
Posted
~pcwiz's osx86 tools



just use that to install chameleon, and then replace the boot file in the root of your install partition with the dfe boot file. The one thing that bothers me about this is that there is no way that i can figure out to get a countdown or automatic load of leopard, i always have to press enter for it to continue. If anyone knows a way past this please let me know!





i am trying to boot from my hard drive with out the boot cd..can you tell me how to do this thanks

one9092002
one9092002
Posted
Posted
hello guys,



glad to know that my custom kexts are helping around, just wait until tomorrow (so i can get back in my studio) and I will post the list of kexts i'm using on that .iso



i also have the shutdown kernel panic issue, i'm going to try to follow Sabr advice and search some solutions on power management kext



as for the iMac appearing as computer model, i kind of like it that way :)





cheers





i have installed retailed disk successfully...with 132 boot cd.. i am trying to install on my hard drive so i can boot from hard drive..can any one give me step by step instructions.. where can i get the files plz

one9092002
one9092002
Posted
Posted
http://forum.insanelymac.com/index.php?act...st&id=29690



use osx86 tools to install chameleon. its really easy. then you'll be able to boot from the hdd





can you give me instructions on how to do this....excuse me....i am new to this..thanks for your hard work







does anyone know where exactly i move the boot file to...after i install the chameleon.

one9092002
one9092002
Posted
Posted
Edit the com.apple.Boot.plist

Just like you do on the OLD WAY of installing.

I think the trick here is add Quiet boot = Yes

or if you want a delay like so

Just adjust delay to appropriate value.

<?xml version="1.0" encoding="UTF-8"?>

<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">

<plist version="1.0">

<dict>

<key>Boot Graphics</key>

<string>Yes</string>

<key>Kernel</key>

<string>mach_kernel</string>

<key>Kernel Flags</key>

<string></string>

<key>Quiet Boot</key>

<string>No</string>

<key>Timeout</key>

<string>5</string>

</dict>

</plist>



I keep getting told this DOESN'T work.

But it WORKS for me.







Anybody interested.

Drum roll!!!

I can now boot a NATIVE DFE DVD.

NO NEED FOR DFE.iso

So EASY to do.





can uou tell me where i can find this file

cautaro
cautaro
Posted
Posted

Hello,



I have successfully installed from the Retail DVD using elastics iso (thanks) on a gigabyte p35 ds3l and then applying the patches as described in this thread. (http://forum.insanelymac.com/index.php?showtopic=115877).



Now i'm getting the classic 'still waiting for root device' because I'm using a SATA HD. I'm a noob at this, so please let me know what to do. My bios doesn't have any SATA settings that I can find, but I know I have to change some kexts in order to get this working. I have posted the way OSX sees the hardrive and cd rom (also sata). Are there some packages I need to get? Where do I get them and how do I install? I posted in this thread because I'm not sure how to get those kexts using the Retail DVD install.



Thanks,


LisPSIH
LisPSIH
Posted
Posted

I stuck with one problem, I can't create bootable cd or usb with my own kext.



1)I use PowerISO and TransMac to add kext in initrd.img and burn it to CD-RW, but while booting i have checksum error





2)When I add kext to usb bootble drive with the help of syslinux... it's boot very well, but my added kext didn't work (if put my kexts directly in extensions folder in Leopard and chmode it  - they work perfectly). Why my kexts didn't recognized in usb drive ??? ;)

(i add <key>OSBundleRequired</key> to info.plist but it's not recogniseble too)

( <string>Root</string>



I have read whole two topics about boot-132, but can't find any methode to solve this problem.



pleeeeeeeeeeeeeeeeeeeeeeasse  guru HELP      HELP                           HELP                           >.... HELP    ;)
