wlazara Posted August 29, 2010 Share Posted August 29, 2010 Hi guys, I am working on a 2009 Mac Pro chassis and it seems to have a newer 44-pin connector as compared to the older models. Does anyone happen to know the pinout for this 44-pin connector? There was a thread at aquamac but no real info and that board doesn't really seem to be functional at the moment. Thanks! Wes Link to comment Share on other sites More sharing options...
craterloads Posted September 5, 2010 Share Posted September 5, 2010 would really like to know aswell. Will be using same case myself in next couple of days Link to comment Share on other sites More sharing options...
dacho Posted September 20, 2010 Share Posted September 20, 2010 Any updates on this?? Thanks Link to comment Share on other sites More sharing options...
Zoran Bogunovic Posted September 20, 2010 Share Posted September 20, 2010 see what i can find out researching... UPDATE: no hits but if you have the harness that would normally connect to the front panel you could do some continuity test to confirm the pinout... few hours work but you'd be the first with documentation Link to comment Share on other sites More sharing options...
wlazara Posted September 22, 2010 Author Share Posted September 22, 2010 see what i can find out researching... UPDATE: no hits but if you have the harness that would normally connect to the front panel you could do some continuity test to confirm the pinout... few hours work but you'd be the first with documentation If I knew how to do that I definitely would =) Link to comment Share on other sites More sharing options...
wlazara Posted October 17, 2010 Author Share Posted October 17, 2010 Anyone have any other ideas? I am willing to work on figuring this out, I just have no idea how to go about it or what equipment would be required... Thanks! Wes Link to comment Share on other sites More sharing options...
Mystroe Posted December 28, 2010 Share Posted December 28, 2010 Any help on this would be appreciated. Looks like the connector is an IDE. Will test this and report back. Link to comment Share on other sites More sharing options...
wlazara Posted December 28, 2010 Author Share Posted December 28, 2010 Any help on this would be appreciated. Looks like the connector is an IDE. Will test this and report back. yep when I noticed it was 44 pins I figured a basic ide cable might work - but the trick is figuring out the pinout apple is using and i have no clue how to do that :-) let us know what you find out! Link to comment Share on other sites More sharing options...
wlazara Posted January 21, 2011 Author Share Posted January 21, 2011 any luck? Link to comment Share on other sites More sharing options...
crazybyte Posted March 24, 2011 Share Posted March 24, 2011 Buy a multimeter and check the pins one by one... Link to comment Share on other sites More sharing options...
riverrun Posted March 25, 2011 Share Posted March 25, 2011 found the info here: http://aquamac.proboards.com/index.cgi?boa...amp;thread=1087 Link to comment Share on other sites More sharing options...
