[HELP!] Intel HD4000 OS X 10.9.2 detected but no QE/QC

intel hd4000 hd 4000 graphics intelcaprifb not working qe/qc

  • Please log in to reply
13 replies to this topic

#1
ACDindia

ACDindia

    InsanelyMac Protégé

  • Members
  • PipPip
  • 62 posts
  • Gender:Male

Hello Guys!



I have ran into a weird situation here.



My DELL 7720 SE laptop had some power problem on the motherboard (as told by the service center guys) which made my system unbootable.

They replaced the motherboard.



I brought it home and obviously, tried installing OSX using the Time Machine Backup. It restored correctly.

Used all the same files/ config as earlier but the system couldn't boot up.



It boots in safe mode, but no QE/QC.

When I delete the Intel HD4000 Kexts and SNBGraphics etc kexts, the system boots up, again w/o QE/QC!!!     :(



Now, what in the world has gone wrong??

I have updated the BIOS to the latest A16.



Is the new motherboard different than the earlier one?

Basically, Intel HD4000 is not working.......



I am trying get it work on OS X 10.9.2



I tried latest Chameleon Bootloader with DSDT=Null and tried all IntelCapriFB=1-11 EnableDualLink=Yes/No, GraphicsEnabler=Yes/No SkipNvidiaGfx=Yes..



All except one gave me Black Screen...

IntelCapriFB=4 was the best one as the Intel Graphics was detected correctly with 1024Mb VRAM...but No QE/QC..



The graphics is obviously crappy without QE/QC...



I checked the loaded KEXTS and found that AGPM is not loading.. FramebufferCapri and HD4000 kexts are loading with IntelCapriFB=4....



Also, clover Bootloader is not able to find my Mac volume, yes, i have the HFS related driver in CLover... tried both Vbox and HFSPlus...!!!!!

So using chameleon on the USB as I have windows in UEFI mode with GPT partitioning.



The older DSDT worked flawlessly (thanks to Lejenk)

Somehow the same DSDT has stopped working after the swapping of motherboard.....


System has Intel HD Graphics 4000 and NVIDIA GT650M in optimus..
CPU is 3rd Gen Intel Core i7 3630QM..
HDD is 1TB partitioned as GPT... with windows 8 installed in UEFI mode...



Please help!



#2
ACDindia

ACDindia

    InsanelyMac Protégé

  • Members
  • PipPip
  • 62 posts
  • Gender:Male

I am uploading my IOReg file here....

thank you for your help!!



I am using MacBookPro9,1 SMBIOS generated using Chameleon Wizard...



Attached File  MacBook_Pro.ioreg.zip   916.86KB   65 downloads


IOReg Extracted using IOREGExplorer v2
Attached File  MacBookPro_IOREGExplorer_v2.ioreg.zip   301.43KB   30 downloads

Attached Files



#3
artur-pt

artur-pt

    InsanelyMacaholic

  • Local Moderators
  • 4,753 posts
  • Gender:Male
  • Location:Portugal
  • Interests:TechManiaco

hello



i think the hd 4000 kext is not loading..



check it in terminal



kextstat



good hack



#4
ACDindia

ACDindia

    InsanelyMac Protégé

  • Members
  • PipPip
  • 62 posts
  • Gender:Male

Hi!



The Intel HD 4000 Kext is loading...

