Hi all!



Today I have tryed AGPGart 2.7 + IOPciFamily 2.4.4



Results:

AGPGart 2.7 + IOPciFamily 2.4.4 + GeForceGA.plugin 1.4.58 = Blue screen without cursor

AGPGart 2.7 + IOPciFamily 2.4.4 works without QE/CI. Xbench's OpenGL test hanged computer.



My ioreg, dmesg, screen are here http://rapidshare.com/files/126123299/for_Slice_1.zip.html

See FAQ

http://forum.insanelymac.com/index.php?showtopic=113396

Link to comment
Share on other sites
rjstrat
rjstrat
Posted
Posted

Hi Slice,

Thanks for your wonderful work, it is greatly appreciated by all :)

Have you heard of anyone with good AGP_Base value for i865g ? ID:80862571 Slice AGP270,AGP267,AGP265f

I've tried all from your faq, most go thru to end of boot sequence and stick on black screen with mouse curser, and only 0xe8000000 gave multi colored vertical lines, but able to make out desktop underneath.

After trying other values with no success, I've gone back to 0xe8000000, but cannot repeat vertical lines, just black screen with mouse again.

I have device resources from windows Everest - don't Know if it helps :D Also attached ioreg and dmesg with AGP_Base: 0x10000000

10.4.11 Tiger, Slice AGP270, Slice IOPCI 2.44

Thanks,

rj







Link to comment
Share on other sites
Slice
Slice
Posted
  • Author
Posted

2 rjstrat

I think a better AGP_Base for you =0x08000000





The project is suspended until I get hardware OpenGL for me.

I need your OpenGL application's crash log!

Link to comment
Share on other sites
rjstrat
rjstrat
Posted
Posted

Hi Slice,

I went back to 0x08000000, still no boot to GUI, with GUI AGPGart doesn't load.

If you give me procedure to generate open gl crash, I will test whatever you need.

Thanks again for great work,

rj

Link to comment
Share on other sites
Slice
Slice
Posted
  • Author
Posted
Hi Slice,

I went back to 0x08000000, still no boot to GUI, with GUI AGPGart doesn't load.

If you give me procedure to generate open gl crash, I will test whatever you need.

Thanks again for great work,

rj

Try to boot without GA.plugin and launch Chess or XBench or OpenGL Extension Viewer. Then launch Console and find crash log.

Link to comment
Share on other sites
toadspit
toadspit
Posted
Posted

Slice: sorry but I somehow broke my setup last week (my osx86 partition was not readable anymore, and I could neither repair it from my second working partition !)

So I have to setup my installation again.

I will be back ASAP!

Link to comment
Share on other sites
Rikad Rahman
Rikad Rahman
Posted
Posted

Is there any soft to build driver for mac from linux drivers or source?



I need to build a driver for chrome9 integrated agp.



I have drivers of all version of linux and also the source.



Plz help me to build the driver or give me any useful link.



Thanks

Link to comment
Share on other sites
Slice
Slice
Posted
  • Author
Posted
Is there any soft to build driver for mac from linux drivers or source?



I need to build a driver for chrome9 integrated agp.



I have drivers of all version of linux and also the source.



Plz help me to build the driver or give me any useful link.



Thanks

We are making Radeon driver from Linux sources. You can go the same way. Join us!

http://forum.insanelymac.com/index.php?showforum=160

Link to comment
Share on other sites
rjstrat
rjstrat
Posted
Posted

Hi Slice,

I can't seem to find detailed log for open gl crash thru console, only this: 2008-07-07 17:59:35.983 Chess[238] invalid drawable

2008-07-07 17:59:47.236 Chess[238] invalid drawable

2008-07-07 17:59:50.323 Chess[238] invalid drawable

2008-07-07 18:02:04.168 Xbench[246] invalid drawable

2008-07-07 18:02:04.206 Xbench[246] invalid drawable

2008-07-07 18:02:04.224 Xbench[246] invalid drawable

2008-07-07 18:04:51.447 DiskImages UI Agent[255] Could not find image named 'background'.

2008-07-07 18:06:01.827 OpenGL Extensions Viewer[267] Error attaching drawable

2008-07-07 18:09:24.376 OpenGL Extensions Viewer[267] Error attaching drawable

where do I find detailed log?

