AbhilashSathe

AppleALC - Headphones buzzing noise

5 posts in this topic

Recommended Posts

Advertisement
On 2/4/2020 at 10:10 PM, Hervé said:

Cache CodecCommander kext from /L/E if you're not already doing so.

The buzzing noise comes back when I wake my machine from sleep. What should I do?

Share this post


Link to post
Share on other sites
Posted (edited)
On 2/16/2020 at 6:59 PM, AbhilashSathe said:

The buzzing noise comes back when I wake my machine from sleep. What should I do?

trying using jack fix

download jack fix and place it usr/local/bin

then go to system pref

user/group

login option

then add jack fix

this will run the script when ever you reboot or wake from hibernate

for more. details follow the guide linked below



https://www.elitemacx86.com/threads/fix-audio-distortion-when-using-headphones-on-laptops.185/

Edited by Bhavin
