Realtek ALC1200 ICH10 working kext on Yosemite 10.10 from 10.6+

578 posts in this topic

Recommended Posts

Ok I think I got it! :)

Device informations:

Realtek ALC1200

00:1b.0 Audio device [0403]: Intel Corporation 82801JI (ICH10 Family) HD Audio Controller [8086:3a3e]

Device ID: 0x3a3e8086

You can find ALC1200 on:
Asus P5Q tested ok
Asus P5Q3 tested ok
Asus P5Q-EM tested ok
Asus P5Q-VM tested ok
Asus P5QL-EM tested ok
Asus P5Q-Pro tested ok
Asus P5Q-SE tested ok
Asus P5Q-SE/R tested ok
Asus P5E3 PRO tested ok
Asus P5Q-C tested ok
Asus P6T tested ok
Asus P6T-SE tested ok
Asus P5QL-PRO tested ok
Asus P6T deluxe
it's an AD2000b!
Asus M3A78-EM it's an ALC888!
Asus P5N7A-VMtested ok
Asus P5QL-E tested ok
Asus M3N78-EM tested ok
Asus M3A-H/HDMI
Asus M3A78-T
Asus M3A78 PRO
Asus P2-M3A3200
Asus M3N78-EM
Asus P2-M3A3200
Gygabyte GA-EP43-S3L tested ok
Gygabyte GA-EP43-DS3L tested ok
MSI P45 NEO3-FR tested ok
MSI P43 tested ok

GA-945GCMX-S2 tested ok



Please signal errors, and missing motherboard (or laptop??) models ;)

==================================================


Howto install:
- choose and download kexts pack for ALC1200
- remove VoodooHDA ALCinjector.kext AppleHDA.kext (don't remove this if you're installing legacy version) ALC1200fix.kext and any audio kext you could have installed in /Extra or in /System/Library/Extensions
- unpack the zip file
- run kexthelper
- install kexts
- reboot


Obviously backup kexts you need.

====Q/A====
Q: What happens when I commit an update, for example from 10.6.1 to 10.6.2?
A: You must reinstall those hacked kexts, because the update overwrite the vanilla hacked applehda kexts.
Should even happens that the update doesn't overwrite the old applehda kext driver, so in this case, you don't need to reinstall.

Q: I'm experiencing pop sound, how can I solve this?
A: Try setting your hack as MacPro3,1 in /Extra/smbios.plist

===========

==================== MAVERICKS 10.9 AND MOUNTAIN LION 10.8 ==========================
Only DSDT method.

ALC1200_lm_108.zip
- edit DSDT pointing to 12 (hex 0C) layout ID, as on the HDEF text file attached
- install AppleHDA.kext attached
- cache rebuild
- reboot

;)

this is from my dsdt (Asus P5Q with E8400 and 4GB ram) so you can understand where you have to put the hdef code. DSDTEditor is recommended. Edit your DSDT, don't use mine.
dsdt.zip

these are the xmls needed for our ALC1200 to work right
layout_and_platforms.zip

==================== MAVERICKS 10.9 AND MOUNTAIN LION 10.8 ==========================

==================== SNOW LEOPARD and LION ==========================
**First method**: with DSDT Injection, patched AppleHDA, and NO HDAenabler attached.
AppleHDA_ALC1200_HDEF.zipremove AppleHDA.kext from /S/L/E and install this after dsdt edit.
HDEF code is attached in the zip pack, put the HDEF code in:
- SCOPE _SB
-- Device PCI0
--- Device HDEF

**Second method**: easier, no quality differences: with HDAEnabler and no DSDT editing.
[latest] ==> ALC1200 for Lion 10.7 and Snow Leopard 10.6.3, 10.6.4, 10.6.5
ALC1200_1063.zip
==================================================

older 10.6x versions:
- SL 10.6.2 modded kexts
ALC1200_1062.zip
- Snow Leopard 10.6.0 and above ALC1200 audio kext:
ALC1200_106.zip

==========OLD STUFF==========
ALC1200 driver for 10.5.x :
I think latest ALC1200_SLIM version could be considered "final", I'm running 10.5.6 and I'm working on this OSx version.
For previous OSx version you can try installing only the ALC1200fix and the HDAEnabler from ALC1200_1056LINEIN version and see if that works.
The other ALC1200 kext versions out on the forum are old and I think can even cause some shutdown/reboot issue.
This driver doesn't work with ALCinjector.

