careerxcriminal

Can't Even Get To macOS Installer!

2 posts in this topic

Recommended Posts

I'm using a HP AIO trying to boot Mojave. Both matter what distro I use, it never boots past a small portion on the line and in verbose it fails at "thread 0 crash". I've tried using "LogEveryBoot" and the debug flags but it will not save any logs for me to look over since verbose goes way to quick to read, even while recording. I've set all bios to the needed settings. Can someone help me get the logs so I can post and hopefully receive some help?

Current setup:

HP C0063W Intel Celeron G4900T

Intel UHD 610

4GB Ram

Share this post


Link to post
Share on other sites
Advertisement

Create an account or sign in to comment

You need to be a member in order to leave a comment

Create an account

Sign up for a new account in our community. It's easy!

Register a new account

Sign in

Already have an account? Sign in here.

Sign In Now
Sign in to follow this
Followers 0

  • Recently Browsing   0 members

    No registered users viewing this page.

Announcements

  • Similar Content

    • By Raffay1234
      I'm transitioning from Clover to Opencore. I thought the process will be simpler but it turns out it isn't. I have created a bootable Catalina USB with Opencore but stuck at this error. I have attached my EFI and the verbose output. Anyone please provide some guidance please?

      The laptop is HP Pavilion 15 Gaming:
      Intel Core i7-9750H
      16GB RAM
      256GB SSD + 1TB SSD
      PS2 Keyboard + I2C Trackpad


      EFI.zip
    • By rawmassen
      Hi there,

      If anyone could help I'd be very grateful, I'm trying to move from Clover to OC but have hit a brick wall for the last 2 days.

      It's an ACPI table error: SB_.PCIO.XHC_RHUB.HS11, Namespace lookup failure.



      Skylake Build:
      OpenCore 0.5.9
      Mojave 10.14.6, iMac17,1
      Asus Maximus Hero VIII
      6700K

      I've attached the config.plist and ACPI folder.

      EFI Drivers: OpenRuntime.efi and HfsPlus.efi
      Kexts: IntelMausi, Lilu, VirtualSMC, Whatevergreen

      Things I've tried...

      1) Clearing NVRAM (as it was previously booted by Clover)

      2) Hackintool USB Mapping: both the SSDT files and the USBPorts.kext

      3) USBInjectAll.kext (with and without SSDT files)

      4) SSDT-RHUB.aml. This seems to be directly involved, spent a long time with this but with no luck.

      I followed this guide:

      https://dortania.github.io/Getting-Started-With-ACPI/Universal/rhub-methods/manual.html

      Everything is XHC in my DSDT, except these definitions at the top (line 72 and 73):

          External (_SB_.PCI0.XHC_.DUAM, MethodObj)    // Warning: Unknown method, guessing 0 arguments     External (_SB_.PCI0.XHC_.RHUB.INIR, MethodObj)    // Warning: Unknown method, guessing 0 arguments
      So I edited the SSDT-RHUB.dsl to this:

      /* * Goal of this SSDT is to shut off the RHUB to force macOS into * manually building ports when the ACPI is screwed up */ DefinitionBlock ("", "SSDT", 2, "DRTNIA", "RhubOff", 0x00001000) { External (_SB_.PCI0.XHC.RHUB, DeviceObj) // Full pathing to RHUB, change to yours Scope (_SB.PCI0.XHC.RHUB) // Full pathing to RHUB, change to yours { Method (_STA, 0, NotSerialized) { If (_OSI ("Darwin")) { Return (Zero) // This disables the device only in macOS } Else { } } } } Which results in this AML version:
      DefinitionBlock ("", "SSDT", 2, "DRTNIA", "RhubOff", 0x00001000) { External (_SB_.PCI0.XHC_.RHUB, DeviceObj) Scope (_SB.PCI0.XHC.RHUB) { Method (_STA, 0, NotSerialized) // _STA: Status { If (_OSI ("Darwin")) { Return (Zero) } Else { } } } } But I get the same error.

      I'm at a complete loss, can anyone help?


      config.plist
      ACPI.zip
    • By CaccapoKissima
      Hi, I wanted to transpose my CLOVER installation to OpenCore for future updates.

      I followed this guide and after some googling
      https://github.com/dortania/vanilla-laptop-guide
      I've fixed the LOG: EXITBS error (RANDOM SEED like error).
      Now I still receiving the IOPCI error (kernel_task kernel panic).

