Squirrelf Posted September 7, 2009 Share Posted September 7, 2009 there is no reason for you to be getting this error, which is strange all i can guess is that go through your bios again and see if you can change the set up. or take your IOATAFamily.kext from leopard and use that. I didn't specifically used IOATAFamily I used ATAPortinjector, which is what I used in Leo, anyway at the same point it KP, but this time the message was about IOATAFAmily instead of ApplePIIxAta Link to comment Share on other sites More sharing options...
noob766 Posted September 7, 2009 Author Share Posted September 7, 2009 I didn't specifically used IOATAFamilyI used ATAPortinjector, which is what I used in Leo, anyway at the same point it KP, but this time the message was about IOATAFAmily instead of ApplePIIxAta well whenever mediafire comes back online, try this kext http://www.mediafire.com/?kmdwnjum90y Link to comment Share on other sites More sharing options...
Squirrelf Posted September 7, 2009 Share Posted September 7, 2009 well whenever mediafire comes back online, try this kexthttp://www.mediafire.com/?kmdwnjum90y ok I'll try it ( I guess I went through the same step as you did, that's dune version) without any kext besides the basic three I get the same kp as previously just about ioatafamily ---- thank you for everything going to sleep now I'll try dune's version tomorrow Link to comment Share on other sites More sharing options...
snifferpro Posted September 7, 2009 Share Posted September 7, 2009 read the guide. Here is your efi string, add it to com.apple.boot.plist <key>device-properties</key> <string>cb0300000100000001000000bf0300001500000002010c00d041030a000000000101060000027 fff04003a000000400032002c0068007700730065006e0073006f0072002d0070006100720061006 d 0073002d00760065007200730069006f006e000000080000000000000222000000400032002c0064 0 0650076006900630065005f0074007900700065000000120000004e5644412c6770752d64696f646 5 0e0000004e00560050004d0000002000000001000000000000000000000000000000000000000000 0 000000000001e00000072006f006d002d007200650076006900730069006f006e000000090000003 3 31373261100000004e00560043004100500000001800000004000000000003000c00000000000007 0 000000022000000400032002c002300730069007a0065002d00630065006c006c007300000008000 0 000000000022000000400030002c006400650076006900630065005f00740079007000650000000b 0 00000646973706c6179100000006d006f00640065006c0000001e0000004e5649444941204765466 f 72636520393830302047542045464914000000400030002c006e0061006d0065000000120000004e 5 644412c446973706c61792d4120000000400032002c0063006f006d00700061007400690062006c0 0 65000000160000004e5644412c73656e736f722d706172656e7414000000400031002c006e006100 6 d0065000000120000004e5644412c446973706c61792d4212000000400032002c007200650067000 0 0008000000000000021c0000006400650076006900630065005f0074007900700065000000100000 0 04e5644412c4765466f72636520000000400031002c0063006f006d00700061007400690062006c0 0 650000000e0000004e5644412c4e564d616326000000400032002c00230061006400720065007300 7 3002d00630065006c006c007300000008000000000000010e0000006e0061006d00650000000f000 0 004e5644412c506172656e7422000000400031002c006400650076006900630065005f0074007900 7 000650000000b000000646973706c617920000000400030002c0063006f006d00700061007400690 0 62006c00650000000e0000004e5644412c4e564d6163220000005600520041004d002c0074006f00 7 40061006c00730069007a0065000000080000000000004036000000400032002c006800770063007 4 0072006c002d0070006100720061006d0073002d00760065007200730069006f006e000000080000 0 00000000214000000400032002c006e0061006d00650000001100000073656e736f722d706172656 e 74</string> Applied above string to com.apple.boot.plist and still get exact same halt shown below. Link to comment Share on other sites More sharing options...