- SPDIF coaxial Digital Out working
- Headphone working
- Line in is working only in the slim and line-in version, read notes down this post

-----------

Works on 10.5.7, just download and reinstall the driver.
Choose driver version, I think best choice is the slim version:
1. Update (4th june 2009) slim version from 10.5.7 applehda with: green line out, headphones, rear mic, line in and spdif out
I removed not needed verbs for multiple channel output (I don't need them)
ALC1200_1057_SLIM.zip 4th june 2009 10.5.7 version [latest]

----
ALC1200_SLIM.zip[/b] 19th april 2009 10.5.6 version (discontinued)
2. Normal version with no line-in, you can switch between front/rear mic without any trouble
ALC1200_1056.zip

3. This is a beta version with all three input working, line-in, front mic and rear mic, front-mic has some trouble :P
This version works but if you switch between inputs, front mic stops working (only for that session obviously, if you reboot it works). This happens because ALC1200 has 1 digital mixer node for 2 channel (linein and front mic) instead of one, so if you come back from line-in input, to front mic, front mic stops working.
At the moment I would think this driver can't manage thing like this, so I don't know if we could have a better driver than this.
Anyway I wanted a working line in and if you select this and use it, that works, so if you need line-in you should use this version. ;)

Update (14th april 2009) with RCA spdif in "about this mac"


Update (17th april 2009) removed ALC1200fix.kext from the pack

If you're updating your driver, in order to install this, remove ALC1200fix.kext from your extension folder, then install this with kexthelper.
Now in sound preference there's no (useless) "Internal speaker" "Built in" for input and output.

==================================================

Thanks the whole forum, especially this thread, TheKing and Taruga ;)
Removed verbs they're too large.

This is how looks like About this mac:

You're lucky,
enjoy it!!
:)

Share this post


Link to post
Share on other sites
Advertisement

The main difference is that ALCinjector is not needed, so you're running a clean vanilla AppleHDA kext from latest 10.5.6 update just modded for ALC1200.

On the other hand this driver has potential to be fully working. Line-in could be on the to-do-list, I've not so many time to spend, but I'll try.

Share this post


Link to post
Share on other sites

marionez



thanks this solved my restart, shutdown and sleep issues on my p5q em. sleep is working perfect and still testing the restart shutdown. audio works good. everything on the motherboard works (except the x4500 graphics, got a cheap 9500 GT)







Thank you for taking the time and sharing!!

Share this post


Link to post
Share on other sites

Oh my ... marionez!

I love you!

Woooozaaa... I could jump around in circles!

I have a 100% working PC now!



This solved theshutdown issue!



Wohooo

Share this post


Link to post
Share on other sites
Howto install:

- remove ALCinjector.kext AppleHDA.kext and his friends from /System/Library/Extension

- remove /System/Library/Extension.mkext (not needed at all)

- unpack the zip file

- run kexthelper

- install kexts

- reboot

did anyone try to install on /Extra/Extensions?



this solved my restart, shutdown and sleep issues on my p5q em. sleep is working perfect and still testing the restart shutdown. audio works good. everything on the motherboard works (except the x4500 graphics, got a cheap 9500 GT)



weird...



i got errors about HDAEnabler not loading/duplicate, never had sleep issues tho



P5Q-EM

Core2Quad Q6600

4GB RAM

NVIDIA GeForce 8800GT 512MB



Mustang Sally, (since we have the same mobo), how do you install the custom kexts?



/Extra/Extensions to keep your system vanilla?

or in /System/Library/Extension?

Share this post


Link to post
Share on other sites

Kexthelper install kexts in /System/Library/Extension remove those audio kexts you installed on the other thread in /Extra/Extensions ;)



Happy to see that works :)

Share this post


Link to post
Share on other sites

I thought you should all know that Marionez' kext for the ALC1200 kext is a twofer (two for one). Not only does it work perfect, near as I can tell, but it also dramatically improved the sleep function. The old sleep fix seemed to simply kill the machine immediately whereas now it actually seems to go to sleep properly. My Hackintosh light even blinks to show it is in sleep mode, which it did not with the other 'fix'.



Nice work marionez!!!!!!!!!



By the way Marionez, my network won't come back up after sleep. Do you know of any vanilla fix for this that does not involve fixed IPs?