      My CLOVER is fully working.
      - Backlight and Monitor
      - Trackpad
      - i7-7700HQ
      - Battery Patch
      - Camera and Audio (B&O)
      - Keyboard
      - dGPU GTX 1050 is turned off

      On OpenCore I translated everything except the battery (I just need to apply the If statement in ACPI), but I want first to boot on Mac OS using the OpenCore.

      HP Pavilion Power 15


      config.plist

    • By tonyx86
      *** I have started another thread for installing Catalina on the Dell Latitude E6410.  If you were thinking of installing Mojave, but would prefer to skip right to Catalina, click here. ***

      *** I am no longer maintaining the installation files in this first post.  Refer to my Catalina thread for the latest guidelines / files for installing macOS on this Latitude E6410 with Nvidia graphics ***

      I was inspired by @duduclx post here for installing El Capitan on a Dell Latitude E6410, so I decided to install Mojave 10.14.5 and subsequently 10.14.6.  Everything works perfectly (including sleep).  I'm starting this thread hoping to help others install Mojave on their E6410s.  A brief installation guide is provided later in this first post.  The interested reader is encouraged to read the other posts in this thread to see how this solution evolved and to learn additional tips/details not provided in this first post (including dual-booting with macOS and Windows).

      My system is as follows:
      Dell Latitude E6410 (I7-620m, Nvidia 3100M, 8GB DDR3, 512GB SSD, 1440x900 display, BIOS: A17) MacOS: Mojave 10.14.6 (APFS) (Patched with DosDude Mojave Patcher 1.3.3) MacModel: MacBookPro 6,2 (LPCB._DSM.Name "pci8086,3b09") Kexts: Lilu 1.3.6, VoodooHDA 2.9.2, AirportBrcmFixup 2.0.0, IntelMausiEthernet 2.4.1d1, ACPIBatteryManager 1.90.1, BrcmPatchRam2.kext, BrcmFirmwareRepo.kext, VoodooPS2Controller (the "Refined ALPS Touchpad" version - release 6 developed by @Dr. Hurt and compiled by @bronxteck), not the original version), USBInjectAll (with custom SSDT-UIAC), VoodooSDHC.kext (configured as shown here). Wi-Fi: Broadcom BCM 94352HMB (with AirportBrcmFixup.kext) CLOVER (Legacy): R4961
      Configuration items that may be different from what you have seen in other E6410 configurations
      Addition of _OFF and _ON methods to _PTS and _WAK methods respectively (to control discrete graphics in order to enable sleep/wake) LPCB._DSM patched with device-id "3b09" AND "name", "pci8086,3b09" for native Nehalem power management with MacBookPro 6,2 ECDV renamed to EC so that AppleBusPowerController loads AGP.VID._DSM patched with device-id "0a29" so that AppleGraphicsPowerManagement loads No CLOVER Generate P or Generate C States (with the correct LPCB._DSM and MacBookPro 6,2, these CLOVER options are unnecessary for this architecture and only limit max multiplier and reduce number of P states) DSDT patched to include HDAU device (device-id 0x0be3)
      What is NOT working:
      Display brightness can be controlled with keyboard keys, but cannot be controlled with slider in Display settings. Graphics Power Management - AGPM loads (because 10de,0a29 device is injected), but there's no evidence that 3100m frequency and voltage is changing.
        What is NOT tested:
      Smartcard Reader eSata (I have this disabled in my BIOS) Firewire Port (it does appear in the Network settings, just haven't tried it) Microphone Jack PC Card Slot (I have this disabled in my BIOS)
      What IS working:
      SLEEP IS WORKING! Everything else not mentioned above.   Speedstep/CPUPowerManagement is perfect, system temps are low, CPU multiplier operates as expected, battery life is long Shutdown is fast Display/graphics acceleration is perfect (thanks to DosDude's Mojave patcher) Brightness (adjusted with brightness keys on keyboard) works perfectly Battery Manager works (battery status is displayed in menu bar) simply by installing ACPIBatterManager.kext. Wi-Fi (after changing to Broadcom BCM94352HMB and installing AirportBrcmFixup.kext) Audio (volume adjustable, volume indicator appears in menu bar).  Switched to VoodooHDA from AppleALC after AppleALC caused slow boot due to "IOHDACodecFunction timeout." Ethernet port (with IntelMausiEthernet.kext) Broadcom BCM20702A0 Bluetooth (with BrcmPatchRam2.kext and BrcmFirmwareRepo.kext) Optical Drive External VGA (with corrected NVCAP.  Need NVCAP 04000000 00000100 0E000000 00000007 00000000 (credit: here) for working external VGA display. Headphone jack Display Port (tested using DP > HDMI adapter) Camera SD Card Reader
