MaLd0n

[Guide] Sierra / High Sierra on GA X99-UD3P / i7 5820k / DSDT

1 post in this topic

Recommended Posts

--Install
Follow my tutorial and use my Clover folder

--Post Install
--Install Clover bootloader and replace with my folder

Bingo!

Now you need a fine tune! DSDT time!

If you need edited DSDT...
-Post your full Clover folder with original tables in Origin folder(Extract with F4 in Clover boot screen)
-Post Ioreg, extract with Ioreg Explorer
-Run it, post files generate in your desktop


-DSDT bios F23
My DSDT

-Patches
-FIX ERRORS AND WARNINGS
-HPET
-SATA
-sSATA
-DMAC
-SLPB
-DARWIN
-LPC
-XHCI
-EHCI
-PLUGIN TYPE
-ALZA to HDEF
-HDEF
-RTC
-IRQs
-SBUS
-BLC0
-BUS1
-MCHC
-ALS0
-IMEI
-SHUTDOWN
-LAN
-SPSR
-EC
-PNLF
-HDMI


MaLd0n 2018-01-18 às 00.24.49.png


e.g

MaLd0n 01.png



-Clover
-FakeSMC
-Audio
-USB
-LAN

-Credits and thanks to the old and new people in the community who developed patches, kexts and bootloaders!

Apple, Slice, Kabyl, usr-sse2, jadran, Blackosx, dmazar, STLVNUB, pcj, apianti, JrCs, pene, FrodoKenny, skoczy, ycr.ru, Oscar09, xsmile, SoThOr, RehabMan, Download-Fritz, Zenit432, cecekpawon, Intel, Apple, Oracle, Chameleon Team, crazybirdy, Mieze, Mirone, Oldnapalm, netkas, Elconiglio, artut-pt, ErmaC, Pavo, Toleda, Master Chief and family, bcc9, The King, PMheart, Sherlocks, Micky1979, vit9696, vandroiy2013, Voodoo Team, Pike R. Alpha, lvs1974, Austere.J, CVad, nmano and many, many, many others!

We're all here to have fun and learn from each other!



Share this post


Link to post
Share on other sites
