Gigabyte H87 D3H + GTX 560ti + Intel Xeon: Sound + VGA problem.

Recommended Posts

Hi, I success to install Mac OSX on my system. I have 2 problems:

- VGA problem: The system now can show my Graphics is: GTX 560ti. But cannot change resolution.


- No Sound: I tried (manually) install VooDooHDA. But not success, the VooDooHDA say that No VooDooHDA devices detected.



My Mainboard is: Gigabyte H87 D3H. The audio chip is: Realtek® ALC892 codec. http://www.gigabyte.vn/products/product-page.aspx?pid=4491#sp


VGA: Sparkle GTX 560ti.


My CPU is Xeon 1230 v3 (No integrated graphics).



Does any encounted the same problems as my? Any help is very appreciated.

Share this post

Link to post
Share on other sites

Updated to DP2, edited the Info.plist. Installed CUDA driver.

Not works.

When I boot straight (no boot flags), or -v only: the system boot but in the last moment, my monitor turn off!

It only boot with: -v -f.

I can see something like: Couldn't load NVAccelerator.

Share this post

Link to post
Share on other sites



_ I updated my ML 10.9 from DP2 to DP3.

_ Tried installing the VooDooHDA.Lion.


Got the kernel panic.

Go to the USB, reinstall Extra folder using myHack.


Boot straight to OSX (no need any boot flag).


Holy !!!!!!!!!!!!!! => System have sound !!!!


_ Shut down function: Work.

_ Restart function: Work.

_ Sleep: when I hit sleep, black screen appear with a mouse icons, Moving the mouse, desktop show again (some kind of screen saver?). But the CPU fan still run. Not sure sleep function works properly or not.



Now I only need one step to perfection: Make the GTX 560ti to WORK!



Any advice is very appreciated.

Share this post

Link to post
Share on other sites

Now I have a great news and a bad news.

I tried an app called FrezzerFix. (on a site, you knows what I mean...). Thx to FusselFuz.

I updated my 10.9 to DP4.

After that I cannot boot, the screen turn off after boot.


Then I have to reinstall my extra folder (this method saves me thousand of times).


Then I boot straight to OSX.


The miracle being: Full resolution ! and Dual Monitor !

That is the good news.


But there's the bad news:

1. System animation very slow

2. Safari flickering!

3. Can open chess app, but it's very slow

4. Can not review other screen saver.



How can I enable full hardware acceleration on my GTX 560ti?

Share this post

Link to post
Share on other sites

Breaking news:

_ The problem is: My 2nd Monitor connected via VGA cable.

Solution: Turn off that monitor.


Now I can happily announce that: My system is fully hackintoshed ! (Mavericks 10.9 SP6).

+ VGA GTX 560ti: Fully works!

+ Mainboard:

  1. Shutdown; Restart; and Sleep: Fully works.
  2. Audio: Yes.
  3. Network: Yes.

Thx you so much to everyone in the forums and over internet help me with my mackintosh process.


Happy weekend!



Share this post

Link to post
Share on other sites

My system fools me every time.

Now: The second monitor (VGA) also works ! (Don't know what I did).

Even when i turn it off, system still works in 2 monitors (When drag windows, they disappears !).


Now, I can say that my mackintosh system is COMPLETE!

Share this post

Link to post
Share on other sites

I don't need any boot flags, just choose the OSX disk and it go in !

I think it uses default option: GraphicsEnabler=Yes npci=0x2000 (in the chameleon boot list).


But when I install new kext, sometime it cause kernel panic, then I just have to reinstall Extra folder using MyHack, and everything is fine !

Share this post

Link to post
Share on other sites