Thanks and keep on rockin!

Share this post


Link to post
Share on other sites
Kexthelper install kexts in /System/Library/Extension remove those audio kexts you installed on the other thread in /Extra/Extensions :blink:

kexthelper sure does put them in /System/Library/Extensions, i just wondered if there's a way to stay vanilla



anyway, it seems that your pack needs to reside in /System/Library/Extensions



i tried running it from /Extra/Extensions with vanilla kexts @ /System/Library/Extensions and it'd barf out several errors, ending up in sound not working



---

confirming that it also works with Asus P5Q-EM:



on a fresh vanilla install, removing the original AppleHDA.kext and installing marionez 3-kext pack with kexthelper, looks like it's working ok





---



by inspecting the logs i see that it still complains @ boot time, though it does work once logged-in:

11/04/09 7:53:50 PM	kernel	Class "HDAEnabler" is duplicate
11/04/09 7:53:50 PM	kextd[18]	kmod_control/start failed for com.kext.HDAEnabler; destroying kmod
11/04/09 7:53:50 PM	kernel	Duplicate class
11/04/09 7:53:50 PM	kextd[18]	a link/load error occured for kernel extension /System/Library/Extensions/HDAEnabler.kext



again this is a vanilla install so i find it really weird since there's only one instance of HDAEnabler



(no nagging from me, just thought to give some feedback :) )

Share this post


Link to post
Share on other sites

You're right there's a duplicate of HDAenabler! I'm going to update the #1 post kext pack



I even attached a line-in version, is not working very well, but it could be a good beta version, there's some trouble switching between inputs. I think I set a wrong mixer node, but I'll work on it later.



http://www.insanelymac.com/forum/index.php...st&id=48413

Share this post


Link to post
Share on other sites

Hi!



I have new idea for Realtek 1200 audio driver.



Briefly:

Audio works cool with digital output, but i can't volume level up or down in preferences/sound settings.

I can't setting digital output.

In any application i can modified volume level!



I have new DTS music and iTunes play the soungs in static, this is fake!

Here is link from Apple:

support.apple.com/kb/TA47850?viewlocale=en_US





I have Logitech Z5500 sound system. In system is DTS decoder.



My discovery is with VLC i can play DTS music, but this is not elegant:)



I think with driver is a problem.

Share this post


Link to post
Share on other sites

OMG, my English is not that good, but it's quite difficult to understand what you wrote... could be even nice placing some "please" "thanks", you're not going to pay for this driver :P



The issue: Digital Out works but you can't set the volume, right?

I've never used a digital coax connection, is there a volume control? Maybe not in osx.

I would think that audio signal is sent in digital then you set the volume on your audio system.

But this could be a wrong though, I definetely don't know about it.

I don't think it's a specific driver issue, read this: http://www.insanelymac.com/forum/index.php?showtopic=102786



I thought you should all know that Marionez' kext for the ALC1200 kext is a twofer (two for one). Not only does it work perfect, near as I can tell, but it also dramatically improved the sleep function. The old sleep fix seemed to simply kill the machine immediately whereas now it actually seems to go to sleep properly. My Hackintosh light even blinks to show it is in sleep mode, which it did not with the other 'fix'.



Nice work marionez!!!!!!!!!



By the way Marionez, my network won't come back up after sleep. Do you know of any vanilla fix for this that does not involve fixed IPs?



Thanks and keep on rockin!



Great, click on ATL1E link in my signature and download latest version, this works even after sleep :(

Share this post


Link to post
Share on other sites

the new audio driver works for my p5q-pro!



it completely solve my shut down issue, because, when I did my install I did install every new driver one by one and noted that that was the old alc driver cause the shutdone issue! so glad to have 100% worked

Q9450-8g 800 ddr2-ATI 4870-Vertex system.

Share this post


Link to post
Share on other sites

Everythings work fine with new ALC1200_1056 package!

Realy nice work Marionez :P



The digital output work quite perfect.

I will ask little things:



With QuickTime and VLC work DTS or AC3 :thumbsup_anim:

But with iTunes work not the DTS, only static sound coms out.

Have you got a idea for this problem?



Nice work the new AttansicL1 driver. After sleep works fine, but sleep don't work only 2 sec.

Share this post


Link to post
Share on other sites

Fecso I started mixer on windows and I confirm that there's no SPDIF volume available.

