Genty Posted April 19, 2015 Share Posted April 19, 2015 I made new kext as an addition to HWSensors v3.3. Compatibility with OS 10.6 - 10.10 Currently it show only CPU temperature. May be later I make voltage and frequencies. Voluntaries welcomed. I am not sure with kozlek's project compatibility. Test with precations. (kozlek's version is not newer. It is a branch with own enumeration) Manual testing without installation: sudo -s chown -R root:wheel ~/Downloads/AmdCPUMonitor.kext chmod -R 755 ~/Downloads/AmdCPUMonitor.kext kextutil -v ~/Downloads/AmdCPUMonitor.kext This kext v1.0 AmdCPUMonitor.kext.zip Other files in the project (don't install all of them! For example you don't need IntelCPUMonitor) FakeSMC_plugins_746.zip New FakeSMC with Illumination version in System Profiler and no warnings in kernel.log FakeSMC.kext_Illumination.zip Minimum set includes FakeSMC+HWInfo Recommended installation (I have no installer so I propose you will use Terminal.app) sudo -s cp -r -v ~/Downloads/HWSensors/AmdCPUMonitor.kext /System/Library/Extensions/ and so on for all kexts that will have a sense for you ACPIMonitor.kext - for devices in DSDT. Only for advanced users! AmdCPUMonitor.kext - temperature for AMD CPU Andigilog.kext - for andigilog chip. Found on some Intel motherboard AnalogDevices.kext - for chips like ADT7470-7475 F718x.kext - for Fintek chip FakeSMC.kext - obligatory for any Hackintosh GeforceSensor.kext - for new NVidia Geforce cards HWInfo.kext - if you use Clover bootloader ICHSMBus.kext - an addition for Andigilog.kext IntelCPUMonitor.kext - temperature, voltage and frequencies for Intel CPU up to Haswell ITEIT87x.kext - for ITE chip, found on most Gigabyte motherboards NuvotonNCT677x.kext - for Nuvotone chip, found on new ASUS motherboards NVClockX.kext - for old NVidia cards PC8739x.kext - for NSC chip, found on Dell Inspiron only RadeonMonitor.kext - for Radeon videocard HD4000+ W836x.kext - for Winbond chips found on old ASUS motherboards X3100.kext - for Intel X3100 (GM965 chip) Monitor application to be used HWMonitor.app_731.zip New version andigilog.kext supports EMC6D103 chip. Advantages: - no spam in system.log - CPU usage only 0.1% - no panics - supported wide range of chips. Sources are available here https://www.assembla.com/code/fakesmc/subversion/nodes/738/HWSensors Hey can u re upload all the files u shared here, I am not able to download from here for some reason,. Thanks Link to comment https://www.insanelymac.com/forum/topic/296460-amdcpumonitor-and-hwsensors-331/page/5/#findComment-2129351 Share on other sites More sharing options...
pico joe Posted April 20, 2015 Share Posted April 20, 2015 @Genty .. http://sourceforge.net/projects/hwsensors3.hwsensors.p/ Link to comment https://www.insanelymac.com/forum/topic/296460-amdcpumonitor-and-hwsensors-331/page/5/#findComment-2129547 Share on other sites More sharing options...
Genty Posted April 20, 2015 Share Posted April 20, 2015 @Genty .. http://sourceforge.net/projects/hwsensors3.hwsensors.p/ Thanks very much. I will update how it works. Link to comment https://www.insanelymac.com/forum/topic/296460-amdcpumonitor-and-hwsensors-331/page/5/#findComment-2129568 Share on other sites More sharing options...
Genty Posted April 20, 2015 Share Posted April 20, 2015 @Genty .. http://sourceforge.net/projects/hwsensors3.hwsensors.p/ So I tried to install it but installation fails due to some error. But I can still see new HWMonitorSMC app installed. But it show only Hard disk temp nothing else. More over Now I have started to freez during restart and my external hdd is now being recognized as Read Only. How do I uninstall it now? Link to comment https://www.insanelymac.com/forum/topic/296460-amdcpumonitor-and-hwsensors-331/page/5/#findComment-2129583 Share on other sites More sharing options...
Op15L Posted May 8, 2015 Share Posted May 8, 2015 the link does not work I made new kext as an addition to HWSensors v3.3. Compatibility with OS 10.6 - 10.10 Currently it show only CPU temperature. May be later I make voltage and frequencies. Voluntaries welcomed. I am not sure with kozlek's project compatibility. Test with precations. (kozlek's version is not newer. It is a branch with own enumeration) Manual testing without installation: sudo -s chown -R root:wheel ~/Downloads/AmdCPUMonitor.kext chmod -R 755 ~/Downloads/AmdCPUMonitor.kext kextutil -v ~/Downloads/AmdCPUMonitor.kext This kext v1.0 AmdCPUMonitor.kext.zip Other files in the project (don't install all of them! For example you don't need IntelCPUMonitor) FakeSMC_plugins_746.zip New FakeSMC with Illumination version in System Profiler and no warnings in kernel.log FakeSMC.kext_Illumination.zip Minimum set includes FakeSMC+HWInfo Recommended installation (I have no installer so I propose you will use Terminal.app) sudo -s cp -r -v ~/Downloads/HWSensors/AmdCPUMonitor.kext /System/Library/Extensions/ and so on for all kexts that will have a sense for you ACPIMonitor.kext - for devices in DSDT. Only for advanced users! AmdCPUMonitor.kext - temperature for AMD CPU Andigilog.kext - for andigilog chip. Found on some Intel motherboard AnalogDevices.kext - for chips like ADT7470-7475 F718x.kext - for Fintek chip FakeSMC.kext - obligatory for any Hackintosh GeforceSensor.kext - for new NVidia Geforce cards HWInfo.kext - if you use Clover bootloader ICHSMBus.kext - an addition for Andigilog.kext IntelCPUMonitor.kext - temperature, voltage and frequencies for Intel CPU up to Haswell ITEIT87x.kext - for ITE chip, found on most Gigabyte motherboards NuvotonNCT677x.kext - for Nuvotone chip, found on new ASUS motherboards NVClockX.kext - for old NVidia cards PC8739x.kext - for NSC chip, found on Dell Inspiron only RadeonMonitor.kext - for Radeon videocard HD4000+ W836x.kext - for Winbond chips found on old ASUS motherboards X3100.kext - for Intel X3100 (GM965 chip) Monitor application to be used HWMonitor.app_731.zip New version andigilog.kext supports EMC6D103 chip. Advantages: - no spam in system.log - CPU usage only 0.1% - no panics - supported wide range of chips. Sources are available here https://www.assembla.com/code/fakesmc/subversion/nodes/738/HWSensors Link to comment https://www.insanelymac.com/forum/topic/296460-amdcpumonitor-and-hwsensors-331/page/5/#findComment-2133973 Share on other sites More sharing options...
