southbay Posted January 21, 2006 Share Posted January 21, 2006 Howdy folks, my first post in this forum, hoping to get some light shed on a specific topic. I have an Inspiron 9100 PM 1.6 1GB RAM SSE SSE2 NO PAE Here's my short questions. Several people have posted supposed success with NO PAE but with SSE2. My question, is this true? I need the help of the great GURU's out there to fill me in. I am so anxious to run OSX on my LAPTOP I can't sleep. But also, I can't get any straight answers. So, if this is so, and your a NO PAE OSX on the PC user, please email me. I need to know which installation to use, and the steps to do it. I'm from way back in the Apple II days (live in Silicon Valley) about 10 minutes from Apple. I would be eternally greatful if someone could help with this. Thanks a bunch guys.....This looks to be an interesting year! Link to comment https://www.insanelymac.com/forum/topic/7356-pae-or-no-pae-that-is-the-question-need-help/ Share on other sites More sharing options...
bloodroot Posted January 21, 2006 Share Posted January 21, 2006 I'm trying to figure out the same. It looks like win2osx.net is the place, but they're down. There's a long thread on the subject, though googles only cached one of the pages google for pae reboot problems Link to comment https://www.insanelymac.com/forum/topic/7356-pae-or-no-pae-that-is-the-question-need-help/#findComment-45935 Share on other sites More sharing options...
MikeBee Posted January 21, 2006 Share Posted January 21, 2006 Right chaps. Here's the deal with my machine: Dell D600 Pentium M 1.6 -> CPU has no PAE. I was running 10.4.1 fine from the Deadmoo image, but wanted to run 10.4.3, so downloaded the image and patched with Jas 4.2b ppf. Mounting the image in vmware and trying to install that way was a no show as vmware would moan about the lack of pae.... But, when I burned the image to DVD and booted native it worked a charm. Am now running 10.4.3 just as well as 10.4.1 and tbh it feels much the same. Link to comment https://www.insanelymac.com/forum/topic/7356-pae-or-no-pae-that-is-the-question-need-help/#findComment-45937 Share on other sites More sharing options...
southbay Posted January 21, 2006 Author Share Posted January 21, 2006 Right chaps. Here's the deal with my machine: Dell D600 Pentium M 1.6 -> CPU has no PAE. I was running 10.4.1 fine from the Deadmoo image, but wanted to run 10.4.3, so downloaded the image and patched with Jas 4.2b ppf. Mounting the image in vmware and trying to install that way was a no show as vmware would moan about the lack of pae.... But, when I burned the image to DVD and booted native it worked a charm. Am now running 10.4.3 just as well as 10.4.1 and tbh it feels much the same. Excellent! I had a feeling there would be someone out there that could help me. Can you tell me the process, in some steps? (.e.e which image you converted to DVD and installed native? My buddy is a VMWare junky, but I never care for it (slowness). At least at that time (several years ago) I played around with VMWare a little bit. I spent about $1500.00 on my Inspiron about a year ago, and can't afford a new PC. This would be the greatest if I had a simple guide my Pal and I could go with to make it an easy transition, multi-system. Any help again, is really appreciated. Here is my system config report: <<< System Summary >>> -------------------------------------------------------------------------------- < System > Host Name: INSPIRON9100 User: Brian Domain: WORKGROUP < Processor > Model: Intel® Pentium® M processor 1.60GHz Speed: 1.60GHz Performance Rating: PR1914 (estimated) Type: Mobile L2 On-board Cache: 2MB ECC Synchronous, ATC, 8-way set, 64 byte line size < Mainboard > Bus(es): ISA X-Bus AGP PCI PCMCIA CardBus USB FireWire/ 1394 MP Support: No MP APIC: No System BIOS: Dell Inc. A00 System: Dell Inc. Inspiron 9200 Mainboard: Dell Inc. 0G7183 Total Memory: 1.2GB DDR-SDRAM < Chipset 1 > Model: Dell Computer Corp 82855PM Host-Hub Interface Bridge Front Side Bus Speed: 4x 100MHz (400MHz data rate) Total Memory: 1.3GB DDR-SDRAM Memory Bus Speed: 2x 166MHz (332MHz data rate) < Video System > Monitor/Panel: Default Monitor Adapter: ATI MOBILITY RADEON 9700 Series Imaging Device: Hewlett-Packard OfficeJet G85 Scanner < Physical Storage Devices > Hard Disk: HTS548040M9AT00 (37GB) CD-ROM/DVD: SONY DVD+-RW DW-D56A (CD 47X Rd, 63X Wr) (DVD 6X Rd, 8X Wr) CD-ROM/DVD: Generic DVD-ROM SCSI CdRom Device (CD 32X Rd) (DVD 4X Rd) < Logical Storage Devices > Hard Disk (C:): 37GB (16GB, 43% Free Space) (NTFS) Curb_enthusiasm (D:): 7.2GB (UDF) < Peripherals > Serial/Parallel Port(s): 1 COM / 0 LPT USB Controller/Hub: Intel® 82801DB/DBM USB Universal Host Controller - 24C2 USB Controller/Hub: Intel® 82801DB/DBM USB Universal Host Controller - 24C4 USB Controller/Hub: Intel® 82801DB/DBM USB Universal Host Controller - 24C7 USB Controller/Hub: Intel® 82801DB/DBM USB2 Enhanced Host Controller - 24CD USB Controller/Hub: USB Root Hub USB Controller/Hub: USB Root Hub USB Controller/Hub: USB Root Hub USB Controller/Hub: USB Root Hub USB Controller/Hub: USB Composite Device FireWire/1394 Controller/Hub: OHCI Compliant IEEE 1394 Host Controller PCMCIA/CardBus Controller: Ricoh R/RL/5C476(II) or Compatible CardBus Controller Keyboard: Standard 101/102-Key or Microsoft Natural PS/ 2 Keyboard Keyboard: HID Keyboard Device Mouse: Alps Touch Pad Mouse: HID-compliant mouse Human Interface: HID-compliant consumer control device Human Interface: HID-compliant consumer control device Human Interface: HID-compliant consumer control device Human Interface: HID-compliant device Human Interface: HID-compliant