About iTunes and dts track I can't help, I hope some other could, but maybe this is not the right thread.



About line in: This version works but if you switch between inputs, front mic stops working (only for that session obviously, if you reboot it works). The problem is that in ALC1200 there's one digital mixer node for 2 channel (linein front mic) instead of one, so if you come back from line-in choose to front mic, front mic stop working.

At the moment I would think this driver can't manage thing like this, so I don't know if we could have a better driver than this.

Anyway I repeat I wanted a working line in and if you select this and use it, that works, so if you need line-in you should use this version. :P

Share this post


Link to post
Share on other sites
Fecso I started mixer on windows and I confirm that there's no SPDIF volume available.

About iTunes and dts track I can't help, I hope some other could, but maybe this is not the right thread.



Potentially stupid observation (in that I am stupid):



Can you control digital volume at the source? I have some high end audio gear and volume can only be controlled at the amp because there is no way to 'reduce' a digital signal, it is either on or off. It's not like analog.



Again I am not sure of how it works on pc's because I don't have gear to test.









Great, click on ATL1E link in my signature and download latest version, this works even after sleep :P



Network now comes back after sleep, absolutely OUTSTANDING and a big THANK YOU!!!!



It may have even fixed the random shut down issue. I was able to recreate the shut down problem by doing sleep, wake up, shut down. Now it seems to work fine but I will confirm after some more tests.



Cheers!

Share this post


Link to post
Share on other sites

Atta great work, marionez! Kudos to you! I almost given hope for my sounds and line-in. Now I'm happier than before! :)

Share this post


Link to post
Share on other sites

Thanks a million Marionez for your excellent work & effort for the new audio driver! it really makes everyone of us happy! ;)



However, anyone of you confirmed that 8 channel audio works?

Share this post


Link to post
Share on other sites

Great ;)

About 8 channel I think this wouldn't work, this is an AppleHDA patched and I don't know about any iMac with 8 channel output. Maybe the best (and quite expensive) way to have a splitted audio is the spdif out in a spdif sound system.

Consider with this driver you have to choose one output between those you have, 8 channel it's very different.

Anyway perhaps someone could help this and maybe feedback about it.



update: these above was wrong, read this: http://www.insanelymac.com/forum/index.php?showtopic=87336



I tested VodooHDA driver and is not working, there's no input working.

Share this post


Link to post
Share on other sites

Oh sorry there is an issue



from my P5Q-Pro mobo, it comes with the coaxial SPDIF output so, it is not a optical digital output. So I can;t get the digital out functioning as the kext I guess was being modified to with optical output, is that any chance to create a version that suit for ALC2000 with coaxial digital output interface?



thanks

Share this post


Link to post
Share on other sites
This ALC1200 can't suite with ALC2000, that has different codec dump.

If you want to give me a codec dump we can try to create a driver that suite with ALC2000: http://www.insanelymac.com/forum/lofiversi...php/t46378.html



Don't care about what is written in about this mac :P





sorry That was a typo, should be ALC1200, i have p5q pro as wel



not sure why mine one is not working....



thanks for your help,

Share this post


Link to post
Share on other sites

Yes it works, in this moment I'm playing mp3 with iTunes on the Digital Output (you've to choose this in system preferences - sound preferences - output), connected the ALC1200 spdif out on my external usb audio card spdif in, and with garageband I'm monitoring the usb audio card output, quite difficult to explain, but works very well... :P

Share this post


Link to post
Share on other sites

Create an account or sign in to comment

You need to be a member in order to leave a comment

Create an account

Sign up for a new account in our community. It's easy!

Register a new account

Sign in

Already have an account? Sign in here.

Sign In Now

  • Recently Browsing   0 members

    No registered users viewing this page.

