[SUCCESS] Asrock H370M-ITX/ac and getting RX560 or RX580 to work with Intel graphics for full hardware acceleration on Mojave (and maybe High Sierra 10.13.6)By macinsane
Mojave (and maybe High Sierra 10.13.6) on Asrock H370M-ITX/ac and getting RX560 or RX580 to work with Intel graphics for full hardware acceleration
Core i7 8700, UHD 630
Gigabyte Radeon RX560
Wifi/BT BCM943602BAED (DW1830) M.2
Sapphire Nitro RX 580
Samsung PM961 NVMe SSD
*This guide requires you to know the basics, meaning how to create a macOS install drive, installing and using Clover. There are great beginners guides out there! As always you need at least FakeSMC to boot, every other kext I’ve used is mentioned in the guide. For Mojave beta you need to be enlisted with your Apple-ID in Apple’s beta programme. What is described here may work for High Sierra 10.13.6, but I doubt it to be reliable. Even in early beta status (PB3) Mojave runs much more stable and smoother than High Sierra ever did for me.*
I've updated to BIOS Revision 3.00 which seems to work fine in contrast to 1.50. Already compiled a new DSDT and uploaded it alongside a new config.plist. You can use both if you like. If you don't use a RX 580 you need to edit the PEG0-PEGP section in the DSDT to adjust it to your graphics hardware. With this DSDT and config in place you'll only need FakeSMC, IntelMausiEthernet, USBinjectall plus XHCI-300-Injector, Lilu plus AppleALC for Sound. You can add Shiki for iTunes DRM playback if you like, I've uploaded the latest version as well. Avoid Whatevergreen at this time.
The board comes with BIOS version 1.20, there is an update 1.50 on the Asrock website. Usually it is good to stay updated but in this case I’ll recommend to stay on 1.20, because the 1.50 version seems to be unstable and I had restarts upon wake and things like that I couldn’t get fixed even with dsdt patches. So I just downgraded to 1.20 which runs fine.
Settings needed: Just the usual. Disable fast boot and security boot (everything Windows-related), disable vt-d and enable XHCI hand-off. Activate multi monitor support and set VRAM to 64MB to activate the Intel IGPU. From what I’ve read most people recommend 128MB but I find the 64MB setting to be more reliable, getting artifacts with settings below or above 64MB. 128MB may be needed for 4k support, though. As for nVidia users: You may have to disable the Intel graphics. I’m using an AMD card and that is the brand to go these days since Apple decided to work with AMD
Clover and power management:
I recommend upgrading to 4586. It seems that Aptiomemoryfix is now working with H370 chipsets. I stayed on OsxAptiomemoryfix2 together with Emuvariable and it works. Feel free to experiment.
For power management with your CoffeeLake cpu you can just tick plugin type within Clover or compile a ssdt with Pikeralphas script. Mojave reports my cpu correctly as Core i7 since PB3, before that it is just “Unknown” but that is just cosmetic.
I updated to PB4/DP5 and switched to a Sapphire Nitro RX 580. You don't need to spoof Kabylake anymore, SMBIOS 18,x now works and can use my attached DSDT_RX580 for your convenience! You'll need it for displayport to work as primary display or else you get black screen on boot and can use only HDMI. Problems are the same as written below in the graphics section. If you need iTunes you absolutely need to keep a copy of the latest Shiki that is available, because it is discontinued. The newest WhatEverGreen-Fix (1.2.0/1.2.1) does not work! If you want to use Final Cut and don't need iTunes just stay away from Shiki or Whatevergreen.
This is the worst part. Getting the Radeon to run correctly alongside the Intel graphics took me weeks to figure out.
While RX570 and 580 run out of the box in most cases, the RX560 models often do not or at least not correctly. Apple even banned them from eGPU use. For my approach you cannot use “Whatevergreen.kext”, it simply didn’t work for me the way I needed it. Instead I added some fixes to my DSDT to set the correct number of ports used (DP, HDMI, DVI) and tell macOS to use the correct frambuffer. For those who are not into dsdt editing I added my DSDT, look at the “PEGP” section how it is done. This works for the RX560 using the “Acre” framebuffer, you can replace it with “Radeon”, that works too. Other cards need a different framebuffer and a different number of ports. You can do it! BTW: Do not buy this Gigabytecard!!! It has some weird VBIOS on it, which caused me nightmares before I got the card to work! Buy a Sapphire card instead, they are used by Apple too.
To get full hardware acceleration for encoding videos you have to have the Intel graphics enabled alongside your AMD card. Problem is, you cannot have it running simply as a second graphics card but you’ll need to “hide” it, means telling macOS that it doesn’t have any display connectors. Otherwise you’ll have screen artifacts or in the worst case just constant crashes. This can be done by adding a certain ig-platform-id in Clover. If you use 59120003 the Intel graphics will not show up in system profiler but it is there. You can check it with iStats or HWMonitor or look if the Kaby Lake graphics kexts are loaded. This ID makes the CoffeeLake UHD 630 to be recognized as a Kaby Lake gpu that has no display ports, is just used as a helper card.