Index Refs Address            Size       Wired      Name (Version) <Linked Against>
    1   62 0xffffff7f807e0000 0x8d80     0x8d80     com.apple.kpi.bsd (13.1.0)
    2    6 0xffffff7f80b22000 0x28c0     0x28c0     com.apple.kpi.dsep (13.1.0)
    3   88 0xffffff7f807a9000 0x1dfb0    0x1dfb0    com.apple.kpi.iokit (13.1.0)
    4   93 0xffffff7f807c7000 0xbf40     0xbf40     com.apple.kpi.libkern (13.1.0)
    5   81 0xffffff7f807a6000 0x2d10     0x2d10     com.apple.kpi.mach (13.1.0)
    6   37 0xffffff7f807d3000 0x7d90     0x7d90     com.apple.kpi.private (13.1.0)
    7   55 0xffffff7f807db000 0x48e0     0x48e0     com.apple.kpi.unsupported (13.1.0)
    8    2 0xffffff7f80b28000 0x47000    0x47000    com.apple.kec.corecrypto (1.0) <7 6 5 4 3 1>
    9    0 0xffffff7f80c79000 0xb000     0xb000     com.apple.kec.pthread (1) <7 6 5 4 1>
   10   16 0xffffff7f80c84000 0x9000     0x9000     com.apple.iokit.IOACPIFamily (1.4) <7 6 4 3>
   11   21 0xffffff7f808bb000 0x2f000    0x2f000    com.apple.iokit.IOPCIFamily (2.9) <7 6 5 4 3>
   12    2 0xffffff7f81b15000 0x5c000    0x5c000    com.apple.driver.AppleACPIPlatform (1.3.5) <11 10 7 6 5 4 3>
   13    1 0xffffff7f80e14000 0xb000     0xb000     com.apple.driver.AppleFDEKeyStore (28.30) <8 7 6 5 4 3 1>
   14    1 0xffffff7f810d7000 0x11000    0x11000    com.apple.iokit.IOReportFamily (23) <5 4 3>
   15   11 0xffffff7f807e9000 0x2d000    0x2d000    com.apple.iokit.IOStorageFamily (1.9) <7 6 5 4 3 1>
   16    0 0xffffff7f811b1000 0x1e000    0x1e000    com.apple.driver.DiskImages (371.1) <15 7 6 5 4 3 1>
   17    0 0xffffff7f81845000 0x14000    0x14000    com.apple.driver.AppleKeyStore (2) <8 7 6 5 4 3 1>
   18    0 0xffffff7f819f1000 0x29000    0x29000    com.apple.driver.AppleIntelCPUPowerManagement (196.0.0) <7 6 5 4 3 1>
   19    0 0xffffff7f80b25000 0x3000     0x3000     com.apple.security.TMSafetyNet (7) <7 6 5 4 2 1>
   20    2 0xffffff7f80bc6000 0x5000     0x5000     com.apple.kext.AppleMatch (1.0.0d1) <4 1>
   21    1 0xffffff7f80bcb000 0x14000    0x14000    com.apple.security.sandbox (278.11) <20 7 6 5 4 3 2 1>
   22    0 0xffffff7f80bdf000 0x7000     0x7000     com.apple.security.quarantine (3) <21 20 7 6 5 4 2 1>
   23    0 0xffffff7f81b90000 0x8000     0x8000     com.apple.nke.applicationfirewall (153) <7 6 5 4 3 1>
   24    0 0xffffff7f819ec000 0x3000     0x3000     com.apple.driver.AppleIntelCPUPowerManagementClient (216.0.0) <7 6 5 4 3 1>
   25    0 0xffffff7f81ae9000 0x3000     0x3000     com.apple.driver.AppleAPIC (1.7) <4 3>
   26    0 0xffffff7f81749000 0x4000     0x4000     com.apple.driver.AppleSMBIOS (2.1) <7 4 3>
   27    0 0xffffff7f81a41000 0x3000     0x3000     com.apple.driver.AppleHPET (1.8) <10 7 5 4 3>
   28    0 0xffffff7f817de000 0x3000     0x3000     com.apple.AppleACPIPS2Nub (1.6.1) <10 7 4 3>
   29    5 0xffffff7f80e1f000 0x85000    0x85000    com.apple.iokit.IOHIDFamily (2.0.0) <13 7 6 5 4 3 2 1>
   30    0 0xffffff7f81b7a000 0x4000     0x4000     com.apple.driver.AppleACPIButtons (1.3.5) <29 12 10 7 6 5 4 3 1>
   31    0 0xffffff7f80c8d000 0x7000     0x7000     com.apple.driver.AppleRTC (1111) <10 5 4 3 1>
   32    2 0xffffff7f81069000 0x4000     0x4000     com.apple.iokit.IOSMBusFamily (1.1) <5 4 3>
   33    0 0xffffff7f81b71000 0x6000     0x6000     com.apple.driver.AppleACPIEC (1.3.5) <32 12 10 5 4 3>
   34    0 0xffffff7f81b81000 0x8000     0x8000     com.apple.driver.AppleACPIBatteryManager (1.0.15) <10 5 4 3 1>
   35    0 0xffffff7f813c8000 0xd000     0xd000     org.netkas.FakeSMC (1111) <10 7 5 4 3>