  • Similar Content

    • By MaLd0n
      Nehalem, SandyBridge, IvyBridge, Haswell, Broadwell     Skylake, Kabylake and Coffeelake is here http://www.insanelymac.com/forum/topic/321872-guide-sierra-on-gigabyte-mobos-serie-200-kabylake-dsdt/   First...   ***Update bios to last available version!***   If you need a full patched DSDT...  -Extract tables with F4 key in Clover boot screen! -Run it and send me files! RunMe.app   Installation   --Create a bootable copy of macOS Sierra Check out the link http://www.insanelymac.com/forum/files/file/559-flash-drive-maker/   --Create a bootable copy of macOS HighSierra Check out the link http://diskmakerx.com/   --Install Clover in USB stick https://sourceforge.net/projects/cloverefiboot/files/Installer/   --Replace with my Clover folder CLOVER Install.zip   --Install Sierra/High Sierra and boot into system!   Post Installation --Install Clover and replace with my folder CLOVER Post Install.zip   --Reboot and activate video!   Bingo!   Now you need a fine tune! DSDT time!   --DSDT   Patches -FIX ERRORS AND WARNINGS -HPET -SATA -DMAC -SLPB -DARWIN -LPC -XHCI -PLUGIN TYPE -XXXX to HDEF -HDEF -RTC -IRQs -SBUS -BUS1 -MCHC -ALS0 -SHUTDOWN -LAN -USBX -PMCR -EC -PNLF -HDMI

      --Power Management
      - 1 Generation Intel Processors, use Generate P and C States in config.plist
      - 2 and 3 Generations Intel Processors, Generate SSDT with Piker script and drop CpuPm and Cpu0Ist SSDTs
      ssdtPRGen.command.zip
      Credits-https://github.com/Piker-Alpha/ssdtPRGen.sh
      - 4 Generation+ Intel Processors, use PluginType=1 in DSDT, SSDT or Clover config.plist

      for check Power, Frequency, Temperature and Utilization, use it
      Install Intel Power Gadget.pkg.zip

      --Brightness
      Install .app, select the required permission and reboot. Work in F1 / F2 keys!
      NativeDisplayBrightness.app.zip


      https://github.com/Bensge/NativeDisplayBrightness/releases
      *in some cases .app don't work, check patches in config.plist inside Clover folder Post Install

      --Clover

      https://sourceforge.net/projects/cloverefiboot/files/Installer/

      --AUDIO

      Use DSDT + AppleAlc

      --install Lan driver by Mieze
        -Atheros http://www.insanelymac.com/forum/files/file/313-atherose2200ethernet/   -Intel http://www.insanelymac.com/forum/files/file/396-intelmausiethernet/   -Realtek http://www.insanelymac.com/forum/files/file/88-realtekrtl8111-binary/   --Links   -FakeSMC https://bitbucket.org/RehabMan/os-x-fakesmc-kozlek   -Audio https://github.com/vit9696/AppleALC http://www.insanelymac.com/forum/topic/314406-voodoohda-289/   -USB https://bitbucket.org/RehabMan/os-x-usb-inject-all/downloads   It's time to Rock   -Credits and thanks to the old and new people in the community who developed patches, kexts and bootloaders!   Apple, Slice, Kabyl, usr-sse2, jadran, Blackosx, dmazar, STLVNUB, pcj, apianti, JrCs, pene, FrodoKenny, skoczy, ycr.ru, Oscar09, xsmile, SoThOr, RehabMan, Download-Fritz, Zenit432, cecekpawon, Intel, Oracle, Chameleon Team, crazybirdy, Mieze, Mirone, Oldnapalm, netkas, Elconiglio, artut-pt, ErmaC, Pavo, Toleda, Master Chief and family, bcc9, The King, PMheart, Sherlocks, Micky1979, vit9696, vandroiy2013, Voodoo Team, Pike R. Alpha, lvs1974, Austere.J, CVad and many, many, many others!   We're all here to have fun and learn from each other!
    • By MaLd0n
      First... If you need DSDT edits... -Extract tables with F4 key in Clover boot screen! -Run it and send me files! RunMe.app   Installation --Create a bootable copy of El Capitan and Sierra Check out the link http://www.insanelymac.com/forum/files/file/559-flash-drive-maker/   --Create a bootable copy of macOS HighSierra Check out the link http://diskmakerx.com/   --Install Clover in USB stick https://sourceforge.net/projects/cloverefiboot/files/Installer/   --Replace with my Clover folder CLOVER Install.zip   --Install EL Capitan / Sierra / High Sierra and boot into system! for Sierra/High Sierra you need a Processor with SSE4.1 instruction   Post Installation --Install Clover and replace with my folder CLOVER Post Install.zip   --Reboot and activate video!   Bingo! Now you need a fine tune! DSDT Time! -Post your full Clover folder with original tables in Origin folder(Extract with F4 in Clover boot screen) and tell me what your hardware! -Post Ioreg, extract with Ioreg Explorer http://www.insanelymac.com/forum/index.php?app=core&module=attach&section=attach&attach_id=222606 -Run it, post files generate in your desktop http://www.insanelymac.com/forum/index.php?app=core&module=attach&section=attach&attach_id=222609    My DSDT GA P35-DS3 DSDT.MaLd0n LGA775.zip   Patches -FIX ERRORS AND WARNINGS -HPET -SATA -SLPB -DARWIN -LPC -HDEF -RTC -EHCI -UHCI -IRQs -SBUS -BUS1 -MCHC -ALS0 -SHUTDOWN -LAN -EC -PNLF --Native Power Management

