tonycrizzy Posted October 9, 2016 Share Posted October 9, 2016 im running a Gigabyte GA-H170M-DS3H I7- 6700 Intel 240GB SSD 16GB Crucial DDR4 Ram Im all out of ideas on how to get to the El Capitan installer screen, ive went back and forth with swapping several different combinations of OsxAptioFixDrv and OsxAptioFix2Drv, Test2, and OsxAptioFix2Drv-free2000 inside my drivers64UEFI folder. I've modified my config file numerous times adding the proper fixes necessary for Skylake cpu's over the last 4 days. I've tried many different boot Flags, used different USB ports, used documented Troubleshooting methods from forums over the web, watched YouTube tutorials, and set recommended Bios Settings for my motherboard. I need to know if there is anyone with my motherboard and cpu or with models similar to mine so i can receive some better insight on how to fix the issue, it already beyond frustrating. also i want to post a copy of my EFI folder and screenshot of the issue i'm seeing before the system restarts thanks in advance for anyone who tries to help. EFI.rar Quote Link to comment Share on other sites More sharing options...
SavageAUS Posted October 9, 2016 Share Posted October 9, 2016 Your config.plist is corrupt. Also AppleIntelE1000e in kext folder is in document format? Quote Link to comment Share on other sites More sharing options...
tonycrizzy Posted October 10, 2016 Author Share Posted October 10, 2016 i always use at least one of them, OsxAptioFixDrv or OsxAptioFix2Drv. i thought you have to have at least one of them in the drivers64UEFI folder to boot, so are you saying i should remove both and just use EmuVariable? or just try with OsxAptioFix2Drv and EmuVariable together? OsxAptioFixDrv or OsxAptioFix2Drv both give me a "OsxAptioFixDrv: Error - requested memory exceeds our allocated relocation block" whenever i use either one, but when i use OsxAptioFix2Drv-free2000 by itself it give me a "Freeing low memory (up to 0x2000000) results = 14"Your config.plist is corrupt. wow, its corrupt? do you know how i can go about repairing it? Quote Link to comment Share on other sites More sharing options...
SavageAUS Posted October 10, 2016 Share Posted October 10, 2016 You can try open it with plist edit pro and look for errors or create a new one.Sent from my SM-G900I using TapatalkAnd I would try with aptiofix2 and emuvariable together once you sort out plist.Sent from my SM-G900I using Tapatalk Are you using intel onboard graphics or something else? Use this one as a base and edit as needed. config.plist.zip Quote Link to comment Share on other sites More sharing options...
tonycrizzy Posted October 10, 2016 Author Share Posted October 10, 2016 thanks a bunch im gonna work with what you gave me and see how it works, appreciate you You can try open it with plist edit pro and look for errors or create a new one.Sent from my SM-G900I using TapatalkAnd I would try with aptiofix2 and emuvariable together once you sort out plist.Sent from my SM-G900I using Tapatalk Are you using intel onboard graphics or something else? Use this one as a base and edit as needed. yes im using on board intel graphics, no graphic card Quote Link to comment Share on other sites More sharing options...
tonycrizzy Posted October 10, 2016 Author Share Posted October 10, 2016 i tried it with the config file as it was given, and with OsxAptioFix2Drv and EmuVariable in the drivers64UEFI folder. i got this message for 4seconds and then the computer reboot: OsxAptioFixDrv: Starting overrides for .IABootFiles\boot.efi Using relic block: yes, hibernate wake: no ++++++++++++++++++++++++++++++++++++++++++++++++ Quote Link to comment Share on other sites More sharing options...
SavageAUS Posted October 10, 2016 Share Posted October 10, 2016 Ok now maybe try with OsxAptioFixDrv and EmuVariable drop Fix2. Sent from my SM-G900I using Tapatalk Quote Link to comment Share on other sites More sharing options...
tonycrizzy Posted October 10, 2016 Author Share Posted October 10, 2016 (edited) Ok now maybe try with OsxAptioFixDrv and EmuVariable drop Fix2. Sent from my SM-G900I using Tapatalk ok, trying now Ok now maybe try with OsxAptioFixDrv and EmuVariable drop Fix2. Sent from my SM-G900I using Tapatalk i just tried it and i got the same message as before OsxAptioFixDrv: Error - requested memory exceeds our allocated relocation block i just cant understand why its not working are there any config file modification that you think will help, maybe some ideas based on your own systems config file? Edited October 10, 2016 by Allan Quote Link to comment Share on other sites More sharing options...
SavageAUS Posted October 10, 2016 Share Posted October 10, 2016 I pretty much copied my configuration except for graphics and ram. You could try change smbios to something newer. Sent from my SM-G900I using Tapatalk Quote Link to comment Share on other sites More sharing options...
SavageAUS Posted October 10, 2016 Share Posted October 10, 2016 Try this one. config.plist.zip Quote Link to comment Share on other sites More sharing options...
SavageAUS Posted October 11, 2016 Share Posted October 11, 2016 Have you had any luck? Sent from my SM-G900I using Tapatalk Quote Link to comment Share on other sites More sharing options...
tonycrizzy Posted October 14, 2016 Author Share Posted October 14, 2016 Have you had any luck? Sent from my SM-G900I using Tapatal sadly no, i had to step away from the computer for a couple days just to cool down but now im back to trying to fix the issue, it seems like nothing will work Try this one. im giving this one you just sent a try i will let you know how it goes, thanks again Quote Link to comment Share on other sites More sharing options...
