OpenCore General Discussion

Alpha22 · April 14, 2023

what is this error due to

41:738 00:027 AAPL: #[EB.H.LV|!] Err(0xE) <- RT.GV boot-signature 7C436110-AB2A-4BBB-A880-FE41995C9F82
41:765 00:027 AAPL: #[EB|WL] 0 0 0x01 0x01  23 0x0E
41:792 00:027 AAPL: #[EB.H.LV|!] Err(0xE) <- RT.GV boot-image-key 7C436110-AB2A-4BBB-A880-FE41995C9F82
41:820 00:027 AAPL: #[EB|WL] 0 0 0x01 0x01  24 0x0E
41:847 00:027 AAPL: #[EB.H.LV|!] Err(0xE) <- RT.GV boot-image 7C436110-AB2A-4BBB-A880-FE41995C9F82
41:875 00:027 AAPL: #[EB.H.LV|!] Err(0xE) <- RT.SV- boot-signature 7C436110-AB2A-4BBB-A880-FE41995C9F82
41:902 00:027 AAPL: #[EB.H.LV|!] Err(0xE) <- RT.SV- boot-image-key 7C436110-AB2A-4BBB-A880-FE41995C9F82
41:930 00:027 AAPL: #[EB.H.LV|!] Err(0xE) <- RT.SV- boot-image 7C436110-AB2A-4BBB-A880-FE41995C9F82

advice

miliuco · April 14, 2023

@Alpha22

I have exactly the same lines but I guess it's not a real error, I have them since a lot of time ago and macOS works ok. Now on Ventura 13.3.1 and OpenCore 0.9.2.

00:117 00:003 AAPL: #[EB.H.LV|!] Err(0xE) <- RT.GV boot-signature 7C436110-AB2A-4BBB-A880-FE41995C9F82
00:120 00:003 AAPL: #[EB|WL] 0 0 0x01 0x01  23 0x0E
00:124 00:003 AAPL: #[EB.H.LV|!] Err(0xE) <- RT.GV boot-image-key 7C436110-AB2A-4BBB-A880-FE41995C9F82
00:127 00:003 AAPL: #[EB|WL] 0 0 0x01 0x01  24 0x0E
00:131 00:003 AAPL: #[EB.H.LV|!] Err(0xE) <- RT.GV boot-image 7C436110-AB2A-4BBB-A880-FE41995C9F82
00:135 00:003 AAPL: #[EB.H.LV|!] Err(0xE) <- RT.SV- boot-signature 7C436110-AB2A-4BBB-A880-FE41995C9F82
00:138 00:003 AAPL: #[EB.H.LV|!] Err(0xE) <- RT.SV- boot-image-key 7C436110-AB2A-4BBB-A880-FE41995C9F82
00:142 00:003 AAPL: #[EB.H.LV|!] Err(0xE) <- RT.SV- boot-image 7C436110-AB2A-4BBB-A880-FE41995C9F82

@Alpha22

Please add a signature to your user profile.

polkaholga · April 15, 2023

Hi developers

Like @Matgen84 I cannot build latest version, but my problem occurs much earlier....

DEFI_TARGET64 ../../OpenCorePkg/User/Library/UserMisc.c -o Darwin_X64_Tool64/UserMisc.o

CommonLib.c:cc -MMD -MT Darwin_X64_Tool32/UserOcDummy.o -MF Darwin_X64_Tool32/UserOcDummy.d -c -fshort-wchar -Wall -Wextra -D EFIUSER -Wno-unused-parameter -Wno-implicit-fallthrough -Wno-strict-aliasing -Wno-address -mmacosx-version-min=10.6 --target=x86_64-apple-darwin -D ENTRY_POINT=main -g -O0 -D EFIUSER_DEBUG -I../../OpenCorePkg/User/Include -I../../OpenCorePkg/Include/Acidanthera -I../../OpenCorePkg/Include/Apple -I../../OpenCorePkg/Include/Apple/X64 -I../../OpenCorePkg/Include/Generic -I../../OpenCorePkg/Include/Intel -I../../OpenCorePkg/Include/Microsoft -I../../OpenCorePkg/Include/Nvidia -D NO_MSABI_VA_FUNCS -D OC_TARGET_DEBUG -I../../MdePkg/Include -I../../MdePkg/Include/Library -I../../MdePkg/Include/X64 -I../../MdePkg/Library/BaseLib -I../../MdeModulePkg/Include -I../../UefiCpuPkg/Include -include ../../OpenCorePkg/User/Include/UserPcd.h -include ../../OpenCorePkg/User/Include/UserGlobalVar.h -Werror -DEFI_TARGET32 ../../OpenCorePkg/User/Library/UserOcDummy.c -o Darwin_X64_Tool32/UserOcDummy.o