      Use Clover, check Generate P and C States

      --Brightness
      Install .app, select the required permission and reboot. Work in F1 / F2 keys!
      NativeDisplayBrightness.app.zip


      https://github.com/Bensge/NativeDisplayBrightness/releases
      *in some cases .app don't work, check patches in config.plist inside Clover folder Post Install

      --AUDIO

      Device HDEF + AppleAlc + Lilu

      --install Lan driver by Mieze
        -Atheros http://www.insanelymac.com/forum/files/file/313-atherose2200ethernet/   -Intel http://www.insanelymac.com/forum/files/file/396-intelmausiethernet/   -Realtek http://www.insanelymac.com/forum/files/file/88-realtekrtl8111-binary/   --Links   -FakeSMC https://bitbucket.org/RehabMan/os-x-fakesmc-kozlek   -Audio https://github.com/vit9696/AppleALC http://www.insanelymac.com/forum/topic/293863-applehda-patch-requests/   -Credits and thanks to the old and new people in the community who developed patches, kexts and bootloaders!   Slice, Kabyl, usr-sse2, jadran, Blackosx, dmazar, STLVNUB, pcj, apianti, JrCs, pene, FrodoKenny, skoczy, ycr.ru, Oscar09, xsmile, SoThOr, RehabMan, Download-Fritz, Zenit432, cecekpawon, Intel, Apple, Oracle, Chameleon Team, crazybirdy, Mieze, Mirone, Oldnapalm, netkas, Elconiglio, artut-pt, ErmaC, Pavo, Toleda, Master Chief and family, bcc9, The King, PMheart, Sherlocks, Micky1979, vit9696, vandroiy2013, Voodoo Team, Pike R. Alpha, lvs1974, Austere.J, CVad and many, many, many others!   We're all here to have fun and learn from each other!   ENJOY!
    • By Mieze
      Being asked to add support for Realtek's Fast Ethernet PCIe NICs to my RTL8111 driver I got tired of answering the same old question again and again so that I finally decided to write a separate driver for these chips and to make a few of you guys and gals happy.