consumer control device Human Interface: HID-compliant consumer control device Human Interface: USB Human Interface Device Human Interface: USB Human Interface Device < MultiMedia Device(s) > Device: SigmaTel C-Major Audio < Communication Device(s) > Device: Conexant D110 MDC V.9x Modem < Printers and Faxes > Model: Intuit Internal Printer Model: hp officejet g series fax Model: hp officejet g series Model: HP LaserJet 5M Model: Auto HP DeskJet 1220C on MONITOR < Power Management > AC Line Status: On-Line Battery No 1: 100% < Operating System(s) > Windows System: Microsoft Windows XP/2002 Professional (Win32 x86) 5.01.2600 (Service Pack 2) < Network Services > Adapter: Broadcom 440x 10/100 Integrated Controller Adapter: Intel® PRO/Wireless 2200BG Network Connection < Performance Tips > Tip 2546: Large memory modules should be ECC/Parity. Tip 2: Double-click tip or press Enter while a tip is selected for more information about the tip. <<< Mainboard Information >>> -------------------------------------------------------------------------------- < System > Manufacturer: Dell Inc. Model: Inspiron 9200 Serial Number: CL72G61 ID: 4C4C4544-3710004C-C0C33280-3136474F < System Chassis > Manufacturer: Dell Inc. Type: Portable Can be locked: No Serial Number: CL72G61 Boot-up State: Safe Power State: Safe Thermal State: Safe Security State: External Interface Locked-out < Mainboard > Manufacturer: Dell Inc. MP Support: No Model: 0G7183 Serial Number: .CL72G61.CN129614C72349. < On-board Devices > ATI Radeon 9700: Video Adapter (Enabled) Sigmatel 9750: Sound Adapter (Enabled) < System Memory Controller > Location: Mainboard Error Correction Capability: None Number of Memory Slots: 2 Maximum Installable Memory: 1GB Bank 1 - DIMM_A: DIMM Synchronous DDR-SDRAM 256MB/64 @ 333Mt/s Bank 2 - DIMM_B: DIMM Synchronous DDR-SDRAM 1GB/64 @ 333Mt/s < Chipset 1 > Model: Dell Computer Corp 82855PM Host-Hub Interface Bridge Bus(es): ISA X-Bus AGP PCI PCMCIA CardBus USB FireWire/ 1394 i2c/SMBus Front Side Bus Speed: 4x 100MHz (400MHz data rate) Maximum FSB Speed / Max Memory:4x 100MHz / 2x 166MHz Width: 64-bit IO Queue Depth: 12 request(s) < Chipset 1 Hub Interface > Type: Hub-Interface Version: 1.50 Number of Ports: 1 Width: 8-bit Full Duplex: Yes Multiplier: 1/1x Speed: 4x 66MHz (264MHz data rate) < Logical/Chipset 1 Memory Banks > Bank 0: 128MB DDR-SDRAM 2.5-3-3-7 1CMD Bank 1: 128MB DDR-SDRAM 2.5-3-3-7 1CMD Bank 2: 512MB DDR-SDRAM 2.5-3-3-7 1CMD Bank 3: 512MB DDR-SDRAM 2.5-3-3-7 1CMD Speed: 2x 166MHz (332MHz data rate) Multiplier: 5/3x Width: 64-bit Refresh Rate: 7.80µs Power Save Mode: Yes Fixed Hole Present: No < Memory Module 1 > Manufacturer: Samsung Model: M4 70L3224FT0-CB3 Serial Number: 08095222 Type: 256MB DDR-SDRAM Technology: 8x(16Mx16) Speed: PC2700U 2.5-3-3-7 Version: 1.0 Date of Manufacture: Thursday, July 07, 2005 Set Timing @ 167MHz: 2.5-3-3-7 Set Timing @ 133MHz: 2.0-2-2-6 < Memory Module 2 > Model: Wu Type: 1GB DDR-SDRAM Technology: 16x(64Mx8) Speed: PC2700U 2.5-3-3-7 Version: 1.0 Date of Manufacture: Saturday, December 25, 1999 Set Timing @ 167MHz: 2.5-3-3-7 Set Timing @ 133MHz: 2.0-2-2-6 < Environment Monitor(s) > Dock Module Bay: Unknown < Cooling Device(s) > Fan: OK < Temperature Sensor(s) > CPU Internal Temperature Proce:OK < AGP Bus(es) on Hub 1 > Version: 2.00 Speed: 4x 66MHz (264MHz data rate) Multiplier: 1/2x Fast-Writes Enabled: Yes Side Band Enabled: Yes Aperture Size: 128MB < PCI Bus(es) on Hub 1 > Version: 2.20 Number of Bridges: 2 PCI Bus 0: PCI (33MHz) PCI Bus 2: PCI (33MHz) Multiplier: 1/3x < LPC Hub Controller 1 > Model: Intel Corporation 82801DBM (ICH4-M) LPC Interface Bridge ACPI Power Management Enabled: Yes Delayed Transaction Enabled: Yes < LPC Legacy Controller 1 > Type: SMSC LPC v1 Version: 1D.01 Number of Enabled Devices: 8 < USB Controller 1 > Model: Dell Computer Corp 82801DB/DBL USB UHCI Controller #1 (ICH4/ICH4-L A1 step) Version: 1.10 Interface: UHCI Channels: 2 Speed: 48MHz Supported Speed(s): Low (1.5Mbps) Full (12Mbps) Legacy Emulation Enabled: No < USB Controller 2 > Model: Dell Computer Corp 82801DB/DBL USB UHCI Controller #2 (ICH4/ICH4-L A1 step) Version: 1.10 Interface: UHCI Channels: 2 Speed: 48MHz Supported Speed(s): Low (1.5Mbps) Full (12Mbps) Legacy Emulation Enabled: No < USB Controller 3 > Model: Dell Computer Corp 82801DB/DBL USB UHCI Controller #3 (ICH4/ICH4-L A1 step) Version: 1.10 Interface: UHCI Channels: 2 Speed: 48MHz Supported Speed(s): Low (1.5Mbps) Full (12Mbps) Legacy Emulation Enabled: No < USB Controller 4 > Model: Dell Computer Corp 82801DB/DBL USB 2.0 EHCI Controller (ICH4/ICH4-L A1 step) Version: 2.00 Specification: 1.00 Interface: EHCI Channels: 6 Companion Controllers: 3 Supported Speed(s): Low (1.5Mbps) Full (12Mbps) High (480Mbps) Addressing Support: 64-bit Legacy Emulation Enabled: No < FireWire/1394 Controller 1 > Model: Dell Computer Corp RL5c552 IEEE-1394 Controller Version: 1.10 Interface: OHCI Enhanced Support: Yes Channels: 64 Speed: 400MHz < CardBus/PCMCIA Controller 1 > Model: Ricoh Co Ltd RL5c476 CardBus Controller < System SMBus Controller 1 > Model: Intel 801xx/63xx SMBus Version: 0.01 Specification: 1.00 Advanced TCO Mode Enabled: No Slave Device Enabled: No PEC Support: No Speed: 100kHz < Expansion Slot(s) > PCMCIA 0: PCMCIA/CardBus 32-bit +5V +3.3V PCMCIA CardBus ZoomVideo ModemRing Available MiniPCI (1h): Other 32-bit +5V +3.3V PME Available < Port Connector > USB: USB - None / USB MONITOR: Video - None / DB-15 pin female FireWire: FireWire/1394 - None / None Modem: Modem - None / RJ-11 Ethernet: Network - None / RJ-45 < Performance Tips > Notice 224: SMBIOS/DMI information