568:10: error: implicit declaration of function 'aligned_alloc' is invalid in C99 [-Werror,-Wimplicit-function-declaration]

return aligned_alloc (Alignment, Size);

^

CommonLib.c:568:10: error: incompatible integer to pointer conversion returning 'int' from a function with result type 'void *' [-Werror,-Wint-conversion]

return aligned_alloc (Alignment, Size);

^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

2 errors generated.

make[2]: *** [CommonLib.o] Error 1

Then it finally stops at.....

make[1]: *** [Common] Error 2

make[1]: *** Waiting for unfinished jobs....

cc -mmacosx-version-min=10.6 --target=x86_64-apple-darwin Darwin_X64_Tool64/ImageTool.o Darwin_X64_Tool64/Image.o Darwin_X64_Tool64/PeEmit.o Darwin_X64_Tool64/PeScan.o Darwin_X64_Tool64/ElfScan.o Darwin_X64_Tool64/BinEmit.o Darwin_X64_Tool64/UefiImageExtraActionLib.o Darwin_X64_Tool64/PeCoffInit.o Darwin_X64_Tool64/PeCoffInfo.o Darwin_X64_Tool64/PeCoffLoad.o Darwin_X64_Tool64/PeCoffRelocate.o Darwin_X64_Tool64/PeCoffHii.o Darwin_X64_Tool64/PeCoffDebug.o Darwin_X64_Tool64/UefiLib.o Darwin_X64_Tool64/UefiLibPrint.o Darwin_X64_Tool64/CpuDeadLoop.o Darwin_X64_Tool64/BaseDebugPrintErrorLevelLib.o Darwin_X64_Tool64/DebugLib.o Darwin_X64_Tool64/PrintLib.o Darwin_X64_Tool64/PrintLibInternal.o Darwin_X64_Tool64/String.o Darwin_X64_Tool64/SafeString.o Darwin_X64_Tool64/SwapBytes16.o Darwin_X64_Tool64/SwapBytes32.o Darwin_X64_Tool64/LinkedList.o Darwin_X64_Tool64/HighBitSet32.o Darwin_X64_Tool64/HighBitSet64.o Darwin_X64_Tool64/MtrrLib.o Darwin_X64_Tool64/GetPowerOfTwo32.o Darwin_X64_Tool64/GetPowerOfTwo64.o Darwin_X64_Tool64/Cpu.o Darwin_X64_Tool64/BmpSupportLib.o Darwin_X64_Tool64/SafeIntLib.o Darwin_X64_Tool64/X86GetInterruptState.o Darwin_X64_Tool64/PciLib.o Darwin_X64_Tool64/PciExpressLib.o Darwin_X64_Tool64/DevicePathUtilities.o Darwin_X64_Tool64/UefiDevicePathLib.o Darwin_X64_Tool64/DevicePathToText.o Darwin_X64_Tool64/DevicePathFromText.o Darwin_X64_Tool64/BitField.o Darwin_X64_Tool64/CheckSum.o Darwin_X64_Tool64/UefiSortLib.o Darwin_X64_Tool64/QuickSort.o Darwin_X64_Tool64/UserFile.o Darwin_X64_Tool64/CommonMemoryAllocationLib.o Darwin_X64_Tool64/CommonMemoryAllocationLibEx.o Darwin_X64_Tool64/BaseMemoryProfileLibNull.o Darwin_X64_Tool64/UserBaseMemoryLib.o Darwin_X64_Tool64/UserBootServices.o Darwin_X64_Tool64/UserGlobalVar.o Darwin_X64_Tool64/UserMath.o Darwin_X64_Tool64/UserMisc.o Darwin_X64_Tool64/UserPcd.o Darwin_X64_Tool64/UserUnicodeCollation.o Darwin_X64_Tool64/UserOcDummy.o Darwin_X64_Tool64/BaseMath.o Darwin_X64_Tool64/BaseBitOverflow.o Darwin_X64_Tool64/BaseNativeOverflow.o Darwin_X64_Tool64/BaseTripleOverflow.o Darwin_X64_Tool64/BaseAlignment.o Darwin_X64_Tool64/OcSerializeLib.o Darwin_X64_Tool64/OcTemplateLib.o Darwin_X64_Tool64/OcXmlLib.o Darwin_X64_Tool64/OcAsciiLib.o Darwin_X64_Tool64/OcUnicodeLib.o Darwin_X64_Tool64/RsaDigitalSign.o Darwin_X64_Tool64/BigNumMontgomery.o Darwin_X64_Tool64/BigNumPrimitives.o Darwin_X64_Tool64/BigNumWordMul64.o Darwin_X64_Tool64/Sha2.o Darwin_X64_Tool64/SecureMem.o Darwin_X64_Tool64/Sha512AccelDummy.o Darwin_X64_Tool64/CxxSymbols.o Darwin_X64_Tool64/MachoFat.o Darwin_X64_Tool64/Header.o Darwin_X64_Tool64/Macho32.o Darwin_X64_Tool64/Macho64.o Darwin_X64_Tool64/Relocations.o Darwin_X64_Tool64/Symbols.o Darwin_X64_Tool64/OcAppleKeysLib.o Darwin_X64_Tool64/FrequencyDetect.o Darwin_X64_Tool64/AppleCpuSupport.o Darwin_X64_Tool64/OcCpuLib.o Darwin_X64_Tool64/MeasureTicks.o Darwin_X64_Tool64/ProtocolSupport.o Darwin_X64_Tool64/DataPatcher.o Darwin_X64_Tool64/PlatformInfo.o Darwin_X64_Tool64/KernelVersion.o Darwin_X64_Tool64/OcUnicodeCollationEngCommon.o Darwin_X64_Tool64/OcVariableLib.o Darwin_X64_Tool64/UserPseudoRandom.o -o ImageTool64

