RehabMan Posted June 19, 2016 Share Posted June 19, 2016 i Dont have Sleep working so i cant now if there still delays. at the first with 10.11.5 i had KP after every reboot but with 10.11.6 its appear a lot less My doubts are confirmed. "appear a lot less" and "haven't tested it" does not imply "fixed". Link to comment Share on other sites More sharing options...
JustAnotherPUser Posted June 19, 2016 Share Posted June 19, 2016 You right its not fixed but its better though do you have any idea about the artefact problem ? its a black bar that appear and disepear on the left beside the Apple logo Link to comment Share on other sites More sharing options...
RehabMan Posted June 19, 2016 Share Posted June 19, 2016 do you have any idea about the artefact problem ? its a black bar that appear and disepear on the left beside the Apple logo Not without hardware details (should be in your signature). Link to comment Share on other sites More sharing options...
JustAnotherPUser Posted June 19, 2016 Share Posted June 19, 2016 Not without hardware details (should be in your signature). Sorry just added my config i am currently using the IGPU HD 530 Link to comment Share on other sites More sharing options...
Mork vom Ork Posted June 19, 2016 Share Posted June 19, 2016 News for NVME devices (thanx to Pike R. Alpha for his hints on his blog on what to patch): This ist how i make my SAMSUNG SM951 NVMe Devices visible under Systeminformation NVMExpress section <key>KextsToPatch</key> <array> <dict> <key>Comment</key> <string>NVMe SSD IONameMatch</string> <key>Disabled</key> <false/> <key>Name</key> <string>IONVMeFamily</string> <key>InfoPlistPatch</key> <true/> <key>Find</key> <data>PHN0cmluZz5wY2kxNDRkLGE4MDQ8L3N0cmluZz4=</data> <key>Replace</key> <data>PHN0cmluZz5wY2kxNDRkLGE4MDI8L3N0cmluZz4=</data> </dict> <dict> <key>Comment</key> <string>NVMe Size</string> <key>Disabled</key> <false/> <key>Find</key> <data>D7aMiIIAAACD+QwP</data> <key>Name</key> <string>IONVMeFamily</string> <key>Replace</key> <data>D7aMiIIAAACD+QkP</data> </dict> <dict> <key>Comment</key> <string>NVMe prefered BlockSize</string> <key>Disabled</key> <false/> <key>Find</key> <data>AADHg6QAAAAAEAAA</data> <key>Name</key> <string>IONVMeFamily</string> <key>Replace</key> <data>AADHg6QAAAAAAgAA</data> </dict> </array> Now the devices are shown as folowing: only problem so far: partitiontable didn't get recogniced, so system wants to format the drives. I will think about how to fix it. 5 Link to comment Share on other sites More sharing options...
magnifico Posted June 19, 2016 Share Posted June 19, 2016 News for NVME devices (thanx to Pike R. Alpha for his hints on his blog on what to patch): This ist how i make my SAMSUNG SM951 NVMe Devices visible under Systeminformation NVMExpress section <key>KextsToPatch</key> <array> <dict> <key>Comment</key> <string>NVMe SSD IONameMatch</string> <key>Disabled</key> <false/> <key>Name</key> <string>IONVMeFamily</string> <key>InfoPlistPatch</key> <true/> <key>Find</key> <data>PHN0cmluZz5wY2kxNDRkLGE4MDQ8L3N0cmluZz4=</data> <key>Replace</key> <data>PHN0cmluZz5wY2kxNDRkLGE4MDI8L3N0cmluZz4=</data> </dict> <dict> <key>Comment</key> <string>NVMe Size</string> <key>Disabled</key> <false/> <key>Find</key> <data>D7aMiIIAAACD+QwP</data> <key>Name</key> <string>IONVMeFamily</string> <key>Replace</key> <data>D7aMiIIAAACD+QkP</data> </dict> <dict> <key>Comment</key> <string>NVMe prefered BlockSize</string> <key>Disabled</key> <false/> <key>Find</key> <data>AADHg6QAAAAAEAAA</data> <key>Name</key> <string>IONVMeFamily</string> <key>Replace</key> <data>AADHg6QAAAAAAgAA</data> </dict> </array>Now the devices are shown as folowing: only problem so far: partitiontable didn't get recogniced, so system wants to format the drives. I will think about how to fix it. have you try without nvmegeneric.kext i thing or not ? Link to comment Share on other sites More sharing options...
Mork vom Ork Posted June 19, 2016 Share Posted June 19, 2016 have you try without nvmegeneric.kext i thing or not ? No NVMeGeneric.kext here (neither on EFI drive, nor in /S/L/E), cause my BootSSD is SAMSUNG SM951 AHCI. the two NVMe SSDs are connected to m.2 slots and contain WINDOWS10 and EL CAPITAN as bootable Systems. AHCI SSD (from which i boot macOS 10.12 right now) sits on PCI-M.2 card in slot#2. Link to comment Share on other sites More sharing options...
magnifico Posted June 19, 2016 Share Posted June 19, 2016 No NVMeGeneric.kext here (neither on EFI drive, nor in /S/L/E), cause my BootSSD is SAMSUNG SM951 AHCI. the two NVMe SSDs are connected to m.2 slots and contain WINDOWS10 and EL CAPITAN as bootable Systems. AHCI SSD (from which i boot macOS 10.12 right now) sits on PCI-M.2 card in slot#2. ok.so...you dont try without kext ? when have time i"ll try Link to comment Share on other sites More sharing options...
