[HOW TO]: Make 9800GX2 work in Mac Leopard 10.5.5! QE/CI Enabled! (WORKS ON NVIDIA M/Bs ONLY!)

ffosilva · August 12, 2009

Did you installed lastest nvidia drivers for OS X? on 10.5.8 you'll need it too. after installed see older posts that says you need generate 2 gfx strings, one for each card (because 9800 gx2 internally is 2 vgas packed in sli on single slot - it have an internal pci-pci bridge).

lafouge · August 12, 2009

thanks for interest ffosilva

what do you mean by latest driver ?

i've downloaded evga driver something like a week ago ( before update ) .

i tried to install again to day and now I have those messages on boot ( on desktop display ):

the extension system "/system/library/extension/NVDAResman.kext" wasn't installed properly & cannot be use.

same for "/system/library/extension/NVDAN50Hal.kext" &"/system/library/extension/GeForce.kext"

but of course no changes ....

would you be kind enough to post what exactly is in your com.apple.Boot.plist just for me to understand well , what is wrong in mine...

thanks in advance

for info,

this is my device properties,plist

<?xml version="1.0" encoding="UTF-8"?>

<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">

<dict>

<key>PciRoot(0x1)/Pci(0x1,0x0)/Pci(0x0,0x0)/Pci(0x2,0x0)/Pci(0x0,0x0)</key>

<dict>

<key>@0,compatible</key>

<string>NVDA,NVMac</string>

<key>@0,device_type</key>

<string>display</string>

<string>NVDA,Display-A</string>

<key>@1,compatible</key>

<string>NVDA,NVMac</string>

<key>@1,device_type</key>

<string>display</string>

<string>NVDA,Display-B</string>

<key>NVCAP</key>

<data>

BAAAAAAAAwAMAAAAAAAABwAAAAA=

</data>

<data>

AQAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA==

</data>

<key>VRAM,totalsize</key>

<key>device_type</key>

<string>NVDA,Parent</string>

<key>model</key>

<string>nVidia GeForce 980gx2</string>

<string>display</string>

<key>rom-revision</key>

<string>nVidia GeForce 980gx2 OpenGL Engine [EFI]</string>

</dict>

</plist>

and this my device properties,hex

7602000001000000010000006a0200000d00000002010c00d041030a010000000101060000010101

060000000101060000020101060000007fff04000e0000004e00560050004d0000002000000001000

000000000000000000000000000000000000000000000000000220000005600520041004d002c0074

006f00740061006c00730069007a006500000008000000000000401c0000006400650076006900630

065005f00740079007000650000000f0000004e5644412c506172656e740e0000006e0061006d0065

0000000b000000646973706c617922000000400030002c006400650076006900630065005f0074007

9007000650000000b000000646973706c617922000000400031002c00640065007600690063006500

5f00740079007000650000000b000000646973706c6179100000006d006f00640065006c000000190

000006e5669646961204765466f7263652039383067783220000000400031002c0063006f006d0070

0061007400690062006c00650000000e0000004e5644412c4e564d616314000000400030002c006e0

061006d0065000000120000004e5644412c446973706c61792d4114000000400031002c006e006100

6d0065000000120000004e5644412c446973706c61792d4220000000400030002c0063006f006d007

00061007400690062006c00650000000e0000004e5644412c4e564d6163100000004e005600430041

00500000001800000004000000000003000c00000000000007000000001e00000072006f006d002d0

07200650076006900730069006f006e0000002d0000006e5669646961204765466f72636520393830

677832204f70656e474c20456e67696e65205b4546495d

lafouge · August 13, 2009

by the way how did you guys , have installed the gtx 285 drivers? the problem may come from there ...

ffosilva · August 13, 2009

Download 'Archive.zip' on older posts and try using hex strings. I think it will work for you.

ghettokid · August 13, 2009

Hello ...

First a big thanks to the whole community and especially ffosilva ...