may be inaccurate. Warning 2507: Mainboard has too few memory slots. Upgrading the memory may be difficult or expensive. Warning 2508: All memory slots are full. Upgrading the memory may be difficult or expensive. Tip 2546: Large memory modules should be ECC/Parity. Tip 2: Double-click tip or press Enter while a tip is selected for more information about the tip. <<< CPU & BIOS Information >>> -------------------------------------------------------------------------------- << Processor 1 >> < Processor > Model: Intel® Pentium® M processor 1.60GHz Speed: 1.60GHz Performance Rating: PR1914 (estimated) Type: Mobile Package: FC µPGA479M Rated Speed/FSB: 1600MHz / 4x 100MHz Multiplier: 16/1x Minimum/Maximum Multiplier: 6/1x / 16/1x Generation: G6 Name: P3D (Dothan) Pentium M 90nm 900-2.2GHz 0.9- 1.4V Revision/Stepping: D / 6 (16) Stepping Mask: B1 Microcode: MU06D617 Core Voltage Rating: 1.308V Maximum Physical / Virtual Add:32-bit / 32-bit Native Page Size: 4kB < Co-Processor (FPU) > Type: Built-in Revision/Stepping: D / 6 (16) < Processor Cache(s) > Internal Data Cache: 32kB Synchronous, Write-Back, 8-way set, 64 byte line size Internal Instruction Cache: 32kB Synchronous, Write-Back, 8-way set, 64 byte line size L2 On-board Cache: 2MB ECC Synchronous, ATC, 8-way set, 64 byte line size L2 Cache Multiplier: 1/1x (1595MHz) < Upgradeability > Socket/Slot: Microprocessor Upgrade Interface: None Supported Speed(s): 1.80GHz+ < Processor Power Management > Processor Throttling Enabled: Yes Throttle Range: 14% - 100% < System Management Device(s) > Dock Module Bay: Unknown < Features > FPU - Co-Processor Built-in: Yes VME - Virtual Mode Extensions: Yes DE - Debugging Extension: Yes PSE - Page Size Extension: Yes TSC - Time Stamp Counter: Yes MSR - Model Specific Registers:Yes PAE - Physical Address Extensi:No MCE - Machine Check Exception: Yes CX8 - Compare & Exchange Instr:Yes APIC - Local APIC Built-in: No SEP - Fast System Call: Yes MTRR - Memory Type Range Regis:Yes PGE - Page Global Enable: Yes MCA - Machine Check Architectu:Yes PAT - Page Attribute Table: Yes PSE36 - 36-bit Page Size Exten:No PSN - Unique Serial Number: No CLF - Cache Line Flush Support:Yes DS - Debug Trace & EMON Store: Yes ACPI - Software Clock Control: Yes (W)MMX Technology: Yes FXSR - Fast Float Save & Resto:Yes SSE Technology: Yes SSE2 Technology: Yes SS - Self Snoop: Yes HTT - Hyper-Threading Technolo:No TM - Thermal Monitor: Yes PBE - Pending Break Enable: Yes SSE3 Technology: No MON - Monitor/MWait: No DSCPL - CPL qualified Debug St:No VMX - Virtual Machine eXtensio:No EST - Enhanced SpeedStep Techn:Yes TM2 - Thermal Monitor 2: Yes DAZ - Denormals Are Zero: Yes < Advanced Settings > L2 Cacheable Range: 4GB Data Error Checking: No IO Queue Depth: 8 request(s) EST - Enhanced SpeedStep Techn:Yes TM - Thermal Monitor: No TM2 - Thermal Monitor 2: Yes < Machine Check Architecture Settings > Number of Reporting Banks: 5 bank(s) < Variable Range MTRR Settings > MTRR 0: 00000000-3FFFFFFF (0MB-1024MB) WB MTRR 1: 40000000-4FFFFFFF (1024MB-1280MB) WB MTRR 2: FEDA0000-FEDBFFFF (4078MB-4078MB) WT < Fixed Range MTRR Settings > MTRR 0 Range 0: 00000000-0000FFFF (0kB-64kB) WB MTRR 0 Range 1: 00010000-0001FFFF (64kB-128kB) WB MTRR 0 Range 2: 00020000-0002FFFF (128kB-192kB) WB MTRR 0 Range 3: 00030000-0003FFFF (192kB-256kB) WB MTRR 0 Range 4: 00040000-0004FFFF (256kB-320kB) WB MTRR 0 Range 5: 00050000-0005FFFF (320kB-384kB) WB MTRR 0 Range 6: 00060000-0006FFFF (384kB-448kB) WB MTRR 0 Range 7: 00070000-0007FFFF (448kB-512kB) WB MTRR 1 Range 0: 00080000-00083FFF (512kB-528kB) WB MTRR 1 Range 1: 00084000-00087FFF (528kB-544kB) WB MTRR 1 Range 2: 00088000-0008BFFF (544kB-560kB) WB MTRR 1 Range 3: 0008C000-0008FFFF (560kB-576kB) WB MTRR 1 Range 4: 00090000-00093FFF (576kB-592kB) WB MTRR 1 Range 5: 00094000-00097FFF (592kB-608kB) WB MTRR 1 Range 6: 00098000-0009BFFF (608kB-624kB) WB MTRR 1 Range 7: 0009C000-0009FFFF (624kB-640kB) WB MTRR 2 Range 0: 000A0000-000A3FFF (640kB-656kB) UC MTRR 2 Range 1: 000A4000-000A7FFF (656kB-672kB) UC MTRR 2 Range 2: 000A8000-000ABFFF (672kB-688kB) UC MTRR 2 Range 3: 000AC000-000AFFFF (688kB-704kB) UC MTRR 2 Range 4: 000B0000-000B3FFF (704kB-720kB) UC MTRR 2 Range 5: 000B4000-000B7FFF (720kB-736kB) UC MTRR 2 Range 6: 000B8000-000BBFFF (736kB-752kB) UC MTRR 2 Range 7: 000BC000-000BFFFF (752kB-768kB) UC MTRR 3 Range 0: 000C0000-000C0FFF (768kB-772kB) WP MTRR 3 Range 1: 000C1000-000C1FFF (772kB-776kB) WP MTRR 3 Range 2: 000C2000-000C2FFF (776kB-780kB) WP MTRR 3 Range 3: 000C3000-000C3FFF (780kB-784kB) WP MTRR 3 Range 4: 000C4000-000C4FFF (784kB-788kB) WP MTRR 3 Range 5: 000C5000-000C5FFF (788kB-792kB) WP MTRR 3 Range 6: 000C6000-000C6FFF (792kB-796kB) WP MTRR 3 Range 7: 000C7000-000C7FFF (796kB-800kB) WP MTRR 4 Range 0: 000C8000-000C8FFF (800kB-804kB) WP MTRR 4 Range 1: 000C9000-000C9FFF (804kB-808kB) WP MTRR 4 Range 2: 000CA000-000CAFFF (808kB-812kB) WP MTRR 4 Range 3: 000CB000-000CBFFF (812kB-816kB) WP MTRR 4 Range 4: 000CC000-000CCFFF (816kB-820kB) WP MTRR 4 Range 5: 000CD000-000CDFFF (820kB-824kB) WP MTRR 4 Range 6: 000CE000-000CEFFF (824kB-828kB) WP MTRR 4 Range 7: 000CF000-000CFFFF (828kB-832kB) WP MTRR 5 Range 0: 000D0000-000D0FFF (832kB-836kB) UC MTRR 5 Range 1: 000D1000-000D1FFF (836kB-840kB) UC MTRR 5 Range 2: 000D2000-000D2FFF (840kB-844kB) UC MTRR 5 Range 3: 000D3000-000D3FFF (844kB-848kB) UC MTRR 5 Range 4: 000D4000-000D4FFF (848kB-852kB) UC MTRR 5 Range 5: 000D5000-000D5FFF (852kB-856kB) UC MTRR 5 Range 6: 000D6000-000D6FFF (856kB-860kB) UC MTRR 5 Range 7: 000D7000-000D7FFF (860kB-864kB) UC MTRR 6 Range 0: 000D8000-000D8FFF (864kB-868kB) UC MTRR 6 Range 