quattrofx

Gigabyte Z370 Aorus Ultra Gaming Bios F7h + i7 8700K + GTX1080

44 posts in this topic

Recommended Posts

Hi to all,



I just wont to give inough informations on one place for all the people with same Hardware with

costimization steps witch i have done. I have fast perfect working High Sierra 10.13.3 on my PC but

still needs to be actualized thru the DSDT, because it ist the only way to get all the hardware

properly working.



Gigabyte Z370 Aorus Ultra Gaming - BIOS F7h

Intel i7-8700K (4.8GHz)

Gigabyte GTX 1080 G1 Gaming  8G

DDR4 64GB PC 3000 CL15 G.Skill KIT (4x16GB) 64GVR Ripjaws V

Dual-Band PCI-e Adapter TP-Link TL-WDN4800

Firewire PCI-e Digitus (Texas Instruments Chipset)

Bluetooth 4.0 USB Dongle ASUS BT400 (Broadcom)

PSU: LC-Power Metatron Prophecy 2 LC8750II V2.2, 750 Watt

2 x NVMe SSD 960 Evo 500GB (Win10Pro & High Sierra 10.13.3)

1 x SSD Crucial 500GB (Sierra 10.12.6)

1 x 4TB Segate Barracuda SATA 3 (Multimedia)

Tripple-boot Win10Pro, Sierra 10.12.6 & High Sierra 10.13.3



Bios Settings:

1.       M.I.T. → Advanced Memory Settings  Extreme Memory Profile(X.M.P.) : Profile1

2.       BIOS → Fast Boot : Disabled

3.       BIOS → LAN PXE Boot Option ROM : Disabled

4.       BIOS → Storage Boot Option Control : UEFI

5.       Peripherals → Trusted Computing → Security Device Support : Disable

6.       Peripherals → Network Stack Configuration → Network Stack : Disabled

7.       Peripherals → USB Configuration → Legacy USB Support : Auto

8.       Peripherals → USB Configuration → XHCI Hand-off : Enabled

9.       Chipset → Vt-d : Enabled

10.   Chipset → Wake on LAN Enable : Disabled

11.   Chipset → IOAPIC 24-119 Entries : Enabled



Dedicated graphics card:

1.      Peripherals → Initial Display Output : PCIe 1 Slot

2.      Chipset → Integrated Graphics : Enabled

  1. Chipset → DVMT Pre-Allocated :128M



Wake for Ethernet Network access - Unchecked

Enable Power Nap - Unchecked











First step:

I have a perfect Sierra 10.12.6 working on my HP Z800 witch i use to clone to one SSD



Second step:

Delete old EFI on cloned SSD and put the new one from here:

https://hackintosher.com/guides/high-sierra-install-full-guide/



Adjusted Kexts and Config.plist for my Rig:



Kext Folder:

FakeSMC.kext + Sensors Kexts

Lilu.kext

CodecCommander.kext

AppleALC.kext

IntelGraphicsFixup.kext

FakePCIID_Intel_HD_Graphics.kext

IntelMausiEthernet.kext

NvidiaGraphicsFixup.kext

Shiki.kext

USBInjectAll.kext

XHCI-200-series-injector.kext



Thread step:

connected new cloned SSD on the SATA port and Sierra started up and working.



Fourth step:

regulary updated to HighSierra 10.13.3 running installer from App folder.



Fifth step:

Cloned Sierra SSD to NVMe SSD 960 Evo 500GB



Made changes to BIOS & Config.plist to become hardware encoding acceleration  in FCPX and HEVC support:



BIOS Gigabyte:

§  Chipset → Integrated Graphics : Enabled

§  Chipset → DVMT Pre-Allocated :128

§  Peripherals → Initial Display Output : PCIe 1 Slot



Config.plist:



1.       Inject Kexts is set to Yes

2.       In Boot Under Custom flags added:

Nvidia users: shikigva=60

3.       Kaby Lake & Coffee Lake Users:

In Devices Using Nvidia

- Set ig-platform-id to: 0x59120003



DSDT Patching:

1.       HECI -> IMEI Patch

1.       Comment: change HECI to IMEI

2.       Find* [Hex]: 48454349

3.       Replace [Hex]: 494d4549

2.       GFX0 -> IGPU Patch

1.       Comment: change GFX0 to IGPU

2.       Find* [Hex]: 47465830

3.       Replace* [Hex] : 49475055

3.        PEGP -> GFX0 Patch

1.       Comment: change PEGP to GFX0

2.       Find* [Hex]: 50454750

3.       Replace [Hex]: 47465830



I think that in my Config.plist (used EFI from here https://hackintosher.com/guides/high-sierra-install-full-guide/  and edited by me)

are the double entries, but i am not shure and i dont wont to make a mess myself.