I have the EVGA drivers installed

and my com.apple.boot.plist now looks like this:

<?xml version="1.0" encoding="UTF-8"?>

<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">

<dict>

<key>PciRoot(0x1)/Pci(0x1,0x0)/Pci(0x0,0x0)/Pci(0x2,0x0)/Pci(0x0,0x0)</key>

<dict>

<key>@0,compatible</key>

<string>NVDA,NVMac</string>

<key>@0,device_type</key>

<string>display</string>

<string>NVDA,Display-A</string>

<key>@1,compatible</key>

<string>NVDA,NVMac</string>

<key>@1,device_type</key>

<string>display</string>

<string>NVDA,Display-B</string>

<key>NVCAP</key>

<data>

BAAAAAAAAwAMAAAAAAAABwAAAAA=

</data>

<data>

AQAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA==

</data>

<key>VRAM,totalsize</key>

<key>device_type</key>

<string>NVDA,Parent</string>

<key>model</key>

<string>nVidia GeForce 9800 GX2</string>

<string>display</string>

<key>rom-revision</key>

<string>nVidia GeForce 9800 GX2 OpenGL Engine [EFI]</string>

</dict>

<key>PciRoot(0x1)/Pci(0x1,0x0)/Pci(0x0,0x0)/Pci(0x0,0x0)/Pci(0x0,0x0)</key>

<dict>

<key>@0,compatible</key>

<string>NVDA,NVMac</string>

<key>@0,device_type</key>

<string>display</string>

<string>NVDA,Display-A</string>

<key>@1,compatible</key>

<string>NVDA,NVMac</string>

<key>@1,device_type</key>

<string>display</string>

<string>NVDA,Display-B</string>

<key>NVCAP</key>

<data>

BAAAAAAAAwAMAAAAAAAABwAAAAA=

</data>

<data>

AQAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA==

</data>

<key>VRAM,totalsize</key>

<key>device_type</key>

<string>NVDA,Parent</string>

<key>model</key>

<string>nVidia GeForce 9800 GX2</string>

<string>display</string>

<key>rom-revision</key>

<string>nVidia GeForce 9800 GX2 OpenGL Engine [EFI]</string>

</dict>

</plist>

Now I ask the following:

1. Where does the hex inside and how do I get the hex?

2. Where I have to do the -f command one time?

MB: P5Q Pro

OS X: iAktos v7 10.5.7

lafouge · August 13, 2009

thanks ffosilva for interest & support,

I'll try the archive files asap, and will provide feedback

finger cross.

qualsiasi · August 13, 2009

hello, i recently changed my mobo with a xfx 780i nforce.

im trying make my 9800gx2 work by following this instructions.

with gfxutil i get this display:

DevicePath = PciRoot(0x1)/Pci(0x3,0x0)/Pci(0x0,0x0)/Pci(0x0,0x0)/Pci(0x0,0x0)/Pci(0x2,0x0)/Pci(0x0,0x0)

with pacifist i installed all evga drivers kext.

i tried Archive.zip device-propierties string in boot.plist.

rebooted with -f and nothing changed, i mean i got usual fram buffer desktop as i did it no changes.

Im running iAktos with 10.5.8.

Any suggestions?

lafouge · August 14, 2009

hi guys,

I have some changes because now my resolution is 1680*1050 but that's it

"in about this mac " we have:

Type : Moniteur

Bus : PCIe

Longueur de la voie PCIe : x16

VRAM (totale) : 32 Mo

Fournisseur : NVIDIA (0x10de)

Identifiant du périphérique : 0x0604

Identifiant de révision : 0x00a2

Moniteurs :

Moniteur de type inconnu :

Résolution : 1680 x 1050

Profondeur : Couleurs 32 bits

Core Image : Logiciel

Moniteur principal : Oui

Miroir : Désactivé

Connecté : Oui

Quartz Extreme : Non géré

so 2 solutions:

either the archive files don't work with my hardware, either I made a syntax error in the com.apple.boot.plist

see under :

