Background: Since the Pre-Release of Clover v5123, OpenCore Momory Fixes have been integrated into Clover in the form of OpenRuntime.efi. It replaces previous AptioMemory Fixes. Since v5126 AptioMemoryFixes are obsolete and no longer supported, so an upgrade to v5126 is mandatory in order to be able to install and boot macOS BigSur with Clover.
This guide is for everyone trying to update to the latest Clover version or having issues while updating from previous versions, so they can install and run BigSur on their Machines. While updating to the latest iteration of Clover, there are several obstacles one can come across along the way. This guide is here to assist users trying to make the switch from the "old" Clover version with AptioMemory Fixes to the new one with OpenRuntime and Quirks Settings in CloverConfigurator.
Problem: If you update your existing Clover installation by either installing the clover.pkg file or manually updating it the way you used to this will most likely result in an inoperable bootlader due to missing boot parameters.
Approach: In order to avoid the dilemma of your system not wanting to boot, you have to know that the following files are obsolete and are no longer necessary, so they should eiither be disbabled/deleted when updating Clover from a built prior to v 5123 or omitted altogether when setting up a new EFI Folder:
AptioMemoryFixes: AptioMemoryFix.efi, OsxAptioFix3Drv.efi, OsxAptioFixDrv.efi and everyhing else containing "memoryfix". Unnecessary Drivers (for UEFI-based Systems): DataHubDxe.efi – enables DataHub Protocol Support if it is missing from the BIOS. Modern UEFI BIOSes support this. So it's probably only necessary for Legacy Systems. FSInject.efi – For Kext-Injecttion. But pretty much obsolete since it's fully integrated in Clover nowadays. Might be necessary for Legacy Systems, though. SMCHelper.efi – Necessary when using FakeSMC.kext and ONLY FakeSMC. If you use it in combination with VirtualSMC.efi, it leads to an instant Kernel Panics. So, in other words: when using VirtualSMC – which is higly recommended over FakeSMC – DON'T use SMCHelper, use it in conjunction with VirtulSMC.efi (although unnecessary in most cases). EmuVariableUefi.efi – necessary for emulating NVRAM, if NVRAM is either not available (legacy systems) or working incorrectly. OcQuirks.efi and OcQuirks.plist – delete if present. OcQuirks is a relict from earlier attempts to include OpenCore Booter Quirks into Clover up until version 5122. Incompatible Kexts – wherever possible, you should use the latest available kexts provided by acidanthera (one of the devs behind OpenCore). Because incompatible Kexts are a source for Kernel Panics. I had an issue with my Laptop where VoodooPS2Controller.kext would cause a kernel Panic when used alongside VoodooPS2Mouse.kext, VoodooPS2Trackpad.kext and VoodooPS2Controller.kext. At the time I updated clover from 5122 to 5123, I didn't know that these 3 kexts are now includes as plugins inside of VoodooPS2Controller, so having them twice would cause a panic.
In general, having Kexts wich have depedencies to oher kexts can cause a KernelPanic if not loaded in the correct order. In OpenCore, you can and have to set up the correct loading order of kexts manually by yourself, but in Clover only a few essential kexts like Lilu and Fake/VirtualSMC are hard-coded in, so they are always loaded first. It took me a while to figure this out. So when you update Clover and you are using lot of Kexts (usually on Laptops), try to update all Kexts first using Kext-Updater which is incredibly useful tool to download all sorts of bootloader-related files, have a look inside of them so see if they include more kexts as plugins and make sure nothing is present twice – HID, Wifi and Bluetooth kexts come to mind here. If you get panics you can not isolate, just move all unnecessary kexts to the "off" folder to temporarily to work around the issue by starting with a minimal set up to get the system running. Then put the disabled kexts back one by one to find the culprit for the panic.
Updating your EFI
Prepare an USB Stick. Format it to FAT32 (MBR). We'll use it for testing our updated EFI Folder first, before copying it to the ESP on the HDD. Download the latest Clover Release as a .zip archive for a manual update (currently "CloverV2-5126.zip"): https://github.com/CloverHackyColor/CloverBootloader/releases Extract the .zip. We'll create our EFI based on the one insides of it. Have a look at the "EFI > Clover > drivers > off > UEFI" Folder – you find the following Files: Copy the following files over to EFI > Clover > drivers > UEFI: ApfsDriverLoader.efi, VBoxHfs.efi and OpenRuntime.efi Now we have a minimal set of Drivers which looks like shown below. The files tagged in gray are in the drivers Folder by defautl and are most likely unnecessary on UEFI-based systems. As mentioned earlier, SMCHelper MUST be deleted when using VirualSMC.kext! I would turn of each of the gray drivers one by one and chick if the system still boots without them.
Next, copy over your kexts (updated to the latest available version, of course), your ACPI > patched folder and your config.plist form your existing EFI Folder Open CloverConfigurator and update it to the latest Version. It should now include a new section at the bottom called Quirks, as mentioned earlier Now open your config.plist you copied over from your working EFI and click on "Quirks". It should look like this (without the descriptions of course):
Head over to the OpenCore Install Guide and pick the guide for your CPU Family and Platform. Jump to the "Booter" Section. It contains all required Booter Quirks tinted green in the screenshot. Make sure to unfold the "more in-depth info" box to see what they do. Find the options for your system and tick them away in Clover Configurator. Next, jump to the "Kernel" section of Dortania's guide and copy over the settings from "Quirks" and "Scheme". Again, make sure to unfold the "more in-depth" section to find all necessary settings. NOTE: some of the settings Located in "Kernel > Quirks" have different names and are located in the "Kernel and Kext Patches" section of Clover Configurator. These include:
In most cases you have these set up correctly already, otherwise your system wouldn't have started before. But it's good to double check if you have settings enabled which may be unnecessary. Once you've ticked all the necessary quirks, save your configuration, copy the new EFI Folder to the root of your USB Flash Drive and try booting from it. If everything was set up correctly, the system should boot as expected. If it does boot, you can mount the ESP partition of your hard drive, backup your EFI Folder, delete it and put in the one from your USB Flash drive to make the changes permanent.
