CI & QE on ATI 9800 XT ?


8 posts in this topic

Recommended Posts

hi folks,


just installed uphuck's iso v1.3. (btw: gr8t release)

callisto is enabled and running smoothly.


unfortunately i cannot switch QE & CI on!


up to 10.4.7 there was no problem to edit ati9700.kext (ID entry).

but now even if i edit the ati9700.kext there are no 3D effects available (see below)


Radeon 9800 XT:


Chipset Model: Radeon 9800 XT

Type: Display

Bus: PCI

VRAM (Total): 128 MB

Vendor: ATI (0x1002)

Device ID: 0x4e4a

Revision ID: 0x0000


BenQ FP937s+:

Resolution: 1280 x 1024 @ 76 Hz

Depth: 32-bit Color

Core Image: Not Supported

Main Display: Yes

Mirror: Off

Online: Yes

Quartz Extreme: Not Supported


has something changed since 10.4.7 concerning the grahics kexts?

if someone has a solution please tell me.






my system specs:

iP4 3GHz SSE2 only, 1024MB RAM, ATI 9800 XXL AGP (Medion), AC97, 20GB IDE HDD, Broadcom WiFi miniPCI,

Pioneer DVD-R/RW, Sony DVDROM

Link to comment
Share on other sites

Yes you should probably use older kexts, I myself did not have that problem b/c i used jas 10.4.9 update




this is what I did for 10.4.8:


Had to add device ID to ATIRADEON9700.kext Later used Callisto 008 for res switching, follow callisto faq

to get res switching and QE CI. Plus installed QuartzSimple to enable Quartz2DExtreme



Link to comment
Share on other sites

hi scrizz,


you mentioned to use callisto (b008) to enable QE & CI.

how did you make it? can't find any instructions for that.

(framebuffer entry/change in ATIGAxxxx-kext was made, too)

res switching goes well - only 3D support is disabled.


if i should go on with older kexts, do ou know which of them i have to replace?

is it sufficient to use Jas 10.4.9 ATI9700.kext?

thank you so muchfor your help!






just checked whether the ati9700.kext was loaded - but no success ! :P

how can i modify my osx86 in order that system will load the kext?

(my ati9700.kext has extended info.plist showing my device id, permisions were repaired and extension cache files were deleted)

Link to comment
Share on other sites

well callisto didn't give me QE CI, editing the info.plist in the ATIRADEON9700.kext did.

Callisto was used to enable res switching.


I personaly used the Jas 10.4.8 sse2/sse3 version and didn't have to replace any kexts.

This is what I did:


Step 1: edit info.plist from ATIRADEON9700.kext

Step 2: intall callisto added CallistoFB to ATIRADEON9700GA.kext (make sure you follow the callisto instructions and the faq.. don't skip steps.

Step 3: Repair permissons

Step 4: Watch a movie, lol




Hope this works for you! :)

Link to comment
Share on other sites
