GFX Glitches on Mojave 10.14 under Haswell/IntelHD 4600


Dragster27
 Share

7 posts in this topic

Recommended Posts

Hi all!



I've successfully installed Mojave on my Haswell/IntelHD4600 Toshiba Laptop... it works well, unfortunately I'm having some GFX glitches...not sure why. I'm using Rehabman's FakePCIID...latest Clover bootloader.der..



ig-platform-id is: 0x0a260006

Devices/IntelGFX is set to: 0x04128086

I also have Lilu and latest whaevergreen kexts in /EFI/Clover/Kexts/Other..



Thanks for your help!



Dragster

Here are some screenshots showing what's going on...





283546194_ScreenShot2018-09-28at11_46_43PM.thumb.png.0aa5b863834137c44bdcc9c9f6daa786.png




Link to comment
Share on other sites

7 hours ago, Dragster27 said:

¡Hola a todos!



Instalé con éxito Mojave en mi computadora portátil Toshiba Haswell / IntelHD4600 ... funciona bien, desafortunadamente estoy teniendo algunas fallas GFX ... no estoy seguro de por qué. Estoy usando FakePCIID de Rehabman ... el último cargador de arranque Clover.der ..



ig-platform-id es: 0x0a260006

Devices / IntelGFX está configurado para: 0x04128086

También tengo Lilu y los últimos kexts verdes en / EFI / Clover / Kexts / Other.



¡Gracias por tu ayuda!



Dragster

Aquí hay algunas capturas de pantalla que muestran lo que está pasando ...





283546194_ScreenShot2018-09-28at11_46_43PM.thumb.png.0aa5b863834137c44bdcc9c9f6daa786.png






test injecting intel. Share your efi folder to know a little more what you are doing. I have a Mojave installation with a Lenovo laptop and graphic Intel4400 working so far without graphic problems.

4 hours ago, ellaosx said:

¿Has intentado instalar lo que sea verde y eliminar todos esos fakepciid & platform-id?

I have tried without success. I think that FakePCI and igplataform / IntelGFX are essential when you do not have a graph with native support.

Edited by camillionario
Link to comment
Share on other sites

10 hours ago, ellaosx said:

Have you tried installing whatevergreen and removing all those fakepciid & platform-id?

yeah, I tried but it didn't work... I think  it's also necessary to set up some config, etc... I don't think it's that simple.

6 hours ago, camillionario said:



test injecting intel. Share your efi folder to know a little more what you are doing. I have a Mojave installation with a Lenovo laptop and graphic Intel4400 working so far without graphic problems.

I have tried without success. I think that FakePCI and igplataform / IntelGFX are essential when you do not have a graph with native support.

I will share it as soon as I go back home. Thanks in advance.



Cheers,

Dragster.

Link to comment
Share on other sites

Hi folks, , sorry for the late reply. Attached is my CLOVER/EFI configuration in a compressed file.



Apprreciate the help!



I've removed the themes and apple/extensions directories to create a smaller zip file.

EFI.zip

Cheers,

Dragster