Mork vom Ork Posted June 19, 2016 Share Posted June 19, 2016 ok.so...you dont try without kext ? when have time i"ll try no, missunderstand me: i DON't use the NVMeGeneric.kext here anymore, cause my bootdrive is AHCI-SSD, not an NVMe-SSD. I just try to make IONVMeFamily.kext work correctly - and i can check that it works correctly by getting my NVMe-devices mounted to the desktop. As soon as i can see them mounted to the desktop, i know that Apple IONVMeFamily.kext would work like a charme. Link to comment Share on other sites More sharing options...
magnifico Posted June 19, 2016 Share Posted June 19, 2016 no, missunderstand me: i DON't use the NVMeGeneric.kext here anymore, cause my bootdrive is AHCI-SSD, not an NVMe-SSD. I just try to make IONVMeFamily.kext work correctly - and i can check that it works correctly by getting my NVMe-devices mounted to the desktop. As soon as i can see them mounted to the desktop, i know that Apple IONVMeFamily.kext would work like a charme. Ah ok ok ...now i understand Link to comment Share on other sites More sharing options...
anerik70 Posted June 19, 2016 Share Posted June 19, 2016 Done! Elan TouchPad and fn-Keys don't work. Link to comment Share on other sites More sharing options...
RehabMan Posted June 19, 2016 Share Posted June 19, 2016 Done! Elan TouchPad and fn-Keys don't work. It is a known problem. It affects all hack keyboard drivers, and system utilities for keyboard such as Karibiner. 2 Link to comment Share on other sites More sharing options...
JustAnotherPUser Posted June 19, 2016 Share Posted June 19, 2016 Piker Alpha confirmed on his blog that once this patch is finished NVMe SSD such as the 950 pro will work without NVMeGeneric.kext Link to comment Share on other sites More sharing options...
MacPeet Posted June 20, 2016 Share Posted June 20, 2016 some of the users of GeForce GT610, managed to get QE / CI? my PNY GT 610 1GB also does not work, only with nv_disable=1 (with Capitan still OOB) If you can find a solution, then please join. Link to comment Share on other sites More sharing options...
Mirone Posted June 20, 2016 Share Posted June 20, 2016 my PNY GT 610 1GB also does not work, only with nv_disable=1 (with Capitan still OOB) If you can find a solution, then please join. The problem is in Geforce.kext I decompilei your binary and made a diff with the binary of GeForce.kext of 10.11 and were made many changes in GeForce.kext of 10.12 I tried a few more things I missed, still looking for a solution . 1 Link to comment Share on other sites More sharing options...
Tusskan Posted June 20, 2016 Share Posted June 20, 2016 It seems the accelerator is causing the issue with my GPU after deleting the kext AMDRadeonX4000.kext the desktop loaded without QE/CI GPU: Sapphire Vapor-X R9 290X Tri-X UEFI OC. Link to comment Share on other sites More sharing options...
Matthew82 Posted June 20, 2016 Share Posted June 20, 2016 It seems the accelerator is causing the issue with my GPU after deleting the kext AMDRadeonX4000.kext the desktop loaded without QE/CI GPU: Sapphire Vapor-X R9 290X Tri-X UEFI OC. I have the same problem Link to comment Share on other sites More sharing options...
Mirone Posted June 20, 2016 Share Posted June 20, 2016 Good to know that users of GT610 are not alone .... 2 Link to comment Share on other sites More sharing options...
MacPeet Posted June 20, 2016 Share Posted June 20, 2016 yes GT610 2 Link to comment Share on other sites More sharing options...
asdesoso Posted June 20, 2016 Share Posted June 20, 2016 yes GT610 I also have a 610 but in Sierra I am using HD 4600. Link to comment Share on other sites More sharing options...
MacPeet Posted June 20, 2016 Share Posted June 20, 2016 On my Esprimo onboard graphics is even older. No way, only GT610. Link to comment Share on other sites More sharing options...
asdesoso Posted June 20, 2016 Share Posted June 20, 2016 On my Esprimo onboard graphics is even older. No way, only GT610. But in 10.11.6 beta 2 610 is working OOB? Thanks. Link to comment Share on other sites More sharing options...
Mirone Posted June 20, 2016 Share Posted June 20, 2016 But in 10.11.6 beta 2 610 is working OOB? Thanks. I'm going to check it. Link to comment Share on other sites More sharing options...
Mirone Posted June 21, 2016 Share Posted June 21, 2016 But in 10.11.6 beta 2 610 is working OOB? Thanks. yes, working OOB. It seems the accelerator is causing the issue with my GPU after deleting the kext AMDRadeonX4000.kext the desktop loaded without QE/CI GPU: Sapphire Vapor-X R9 290X Tri-X UEFI OC. try this: AMDRadeonX4000.kext.zip in boot args use: npci=0x2000 1 Link to comment Share on other sites More sharing options...
MacPeet Posted June 21, 2016 Share Posted June 21, 2016 But in 10.11.6 beta 2 610 is working OOB? Thanks. Yes, OOB works in 10.11.6 and all versions before Rollback of nvidia / geforce - kexts does not work and the new beta web driver does not work with GT610 1 Link to comment Share on other sites More sharing options...