1: 000D9000-000D9FFF (868kB-872kB) UC MTRR 6 Range 2: 000DA000-000DAFFF (872kB-876kB) UC MTRR 6 Range 3: 000DB000-000DBFFF (876kB-880kB) UC MTRR 6 Range 4: 000DC000-000DCFFF (880kB-884kB) UC MTRR 6 Range 5: 000DD000-000DDFFF (884kB-888kB) UC MTRR 6 Range 6: 000DE000-000DEFFF (888kB-892kB) UC MTRR 6 Range 7: 000DF000-000DFFFF (892kB-896kB) UC MTRR 7 Range 0: 000E0000-000E0FFF (896kB-900kB) UC MTRR 7 Range 1: 000E1000-000E1FFF (900kB-904kB) UC MTRR 7 Range 2: 000E2000-000E2FFF (904kB-908kB) UC MTRR 7 Range 3: 000E3000-000E3FFF (908kB-912kB) UC MTRR 7 Range 4: 000E4000-000E4FFF (912kB-916kB) UC MTRR 7 Range 5: 000E5000-000E5FFF (916kB-920kB) UC MTRR 7 Range 6: 000E6000-000E6FFF (920kB-924kB) UC MTRR 7 Range 7: 000E7000-000E7FFF (924kB-928kB) UC MTRR 8 Range 0: 000E8000-000E8FFF (928kB-932kB) UC MTRR 8 Range 1: 000E9000-000E9FFF (932kB-936kB) UC MTRR 8 Range 2: 000EA000-000EAFFF (936kB-940kB) UC MTRR 8 Range 3: 000EB000-000EBFFF (940kB-944kB) UC MTRR 8 Range 4: 000EC000-000ECFFF (944kB-948kB) UC MTRR 8 Range 5: 000ED000-000EDFFF (948kB-952kB) UC MTRR 8 Range 6: 000EE000-000EEFFF (952kB-956kB) UC MTRR 8 Range 7: 000EF000-000EFFFF (956kB-960kB) UC MTRR 9 Range 0: 000F0000-000F0FFF (960kB-964kB) WP MTRR 9 Range 1: 000F1000-000F1FFF (964kB-968kB) WP MTRR 9 Range 2: 000F2000-000F2FFF (968kB-972kB) WP MTRR 9 Range 3: 000F3000-000F3FFF (972kB-976kB) WP MTRR 9 Range 4: 000F4000-000F4FFF (976kB-980kB) WP MTRR 9 Range 5: 000F5000-000F5FFF (980kB-984kB) WP MTRR 9 Range 6: 000F6000-000F6FFF (984kB-988kB) WP MTRR 9 Range 7: 000F7000-000F7FFF (988kB-992kB) WP MTRR 10 Range 0: 000F8000-000F8FFF (992kB-996kB) WP MTRR 10 Range 1: 000F9000-000F9FFF (996kB-1000kB) WP MTRR 10 Range 2: 000FA000-000FAFFF (1000kB-1004kB) WP MTRR 10 Range 3: 000FB000-000FBFFF (1004kB-1008kB) WP MTRR 10 Range 4: 000FC000-000FCFFF (1008kB-1012kB) WP MTRR 10 Range 5: 000FD000-000FDFFF (1012kB-1016kB) WP MTRR 10 Range 6: 000FE000-000FEFFF (1016kB-1020kB) WP MTRR 10 Range 7: 000FF000-000FFFFF (1020kB-1024kB) WP < PAT Settings > PAT 0: WB PAT 1: WC PAT 2: UC- PAT 3: UC PAT 4: WB PAT 5: WC PAT 6: UC- PAT 7: UC < Performance Tips > Tip 210: Mainboard supports faster CPUs, so the CPU can be upgraded when needed. Notice 224: SMBIOS/DMI information may be inaccurate. Tip 2: Double-click tip or press Enter while a tip is selected for more information about the tip. << System BIOS >> < General Information > Manufacturer: Dell Inc. Version: A00 Date of Manufacture: 10/08/2004 Plug & Play Version: 1.00 SMBIOS/DMI Version: 2.30 (EE)PROM Size: 512kB < General Capabilities > Can be Updated/Flashed: Yes Can be Shadowed: Yes Is Socketed: No Supports Plug & Play: Yes Supports ESCD: No Supports Enhanced Disk Drive: No NEC PC-98 Spec Compatible: No < Power Management Features > Supports APM: Yes Supports ACPI: Yes Supports Smart Battery: Yes < Boot Features > Supports Selective Booting: Yes Supports CD/DVD Boot: Yes Supports PCMCIA/CardBus Boot: No Supports LS-120 Boot: No Supports ZIP Boot: No Supports i2o Boot: No Supports FireWire/1394 Boot: No Supports BIOS Boot Block: Yes Supports Interactive Network B:Yes < Performance Tips > Notice 224: SMBIOS/DMI information may be inaccurate. Tip 212: BIOS can be shadowed so check whether it is. Warning 214: BIOS is flash-able but surface-mounted. An unsuccessful flash may be fatal. Warning 208: BIOS does not support the EDD (Enhanced Disk Drive) specification. Check for an update. Tip 2: Double-click tip or press Enter while a tip is selected for more information about the tip. <<< APM & ACPI Information >>> -------------------------------------------------------------------------------- < ACPI BIOS > Version: 1.00 Manufacturer: DELL Revision: 0A.08 MP APIC: No SCI ACPI IRQ: 9 < Advanced Power Management Information > Supported S(leep) States: S1, S3, S4, S5 UPS: No Thermal Zones: Yes Power Button: Yes Sleep Button: Yes Lid Button: Yes Display Dimming Supported: No Hibernate Supported: No < Wake Capabilities > Timer Wake State: S3 < Processor Power Management > Processor Throttling Enabled: Yes Throttle Range: 14% - 100% < Drives Power Management > Drives Spin Down Enabled: Yes Drive Spin Range: 3 seconds(s) - 3600 seconds(s) < Power Schemes > Home/Office Desk: This scheme is suited to most home or desktop computers that are left plugged in all the time. Portable/Laptop: This scheme is designed for extended battery life for portable computers on the road. (Active) Presentation: This scheme keeps the monitor on for doing presentations. Always On: This scheme keeps the computer running so that it can be accessed from the network. Use this scheme if you do not have network wakeup hardware. Minimal Power Management: This scheme keeps the computer on and optimizes it for high performance. Max Battery: This scheme is extremely aggressive for saving power. < APM System Status > AC Line Status: On-Line < Battery No 1 > Battery Status: High Battery Charged At: 100% < Battery No 1 > Manufacturer: Sanyo Model: DELL F51334B Location: Sys. Battery Bay Type: LION Version: 1.0 Serial Number: 0283 Capacity: 53Wh Voltage: 11.1V < Performance Tips > Notice 224: SMBIOS/DMI information may be inaccurate. Tip 2: Double-click tip or press Enter while a tip is selected for more information about the tip. <<< PCI(e), AGP, CardBus Bus(es) Information >>> -------------------------------------------------------------------------------- << Generic >> << Interface >> < System Buses > AGP Bus(es): 1 PCI Bus(es): 2 CardBus Bus(es): 1 Interface Version: 2.20 < Interface Properties > Config space access mechanism :Yes Config space access mechanism :No Cycle generation mechanism 1 s:No Cycle generation