James Drake Posted November 11, 2011 Share Posted November 11, 2011 also, it seems that after a cable has been plugged and unplugged, that ethernet port will no longer work until you reboot. Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1769850 Share on other sites More sharing options...
CooSee Posted November 23, 2011 Share Posted November 23, 2011 a few days ago there's a annoying misbehaviour with the Intel 82574L, tried 1.6.2, too! on W7 no probs. with the onboard LAN everything's ok ! It worked before, now i get these weird glitches CooSee ' Ya Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1772942 Share on other sites More sharing options...
hnak Posted December 5, 2011 Author Share Posted December 5, 2011 ok not for me then... might be a job for lnx2mac, i will ask over there... I have ported the driver (AppleIGB.kext). It might work with your hardware. 1 Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1775849 Share on other sites More sharing options...
hnak Posted January 1, 2012 Author Share Posted January 1, 2012 Incorporated Linux 1.9.5 changes. Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1782597 Share on other sites More sharing options...
xbb Posted January 21, 2012 Share Posted January 21, 2012 1.9.5 works for me but I can't use anything above 4000 mtu. If I do I lose connection (but the interface is still up) after a short while and nothing works until i up it manually. 1.3.7 was working fine instead. Also, is there a way to enable polling? Thanks! Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1788015 Share on other sites More sharing options...
hnak Posted January 24, 2012 Author Share Posted January 24, 2012 1.9.5 works for me but I can't use anything above 4000 mtu. If I do I lose connection (but the interface is still up) after a short while and nothing works until i up it manually. 1.3.7 was working fine instead. Also, is there a way to enable polling? Thanks! I will check if the jumbo frame code has memory leak or something. By the way, how do you utilize polling, maybe debugger ? Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1788941 Share on other sites More sharing options...
xbb Posted January 24, 2012 Share Posted January 24, 2012 I will check if the jumbo frame code has memory leak or something. By the way, how do you utilize polling, maybe debugger ? I thought polling was lowering CPU usage, I can enable it with FreeBSD (drivers must support it), I don't know if you can enable it also on OSX, maybe it's just related to FreeBSD? Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1789008 Share on other sites More sharing options...
hnak Posted January 24, 2012 Author Share Posted January 24, 2012 I thought polling was lowering CPU usage, I can enable it with FreeBSD (drivers must support it), I don't know if you can enable it also on OSX, maybe it's just related to FreeBSD? sendPacket/receivePacket are OSX polling entries, however, they are used by kernel debuggers only ( from the comment in IONetworkController.h ). Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1789018 Share on other sites More sharing options...
Klonkrieger2 Posted February 9, 2012 Share Posted February 9, 2012 Has anyone any idea why my lan controller (82579LM) sporadically resets my router (Fritz!Box 7270)? No (speciel) entries in the console... Edit: I'm sorry, it was a problem with the router firmware. the lan controller works perfectly! Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1794694 Share on other sites More sharing options...
howmany Posted March 7, 2012 Share Posted March 7, 2012 I have the intel 82579 LM on my Dell Optiplex 990, and hrak's kext works beautifully, except: There's no option for WOL in my energy preferences. I have it enabled in my bios. Do I need to modify the kext? Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1803981 Share on other sites More sharing options...
Vlad Posted April 13, 2012 Share Posted April 13, 2012 does anyone have problems with pppoe connection when using this kext? can you post the sourcecode please ? i'm interested in contributing to this kext development cause i am affected by it's functionality Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1813256 Share on other sites More sharing options...
hnak Posted April 14, 2012 Author Share Posted April 14, 2012 does anyone have problems with pppoe connection when using this kext? can you post the sourcecode please ? i'm interested in contributing to this kext development cause i am affected by it's functionality I have just uploaded 1.10.6. Have you read the readme.txt ? The code is availabe at osx86drivers.sourceforge.net from the beginning. PPPoE does nothing special and there is no API/framework entries for it. Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1813514 Share on other sites More sharing options...
xbb Posted April 14, 2012 Share Posted April 14, 2012 I have just uploaded 1.10.6. Have you read the readme.txt ? The code is availabe at osx86drivers.sourceforge.net from the beginning. PPPoE does nothing special and there is no API/framework entries for it. Thanks, I'm going to test if jumbo frames work again later Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1813515 Share on other sites More sharing options...
hnak Posted April 21, 2012 Author Share Posted April 21, 2012 They released 1.11.3, so did I. Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1815122 Share on other sites More sharing options...
brycv Posted April 25, 2012 Share Posted April 25, 2012 A few of us are seeing some errors with the latest 1.11.3 but they don't appear to be there on the previous version. The errors are all with 82579V Ethernet on Z68 and Z77 systems. This is the output in kernel.log. Apparently this prevents sleep for some. I didn't notice any problems until I checked my kernel.log. 4/25/12 8:23:02.000 AM kernel: AppleIntelE1000e(Err): Detected Hardware Unit Hang: 4/25/12 8:23:02.000 AM kernel: TDH <b0> 4/25/12 8:23:02.000 AM kernel: TDT <b0> 4/25/12 8:23:02.000 AM kernel: next_to_use <b0> 4/25/12 8:23:02.000 AM kernel: next_to_clean <b0> 4/25/12 8:23:02.000 AM kernel: buffer_info[next_to_clean]: 4/25/12 8:23:02.000 AM kernel: time_stamp <0> 4/25/12 8:23:02.000 AM kernel: next_to_watch <b0> 4/25/12 8:23:02.000 AM kernel: next_to_watch.status <0> 4/25/12 8:23:02.000 AM kernel: MAC Status <40080083> 4/25/12 8:23:02.000 AM kernel: PHY Status <796d> 4/25/12 8:23:02.000 AM kernel: PHY 1000BASE-T Status <3800> 4/25/12 8:23:02.000 AM kernel: PHY Extended Status <3000> 4/25/12 8:23:02.000 AM kernel: PCI Status <10> Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1816090 Share on other sites More sharing options...