No strip in DEBUG mode ImageTool32

No strip in DEBUG mode ImageTool64

gcc -O -I. -I../support/set -I../h -DUSER_ZZSYN -DZZLEXBUFSIZE=65536 -o ./antlr antlr.o scan.o err.o bits.o build.o fset2.o fset.o gen.o globals.o hash.o lex.o main.o misc.o set.o pred.o egman.o mrhoist.o fcache.o

Pccts/antlr/antlr -CC -e3 -ck 3 -k 2 -fl VfrParser.dlg -ft VfrTokens.h -o . VfrSyntax.g

Antlr parser generator Version 1.33MR33 1989-2001

VfrSyntax.g, line 3529: warning: alts 1 and 2 of {..} ambiguous upon ( ";" RefreshGuid GuidOp Locked Image EndIf InconsistentIf DisableIf SuppressIf Default GrayOutIf )

VfrSyntax.g, line 3538: warning: alts 1 and 2 of {..} ambiguous upon ( ";" RefreshGuid GuidOp Locked Image EndIf InconsistentIf DisableIf SuppressIf Default GrayOutIf )

VfrSyntax.g, line 3547: warning: alts 1 and 2 of {..} ambiguous upon ( ";" RefreshGuid GuidOp Locked Image EndIf InconsistentIf DisableIf SuppressIf Default GrayOutIf )

VfrSyntax.g, line 3557: warning: alts 1 and 2 of {..} ambiguous upon ( ";" RefreshGuid GuidOp Locked Image EndIf InconsistentIf DisableIf SuppressIf Default GrayOutIf )

VfrSyntax.g, line 3587: warning: alts 1 and 2 of {..} ambiguous upon ( ";" RefreshGuid GuidOp Locked Image EndIf InconsistentIf DisableIf SuppressIf Default GrayOutIf )

VfrSyntax.g, line 3596: warning: alts 1 and 2 of {..} ambiguous upon ( ";" RefreshGuid GuidOp Locked Image EndIf InconsistentIf DisableIf SuppressIf Default GrayOutIf )

Pccts/dlg/dlg -C2 -i -CC -cl VfrLexer -o . VfrParser.dlg

dlg Version 1.33MR33 1989-2001

make: *** [Source/C] Error 2

droples · April 15, 2023

30 minutes ago, polkaholga said:

Hi developers

Like @Matgen84 I cannot build latest version, but my problem occurs much earlier....