      As of now the driver supports the following members the RTL810X Fast Ethernet family:
      RTL8101E RTL8102E RTL8103E RTL8401E RTL8105E RTL8402 RTL8106E RTL8106EUS RTL8107E Here is a list of the driver's basic features:
      Supports Sierra (maybe El Capitan). 64 bit architecture only. Support for multisegment packets relieving the network stack of unnecessary copy operations when assembling packets for transmission. No-copy receive and transmit. Only small packets are copied on reception because creating a copy is more efficient than allocating a new buffer. TCP, UDP and IPv4 checksum offload (receive and transmit). TCP segmentation offload under IPv4. Support for TCP/IPv6 and UDP/IPv6 checksum offload. Supports Wake on LAN. Support for Energy Efficient Ethernet (EEE) which can be disabled by setting enableEEE to NO in the drivers Info.plist without rebuild. The default is YES. The driver is published under GPLv2. Built using Xcode 4.6.3.
      Changelog Version 2.0.1 (2018-05-10): Fixes a problem with retrieval of the permanent MAC address on some chips. Version 2.0.0 (2017-04-04): Uses Apple's private driver interface introduced with 10.8. Adds support for the RTL8107E. Supports packet scheduling with QFQ. Adds support for flow control and EEE. Version 1.0.0 (2014-05-24): First offical release.     Installation   Before you install the driver you have to remove any installed driver for RTL810X. Goto /S/L/E and delete the old driver. Recreate the kernel cache. Open System Preferences and delete the corresponding network interface, e. g. en0. If you forget this step you might experience strange problems with certain Apple domains, iTunes and iCloud later. Install the new driver and recreate the kernel cache. Reboot Open System Preferences again, select Network and check if the new network interface has been created automatically or create it manually now. Configure the interface.     Troubleshooting Make sure you have followed the installation instructions especially when you have issues with certain domains while the others are working fine. Use the debug version to collect log data when trying to track down problems. The kernel log messages can be retrieved with "grep kernel /var/log/system.log" in Terminal. Starting from Sierra use "log show --predicate "processID == 0" --debug" in order to retrieve kernel logs. Include the log data when asking for support or giving feedback. I'm an engineer, not a clairvoyant. Don't copy and paste large amounts of log data to your post. Create an archive with the log data and attach it to your post. In case you don't want to make your log data publicly accessible, contact me via PM and I will provide you a mail address to send it directly to me.  Check your BIOS settings. You might want to disable Network Boot and the UEFI Network Stack as these can interfere with the driver. Double check that you have removed any other Realtek kext from your system because they could prevent the driver from working properly. Delete the following files: /Library/Preferences/SystemConfiguration/NetworkInterfaces.plist /Library/Preferences/SystemConfiguration/preferences.plist Verify your bootloader configuration, in particular the kernel flags. Avoid using npci=0x2000 or npci=0x3000.  In Terminal run netstat -s in order to display network statistics. Carefully examine the data for any unusual activity like a high number of packets with bad IP header checksums, etc. In case auto-configuration of the link layer connection doesn't work it might be necessary to select the medium manually in System Preferences under Network for the interface. Use Wireshark to create a packet dump in order to collect diagnostic information. Keep in mind that there are many manufacturers of network equipment. Although Ethernet is an IEEE standard, different implementations may show different behavior causing incompatibilities. In case you are having trouble try a different switch or a different cable.
      Getting the driver
      There is a prebuilt binary in the Download section of this site: http://www.insanelymac.com/forum/files/file/259-realtekrtl8100-binary/ The source code can be found on Github: https://github.com/Mieze/RealtekRTL8100   Mieze
    • By LarryKu
      Hi everyone,
      I am new, I hope I am posting in the correct forum.
      My specs:
      Processor: Core i5 6500 Skylake 3.2ghz
      Mobo: Gigabyte h170-d3h
      M2SSD: WD Black 256gb PCIe (Mac OSx)
      SSD: Samsung 860 Evo (WIndows 10)
      HDD: WD Blue 1TB
      GPU: Radeon RX 480
      Monitor: BenQ RL2460 24"


      I was able to install High Sierra on a new m2 drive, that I added to the above configuration with windows 10 already installed.
      I had a few issues during install, including the monitor turning off at boot screen.

      Unfortunately, this persists even now. It turns off at about 60% of the progress bar, and to turn it on again I have to unplug/plug back my hdmi.
      Additionally, while all of the usb ports worked during install and while running it out of the clover I had on the usb stick, only the rear ones appear to work now.
      The audio doesn't work either, though I added the correct patch according to my mobo

      Lastly, my other drives are not recognized in the bios anymore. They run fine from boot override but they don't show up in the boot priority (while multiple entries of mac OS do, and they seem to increase in number at every reboot)

      Thanks in advance for the help
    • By ITzTravelInTime
      KX AUDIO DRIVER MOD

      Hi guys i am a small developer, i really like to use my sound blaster cards on my machines and i love also coding, so when i find the source code for the kx audio driver on git hub and then Eugene, the creator of kx audio driver decided to no longer maintain the project, i decided to start working on a mod of this driver.

      With my mod, created starting from the sources of the last version of kx audio driver, and also by using apple developer documentation for pci and audio drivers as reference, i am working to achieve 2 things mainly: get all the cards supported by the driver to work with all the recent versions os macOS and add support for other cards that are not officially supported by the driver that works or could, but needs to be more properly supported.

      This driver is made to support cards based on the E-mu 10k1, 10k2 and similars (like what is used by audigy rx and audigy 4 cards).