Thanks

Link to comment
Share on other sites
Slice
Slice
Posted
  • Author
Posted
Hi Slice,

I can't seem to find detailed log for open gl crash thru console, only this: 2008-07-07 17:59:35.983 Chess[238] invalid drawable

2008-07-07 17:59:47.236 Chess[238] invalid drawable

2008-07-07 17:59:50.323 Chess[238] invalid drawable

2008-07-07 18:02:04.168 Xbench[246] invalid drawable

2008-07-07 18:02:04.206 Xbench[246] invalid drawable

2008-07-07 18:02:04.224 Xbench[246] invalid drawable

2008-07-07 18:04:51.447 DiskImages UI Agent[255] Could not find image named 'background'.

2008-07-07 18:06:01.827 OpenGL Extensions Viewer[267] Error attaching drawable

2008-07-07 18:09:24.376 OpenGL Extensions Viewer[267] Error attaching drawable

where do I find detailed log?

Thanks


Link to comment
Share on other sites
rjstrat
rjstrat
Posted
Posted

Hi Slice,

I've been through entire console tree, the only crash log I have is for DVD Player.

All that I can find is the info I gave in previous post. Xbench open gl test and Chess both show only white screen, but do not generate .crash.log, open gl extensions prog opens,

runs software open gl test ok, but crashes on hardware open gl tests, still no .crash.log.

What am I doing wrong ? :( , these apps don't work, but never generate .crash.log.

Help!

Link to comment
Share on other sites
Slice
Slice
Posted
  • Author
Posted
Hi Slice,

I've been through entire console tree, the only crash log I have is for DVD Player.

All that I can find is the info I gave in previous post. Xbench open gl test and Chess both show only white screen, but do not generate .crash.log, open gl extensions prog opens,

runs software open gl test ok, but crashes on hardware open gl tests, still no .crash.log.

What am I doing wrong ? :( , these apps don't work, but never generate .crash.log.

Help!

If it crashes it must produce crash.log. Check once more. If you have screen without image - other story. I need to think what to do.

Link to comment
Share on other sites
Slice
Slice
Posted
  • Author
Posted

For nVidia users.

I recompile AppleFlashNVRAM.

Don't know if it influences on somewhat. If Yes we may be needed to correct it for AGP mode.

Link to comment
Share on other sites
aitikin
aitikin
Posted
Posted

Just FYI Slice, the AppleFlashNVRAM allowed me to boot into a gui with both 2.6.7 and 2.7.0, but it doesn't give me opengl, even with all the GeForce bndles and kernel extensions. Anything I can give you that may help?



EDIT: I should point out that I have a GeForce 6600GT.

Link to comment
Share on other sites
ttinsb
ttinsb
Posted
Posted

Hi, i am totaly new to Mac OS.



I am using the iATKOS 2.0i on a Asrock 4CoreDual Board with VIA VT8xx Chipset and a Nvdia 7600GT AGP card.



The only drivers that does not freeze is AGPGart 2.1 and 2.2. At the moment i am using 2.2



With both i got only 1024x768 pixels and no QE.

My Display is a Neovo F-419 (19" TFT) with 1280x1024 native resolution, connected via DVI).



Display:



Type: Display

Bus: AGP

VRAM (Total): 256 MB

Vendor: NVIDIA (0x10de)

Device ID: 0x02e0

Revision ID: 0x00a2

Displays:

Display:

Resolution: 1024 x 768

Depth: 32-bit Color

Core Image: Software

Main Display: Yes

Mirror: Off

Online: Yes

Quartz Extreme: Not Supported



How can i activate QE and change the resolution?



Thanx in adivce & sorry for my bad english :)

Link to comment
Share on other sites
ttinsb
ttinsb
Posted
Posted

sorry, i forget to mention:

The FAQ says: "1. Look GA.plugin/info.plist. You must edit it to..."



Sorry, but i don't find a GA.plugin Folder.



I have a Folder "AGPGart.kext. Inside is a Folder "Contents" with a File called "Info.plist" and a Subfolder Resources which contains also a file Info.plist.

Which one have to be modified?



"2. Aperture size must be 64Mb or 128Mb. Else - software QE only!"



Is this a BIOS Setting, or a setting inside of AGPGart or somewhere else?



Sorry for my stupid questions.

Link to comment
Share on other sites
toadspit
toadspit
Posted
Posted
sorry, i forget to mention:

The FAQ says: "1. Look GA.plugin/info.plist. You must edit it to..."



Sorry, but i don't find a GA.plugin Folder.



For you (NVIDIA) it means "GeForceGA.plugin"



"2. Aperture size must be 64Mb or 128Mb. Else - software QE only!"



Is this a BIOS Setting, or a setting inside of AGPGart or somewhere else?



Sorry for my stupid questions.



BIOS setting