You’ll need it as a helper card for video encoding. That is what Intel graphics are used for in Macs, to support video encoding on the hardware side. You can check if hardware encoding is supposedly enabled by using MacX Video Converter Pro and VDADecoderChecker. If both say “yes” and “fully supported” this is a good start. But despite the widespread belief this doesn’t mean everything is set correctly! You now have to find out, how to get both cards working together. This is the moment where you have to choose between work and fun: Are you using FinalCut Pro for video editing or are you planning to use iTunes for entertainment? Up until this day (Mojave PB3 PB4/DP5, High Sierra 10.13.6) you cannot have both working correctly! I’ll show you how it is done both ways.
The best settings for Final Cut:
Use the DSDT I’ve added with the respective AMD settings for the RX560 or modify them for your graphics card.
Use SMBIOS for iMac17,1 (14,2 does work but picture over DP port is ugly, iMac 18,1/2/3 do not work *Since Mojave PB4 they do work at least for RX580*) in Clover.
Have AppleIntelKBLGraphicsFramebufferInjector_3e9x.kextin your Clover/kexts/Other folder.
Until Mojave PB2 (may work on High Sierra 10.13.6):
Fake-ID 3E928086 plus ig-platform-id 59120003
These are the correct setting when installing Mojave (usually you will start with PB1 as the full installer).
For Mojave PB3 and higher:
Fake-ID 59128086 plus ig-platform-id 59120003
After upgrading to PB3 you will get a black screen with 3E92 fake id because PB3 introduces Coffee Lake kexts and macOS will use these kexts instead but that doesn’t work with our ig-platform-id. So you can download the update to PB3 but before installing it you’ll need to change the fake-id to a usual Kaby Lake id. While this didn’t work in High Sierra and the first two Mojave betas (meaning you didn’t get full hardware encoding) it is now magically working with PB3. It is safe to remove AppleIntelKBLGraphicsFramebufferInjector_3e9x.kext after upgrading to PB3.
For Mojave PB4 and higher:
Only add ig-platform-id 3E920003 in Clover, no need for spoofing a fake id anymore.
The best setting for iTunes and why it is the worstfor Final Cut:
Just do the same thing as for FinalCut, put Shiki.kext into your Clover/kexts/other folder and add -shikigva boot argument. You can use -shikigva=1 or 2 or 12 it will work either way. Now you can watch movies with iTunes, yay! But it has some sideeffects. You cannot use this setting when seriously editing with Final Cut.
While this works by tricking macOS to use the IntelGraphics to play protected video content, it doesn’t seem to be the way real Macs are doing this. As soon as you open FinalCut you will notice (check this with iStats or HWMonitor) that the Intel graphics is not or only barely utilized, instead cpu usage skyrockets, indicating that slow software rendering is used instead of hardware encoding through Intel graphics. To make it worse the Radeon still “thinks” there is an Intel graphics helping so it does not run at highest potential. You may never notice it when using HD material with 24 or 25p because it still fast enough for that. But 50p or 4k material will most likely cause stuttering. I was astonished when I had stutters while previewing my 50p material, impossible to watch it. Thinking: What is wrong? I have a freaking i7 8700 plus RX560! Even my old hackbook with HD4000 is doing better!
Wifi and Bluetooth
With Mojave PB4/DP5 Bluetooth stopped working with Rehabman's kext, my MagicMouse simply isn't connecting anymore. I decided to finally remove the card because handoff isn't working anyway these days with M.2 or NGFF bluetooth on High Sierra or Mojave (tried several ones "the internet" claims they would work oob but they do not ;)). That is what I wanted Bluetooth for. If you need Wifi I recommend you go with a cheap Wifi-only card, you don't need to pay 30 or 40 $ for dual cards that won't work the way they were intended to work. If you are on a micro ATX board and can have a graphics card plus PCIe Wifi/BT-card that actually connects to a physical USB port on you're board then you may be lucky enough to have handoff working as expected. I'm having a wifi repeater laying around with an ethernet port in case I may need wifi someday on my hack.
I swapped the Intel Wifi card that was coming with the mainboard plugged into the onboard M.2 port with a compatible Dell card. The DW1830 or BCM943602BAED. The wifi part runs half way out of the box, but if you want the card to appear as Apple AirportExtreme and set the country code according to your country you need to put FakePCIID_Broadcom_WiFi.kext into Clover/kexts/other and add some Clover kext-to-patches by PMHeart.
Find: 75166644 3BA3581A 0000750C 4183FE04 7406
Replace: 66906644 3BA3581A 00006690 4183FE04 6690
Comment: AirPortBrcmNIC - PCIe in 10.13.x
Find: 4183FCFF 7435488D 55D0
Replace: 66C70644 45EB348D 55D0 (*this is for DE country code, change for your need)
Comment: BCM4352-Country Code
Bluetooth will work thanks to Rehabman’s kexts. You’ll need BrcmPatchRAM2.kext and BrcmFirmwareData.kext OR BrcmFirmwareRepo.kext. The Data.kext can be injected through Clover, just throw it into the kexts/other folder, the Repo.kext has to be installed in /Library/Extensions on your mac drive, it won’t work with Clover. I had issues with the Data.kext, Bluetooth was gone on every second or third reboot. The Repo.kext is more reliable, haven’t had any issues yet. I really don’t like the kexts to be installed in my system but I guess I have to live with it for the time being.
