mayhemm88 Posted August 10, 2011 Author Share Posted August 10, 2011 OK, so i have everything up and running but I am having a couple of issues 1. How does one get shutdown to work properly with this laptop... it is not powering down the laptop all the way 2. does anyone have a DSDT file for this particular laptop/is it possible to run with AppleCPUPowerManagement.kext instead of NullCPUPowerManagement.kext 3. How do you get the OS to dim the screen automatically, or get the Fn Key on the laptop working to dim the display in battery mode Other than those issues, it appears I have a rather nice hackintosh laptop. Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1732519 Share on other sites More sharing options...
Aim Posted August 10, 2011 Share Posted August 10, 2011 Hey guys, I have managed to install Lion on my work laptop, which is an E6520 (obviously!) but I can't get the HD3000 to work. I don't have any discrete graphic card unfortunately, only the crappy Intel HD setup. I managed to have 1024x768 w/o QE/CI. My e6520 has a Quadcore I5-2520M 2.5Ghz which means Intel HD3000+. Given that the HD 3000+ device id is 0x126, it should work out of the box, since similar to the new Mac mini setup. I tried a couple of fixes like hex editing the hex editing the AppleIntelSNBGraphicsFB kext to modify the number of connectors but it didn't help. I tried only enabling the LVDS connector for instance ... didn't help. I'm curious to know if anybody else managed to get it to work... Cheers, Happy hacking. Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1733011 Share on other sites More sharing options...
Veeper Posted August 18, 2011 Share Posted August 18, 2011 Just got a E6320 with no Nvidia, only Intel HD graphics. Lion is installed and updated to 10.7.1 Not working: Wireless Keyboard mouse (will try other kext here shortly) Graphics are detected but I'm getting tearing. Haven't tried power or CPU settings testing yet. I'm a huge noob at this so I'll keep my chatter to a minimum here and let you guys know if something does/doesn't work as I go at this. Thanks. Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1736680 Share on other sites More sharing options...
Aim Posted August 18, 2011 Share Posted August 18, 2011 Hey, I'm wondering if you didn't anything specific to get the graphics to work. Do you have native resolution and QE/CI? If so, what smbios did you use? Any DSDT mods? Thanks, C. Just got a E6320 with no Nvidia, only Intel HD graphics. Lion is installed and updated to 10.7.1 Not working: Wireless Keyboard mouse (will try other kext here shortly) Graphics are detected but I'm getting tearing. Haven't tried power or CPU settings testing yet. I'm a huge noob at this so I'll keep my chatter to a minimum here and let you guys know if something does/doesn't work as I go at this. Thanks. Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1736829 Share on other sites More sharing options...
Veeper Posted August 22, 2011 Share Posted August 22, 2011 Hey, I'm wondering if you didn't anything specific to get the graphics to work. Do you have native resolution and QE/CI? If so, what smbios did you use? Any DSDT mods? Thanks, C. Greetings! I used TonyMac's install method for 10.6.3 -> 10.6.7 Then I set the system identifier to MacBookPro 8,1 and Lion had no issues installing after that, and it automagically saw that I had an Intel 3000. Initially I had some graphics tearing, but today it hasn't shown up yet. I'll see if it shows up again. EDIT - Screen tearing is still a huge issue. I must have the wrong device ID or something? QE/CI seems to be working aside from that. Res shows up as native 1366x768. I'll paste a screenshot on here from that notebook shortly. Hope this helps. (Me being such a hackintosh n00b, you may need to be more specific with your question, or ask me for screenshot or information from the console.) Anyone (6420, 6520, 6320) have a sleepenabler or power kexts/edit/config suggestion for me? EDIT - going to see if I can get a DSDT from Maldon. Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1738482 Share on other sites More sharing options...
Veeper Posted September 2, 2011 Share Posted September 2, 2011 I forgot to reply to this and add that 10.7.1 and Chimera 1.5 seemed to fix all of my video issues. Also there's an extra PCIe slot in the 6320 which allowed me to add a BCM94322 which seemed to work OOB in Lion. Still no sleep. Anyone have luck with sleep on their 6320/6420/6520? Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1743526 Share on other sites More sharing options...