mechanism 2 s:No << PCI Bus 0 (1/1x PCIClk) >> << Dell Computer Corp 82855PM Host-Hub Interface Bridge >> < Device Information > Device Type: Host Processor Bridge Device ID: bus 0, device 0, function 0 OEM Device Name: Intel Corporation 82855PM Host-Hub Interface Bridge OEM Hardware ID: FUN_0, VEN_8086, DEV_3340, REV_03 Device Name: Dell Computer Corp 82855PM Host-Hub Interface Bridge Product ID: VEN_1028, DEV_01A2 Revision: A / 4 (3) < Host Capabilities > Version: 1.00 < AGP Capabilities > Version: 2.00 Command Queue Length: 32 Fast-Writes Support: Yes Over 4GB Addressing Support: No Side Band Support: Yes Data Transfer Modes Support: 1x 2x 4x < Device Capabilities > I/O port resources: No Memory resources: Yes Bus Master Capable: Yes Special Cycle Recognition: No Memory Write & Invalidate: No VGA Palette Snoop: No Parity Error Response: No Address/Data Stepping: No System Error Line: Yes Fast back-to-back Transactions:No Detects Parity Errors: No Supports System Error Line: No Supports Parity Line: No User Defined Format: No 66MHz Bus Support: No New Capability List: Yes Device Select Timing: Fast Multi-Function Device: No Header: 00 Interface: 00 < Hardware Resources > Memory Range: E8000000 Dynamic Management: Yes << Intel Corporation 82855PM AGP Bridge >> < Device Information > Device Type: PCI to PCI Bridge Device ID: bus 0, device 1, function 0 Windows Device Name: Intel® 82855PM Processor to AGP Controller - 3341 OEM Device Name: Intel Corporation 82855PM AGP Bridge OEM Hardware ID: FUN_0, VEN_8086, DEV_3341, REV_03 Revision: A / 4 (3) < Device Capabilities > Latency Timer: 32 clk I/O port resources: Yes Memory resources: Yes Bus Master Capable: Yes Special Cycle Recognition: No Memory Write & Invalidate: No VGA Palette Snoop: No Parity Error Response: No Address/Data Stepping: No System Error Line: Yes Fast back-to-back Transactions:No Detects Parity Errors: No Supports System Error Line: No Supports Parity Line: No User Defined Format: No 66MHz Bus Support: Yes New Capability List: No Device Select Timing: Fast Multi-Function Device: No Header: 01 Interface: 00 < Bridge Settings > Primary Bus No.: 0 Secondary Bus No.: 1 Subordinate Bus No.: 1 Decoding: Positive < Hardware Resources > Dynamic Management: Yes << Dell Computer Corp 82801DB/DBL USB UHCI Controller #1 (ICH4/ICH4-L A1 step) >> < Device Information > Device Type: Universal Serial Bus Controller Device ID: bus 0, device 1D, function 0 Windows Device Name: Intel® 82801DB/DBM USB Universal Host Controller - 24C2 OEM Device Name: Intel Corporation 82801DB/DBL USB UHCI Controller #1 (ICH4/ICH4-L A1 step) OEM Hardware ID: FUN_0, VEN_8086, DEV_24C2, REV_01 Device Name: Dell Computer Corp 82801DB/DBL USB UHCI Controller #1 (ICH4/ICH4-L A1 step) Product ID: VEN_1028, DEV_01A2 Revision: A / 2 (1) < Device Capabilities > I/O port resources: Yes Memory resources: No Bus Master Capable: Yes Special Cycle Recognition: No Memory Write & Invalidate: No VGA Palette Snoop: No Parity Error Response: No Address/Data Stepping: No System Error Line: No Fast back-to-back Transactions:No Detects Parity Errors: No Supports System Error Line: No Supports Parity Line: No User Defined Format: No 66MHz Bus Support: No New Capability List: No Device Select Timing: Medium Multi-Function Device: Yes Header: 00 Interface: 00 < Hardware Resources > I/O Range: 0000BF80 Irq. No.: 11 INT Pin: A# Dynamic Management: Yes << Dell Computer Corp 82801DB/DBL USB UHCI Controller #2 (ICH4/ICH4-L A1 step) >> < Device Information > Device Type: Universal Serial Bus Controller Device ID: bus 0, device 1D, function 1 Windows Device Name: Intel® 82801DB/DBM USB Universal Host Controller - 24C4 OEM Device Name: Intel Corporation 82801DB/DBL USB UHCI Controller #2 (ICH4/ICH4-L A1 step) OEM Hardware ID: FUN_1, VEN_8086, DEV_24C4, REV_01 Device Name: Dell Computer Corp 82801DB/DBL USB UHCI Controller #2 (ICH4/ICH4-L A1 step) Product ID: VEN_1028, DEV_01A2 Revision: A / 2 (1) < Device Capabilities > I/O port resources: Yes Memory resources: No Bus Master Capable: Yes Special Cycle Recognition: No Memory Write & Invalidate: No VGA Palette Snoop: No Parity Error Response: No Address/Data Stepping: No System Error Line: No Fast back-to-back Transactions:No Detects Parity Errors: No Supports System Error Line: No Supports Parity Line: No User Defined Format: No 66MHz Bus Support: No New Capability List: No Device Select Timing: Medium Header: 00 Interface: 00 < Hardware Resources > I/O Range: 0000BF40 Irq. No.: 11 INT Pin: B# Dynamic Management: Yes << Dell Computer Corp 82801DB/DBL USB UHCI Controller #3 (ICH4/ICH4-L A1 step) >> < Device Information > Device Type: Universal Serial Bus Controller Device ID: bus 0, device 1D, function 2 Windows Device Name: Intel® 82801DB/DBM USB Universal Host Controller - 24C7 OEM Device Name: Intel Corporation 82801DB/DBL USB UHCI Controller #3 (ICH4/ICH4-L A1 step) OEM Hardware ID: FUN_2, VEN_8086, DEV_24C7, REV_01 Device Name: Dell Computer Corp 82801DB/DBL USB UHCI Controller #3 (ICH4/ICH4-L A1 step) Product ID: VEN_1028, DEV_01A2 Revision: A / 2 (1) < Device Capabilities > I/O port resources: Yes Memory resources: No Bus Master Capable: Yes Special Cycle Recognition: No Memory Write & Invalidate: No VGA Palette Snoop: No Parity Error Response: No Address/Data Stepping: No System Error Line: No Fast back-to-back Transactions:No Detects Parity Errors: No Supports System Error Line: No Supports Parity Line: No User Defined Format: No 66MHz Bus Support: No New Capability List: No Device Select Timing: Medium Header: 00 Interface: 00 < Hardware Resources > I/O Range: 0000BF20 Irq. No.: 11 INT