   36    0 0xffffff7f817e4000 0x9000     0x9000     com.apple.driver.ApplePS2Controller (2.0.0) <5 4 3>
   37    1 0xffffff7f81ac4000 0x5000     0x5000     com.apple.driver.AppleEFIRuntime (2.0) <7 6 5 4 3>
   38    0 0xffffff7f81ac9000 0xa000     0xa000     com.apple.driver.AppleEFINVRAM (2.0) <37 7 6 5 4 3>
   39   11 0xffffff7f80be7000 0x6d000    0x6d000    com.apple.iokit.IOUSBFamily (675.4.0) <11 7 5 4 3 1>
   40    0 0xffffff7f813ad000 0x1b000    0x1b000    net.osx86.kexts.GenericUSBXHCI (1.2.7) <39 11 7 5 4 3>
   41    0 0xffffff7f80f31000 0x18000    0x18000    com.apple.driver.AppleUSBEHCI (660.4.0) <39 11 7 5 4 3 1>
   42    3 0xffffff7f8134f000 0x19000    0x19000    com.apple.iokit.IOAHCIFamily (2.6.5) <5 4 3 1>
   43    0 0xffffff7f81aee000 0x1a000    0x1a000    com.apple.driver.AppleAHCIPort (3.0.0) <42 11 5 4 3 1>
   44    0 0xffffff7f80c54000 0x1e000    0x1e000    com.LaCie.driver.PXHCD (1111) <39 11 7 5 4 3>
   45    0 0xffffff7f80eb4000 0x1d000    0x1d000    com.apple.driver.AppleUSBXHCI (670.4.0) <39 11 7 5 4 3 1>
   46    2 0xffffff7f80dbc000 0x34000    0x34000    com.apple.iokit.IONetworkingFamily (3.2) <7 6 5 4 3 1>
   47    0 0xffffff7f81137000 0x1d000    0x1d000    com.apple.driver.AppleRTL8169Ethernet (1.1.4a5) <46 11 5 4 3 1>
   48    0 0xffffff7f80e11000 0x3000     0x3000     com.apple.iokit.IOUSBUserClient (660.4.2) <39 7 5 4 3 1>
   49    0 0xffffff7f80f12000 0x18000    0x18000    com.apple.driver.AppleUSBHub (666.4.0) <39 5 4 3 1>
   50    0 0xffffff7f814bd000 0x9000     0x9000     com.apple.BootCache (35) <7 6 5 4 3 1>
   51    0 0xffffff7f81ab5000 0x4000     0x4000     com.apple.AppleFSCompression.AppleFSCompressionTypeZlib (1.0.0d1) <6 4 3 2 1>
   52    0 0xffffff7f81abb000 0x3000     0x3000     com.apple.AppleFSCompression.AppleFSCompressionTypeDataless (1.0.0d1) <7 6 4 3 2 1>
   53    0 0xffffff7f81ac0000 0x2000     0x2000     com.apple.driver.AppleFileSystemDriver (3.0.1) <15 4 3>
   54    0 0xffffff7f81375000 0x18000    0x18000    com.apple.iokit.IOAHCIBlockStorage (2.5.1) <42 15 6 5 4 3 1>
   55    5 0xffffff7f80879000 0x31000    0x31000    com.apple.iokit.IOSCSIArchitectureModelFamily (3.6.6) <5 4 3 1>
   56    0 0xffffff7f81368000 0xd000     0xd000     com.apple.iokit.IOAHCISerialATAPI (2.6.1) <55 42 5 4 3 1>
   57    0 0xffffff7f815f4000 0x3000     0x3000     com.apple.driver.XsanFilter (404) <15 5 4 3 1>
   58    0 0xffffff7f817d9000 0x5000     0x5000     com.apple.driver.ApplePS2Keyboard (2.0.0) <29 5 4 3>
   59    0 0xffffff7f817cc000 0x8000     0x8000     com.apple.driver.ApplePS2Trackpad (2.0.0) <29 5 4 3>
   60    0 0xffffff7f817d4000 0x5000     0x5000     com.apple.driver.ApplePS2Mouse (2.0.0) <29 5 4 3>
   61    0 0xffffff7f81083000 0x7000     0x7000     com.apple.iokit.SCSITaskUserClient (3.6.6) <55 15 5 4 3 1>
   62    3 0xffffff7f8108e000 0x11000    0x11000    com.apple.iokit.IOCDStorageFamily (1.7.1) <15 5 4 3 1>
   63    2 0xffffff7f8109f000 0xe000     0xe000     com.apple.iokit.IODVDStorageFamily (1.7.1) <62 15 5 4 3 1>
   64    1 0xffffff7f810ad000 0xc000     0xc000     com.apple.iokit.IOBDStorageFamily (1.7) <63 62 15 5 4 3 1>
   65    0 0xffffff7f810b9000 0x1e000    0x1e000    com.apple.iokit.IOSCSIMultimediaCommandsDevice (3.6.6) <64 63 62 55 15 5 4 3 1>
   66    0 0xffffff7f80ead000 0x7000     0x7000     com.apple.driver.AppleUSBComposite (656.4.1) <39 4 3 1>
   67    0 0xffffff7f80dfd000 0x14000    0x14000    com.apple.iokit.IOUSBMassStorageClass (3.6.0) <55 39 15 5 4 3 1>
   68    0 0xffffff7f80cdf000 0x18000    0x18000    com.apple.iokit.IOSCSIBlockCommandsDevice (3.6.6) <55 15 5 4 3 1>