328ti Posted September 7, 2011 Share Posted September 7, 2011 I have an E6420 with NVS4200s, installed lion and updated to 10.7. I've got everything working except sleep and external display, also it does not shutdown completely. I replaced the wireless card to an AR9280 to make wifi work. Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1745409 Share on other sites More sharing options...
tarekibrahim83 Posted September 17, 2011 Share Posted September 17, 2011 Everybody with the Nvidia NVS4200 video card. WHen you launch iPhoto does the slideshow work? ANd when you launch iMovie and assemble a clip can you preview it properly? If so what do you have installed. Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1749654 Share on other sites More sharing options...
Random Hajile Posted September 20, 2011 Share Posted September 20, 2011 I used these files (attached). Be sure to put them in /System/Library/Extensions and rebuild the cache or boot with the -x option once. This works great for getting the keyboard/trackpad working. However, the trackpad is so sensitive (and huge) that I'm constantly moving my cursor accidentally. The trackpad isn't recognized as an actual trackpad and so doesn't show up in the system preferences, but does anybody know how I might temporarily disable the trackpad? I'd still like to use the keyboard on the laptop, but would rather stick with a mouse when possible. Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1750813 Share on other sites More sharing options...
GrimmVarg Posted September 27, 2011 Share Posted September 27, 2011 This works great for getting the keyboard/trackpad working. However, the trackpad is so sensitive (and huge) that I'm constantly moving my cursor accidentally. The trackpad isn't recognized as an actual trackpad and so doesn't show up in the system preferences, but does anybody know how I might temporarily disable the trackpad? I'd still like to use the keyboard on the laptop, but would rather stick with a mouse when possible. Any progress for you guys? Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1753404 Share on other sites More sharing options...
Theta Posted September 27, 2011 Share Posted September 27, 2011 Any progress for you guys? Unfortunately, I left my position with my company so I no longer have this laptop. I apologize, but there's nothing more I can offer. Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1753533 Share on other sites More sharing options...
willpower101 Posted October 22, 2011 Share Posted October 22, 2011 Bump, If there's no progress on this then I'm thinking of selling it and getting the hp probook 4530s instead. Most stuff works out of the box. Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1763364 Share on other sites More sharing options...
willpower101 Posted October 26, 2011 Share Posted October 26, 2011 Well, I've done some cursory research on this and it looks the dell latitude E series refresh, while a really nice set of hardware, simply doesn't have the following that some other laptops have. Fortunately they fetch a pretty penny on ebay. Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1764727 Share on other sites More sharing options...
Baddy_FX Posted November 7, 2011 Share Posted November 7, 2011 Hi, I have an Dell E6520 laptop too. I try to install Lion for hours now. No matter how I try to install lion (the tutorial from this post, [url="http://www.insanelymac.com/forum/topic/279450-why-insanelymac-does-not-support-tonymacx86/"]#####[/url], rboot, . . .) I get this error: unable to open var db bootcache.playlist 2 no such file or directory I googled alot but nothing I found helped me. Any ideas? Regards Felix Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1768569 Share on other sites More sharing options...
jmac_qld Posted November 9, 2011 Share Posted November 9, 2011 Does anyone know how to properly install Chameleon? I was using the guide which worked great on my D620 but on the E6520, I'm getting the boot0: error... I've tried everything I could find on the internet. It works fine if I boot off the Chameleon USB stick.. I use Chimera (installed through [url="http://www.insanelymac.com/forum/topic/279450-why-insanelymac-does-not-support-tonymacx86/"]#####[/url]). Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1769131 Share on other sites More sharing options...
LatinMcG Posted November 9, 2011 Share Posted November 9, 2011 wireless device id is 4727 not 43xx so no it wont work. the AR9280 is AR5B91 on Ebay. (if u use 10.5 also= it wont work due to driver being apple included in 10.6.3+ so use instead BCM94321MC) Hi, I have an Dell E6520 laptop too. I try to install Lion for hours now. No matter how I try to install lion (the tutorial from this post, [url="http://www.insanelymac.com/forum/topic/279450-why-insanelymac-does-not-support-tonymacx86/"]#####[/url], rboot, . . .) I get this error: unable to open var db bootcache.playlist 2 no such file or directory I googled alot but nothing I found helped me. Any ideas? Regards Felix boot with -x UseKernelCache=No Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1769141 Share on other sites More sharing options...
m45k Posted December 2, 2011 Share Posted December 2, 2011 Hello guys, im new here and have a couple of questions. i have an e6520 with nvidia card without a dvd-drive. i tried to install iaktos L2 with an USB-Stick, but the laptop doesnt boot up from the USB-Stick .. i created the stick under OS X Lion on my other PC and the stick is booting with this pc. my second question is, how long is the battery life with mac os and the nvidia card? Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1775319 Share on other sites More sharing options...