Pin: C# Dynamic Management: Yes << Dell Computer Corp 82801DB/DBL USB 2.0 EHCI Controller (ICH4/ICH4-L A1 step) >> < Device Information > Device Type: Universal Serial Bus Controller Device ID: bus 0, device 1D, function 7 Windows Device Name: Intel® 82801DB/DBM USB2 Enhanced Host Controller - 24CD OEM Device Name: Intel Corporation 82801DB/DBL USB 2.0 EHCI Controller (ICH4/ICH4-L A1 step) OEM Hardware ID: FUN_7, VEN_8086, DEV_24CD, REV_01 Device Name: Dell Computer Corp 82801DB/DBL USB 2.0 EHCI Controller (ICH4/ICH4-L A1 step) Product ID: VEN_1028, DEV_01A2 Revision: A / 2 (1) < Power Management Features > Version: 2.00 Supports Clock Slow-down: No Supports D1 PM State: No Supports D2 PM State: No Supports PME#: Yes Supports PME Clock: No < Device Capabilities > I/O port resources: No Memory resources: Yes Bus Master Capable: Yes Special Cycle Recognition: No Memory Write & Invalidate: No VGA Palette Snoop: No Parity Error Response: No Address/Data Stepping: No System Error Line: Yes Fast back-to-back Transactions:No Detects Parity Errors: No Supports System Error Line: No Supports Parity Line: No User Defined Format: No 66MHz Bus Support: No New Capability List: Yes Device Select Timing: Medium Header: 00 Interface: 20 < Hardware Resources > Memory Range: F8FFFC00 Irq. No.: 11 INT Pin: D# Dynamic Management: Yes << Intel Corporation 82801BAM/CAM/DBM (ICH2-M/3-M/4-M) Hub Interface to PCI Bridge >> < Device Information > Device Type: PCI to PCI Bridge Device ID: bus 0, device 1E, function 0 Windows Device Name: Intel® 82801DBM PCI Bridge - 2448 OEM Device Name: Intel Corporation 82801BAM/CAM/DBM (ICH2-M/3- M/4-M) Hub Interface to PCI Bridge OEM Hardware ID: FUN_0, VEN_8086, DEV_2448, REV_81 Revision: I / 2 (129) < Device Capabilities > I/O port resources: Yes Memory resources: Yes Bus Master Capable: Yes Special Cycle Recognition: No Memory Write & Invalidate: No VGA Palette Snoop: No Parity Error Response: No Address/Data Stepping: No System Error Line: Yes Fast back-to-back Transactions:No Detects Parity Errors: Yes Supports System Error Line: No Supports Parity Line: No User Defined Format: No 66MHz Bus Support: No New Capability List: No Device Select Timing: Fast Multi-Function Device: No Header: 01 Interface: 00 < Bridge Settings > Primary Bus No.: 0 Secondary Bus No.: 2 Subordinate Bus No.: 3 Decoding: Positive < Hardware Resources > Dynamic Management: Yes << Intel Corporation 82801DBM (ICH4-M) LPC Interface Bridge >> < Device Information > Device Type: PCI to ISA Bridge Device ID: bus 0, device 1F, function 0 Windows Device Name: Intel® 82801DBM LPC Interface Controller - 24CC OEM Device Name: Intel Corporation 82801DBM (ICH4-M) LPC Interface Bridge OEM Hardware ID: FUN_0, VEN_8086, DEV_24CC, REV_01 Revision: A / 2 (1) < Device Capabilities > I/O port resources: Yes Memory resources: Yes Bus Master Capable: Yes Special Cycle Recognition: Yes Memory Write & Invalidate: No VGA Palette Snoop: No Parity Error Response: No Address/Data Stepping: No System Error Line: Yes Fast back-to-back Transactions:No Detects Parity Errors: No Supports System Error Line: No Supports Parity Line: No User Defined Format: No 66MHz Bus Support: No New Capability List: No Device Select Timing: Medium Multi-Function Device: Yes Header: 00 Interface: 00 < Hardware Resources > Dynamic Management: Yes << Dell Computer Corp 82801DBM (ICH4-M) UltraATA/100 EIDE Controller >> < Device Information > Device Type: ATA Disk Controller Device ID: bus 0, device 1F, function 1 Windows Device Name: Intel® 82801DBM Ultra ATA Storage Controller - 24CA OEM Device Name: Intel Corporation 82801DBM (ICH4-M) UltraATA/ 100 EIDE Controller OEM Hardware ID: FUN_1, VEN_8086, DEV_24CA, REV_01 Device Name: Dell Computer Corp 82801DBM (ICH4-M) UltraATA/ 100 EIDE Controller Product ID: VEN_1028, DEV_01A2 Revision: A / 2 (1) < Device Capabilities > I/O port resources: Yes Memory resources: Yes Bus Master Capable: Yes Special Cycle Recognition: No Memory Write & Invalidate: No VGA Palette Snoop: No Parity Error Response: No Address/Data Stepping: No System Error Line: No Fast back-to-back Transactions:No Detects Parity Errors: No Supports System Error Line: No Supports Parity Line: No User Defined Format: No 66MHz Bus Support: No New Capability List: No Device Select Timing: Medium Header: 00 Interface: 8A < Hardware Resources > I/O Range: 000001F0 I/O Range: 000003F0 I/O Range: 00000170 I/O Range: 00000370 I/O Range: 0000BFA0 Memory Range: FFAFFC00 INT Pin: A# I/O Range: 000001F0 Irq. No.: 14 I/O Range: 00000170 Irq. No.: 15 Dynamic Management: Yes << Dell Computer Corp 82801DB/DBL SMBus Controller (ICH4/ICH4-L A1 step) >> < Device Information > Device Type: i2c/SMBus Serial Bus Controller Device ID: bus 0, device 1F, function 3 OEM Device Name: Intel Corporation 82801DB/DBL SMBus Controller (ICH4/ICH4-L A1 step) OEM Hardware ID: FUN_3, VEN_8086, DEV_24C3, REV_01 Device Name: Dell Computer Corp 82801DB/DBL SMBus Controller (ICH4/ICH4-L A1 step) Product ID: VEN_1028, DEV_01A2 Revision: A / 2 (1) < Device Capabilities > I/O port resources: Yes Memory resources: No Bus Master Capable: No Special Cycle Recognition: No Memory Write & Invalidate: No VGA Palette Snoop: No Parity Error Response: No Address/Data Stepping: No System Error Line: No Fast back-to-back Transactions:No Detects Parity Errors: No Supports System Error Line: No Supports Parity Line: No User Defined Format: No 66MHz Bus Support: No New Capability List: No Device Select Timing: Medium Header: 00 Interface: 00 < Hardware Resources > I/O Range: 000008C0 INT Pin: B# Dynamic Management: Yes << Dell Computer Corp 82801DB/DBL AC'97 