GeForce 200 series support

EGOvoruhk

By EGOvoruhk,
in nVidia

 Share
638 posts in this topic

Recommended Posts

javi mahai
javi mahai
Posted
Posted

Great work everyone.



I got a system with 2x GT200 boards now working quite nicely now on OSX (except for the second DVI port on each of the boards).



However, I am having a tough time getting CUDA to work now. I reinstalled both the tookit/kext and the SDK and CUDA still refuses to acknowledge there is any NVIDIA card for it to use. Even though the CUDA kext is loaded.



Anyone having the same issues regarding CUDA?


totentanz
totentanz
Posted
Posted

Wow, this is great! So what would be the procedure for a fresh Retail 10.5.7 + Chameleon v2.0 RC1 install like the one detailed here? Would I need to run the install first with another video card first, then install the GX 200 drivers, shut down, swap the cards, and reboot?

netkas
netkas
Posted
Posted
Great work everyone.



I got a system with 2x GT200 boards now working quite nicely now on OSX (except for the second DVI port on each of the boards).



However, I am having a tough time getting CUDA to work now. I reinstalled both the tookit/kext and the SDK and CUDA still refuses to acknowledge there is any NVIDIA card for it to use. Even though the CUDA kext is loaded.



Anyone having the same issues regarding CUDA?



was the vram amount of both cards recognized properly

sam3
sam3
Posted
Posted

Thanks - but couldnt get it to work on my machine,

Just got stuck at a black screen at boot (using the drivers and netkas enabler).

This was using lawlessppc 10.5.4 .



I tried installing ideneb v1.3 (with nforce patch too) and v1.4 with no luck (got stuck at detecting root device during startup). Tried changing graphics card to 8600gts and still wouldnt install.



Anyone know any other good distros for amd phenom procs (amd hammer chipset)



Thanks

jammycow
jammycow
Posted
Posted

i just have to reply to say thank you netkas and to everyone else for their hard work - am now very happily running my GTX 260 on my Gigabyte EX58-UD5. CI/QE are now hardware accelerated with 896MB VRAM - and it runs sweeeeeet!



as for install - removed NVinject kext and old geforce kext's, installed drivers and injectors, rebooted and rebuilt caches, all as per others have said earlier in this thread.

javi mahai
javi mahai
Posted
Posted
was the vram amount of both cards recognized properly



Everything works fine now with the latest CUDA driver from the irc. Thanks Netkas!



BTW, the GTXs are kinda picky when they initialize the PCI-E (i.e. if having more than 1 which one decides to be the display for the BIOS, etc). So make sure your mobo settings are taking care of that, esp. regarding PCI memory remap, PEG port initialization (those are the main things to check in my ASUS mobo, dunno about other brands).



Cheers, and again... great work!

radov4n
radov4n
Posted
Posted

javi, does deviceQuery (in CUDA samples) detect shader clock properly on your cards?

for some reason it doesn't on my gtx 260's, should be 1.2 ghz, detects as 600 mhz.



i am also somewhat sad about the speed of CUDA on macos, non-graphical samples run as fast as xp cuda, but when it comes to CUDA-opengl interop performance blows completely.

asfastas63
asfastas63
Posted
Posted

Just got my 280 set up on my iPC 10.5.6 build.



1. Deleted the following kexts.



GeForce.kext

NVDANV40Hal.kext

NVDANV50Hal.kext

NVDAResman.kext

NVinject.kext



2. No reboot, install package, then install enabler.



3. Swap cards, reboot, and viola!



Note: As previously stated, multiple monitors does not work, and will not display anything if both cables are plugged in. Pull out the cable and one display works fine.



Thanks to netkas and everyone on this thread, I've been waiting for this for a long, long time!




javi mahai
javi mahai
Posted
Posted
javi, does deviceQuery (in CUDA samples) detect shader clock properly on your cards?

for some reason it doesn't on my gtx 260's, should be 1.2 ghz, detects as 600 mhz.



i am also somewhat sad about the speed of CUDA on macos, non-graphical samples run as fast as xp cuda, but when it comes to CUDA-opengl interop performance blows completely.



