Installation of Sierra on Asus N552VW touch laptop

modaifallah

By modaifallah,
in OSx86 10.12 (Sierra)

 Share
61 posts in this topic

Recommended Posts

modaifallah1
modaifallah1
Posted
Posted

Boot hangs at intelbacklight handler failed to show up. Uppost-2094977-0-20405300-1495760096_thumb.jpg

Removing the dsdt and adding audio layout 13 injection from clover configurator fixed audio but again no backlight ?

You can remake a DSDT without audio patches only battery, brightness and touchpad patches.

here is a new ioreg just in case without DSDT in clover:

MacBook Pro2.zip

  • Like 1
Link to comment
Share on other sites
modaifallah1
modaifallah1
Posted
Posted

old folder with inject 13 in clover

attachicon.gifCLOVER.zip

Trying now. I hope it works :D

Sound not working again :''''''(

I don't know how it works without patched DSDT and doesn't with it -_-

Hackintoshing is really complex LOL

Any suggestions? I know I've been a headache, just give me brightness control and sound together. forget about the trackpad I have my USB mouse everywhere.

  • Like 1
Link to comment
Share on other sites
modaifallah1
modaifallah1
Posted
Posted

Nothing about sound in DSDT, only device HDEF



What ur audio codec?

How to know that?

Btw sound worked with just a reboot LOL

Now my hackintosh is useful enough for me, if you kindly have any time for me help me in fixing the touchpad.

Thanks a lot man ! <3

  • Like 1
Link to comment
Share on other sites
modaifallah1
modaifallah1
Posted
Posted

Trying and will give feedback shortly. Thank you :D


Try

Worked! :D Thank you!!!!!

Plz add this patch to the DSDT to enable keyboard backlight. I did it to the last one and it worked but when applying it to your DSDT it gives error :'(

"# Patch by EMlyDinEsH (www.osxlatitude.com)# Enables 16 keyboard backlight levels control to work using my kexts AsusNBFnKeys and Smart Touchpad
# This patch meant for the notebooks up to Ivy Bridge.


# Insert backlight auto off control sync field for Smart Touchpad and Asus Fn Keys driver
into device label ATKD code_regex Name\s\(BOFF,\sZero\) remove_matched;
into device label ATKD insert begin Name (BOFF, Zero) end;


# Insert method SKBL for setting keyboard backlight level
into method label SKBL parent_label ATKD remove_entry;
into Device label ATKD insert begin
Method (SKBL, 1, NotSerialized)\n
            {\n
                If (Or (LEqual (Arg0, 0xED), LEqual (Arg0, 0xFD)))\n
                {\n
                    If (And (LEqual (Arg0, 0xED), LEqual (BOFF, 0xEA)))\n
                    {\n
                        Store (Zero, Local0)\n
                        Store (Arg0, BOFF)\n
                    }\n
                    Else\n
                    {\n
                        If (And (LEqual (Arg0, 0xFD), LEqual (BOFF, 0xFA)))\n
                        {\n
                            Store (Zero, Local0)\n
                            Store (Arg0, BOFF)\n
                        }\n
                        Else\n
                        {\n
                            Return (BOFF)\n
                        }\n
                    }\n
                }\n
                Else\n
                {\n
                    If (Or (LEqual (Arg0, 0xEA), LEqual (Arg0, 0xFA)))\n
                    {\n
                        Store (KBLV, Local0)\n
                        Store (Arg0, BOFF)\n
                    }\n
                    Else\n
                    {\n
                        Store (Arg0, Local0)\n
                        Store (Arg0, KBLV)\n
                    }\n
                }\n


                Store (DerefOf (Index (KBPW, Local0)), Local1)\n
                ^^PCI0.LPCB.EC0.WRAM (0x04B1, Local1)\n
                Return (Local0)\n
            }\n
end;


# Insert keyboard backlight 16 levels buffer
into device label ATKD code_regex Name\s\(KBPW,\sBuffer\s\(0x10\)\s*\n\s*\{\s*\/\*\s0000\s\*\/\s*0x00,\s0x11,\s0x22,\s0x33,\s0x44,\s0x55,\s0x66,\s0x77,\s*\/\*\s0008\s\*\/\s*\s0x88,\s0x99,\s0xAA,\s0xBB,\s0xCC,\s0xDD,\s0xEE,\s0xFF\s*\}\) remove_matched;
into device label ATKD insert begin
Name (KBPW, Buffer (0x10)\n
   {\n
      0x00, 0x11, 0x22, 0x33, 0x44, 0x55, 0x66, 0x77, 0x88, 0x99, 0xAA, 0xBB, 0xCC, 0xDD, 0xEE, 0xFF\n
   })
end;


#into device label ATKD code_regex Name\s\(PWKB,\sBuffer\s\(0x04\)\s*\n\s*\{\s*0x00,\s0x55,\s0xAA,\s0xFF\s*\}\) remove_matched
#into device label ATKD insert begin
#Name (PWKB, Buffer (0x10)\n
#   {\n
#      0x00, 0x11, 0x22, 0x33, 0x44, 0x55, 0x66, 0x77, 0x88, 0x99, 0xAA, 0xBB, 0xCC, 0xDD, 0xEE, 0xFF\n
#   })
#end;




# Insert method GKBL for reading keyboard backlight level
into method label GKBL parent_label ATKD remove_entry;
into Device label ATKD insert begin
Method (GKBL, 1, NotSerialized)\n
            {\n
               If (LEqual (Arg0, 0xFF))\n
                {\n
                    Return (BOFF)\n
                }\n


                Return (KBLV)\n
            }\n
end;
"