Squirrelf Posted September 7, 2009 Share Posted September 7, 2009 well whenever mediafire comes back online, try this kexthttp://www.mediafire.com/?kmdwnjum90y that didn't do it same as last KP, about ioatafamily ---- edit: WELL I tried disabling IDE, and IT WORKED so I guess I can't use IDE in Snow Leopard, but I was able to boot my "USB install disk", I'll install it now and hope everything works... (I'll have to figure out sound and ethernet, I already have video in my dsdt) Link to comment Share on other sites More sharing options...
noob766 Posted September 7, 2009 Author Share Posted September 7, 2009 that didn't do it same as last KP, about ioatafamily ---- edit: WELL I tried disabling IDE, and IT WORKED so I guess I can't use IDE in Snow Leopard, but I was able to boot my "USB install disk", I'll install it now and hope everything works... (I'll have to figure out sound and ethernet, I already have video in my dsdt) lol didn't i say that at the beginning? Link to comment Share on other sites More sharing options...
snifferpro Posted September 7, 2009 Share Posted September 7, 2009 read the guide. Here is your efi string, add it to com.apple.boot.plist <key>device-properties</key> <string>cb0300000100000001000000bf0300001500000002010c00d041030a000000000101060000027 fff04003a000000400032002c0068007700730065006e0073006f0072002d0070006100720061006 d 0073002d00760065007200730069006f006e000000080000000000000222000000400032002c0064 0 0650076006900630065005f0074007900700065000000120000004e5644412c6770752d64696f646 5 0e0000004e00560050004d0000002000000001000000000000000000000000000000000000000000 0 000000000001e00000072006f006d002d007200650076006900730069006f006e000000090000003 3 31373261100000004e00560043004100500000001800000004000000000003000c00000000000007 0 000000022000000400032002c002300730069007a0065002d00630065006c006c007300000008000 0 000000000022000000400030002c006400650076006900630065005f00740079007000650000000b 0 00000646973706c6179100000006d006f00640065006c0000001e0000004e5649444941204765466 f 72636520393830302047542045464914000000400030002c006e0061006d0065000000120000004e 5 644412c446973706c61792d4120000000400032002c0063006f006d00700061007400690062006c0 0 65000000160000004e5644412c73656e736f722d706172656e7414000000400031002c006e006100 6 d0065000000120000004e5644412c446973706c61792d4212000000400032002c007200650067000 0 0008000000000000021c0000006400650076006900630065005f0074007900700065000000100000 0 04e5644412c4765466f72636520000000400031002c0063006f006d00700061007400690062006c0 0 650000000e0000004e5644412c4e564d616326000000400032002c00230061006400720065007300 7 3002d00630065006c006c007300000008000000000000010e0000006e0061006d00650000000f000 0 004e5644412c506172656e7422000000400031002c006400650076006900630065005f0074007900 7 000650000000b000000646973706c617920000000400030002c0063006f006d00700061007400690 0 62006c00650000000e0000004e5644412c4e564d6163220000005600520041004d002c0074006f00 7 40061006c00730069007a0065000000080000000000004036000000400032002c006800770063007 4 0072006c002d0070006100720061006d0073002d00760065007200730069006f006e000000080000 0 00000000214000000400032002c006e0061006d00650000001100000073656e736f722d706172656 e 74</string> Don't know what happened to my earlier reply this morning, but i used your above string and still get the same results. Link to comment Share on other sites More sharing options...
noob766 Posted September 7, 2009 Author Share Posted September 7, 2009 Don't know what happened to my earlier reply this morning, but i used your abovestring and still get the same results. post your lspci Link to comment Share on other sites More sharing options...
snifferpro Posted September 7, 2009 Share Posted September 7, 2009 post your lspci lspci 00:00.0 Host bridge: Intel Corporation Device 2e20 (rev 03) 00:01.0 PCI bridge: Intel Corporation Device 2e21 (rev 03) 00:1a.0 USB Controller: Intel Corporation Device 3a37 00:1a.1 USB Controller: Intel Corporation Device 3a38 00:1a.2 USB Controller: Intel Corporation Device 3a39 00:1a.7 USB Controller: Intel Corporation Device 3a3c 00:1b.0 Audio device: Intel Corporation Device 3a3e 00:1c.0 PCI bridge: Intel Corporation Device 3a40 00:1c.5 PCI bridge: Intel Corporation Device 3a4a 00:1d.0 USB Controller: Intel Corporation Device 3a34 00:1d.1 USB Controller: Intel Corporation Device 3a35 00:1d.2 USB Controller: Intel Corporation Device 3a36 00:1d.7 USB Controller: Intel Corporation Device 3a3a 00:1e.0 PCI bridge: Intel Corporation 82801 PCI Bridge (rev 90) 00:1f.0 ISA bridge: Intel Corporation Device 3a16 00:1f.2 SATA controller: Intel Corporation Device 3a22 00:1f.3 SMBus: Intel Corporation Device 3a30 01:00.0 VGA compatible controller: nVidia Corporation Device 0614 (rev a2) 02:00.0 Ethernet controller: Marvell Technology Group Ltd. 88E8056 PCI-E Gigabit Ethernet Controller (rev 12) 04:02.0 Ethernet controller: Marvell Technology Group Ltd. 88E8001 Gigabit Ethernet Controller (rev 14) 04:03.0 FireWire (IEEE 1394): Agere Systems FW323 (rev 70) Link to comment Share on other sites More sharing options...
