Making a bootable High Sierra USB Installer Entirely From Scratch in Windows or Linux Mint (without access to Mac or App Store Installer.app)By fusion71au
Making a High Sierra USB Installer Entirely From Scratch in Windows
This is a proof of concept tutorial, to show it's possible to create a vanilla High Sierra installer, entirely from scratch, in Windows (even without App Store downloaded "Install macOS High Sierra.app" from a real Mac ). @PikeRAlpha's link to Apple's Software Catalog provides us with all the URLs necessary to download the needed files directly from Apple instead of some dubious source from the internet...
8GB or larger USB drive Boot Disk Utility v2.1.2017rev021b from @CVAD TransMac (free 15 day trial) Paragon Hard Disk Manager Free Download Installer Files Directly from Apple
1) Browse Apple's Regular Software Catalog and find the URLs to download the following 6 installer files...
BaseSystem.dmg BaseSystem.chunklist InstallInfo.plist InstallESDDmg.pkg AppleDiagnostics.dmg AppleDiagnostics.chunklist (Hint - search page for "InstallESD" to find its URL and others nearby)
to a folder named "SharedSupport" on your Windows NTFS drive. A browser download manager (eg Chrono for Chrome, dTA for FireFox) is handy since InstallESD is >4GB ---> allows you to pause/resume interrupted download...
2) Rename InstallESDDmg.pkg to InstallESD.dmg
3) Edit InstallInfo.plist with WordPad/text editor to remove the chunklistURL and chunklistid keys for InstallESD, and renaming it from InstallESDDmg.pkg to InstallESD.dmg (example of edited file attached to this post)...
Note: You can verify the SHA1 checksum of your InstallESD.dmg and BaseSystem.dmg with the correct ones at this website.
Boot Disk Utility to format the Installer USB and Restore OS X Base System HFS partition
1. Format USB with BDU & latest Clover ---> creates boot files in CLOVER partition + second FAT partition
2. Extract 4.hfs from \SharedSupport\BaseSystem.dmg with BDU --> save to it's local folder
3. Restore 4.hfs to USB second partition with BDU ---> 2nd partition becomes bootable "OS X Base System"
Paragon Hard Disk Manager to extend HFS Partition to its Full Extent
Open Paragon Partition Manager Free and resize the second partition of the USB drive to the full size allowed. Don't forget to apply the changes at the end...
Transmac to Copy "SharedSupport" folder to OS X Base System
1. Open the TransMac program and navigate to the HFS+ Volume/Install macOS High Sierra.app/Contents folder. Right click anywhere in the empty space on the RHS pane and select "Copy Here"...
2. In the next stage, select the "SharedSupport" folder we created above as the "Files and Folders to be copied to the Mac Volume"...
Clover configuration is required now. The default config.plist (in the Clover FAT32 partition of the USB) maybe sufficient to boot your machine if you’re lucky. If not, look at the Clover Wiki, Clover Instructions and Clover Configuration Thread for pointers and edit /EFI/Clover/config.plist accordingly with Wordpad or Notepad.
The location of the important configuration files for Clover are summarized below
config.plist--->EFI/CLOVER folder DSDT.aml with or without SSDT.aml--->EFI/CLOVER/ACPI/patched (don't need one if your DSDT is auto patched by Clover in config.plist) Kexts eg FakeSMC, NullCPUPowerManagement --->EFI/CLOVER/kexts/<osx version> or /Other. NB BootDiskUtility by default already has FakeSMC.kext installed here. You may need to add VoodooPS2Controller for your laptop keyboard/trackpad to work. If UEFI booting, you will most likely need one of the OsxAptioFixDrv-64 drivers copied from /EFI/CLOVER/drivers-off/drivers64UEFI to /EFI/CLOVER/drivers64UEFI. If you want to use the installer to run High Sierra in Windows on VMware, you can follow my guide to set up the Virtual Machine and replace Clover's default config with EFI_Clover for VMware (which is compatible to run in VMware). In the screenshots below, I have attached the USB Installer (in this case PhysicalDrive7) to my macOS Virtual Machine. Reboot the system to the USB installer to install High Sierra ...
What happens if we don't have access to TransMac or Paragon Hard Disk Manager?