      Known issues and their solutions (These issues have all been resolved, with the solutions incorporated into the attached config files.  The issues are listed here for historical purposes and no further work is needed unless stated otherwise).
      (Solution to this issue is to remove Device (PNLF) from the DSDT): Some users experience display issues.  Solution is to remove Device (PNLF) from the DSDT.  The attached DSDT currently still includes Device (PNLF), so you will need to edit the DSDT to remove PNLF. USB sleep/wake power IORegistry keys are no longer provided in IOUSBHostFamily.kext after High Sierra 10.13.6.  Solution is to added SSDT-USBX.aml to EFI/CLOVER/ACPI/patched.  The attached SSDT-USBX.aml includes USB sleep/wake properties for MacBookPro6,2 from High Sierra 10.13.6 IOUSBHostFamily.kext. Laptop does not sleep on lid close.  Solution is to add Notify (LID0) code to Method (BTNV) in the DSDT.  This is solved in the attached DSDT. Leaving this for historical purposes, but the CLOVER USBFix is no longer necessary after finding that I had incorrectly applied the DSDT _DSM patch for Device (EHC1).  The CLOVER USBFix is not needed after fixing the DSDT..  AAPL,clock-id and device_type do not appear in IORegistry for EHC1.  Solution is to use CLOVER on-the-fly patching/fixing/renaming for EHC1 and EHC2.  Thank you, @feartech, for this tip. ALPS trackpad performance is not good with the "standard" VoodooPS2Controller.kext that I initially used.  Switching to the "Refined ALPS TouchPad driver" is a big improvement.  I've implemented and tested this on my system.  The ALPS version of VoodooPS2Controller.kext mixes up a few keys.  Need to switch the Command and Option keys (System Preferences > Keyboard > Modifier Keys) and change keyboard type to ISO European. This configuration (captured in the attached config files) uses an injected device-id (10de,0a29) for NVidia 3100m to get AGPM to load.  While I haven't observed any performance differences, a better approach may be to inject AGPM properties for device 10de,0a6c (the actual device-id for the 3100m).  This AGPM method is discussed later in this thread.  I have briefly tested this "FakeSMC.kext method" for injecting AGPM attributes without any noticeable changes in laptop/graphics behavior. IOHWControl is not loaded under AGPM (Should be AGP > VID > NVDA,Display-A@0 > NVDATesla > AGPM > gpu-control > IOHWControl as viewed in IORegistryExplorer).  It is loaded on a real MacBookPro6,2 running Mojave and is loaded on this Dell Latitude E6410 running High Sierra.  If I "Inject NVidia" via CLOVER, IOHWControl loads properly. The Dell Latitude DSDT (BIOS A17) has a bug in Method (GNOT).  In the method, the expression  If (LOr (LGreater (OSYS, 0x07D0), LLess (OSYS, 0x07D6))) always evaluates to TRUE, so the patched DSDT has no dependency on the value of OSYS.  I suspect that LOr should be replaced with LAnd, so that this expression is TRUE for variants of Windows 2001 and False for any other OS.  While this may have no affect on MacOS, it makes one wonder how such an obvious bug made it through Dell QA and is still present in BIOS A17.  Also makes one wonder whether the sleep problem (which no one has solved) was fixed in Windows to address another DSDT bug. The assigned value of ACOS and OSYS in the DSDT are conditional on the operating system.  There is no condition for "Darwin."  The solution is to add a condition for "Darwin" (making it equivalent to one of the defined operating systems (e.g. Linux, Win7, etc).  The attached config hard-codes ACOS and OSYS values equivalent to those for Linux.  Another way to handle this (different from the method employed in the attached config files) might be to override _OSI with XOSI (defined in a custom SSDT). The portType of the Internal Bluetooth device is portType=0 which, according to Rehabman's comments in SSDT-UIAC-All.dsl, is an external USB 2 port.  This should be an internal USB port (portType=2).  I learned through trial and error that the HUB1 and HUB2 definitions in Rehabman's SSDT-UIAC-ALL.dsl apply to the ports on the EHCx USB hubs.  The solution is to include the HUB1 definition in SSDT-UIAC.dsl and change portType to 2 for HP15.  This change doesn't appear to affect/fix sleep, but it may prevent instant wake if we get sleep working. There are minor differences between a real MacBookPro6,2 IORegistry dump and this HackBookPro6,2 IORegistry dump that can be resolved with simple DSDT edits.  I am now running with these changes, but haven't found these changes to make any difference in operational behavior.