noob766 Posted September 7, 2009 Author Share Posted September 7, 2009 lspci 00:00.0 Host bridge: Intel Corporation Device 2e20 (rev 03) 00:01.0 PCI bridge: Intel Corporation Device 2e21 (rev 03) 00:1a.0 USB Controller: Intel Corporation Device 3a37 00:1a.1 USB Controller: Intel Corporation Device 3a38 00:1a.2 USB Controller: Intel Corporation Device 3a39 00:1a.7 USB Controller: Intel Corporation Device 3a3c 00:1b.0 Audio device: Intel Corporation Device 3a3e 00:1c.0 PCI bridge: Intel Corporation Device 3a40 00:1c.5 PCI bridge: Intel Corporation Device 3a4a 00:1d.0 USB Controller: Intel Corporation Device 3a34 00:1d.1 USB Controller: Intel Corporation Device 3a35 00:1d.2 USB Controller: Intel Corporation Device 3a36 00:1d.7 USB Controller: Intel Corporation Device 3a3a 00:1e.0 PCI bridge: Intel Corporation 82801 PCI Bridge (rev 90) 00:1f.0 ISA bridge: Intel Corporation Device 3a16 00:1f.2 SATA controller: Intel Corporation Device 3a22 00:1f.3 SMBus: Intel Corporation Device 3a30 01:00.0 VGA compatible controller: nVidia Corporation Device 0614 (rev a2) 02:00.0 Ethernet controller: Marvell Technology Group Ltd. 88E8056 PCI-E Gigabit Ethernet Controller (rev 12) 04:02.0 Ethernet controller: Marvell Technology Group Ltd. 88E8001 Gigabit Ethernet Controller (rev 14) 04:03.0 FireWire (IEEE 1394): Agere Systems FW323 (rev 70) hah wow that one tells me nothing, wow intel corporation device. you need to update pciutils but first post what kexts you are using. Link to comment Share on other sites More sharing options...
snifferpro Posted September 7, 2009 Share Posted September 7, 2009 hah wow that one tells me nothing, wow intel corporation device. you need to update pciutils but first post what kexts you are using. Currently using V3.0.0 - is there a newer version. That lspci is from my working Leopard 10.5.8 - can't give you one from SL as it won't boot. How do I determine what kexts I am using? Sorry, still a noob Is it just me or is there a problem with the board? I don't see my replies to my original post on page 3. If I go to page 4, all I get is your original post. Thanks for bearing with me Link to comment Share on other sites More sharing options...
noob766 Posted September 7, 2009 Author Share Posted September 7, 2009 Currently using V3.0.0 - is there a newer version. That lspci is from my working Leopard 10.5.8 - can't give you one from SL as it won't boot. How do I determine what kexts I am using? Sorry, still a noob Is it just me or is there a problem with the board? I don't see my replies to my original post on page 3. If I go to page 4, all I get is your original post. Thanks for bearing with me lol did you even follow my guide? boot-132 is not the method for you if you don't know what kexts are... Link to comment Share on other sites More sharing options...
snifferpro Posted September 7, 2009 Share Posted September 7, 2009 lol did you even follow my guide? boot-132 is not the method for you if you don't know what kexts are... Yes, I followed your guide using the second option (USB). I used the kexts that you provided links to and put them on my USB stick and did the install. The install completed normally. When I boot the new SL on HD I get the error. Link to comment Share on other sites More sharing options...