It is beter to leave it to the profis like Maldon!







Maldon, i have attached my Send me iMac_4FX.zip file generated with RunMe.app



Can you post the list of maded Patches for this RIG please.



THX in advance



QuattroFX

Send me iMac_4FX.zip

Share this post


Link to post
Share on other sites
Advertisement
-FIX ERRORS AND WARNINGS
-HPET
-SATA
-DMAC
-SLPB
-DARWIN
-XHCI
-PLUGIN TYPE
-HDAS to HDEF
-HDEF
-RTC
-IRQs
-SBUS
-BLC0
-BUS1
-MCHC
-ALS0
-SHUTDOWN
-LAN
-USBX
-PMCR
-IMEI
-EC
-FRWR
-NVME
-ARPT
-Some Cosmetics

CLOVER.zip

Share this post


Link to post
Share on other sites

Hi Maldon,



BIG THX for the RAPID replay.

Question before I test it:

config.plist still has a lot of same stuff activated as in your DSDT. For example Shutdown.fix Should I disable or live like this?



BR

QFX

Share this post


Link to post
Share on other sites

THX Maldon,



I've just tried and everything working PERFECT! The Benchmark scores are little bit higher! Only glitch what I have had before is still present:

Sleep works perfect but after shutdown my LED´s on Motherboard are still on! Under the Windows 10 after shutdown they are off.

What can cause this problem?



BR

QFX

Share this post


Link to post
Share on other sites

i think is erp ready option in bios, check there

i see many users with problem, is a bios config

Share this post


Link to post
Share on other sites

ERP Funktion was already disabled in Bios. I've just played with other settings, but none of them sims to solve the problem. I will just turn off the LED´s in Bios, till we found the solution.

Only problem witch I found at the moment are to many dropped frames in FCP 10.4 after replaying DSDT, but I still have iGPU Intel hardware encoding ON.

Share this post


Link to post
Share on other sites

Yesterday i had a Problem installing HS 10.13.3 supplemental update.... Need to fix it today.



Maldon, do i need NVRAM.plist in EFI with the AptioMemoryFix.efi kext?

Share this post


Link to post
Share on other sites

Maldon, do i need NVRAM.plist in EFI with the AptioMemoryFix.efi kext?

No, dont need ;)

Share this post


Link to post
Share on other sites

I've removed NVRAM.plist from EFI.

Removing IntelGraphicsFixup.kext didn't solved my FCP X Problem. HS woks without as well and I have still iGPU Intel hardware encoding ON.

Share this post


Link to post
Share on other sites

Just for the Info,



I have tested Sierra 10.12.6 with the same DSTD and there FCPX working flawlessly!



Under HS 10.13.3 I have tested MacX Video Converter Pro with INTEL Hardware acceleration enabled and disabled:

56GB 4K RAW Video convert to FullHD .MP4 with > 9min 22sec

56GB 4K RAW Video convert to FullHD .MP4 without > 18min 46sec



Maldon, after applied DSDT my booting time is double longer... can it hang on AptioMemoryFix.efi?

Share this post


Link to post
Share on other sites

Just for the Info,



I have tested Sierra 10.12.6 with the same DSTD and there FCPX working flawlessly!



Under HS 10.13.3 I have tested MacX Video Converter Pro with INTEL Hardware acceleration enabled and disabled:

56GB 4K RAW Video convert to FullHD .MP4 with > 9min 22sec

56GB 4K RAW Video convert to FullHD .MP4 without > 18min 46sec



Maldon, after applied DSDT my booting time is double longer... can it hang on AptioMemoryFix.efi?

send me files, i'll check log

RunMe.app.zip

Share this post


Link to post
Share on other sites

I have updated HS 10.13.3 with the supplement update, immediately after reboot installed newest NVIDIA driver regularly and applied your DSDT.

Everything working perfect now, fast boot, iGPU Hardware acceleration ON, but FCPX 10.4 still has dropped frames.

I am using mainly Adobe Premiere Pro, so it is not a problem for me, because Mercury dGPU acceleration working flawlessly.



BIG THX MALDON!

Share this post


Link to post
Share on other sites

Sorry,

I was to early.... after couple of reboots, I have problem with shutdown, seams does not doing it properly every second time and after reboot showing failure, first in Boot process and

after on the desktop that the System didn't shutdown properly.

Share this post


Link to post
Share on other sites