TROUBLESHOOTING: If you get Kernel Panics take a note of them and head over to the OpenCore Troubleshooting Guide and have a look at the "OpenCore Boot issues" and "Kernelspace Issues" sections to find your error message and possible fixes to resolve it. Another great resource to check if your Clover config is set-up correctly in general (excluding Quirks) is the Hackintosh Vanilla Desktop Guide For more info about how OpenCore differs from clover and see which settings, drivers and features are compatible, check out the Clover Conversion Guide.
PS: If you run into trouble after following this guide you can upload your config.plist and I can have a look at the quirks.
PSS: When running BigSur, you need to remove the PreBoot Volume from the "Hide" Section of the GUI because if I understand correctly, BigSur requires booting from it.
PSSS: if your system boots correctly you can upload a screenshot with your quirks with additional Info like your Board and CPU which might be helpful for other users.
[GUIDE] Catalina and Big Sur on HP EliteDesk 800 G4/G5 Mini - The perfect MacMini8,1 Hackintosh - CLOVER & OCBy tonyx86
In this thread, I have fully documented the installation of macOS Catalina on my HP EliteDesk 800 G4 Mini. It is a PERFECT HackMini8,1 and is running very well for me without any issues. I hope this documentation helps you to install macOS on your hack. Please leave feedback if you think there is anything I can improve and let me know if you have any questions.
This is my first "modern" hack supporting UEFI and my first hack using Clover "on-the-fly" patches. My previous hacks
Laptop: Thinkpad T61 / Nvidia NVS 140m Laptop: Dell Latitude E6410 / Nvidia G3100m Desktop: Gigabyte G31 / GeForce 9600 Desktop: Biostar TH55HD / Sapphire Pulse RX580 (Google "Catalina Biostar TH55HD" and look for user name deeveedee)
are all perfectly running Catalina and I patched them all "manually" - all DSDT patches applied with MaciSL with virtually no Clover on-the-fly patching and all booted Legacy Clover. This UEFI hack was MUCH easier and took about 20 hours vs. a combined hundreds of hours for the old hacks. I wanted a hack that was a little more future proof and I think this is it. I hope you enjoy this as much as I am enjoying it. It is a perfect MacMini8,1.
My system specs
HP EliteDesk 800 G4 Mini (I7-8700T / UHD 630 / Q370 Chipset / 32GB DDR4 RAM) 3 x DP Ports (connected to monitors using DP -> DVI adapters) 6 x USB 3.1 1 x USB Type-C 3.1 2 x NVMe SSD (M.2 PCIe x4 2280/2230 combo ports) 1 x SATA6 SSD 1 x Intel Ethernet RJ-45 Conexant CX20632 Audio Codec Unsupported M.2 PCIe x1 2230 Intel Wi-Fi. A possible solution is here, but I am NOT offering any support for this.
Important: You MUST BE LOGGED-IN to download attachments from this forum
See macOS installation steps here See Known Issues here for additional installation steps that may not yet be included in my attached config files See CLOVER (UEFI) installation later in this first post
See OC (UEFI) draft EFI here
See BIOS configuration in attached BIOS configuration PDF document
See EFI and /L/E kexts in attached EliteDesk.zip archive See how I developed my installation methodology here See references here See instructions here for installing two M.2 2280 NVMe SSDs and one SATA HD / SSD
What is not working
What is not tested
USB c 3.1 port (I have partially tested the USB 3 functionality of the port and it seems to be working fine with the USBPorts.kext in the attached EliteDesk800.zip archive) Wi-Fi / Bluetooth (intentional since I have not yet replaced my Intel card). A possible solution is here, but I am not offering any support for this.
What is working
Everything not mentioned above Sleep / Wake Multiple displays with IGPU graphics acceleration, hot pluggable display ports and DP->DVI adapters USB 3.1 ports Audio (internal speaker and headphone jack) Ethernet
Known Issues and their solutions - see here
BIOS Version / Configuration
Version: 02.11.01 Rev.A or 02.12.00 Rev.A or 02.14.01 Rev.A See attached BIOS configuration in PDF document "HP EliteDesk 800 G4 Mini BIOS Configuration.pdf" Intel ME must be enabled for proper sleep / wake of UHD 630
Clover for UEFI booting only Install Clover in the ESP UEFI Drivers Recommended drivers DataHubDxe FSInject SMCHelper File System drivers ApfsDriverLoader VBoxHfs Memory fix drivers OcQuirks (replaces AptioMemoryFix) Additional drivers NvmExpressDxe Install RC scripts on target volume Themes Choose your desired theme Install Clover Preference Pane (option not available when installing on USB thumb drive)
UHD 630 Framebuffer Patching
See here and here to understand my graphics properties for use with WhateverGreen.kext Read this to see my attempt at graphics patching without WhateverGreen.kext (WEG) to get a better understanding of what WEG is doing
Catalina 10.15.7 Clover (UEFI) r5122 Lilu.kext 1.4.9 WhateverGreen.kext 1.4.4 AppleALC.kext 1.5.4 IntelMausi.kext 1.0.4 (acidanthera version) EFIChecikDisabler.kext 0.5
HP EliteDesk 800 G4 Mini BIOS Configuration.pdf
EliteDesk 800 G4 Mini - CLOVER Rev 1.4.zip