haraldschmidt Posted September 7, 2009 Share Posted September 7, 2009 Here there guys... I'm runnin a pretty much vanilla iatkos v7 updated to 10.5.8 and wanted to give SL a try using 132boot method. During booting the retail disc: kernel panic!!! here is my lspci: 00:00.0 Host bridge [0600]: Intel Corporation Mobile PM965/GM965/GL960 Memory Controller Hub [8086:2a00] (rev 0c) 00:01.0 PCI bridge [0604]: Intel Corporation Mobile PM965/GM965/GL960 PCI Express Root Port [8086:2a01] (rev 0c) 00:1a.0 USB Controller [0c03]: Intel Corporation 82801H (ICH8 Family) USB UHCI Controller #4 [8086:2834] (rev 02) 00:1a.1 USB Controller [0c03]: Intel Corporation 82801H (ICH8 Family) USB UHCI Controller #5 [8086:2835] (rev 02) 00:1a.7 USB Controller [0c03]: Intel Corporation 82801H (ICH8 Family) USB2 EHCI Controller #2 [8086:283a] (rev 02) 00:1b.0 Audio device [0403]: Intel Corporation 82801H (ICH8 Family) HD Audio Controller [8086:284b] (rev 02) 00:1c.0 PCI bridge [0604]: Intel Corporation 82801H (ICH8 Family) PCI Express Port 1 [8086:283f] (rev 02) 00:1c.1 PCI bridge [0604]: Intel Corporation 82801H (ICH8 Family) PCI Express Port 2 [8086:2841] (rev 02) 00:1c.3 PCI bridge [0604]: Intel Corporation 82801H (ICH8 Family) PCI Express Port 4 [8086:2845] (rev 02) 00:1c.5 PCI bridge [0604]: Intel Corporation 82801H (ICH8 Family) PCI Express Port 6 [8086:2849] (rev 02) 00:1d.0 USB Controller [0c03]: Intel Corporation 82801H (ICH8 Family) USB UHCI Controller #1 [8086:2830] (rev 02) 00:1d.1 USB Controller [0c03]: Intel Corporation 82801H (ICH8 Family) USB UHCI Controller #2 [8086:2831] (rev 02) 00:1d.2 USB Controller [0c03]: Intel Corporation 82801H (ICH8 Family) USB UHCI Controller #3 [8086:2832] (rev 02) 00:1d.7 USB Controller [0c03]: Intel Corporation 82801H (ICH8 Family) USB2 EHCI Controller #1 [8086:2836] (rev 02) 00:1e.0 PCI bridge [0604]: Intel Corporation 82801 Mobile PCI Bridge [8086:2448] (rev f2) 00:1f.0 ISA bridge [0601]: Intel Corporation 82801HEM (ICH8M) LPC Interface Controller [8086:2815] (rev 02) 00:1f.1 IDE interface [0101]: Intel Corporation 82801HBM/HEM (ICH8M/ICH8M-E) IDE Controller [8086:2850] (rev 02) 00:1f.2 SATA controller [0106]: Intel Corporation 82801HBM/HEM (ICH8M/ICH8M-E) SATA AHCI Controller [8086:2829] (rev 02) 00:1f.3 SMBus [0c05]: Intel Corporation 82801H (ICH8 Family) SMBus Controller [8086:283e] (rev 02) 01:00.0 VGA compatible controller [0300]: nVidia Corporation GeForce 8400M GS [10de:0427] (rev a1) 0c:00.0 Network controller [0280]: Broadcom Corporation BCM4328 802.11a/b/g/n [14e4:4328] (rev 05) I tried a lot of kexts - combinations but always the same... KP It's a DELL XPS 1330M with NV8400m GS 128 MB (not sure if i am using correct efi string but that seems not to be my major problem, is it? ) Tried a lot workaround with AppleIntelPIIXPATA but always Kernel Panic. What is ment with replacing Device / Vendor ID in this kext (1. where do I get those IDs 2. How to and where to insert?) What do think are the minimal kexts I have to use? Anyone made SL running with ICH8 mobile boards...? Thanks a lot in advance... Link to comment Share on other sites More sharing options...
