TomHsiung Posted May 21, 2015 Author Share Posted May 21, 2015 These values have nothing to do with what I showed! You really need fix your power management, like USB ports in DSDT, and another patches. Proof: 5/21/15 12:17:37.000 AM kernel[0]: Wake reason: XHC But the USB is native compatible. I did not do anything with the USB driver. Link to comment Share on other sites More sharing options...
TimeWalker75a Posted May 21, 2015 Share Posted May 21, 2015 By supported models and fan staying silent I think they probably expect your supported model to have an SMC chip that would programmatically suppress fans during the instances of waking up.. which won't be as noticeable as you expect it to on a desktop computer where fans gets powered as soon as +12V lane springs back to life... 1 Link to comment Share on other sites More sharing options...
TomHsiung Posted May 21, 2015 Author Share Posted May 21, 2015 By supported models and fan staying silent I think they probably expect your supported model to have an SMC chip that would programmatically suppress fans during the instances of waking up.. which won't be as noticeable as you expect it to on a desktop computer where fans gets powered as soon as +12V lane springs back to life...So, do you know how to enable Power Nap? Link to comment Share on other sites More sharing options...
TomHsiung Posted May 21, 2015 Author Share Posted May 21, 2015 These values have nothing to do with what I showed! You really need fix your power management, like USB ports in DSDT, and another patches. Proof: 5/21/15 12:17:37.000 AM kernel[0]: Wake reason: XHC But, in the same post the author has the same console record as mine. See @charliebounce's post here, http://www.insanelymac.com/forum/topic/299222-is-power-nap-possible-for-hackintosh/?do=findComment&comment=2036187 Here is @charliebounce's console record, he has wakes by XHC too. 30/06/2014 06:27:06.000 kernel[0]: Wake reason: XHC 30/06/2014 06:45:47.000 kernel[0]: full wake (reason 1) 62 ms 30/06/2014 07:06:14.000 kernel[0]: Wake reason: RTC (Alarm) 30/06/2014 07:48:48.000 kernel[0]: Wake reason: RTC (Alarm) 30/06/2014 08:49:39.000 kernel[0]: Wake reason: RTC (Alarm) 30/06/2014 09:46:51.000 kernel[0]: Wake reason: RTC (Alarm) 30/06/2014 10:47:44.000 kernel[0]: Wake reason: RTC (Alarm) 30/06/2014 11:48:38.000 kernel[0]: Wake reason: RTC (Alarm) 30/06/2014 12:49:31.000 kernel[0]: Wake reason: RTC (Alarm) 30/06/2014 13:50:24.000 kernel[0]: Wake reason: RTC (Alarm) 30/06/2014 14:51:17.000 kernel[0]: Wake reason: RTC (Alarm) 30/06/2014 15:52:10.000 kernel[0]: Wake reason: RTC (Alarm) 30/06/2014 16:53:04.000 kernel[0]: Wake reason: RTC (Alarm) 30/06/2014 17:53:57.000 kernel[0]: Wake reason: RTC (Alarm) 30/06/2014 18:54:50.000 kernel[0]: Wake reason: XHC 30/06/2014 18:59:30.000 kernel[0]: full wake (reason 1) 62 ms 30/06/2014 20:24:34.000 kernel[0]: Wake reason: RTC (Alarm) 30/06/2014 21:06:42.000 kernel[0]: Wake reason: XHC 30/06/2014 21:42:11.000 kernel[0]: full wake (reason 1) 63 ms 01/07/2014 02:47:59.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 03:22:15.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 04:23:09.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 05:24:03.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 06:24:57.000 kernel[0]: Wake reason: XHC 01/07/2014 06:44:58.000 kernel[0]: full wake (reason 1) 63 ms 01/07/2014 07:08:17.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 07:47:49.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 08:48:42.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 09:49:36.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 10:50:30.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 11:51:24.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 12:52:18.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 13:53:12.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 14:54:06.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 15:55:00.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 16:55:54.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 17:56:48.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 18:57:42.000 kernel[0]: Wake reason: XHC 01/07/2014 19:44:05.000 kernel[0]: full wake (reason 1) 65 ms 01/07/2014 20:51:55.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 21:49:04.000 kernel[0]: full wake (reason 1) 83250 ms 01/07/2014 23:07:13.000 kernel[0]: Wake reason: RTC (Alarm) 01/07/2014 23:55:04.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 00:55:56.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 01:56:48.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 02:27:42.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 03:28:35.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 04:29:27.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 05:30:21.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 06:31:14.000 kernel[0]: Wake reason: XHC 02/07/2014 06:51:37.000 kernel[0]: full wake (reason 1) 60 ms 02/07/2014 07:07:53.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 07:54:55.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 08:55:47.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 09:52:45.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 10:53:37.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 11:54:30.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 12:55:24.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 13:56:19.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 14:57:12.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 15:58:05.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 16:58:59.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 17:59:52.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 19:00:45.000 kernel[0]: Wake reason: RTC (Alarm) 02/07/2014 20:01:37.000 kernel[0]: Wake reason: XHC 02/07/2014 20:33:21.000 kernel[0]: full wake (reason 1) 61 ms Link to comment Share on other sites More sharing options...
TomHsiung Posted May 22, 2015 Author Share Posted May 22, 2015 I think the issue has been figured out. I only made these three changes to my hack, 1.check the clover option of AppleRTC, 2.change the smbios from iMac14,2 to MacBook Pro 11,2, 3.re-patch the SSDTs for native power management and 9 series LPC. below is the result. 5/22/15 1:19:34.000 AM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 2:20:46.000 AM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 3:21:38.000 AM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 4:22:30.000 AM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 5:23:22.000 AM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 6:24:14.000 AM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 7:25:06.000 AM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 8:25:58.000 AM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 9:26:50.000 AM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 9:35:23.000 AM kernel[0]: Wake reason: XHC 5/22/15 9:35:23.000 AM kernel[0]: full wake promotion (reason 1) 29 ms 5/22/15 12:28:54.000 PM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 1:29:46.000 PM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 2:30:58.000 PM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 3:31:50.000 PM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 4:32:42.000 PM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 5:33:34.000 PM kernel[0]: Wake reason: RTC (Alarm) 5/22/15 5:51:38.000 PM kernel[0]: Wake reason: XHC 5/22/15 5:51:38.000 PM kernel[0]: full wake promotion (reason 1) 29 ms Link to comment Share on other sites More sharing options...
crusher Posted May 22, 2015 Share Posted May 22, 2015 Look this> http://www.insanelymac.com/forum/topic/300072-wake-reason-rtc-alarm-how-to-deactivate/?p=2071984 I fix like this!!! 1 Link to comment Share on other sites More sharing options...
