Vollstein

Asus P9X79 SATA RAID Controller

3 posts in this topic

Recommended Posts

I have a RAID0 with two of my OCZ Vertex 3 240Gb SSD disk's, how i may use this controller in OSX 10.8? It's possible?



240-256GB Max Performance

  • Max Read: up to 550MB/s
  • Max Write: up to 520MB/s
  • Random Write 4KB: 60,000 IOPS
  • Maximum 4K Random Write: 85,000 IOPS



http://www.asus.com/...#specifications



Storage

Intel® X79 chipset :

2 x SATA 6Gb/s port(s), white

4 x SATA 3Gb/s port(s), blue

Support Raid 0, 1, 5, 10



Share this post


Link to post
Share on other sites