noob766 Posted September 7, 2009 Author Share Posted September 7, 2009 Here there guys... I'm runnin a pretty much vanilla iatkos v7 updated to 10.5.8 and wanted to give SL a try using 132boot method. During booting the retail disc: kernel panic!!! here is my lspci: 00:00.0 Host bridge [0600]: Intel Corporation Mobile PM965/GM965/GL960 Memory Controller Hub [8086:2a00] (rev 0c) 00:01.0 PCI bridge [0604]: Intel Corporation Mobile PM965/GM965/GL960 PCI Express Root Port [8086:2a01] (rev 0c) 00:1a.0 USB Controller [0c03]: Intel Corporation 82801H (ICH8 Family) USB UHCI Controller #4 [8086:2834] (rev 02) 00:1a.1 USB Controller [0c03]: Intel Corporation 82801H (ICH8 Family) USB UHCI Controller #5 [8086:2835] (rev 02) 00:1a.7 USB Controller [0c03]: Intel Corporation 82801H (ICH8 Family) USB2 EHCI Controller #2 [8086:283a] (rev 02) 00:1b.0 Audio device [0403]: Intel Corporation 82801H (ICH8 Family) HD Audio Controller [8086:284b] (rev 02) 00:1c.0 PCI bridge [0604]: Intel Corporation 82801H (ICH8 Family) PCI Express Port 1 [8086:283f] (rev 02) 00:1c.1 PCI bridge [0604]: Intel Corporation 82801H (ICH8 Family) PCI Express Port 2 [8086:2841] (rev 02) 00:1c.3 PCI bridge [0604]: Intel Corporation 82801H (ICH8 Family) PCI Express Port 4 [8086:2845] (rev 02) 00:1c.5 PCI bridge [0604]: Intel Corporation 82801H (ICH8 Family) PCI Express Port 6 [8086:2849] (rev 02) 00:1d.0 USB Controller [0c03]: Intel Corporation 82801H (ICH8 Family) USB UHCI Controller #1 [8086:2830] (rev 02) 00:1d.1 USB Controller [0c03]: Intel Corporation 82801H (ICH8 Family) USB UHCI Controller #2 [8086:2831] (rev 02) 00:1d.2 USB Controller [0c03]: Intel Corporation 82801H (ICH8 Family) USB UHCI Controller #3 [8086:2832] (rev 02) 00:1d.7 USB Controller [0c03]: Intel Corporation 82801H (ICH8 Family) USB2 EHCI Controller #1 [8086:2836] (rev 02) 00:1e.0 PCI bridge [0604]: Intel Corporation 82801 Mobile PCI Bridge [8086:2448] (rev f2) 00:1f.0 ISA bridge [0601]: Intel Corporation 82801HEM (ICH8M) LPC Interface Controller [8086:2815] (rev 02) 00:1f.1 IDE interface [0101]: Intel Corporation 82801HBM/HEM (ICH8M/ICH8M-E) IDE Controller [8086:2850] (rev 02) 00:1f.2 SATA controller [0106]: Intel Corporation 82801HBM/HEM (ICH8M/ICH8M-E) SATA AHCI Controller [8086:2829] (rev 02) 00:1f.3 SMBus [0c05]: Intel Corporation 82801H (ICH8 Family) SMBus Controller [8086:283e] (rev 02) 01:00.0 VGA compatible controller [0300]: nVidia Corporation GeForce 8400M GS [10de:0427] (rev a1) 0c:00.0 Network controller [0280]: Broadcom Corporation BCM4328 802.11a/b/g/n [14e4:4328] (rev 05) I tried a lot of kexts - combinations but always the same... KP It's a DELL XPS 1330M with NV8400m GS 128 MB (not sure if i am using correct efi string but that seems not to be my major problem, is it? ) Tried a lot workaround with AppleIntelPIIXPATA but always Kernel Panic. What is ment with replacing Device / Vendor ID in this kext (1. where do I get those IDs 2. How to and where to insert?) What do think are the minimal kexts I have to use? Anyone made SL running with ICH8 mobile boards...? Thanks a lot in advance... First of all, Thank you for including everything I asked for. It makes solving your issue much easier. change your hard drive mode in your bios add appleintelPIIXata.kext with dev ID's AHCIPortInjector.kext Yes, I followed your guide using the second option (USB). I used the kexts that you provided links to and put them on my USB stick and did the install. The install completed normally. When I boot the new SL on HD I get the error. list the kexts in your USB bootloader. Link to comment Share on other sites More sharing options...
