imatch Posted May 19, 2017 Share Posted May 19, 2017 I recently installed the AW-CE123H in my thinkpad x230(running osx 10.12.5 sierria ). AW-CE123H info: Model:BCM94352HMB with a buletooth chip(BCM20702) device ID:13d3:3411 I have read the guide https://www.tonymacx86.com/threads/guide-airport-pcie-half-mini-v2.104850/ And here is what I did: 1.put the latest FakePCIID_Broadcom_WiFi.kext FakePCIID.kext BrcmFirmwareRepo.kext BrcmPatchRAM2.kext in EFI/CLOVER/kexts/Other 2.modify the config.plist and adds those patch: Comment = "10.12-BCM94352-fvco-darkvoid"; Find = <81f952aa 00007529>; Name = AirPortBrcm4360; Replace = <81f952aa 00006690>; Comment = "10.11+-BCM94352-Airport-Extreme-skvo"; Find = <6b100000 750d>; Name = AirPortBrcm4360; Replace = <6b100000 9090>; Comment = "10.11+-BT4LE-Handoff-Hotspot-lisai9093"; Find = <4885ff74 47488b07>; Name = IOBluetoothFamily; Replace = <41be0f00 0000eb44>; The wifi is OK(both 2.4G and 5G works), and the system can find the Bluetooth, but I can't pair with any device through bluetooth. Plus, the Bluebooth is working well in Windows10. Has anyone had any experience with getting the Bluetooth connecting to devices under osx 10.12.5? I tried reboot again after sent this post, then I find the Bluetooth start work... I don't know why... I have rebooted several times before I came here ask for help. Link to comment Share on other sites More sharing options...
SavageAUS Posted May 19, 2017 Share Posted May 19, 2017 Try repairing permissions and rebuild kext cache. Sent from my SM-G930F using Tapatalk 1 Link to comment Share on other sites More sharing options...
imatch Posted May 19, 2017 Author Share Posted May 19, 2017 I'm pretty sure both firmware patching kexts have to be installed in /L/E or S/L/E to be cached... From memory, they can't be injected from EFI folder. I put them in efi/clover/kexts/other, the WIFI is always working, and BT is working after my last reboot... Link to comment Share on other sites More sharing options...
imatch Posted May 20, 2017 Author Share Posted May 20, 2017 The BT is not working again after I just boot. I copy BrcmFirmwareRepo.kext BrcmPatchRAM2.kext to /L/E and use KextUtility fix the permission, after reboot, the BT is working. Thanks for helping. Link to comment Share on other sites More sharing options...