Oh, handoff and continuity don’t work, doesn’t matter that system profiler shows them as enabled. At least it works in one way: the mac can handoff Safari pages to my iPhone, but not the other way around. Documents opened on my phone show up in the dock, but they are not loaded.
This issue is around since at least High Sierra and from what I’ve read Rehabman is not going to fix this, because he founds this features not worth it. I have to disagree, these are very convenient and valuable features if you work with desktop, laptop and tablet in different situations, I miss this capability very much!
Audio works with Lilu.kext plus AppleALC.kext and you need to inject Layout ID=1 in Clover. For Mojave use the boot setting -lilubetaall to force the kexts to load. If you like to have DP or HDMI audio add a HDAU device to your dsdt (see mine for reference).
Credits go to this great community! I hope I mentioned everyone in this guide whose insights made this hack possible. If I have forgotten someone please let me know!
Sierra, 10.12.6/ High Sierra 10.13.6 on x99 chipset with GTX960 GPU and i7 6800k CPU UEFI 3.50 Hi folks. I managed to make it stable as possible. everything seems to work. for suggestions and additions we are all open. see attachment below
with respect to developers like Pike R. Toleda MaLd0n fabiosun and many others brave people AsRock x99m Extreme 4 Intel® Core™ i7-6800K Processor 15M Cache, up to 3.60 GHz
Gigabyte GTX960 GV-N960IXOC-2GD
HyperX FURY Black 8GB, DDR4, 2400MHz, CL15, 1.2V *2
Solid State Drive (SSD) Intel 600p Series, 256GB, M.2 80mm, PCIe
Corsair VS550 550W
PS: for all apple services to work, you will need to grab some real MLB/ROM mike 2018 asrock_x99m_extreme4_6october2017_EFI_10.12.6.zip
I have the USB ports that are messy. It's even hard to explain what happens as it's not linear.
At second wake from sleep USBs keyboard and mouse become unusable.
If they're plugged on USB3 instead at second wake from sleep the PC...reboots itself.
When I reboot at times USB keyb and mouse are not recognised. Front panel USB3 don't work. USB bluetooth after wake from sleep works really bad.
Some USB3 drives get stuck while copying forcing a reboot.
On Tonymac (sorry) some guy called pastrychef (moderator) tells the story of his build and how he fixed USB. He says Mr RehabMan in person suggests to create a custom SSDT for USBInjectAll.kext
Now, being my machine AMD, some of what they suggest to do becomes difficult to process.
All in all they say to forget your USBs are working fine unless: 1 you're lucky, 2 you fix them properly.
I'm not lucky. Are there permanent fixes because I need sleep to work on my machine and I have all these troubles on USB that affect stability.
Thanks all for your help.
Hi all guys I need your help and I hope you can help me
I took the road to install High Sierra on my new build and now I have some doubt / difficulty I do not know how to solve. My configuration: 8700K Asrock Z370 Professional Gaming i7 AMD RX580 Nitro+ 8GB First I created the usb pendrive and I used Clover with the following configurations: Bootflag: dart=0 -v Kext:
Bios Setting: VT-d = Disabled Share Memory = 128MB IGPU Multi-Monitor = Enabled XHCI Hand-off = Enabled SMBIOS: iMac18,3 So far no problem, it started successfully, I initialized the hdd in APFS and I ran the installation.
Once finished, it started and I made the first configuration successfully. At this point I configured Clover the same way as the installation: Bootflag: dart=0 disablegfxfirmware shikigva=4 -rad4200 darkwake=8 Devices:
Kernel and Kext Patches:
I reboot and start without problems, but I know there is some problem to solve ... for example, the video card seems to recognize it but if I run a benchmark with "Novabench" I noticed that the GPU is recognized as 1GB: With "WhateverGreen.kext" and "RadeonDeInit=Disabled": || || ||
I tried to delete "WhateverGreen.kext" and "RadeonDeInit=Enabled" and I recognize the card differently but the same problem presents itself:
|| || ||
Why is it recognized by 1GB instead of 8GB? While on System Profiler is recognized by 8GB .... I'm doing something wrong?
I tried to enable also "Hardware Encoding & HEVC Support" but I noticed a detail that I do not know if it's right or not (Hardware Info "MacX Video Converter Pro"):
Without "WhateverGreen.kext" and "RadeonDeInit=Enabled": With "WhateverGreen.kext" and "RadeonDeInit=Disabled":
[COMING SOON SCREENSHOT]
Is it normal that this occurs? Which one is correct? I'm going completely in confusion
I'm trying to figure out if I need to make any other changes to the system, if I add some other patches to make it work properly but I do not know where to check.
I'm trying to configure the DSDT but DSDT Editor and MaciASL do not work, they do not open the DSDT.aml file generated by AIDA64. Do you know how to give me a hand? I'm banging my head for 2 days I thank you in advance for the help and I apologize for my english I hope I was clear