haraldschmidt Posted September 7, 2009 Share Posted September 7, 2009 First of all, Thank you for including everything I asked for. It makes solving your issue much easier. change your hard drive mode in your bios add appleintelPIIXata.kext with dev ID's AHCIPortInjector.kext Hi again, 1. my only optins in bios are SATA or AHCI (played around already, had to do so already for leopard install back in time) 2. I will try AHCIPortInjector.kext very soon 3. with appleintelPIIXata.kext - where do I get the ID (OSXtools?, Sys-Profiler? ) Where will I have to insert the ID in the kext exactly, under some ICH8 Device (already searched for a detailed explanation since this could be it) Could you please explain that part in more detail (not epic)... Thanks so far... Link to comment Share on other sites More sharing options...
snifferpro Posted September 7, 2009 Share Posted September 7, 2009 First of all, Thank you for including everything I asked for. It makes solving your issue much easier. change your hard drive mode in your bios add appleintelPIIXata.kext with dev ID's AHCIPortInjector.kext list the kexts in your USB bootloader. Fakesmc.kext NullCOUPowerManagement.kext OpenHaltRestart.kext Link to comment Share on other sites More sharing options...
noob766 Posted September 7, 2009 Author Share Posted September 7, 2009 Hi again, 1. my only optins in bios are SATA or AHCI (played around already, had to do so already for leopard install back in time) 2. I will try AHCIPortInjector.kext very soon 3. with appleintelPIIXata.kext - where do I get the ID (OSXtools?, Sys-Profiler? ) Where will I have to insert the ID in the kext exactly, under some ICH8 Device (already searched for a detailed explanation since this could be it) Could you please explain that part in more detail (not epic)... Thanks so far... check the optional kexts section of my guide. Fakesmc.kextNullCOUPowerManagement.kext OpenHaltRestart.kext download osx86 tools and reinstall pciutils, then hit view pci/vendor id's Link to comment Share on other sites More sharing options...
snifferpro Posted September 7, 2009 Share Posted September 7, 2009 check the optional kexts section of my guide. download osx86 tools and reinstall pciutils, then hit view pci/vendor id's 00:00.0 Host bridge [0600]: Intel Corporation Device [8086:2e20] (rev 03) 00:01.0 PCI bridge [0604]: Intel Corporation Device [8086:2e21] (rev 03) 00:1a.0 USB Controller [0c03]: Intel Corporation Device [8086:3a37] 00:1a.1 USB Controller [0c03]: Intel Corporation Device [8086:3a38] 00:1a.2 USB Controller [0c03]: Intel Corporation Device [8086:3a39] 00:1a.7 USB Controller [0c03]: Intel Corporation Device [8086:3a3c] 00:1b.0 Audio device [0403]: Intel Corporation Device [8086:3a3e] 00:1c.0 PCI bridge [0604]: Intel Corporation Device [8086:3a40] 00:1c.5 PCI bridge [0604]: Intel Corporation Device [8086:3a4a] 00:1d.0 USB Controller [0c03]: Intel Corporation Device [8086:3a34] 00:1d.1 USB Controller [0c03]: Intel Corporation Device [8086:3a35] 00:1d.2 USB Controller [0c03]: Intel Corporation Device [8086:3a36] 00:1d.7 USB Controller [0c03]: Intel Corporation Device [8086:3a3a] 00:1e.0 PCI bridge [0604]: Intel Corporation 82801 PCI Bridge [8086:244e] (rev 90) 00:1f.0 ISA bridge [0601]: Intel Corporation Device [8086:3a16] 00:1f.2 SATA controller [0106]: Intel Corporation Device [8086:3a22] 00:1f.3 SMBus [0c05]: Intel Corporation Device [8086:3a30] 01:00.0 VGA compatible controller [0300]: nVidia Corporation Device [10de:0614] (rev a2) 02:00.0 Ethernet controller [0200]: Marvell Technology Group Ltd. 88E8056 PCI-E Gigabit Ethernet Controller [11ab:4364] (rev 12) 04:02.0 Ethernet controller [0200]: Marvell Technology Group Ltd. 88E8001 Gigabit Ethernet Controller [11ab:4320] (rev 14) 04:03.0 FireWire (IEEE 1394) [0c00]: Agere Systems FW323 [11c1:5811] (rev 70) Link to comment Share on other sites More sharing options...
