f-pierre-76 Posted June 17, 2017 Share Posted June 17, 2017 Hey, I'm new here and i want install Mac OS Sierra on my Asus computer, It's an : -Asus rog G20CB with an intel core i5-6400 2.70GHZ -1x8GB of ram-Nvidia GeForce GTX 950 Ask me for other specs info. The problem appear when I want to boot on my install usb drive, the logo of apple appear but after 4 or 5 seconds an error stop all the job. I have take a picture to show you the problem. What can I do please, for continue the installation ? Thanks for your help ? Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/ Share on other sites More sharing options...
GIEBELWALD Posted June 17, 2017 Share Posted June 17, 2017 Is FakeSMC.kext in place? Wich Clover Version is in use? Set nv_disable=1? OsxAptioFix2Drv-64.efi or OsxAptioFixDrv-64.efi? Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446328 Share on other sites More sharing options...
f-pierre-76 Posted June 17, 2017 Author Share Posted June 17, 2017 Yes I think, I have made my Mac OS drive with #####. I thought it was the easiest way to make a "stable" usb drive. How can I check that ? O I can't talk about insanelymac software ? Sorry ... Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446331 Share on other sites More sharing options...
GIEBELWALD Posted June 17, 2017 Share Posted June 17, 2017 According to the Rules I can not see the tool you used. Use Diskutil to mount diskXs1 (EFI Partition of your USB Stick) and copy FakeSMC to /kexts/other/ and /kexts/10.12 also create a 10.13 folder and add also here FakeSMC, just to be sure. I'd prefer the "createmedia way" to create an USB Stick. Here are many infos how it can be done: http://www.insanelymac.com/forum/topic/324233-mac-os-high-sierra-installation-attempts/ Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446337 Share on other sites More sharing options...
f-pierre-76 Posted June 17, 2017 Author Share Posted June 17, 2017 Okay so I prefer create a new usb drive to continue in the right way. Can you give me a topic or a tutorial who show how can i do properly ? Sorry I feel like you're wasting your time ... Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446353 Share on other sites More sharing options...
GIEBELWALD Posted June 17, 2017 Share Posted June 17, 2017 There is no proper tutorial right now. I think you have to read a lot of topics. Create the Stick: sudo /Applications/Install\ macOS\ 10.13\ beta.app/Contents/Resources/createinstallmedia --volume /Volumes/USB --applicationpath /Applications/Install\ macOS\ 10.13\ beta.app Then install Clover r4088. Add needed Kexts. And apfs.efi... Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446371 Share on other sites More sharing options...
Cyberdevs Posted June 17, 2017 Share Posted June 17, 2017 Hey, I'm new here and i want install Mac OS Sierra on my Asus computer, It's an : -Asus rog G20CB with an intel core i5-6400 2.70GHZ -1x8GB of ram -Nvidia GeForce GTX 950 Ask me for other specs info. The problem appear when I want to boot on my install usb drive, the logo of apple appear but after 4 or 5 seconds an error stop all the job. I have take a picture to show you the problem. What can I do please, for continue the installation ? Thanks for your help Hi and welcome Do you want to instal macOS Sierra or macOS High Sierra? Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446533 Share on other sites More sharing options...
f-pierre-76 Posted June 17, 2017 Author Share Posted June 17, 2017 I want install macOS Sierra, not Hight Sierra. Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446535 Share on other sites More sharing options...
Cyberdevs Posted June 17, 2017 Share Posted June 17, 2017 Ok the command for creating the macOS Sierra is: sudo /Applications/Install\ macOS\ Sierra.app/Contents/Resources/createinstallmedia --volume /Volumes/Untitled --applicationpath /Applications/Install\ macOS\ Sierra.app --nointeraction The command Giebelwald posted it for macOS High Sierra Do you have access to a Mac or a working hackintosh? Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446538 Share on other sites More sharing options...
f-pierre-76 Posted June 17, 2017 Author Share Posted June 17, 2017 I have accès to a MacBook Air EARLY2015 Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446541 Share on other sites More sharing options...