<?xml version="1.0" encoding="UTF-8"?>

<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">

<dict>

<key>Kernel</key>

<string>mach_kernel</string>

<key>Kernel Flags</key>

<key>Timeout</key>

<key>PciRoot(0x1)/Pci(0x1,0x0)/Pci(0x0,0x0)/Pci(0x0,0x0)/Pci(0x0,0x0)</key>

<dict>

<key>@0,compatible</key>

<data>

TlZEQSxOVk1hYw==

</data>

<key>@0,device_type</key>

<data>

ZGlzcGxheQ==

</data>

<data>

TlZEQSxEaXNwbGF5LUE=

</data>

<key>@1,compatible</key>

<data>

TlZEQSxOVk1hYw==

</data>

<key>@1,device_type</key>

<data>

ZGlzcGxheQ==

</data>

<data>

TlZEQSxEaXNwbGF5LUI=

</data>

<key>@2,#adress-cells</key>

<data>

AAAAAQ==

</data>

<key>@2,#size-cells</key>

<data>

AAAAAA==

</data>

<key>@2,compatible</key>

<data>

TlZEQSxzZW5zb3ItcGFyZW50

</data>

<key>@2,device_type</key>

<data>

TlZEQSxncHUtZGlvZGU=

</data>

<key>@2,hwctrl-params-version</key>

<data>

AAAAAg==

</data>

<key>@2,hwsensor-params-version</key>

<data>

AAAAAg==

</data>

<data>

c2Vuc29yLXBhcmVudA==

</data>

<data>

AAAAAg==

</data>

<key>NVCAP</key>

<data>

BAAAAAAAAwAAAAAAAAAABwAAAAA=

</data>

<data>

AQAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA==

</data>

<key>VRAM,totalsize</key>

<data>

AAAAIA==

</data>

<key>device_type</key>

<data>

TlZEQSxHZUZvcmNl

</data>

<key>model</key>

<data>

TlZJRElBIEdlRm9yY2UgOTgwMCBHWDI=

</data>

<data>

TlZEQSxQYXJlbnQ=

</data>

<key>rom-revision</key>

<data>

MzE3MmE=

</data>

</dict>

<key>PciRoot(0x1)/Pci(0x1,0x0)/Pci(0x0,0x0)/Pci(0x2,0x0)/Pci(0x0,0x0)</key>

<dict>

<key>@0,compatible</key>

<data>

TlZEQSxOVk1hYw==

</data>

<key>@0,device_type</key>

<data>

ZGlzcGxheQ==

</data>

<data>

TlZEQSxEaXNwbGF5LUE=

</data>

<key>@1,compatible</key>

<data>

TlZEQSxOVk1hYw==

</data>

<key>@1,device_type</key>

<data>

ZGlzcGxheQ==

</data>

<data>

TlZEQSxEaXNwbGF5LUI=

</data>

<key>@2,#adress-cells</key>

<data>

AAAAAQ==

</data>

<key>@2,#size-cells</key>

<data>

AAAAAA==

</data>

<key>@2,compatible</key>

<data>

TlZEQSxzZW5zb3ItcGFyZW50

</data>

<key>@2,device_type</key>

<data>

TlZEQSxncHUtZGlvZGU=

</data>

<key>@2,hwctrl-params-version</key>

<data>

AAAAAg==

</data>

<key>@2,hwsensor-params-version</key>

<data>

AAAAAg==

</data>

<data>

c2Vuc29yLXBhcmVudA==

</data>

<data>

AAAAAg==

</data>

<key>NVCAP</key>

<data>

BAAAAAAAAwAEAAAAAAAABwAAAAA=

</data>

<data>

AQAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA==

</data>

<key>VRAM,totalsize</key>

<data>

AAAAIA==

</data>

<key>device_type</key>

<data>

TlZEQSxHZUZvcmNl

</data>

<key>model</key>

<data>

TlZJRElBIEdlRm9yY2UgOTgwMCBHWDI=

</data>

<data>

TlZEQSxQYXJlbnQ=

</data>

<key>rom-revision</key>

<data>

MzE3MmE=

</data>

</dict>

<string>0e0800000100000002000000010400001600000002010c00d041030a010000000101060000010

101060000000101060000020101060000007fff0400220000004100410050004c002c0073006c006f

0074002d006e0061006d006500000011000000504349652078313620536c6f7422000000400032002

c006400650076006900630065005f0074007900700065000000120000004e5644412c6770752d6469

6f64650e0000004e00560050004d00000020000000010000000000000000000000000000000000000

000000000000000001e00000072006f006d002d007200650076006900730069006f006e0000000900

00003331373261100000004e005600430041005000000018000000040000000000030004000000000

