jalavoui Posted March 2, 2007 Author Share Posted March 2, 2007 iwi2200 i'm trying to fix the 170M bug and also to maximize the download speed please report the speed you get in windows/linux/iwi2200 iwi2200.dmg Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315005 Share on other sites More sharing options...
Glauber Lobo Posted March 2, 2007 Share Posted March 2, 2007 Ok. Windows get 270k/s download rate max. Linux (ubuntu Feisty Faw 7.0.4) 260k/s download rate max. (same file and server test) OSX86 get 170k/s download rate max. (same file and server test) I´ll try that last kext posted ? Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315011 Share on other sites More sharing options...
keithoms Posted March 2, 2007 Share Posted March 2, 2007 Hi all,i downloaded the xkazu2 v6 for my 2200bg running 10.4.7, i ran the iwi2200.pkg, installed it, restarted, clicked on the airport icon, clicked apply now, then restarted again, i try to search for networks but it does not find any, and it doesnt work if i put it in manually, anything i can do to get it to work? bump,please i need an answer quick Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315012 Share on other sites More sharing options...
Glauber Lobo Posted March 2, 2007 Share Posted March 2, 2007 (edited) read olders topics or use search command. it´s your friend believe me. you will find all about that. Edited March 2, 2007 by Glauber Lobo Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315014 Share on other sites More sharing options...
keithoms Posted March 2, 2007 Share Posted March 2, 2007 read olders topics or use search command. it´s your friend believe me.you will find all about that. i have, but i am not into all of this programming, i would just like a straight answer Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315015 Share on other sites More sharing options...
WaldMeister Posted March 2, 2007 Share Posted March 2, 2007 (edited) ok, I'm almost there, the only thing preventing me from connecting is that I can't turn my airport on. I replaced all the files from the AirportExtremeUpdate, with the ones from the 10.4.8 Intel Update. Did I mis something, or it normal that the card can't be turned on? Edited March 2, 2007 by Lejenk Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315032 Share on other sites More sharing options...
patatester Posted March 2, 2007 Share Posted March 2, 2007 (edited) jalavoui thats good news. I will test this driver as soon as i get back home tonight and also check the attachInterface, resetDevice and that line you said to uncomment if everything was stable. And yes it SEEMS like the firmware is loading, i will confirm tonight. This line doesnt look too good to me, it is in FlipHDK's dmesg iwi3945: uCode file size 0 too small Anyway to determine for sure if the firmware is loading? Let me know and, it seems like there a 5second loop which prints out the mac address in /var/log/system.log . never stops to iterate it seems... i think top priority to be able to further debug the driver is to associate the mac to the interface Edited March 2, 2007 by patatester Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315034 Share on other sites More sharing options...
FlipHDK Posted March 2, 2007 Share Posted March 2, 2007 (edited) and, it seems like there a 5second loop which prints out the mac address in /var/log/system.log . never stops to iterate it seems... In the latest kext, that seems to have stopped. ( on my logs it has ) Edited March 2, 2007 by FlipHDK Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315056 Share on other sites More sharing options...
KrzychuG Posted March 2, 2007 Share Posted March 2, 2007 Manually loaded: iwi3945: disable 0 led 1 mode 0 iwi3945: darwin_iwi3945 iomemory length: 0x1000 @ 0xb3000000 iwi3945: darwin_iwi3945 virt: 0x2c772000 physical: 0xb3000000 iwi3945: darwin_iwi3945 IRQ: 18, Vendor ID: 8086, Product ID: 4222 iwi3945: getHardwareAddress 00:00:00:00:00:00 iwi3945: setPowerState to 2 iwi3945: getCARD_CAPABILITIES 72 iwi3945: getHardwareAddress 00:00:00:00:00:00 iwi3945: configureInterface darwin_iwi3945: Ethernet address 00:00:00:00:00:00 iwi3945: dataLinkLayerAttachComplete iwi3945: getSTATUS_DEV iwi3945: ifnet_t en1 = 3668004 iwi3945: pci_id 0x42228086 iwi3945: : Detected Intel PRO/Wireless 3945ABG Network Connection iwi3945: f/w package hdr ucode version = 0x2000d iwi3945: f/w package hdr runtime inst size = 80376 iwi3945: f/w package hdr runtime data size = 32768 iwi3945: f/w package hdr boot inst size = 2396 iwi3945: f/w package hdr boot data size = 32768 iwi3945: uCode file size 0 too small iwi3945: Copying (but not loading) uCode instr len 80376 iwi3945: Copying (but not loading) uCode data len 32768 iwi3945: Copying (but not loading) boot instr len 2396 iwi3945: Copying (but not loading) boot data len 32768 iwi3945: Waiting for ipw3945d to request INIT. iwi3945: getPOWER 1252820, 1252997 31 315802820 1109557382 iwi3945: getSSID <hidden> l:343291208 iwi3945: getCHANNEL c:0 f:0 iwi3945: getBSSID <hidden> iwi3945: Intialize power iwi3945: adjust power command flags iwi3945: initialize rate scale window to 62 iwi3945: MAC is in deep sleep! iwi3945: HW Revision ID = 0x2 iwi3945: MAC is in deep sleep! iwi3945: ALM-MM type iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! iwi3945: MAC is in deep sleep! Seems like MAC is read incorrectly. Can't run card in airort menu. Unloading kext causes kernel panic. Keep up the good work ;-) Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315065 Share on other sites More sharing options...
