MaLd0n

[Guide] Sierra / High Sierra on MSI Gaming 24 6QD 23.6-Inch All-In-One

3 posts in this topic

Recommended Posts

:rofl:

--Create a bootable copy of macOS Sierra
Check out the link

--Create a bootable copy of macOS HighSierra
Check out the link

Installation

--Install Clover in USB stick

--Replace with my Clover folder

--Install Sierra/High Sierra and boot into system!

Post Installation

--Install Clover in HDD/SSD and replace with my folder

--Reboot

DSDT

Patches
-FIX ERRORS AND WARNINGS
-HPET
-SATA
-DMAC
-SLPB
-DARWIN
-LPC
-XHCI
-PLUGIN TYPE
-XXXX to HDEF
-HDEF
-RTC
-IRQs
-SBUS
-BLC0
-BUS1
-MCHC
-ALS0
-SHUTDOWN
-LAN
-USBX
-PMCR
-EC
-----
-Disable GPU new patch and PNLF SSDT - Credits RehabMan






SSDT  :)
Generate your SSDT for PM, use ssdtPRGen by Piker-Alpha

or just use "plugin-type"=0x01 in DSDT, SSDT or Clover config.plist

for check Power, Frequency, Temperature and Utilization, use it



-Audio

https://github.com/vit9696/AppleALC



-FakeSMC


-Atheros Ethernet

-IntelGraphicsFixup

-IntelGraphicsDVMTFixup

-USBInjectAll

-Credits and thanks to the old and new people in the community who developed patches, kexts and bootloaders!

Slice, Kabyl, usr-sse2, jadran, Blackosx, dmazar, STLVNUB, pcj, apianti, JrCs, pene, FrodoKenny, skoczy, ycr.ru, Oscar09, xsmile, SoThOr, RehabMan, Download-Fritz, Zenit432, cecekpawon, Intel, Apple, Oracle, Chameleon Team, crazybirdy, Mieze, Mirone, Oldnapalm, netkas, Elconiglio, artut-pt, ErmaC, Pavo, Toleda, Master Chief and family, bcc9, The King, PMheart, Sherlocks, Micky1979, vit9696, vandroiy2013, Voodoo Team, Pike R. Alpha, lvs1974, Austere.J, CVad and many, many, many others!

Special Thanks to Pablo Galán

We're all here to have fun and learn from each other!

ENJOY!
