i-NG

ASUS P5Q PRO e Realtek Audio ALC1200

Recommended Posts

Ho una P5Q pro ed ho installato la kext AppleHDA.kext per la Realtek ALC1200 versione 1063 (vedi allegato) e funziona per 2 casse.

Ora volevo abilitare il 7.1 surround della Creative ma da Configurazione Midi Audio non mi permette di scegliere ne 5.1 ne 7.1...

C'è un modo per abilitare la piena funzionalità della scheda audio integrata???



Grazie mille

ALC1200_1063.zip

Share this post


Link to post
Share on other sites
Advertisement

Allora ho seguito la guida, ho installato le kext e funziona il 2.0.

Ho riseguito la guida, abilitato HDA dal dsdt.aml e aggiornato tramite terminale ma il risultato non cambia.



Share this post


Link to post
Share on other sites

Ricapitolando:

- ho scaricato questo file [ LINK ] ALC1200+HDA

- ho rimosso AppleHDA.kext da S/L/E (system/library/extensions)

- ho installato AppleHDA.kext modificata tramite KEXTWIZARD

- ho creato e modificato dsdt.aml del mio bios inserendo la modifica in

SCOPE _SB >

Device PCI0 >

Device HDEF

- ho digitato sudo perl -pi -e 's|\x85\x08\xec\x10|\x88\x08\xec\x10|g' /System/Library/Extensions/AppleHDA.kext/Contents/MacOS/AppleHDA

da terminale

- ho riavviato ma ancora non funziona... -.-' in compenso lo spegnimento lo fa perfetto (e prima non lo faceva così)

Share this post


Link to post
Share on other sites

Non devi eliminare Applehda.kext

Hai possibilita' di recuperarlo e installarlo in S/L/E

La modifica al dsdt ho letto che l'hai fatta

Allora scarica HDA Wizard aprilo vedrai ALC1200 con i tre file da patchare

Devi inserire i tre file che ti indica HDA Wizard che sarebbero quelli di Applehda.kext

Finito devi da terminale patchare con il comando che ti ho passato

Riavvia

Share this post


Link to post
Share on other sites