   69    0 0xffffff7f81860000 0x8000     0x8000     com.apple.driver.AppleIntelMCEReporter (104) <7 6 5 4 3>
   70    0 0xffffff7f81a1d000 0x3000     0x3000     com.apple.driver.AppleHWAccess (1) <7 5 4 3>
   71    2 0xffffff7f8110b000 0x15000    0x15000    com.apple.driver.AppleSMC (3.1.8) <10 7 5 4 3 1>
   72    0 0xffffff7f813d5000 0x5000     0x5000     com.apple.Dont_Steal_Mac_OS_X (7.0.0) <71 7 4 3 1>
   73    0 0xffffff7f8126e000 0xad000    0xad000    com.apple.iokit.IOBluetoothFamily (4.2.3f10) <39 14 7 5 4 3 1>
   74    6 0xffffff7f8115e000 0x43000    0x43000    com.apple.iokit.IOGraphicsFamily (2.4.1) <11 7 5 4 3 1>
   75    1 0xffffff7f81055000 0x14000    0x14000    com.apple.iokit.IOSurface (91) <7 5 4 3 1>
   76    0 0xffffff7f80df0000 0x7000     0x7000     com.apple.iokit.IOUserEthernet (1.0.0d1) <46 6 5 4 3 1>
   77    4 0xffffff7f810e8000 0xa000     0xa000     com.apple.driver.IOPlatformPluginFamily (5.7.0d10) <10 7 6 5 4 3>
   78    0 0xffffff7f8183d000 0x3000     0x3000     com.apple.driver.AppleLPC (1.7.0) <77 11 5 4 3>
   79    1 0xffffff7f81977000 0x6000     0x6000     com.apple.AppleGraphicsDeviceControl (3.4.35) <7 6 5 4 3 1>
   80    2 0xffffff7f81894000 0x72000    0x72000    com.apple.iokit.IOAcceleratorFamily2 (98.14) <74 11 7 6 5 4 3 1>
   81    0 0xffffff7f8197d000 0x58000    0x58000    com.apple.driver.AppleIntelFramebufferCapri (8.2.4) <80 79 74 11 10 7 6 5 4 3 1>
   82    0 0xffffff7f81746000 0x3000     0x3000     com.apple.driver.AppleSMBusPCI (1.0.12d1) <11 5 4 3>
   83    0 0xffffff7f811a1000 0x10000    0x10000    com.apple.iokit.IONDRVSupport (2.4.1) <74 11 7 5 4 3>
   84    0 0xffffff7f810f2000 0x3000     0x3000     com.apple.driver.AppleSMCPDRC (1.0.0) <77 11 6 4 3>
   85    1 0xffffff7f81a76000 0xf000     0xf000     com.apple.iokit.IOHDAFamily (2.3.0f2) <5 4 3 1>
   86    0 0xffffff7f81a85000 0x16000    0x16000    com.apple.driver.AppleHDAController (2.3.0f2) <85 74 11 6 5 4 3 1>
   87    1 0xffffff7f810f7000 0x14000    0x14000    com.apple.driver.IOPlatformPluginLegacy (1.0.0) <77 10 7 6 5 4 3>
   88    0 0xffffff7f81120000 0x10000    0x10000    com.apple.driver.ACPI_SMC_PlatformPlugin (1.0.0) <87 77 71 11 10 7 6 5 4 3>
   89    0 0xffffff7f80ca7000 0x4000     0x4000     com.evosx86.driver.lspcidrv (1111) <4 3>
   90    0 0xffffff7f81906000 0x4c000    0x4c000    com.apple.driver.AppleIntelHD4000Graphics (8.2.4) <80 75 74 11 7 5 4 3 1>
   91    1 0xffffff7f817f3000 0x11000    0x11000    com.apple.driver.AppleSMBusController (1.0.11d1) <32 11 10 5 4 3>
   92    0 0xffffff7f81804000 0xd000     0xd000     com.apple.driver.AppleMCCSControl (1.1.12) <91 74 11 10 7 5 4 3 1>
   93    0 0xffffff7f8124d000 0x1d000    0x1d000    com.apple.iokit.IOBluetoothHostControllerUSBTransport (4.2.3f10) <39 11 10 7 5 4 3 1>
   94    0 0xffffff7f80ea4000 0x9000     0x9000     com.apple.iokit.IOUSBHIDDriver (660.4.0) <39 29 5 4 3 1>
   95    1 0xffffff7f80b6f000 0x5000     0x5000     com.apple.kext.triggers (1.0) <7 6 5 4 3 1>
   96    0 0xffffff7f814c8000 0x9000     0x9000     com.apple.filesystems.autofs (3.0) <95 7 6 5 4 3 1>
   97    0 0xffffff7f81bad000 0x17000    0x17000    com.tuxera.filesystems.tufsfs.fusefs_txantfs (2013.3.14) <7 5 4 3 1>
   98    1 0xffffff7f81072000 0x11000    0x11000    com.apple.iokit.IOSerialFamily (10.0.7) <7 6 5 4 3 1>
   99    0 0xffffff7f8123d000 0xa000     0xa000     com.apple.iokit.IOBluetoothSerialManager (4.2.3f10) <98 7 5 4 3 1>
  100    1 0xffffff7f80c97000 0xe000     0xe000     com.apple.filesystems.msdosfs (1.9) <7 5 4 1>

