Mainboards for Intel Xeon E5-2600 V4?

[nbritton]

Can anyone recommend a hackintosh mainboard for the Intel Xeon E5-2600 V4? Preferably dual socket?

[okrasit]

Asus z10pe-d16 ws, just be aware of macOS max core count of 64 -> 16cores/32threads per socket.

[nbritton]

Asus z10pe-d16 ws, just be aware of macOS max core count of 64 -> 16cores/32threads per socket.

Thanks for your reply, I didn't realize MacOS had a core count limit.



I'm not sure what I should do, I pulled eight Intel Xeon E5-2600 V4 engineering samples out of the trash the other day, four are E5-2680 V4 and four are E5-2660 V4. What should I do with all these? I already have a Mac Pro 2012 with two X5690, 128GB of RAM, Nvidia GTX 980, and PCIe SSD, and to be complete honest it's already fast enough and the system just works. A dual socket E5-2680 V4 would totally blow the socks off my Mac Pro 2012, but is it worth the effort of going the hackintosh route? Alternatively, I was thinking maybe I could build them into single socket gaming systems and sell them on eBay. What would you do with them?



Also is the MSI X99A Gaming Pro Carbon hackintosh compatible?

[okrasit]

Those 2660v4 aren't really attractive, at all. I'd try to sell those on eBay.  Even the 2680v4s might be {censored}, if the uncore multiplier is capped to 16, which it probably is. I'd check that before throwing money on a mobo & ram. Overall, I'd try to sell them all, as is, and spend the money on a pair of OEM/QS v4s, mobo and ram.



[nbritton]

I'm not sure what uncore is, but I believe the 2680v4 is unlocked since I can change the base frequency and multiplier. The chip is marked QHVA, and currently I have it working with a MSI X99A Gaming Pro Carbon, tested with BIOS V1.2 and V1.3.

Architecture:          x86_64

CPU op-mode(s):        32-bit, 64-bit

Byte Order:            Little Endian

CPU(s):                28

On-line CPU(s) list:   0-27

Thread(s) per core:    2

Core(s) per socket:    14

Socket(s):             1

NUMA node(s):          1

Vendor ID:             GenuineIntel

CPU family:            6

Model:                 79

Model name:            Genuine Intel(R) CPU 0000 @ 2.40GHz

Stepping:              0

CPU MHz:               1201.875

CPU max MHz:           3100.0000

CPU min MHz:           1200.0000

BogoMIPS:              4799.45

Virtualization:        VT-x

L1d cache:             32K

L1i cache:             32K

L2 cache:              256K

L3 cache:              35840K

NUMA node0 CPU(s):     0-27

Flags:                 fpu vme de pse tsc msr pae mce cx8 apic sep mtrr pge mca cmov pat pse36 clflush dts acpi mmx fxsr sse sse2 ss ht tm pbe syscall nx pdpe1gb rdtscp lm constant_tsc arch_perfmon pebs bts rep_good nopl xtopology nonstop_tsc aperfmperf eagerfpu pni pclmulqdq dtes64 monitor ds_cpl vmx smx est tm2 ssse3 sdbg fma cx16 xtpr pdcm pcid dca sse4_1 sse4_2 x2apic movbe popcnt tsc_deadline_timer aes xsave avx f16c rdrand lahf_lm abm 3dnowprefetch intel_pt tpr_shadow vnmi flexpriority ept vpid fsgsbase tsc_adjust bmi1 hle avx2 smep bmi2 erms invpcid rtm cqm rdseed adx smap xsaveopt cqm_llc cqm_occup_llc cqm_mbm_total cqm_mbm_local dtherm ida arat pln pts





Processor Information

    Socket Designation: SOCKET 0

    Type: Central Processor

    Family: Xeon

    Manufacturer: Intel

    ID: F0 06 04 00 FF FB EB BF

    Signature: Type 0, Family 6, Model 79, Stepping 0

    Flags:

        FPU (Floating-point unit on-chip)

        VME (Virtual mode extension)

        DE (Debugging extension)

        PSE (Page size extension)

        TSC (Time stamp counter)

        MSR (Model specific registers)

        PAE (Physical address extension)

        MCE (Machine check exception)

        CX8 (CMPXCHG8 instruction supported)

        APIC (On-chip APIC hardware supported)

        SEP (Fast system call)

        MTRR (Memory type range registers)

        PGE (Page global enable)

        MCA (Machine check architecture)

        CMOV (Conditional move instruction supported)

        PAT (Page attribute table)

        PSE-36 (36-bit page size extension)

        CLFSH (CLFLUSH instruction supported)

        DS (Debug store)

        ACPI (ACPI supported)

        MMX (MMX technology supported)

        FXSR (FXSAVE and FXSTOR instructions supported)

        SSE (Streaming SIMD extensions)

        SSE2 (Streaming SIMD extensions 2)

        SS (Self-snoop)

        HTT (Multi-threading)

        TM (Thermal monitor supported)

        PBE (Pending break enabled)

    Version: Genuine Intel(R) CPU 0000 @ 2.40GHz

    Voltage: 0.2 V

    External Clock: 100 MHz

    Max Speed: 4000 MHz

    Current Speed: 2400 MHz

    Status: Populated, Enabled

    Upgrade: Socket LGA2011-3

    L1 Cache Handle: 0x0067

    L2 Cache Handle: 0x0068

    L3 Cache Handle: 0x0069

    Serial Number: Not Specified

    Asset Tag: Not Specified

    Part Number: Not Specified

    Core Count: 14

    Core Enabled: 14

    Thread Count: 28

    Characteristics:

        64-bit capable

        Multi-Core

        Hardware Thread

        Execute Protection

        Enhanced Virtualization

        Power/Performance Control

[okrasit]

The "unlocked" refers to the core multiplier lock bit not being set, allowing you to only under clock on E5 2600 v1/v2/v3/v4 Xeons. Setting any higher multipliers, than the cpu is rated for, will simply do the max rated multi. The only setting, that actually does something, is the BCLK and it'll max out at around < 110MHz. The gain from overclocking via BCLK is, in fact, near zero because of the "on die" voltage regulators current limiter -> the cpu will start to throttle.



The crippled uncore frequency adds latency (40% x16 vs x27), not only to the L3 cache but to the memory controller, QPI, SA -> PCIe and so on.  It'll cascade on a dual socket system, giving you a really unresponsive system.

[nbritton]

The "unlocked" refers to the core multiplier lock bit not being set, allowing you to only under clock on E5 2600 v1/v2/v3/v4 Xeons. Setting any higher multipliers, than the cpu is rated for, will simply do the max rated multi. The only setting, that actually does something, is the BCLK and it'll max out at around < 110MHz. The gain from overclocking via BCLK is, in fact, near zero because of the "on die" voltage regulators current limiter -> the cpu will start to throttle.



The crippled uncore frequency adds latency (40% x16 vs x27), not only to the L3 cache but to the memory controller, QPI, SA -> PCIe and so on.  It'll cascade on a dual socket system, giving you a really unresponsive system.



What do you mean crippled? A single 2680v4 is faster than my dual X5690 Mac Pro. However, I logged my system load on my Mac Pro over the last day and I only averaged 1.775 (uptime command, 15 minute average, n = 44, x̅ = 1.775, s = 0.7631), max was under 4 for a normal workload. RAM usage ranges from 50GB to 100GB. So since my workload can't max out even a single X5690 I'm doubting that upgrading to dual 2680v4 would yield practical gains relative to what I have now.