Audio Controller (ICH4/ICH4-L A1 step) >> < Device Information > Device Type: Audio Multimedia Device Device ID: bus 0, device 1F, function 5 Windows Device Name: SigmaTel C-Major Audio OEM Device Name: Intel Corporation 82801DB/DBL AC'97 Audio Controller (ICH4/ICH4-L A1 step) OEM Hardware ID: FUN_5, VEN_8086, DEV_24C5, REV_01 Device Name: Dell Computer Corp 82801DB/DBL AC'97 Audio Controller (ICH4/ICH4-L A1 step) Product ID: VEN_1028, DEV_01A2 Revision: A / 2 (1) < Power Management Features > Version: 2.00 Supports Clock Slow-down: No Supports D1 PM State: No Supports D2 PM State: No Supports PME#: Yes Supports PME Clock: No < Device Capabilities > I/O port resources: Yes Memory resources: Yes Bus Master Capable: Yes Special Cycle Recognition: No Memory Write & Invalidate: No VGA Palette Snoop: No Parity Error Response: No Address/Data Stepping: No System Error Line: No Fast back-to-back Transactions:No Detects Parity Errors: No Supports System Error Line: No Supports Parity Line: No User Defined Format: No 66MHz Bus Support: No New Capability List: Yes Device Select Timing: Medium Header: 00 Interface: 00 < Hardware Resources > I/O Range: 0000D800 I/O Range: 0000DC40 Memory Range: F8FFF800 Memory Range: F8FFF400 Irq. No.: 5 INT Pin: B# Dynamic Management: Yes << Conexant Systems 82801DB/DBL AC'97 Modem Controller (ICH4/ICH4-L A1 step) >> < Device Information > Device Type: Modem Communication Device Device ID: bus 0, device 1F, function 6 Windows Device Name: Conexant D110 MDC V.9x Modem OEM Device Name: Intel Corporation 82801DB/DBL AC'97 Modem Controller (ICH4/ICH4-L A1 step) OEM Hardware ID: FUN_6, VEN_8086, DEV_24C6, REV_01 Device Name: Conexant Systems 82801DB/DBL AC'97 Modem Controller (ICH4/ICH4-L A1 step) Product ID: VEN_14F1, DEV_5423 Revision: A / 2 (1) < Power Management Features > Version: 2.00 Supports Clock Slow-down: No Supports D1 PM State: No Supports D2 PM State: No Supports PME#: Yes Supports PME Clock: No < Device Capabilities > I/O port resources: Yes Memory resources: No Bus Master Capable: Yes Special Cycle Recognition: No Memory Write & Invalidate: No VGA Palette Snoop: No Parity Error Response: No Address/Data Stepping: No System Error Line: No Fast back-to-back Transactions:No Detects Parity Errors: No Supports System Error Line: No Supports Parity Line: No User Defined Format: No 66MHz Bus Support: No New Capability List: Yes Device Select Timing: Medium Header: 00 Interface: 00 < Hardware Resources > I/O Range: 0000D400 I/O Range: 0000D080 Irq. No.: 5 INT Pin: B# Dynamic Management: Yes << AGP Bus 1 (2/1x PCIClk) >> << Dell Computer Corp Radeon Mobility M10 NP (RV350) >> < Device Information > Device Type: VGA Video Adapter Device ID: bus 1, device 0, function 0 Windows Device Name: ATI MOBILITY RADEON 9700 Series OEM Device Name: ATI Technologies Inc Radeon Mobility M10 NP (RV350) OEM Hardware ID: FUN_0, VEN_1002, DEV_4E50, REV_00 Device Name: Dell Computer Corp Radeon Mobility M10 NP (RV350) Product ID: VEN_1028, DEV_2002 Revision: A / 1 (0) < AGP Capabilities > Version: 2.00 Command Queue Length: 80 Fast-Writes Support: Yes Over 4GB Addressing Support: No Side Band Support: Yes Data Transfer Modes Support: 1x 2x 4x < Power Management Features > Version: 2.00 Supports Clock Slow-down: Yes Supports D1 PM State: Yes Supports D2 PM State: Yes Supports PME#: No Supports PME Clock: No < Device Capabilities > Line Cache Size: 8 byte(s) Latency Timer: 255 clk I/O port resources: Yes Memory resources: Yes Bus Master Capable: Yes Special Cycle Recognition: No Memory Write & Invalidate: No VGA Palette Snoop: Yes Parity Error Response: No Address/Data Stepping: No System Error Line: Yes Fast back-to-back Transactions:No Detects Parity Errors: No Supports System Error Line: No Supports Parity Line: No User Defined Format: No 66MHz Bus Support: Yes New Capability List: Yes Device Select Timing: Medium Multi-Function Device: No Header: 00 Interface: 00 < Hardware Resources > Memory Range: F0000000 I/O Range: 0000C000 Memory Range: FCFF0000 Irq. No.: 11 INT Pin: A# Expansion ROM: 80000000 Dynamic Management: Yes < Performance Tips > Warning 1203: VGA palette snooping seriously reduces video performance. Disable it if you don't need it. Tip 2: Double-click tip or press Enter while a tip is selected for more information about the tip. << PCI Bus 2 (1/1x PCIClk) >> << Dell Computer Corp BCM440x 100Base-TX Fast Ethernet >> < Device Information > Device Type: Ethernet Network Device ID: bus 2, device 0, function 0 Windows Device Name: Broadcom 440x 10/100 Integrated Controller OEM Device Name: Broadcom Corp BCM440x 100Base-TX Fast Ethernet OEM Hardware ID: FUN_0, VEN_14E4, DEV_170C, REV_02 Device Name: Dell Computer Corp BCM440x 100Base-TX Fast Ethernet Product ID: VEN_1028, DEV_01A2 Revision: A / 3 (2) < Power Management Features > Version: 2.00 Supports Clock Slow-down: Yes Supports D1 PM State: Yes Supports D2 PM State: Yes Supports PME#: Yes Supports PME Clock: No < Device Capabilities > Latency Timer: 32 clk I/O port resources: No Memory resources: Yes Bus Master Capable: Yes Special Cycle Recognition: No Memory Write & Invalidate: No VGA Palette Snoop: No Parity Error Response: No Address/Data Stepping: No System Error Line: Yes Fast back-to-back Transactions:No Detects Parity Errors: No Supports System Error Line: No Supports Parity Line: No User Defined Format: No 66MHz Bus Support: No New Capability List: Yes Device Select Timing: Fast Multi-Function Device: Link to comment https://www.insanelymac.com/forum/topic/7356-pae-or-no-pae-that-is-the-question-need-help/#findComment-45967 Share on other sites More sharing options...