pokenguyen checked my IOReg, and suggested that my laptop is missing Intel Management Engine Interface (IMEI).... The motherboard was swapped by DELL service center... so probably the motherboard is faulty... I am looking for a reason to complain about it to the service center guys.... can't say that I am installing Hack MAC.... :P :P



Do you know any app that utilizes this device and can return me with a error that the device is not found...? :P



#5
ACDindia

ACDindia

    InsanelyMac Protégé

  • Members
  • PipPip
  • 62 posts
  • Gender:Male

I checked for drivers on the DELL website.. They do not have a Intel Management Engine Interface (IMEI) driver for my laptop!!!!

Is it possible that a laptop lacks that device??



Can OS X work without that device??



#6
pokenguyen

pokenguyen

    InsanelyMac Sage

  • Members
  • PipPipPipPipPipPip
  • 473 posts
  • Gender:Male

Try patching your dsdt with this (use MacIASL):

into device label IMEI parent_label PCI0 remove_entry;
into device label PCI0 insert
begin
Device (IMEI)\n
{\n
    Name (_ADR, 0x00160000)\n
    Method (_DSM, 4, NotSerialized)\n
    {\n
        If (LEqual (Arg2, Zero)) { Return (Buffer() { 0x03 } ) }\n
        Return (Package()\n
        {\n
            "device-id", Buffer() { 0x3A, 0x1E, 0x00, 0x00 },\n
            "name", "pci8086,1e3a",\n
        })\n
    }\n
}\n
end;


#7
ACDindia

ACDindia

    InsanelyMac Protégé

  • Members
  • PipPip
  • 62 posts
  • Gender:Male

Thank you!!!
I will give it a spin!!!! :)



Will revert back with the results....