Cyberdevs Posted June 17, 2017 Share Posted June 17, 2017 You can follow this guide to get your USB installer ready. http://www.insanelymac.com/forum/topic/324138-guide-install-macos-sierra-10125-on-ga-z170x-gaming-5/ read the guide to the "Post Installation" part. From there some things are different for your pc. for post installation you'll a DSDT for your mother board For Audio you can use AppleALC.kext, Lilu.kext For USB you'll need a custom SSDT, although you might have fully functional USB ports with just Clover Patches. For Video Card you'll need to install nVidiaWebDrivers Last but not least you'll need the latest version of FakeSMC.kext to be able to boot into macOS. Update: You can also post your clover folder for the installer you use for examinations. Before you do post the EFI folder you are using remove "APPLE" folder and the serial number from the config.plist Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446545 Share on other sites More sharing options...
f-pierre-76 Posted June 18, 2017 Author Share Posted June 18, 2017 Thanks a lot cyberdevs and GIEBELWALD !! Now I'm at the step of the configuration of the config.plist, but I don't know ho to configure and what can I must change. I will show you my configuration, G20CB-FR039T (the name serial of my computer) Open the attached files to view my configuration. I have join my folder of the EFI partition. The folder is blank, I have not modified anything yet. Is it good ? specs.txt EFI.zip 1 Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446838 Share on other sites More sharing options...
Cyberdevs Posted June 18, 2017 Share Posted June 18, 2017 Thanks a lot cyberdevs and GIEBELWALD !! Now I'm at the step of the configuration of the config.plist, but I don't know ho to configure and what can I must change. I will show you my configuration, G20CB-FR039T (the name serial of my computer) Open the attached files to view my configuration. I have join my folder of the EFI partition. The folder is blank, I have not modified anything yet. Is it good ? Have you configure the BIOS properly? Is everything in place? Replace your EFI folder with this one and let me know how it goes. EFI-01.zip 1 Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446842 Share on other sites More sharing options...
f-pierre-76 Posted June 18, 2017 Author Share Posted June 18, 2017 Thanks man !!!! It's working! I can install Mac OS. The install is in progress. I will tell you what's going after the end of the installation 1 Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446847 Share on other sites More sharing options...
Cyberdevs Posted June 18, 2017 Share Posted June 18, 2017 Thanks man !!!! It's working! I can install Mac OS. The install is in progress. I will tell you what's going after the end of the installation Very Nice You're welcome Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446850 Share on other sites More sharing options...
f-pierre-76 Posted June 18, 2017 Author Share Posted June 18, 2017 It's good ! I can boot on Mac OS ! Now I mus install clover on my hard drive to boot without my USB key isn't ? And install pilotes for my devices ? Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446887 Share on other sites More sharing options...
Cyberdevs Posted June 18, 2017 Share Posted June 18, 2017 You can simply mount the EFI partition on the drive you've just installed macOS to an copy/paste the folder I posted. Use clover configurator to mount the EFI partition. Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446895 Share on other sites More sharing options...
f-pierre-76 Posted June 18, 2017 Author Share Posted June 18, 2017 Thanks, it's working ! I have install the Nvidia driver, How can I know what kext I must have for my wifi and audio devices ? Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446913 Share on other sites More sharing options...
Cyberdevs Posted June 18, 2017 Share Posted June 18, 2017 Great! For audio I already added what's needed, You'll need to have AppleALC.kext and Lilu.kext. HDMI Audio will be activated after installing the nVidia WebDrives and if it didn't you'll need to use a patched DSDT/SSDT There are other options for activating HDMI audio without a patched DSDT. You can use cloverHDMI command by Toleda, google it if your audio doesn't start let me know and I will find a way to fix it. Your WiFi might not be supported I need to check that about to see what chipset is in the WiFi adapter. Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446919 Share on other sites More sharing options...
f-pierre-76 Posted June 18, 2017 Author Share Posted June 18, 2017 I have install AppleALC.kext and lilu.kext but the sound card doesn't appear in the settings ... Not again with a reboot .. Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446934 Share on other sites More sharing options...
Cyberdevs Posted June 18, 2017 Share Posted June 18, 2017 Ok, download IOJones or IORegistryexplorer run it, save the results and send the file is I can see what's wrong. Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446937 Share on other sites More sharing options...
f-pierre-76 Posted June 18, 2017 Author Share Posted June 18, 2017 Is it the right files that you want ? Pierre’s iMac.zip Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446947 Share on other sites More sharing options...
Cyberdevs Posted June 18, 2017 Share Posted June 18, 2017 The layout ID for audio is not detected correctly. Open the config.plist and under the devices/audio try with ID 3 and if it didn't work try ID 3 and let me know Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446961 Share on other sites More sharing options...
f-pierre-76 Posted June 18, 2017 Author Share Posted June 18, 2017 The config.plist files in my EFI Partition ? yes I have change to 3 and it's working !! Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446976 Share on other sites More sharing options...
fivos1996 Posted June 18, 2017 Share Posted June 18, 2017 Hi there and congratulations. Does this mobo have a Broadcom wifi card? Link to comment https://www.insanelymac.com/forum/topic/324531-panic-cpu-error-os-sierra-install/#findComment-2446980 Share on other sites More sharing options...