      Rename Device (AC) -> Device (ADP1) Remove UID from Device (HPET) Add compatible ID "PNP0C01" to Device (HPET) Change ADP1:_STA from 0x0F to 0xFFFFFFFF Enable Ambient Light Sensor and renamed to Device (ALS0) from Device (ALS) Add compatible ID "smc-als" to ALS0 Rename LID -> LID0 Change "name" definitions to Buffers in _DSM methods Rename Device (PBTN) to PWRB Rename Device (SBTN) to SLPB Sleep / Wake does not work with the basic DSDT edits.  I have discovered that Sleep / Wake can be made to work by adding discrete graphics _OFF and _ON methods to _PTS and _WAK methods respectively (borrowed the concept and code from a working E6430 DSDT: Credit here: https://osxlatitude.com/forums/topic/9248-working-sleep-on-intel-hd-and-nvidia-nvs-on-dell-latitude-e6430-optimus-enabled-or-disabled/page/6/. The Clover boot arg should be changed to "darkwake=0" for reasons explained by @holyfield in this thread.  Leaving this for historical purposes: LCD screen is blank when waking laptop by opening lid (screen is not blank when waking with power button).  Solution is to add darkwake=8 to CLOVER boot args.  Thank you @Hervé for this tip.
      Brief Installation Guide:
      Configure BIOS (version A17) as follows (leave default unless listed here): Boot Sequence: USB, Internal HDD, CD/DVD, Modular Bay HDD; Boot List Option: Legacy; Integrated NIC: Enabled; Parallel Port: Disabled; Serial Port: Disabled; SATA Operation: AHCI; Misc Devices: Enable Modular Bay, Camera, External USB, Microphone, Media Card and 1394; Latitude ON Reader: Disabled; Keyboard Illumination: Auto ALS and Input; Ambient Light Sensor: Enabled; OROM Keyboard Access: Disable; TPM Security: Disable; Computrace: Deactivate; CPU XD Support: Enable; Performance: Enable all options; Power Management: Disable Wake on AC, Disable Wake on LAN/WAN, Express Charge: Standard, Charge Behavior: Enabled; Keypad: Fn Key Only; Mouse/Touchpad: Touchpad/PS-2 Mouse; USB Emulation: Enable Legacy; Fn Key Emulation: Disabled; Fastboot: Thorough; Virtualization: Enable Intel Virtualization, Disable VT for Direct I/O, Disable Trusted Execution; Wireless Switch: Bluetooth and WLAN; Wireless Device Enable: Bluetooth and WLAN;  Create your MacOS installer USB (Use DosDude's Mojave Patcher for Mojave) (start with High Sierra and not Mojave if you're new to hackintosh). Install CLOVER (Legacy) on installer USB using attached EFI as your guide for patched ACPI, kexts and config.plist Install MacOS to your SSD.  When you run DosDude's Mojave Patcher, DO NOT install LegacyUSBInjector.kext - you're going to use Rehabman's USBInjectAll.kext.  Also, do not install the DosDude SIP kext (you're using CLOVER to manage SIP). Install the following kexts in /Library/Extensions:  ACPIBatteryManager.kext, AirportBrcmFixup.kext, BrcmFirmwareRepo.kext, BrcmPatchRAM2.kext, FakeSMC.kext, FakeSMC_ACPISensors.kext, FakeSMC_CPUSensors.kext, FakeSMC_GPUSensors.kext, FakeSMC_LPCSensors.kext, IntelMausiEthernet.kext, Lilu.kext, USBInjectAll.kext, VoodooPS2Controller.kext (the "Refined ALPS Touchpad driver," not the original), VoodooSDHC.kext (configured as shown here). Switch Command and Option keys to compensate for Refined ALPS driver issue (System Preferences > Keyboard > Modifier Keys).  Also change keyboard type to ISO European to fix the [ ` ~ ] key (to the left of the "1" (one) key. Install VoodooHDA Install HWMonitor application
      Tips for Improved Performance (on this and other older systems)
      System Preferences > Spotlight > Search Results: Uncheck all options System Preferences > Spotlight > Privacy: Add all Volumes System Preferences > Accessibility > Display: Check "Reduce motion" System Preferences > Accessibility > Display: Check "Reduce transparency"
      Other tips
      If your fan is always running and temps are good, try pressing Fn + z After applying Mojave updates, HWMonitor may not display discrete graphics attributes.  On systems with multiple displays, a second (or third display) may not be active after applying the Mojave update.  The solution to this is to run "sudo kextcache -i /" (in a terminal window) and reboot.  This will usually fix the issue.  If the issue is not fixed, run DosDude's Post Install Utility, apply the Legacy Graphics Patch, reboot and then run "sudo kextcache -i /" if necessary.
      Screenshots