Klonkrieger2 Posted April 25, 2012 Share Posted April 25, 2012 same entries here with a 82579LM. Sleep is working anyway Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1816121 Share on other sites More sharing options...
hnak Posted April 26, 2012 Author Share Posted April 26, 2012 The driver hangs correctly when it is about to stop. So the orignial code to report hang checks if it is in terminating process. I just removed the check as I thought it would never bother users. It seems untrue for sleep/resume users. Though it is a normal operation, I will add some check in the next version. Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1816203 Share on other sites More sharing options...
brycv Posted April 26, 2012 Share Posted April 26, 2012 The driver hangs correctly when it is about to stop. So the orignial code to report hang checks if it is in terminating process. I just removed the check as I thought it would never bother users. It seems untrue for sleep/resume users. Though it is a normal operation, I will add some check in the next version. Thank you. I appreciate it. Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1816328 Share on other sites More sharing options...
ayuayu129 Posted April 28, 2012 Share Posted April 28, 2012 Hi hnak I have 0x1503 device on P8Z68-V/GEN3. As Cipolippo said in this topic, the driver seems not to work correctly on this board. First I connected LAN to Intel port, IP was not assigned (yellow icon in Network PrefPane). Then I set it "Manually" or "Using DHCP with manual address", the icon is turned green, but no internet connection. Browser and other applications show that request is timed out. I tried all version supporting 10.7, and got same result. Could you tell me how to solve this? Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1816683 Share on other sites More sharing options...
hethwt Posted April 28, 2012 Share Posted April 28, 2012 A few of us are seeing some errors with the latest 1.11.3 but they don't appear to be there on the previous version. The errors are all with 82579V Ethernet on Z68 and Z77 systems. This is the output in kernel.log. Apparently this prevents sleep for some. I didn't notice any problems until I checked my kernel.log. 4/25/12 8:23:02.000 AM kernel: AppleIntelE1000e(Err): Detected Hardware Unit Hang: 4/25/12 8:23:02.000 AM kernel: TDH <b0> 4/25/12 8:23:02.000 AM kernel: TDT <b0> 4/25/12 8:23:02.000 AM kernel: next_to_use <b0> 4/25/12 8:23:02.000 AM kernel: next_to_clean <b0> 4/25/12 8:23:02.000 AM kernel: buffer_info[next_to_clean]: 4/25/12 8:23:02.000 AM kernel: time_stamp <0> 4/25/12 8:23:02.000 AM kernel: next_to_watch <b0> 4/25/12 8:23:02.000 AM kernel: next_to_watch.status <0> 4/25/12 8:23:02.000 AM kernel: MAC Status <40080083> 4/25/12 8:23:02.000 AM kernel: PHY Status <796d> 4/25/12 8:23:02.000 AM kernel: PHY 1000BASE-T Status <3800> 4/25/12 8:23:02.000 AM kernel: PHY Extended Status <3000> 4/25/12 8:23:02.000 AM kernel: PCI Status <10> I'm getting the same, but I can't sleep either. I don't know if something else is going on or not, but the only thing I changed was off of the realtek nic to the intel PCI-E nic. Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1816696 Share on other sites More sharing options...
hnak Posted April 28, 2012 Author Share Posted April 28, 2012 I'm getting the same, but I can't sleep either. I don't know if something else is going on or not, but the only thing I changed was off of the realtek nic to the intel PCI-E nic. Does sleep work with previous versions - for example, 1.10.6 ? Hi hnak I have 0x1503 device on P8Z68-V/GEN3. As Cipolippo said in this topic, the driver seems not to work correctly on this board. First I connected LAN to Intel port, IP was not assigned (yellow icon in Network PrefPane). Then I set it "Manually" or "Using DHCP with manual address", the icon is turned green, but no internet connection. Browser and other applications show that request is timed out. I tried all version supporting 10.7, and got same result. Could you tell me how to solve this? Unfortunately, I cannot fix a problem which is not reproducible with my own hardware. I hope someone who has the same problem as well as programming skill fix it... Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1816761 Share on other sites More sharing options...
brycv Posted April 29, 2012 Share Posted April 29, 2012 I can confirm that with 1.10.6 and the Intel 82579V chip on both the Gigabyte G1.Sniper M3 and Asus Sabertooth Z77 manual sleep works fine. Energy Saver sleep is not working on the G1.Sniper M3 but I don't think that is related. Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1816931 Share on other sites More sharing options...
hnak Posted April 30, 2012 Author Share Posted April 30, 2012 I have uploaded a version which just suppresses TxHung warnings. Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1816975 Share on other sites More sharing options...
brycv Posted May 4, 2012 Share Posted May 4, 2012 Thanks hnak. The updated version works perfectly and I have confirmation from another user that it works 100% with sleep and all. Thank you! Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1817910 Share on other sites More sharing options...
hnak Posted May 19, 2012 Author Share Posted May 19, 2012 They released 2.0.0 on e1000.sourceforge.net and I incorporated the changes. I also enabled VLAN. Link to comment https://www.insanelymac.com/forum/topic/205771-appleintele1000ekext-for-108107106105/page/7/#findComment-1821603 Share on other sites More sharing options...