DEFI_TARGET64 ../../OpenCorePkg/User/Library/UserMisc.c -o Darwin_X64_Tool64/UserMisc.o

CommonLib.c:cc -MMD -MT Darwin_X64_Tool32/UserOcDummy.o -MF Darwin_X64_Tool32/UserOcDummy.d -c -fshort-wchar -Wall -Wextra -D EFIUSER -Wno-unused-parameter -Wno-implicit-fallthrough -Wno-strict-aliasing -Wno-address -mmacosx-version-min=10.6 --target=x86_64-apple-darwin -D ENTRY_POINT=main -g -O0 -D EFIUSER_DEBUG -I../../OpenCorePkg/User/Include -I../../OpenCorePkg/Include/Acidanthera -I../../OpenCorePkg/Include/Apple -I../../OpenCorePkg/Include/Apple/X64 -I../../OpenCorePkg/Include/Generic -I../../OpenCorePkg/Include/Intel -I../../OpenCorePkg/Include/Microsoft -I../../OpenCorePkg/Include/Nvidia -D NO_MSABI_VA_FUNCS -D OC_TARGET_DEBUG -I../../MdePkg/Include -I../../MdePkg/Include/Library -I../../MdePkg/Include/X64 -I../../MdePkg/Library/BaseLib -I../../MdeModulePkg/Include -I../../UefiCpuPkg/Include -include ../../OpenCorePkg/User/Include/UserPcd.h -include ../../OpenCorePkg/User/Include/UserGlobalVar.h -Werror -DEFI_TARGET32 ../../OpenCorePkg/User/Library/UserOcDummy.c -o Darwin_X64_Tool32/UserOcDummy.o

568:10: error: implicit declaration of function 'aligned_alloc' is invalid in C99 [-Werror,-Wimplicit-function-declaration]

return aligned_alloc (Alignment, Size);

^

CommonLib.c:568:10: error: incompatible integer to pointer conversion returning 'int' from a function with result type 'void *' [-Werror,-Wint-conversion]

return aligned_alloc (Alignment, Size);

^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

2 errors generated.

make[2]: *** [CommonLib.o] Error 1

Then it finally stops at.....

@polkaholgawrite the sequence of commands that you run when compiling OpenCore . What version OS and XCODE? I have no problem compiling from last OC-master on three different systems.


polkaholga · April 15, 2023

@droples

I'm on 11.7.5 (20G1225) & use Xcode 10.3 (10G8)

Download of the latest repo with Github Desktop and then I just run build_oc.tool

Edit 1:

Tried with downloading source code, build process got aborted because of too many errors 😞

Tried every older version till 0.8.5 , same story.... abortion of build process because of too many errors

I just deleted my Xcode ver. and install the latest compatible ( to my OS ), then I'll check again

Edited April 15, 2023 by polkaholga

miliuco · April 15, 2023

@polkaholga

I have no problem building on Ventura + Xcode 14.1 as @droples

Building by build_oc.tool.

droples · April 15, 2023

5 minutes ago, polkaholga said:

@droples

I'm on 11.7.5 (20G1225) & use Xcode 10.3 (10G8)

Download of the latest repo with Github Desktop and then I just run build_oc.tool

On 11.7.7 I use Xcode 12.4 and everything compiles successfully. There are problems on XCODE << 12.0

Matgen84 · April 15, 2023

1 hour ago, droples said:

@polkaholgawrite the sequence of commands that you run when compiling OpenCore . What version OS and XCODE? I have no problem compiling from last OC-master on three different systems.

Hi @droples Like @polkaholga I can't build using build_oc.tool ( Xcode 12.4 on Catalina) after updating local repo. To solve this problem, I git clone a new directory

Edited April 15, 2023 by Matgen84

polkaholga · April 15, 2023

@droples, @miliuco

Installed Xcode 13.2.1 and now it's without errors again.

Checking schema mUefiOutputSchema

Checking schema mUefiReservedMemoryEntrySchema

Checking schema mUefiReservedMemorySchema

Checking schema mUefiConfigurationSchema

Checking schema mRootConfigurationNodes

Saving session...

...copying shared history...

...saving history...truncating history files...

...completed.

Anyway I find this weird because I built all OC versions ( as far as I remember 0.0.4 was my first one ) til 0.9.0 with 10.3 and did have only once a small issues not too long ago.