LatinMcG Posted December 3, 2011 Share Posted December 3, 2011 Hello guys, im new here and have a couple of questions. i have an e6520 with nvidia card without a dvd-drive. i tried to install iaktos L2 with an USB-Stick, but the laptop doesnt boot up from the USB-Stick .. i created the stick under OS X Lion on my other PC and the stick is booting with this pc. my second question is, how long is the battery life with mac os and the nvidia card? EDIT: in disk utility have to go to partition of usb. create 1 and click advanced then select GUID. then u can do the restore the .dmg to usb then install chameleon and the fakesmc and dsdt and smbios Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1775619 Share on other sites More sharing options...
GrimmVarg Posted December 6, 2011 Share Posted December 6, 2011 have to go to partition of usb. create 1 and click advanced then select GUID. then u can do the restore the .dmg to usb then install chameleon and the fakesmc and dsdt and smbios Have you made any progress on suspend and graphics? The last time I tried this none of them worked. And I would really like to get rid of my linux mint install XD Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1776123 Share on other sites More sharing options...
LatinMcG Posted December 6, 2011 Share Posted December 6, 2011 uhh didnt know sleep was broken. likely usb EHCI fix needed or _OSI Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1776177 Share on other sites More sharing options...
willpower101 Posted December 6, 2011 Share Posted December 6, 2011 uhh didnt know sleep was broken. likely usb EHCI fix needed or _OSI Yes, the thread mentions several times that sleepenabler.kext doesn't work with this laptop. I think I know what usb ECHI Fix is, but what is _OSI. I'll grab a second drive and install osx on this laptop right now if you think we can get sleep working! It's the ONLY thing it's lacking other than audio over hdmi. Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1776228 Share on other sites More sharing options...
LatinMcG Posted December 6, 2011 Share Posted December 6, 2011 _osi on acpi is the OS like Windows 2009 is win 7 and so. on a desktop i worked on the wake would not work till "Windows 2006" was replaced with Darwin Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1776240 Share on other sites More sharing options...
m45k Posted December 10, 2011 Share Posted December 10, 2011 my laptop is now running with Lion and a lot of stuff is working. my graphic card is recognized correctly as a NVS 4200M. Touchpad and Keyboard are working, but Touchpad is a mouse and not a trackpad, so 2-finger scrolling is not working. on the osx86project wiki is someone who posted that on his e6420 the 2-finger scrolling is working with the VoodooPS2TrackPad kext, but for me it is not working with this, maybe i do something wrong. restarting the computer is working, but shutting down not. Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1777268 Share on other sites More sharing options...
tarekibrahim83 Posted December 10, 2011 Share Posted December 10, 2011 my laptop is now running with Lion and a lot of stuff is working. my graphic card is recognized correctly as a NVS 4200M. Touchpad and Keyboard are working, but Touchpad is a mouse and not a trackpad, so 2-finger scrolling is not working. on the osx86project wiki is someone who posted that on his e6420 the 2-finger scrolling is working with the VoodooPS2TrackPad kext, but for me it is not working with this, maybe i do something wrong. restarting the computer is working, but shutting down not. When you say a lot of stuff is working. Does the slideshow on iphoto work and videos in imovie work? Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1777276 Share on other sites More sharing options...
LatinMcG Posted December 10, 2011 Share Posted December 10, 2011 try this one http://www.insanelymac.com/forum/index.php?showtopic=240639 Link to comment https://www.insanelymac.com/forum/topic/261313-osx-on-dell-latitude-e6520/page/2/#findComment-1777297 Share on other sites More sharing options...