Not a problem, as long as we get "OS X Base System" bootable, we can launch terminal from the Utilities Menu to copy the SharedSupport folder over to the Installer app. In essence, we will build the full installer app = 5GB+ on the target HD eg "Macintosh HD", by copying both the "small" installer app = 15MB (on "OS X Base System") and the SharedSupport folder from the NTFS volume (mounted in this example on /Volumes/DATA)...
-bash-3.2# cd / -bash-3.2# cp -R Install\ macOS\ High\ Sierra.app /Volumes/Macintosh\ HD/ -bash-3.2# cp -R /Volumes/DATA/SharedSupport /Volumes/Macintosh\ HD/Install\ macOS\ High\ Sierra.app/Contents/
...then start installation with the startosinstall utility...
-bash-3.2# /Volumes/Macintosh\ HD/Install\ macOS\ High\ Sierra.app/Contents/Resources/startosinstall --volume /Volumes/Macintosh\ HD --converttoapfs NO --applicationpath /Volumes/Macintosh\ HD/Install\ macOS\ High\ Sierra.app
The above steps can be automated with the attached "startosinstall.command" script, which will assemble "Install macOS High Sierra.app" on "Macintosh HD" and launch the startosinstall utility targeting the "Macintosh HD" volume. Copy/download to "Macintosh HD", then run in terminal (after attaching DATA USB with /Shared Support folder)...
cd "/Volumes/Macintosh HD" chmod +x startosinstall.command ./startosinstall.command Updated Download Links for macOS Mojave 10.14beta
Browse Apple's Public Beta Software Catalog and find the URLs to download the following 6 installer files...
BaseSystem.dmg BaseSystem.chunklist InstallInfo.plist InstallESDDmg.pkg AppleDiagnostics.dmg AppleDiagnostics.chunklist
Create a bootable copy of macOS Sierra Check out the link http://www.insanelymac.com/forum/files/file/559-flash-drive-maker/ --Install Clover UEFI in USB stick https://sourceforge.net/projects/cloverefiboot/files/Installer/ --Replace Folder CLOVER INSTALLATION.zip --Install Sierra and boot into system! --Install Clover UEFI and replace with my folder CLOVER POST INSTALLATION.zip --Reboot and activate video! Bingo! Now you need a fine tune! I prefer DSDT way, apply all patches in one file, many people prefer many SSDTs or Clover patches! If you need DSDT edit... Run it RunMe.app --DSDT My DSDT DSDT.ASUS H61M-A MaLd0n.zip Patches -FIX ERRORS AND WARNINGS -HPET -SATA -SLPB -DARWIN -EHCx -LPC -HDEF -RTC -IRQs -SBUS -BUS1 -MCHC -ALS0 -SHUTDOWN -LAN -PNLF Clear NVRAM, Purge and Kextcache
--FakeSMC http://www.hwsensors.com/releases --Audio https://github.com/vit9696/AppleALC --USB https://bitbucket.org/RehabMan/os-x-usb-inject-all/downloads --LAN http://www.insanelymac.com/forum/topic/287161-new-driver-for-realtek-rtl8111/ Credits and thanks to the old and new people in the community who developed patches, kexts and bootloaders!
I'm running Mac OS High Sierra in VM Ware Workstation 14 Player on a Windows 10 host.
While it is possible to copy and paste text from the host to the guest, it is not possible to copy and paste from guest to host when running the virtual machine in fullscreen mode with "vmware-kvm.exe".
However, it is working if I run the virtual machine directly in vmplayer in windowed mode.
Any idea how to fix this?