gils83 Posted May 11, 2015 Share Posted May 11, 2015 but temperature is false Link to comment https://www.insanelymac.com/forum/topic/296460-amdcpumonitor-and-hwsensors-331/page/5/#findComment-2134608 Share on other sites More sharing options...
J0hny Posted October 10, 2015 Share Posted October 10, 2015 but temperature is false Same thing... This is my speedfan log from windows: Win9x:NO 64Bit:YES GiveIO:NO SpeedFan:YESI/O properly initialized Linked ISA BUS at $0290 Linked ATI SBx00 SMBUS at $0B00 Linked ISA BUS at $0CCB SB7xx/8xx PM2 found on ISA at $CCB Found nVidia GeForce GT 610 Linked nVidiaI2C0 SMBUS at $3D403E3F Linked nVidiaI2C1 SMBUS at $3D403637 Linked nVidiaI2C2 SMBUS at $3D405051 Scanning ISA BUS at $0290... IT8712F(J) found on ISA at $290 Scanning AtiIgp SMBus at $0B00... Scanning ISA BUS at $0CCB... Scanning I2CNVidia SMBus at $3D403E3F... Scanning I2CNVidia SMBus at $3D403637... Scanning I2CNVidia SMBus at $3D405051... Found Hitachi HTS543232A7A384 on AdvSMART Found WDC WD5000AAKX-083CA1 on AdvSMART ATK0110 (MB=M5A78L-M-LX3) found on ACPI End of detection Used these kexts: ACPIMonitor.kext - for devices in DSDT. Only for advanced users!AmdCPUMonitor.kext - temperature for AMD CPU Andigilog.kext - for andigilog chip. Found on some Intel motherboard AnalogDevices.kext - for chips like ADT7470-7475 F718x.kext - for Fintek chip FakeSMC.kext - obligatory for any Hackintosh GeforceSensor.kext - for new NVidia Geforce cards HWInfo.kext - if you use Clover bootloader ICHSMBus.kext - an addition for Andigilog.kext IntelCPUMonitor.kext - temperature, voltage and frequencies for Intel CPU up to Haswell ITEIT87x.kext - for ITE chip, found on most Gigabyte motherboards NuvotonNCT677x.kext - for Nuvotone chip, found on new ASUS motherboards NVClockX.kext - for old NVidia cards PC8739x.kext - for NSC chip, found on Dell Inspiron only RadeonMonitor.kext - for Radeon videocard HD4000+ W836x.kext - for Winbond chips found on old ASUS motherboards X3100.kext - for Intel X3100 (GM965 chip) It's just a little report. Maybe I should use some other kexts, I'm not sure. p.s. my hardware you can see at my signature... Link to comment https://www.insanelymac.com/forum/topic/296460-amdcpumonitor-and-hwsensors-331/page/5/#findComment-2175843 Share on other sites More sharing options...
spakk Posted October 10, 2015 Share Posted October 10, 2015 The drivers that are not suitable for your hardware, you have to remove from Fakesmc.kext/ ... /plugin/ folders. Or add missing drivers in the pluging folder. you need to test. Link to comment https://www.insanelymac.com/forum/topic/296460-amdcpumonitor-and-hwsensors-331/page/5/#findComment-2175956 Share on other sites More sharing options...
J0hny Posted October 10, 2015 Share Posted October 10, 2015 The drivers that are not suitable for your hardware, you have to remove from Fakesmc.kext/ ... /plugin/ folders. Or add missing drivers in the pluging folder. you need to test. Ok, I'll try in a free time.) 1 Link to comment https://www.insanelymac.com/forum/topic/296460-amdcpumonitor-and-hwsensors-331/page/5/#findComment-2175977 Share on other sites More sharing options...
J0hny Posted October 10, 2015 Share Posted October 10, 2015 Alright I've tried - same result, I had even delete all drivers and left only fakesmc.kext and amdcpumonitor.kext in Contents/Plugins. edit: I think it's not compatible with my type of CPU, the driver should be updated for compatibility. But it's ok, for now will be enough GPU sensor. Link to comment https://www.insanelymac.com/forum/topic/296460-amdcpumonitor-and-hwsensors-331/page/5/#findComment-2176031 Share on other sites More sharing options...