bloodroot Posted January 22, 2006 Share Posted January 22, 2006 I figured it was just a no go if it wouldn't even work in vmware. Nice to hear it's a possibility, I'll have to give it another shot. My main reason for using vmware was due to lack of intel wireless drivers, but I guess theres always the usb solution. Link to comment https://www.insanelymac.com/forum/topic/7356-pae-or-no-pae-that-is-the-question-need-help/#findComment-46183 Share on other sites More sharing options...
southbay Posted January 22, 2006 Author Share Posted January 22, 2006 I figured it was just a no go if it wouldn't even work in vmware. Nice to hear it's a possibility,I'll have to give it another shot. My main reason for using vmware was due to lack of intel wireless drivers, but I guess theres always the usb solution. Interesting. Well if Bob got it going, I'm sure anxious to get mine going too! What a year this is going to be for computing! Brian Link to comment https://www.insanelymac.com/forum/topic/7356-pae-or-no-pae-that-is-the-question-need-help/#findComment-46185 Share on other sites More sharing options...
VaiOSX Posted February 26, 2006 Share Posted February 26, 2006 As far as i know : Pentium M @900Mhz (code named "Banya") doesn't have PAE at all (it is really broken). It only supports SSE2, which is enough to run 10.4.1. (forget 10.4.3 and more) Pentium M @1.6Ghz (code named "Dothan") doesn't have "officially" PAE. It's not true because i can successfully install all the OS X Intel versions from 10.4.1 to 10.4.5. In fact the PAE is broken but (for a reason that only Jas and Maxxuss could answer) it seems that it is not really disabled. If you have a Dothan version of the Pentium M, you will be able to install OS X 10.4.3 and more, only in Native Mode (VM Ware says that it has no PAE, even if it's already activated in VMWARE vmx prefs or boot.ini /PAE). Link to comment https://www.insanelymac.com/forum/topic/7356-pae-or-no-pae-that-is-the-question-need-help/#findComment-63785 Share on other sites More sharing options...
Silicon Valley Posted February 26, 2006 Share Posted February 26, 2006 Ok, so VMWare no, and native install yes. Only one question. Which image should I use then. If you installed 10.4.1 - 10.4.3 with no problems, thats great. I just need to know which image to install, and when you say NATIVE, I'm assuming you mean from the built in CD? I installed 10.4.4 this morning with the GHOST 8.0 image from Canada on my Fujitsu Lifebook (N6010) but it doesn't recognize the DVD-RAM drive, nor the Ethernet (GIGABIT ethernet) or the sound, or the Athero Wireless. Makes this machine pretty useless unless I wanna spend a ton of money on accessories, and then it's not a laptop anymore. I will give a shot to installing on the Inspiron. Which image would your recommend since that system (Inspiron 9200) only has SSE2, and I don't think I've gotten that one from the torrents yet. If that doesn't work, I'm going to say screw it, and I'm gonna build an INTEL 915GUXL with a 3.2 in it. It's one of the only ones on the HCL that "EVERYTHING WORKS". The lowest cost I could find on the web was around $102.00 for the motherboard, and then I think the 3.2 is close to $200.00. I have an HP200I DVD single layer for reading and general purpose burning which the HCL says is compatible with Patch4 or something to that effect. It has the latest Intel Extreme Graphics, Superific Accellerated video card which will be more than enough for me, since I really want to use it for IWORK and ILIFE apps. I think with a GIG or ram and all my price may be around $400.00 for a nice fast WoZx 10.4.4 machine. As a side note, I wonder if Apple is looking at the fact that people in the Windows community love ITunes so much and the players, maybe Steve is moving in the right direction by making it very possible to run every one of his IWORK ILIFE, etc. etc programs on the PC side. Maybe some day in the future he will release OSX Intel v1.01. The reason for the .01 is because version 1.0 will have a major bug that directs you to the Microsoft Update page........snicker.... Thanks for the help, and just let me know which file to get for the Inspiron and I'll give it a shot. Thanks Southbay Link to comment https://www.insanelymac.com/forum/topic/7356-pae-or-no-pae-that-is-the-question-need-help/#findComment-63793 Share on other sites More sharing options...
antrunix Posted February 26, 2006 Share Posted February 26, 2006 My Dothan according to Everest has to PAE enabled. But in reality it has according to FreeBSD system. So, I installed 10.4.4...fairy tale, isn't? Link to comment https://www.insanelymac.com/forum/topic/7356-pae-or-no-pae-that-is-the-question-need-help/#findComment-63798 Share on other sites More sharing options...
Silicon Valley Posted February 26, 2006 Share Posted February 26, 2006 Nothing surprises me at this point. I still contemplate just buying like an Apple Mini, but I don't want a system with a cheezy 40gig 4200rpm drive. That's always kind of been my only beef with Apple. I can live with the Steve Jobs attitude, we all have our trademarks (of course his attitude is Copyright 1980, Apple Computer Inc.". This is why he needs to share at least his applications for Windows users like me. I can't justify paying twice or more for a system I can get the same performance on for over half the price. I just price out a Shuttle PC online, with a 3.2 P4 775 chip, and everything that's compatable on the HCL list. The total cost with 1GB RAM, 250GB HD, and DVD Dual Layer for around $600.00. If I combo all the items at my local Fry's, I can probably get out for the same price or less with tax. This is where Apple is making their mistakes. They keep themselves under performing and over priced. Heck they barely keep the newer models long enough and they're on to the next "new and great, fantastic breakthrough" like the Mac Mini. The only problem is, it's like a cheap mini AT board running on old pinball machine parts (is that from Back to the Future?). Jobs needs to step up and broaden Apple's horizons, and really get the HYPE going again for Apple. Peace Southbay Link to comment https://www.insanelymac.com/forum/topic/7356-pae-or-no-pae-that-is-the-question-need-help/#findComment-63801 Share on other sites More sharing options...
bilditup1 Posted February 26, 2006 Share Posted February 26, 2006 The fact is, whether or not 10.4.3 will work on a non-PAE Pentium M varies from person to person. It worked for my first generation Fujitsu P7010D and various others have also reported success. (Of course, if you're talking about running 10.4.1 on a widescreen 855gme, forget it, cuz you wont have any support, period.) Link to comment https://www.insanelymac.com/forum/topic/7356-pae-or-no-pae-that-is-the-question-need-help/#findComment-63980 Share on other sites More sharing options...