      Supported cards are:

       - most of the sound blaster live!, live! 5.1 and live! 5.1 digital series
       - sound blaster 512
       - sound blaster 256
       - other creative and e-mu sound cards based on the 10k1 chip (cards with the ES1370/ES1371/ES1372/ES1373 chips are not supported)
       - sound blaster Audigy series (1 st gen)
       - sound blaster Audigy 2  and audigy 2 zs series
       - E-MU cards based on the 10k2 sound chip
       - Some Audigy 4 cards (SB0610 only) and the audigy 4 pro
       - Sound blaster Audigy RX (sb0155)
       - other creative and e-mu cards based on the (10k2, 10k2,5 and CA10300 based cards)

      NOT supported cards:

       - Any ISA Sound card
       - ES1370/ES1371/ES1372/ES1373 based sound cards
       - CMI8738/CMI8788 based cards
       - Any CA0106 based card and cards with similar architectures (like sound blaster live! 24 bit, sound blaster audigy SE SB0570, audigy LS and similars, but audigy SA is supported)
       - Any sound blaster x-fi (some of them works on macOS using a modified version of voodoo hda)
       - Any sound blaster recon3D
       - Any sound blaster Z/ZS/ZX and similar series
       - Any sound blaster AE5 series

      In the time being the things i have modded or added with this mod are:

      - increased the simple buffer frames number with different values for emu10k1 based cards and emu10k2 based cards (including recent audigy 4 and rx) to reduce and all the audio cracking issues and possibly fixing all of them on a lot of cards

      - added a more proper support for the pci express sound blaster audigy rx (which basically is an audigy 4 with a pcie bridge chip)

      - added more fancy names for the cards in the settings and other menus (so the name will be, for example, SB live! 5.1 SB0060 instead of kx SB0060 [e880] witch was shown in the original driver)

      - added support to sample rate chaning and added lots of sample rates (from 8 khz to 176,4 khz) to accomodate any possible usecase (note that 10k1 sound cards are limited up to 48khz sample rate, and 10k2 based cards for now are limited up to 176,4 khz and because of issues getting 192 khz to work, for now the driver goes up to 176,4 khz for supported cards)

      - added boot args to manage the driver:

      Boot args to use with the kx audio driver mod: -kx_disable or -kxdisable or -kxoff This will prevent the driver from doing any initialization work, so the driver is basically disabled, use it to boot your ssytem in case the driver is giving you issues and kernel panics while you are trying to boot/using your system, so you are able to remove this driver or replace it with another version of it or to do some truble shooting. -kx_debug or -kxdebug or -kxspec Will show more debug info about the card, mainly the i/o port address and the kind of bus that it uses -kx_exp_deb or -kx_beta or -kxbeta Will enable experimental and probably not working or unstable features like showing inputs for the card or 192 khz sampling rate, use it only for testing and debug purposes, this may likely cause instability and problems in the everyday usage! Use it at your own risk! -kx_original or -kxoriginal This will basically turn off almost all the mods of this mod, so the driver will come to work as it was before modding it, this can be usefoul as a "safe mode" like feture to have a working driver in case of problems with features of the mod, so using this means no crsking issues improvements, only 48 khz sample rate and only features of the non-modded kx audio driver for mac os x
      - created a script file to use with the driver for debug and also installer replacement, it can be also used to unload and reload, replacement of the driver without rebooting

      What i'd like to implement but i don't know how to do:

       - I'd like mainly to add a more proper support to the pci bridge chip of the audigy rx,

       - have audio inputs working,

       - fix the support when using more than one card, to get all the cards shown in the settings and other menus,

       - have the gameport/gameport midi port of older cards to be used in mac os as a midi in/out

      If other developers would like to join and help me, you can, and also an hand from other people with testing and feedback will be nice.

      link for the kext only (if you have clover put it in [your clover efi folder]/clover/kexts/[your macOS version]/ so it will not be deleted when updating macOS):
               - download from the downloads section:          kX Audio Driver Mod by ITzTravelInTime 1.01                                                                                    - external download:                                      https://dl.dropboxus...Driver.kext.zip   link for the installer pack (the best way to install it, but you have to reinstall it when you upgrade macOS, remeber to fix kext permitions and rebuild the kernelcache if you want to remove the kext from it's install directory without using the unistall feature of the provvided script):              - download:                                                   https://dl.dropboxus...aller pack.zip   Source code from Git Hub:          -  github repo:                                               https://github.com/ITzTravelInTime/kx-audio-driver   NOTE: Some system because of some problems with the HPET may need to use FixHPET in clover and to install the kext in /System/Library/Extensions






×