noob766 Posted September 7, 2009 Author Share Posted September 7, 2009 00:00.0 Host bridge [0600]: Intel Corporation Device [8086:2e20] (rev 03)00:01.0 PCI bridge [0604]: Intel Corporation Device [8086:2e21] (rev 03) 00:1a.0 USB Controller [0c03]: Intel Corporation Device [8086:3a37] 00:1a.1 USB Controller [0c03]: Intel Corporation Device [8086:3a38] 00:1a.2 USB Controller [0c03]: Intel Corporation Device [8086:3a39] 00:1a.7 USB Controller [0c03]: Intel Corporation Device [8086:3a3c] 00:1b.0 Audio device [0403]: Intel Corporation Device [8086:3a3e] 00:1c.0 PCI bridge [0604]: Intel Corporation Device [8086:3a40] 00:1c.5 PCI bridge [0604]: Intel Corporation Device [8086:3a4a] 00:1d.0 USB Controller [0c03]: Intel Corporation Device [8086:3a34] 00:1d.1 USB Controller [0c03]: Intel Corporation Device [8086:3a35] 00:1d.2 USB Controller [0c03]: Intel Corporation Device [8086:3a36] 00:1d.7 USB Controller [0c03]: Intel Corporation Device [8086:3a3a] 00:1e.0 PCI bridge [0604]: Intel Corporation 82801 PCI Bridge [8086:244e] (rev 90) 00:1f.0 ISA bridge [0601]: Intel Corporation Device [8086:3a16] 00:1f.2 SATA controller [0106]: Intel Corporation Device [8086:3a22] 00:1f.3 SMBus [0c05]: Intel Corporation Device [8086:3a30] 01:00.0 VGA compatible controller [0300]: nVidia Corporation Device [10de:0614] (rev a2) 02:00.0 Ethernet controller [0200]: Marvell Technology Group Ltd. 88E8056 PCI-E Gigabit Ethernet Controller [11ab:4364] (rev 12) 04:02.0 Ethernet controller [0200]: Marvell Technology Group Ltd. 88E8001 Gigabit Ethernet Controller [11ab:4320] (rev 14) 04:03.0 FireWire (IEEE 1394) [0c00]: Agere Systems FW323 [11c1:5811] (rev 70) not sure if i can help you unless you can tell me what chipset you have and graphics card since it isnt shown in there Link to comment Share on other sites More sharing options...
snifferpro Posted September 7, 2009 Share Posted September 7, 2009 not sure if i can help you unless you can tell me what chipset you have and graphics card since it isnt shown in there Evga Nvidia Geforce 9800gt 512MB What chipset are you referring to? Link to comment Share on other sites More sharing options...
haraldschmidt Posted September 7, 2009 Share Posted September 7, 2009 I dont get that VENDOR ID thang... OSX86 gives me nothin but: Bildschirmfoto_2009_09_07_20_01_44.tiff Once I knew my vendor / device ID... where to insert in AppleIntelPIIXATA.kext? ICH8 Part, some string <key>ICH8 ATA/100</key> <dict> <key>CFBundleIdentifier</key> <string>com.apple.driver.AppleIntelPIIXATA</string> <key>Controller Name</key> <string>ICH8 ATA/100</string> <key>IOClass</key> <string>AppleIntelPIIXATARoot</string> <key>IOPCIPrimaryMatch</key> <string>0x28508086</string> <key>IOProbeScore</key> <integer>2000</integer> <key>IOProviderClass</key> <string>IOPCIDevice</string> <key>Supported Transfer Modes</key> <string>0x3f061d</string> </dict> <key>ICH8 Serial ATA</key> <dict> <key>CFBundleIdentifier</key> <string>com.apple.driver.AppleIntelPIIXATA</string> <key>Controller Name</key> <string>ICH8 SATA</string> <key>IOClass</key> <string>AppleIntelPIIXATARoot</string> <key>IOPCIPrimaryMatch</key> <string>0x28288086</string> <key>IOProbeScore</key> <integer>2000</integer> <key>IOProviderClass</key> <string>IOPCIDevice</string> <key>PCS Port Map</key> <data> kgGTAZICkwKSBJMEkgiTCA== </data> <key>Serial ATA</key> <true/> <key>Supported Transfer Modes</key> <string>0x3f061d</string> </dict> thanks a lot... Link to comment Share on other sites More sharing options...