Alpha22 · April 17, 2023

question: if I set ScanPolicy 2687747 in the log I have OCB: Invalid file system policy (0/290303) for 319A7518
instead if I set ScanPolicy 0 I don't have that error, if it is an error

Spoiler

27:501 00:092 OCPI: Partition table not supported
27:584 00:082 OCPI: Failed to retrieve disk info
27:666 00:081 OCB: Missing partition info for 319A7518
27:696 00:030 OCB: Invalid file system policy (0/290303) for 319A7518
27:777 00:081 OCB: Adding fs 319A7518 (E:1|L:1|P:Security Violation)

advice

Edited April 17, 2023 by Alpha22

eSaF · April 17, 2023

35 minutes ago, Alpha22 said:

question: if I set ScanPolicy 2687747 in the log I have OCB: Invalid file system policy (0/290303) for 319A7518
instead if I set ScanPolicy 0 I don't have that error, if it is an error

You cannot just use that value on it's own as you've found out with the error.

That value is used in conjunction with Misc/Entries in the config.plist when dual booting with i.e Windows but you need to find the correct path of the windows disk on your machine like my example. If the correct path is not correct, you will still get the error with that value. If you're not dual booting, then the '0' value is fine.

@miliuco - Has a great tutorial/walk through on 'How to Custom Entry in Opencore to boot Windows' to find the path of the disk and what you need to do.

PS Don't use the example in the Sample Config.plist as it is Generic and only there as an illustration or guide, you need to find your own on your machine.

Spoiler

Edited April 17, 2023 by eSaF

miliuco · April 17, 2023

@Alpha22

I'm afraid that there is an issue with this volume (partition table error, maybe fixable by First aid in Disk Utility or equivalent in the filesystem of the volume). Is it NTFS?

Maybe setting it to 0 (will allow all sources present to be bootable) doesn't check the volumes (all are accepted as bootable without further ado) while any other numeric value checks the volumes included in ScanPolicy and hence the error. But I'm not sure about this.

Alpha22 · April 17, 2023

from the guide given by eSaF the map> map_table.txt command is wrong

dualboot: macOS Ventura -> Volume di sistema APFS Windows 11 File System Windows NT (NTFS)

eSaF · April 17, 2023

11 minutes ago, Alpha22 said:

from the guide given by eSaF the map> map_table.txt command is wrong

From memory (then again could be early signs of dementia that comes with old age) this is what worked for me............. map > map-table-windows.text.

Apart from @miliuco Guide, there is another one and this is where Google temporarily becomes your best friend.

What I posted was copied from part of a tutorial although I can remember which one..............Dementia (inserted here about).

Edited April 17, 2023 by eSaF

Alpha22 · April 17, 2023

54 minutes ago, eSaF said:

From memory (then again could be early signs of dementia that comes with old age) this is what worked for me............. map > map-table-windows.text.

Apart from @miliuco Guide, there is another one and this is where Google temporarily becomes your best friend.

What I posted was copied from part of a tutorial although I can remember which one..............Dementia (inserted here about).

map > map-table-windows.text is right

executed by guide, Misc/Entries in config.plist but still same problem

Quote

17:908 00:022 OCPI: Partition table not supported
17:977 00:069 OCPI: Failed to retrieve disk info
17:997 00:020 OCB: Missing partition info for 319A7518
18:070 00:072 OCB: Invalid file system policy (0/290303) for 319A7518

eSaF · April 17, 2023

20 minutes ago, Alpha22 said:

executed by guide, Misc/Entries in config.plist but still same problem

I don't know man I followed @miliuco Guide and mine is correct.

I will post a couple of pics to show how it is on my rig.

PS - This is how mine looks after finding the path of Windows volume and entry made in Misc/Entries.

The path has to be exactly as printed out by Shell.

Spoiler

Edited April 17, 2023 by eSaF

Alpha22 · April 17, 2023

4 minutes ago, eSaF said:

I don't know man I followed @miliuco Guide and mine is correct.

I will post a couple of pics to show how it is on my rig.

followed this guide:

eSaF · April 17, 2023

Just now, Alpha22 said:

followed this guide:

Ok did you find and verified the EFI Partition of the volume you want to make the entry?

Like I said, it must be copied exactly as it appears and entered into the config.plist.

I have to go out so I will be away from my p/c for approx: an hour or so, maybe @miliuco can chip in with some input if he's available.

Alpha22 · April 17, 2023

Re-checked everything, but still the same problem

Edited April 17, 2023 by Alpha22

eSaF · April 17, 2023

42 minutes ago, Alpha22 said:

Re-checked everything, but still the same problem

When you checked in Shell did you find the EFI Partition of Windows and did you make a note of it so that you can select the right one that was recorded in text form on the EFI Partition of your boot volume?