Hmmm... In my case deviceQuery picks up the correct frequency for my shaders (1.5 Ghz), it seems that your cards are stuck in the low throttle state (I think the GT200 parts have 3 speed levels for their shaders/cores) and aren't kicking out of it.



I haven't noticed any significant slowdown between my linux CUDA code and the version I just compiled for OSX. Although my GL calls are minimal, so I may not be stressing that part of the driver. For normal computation, as I said... I don't see an appreciable slowdown when I time them between linux and OSX.

radov4n
radov4n
Posted
Posted
Hmmm... In my case deviceQuery picks up the correct frequency for my shaders (1.5 Ghz), it seems that your cards are stuck in the low throttle state (I think the GT200 parts have 3 speed levels for their shaders/cores) and aren't kicking out of it.



I haven't noticed any significant slowdown between my linux CUDA code and the version I just compiled for OSX. Although my GL calls are minimal, so I may not be stressing that part of the driver. For normal computation, as I said... I don't see an appreciable slowdown when I time them between linux and OSX.



Nod, thanks, I'll look into it.

I am not sure about Linux, never tried CUDA on it. If you have access to XP machine, try running smoke and fluids demo on XP and OS X and compare. It's about 5x performance difference in my case.

Papek_SVK
Papek_SVK
Posted
Posted

Hey guys, can someone write step-by-step guide what exactly i have to do? I tried install drives x-times but still with no result. I'm absolutely noob at Mac so pls have a patience. First removed GeForce.kext (if there is one), NVDANV40Hal.kext, NVDANV50Hal.kext, NVDAResman.kext, NVinject.kext, installed the package, then downloaded latest_nvinject_0.2.1.zip, opened it and installed with kext helper. Also tried other version of nvinject and some universal injector (found with google). But I still getting this



Graphics by NVIDIA:

 Chipset Model:	Graphics by NVIDIA
 Type:	Display
 Bus:	PCIe
 PCIe Lane Width:	x16
 VRAM (Total):	256 MB
 Vendor:	NVIDIA (0x10de)
 Device ID:	0x05e2
 Revision ID:	0x00a1
 ROM Revision:	NVinject 0.2.1
 Displays:
ASUS VK222H:
 Resolution:	1680 x 1050 @ 60 Hz
 Depth:	32-bit Color
 Core Image:	Software
 Main Display:	Yes
 Mirror:	Off
 Online:	Yes
 Quartz Extreme:	Not Supported
Display Connector:
 Status:	No display connected



pc: C2D E8400, ASUS P5Q-E with modified bios, Gigabyte GTX260 896MB, 4GB DDR2, blackmagic hd extreme .... everything else works well, only that stupid graphics not



Thanks for each advise.

Papek.

farhad avari
farhad avari
Posted
Posted
What is your card?

Is dual display work for you?





i have only one display but it is connected via vga to dvi connecter nearest to the mother board n its a zotac gtx295



also the second core on the card only shows 512mb instead of 896 unlike the one in the screenshot n i dont know if the second core has hardware acceleration.



using 10.5.5

cinema32
cinema32
Posted
Posted

First of all thanks netkas!



I have my Club3d Gtx 260 running like a dream in 10.5.7 on a Asus p5q modified bios 2002 with C2Q Q 9550 overclocked to 3,72 Ghz. Same as most others in this thread; no dual output. Performance increase from 8600 GTS is disappointing. Flashed the GTX260 with firmware modified to overclock values that were stable in Windows (rivatuner) and saw hardly any speed increase in OSX. (The overclocked values were mega; +/- 18%. In Windows the card was only becoming unstable at around 23%+ GPU and RAM speed)



Does anybody know if the OSX drivers override BIOS speed settings and if so, can the driver side speedsettings be modified withe hexedit?



Just bought a GTX 285 will need to fly about 13 Hours before I can test it. If needed I'll flash it later on with a mac bios.

unext
unext
Posted
Posted
Cool! Could you post the EFI string or tell us how to generate one?







I followed aqua-mac's instructions here http://aquamac.proboards.com/index.cgi?boa...&thread=569





its a little shifty with the sound and every now and again it pops out. I had it working as a 9500GT with the efi strings I got from that and surprise to me it worked and no problems. I think I might go back to that.







*EDIT

It seems to work great now that I reinstalled the kernel my bad.



thanks aqua for the info