noob766 Posted September 7, 2009 Author Share Posted September 7, 2009 I dont get that VENDOR ID thang... OSX86 gives me nothin but: Bildschirmfoto_2009_09_07_20_01_44.tiff Once I knew my vendor / device ID... where to insert in AppleIntelPIIXATA.kext? ICH8 Part, some string <key>ICH8 ATA/100</key> <dict> <key>CFBundleIdentifier</key> <string>com.apple.driver.AppleIntelPIIXATA</string> <key>Controller Name</key> <string>ICH8 ATA/100</string> <key>IOClass</key> <string>AppleIntelPIIXATARoot</string> <key>IOPCIPrimaryMatch</key> <string>0x28508086</string> <key>IOProbeScore</key> <integer>2000</integer> <key>IOProviderClass</key> <string>IOPCIDevice</string> <key>Supported Transfer Modes</key> <string>0x3f061d</string> </dict> <key>ICH8 Serial ATA</key> <dict> <key>CFBundleIdentifier</key> <string>com.apple.driver.AppleIntelPIIXATA</string> <key>Controller Name</key> <string>ICH8 SATA</string> <key>IOClass</key> <string>AppleIntelPIIXATARoot</string> <key>IOPCIPrimaryMatch</key> <string>0x28288086</string> <key>IOProbeScore</key> <integer>2000</integer> <key>IOProviderClass</key> <string>IOPCIDevice</string> <key>PCS Port Map</key> <data> kgGTAZICkwKSBJMEkgiTCA== </data> <key>Serial ATA</key> <true/> <key>Supported Transfer Modes</key> <string>0x3f061d</string> </dict> thanks a lot... the dev id's already has it inserted in, use that kext and the AHCIPortInjector.kext and you should be okay. Link to comment Share on other sites More sharing options...
haraldschmidt Posted September 7, 2009 Share Posted September 7, 2009 I'll try that now... THX so far... Link to comment Share on other sites More sharing options...
noob766 Posted September 7, 2009 Author Share Posted September 7, 2009 Evga Nvidia Geforce 9800gt 512MB What chipset are you referring to? try this EFI string, if it doesn't work, try NVEnabler0.1.kext then after that try NVInject.kext with your dev and vendor ID placed inside <key>device-properties</key> <string>cd0300000100000001000000c10300001500000002010c00d041030a000000000101060000027 fff04003a000000400032002c0068007700730065006e0073006f0072002d0070006100720061006d 0073002d00760065007200730069006f006e000000080000000000000222000000400032002c00640 0650076006900630065005f0074007900700065000000120000004e5644412c6770752d64696f6465 0e0000004e00560050004d00000020000000010000000000000000000000000000000000000000000 000000000001e00000072006f006d002d007200650076006900730069006f006e0000000900000033 31373261100000004e00560043004100500000001800000004000000000003000c000000000000070 000000022000000400032002c002300730069007a0065002d00630065006c006c0073000000080000 000000000022000000400030002c006400650076006900630065005f00740079007000650000000b0 00000646973706c6179100000006d006f00640065006c000000200000004e5649444941204765466f 7263652039383030204754582b2045464914000000400030002c006e0061006d00650000001200000 04e5644412c446973706c61792d4120000000400032002c0063006f006d0070006100740069006200 6c0065000000160000004e5644412c73656e736f722d706172656e7414000000400031002c006e006 1006d0065000000120000004e5644412c446973706c61792d4212000000400032002c007200650067 00000008000000000000021c0000006400650076006900630065005f0074007900700065000000100 000004e5644412c4765466f72636520000000400031002c0063006f006d0070006100740069006200 6c00650000000e0000004e5644412c4e564d616326000000400032002c00230061006400720065007 30073002d00630065006c006c007300000008000000000000010e0000006e0061006d00650000000f 0000004e5644412c506172656e7422000000400031002c006400650076006900630065005f0074007 9007000650000000b000000646973706c617920000000400030002c0063006f006d00700061007400 690062006c00650000000e0000004e5644412c4e564d6163220000005600520041004d002c0074006 f00740061006c00730069007a0065000000080000000000002036000000400032002c006800770063 00740072006c002d0070006100720061006d0073002d00760065007200730069006f006e000000080 000000000000214000000400032002c006e0061006d00650000001100000073656e736f722d706172 656e74</string> Link to comment Share on other sites More sharing options...