It is a tedious operation but you have to get it absolutely right because it won't work otherwise. I have tried to depict what the format is in the attached Pic as best as I can remember.

I am sure the Guide provided by @miliuco and the other one is still very much relevant to get the desired result.

Edited April 17, 2023 by eSaF

miliuco · April 17, 2023

@Alpha22

No more ideas.

Maybe you have to post this issue as a separate thread, here it's hidden and probably you'll get more help as standalone post.

eSaF · April 17, 2023

1 minute ago, miliuco said:

@Alpha22

No more ideas.

Maybe you have to post this issue as a separate thread, here it's hidden and probably you'll get more help as standalone post.

I agree.

MakAsus · April 19, 2023

Came to Israel, my old hardware build and I installed macOS 12.6.5 (21G531). Installed in this way: Using OpenCore Legacy Patcher v.0.6.4 - download the OS and create an installation flash drive, then follow the instructions

edit Sample.plis, rename it to Config.plist, downloaded the necessary drivers and the latest kexts for my hardware. I put it all of them on EFI partition to the suitable in OC folders on the flash drive.

Everything was successfully installed (including after installation patches) and loaded into the desktop, but here's the oddity: It loads - not every time. That is, if you turn on the power button and do not press anything else, then the boot is usually normal, but if you select another partition (I have two different macOS on various volumes), then a black screen appears for a few seconds and then appears again the OS selection menu and so on in a circle. I don’t know where to dig, since logs are not created in this case. If you use the built-in Picker instead of OpenCanopy, then everything is OK. Can you see where I messed up? I am new to OpenCore. Iron earned everything except sleep.

opencore-2023-04-17-223314.txt EFI.zip

Stefanalmare · April 19, 2023

1 hour ago, MakAsus said:

Came to Israel, my old hardware build and I installed macOS 12.6.5 (21G531). Installed in this way: Using OpenCore Legacy Patcher v.0.6.4 - download the OS and create an installation flash drive, then follow the instructions

edit Sample.plis, rename it to Config.plist, downloaded the necessary drivers and the latest kexts for my hardware. I put it all of them on EFI partition to the suitable in OC folders on the flash drive.

Everything was successfully installed (including after installation patches) and loaded into the desktop, but here's the oddity: It loads - not every time. That is, if you turn on the power button and do not press anything else, then the boot is usually normal, but if you select another partition (I have two different macOS on various volumes), then a black screen appears for a few seconds and then appears again the OS selection menu and so on in a circle. I don’t know where to dig, since logs are not created in this case. If you use the built-in Picker instead of OpenCanopy, then everything is OK. Can you see where I messed up? I am new to OpenCore. Iron earned everything except sleep.

opencore-2023-04-17-223314.txt 256 kB · 3 downloads EFI.zip 9.19 MB · 6 downloads

OCLP it is JUST for real MAC's. For sure we can use it to see the patches and adapt them to our needs and hardware, but not to use the EFI generated by OCLP. The only thing that can be done directly in non Macintosh machine by OCLP is post install root patch (thanks to OCLP devs), to fix graphics an occasionally other things (USB1,1).

To build an opencore EFI for hackintosh use this:

https://dortania.github.io/OpenCore-Install-Guide/

After, if you want Monterey or Ventura and the processor is unsupported, OCLP become source of inspiration.

Edited April 19, 2023 by Stefanalmare

MakAsus · April 19, 2023

7 hours ago, Stefanalmare said:

OCLP it is JUST for real MAC's. For sure we can use it to see the patches and adapt them to our needs and hardware, but not to use the EFI generated by OCLP. The only thing that can be done directly in non Macintosh machine by OCLP is post install root patch (thanks to OCLP devs), to fix graphics an occasionally other things (USB1,1).

To build an opencore EFI for hackintosh use this:

https://dortania.github.io/OpenCore-Install-Guide/

After, if you want Monterey or Ventura and the processor is unsupported, OCLP become source of inspiration.

I did everything just like that, only with the help of OCLP I made a USB flash drive, because it turned out to be convenient for them to download and prepare a usb media. And I set up OpenCore with my hands according to the manual. The question is: Why does everything load normally with the built-in picker, but not every time with OpenCanopy? There is no critical errors in the logs. 🤔

OpenCore General Discussion

Recommended Posts

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites

Link to comment

Share on other sites
