Mac OSX Tiger 10.4 in VirtualBox [Proof of Concept]

4 posts in this topic

Recommended Posts


in my trials of Virtualize OSX , yesterday i have tried to install Mac OSX Tiger 10.4 ( yes very old OSX) in Virtualbox


I was able to ?? ... Yes


Here i explain How to ...

Remember it's just a Proof of concept ...


GUIDE - How to install OS X Tiger 10.4 on Virtualbox 4.x


What we need

an Intel Core Duo2 Host computer

Windows XP or win7

Needed (VT-x) enabled on Bios PC

2GB of phisical Ram or more

VirtualBox 4.0 or later ( 4.30 better)

An Hackintosh distro of Tiger ( i.e. Mac.OSX.10.4.5 intelX86.iso -> Intel X86 , AMD, SSE2, SSE3 )


If you choose a OSX Tiger IntelX86 10.4.11 Distro you don't need later to update the Os....



1. Create virtual machine:


VM Name and OS Type


* Name: OSX Tiger

* Operating System: Linux

* Version: Linux 2.6 (32 bit or 64 bit is the same)

* enable virtualization in BIOS HOST computer (VT-x)

* Memory 1024 MB (minimum)

* Virtual Disk Size: 20GB (or more)

* Boot Order: CD/DVD-ROM, Hard Disk




2. Set Option in VM


Enable Hardware clock in UTC time

Enable absolute pointing device

Enable IO APIC

Display Video Memory: 32 MB

Extended Features: Enable 3D Acceleration


Storage SATA controller for HDD image Type: AHCI

IDE Controller for CD/DVD device Type: ICH9


Audio Host Audio: Windows Direct Sound

Audio Controller: Intel HD Audio



* Enable Network Adapter

* Attached to: NAT

* Adapter Type: Intel PRO/1000 MT Server (82545EM)

* Cable connected



3. Installation


Link OSX Tiger.iso to DVD emulation and run Virtual Machine

Start installation


- Choose the language you want

- Choose Disk Utility in the menu Utilities

- Choose the VBOX Hard Disk, put the name OSX Tiger and press Erase button

partition scheme GUID and HFS+ journaled

- When finished close the Disk Utility and continue

- Now you should be able to choose the formated drive and then choose install button

- Press Ad Hoc installation




- Intel BaseSystem package

- Intel SSe3 package

- Update to 10.4.5 ( in this case )


- Now it should install OSX Tiger on your volume (Notice that it will take ~20-30 min to finish!)



4. Post Installation


- Create user ...., ect...



Enjoy your old OSX Tiger on VB!







I'm trying to get the best from this old OSX ... Stay tunes for news ....

Link to comment
Share on other sites

I have teached to Mac OSX Tiger on Virtualbox a new Trick :


I got Full Video resolution inside Virtualbox by manually installing Chameleon 2.1svn r2003 ( i Know is for OSX Lion or ML but works ... so who care ...?)

and by setting Video custom resolution at 1680x1050x32 .


I have changed video resolution on MacOSXTiger.Vbox (before edit i have closed Virtualbox or the modifications were lost)

From windows using notepad and i have edited MacOSXTiger.Vbox and i have inserted in EXTRADATA the CustomVideoMode


<ExtraDataItem name="CustomVideoMode1" value="1680x1050x32"/>



Now i have booted Mac OSX Tiger and edited /Extra/org.chameleon.Boot.plist : inserting Graphics Mode



Graphics Mode ='1680x1050x32'


Save, reboot


Voila! Now i can display full Resolution on my monitor.



Graphics = oob - NO QE/CI due to VM

Audio = ok need patch

Network =oob


Mac Osx Tiger shuts down even in Virtualbox ( don't freeze like Lion/ML or Mavericks). It really shuts down the VM closing window.


Using Chameleon give me the possibility to use SMBIOS.plist ( i make one like Mac3,1) and DSDT.aml (if i want)


See Ya