      Credits
      In addition to those mentioned in this first post and in subsequent posts in this thread, much of this solution for the Latitude E6410 was made possible by the numerous contributions of @RehabMan.  I hope he's doing well, wherever he is.  Hopefully he has long since forgotten what a PIA I was (and still am) as I was (and still am) learning hackOS.

      E6410-Mojave-v4.zip
    • By tonyx86
      **********************************************************************************
      In this thread, I have fully documented the installation of macOS Catalina on my HP EliteDesk 800 G4 Mini. It is a PERFECT HackMini8,1 and is running very well for me without any issues. I hope this documentation helps you to install macOS on your hack. Please leave feedback if you think there is anything I can improve and let me know if you have any questions.
      **********************************************************************************

      Background
      This is my first "modern" hack supporting UEFI and my first hack using Clover "on-the-fly" patches.  My previous hacks
      Laptop: Thinkpad T61 / Nvidia NVS 140m Laptop: Dell Latitude E6410 / Nvidia G3100m Desktop: Gigabyte G31 / GeForce 9600 Desktop: Biostar TH55HD / Sapphire Pulse RX580 (Google "Catalina Biostar TH55HD" and look for user name deeveedee)
      are all perfectly running Catalina and I patched them all "manually" - all DSDT patches applied with MaciSL with virtually no Clover on-the-fly patching and all booted Legacy Clover.  This UEFI hack was MUCH easier and took about 20 hours vs. a combined hundreds of hours for the old hacks.  I wanted a hack that was a little more future proof and I think this is it.  I hope you enjoy this as much as I am enjoying it.  It is a perfect MacMini8,1.



      My system specs
      HP EliteDesk 800 G4 Mini (I7-8700T / UHD 630 / Q370 Chipset / 32GB DDR4 RAM) 3 x DP Ports (connected to monitors using DP -> DVI adapters) 6 x USB 3.1 1 x USB Type-C 3.1 2 x NVMe SSD (M.2 PCIe x4 2280/2230 combo ports) 1 x SATA6 SSD 1 x Intel Ethernet RJ-45 Conexant CX20632 Audio Codec Unsupported M.2 PCIe x1 2230 Intel Wi-Fi (currently disabled in BIOS).  I may replace this with Brcm, but am using only Ethernet (IntelMausi) for now.
      macOS Installation
      See macOS installation steps here See Known Issues here for additional installation steps that may not yet be included in my attached config files See CLOVER (UEFI) installation later in this first post
      See BIOS configuration in attached BIOS configuration PDF document
      See EFI and /L/E kexts in attached EliteDesk.zip archive See how I developed my installation methodology here See references here See instructions here for installing two M.2 2280 NVMe SSDs and one SATA HD / SSD
      What is not working
      Wi-Fi / Bluetooth (intentional since I have not yet replaced my Intel card).
      What is not tested
      USB c 3.1 port (I have partially tested the USB 3 functionality of the port and it seems to be working fine with the SSDT-UIAC.aml here) Microphone port
      What is working
      Everything not mentioned above Sleep / Wake Multiple displays with IGPU graphics acceleration, hot pluggable display ports and DP->DVI adapters USB 3.1 ports Audio (internal speaker and headphone jack) Ethernet Auto-sensing headphone jack automatically switches to internal speaker when headphones removed
      Known Issues and their solutions - see here

      BIOS Version / Configuration
      Version: 02.11.01 Rev.A See attached BIOS configuration in PDF document "HP EliteDesk 800 G4 Mini BIOS Configuration.pdf" Intel ME must be enabled for proper sleep / wake of UHD 630

      Clover Configuration
      Clover for UEFI booting only Install Clover in the ESP UEFI Drivers Recommended drivers DataHubDxe FSInject SMCHelper File System drivers ApfsDriverLoader VBoxHfs Memory fix drivers AptioMemoryFix Additional drivers NvmExpressDxe Install RC scripts on target volume Themes Choose your desired theme Install Clover Preference Pane (option not available when installing on USB thumb drive)
      UHD 630 Framebuffer Patching
      See here and here
      Current Versions
      Catalina 10.15.5.02 Clover (UEFI) r5119 Lilu.kext 1.4.5 WhateverGreen.kext 1.4.0 AppleALC.kext 1.5.0 IntelMausi 1.0.3 (Not IntelMausiEthernet)
      Credits To be provided

      ScreenShots


      HP EliteDesk 800 G4 Mini BIOS Configuration.pdf
      EliteDesk800 G4 Mini - Rev 0.91.zip
×