keithoms Posted March 2, 2007 Share Posted March 2, 2007 Hi all,i downloaded the xkazu2 v6 for my 2200bg running 10.4.7, i ran the iwi2200.pkg, installed it, restarted, clicked on the airport icon, clicked apply now, then restarted again, i try to search for networks but it does not find any, and it doesnt work if i put it in manually, anything i can do to get it to work? please somebody help me, i really would like intrnet Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315067 Share on other sites More sharing options...
FlipHDK Posted March 2, 2007 Share Posted March 2, 2007 I was looking into the size of ucode. /* verify size of file vs. image size info in file's header */ if (ucode_raw->size < sizeof(*ucode) + ucode->inst_size + ucode->data_size + ucode->boot_size + ucode->boot_data_size) { IOLog("uCode file size %d too small\n", (int)ucode_raw->size); rc = -EINVAL; //goto err_release; } and at the top there is a comment: /*ipw3945: priv->ucode_raw->size: 111572 ipw3945: ucode->boot_size: 900 ipw3945: ucode->inst_size: 77888 ipw3945: ucode->data_size: 32768 ipw3945: sizeof(*ucode): 16 */ The size is commented out. Should this be like this? Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315068 Share on other sites More sharing options...
jalavoui Posted March 2, 2007 Author Share Posted March 2, 2007 iwi3945: uCode file size 0 too small Anyway to determine for sure if the firmware is loading? Let me know and, it seems like there a 5second loop which prints out the mac address in /var/log/system.log . never stops to iterate it seems... i think top priority to be able to further debug the driver is to associate the mac to the interface yes, please check ucode size the command ifnet_setlladdr fails to set the mac address - remove it - this should be made in the start() as i said before you can try to load the eprom in the start() - this will give the right mac address but can cause a kernel panic i-ve remove the 5 second show mac address log - it is anoying if you feel you are able to use svn ask kazu to add you to the project to allowo you to commit changes after this bugs, firmware and mac address, get fixed the driver soon will be ready I was looking into the size of ucode. The size is commented out. Should this be like this? nops this is an old comment fromm previous firmware from ipw3945 i changed to the new intel iwifi firmware - see link in the google site if you feel like writing code and use svn ask kazu to add you to the project please somebody help me, i really would like intrnet try the last release i posted try the kazu test version from the google site make shure you have the right io80211family files Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315072 Share on other sites More sharing options...
keithoms Posted March 2, 2007 Share Posted March 2, 2007 yes, please check ucode size the command ifnet_setlladdr fails to set the mac address - remove it - this should be made in the start() as i said before you can try to load the eprom in the start() - this will give the right mac address but can cause a kernel panic i-ve remove the 5 second show mac address log - it is anoying if you feel you are able to use svn ask kazu to add you to the project to allowo you to commit changes after this bugs, firmware and mac address, get fixed the driver soon will be ready nops this is an old comment fromm previous firmware from ipw3945 i changed to the new intel iwifi firmware - see link in the google site if you feel like writing code and use svn ask kazu to add you to the project try the last release i posted try the kazu test version from the google site make shure you have the right io80211family files i have tried all of those, how do i log so i can show you it? Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315090 Share on other sites More sharing options...
cw4u Posted March 2, 2007 Share Posted March 2, 2007 How do I manually connect to a wireless network on the 2200 b/g card? Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315093 Share on other sites More sharing options...