First... If you need DSDT edits... -Post your full Clover folder with original tables in Origin folder(Extract with F4 in Clover boot screen) -Run it, post files generated in your desktop RunMe.app Installation --Create a bootable copy of macOS Sierra Check out the link http://www.insanelymac.com/forum/files/file/559-flash-drive-maker/ --Create a bootable copy of macOS HighSierra Check out the link http://diskmakerx.com/ --Install Clover in USB stick https://sourceforge.net/projects/cloverefiboot/files/Installer/ --Replace with my Clover folder CLOVER.zip --Install Sierra/High Sierra and boot into system! Post Installation --Install Clover in HDD/SSD and replace with my folder CLOVER.zip --Reboot and activate video! -Nvidia WebDriver Sierra http://www.insanelymac.com/forum/topic/312525-nvidia-web-driver-updates-for-macos-sierra-update-07212017/ -Nvidia WebDriver High Sierra http://www.insanelymac.com/forum/topic/324195-nvidia-web-driver-updates-for-macos-high-sierra-update-10162017/ -Cuda http://www.insanelymac.com/forum/topic/302795-cuda-90214-is-out-update-10162017/ -DSDT My DSDT DSDT.GA H97M-DS3P MaLd0n.zip -Patches -FIX ERRORS AND WARNINGS -HPET -SATA -DMAC -SLPB -DARWIN -LPC -XHCI -HDEF -RTC -IRQs -SBUS -MIKEY -BUS1 -MCHC -ALS0 -SHUTDOWN -LAN -EC -PNLF -HDMI
https://bitbucket.org/RehabMan/os-x-fakesmc-kozlek -Audio https://github.com/vit9696/AppleALC -LAN https://github.com/Mieze/IntelMausiEthernet -Credits and thanks to the old and new people in the community who developed patches, kexts and bootloaders! Slice, Kabyl, usr-sse2, jadran, Blackosx, dmazar, STLVNUB, pcj, apianti, JrCs, pene, FrodoKenny, skoczy, ycr.ru, Oscar09, xsmile, SoThOr, RehabMan, Download-Fritz, Zenit432, cecekpawon, Intel, Apple, Oracle, Chameleon Team, crazybirdy, Mieze, Mirone, Oldnapalm, netkas, Elconiglio, artut-pt, ErmaC, Pavo, Toleda, Master Chief and family, bcc9, The King, PMheart, Sherlocks, Micky1979, vit9696, vandroiy2013, Voodoo Team, Pike R. Alpha, lvs1974, Austere.J, CVad and many, many, many others! We're all here to have fun and learn from each other! ENJOY!
--Install Follow my tutorial and use my Clover folder http://www.insanelymac.com/forum/topic/323052-guide-sierra-high-sierra-on-intel-5-6-7-8-and-9-chipset-series-nehalem-sandybridge-ivybridge-haswell-broadwell/ CLOVER Install.zip --Post Install --Install Clover bootloader and replace with my folder CLOVER Post Install.zip Bingo! Now you need a fine tune! DSDT time! If you need edited DSDT... -Post your full Clover folder with original tables in Origin folder(Extract with F4 in Clover boot screen) -Post Ioreg, extract with Ioreg Explorer IORegistryExplorer.app.zip -Run it, post files generate in your desktop RunMe.app -DSDT bios F23 My DSDT DSDT.MaLd0n GA X99-UD3P.zip -Patches -FIX ERRORS AND WARNINGS -HPET -SATA -sSATA -DMAC -SLPB -DARWIN -LPC -XHCI -EHCI -PLUGIN TYPE -ALZA to HDEF -HDEF -RTC -IRQs -SBUS -BLC0 -BUS1 -MCHC -ALS0 -IMEI -SHUTDOWN -LAN -SPSR -EC -PNLF -HDMI
-Clover https://sourceforge.net/projects/cloverefiboot/files/Installer/ -FakeSMC https://bitbucket.org/RehabMan/os-x-fakesmc-kozlek -Audio https://github.com/vit9696/AppleALC -USB https://bitbucket.org/RehabMan/os-x-usb-inject-all/downloads -LAN https://github.com/Mieze/IntelMausiEthernet -Credits and thanks to the old and new people in the community who developed patches, kexts and bootloaders! Apple, Slice, Kabyl, usr-sse2, jadran, Blackosx, dmazar, STLVNUB, pcj, apianti, JrCs, pene, FrodoKenny, skoczy, ycr.ru, Oscar09, xsmile, SoThOr, RehabMan, Download-Fritz, Zenit432, cecekpawon, Intel, Apple, Oracle, Chameleon Team, crazybirdy, Mieze, Mirone, Oldnapalm, netkas, Elconiglio, artut-pt, ErmaC, Pavo, Toleda, Master Chief and family, bcc9, The King, PMheart, Sherlocks, Micky1979, vit9696, vandroiy2013, Voodoo Team, Pike R. Alpha, lvs1974, Austere.J, CVad, nmano and many, many, many others! We're all here to have fun and learn from each other!