#8
pokenguyen

pokenguyen

    InsanelyMac Sage

  • Members
  • PipPipPipPipPipPip
  • 473 posts
  • Gender:Male

Run DPCIManager, take a screenshot of PCI List tab.



#9
ACDindia

ACDindia

    InsanelyMac Protégé

  • Members
  • PipPip
  • 62 posts
  • Gender:Male

Run DPCIManager, take a screenshot of PCI List tab.



Hi!



I added your provided patch for IMEI in the DSDT which worked earlier for me...



I removed Chameleon argument "IntelCapriFB=4 GraphicsEnabler=Yes"..



The system doesn't boot up.. It gets stuck at



DRMStatus Error: iTunes/Apple Store Content Access Problem. Content playback may be disabled on this computer. You can continue to use the machine, but you should contact an Apple support representative. ErrorCode: 8877652"



I tried with "IntelCapriFB=4 GraphicsEnabler=Yes" with the same result...



Finally booted with -x parameter.....



Attaching the DPCIManager screenshot..



Attached File  PCI_List_Screen.tiff   337.87KB   59 downloads





Also, I am attaching my new IOReg after using the DSDT



Attached File  MacBookPro_DSDT_Patch.ioreg.zip   298.65KB   31 downloads



Thank you for your help!!!





#10
PJALM

PJALM

    InsanelyMac Geek

  • Coders
  • 167 posts
  • Gender:Male

have u applied any patch to disable your optimus?



try this if not http://www.osx86.net...a-optimus-dsdt/



#11
ACDindia

ACDindia

    InsanelyMac Protégé

  • Members
  • PipPip
  • 62 posts
  • Gender:Male

Thanks!!

but, NVIDIA Optimus is already disabled in the DSDT.....



have no luck yet!!! don't know where I am going wrong..!! Probably that IMEI device is the root cause of this.....



#12
Steel1990

Steel1990

    InsanelyMac Protégé

  • Members
  • Pip
  • 1 posts

Hi ACD,

Just played the quiz to get here, gues what i passed...
Anyway i have the same problem as you, for the H7 series chipset we shoulden't need a imei, I get the same message about the "DRMStatus".
My idea was to try different ports on my notebook to see what will happen, wel if i counter anything i let you know.



#13
ACDindia

ACDindia

    InsanelyMac Protégé

  • Members
  • PipPip
  • 62 posts
  • Gender:Male

Hey bro!

Thank you for that ray of hope...



I really hope that you get through this problem and both of us could have a working Hackintosh.



Waiting eagerly. :)



#14
ACDindia

ACDindia

    InsanelyMac Protégé

  • Members
  • PipPip
  • 62 posts
  • Gender:Male
Update:
I installed OS X 10.8 which worked with the same DSDT... Then I gladly updated it to 10.8.5.. But to my dismay, the same problem surfaced!!!
I decided to update one by one... So that I could know which version of OS X stops working..
It worked till 10.8.2.. I had Intel HD Graphics 4000 with 512MB VRAM and QE/QC... Only thing was my ISB 3.0 wasn't working... But I can't use 10.8.2 as many softwares are not supported on it... At least Maverics is required!!
I searched for the IMEI device problem... What I have learned is that it becomes mandatory for the hybrid systems... Like 6 series chip on 7 series board.. But mine is both 7 Series...
Please someone help!! :'( :'(





Also tagged with one or more of these keywords: intel, hd4000, hd, 4000, graphics, intelcaprifb, not, working, qe/qc


0 user(s) are reading this topic

0 members, 0 guests, 0 anonymous users

© 2014 InsanelyMac  |   News  |   Forum  |   Downloads  |   OSx86 Wiki  |   Mac Netbook  |   PHP hosting by CatN  |   Designed by Ed Gain  |   Logo by irfan  |   Privacy Policy