optimistic Posted March 2, 2007 Share Posted March 2, 2007 (edited) I have installed iwi3945.kext but to the start the mac os they give this to me: iwi3945: disable 0 led 1 mode 0 iwi3945: darwin_iwi3945 iomemory length: 0x1000 @ 0xF0800000 iwi3945: darwin_iwi3945 virt: 0x31c13000 physical: 0xF0800000 iwi3945: darwin_iwi3945 IRQ: 18, Vendor ID: 8086, Product ID: 4222 iwi3945: getHardwareAddress 00:00:00:00:00:00 iwi3945: configureInterface and here one jams. How never? if kext the cargo manually before the time that I put it, the card works but to reboot me it blocks always them. HELP ME Edited March 2, 2007 by optimistic Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315098 Share on other sites More sharing options...
moseschrist Posted March 2, 2007 Share Posted March 2, 2007 How do I manually connect to a wireless network on the 2200 b/g card? at the moment, you don't... it's not possible. Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315159 Share on other sites More sharing options...
Ivan F. Ablasmkiy Posted March 2, 2007 Share Posted March 2, 2007 Any body can upload IO80211.kext what you using, becouse after Update i can't testing driver Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315172 Share on other sites More sharing options...
TheQwertz Posted March 2, 2007 Share Posted March 2, 2007 Any body can upload IO80211.kext what you using, becouse after Update i can't testing driver Here: http://download.yousendit.com/C73C5187474C07BA Contains both Apple80211.framework and IO80211Family.kext from 10.4.7 Cheers Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315186 Share on other sites More sharing options...
edmund Posted March 3, 2007 Share Posted March 3, 2007 So i downloaded the lastes iwi2200.dmg and when i run it and press install i get a dialog that says.. "you cannot continue.. there is nothing to install." what is that about?? Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315249 Share on other sites More sharing options...
starfish Posted March 3, 2007 Share Posted March 3, 2007 (edited) just tested the v11 dmesg.txt ioreg.txt system.txt Edited March 3, 2007 by starfish Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315285 Share on other sites More sharing options...
muhammadbeig Posted March 3, 2007 Share Posted March 3, 2007 hey guys, I installed iwi2200.kext and it detected the Airport thing.. when i try to connect it by manually typing the name of my wireless network, it crashes saying i need to reboot... i have 2915 intel wireless... please help!! Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315371 Share on other sites More sharing options...
eLMafUDd Posted March 3, 2007 Share Posted March 3, 2007 (edited) As far as I know, the only way it can connect is by setting it to automatically connect to open networks, and have your network without a password. Edited March 3, 2007 by eLMafUDd Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315374 Share on other sites More sharing options...
Scorp28 Posted March 3, 2007 Share Posted March 3, 2007 Sorry for my poor english. I can't make Intel PRO/Wireless 2200BG work. I have DELL D610 laptop. All kexts that I have can't solve the problem.The only result I get but I can't choose nither build-in-ethernet nor Airport. Can you give me kext and explane accurate what should I do. I spend a lot of time reading forum but it steel doesn't work :-( Thenks so much. Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315453 Share on other sites More sharing options...
Ivan F. Ablasmkiy Posted March 3, 2007 Share Posted March 3, 2007 Here: http://download.yousendit.com/C73C5187474C07BA Contains both Apple80211.framework and IO80211Family.kext from 10.4.7 Cheers Thanks. Now i can try to test driver Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315464 Share on other sites More sharing options...
patatester Posted March 3, 2007 Share Posted March 3, 2007 (edited) Ok, done some xcoding, got the mac address loaded on my machine correctly, same as in linux ! jalavoui, change the ifnet_setlladdress or whatever that was, i commented that then in ::start(), i uncommented the line ipw_sw_reset and ipw_nic_up. ipw_nic_up is the one which loads the eprom and associates the mac address if im not mistaking. Therefore the airport menu shows the correct mac address for the device. Now the problem is im still running under 10.4.8, due to my lazyness to downgrade to 10.4.7, and my desire to make this work under 10.4.8 if possible. As for SVN, ive never used before, but i think i could manage after some wiki exploration. So heres the kext for everyone who wants to test. Post your results! System.log and dmesg iwi3945.kext.zip system.log.txt Edited March 3, 2007 by patatester Link to comment https://www.insanelymac.com/forum/topic/36976-intel-wireless-driver/page/39/#findComment-315572 Share on other sites More sharing options...