000070000000022000000400032002c002300730069007a0065002d00630065006c006c0073000000

080000000000000022000000400030002c006400650076006900630065005f0074007900700065000

0000b000000646973706c6179100000006d006f00640065006c0000001b0000004e56494449412047

65466f72636520393830302047583214000000400030002c006e0061006d0065000000120000004e5

644412c446973706c61792d4120000000400032002c0063006f006d00700061007400690062006c00

65000000160000004e5644412c73656e736f722d706172656e741c000000640065007600690063006

5005f0074007900700065000000100000004e5644412c4765466f72636514000000400031002c006e

0061006d0065000000120000004e5644412c446973706c61792d4212000000400032002c007200650

067000000080000000000000220000000400031002c0063006f006d00700061007400690062006c00

650000000e0000004e5644412c4e564d616326000000400032002c002300610064007200650073007

3002d00630065006c006c007300000008000000000000010e0000006e0061006d00650000000f0000

004e5644412c506172656e7422000000400031002c006400650076006900630065005f00740079007

000650000000b000000646973706c617920000000400030002c0063006f006d007000610074006900

62006c00650000000e0000004e5644412c4e564d6163220000005600520041004d002c0074006f007

40061006c00730069007a0065000000080000000000002036000000400032002c0068007700630074

0072006c002d0070006100720061006d0073002d00760065007200730069006f006e0000000800000

00000000214000000400032002c006e0061006d00650000001100000073656e736f722d706172656e

743a000000400032002c0068007700730065006e0073006f0072002d0070006100720061006d00730

02d00760065007200730069006f006e0000000800000000000002010400001600000002010c00d041

030a010000000101060000010101060000000101060000000101060000007fff04002200000041004

10050004c002c0073006c006f0074002d006e0061006d006500000011000000504349652078313620

536c6f7422000000400032002c006400650076006900630065005f007400790070006500000012000

0004e5644412c6770752d64696f64650e0000004e00560050004d0000002000000001000000000000

0000000000000000000000000000000000000000001e00000072006f006d002d00720065007600690

0730069006f006e000000090000003331373261100000004e00560043004100500000001800000004

0000000000030000000000000000070000000022000000400032002c002300730069007a0065002d0

0630065006c006c0073000000080000000000000022000000400030002c0064006500760069006300

65005f00740079007000650000000b000000646973706c6179100000006d006f00640065006c00000

01b0000004e5649444941204765466f72636520393830302047583214000000400030002c006e0061

006d0065000000120000004e5644412c446973706c61792d4120000000400032002c0063006f006d0

0700061007400690062006c0065000000160000004e5644412c73656e736f722d706172656e741c00

00006400650076006900630065005f0074007900700065000000100000004e5644412c4765466f726

36514000000400031002c006e0061006d0065000000120000004e5644412c446973706c61792d4212

000000400032002c007200650067000000080000000000000220000000400031002c0063006f006d0

0700061007400690062006c00650000000e0000004e5644412c4e564d616326000000400032002c00

23006100640072006500730073002d00630065006c006c007300000008000000000000010e0000006

e0061006d00650000000f0000004e5644412c506172656e7422000000400031002c00640065007600

6900630065005f00740079007000650000000b000000646973706c617920000000400030002c00630

06f006d00700061007400690062006c00650000000e0000004e5644412c4e564d6163220000005600

520041004d002c0074006f00740061006c00730069007a00650000000800000000000020360000004

00032002c00680077006300740072006c002d0070006100720061006d0073002d0076006500720073

0069006f006e000000080000000000000214000000400032002c006e0061006d00650000001100000

073656e736f722d706172656e743a000000400032002c0068007700730065006e0073006f0072002d

0070006100720061006d0073002d00760065007200730069006f006e0000000800000000000002</string>

<key>Graphics Mode</key>

</dict>

</plist>

anything sound weird in it ?

ffosilva · August 15, 2009

anything sound weird in it ?

A lot! hahahha

You need only put copy .hex file content and your com.apple.Boot.plist will be:

<?xml version="1.0" encoding="UTF-8"?>

<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">

<dict>

<key>Kernel</key>

<string>mach_kernel</string>

<key>Kernel Flags</key>

<key>Timeout</key>

<key>device-properties</key>
